150 Watt Explosion Proof LED Light Tower - Quadpod Mount - C1D1 - 100 foot Cord w/ EXP Plug

Part #: EPL-LQP-1X150RT-100

Page: 1

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Made in the USA

The EPL-LQP-1X150RT-100 Quadpod Mounted Explosion Proof LED Light Tower from Larson Electronics produces 13,000 lumens of
light capable of illuminating an area 9,500 square feet in size. This adjustable LED light tower is designed for portability and durable
operation and ideal for use in demanding conditions.

*PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO LIGHT MASTS, LIGHT TOWERS, OR QUADPODS*

The EPL-LQP-1X150RT-100 is a quadpod mounted explosion proof LED lighting system and provides 9,500 square feet of work area coverage
with 13,000 lumens of light output. This portable LED light tower has a removable LED light head mounted on top of a four leg durable non­sparking aluminum quadpod equipped with wheels for easy positioning of the unit from one area of the workspace to another. The LED light head
on this unit produces a wide flood pattern of light that is ideal for illuminating large workspaces and job sites. This light is designed for heavy duty
use in demanding conditions including emergency services, mining, construction, marine, and industrial operations where durability and reliability
is critical.
This portable LED light is comprised of an adjustable LED light head mounted atop a four leg quadpod fabricated from non-sparking powder
coated aluminum. This adjustable and collapsible quadpod can be extended to ten feet, collapsed to six feet, and includes solid wheels allow the
operator to tilt the unit back and simply roll the entire assembly to a new location when fully deployed. The LED light fixture assembly can be
removed by releasing the hand knob and sliding the light and mounting bracket off of the center support while the legs can be collapsed, aiding in
deployment, storage and transport. The lamp can be easily adjusted vertically and locked into position.

Page: 2

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Click Photos to Enlarge

Page: 3

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

The explosion proof LED light tower features multiple LED drivers which helps to increase the operational life of the fixture. With traditional LED
lights, in the event an LED array or driver fails, the entire fixture no longer illuminates. This new series of LED lamps contains twelve individual
LED boards configured in a series of banks. Each bank contains two LED boards with an individual driver. In the event of a driver failure, only
one bank of LEDs will be effected while the other banks will continue to operate. In the event that of an LED failure, the mating LED will continue
to operate.
Unlike gas burning and arc type lamps that have glass bulbs, LEDs have no filaments or fragile housings to break during operation. Instead of
heating a small filament or using a combination of gases to produce light, light emitting diodes (LEDs) use semi-conductive materials that
illuminate when electric current applied and emitting light. With LED lights, there is no warm up time or cool down time before re-striking and
provide instant illumination when powered on, adding to the reliability of LED technology. By nature, LED light sources run significantly cooler
than traditional lamps, reducing the chance of accidental burns and increased temperatures due to heat emissions. This solid state design of light
emitting diodes provides a more reliable, stable, durable, and energy efficient light source over traditional lighting.
Included with this hazardous location LED light tower is 100' of SOOW cord which combined with adjustability offered by the LED light head
provides ample length for tower placement and optimal coverage of the workspace. The easy to collapse design of this Class 1 Division 1 LED
work light allows Larson Electronics to avoid pallet freight charges when shipping and deliver these units via UPS next day air service, which in
turn improves delivery time and reduces the cost to buyers.
The LED light head on this tower contains twelve 12.5 watt LEDs producing 1084 lumens each. These LEDs are arranged in rows and paired
with high purity optics to produce 13,000 lumens and a 60 degree flood beam while only drawing 1.25 amps on 120V, making these units ideal
for use as highly efficient yet powerful work and area lights. The EPL-LQP-1X150RT-100 hazardous location LED light is an ideal replacement
for fragile and hot running 400 watt metal halide floodlights.
This light tower is universal voltage capable and can be operated with 100-277 VAC, 50/60Hz. We also offer a low voltage version of this LED
fixture that operates on AC/DC voltages from 11-25 Volts. This explosion proof LED light is IP67 rated, dust-proof, and protected against high
pressure jets and temporary submersion. The cast aluminum body and LED lamp give this light excellent durability and resistance to vibration
and impacts. The housing is specially designed to dissipate heat which increases the efficiency and lifespan of the LEDs and electronics.
The LED light head produces 13,000 lumens with a color temperature of 5600K and a color rendering index of 75 which produces colors and
details much more accurately than high pressure sodium or mercury vapor luminaries. We also offer a 3000K warm white and 4500K natural
white color temperature options (longer lead times may apply for non-standard temperatures). 25 peel off mylar overspray covers are included for
protecting the glass face of the LED fixture during operation.
The LED light head on this unit is small enough to allow it to fit through most standard size manholes and entry points. The LED light head can
also be removed from the quadpod, the tower collapsed and the entire assembly passed through a manhole and reassembled once inside. The
wheel kit can be removed from the base of the tower and setup as a stationary quadpod, or left installed for quick deployments. The LED light
head retains 80% of its lumen output after 60,000 hours of use, far longer than incandescent or fluorescent lamps.

