Lanzar OPTIX-2B Users Manual

www.lanzar.com

OptiX-2B

OptiX-2B

user’s manual

2-Way Electronic Crossover Network

w/Remote Bass Boost and Level Control

INTRODUCTION...

Congratulations on your purchase of a new Lanzar Opti signal processor. Opti mobile electronics are some of the most advanced
car audio products available. These quality audio products are designed and engineered to afford you years of uncompromising
musical service. Lanzar has utilized the latest electronic technologies in order to deliver a superb listening experience.

The X-2B Active Crossover offers the listener the ability to enjoy the finest in mobile audio. The X-2B unleashes the effortless,
natural and open quality of the real performance. Car audio systems which utilize passive crossovers feed the music through
chokes and capacitors, which creates a “bottleneck” through which the music must pass. Portions of the program material may
pass through at different speeds, creating distortion – some of the music doesn’t make it through at all!

With the Lanzar Opti X-2B you’ll hear all the dynamics in the bass, and still hear delicacies like fingers sliding across guitar
strings.The X-2B also allows the user to group amplifiers and separate speakers in discrete assemblages so they play as one
cohesive unit, in harmony with each other. The X-2B becomes the music conductor in the system, balancing volume, assigning
the proper part of the music to a specific instrument, delaying some sounds so they reach your ear just as the rest of the music
does, with the sole purpose of creating the illusion that there is only the music.

table of contents

general features

precautions

features and specifications

system wiring

mounting and installation

noise check and system adjustment

troubleshooting

2
3
4-5
6
7
8
9

general features

Blue light illuminated control panel
Rotary control knobs
12dB per octave crossover slopes
PWM power supply
Remote bass boost (0-+18dB) and level controls
Subwoofer mode switch
Frequency multiplier (x1, x10 high-pass crossover)
Variable high-pass frequency control 40-8 kHz
Left and right high pass phase shift control (0-180)
High-pass level control
Frequency multiplier (x1, x10 subwoofer crossover)
Parametric "Q" control (2-20)
Variable subwoofer frequency control 40-8 kHz
Variable subwoofer bass boost frequency control 25-250 Hz
Subwoofer level control
Subwoofer stereo/mono mode control
Sub & High RCA inputs
Line out port
Sub & high pass outputs
Max Variable output level controls, 7 volts
