Power Distribution System - 10KVA - (1) 480V Outlet - (6) 5-20 GFCI Outlets

Part #: MGS-480.1X100A-10K-6X120

Made in the USA.

The Larson Electronics MGS-480.1X100A-10K-6X120 heavy duty power transformer substation converts 480 VAC electrical current to
single phase 120V AC and 208Y 3P AC. This unit provides operators the ability to safely tap into and distribute 480 volt power from a
variety of sources including generators and direct grid power via six 120-volt outlets. This portable power distribution panel also
provides one 100-amp, 480V Hubbell HBL4100RW receptacle on the primary 3 phase panel.

*PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO POWER DISTRIBUTION PANELS,
TRANSFORMERS, OR SUBSTATIONS*

This portable power transformer provides a safe and reliable way for operators in industrial settings to tap into and utilize power sources
independently of the work area. This unit provides an effective power source for operators performing plant turn-a-rounds, maintenance,
equipment installations and repairs and any activities requiring an alternative to native power sources.
This power distribution converts 480VAC to 120/208Y with a 10KVA transformer. On the primary side, a 150-amp main breaker panel includes a
100amp breaker protecting a HBL4100RW 100-amp receptacle. The primary panel feeds the 10KVA 480V to 120/208Y NEMA 3R transformer,
which in turn feeds a the secondary panel. On the secondary side, a 100-amp main breaker panel includes six 20-amp breakers protecting six 5­20 GFI outlets.

Page: 1

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Click Photo to Enlarge Click Photo to Enlarge

Click Photo to Enlarge Click Photo to Enlarge

The standard frame construction is 1/4" thick, 2" square tubing frame and 1/4" steel plate floor base. This can be replaced with stainless steel,
hot dip galvanized steel, or aluminum depending on the customer’s needs for an additional cost.
Larson Electronics' Larson Electronics is a manufacturer and as such can build portable power distribution systems to your specifications.
Although we carry several models of power distribution transformers, we can deliver custom ordered units almost as quickly as our prebuilt units
If this model does not meet your needs, please contact us at 1-800-369-6671 or [e-mail] to discuss your specific
requirements.
