Engine Timing Tool Kit
Fiat 1.0 & 1.3L Petrol
Part No. 8557
Instructions
www.lasertools.co.uk
Page 2
Introduction
Instructions
Developed to allow the user to lock the latest generation 1.0L & 1.3L Fiat petrol engines in their
timed position when removing and refitting the timing chain, cylinder head or camshafts.
• Applications: Fiat 500X (from 2018), Tipo (from 2020), Jeep Renegade (from 2018),
Compass (from 2020)
• Engine code applications: 1.0L 55282151, 1.3L 55282328.
• Equivalent to OEM tools: 2063500090, 206300090, 2064000090.
• Includes the crankshaft pulley holding tool.
• Use in accordance with manufacturer’s instructions.
Components
Ref. Code OEM Ref. Description
A C1009 2063500090 Camshaft Alignment Tool
B C1010 2063600090 Flywheel Locking Pin
C C1011 2064000090 Crankshaft Pulley Holding Tool
The following instructions are for guidance only; please refer to OEM derived data
such as the vehicle manufacturer’s own data or Autodata. The use of this puller tool
is purely down to the user’s discretion and Laser Tools cannot be held responsible for
any damage caused whatsoever.
Preparation:
• Set engine to TDC on number 1 Cylinder
• Remove the brake vacuum pump.
Component Descriptions:
Component A = Camshaft
Alignment Tool – with the engine
set at TDC on number 1 cylinder fit
the Component (A) to the camshaft
in place of the brake vacuum
pump. See figure 1.
Component B =
Flywheel Locking Pin - Fit
the crankshaft locking pin
as shown in figure 2 from
underneath the vehicle.
FIG.2
FIG.1
Applications
Make Model Year Engine Codes
Fiat
Jeep
500X From 2018
Tipo From 2020
Renegade From 2018
Compass From 2020
www.lasertools.co.uk www.lasertools.co.uk
1,0
55282151
1,3
55282328
Component C =
Crankshaft pulley Holding
Tool – Fit component (C)
as shown in figure 3 and
remove the crankshaft
pulley fixing bolt.
WARNING: The
crankshaft pulley bolt
has a LH thread.
ALWAYS REPLACE THE
PULLEY BOLT WITH NEW.
FIG.3
32
