Lanzar OPTI1213D User Manual

Overall

Diameter

14”

16 1/8”

9 3/4”

Suggested enclosure parameters

SPECIFICATIONS

(mm)

SeriesOpti

OPTI1522D

1800W

3600W

1 ohm

0.98
30

4.811

1.167

0.939

17.75

2.812

Performance
Parameters

Power

(Watts RMS)

Power

(Watts Peak)

Nom. Impedance

Re (ohms)
Fs (Hz)
Qms
Qes
Qts
X-Max

(cu. ft.)

Vas

Lanzar continually strives to improve the performance and value of its products \all specifications are subject to change.–

Woofer for small enclosures

1800W

3600W

4 ohm

3.9

30

5.289

1.184

0.967

17.75

2.864

Physical & lnstallation
Parameters

Voice

Magnet

Cone

Surround

Spider

Dustcap

Frame

Terminals

4" BACCAR

82oz x 2

Pulp Paper

Poly Mica

Cast Aluminum

High Density
Screw in

Foam

Conex

speaker model

OPTI
1522D

Enclosure type

size

Enclosure volume, cu. ft.

Vent length, inches

Vent diameter, inches

Enclosure Frequency, Hz

Fb Tuning Frequency of the Vented Enclosure

F3 S ystems 3dB Down Piont (Sealed)

Sealed or vented

Sealed Vented

Small

2.5

Large Small Large

NA

2.3

12

5

36.32

NA

37.8

31.29

Opti SERIES

W

2.8

9.5

5

37.5

oofer Specifications
