Page 1
Owners manual :
English
Other languages,see
www.lascal.net
81900
Lascal BuggyBoard
®
TM TM TM
,
www.buggyboard.info
Lascal BuggyBoard® is a registered
trademark created by
The BuggyBoard® is protected
by patent
,
Lascal
Page 2
Page 3
English
81520
81150
81330
81900
81320
81300
81618
81321
80371
81310/81311
81636
81602
81601
81603
81521
81600
81604
80370
81301
CONTENT BUGGYBOARD - MINI, MAXI, MAXI+
Serial Number
81340
Mini 81135 – 81139
Maxi 81610 – 81612
Maxi+81630 – 81632
Mini 81570
Maxi 81614
Mini 81400
Maxi 81613
Mini 81571
Maxi 81615
Mini 81572
Maxi 81616
Mini 81573
Maxi 81617
a
a = max . 22.5 cm / 9 in.
2. Positioning the Connectors.
Forward Backward
The Connectors can be attached facing forward
or backwards. The Connectors can be fitted onto
different shapes of tubing with a maximum
circumference of 22.5 cm (9 in.). Bend the
Strap round the tubing. Then feed the Strap
through the slot in the Connector Cover and
pull the Strap gently. Check the position of the
Connectors to be sure that
• the Arms (81300/81301) will be able to reach
the Connectors (maximum 35 cm (14 in.),
with
Extenders accessory 39 cm (15,5 in), above the
ground
).
• they are as low as possible on the stroller.
• they do not interfere with the stroller’s folding
mechanism.
• the Arms stay clear of both the braking
mechanisms and the wheels of the stroller.
3. Attaching the Connectors.
Once certain of the position of the Connectors,
loosen the Strap and fix the Friction Tape on the
uprights where the Connectors are going to be
attached. Reposition the Connector Cover, the
Friction Tape and pull the Strap tight. Secure the
Connector by turning the Connector Bolt
clockwise. Check that the stroller still folds
properly and the brakes still work properly; if
not, you may need to reposition the Connectors.
2
1
THE CONNECTORS
Friction Tape
(Detaching the Wheels)
THE WHEELS AND ARMS
1. Attaching the Wheels and the Arms.
For more details: www.buggyboard.info
Click
35 (39) cm/ 14 (15,5) in.
35 (39) cm/ 14 (15,5) in.
MINI
™
MAXI
™
English
- 4 -- 3 -
2
3
1
www.buggyboard.info
Lascal BuggyBoard
Mini, Maxi, Maxi+
Owners manual :
English
Other languages,see
www.lascal.net
Lascal BuggyBoard™ is a registered
trademark created by
Lascal
The BuggyBoard™ is protected
by patent
®
81900
Part no.
mini
81135-81139
81150
81300L/81301R
81310R/81311B
81320L/81321R
81330
81340R/81341B
81400
81520
81600
81604
81570L/81571R
81572
81573
81618
80370
80371
81521
81900
Description
Platform
Strap with Hook
Arm Left/ Arm Right
Height Adjustment Screw (Red/Blue)
Arm Support Left/Arm Support Right
Fixing Plate
Fixing Screw
Wheel
Cotter Pin
Connector Assembled
81601 Connector Cover
81602 Connector Strap
81603 Connector Bolt
Friction Tape
Susp. Arm Left/Susp. Arm Right
Susp. Spring
Susp. Rivet
Wheel Locking Cage
Extender
Extender Screw
Cotter Pin Key
User Manual
Blue Saddle/Red Saddle for Maxi+
Lid for Maxi+
maxi+
81630-81632
81150
81300L/81301R
81310R/81311B
81320L/81321R
81330
81340R/81341B
81613
81520
81600
81604
81614L/81615R
81616
81617
81618
80370
80371
81521
81900
81634B/81635R
81636
maxi
81610-81612
81150
81300L/81301R
81310R/81311B
81320L/81321R
81330
81340R/81341B
81613
81520
81600
81604
81614L/81615R
81616
81617
81618
80370
80371
81521
81900
81634/81635
Maxi+
Page 4
Page 5
Page 6
WARRANTY
Your BuggyBoard™ is warranted to be free from manufacturing defects for a period of one
year from date of purchase under normal use and in compliance with the operating
instructions. This warranty extends only to the original retail purchaser and is only valid
when supplied with proof of purchase.
We are committed to ensuring that the BuggyBoard™ is of the highest quality. The
manufacturing process is regularly checked by both internal and external (TÜV) controllers.
Samples of parts and completed products are also taken out regularly for tests in our
own testing laboratory. The BuggyBoard™ is tested and approved by according to the
relevant clauses in EN 1888:2012 Clause 6.1.1 – 6.1.5, 7.2.2.6, 17.3, 18.2 and 21.4
All components are tested and meet the standard for children products according to
REACH (EU) and CPSIA (U.S.)
Cleaning instructions: Use warm water with a soft cloth and a mild non-abrasive cleaning
fluid. All BuggyBoard™ parts and packaging are made from recyclable materials.
CLEANING AND RECYCLING
English
English
13. Extender Kit
Item no. 11310
To attach the BuggyBoard™ onto certain
stroller the ‘Extender Kit’ may be needed.
This will lengthen each Arm up to 6cm (2.4”).
The Extender Kit is included with the
BuggyBoard™.
13
EXTENDER KIT
14. Extra Connector Kit
Item no. 11340
If you want to attach the BuggyBoard™ to
another stroller/pram without having to
remove the Connectors, you may purchase an
Extra Connector Kit as a separate accessory.
Each Extra Connector Kit contains:
2 Connectors, 2 Cotter Pins, 2 Friction Tapes
and 1 Strap with Hook.
14
ACCESSORY
15. Saddle for BuggyBoard Maxi
(included for Maxi+)
Attention the child shall always sit
backwards.
The BuggyBoard Saddle is an exclusive
accessory for the BuggyBoard Maxi,
which transforms the ride-on board in to
a seat for young children.It has been carefully
designed to securely and safely clamp on
and off the board, which makes fitting easy.
No special tools are needed to fit the Saddle.
At any time, if your toddler prefers to stand
rather than sit, the Saddle simply folds down
and out of the way, without needing to
be removed.
TESTS
15
The use of any accessories with the
BuggyBoard™ that have not been
approved by the manufacturer is
not recommended.
- 10 -- 9 -
