Portable Light Tower - 1000 Watt Metal Halide - Covers 23,000 SF - Extends to 12 feet

Part #: WAL-C-1XM

Made in the USA

The WAL-C-1XM Quadpod Mini Light Tower from Larson Electronics produces 110,000 lumens of light capable of illuminating an area
49,000 square feet in size. This adjustable light tower is designed for rugged, yet portable use and is ideal for use in demanding
industrial and outdoor construction conditions.

*PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO LIGHT MASTS OR LIGHT TOWERS*

The WAL-C-1XM is a quadpod mounted mini light tower and provides 49,000 square feet of work area coverage with 110,000 lumens of light
output. This portable light tower has a removable dual light head assembly mounted on top of a four leg steel quadpod equipped with 10 inch
wheels for easy positioning of the unit from one area of the workspace to another. The light assembly on this unit produces a wide flood pattern
of light that is ideal for illuminating large workspaces and jobsites. This light is designed for heavy duty use in demanding conditions including
emergency services, mining, construction, marine and industrial operations where durability and portability is important.

Page: 1

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Click Photo to Enlarge Click Photo to Enlarge Click Photo to Enlarge

This portable light tower is comprised of a removable light assembly fitted with one metal halide lamp mounted atop a four leg tripod fabricated
from heavy duty steel. This adjustable and collapsible quadpod pod can be extended to fourteen feet and collapsed to seven feet and is locked
into position with t-handle locking pins. The unit is extended and lowered using an included hand crank cable winch equipped with a brake for
fast and safe deployment. Included solid wheels allow the operator to tilt the unit back and simply roll the entire assembly to a new location when
fully deployed. The light fixture assembly can be removed by releasing the hand knob and sliding the light and mounting bracket off of the center
support while the legs can be collapsed, aiding in deployment, storage and transport. The lamps can be easily adjusted up, down or from side to
side independently of each other and locked into position for maximum coverage of the work area.
Included with this quadpod tower is 25 feet of SOOW cord with a 5-15 straight blade plug for 120 volt configurations or a L6-30 plug for 220/240V
configurations, which combined with the full adjustability of the light heads helps provide optimal coverage of the workspace. The easy to
collapse design of this mini light tower allows users to easily break down and transport the unit yet is durable enough for any industrial or
commercial application.
The light head assembly on this tower contains one 1000 watt metal halide lamp producing 110,000 lumens. This lamps is adjustable, allowing
operators to adjust the light for maximum coverage of the workspace. An included control box containing the ballast is included and features a
built in On/off switch, line circuit protection and power indicator. This tower Operates on 120 volts, 60 hz, 1 phase power and draw 8.34 amps @
1000 watts. Also available are 240 Volt versions for use with higher voltages. Choose voltage option below when ordering.
This is a heavy duty unit designed for use in demanding conditions and for overall longevity in difficult construction environments with heavy duty
steel construction for maximum durability. We make this lighting solution in the United States. Larson Electronics tower lights are designed for
industrial, commercial, emergency response, and military applications where the operators are working in harsh, destructive environments and
the operators income or mission success are dependent on dependable, durable lighting.

Page: 2

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Specifications / Additional Information

WAL-C-1XM QuadPod Light Tower Quick Summary
Lamp Type: Metal Halide 1,100 Watt, 110,000 Lumen Light Assembly
Lighting Configuration: Flood Pattern 49,000 Square Foot Coverage
Dimensions: Adjustable Tower 7 to 14 Feet Height Adjustable Tower 7 - 14 Feet
Total Watts: 1000 watts Wheeled
Total Lumens: 110,000 25 Foot Cord
Voltage: 120 VAC 50/60Hz / 220 Optional
Amps: 18
Wiring: 25 feet SOOW Cord - 5-15 Straight Blade Plug (120V) OR L6-

30 plug (220/240V)

Mounting: Steel Square Tube Quadpod, 7-14' Adjustable Height
Weight: Tower only 33 lbs, Total 150 Lbs Special Orders- Requirements

Contact us for special requirements

Scroll Down to Purchase-

Part #: WAL-C-1XM (1672)

Toll Free: 1-800-369-6671
Intl: 1-903-498-3363
