LE-217
Explosion Proof LED Spotlight Instruction
Manual
Congratulations on the purchase of your new Handheld LED
Spotlight. Please read these instructions carefully to familiarize
yourself with the safe operation and maintenance of your new
ashlight. Following these instructions will insure many years of safe
and dependable service.
Table of Contents
I. Operating Instructions 2
I.I Assembly 2
I.II Operation 2
II. Warnings 3
VI. Warranty and Disclaimer 4
VI.I Limitation of Liability 4
VI.II Conditions 4
VII. Return Requests and Inquiries 5
8.1 Warranty Returns 5
8.2 Non-Warranty Returns 5
1
I. Assembly and Operation
I. Assembly
Unscrew the bottom cap and install approved
batteries like shown below. Once batteries have
been place, screw the bottom cap back on.
Slide to top for on
Slide to middle for momentary
Slide to bottom for off
II. Operation
This ashlight features a simple slide switch for
easy operation. Operators slide the switch up
to turn on, down to turn off or in the middle for
momentary.
Insert batteries (+ side
rst) and replace cap.
2 Return to Table of Contents
II. Safety Warnings and Ratings
For personal safety, always follow the safety instructions in this manual to ensure safe and longterm use. Failing to do so can result in damage to the product or serious bodily injury.
I. Safety Warnings
Never place ashlight face down when light is
on or is still hot from recent use. Doing so could
burn/ignite surfaces such as seats, carpeting,
etc. and cause major property damage. Always
turn spotlight off when not
in use.
To prevent serious damage to eyesight, never
look into spotlight when light is on. DO NOT
shine light into the face of someone else.
DO NOT touch lens of spotlight when light is on
or if it was recently on. The lens will be hot and
could cause serious burns.
DO NOT allow children to handle or operate
this spotlight.
DO NOT use this product for other than its
intended use.
II. Ratings
Class I, Division 1, Group C & D
Class I, Division 2, Group A, B, C, & D
Class II, Division 2, Group G - Class 3
CSA: Class I, Division 1, Group C & D
CSA: Class II, Division 1, Group G - Temp T3C
ASTM & MSHA: Approved
DO NOT operate in close proximity of
combustible or ammable materials.
DO NOT attempt to operate this spotlight if cord,
plug, battery, bulb or any part of the spotlight is
damaged or corroded.
DO NOT remove lens ring.
DO NOT allow metal parts to touch metal
contacts on battery as this can cause a short
circuit and result in a re.
Return to Table of Contents3
