Explosion Proof 100 Foot SOOW Extension Cord - 20 amp continuous service - 12/3 SOOW

Part #: EPEXC-100-12-3-20A

Made in the USA

Larson Electronics 100' Explosion Proof 20 Amp Extension Cord

The Larson Electronics EPEXC-100-12-20A Explosion Proof extension cord allows operators to safely extend the range of their explosion proof
light or equipment cords beyond the boundaries of the hazardous work area. These units are constructed of 100 feet of 12/3 SOOW explosion
proof cord rated at 20 amps of continuous service. The cord is chemical and abrasion resistant and comes with an explosion proof receptacle
installed on one end and an explosion proof plug installed on the other end. We also include an extra matching plug for operators to attach to
their equipment which allows them to avoid any issues with plug and receptacle equipment compatibility with this cord.
The plugs on these units are of a twist lock design. In order for a secure and working connection to take place, the operator must insert the plug
and twist until it locks into place. This ensures a safe seal is made before any sparks from electrical contact can take place. To ensure the
highest safety, operators should make connections outside of the hazardous area.
