Larson Electronics EPL-SL-10-LED-TXF-515-24VDC User Manual

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Explosion Proof LED String Lights - 10 lights - 120/277 to 12V DC - Class 1 Div 1 and Class 2 Div 1

Part #: EPL-SL-10-LED-TXF

Page: 1

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Made in the USA

The Larson Electronics EPL-SL-10-LED-TXF Explosion Proof String Light set with stepdown transformer is approved Class 1 Division
1 Groups C and D - and is ideal for general close work and inspection activities in hazardous locations requiring explosion proof
protection. This explosion proof string light has ten low voltage explosion proof drop lights spaced ten feet apart and an encapsulated
step-down inline transformer.

Click here to see the Incandescent version of this light
This explosion proof string light set from Larson Electronics contains a total of ten low voltage LED 10 watt work lights equipped with aluminum
hooks and connected in series along 90 feet of 14/3 SOOW explosion proof cord. A molded T junction is mounted every ten feet, with 3 feet of
16/3 SOOW cord connecting a single drop light to the backbone. A 25 foot tail section of main SOOW cord is included to allow ample length for
connection to the inline stepdown transformer. The transformer is encapsulated in a NEMA 4X enclosure, is equipped with a 10 foot line in cable,
and equipped with an industrial grade plug.

Click Photo to Enlarge Click Photo to Enlarge Click Photo to Enlarge

This unit incorporates ten explosion proof LED hand lamps connected in series and is suitable for use in areas where petrochemical vapors and
various dusts are present. The machined aluminum housings, cast aluminum guard, tempered glass lamp globe, and abrasion resistant cord
make this a very durable unit that will resist damage from chemicals, abrasion, vibrations and impacts. This string lighting solution will provide the
lighting you require in a flexible, easy to manage configuration. The hand lamps can be moved around and hooked to different points on your
scaffold. The lights, however must remain within 10 feet of one other. Each molded T section contains a hook eyelet, allowing operators to
suspend the entire backbone off the ground and out of the work space.

100 Watt Incandescent Bulb With the EPL-SL-10-LED-TXF
Click Photo to Enlarge Click Photo to Enlarge

This stringer light set is Class 1, Division 1 rated for Groups C and D and Class II, Division 1 Groups F and G. This unit is multi-voltage and
configured to operate on 120-277V AC stepped down to 12V or 24V DC, please choose your configuration below.

Page: 2

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Stringer Energy Consumption Comparison

Incandescent CFL LED

Wattage 1000 watts 260 watts 100 watts
Amp Draw @ 120V AC 8.34 amps 2.17 amps 0.84 amps
Amp Draw @ 277V AC 3.61 amps 0.94 amps 0.36 amps
Lamp Life Expectancy 1,500 hours 8,000 hours 50,000 hours
Color Temperature 2800K 4300K 6000K
Operation cost per year

(8hs/day @ 11c/kWh)

Wiring: This unit is equipped with SO cable leading to an encapsulated step down transformer. There is ten feet of 16/3 SO cable coming out of
the inline transformer, and is terminated in an industrial grade cord cap. This inline power supply for this LED string light is an auto sensing
universal voltage transformer that operates on any voltage within the 100-277 volts AC 50/60Hz range. This unit allows operators to power the
string light from any 120-277V AC power source, and steps down AC voltage to 24V DC. Plug options include standard 5-15 straight blade plug
for 110V wall outlets with ground, NEMA L5-15 twist lock plug for 125V twist lock outlets, NEMA L6-15 twist lock plug for 240V twist lock outlets,
BS1363 3-blade plug for United Kingdom outlets, and a two pin Schuko plug for European outlets.

Made in USA Quality Lamp Features

1. Federal Spec Cord.

2. Explosion Proof.

3. Total of (10) 10 watt LED Lamps.

4. Non-sparking aluminum construction.

5. UL Class 1 Div 1 Class 2 Div1

7. 120-277V AC stepped down to12/24V DC Operation

8. SOOW cable.

9. Aluminum Hooks for Convenient Placement.

Specifications / Additional Information

EPL-SL-10-LED-TXF U.L. Ratings
UL Listing: United States Class 1, Divisions 1 & 2, Groups C, D
Dimensions- Each Lamp: L-16.5" Diam-5" Class 2, Divisions 1 & 2, Groups, F, G

$321.2 $83.52 $32.12

100 watts of LED illumination
Non-sparking aluminum housings
Light weight mold T Juctions
Cast aluminum guard prevent lamp or globe damage
Temptered Soda-Lime Glass Lamp Globe
Integrated lamp shock absorbers prevent drop damage
Swivel hook for hanging and hands free operation
14/3 SOOW Abrasion Resistant Cable

Total Watts: 100 Class 1, Zone 1, Group IIB
Single Lamp Watt: 10 watts NEMA 4X
Voltage: 120-277V AC to 12V or 24V DC Stepdown Transformer
Amps: 0.84 120V AC
Mounting: Handheld / Hanging via Aluminum Hooks Special Orders- Requirements
Wiring: 90' 14/3 SOOW Cable, 25' lead - 10' 16/3 input Contact us for special requirements
Total Length: 125' Toll Free: 1-800-369-6671
Single Lamp Weight: 6 lbs Intl: 1-903-498-3363
Total Weight: 75 lbs E-mail: [e-mail]

Scroll Down to Purchase- Same Day Shipping on This Light!

Part #: EPL-SL-10-LED-TXF (105162)

Page: 3

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Page: 4

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Links (Click on the below items to view):

- Hi-Res Image 1 - Explosion Proof LED String Lights

- Hi-Res Image 2 - Explosion Proof LED String Lights

- Hi-Res Image 3 - Explosion Proof LED String Lights

Page: 5

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

- Hi-Res Image 4 - Explosion Proof LED String Lights

- Hi-Res Image 5 - Explosion Proof LED String Lights

- Hi-Res Image 6 - Explosion Proof LED String Lights

- Hi-Res Image 7 - Explosion Proof LED String Lights

- Hi-Res Image 8 - Explosion Proof LED String Lights
