MegaTower 50' Pneumatic Light Mast - 21 Foot Trailer - Extends 22-58 Feet - (16) 500 Watt LED Lights

Part #: LM-50-5S-TLR-16X400LTL-LED

Made in Texas

The Larson Electronics LM-50-5S-TLR-16X400LTL-LED trailer mounted fold over 7-stage light mast provides a safe and effective way
for operators to quickly deploy the sixteen 500 watt LED light heads to elevations up to fifty feet. This pneumatic light tower folds over
for easy transportation, features a hydraulic ram upright assist, air powered pneumatic mast and high output LED fixtures. The entire
assembly is mounted onto a 21' by 8' tandem axle trailer, allowing operators to transport this fold over boom from location to location.

*PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO LIGHT MASTS OR LIGHT TOWERS*

This telescoping seven stage pneumatic light mast from Larson Electronics’ is designed to allow operators to quickly and safely deploy up to
960,000 lumens of high intensity LED lighting in locations where illumination must be elevated to heights up to 58' for effective coverage. This
light boom can be extended to 58' for maximum area coverage, and collapsed to 22' for applications where a footprint smaller is required. The
tower is constructed of heat treated aluminum tubing with 2.69' foot of overlap per section. The mast is elevated using an included hydraulic ram,
and extended to its full height using a trailer mounted air compressor.

Page: 1

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Click Images to Enlarge

Page: 2

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

A 90" wide by 109.5" tall and 2" by 2" by 1/4" thick steel mast head is attached to the upper section of the mast which provides a strong and
stable platform for the sixteen 500 watt LED light heads.
Lights: Included with this light tower is one of our wet area suitable GAU-LTL-600W-LED high output LED fixtures producing a combined total of
approximately 60,000 lumens at 500 watts. The light head contains forty-eight CREE® high output LEDs producing 1250 lumens each are
arranged in rows and paired with PMMA high purity optics to produce a well focused 25° wide spot beam that is ideal for providing far reaching
concentrated illumination while still covering a substantial amount of area. We also offer optional optics with 10° spot, 38° narrow flood, 60° flood,
and 90° wide flood beam spreads. The spot beams are tightly focused and are designed for high elevation mounting to achieve distance, making
spot versions ideal for high mast and spots lighting. The flood beams are designed to provide more light over a larger area nearer the fixture,
making flood versions ideal for use as dedicated work and area lights. Each floodlight is securely fastened to the light boom and each lamp
includes a support bracket to help maintain lamp stability within its housing. The lamps are hard wired into a NEMA 3R panel located on the end
of the telescoping boom.
Click here to see the lighting layout comparison of the metal halide verses LED Megatower light plants from Larson Electronics.
