STARTSTATUS
MARK STOP
CHILLED GOODS
EasyLog
QUICK START GUIDE
STARTSTAT US
MARK STOP
CHILLED GOODS
EasyLog
STARTSTATU S
MARK STOP
AMBIENT PHARMA
EasyLog
EL-PDF-1 Series
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 -
TestEquipmentDepot.com
1. Your new logger comes ready to go.
Simply press and hold the
button until the green LED lights up to start logging.
Push to start/stopStatus mark
Preset high
and low alarm
levels
Status LEDs
2. Now place your logger in the location you want to monitor.
Once logging, pressing the
status. It will also add a marker to the data to show that you have checked it.
button will light up an LED to give a quick indication of the
No alarms will be triggered in the rst 30 minutes to allow the logger to settle at the
monitored conditions.
Red + Green single ash
Logger is ready to start new logging session
Green single ash
The data logger is currently logging
No alarm has been triggered
Red single ash
The data logger is currently logging
An alarm has been triggered!
Green double ash
The data logger’s memory is full or the logger has been
stopped. No alarm was triggered during the session.
Red double ash
The data logger’s memory is full or the logger has been
stopped. An alarm was triggered during the session!
No LEDs ash
The data logger has a at battery
Push Start / Stop button
No action required
Check status in the PDF
Plug your logger in to a PC and download
the PDF
Plug your logger in to a PC, download the PDF
and check alarm condition
Contact your distributor for a new logger
3. When you are ready to view the recorded data on your logger, press and hold the
button to stop the current logging session. Remove the logger from the plastic sleeve and
connect it to a USB port.
4. Copy the le off the device as if it were a memory stick.
EL-PDF-1(F:)
EL-PDF-1(F:)
PDF
Example
5. Press the
button to start a new data logging session. To maintain IP67 status,
the logger must be placed in Lascar’s accessory bag, EL-CC-BAG.
Other EasyLog Cold Chain Data Loggers
ALARMS:
HIGH
8°C
LOW
2°C
CHILLED GOODS
STATUS:
EL-CC-1
Temperature
FOOD
99 Washington Street Melrose, MA 02176
Phone 781-665-1400 Toll Free
1-800-517-8431
TestEquipmentDepot.com
EL-CC-2
Temperature/Humidity
FOOD
EL-CC-2
Temperature/Humidity
PHARMACEUTICAL
Issue 1