Made in USA Quality Superior LED Benefits

1. Approved Class 1 Div1-2 Class 2 Div I-2

2. Led lamp head requires no lamping and simply slides on
the quadpod and is locked into place with a hand tightened set screw.

3. Quadpod constructed of corrosion resistant, non-sparking aluminum
with powder coated finish.

4. No ballast box. No ballast to replace.

5. Extreme long life LEDs reduce maintenance and replacement costs.

6. Solid rubber tires. No flats or tube replacements.

7. 25 peel off mylar overspray lamp protectors ship with the unit.

8. 13,000 Lumens produced from only 150 watts.

9. Mercury free shock proof LED lamp light head.

Page: 4

1. 60,000+ hour lifespan.

2. Can SAVE 50% or more on energy.

3. 100% recyclable.

4. No toxins-lead, mercury.

5. No UV light, infrared radiation or CO2 emissions.

6. Bright, even light maintains consistent color over time.

7. Instant on/off – No flickering, delays or buzzing.

8. Very good color rendering.

9. Vibration/impact resistant.

10. Significantly cooler operation.

11. Less frequent outages, higher output improves workplace safety.

Larson Electronics LLC www.LarsonElectronics.com

9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]

Specifications / Additional Information

EPL-LQP-1X150RT-100 Explosion Proof LED Quadpod Quick Summary
Listing: United States Listed for United States and Canada
Lamp Type: LED Class I, Divisions 1 & 2, Groups C and D
Dimensions: 14"-W 16"-H 5"-D- Light Head - 6' to 10' Extendible

Tower

Weight: 50 lbs. Class III, Divisions 1 & 2
Voltage: 100-277 Volts AC, 50/60Hz Certified to UL 844 Ed. 13
Total Watts: 150 watts Certified to UL 1598
Total Lumens: 13,000 Certified to C22.2 No. 137 Rev 2009
Luminous Efficiency: 86.67 Lm/W Certified to C22.2 No. 250.0
Lamp Life: 60,000+ Hours T5 Temperature Rating
Color Temp: 5600K, 4500K, 3000K Paint Spray Booth Approved
Color Rendering Index: >75 CRI IEC 60529 Tested
Beam Angle: 60° or 125° IP67 Rated Waterproof
Lighting Configuration: Flood Pattern DLC Approved
Power Efficiency: >95% Multiple Driver Banks
Power Factor: 0.992 80% Lumen Retention after 60,000 Hours
Ambient Operating Temp Range:-50° C to +65°C Class I, Division 1 Cord Cap
Operating Temp Rating: T5 Wheeled Adjustable Tower 6-10'

Class II, Divisions 1 & 2, Groups E,F,G

Lamp Housing Material: Copper Free Cast Aluminum 100' SOOW Cable
Tower Material: Non-Sparking Aluminum Stock Special Orders- Requirements
Mounting: Non-Sparking Wheeled Aluminum Quadpod Contact us for special requirements
Wiring: 100' 16/3 SOOW Cord Explosion Proof Plug Toll Free: 1-800-369-6671
Cord Cap: 5-15, 5-20, or 6-20 Intl: 1-903-498-3363
Warranty: Yes - 5 Years* - 10 Year / 100,000 Lumen Available** E-mail: [e-mail]

*5 year warranty replacement on this LED light (or LED bulbs for light
fixtures with removable LED bulbs). After 30 days, the customer ships
the failed LED light and/or LED bulb to Larson Electronics at their
expense. If the failure is a manufacturer defect, we will ship a new
replacement to the customer. If failure occurs within 30 days of receipt,
Larson Electronics will provide a return label via email to the customer.
When the failed light is returned, Larson Electronics will ship a new
replacement. Please click here to see our 5 Year Warranty pamphlet.
**10 year / 100,000 hour warranty available for this product. For more
information, please click here
