1: Introduction

The Lantronix SLP Remote Power Manager family of products provides easy, practical, and secure solutions for power distribution, power management and loadmeasurement for remote equipment and branch AC circuits.

The SLP Remote Power Manager supports the elimination of unnecessary trips to remote locations by allowing remote control of the power on/off status for distant critical equipment, minimizing the impact of locked-up devices on mission-critical systems.

Features and Benefits

SLP models are available in 8-outlet and 16-outlet configurations for 100-120VAC and 208-240VAC up to 16A. Expansion models are available in 8-outlet and 16outlet configurations for 100-120VAC and 208-240VAC up to 16A. See

101.

page

Models on

Communication Access Modes

All models are equipped standard with a RS-232 (serial) port and a 10/100 Base-T Ethernet port for Telnet, Secure Shell (SSH), and web browser access.

Power Distribution

Up to 16A/24A of AC power (dependant on model) can be distributed across up to sixteen attached devices. See

Models on page 101 for available models.

Remote Power Management

Remote control of power outlets allows individual on/off and reboot control of up to 16 devices or up to 32 devices with the addition on an expansion unit.

Load and Environment Measurement

Load measurement eliminates guesswork by supplying the cumulative operating load in amperes. This allows on-site technicians to maximize the equipment installed and operated on a circuit without concern. Use of the circuit is maximized, while effectively allowing a 10% to 20% safety margin. Remote users also may access this information at any time from the command line or web browser interface.

Optionally, temperature and humidity sensors allow monitoring of key environmental conditions at remote facilities.

Power-up Sequencing

SecureLinx SLP Remote Power Manager 7

1: Introduction

When powered on, each of the power outlets power sequentially with a two-second delay between each outlet. Power sequencing staggers the individual loads, eliminating the potential of a blown fuse or circuit breaker due to excessive in-rush current and allows circuit support for operating load capacities of 80% to 90%.

Outlet Grouping

For operations across multiple attached devices or devices with multiple or redundant power supplies, include outlets in one or more named groups of outlets. This allows changes to all outlets in the named group with a single command sequence.

Security

Units ship with one predefined administrative user account. The administrator can create up to 128 user accounts, with individualized access to outlets and commands. All accounts support username and password protection. For configurations requiring multiple fully-privileged users, the administrator can grant administrative privileges to other user accounts in the system.

User Interfaces and LEDs

Two types of user interfaces are available: the web browser and the command line interface. For easy outlet recognition, assign descriptive names to both individual outlets and outlet groups for use in control commands. For the on-site technician, LEDs indicate individual outlet power status and cumulative power load.

Automatic Timeout

For added security, a user session automatically terminates after five minutes of inactivity; if a user is called away unexpectedly, an unprotected channel does not remain open indefinitely.

SecureLinx SLP Remote Power Manager 8

2: Installation

Prior to installation, refer to the following lists to ensure that you have all the items shipped with the unit as well as all other items required for proper installation.

Standard Accessories

 Mounting bracket hardware:

Vertical (SLP-V, SLPY* models) – two removable flanges with four M4 screws and two mounting L-brackets with two nut plates and four sets of screws and washers

Horizontal/Rack (SLP-H, SLPX* models) – two mounting brackets and four screws

 RJ45 to RJ45 serial rollover cable

 RJ45 to DB9F serial port adapter (for connection to standard DB9M DTE serial

port)

 Outlet retention clips, one per outlet (208-240V units only)

 Power input retention bracket hardware

 Two removable T-brackets with two 40mm screws

 Additional required Items:

Phillip screwdriver

Screws, washers and nuts to attach the SLP to your rack

Power input cord (purchased separately)

*SLPY, SLPX includes RJ12 link cable

Equipment Overview

The outlets are labeled 1 through 16. These numbers may be used in commands that require an outlet name. See power inlet connects to the electrical power source. features of the SLP.

Outlet Naming and Grouping for more information. The

Figure 2-1 shows the hardware

Note: Models SLP-H8 and SLP-V16 are displayed in the following

illustration. Other models may have variations.

SecureLinx SLP Remote Power Manager 9

2: Installation

Connectors for Optional

Temperature/Humidity

Sensor

RJ12 Link

Input

Current

LED

Outlet

10/100Base-T

Ethernet

(RJ45)

Output Power

Status LED

Figure 2-1. SLP Hardware View

RS-232 Serial

(RJ45)

AC Power

Inlet

RJ12 Link

Outlet

Connectors for Optional

Temperature/Humidity

Sensor

Output Power

Status LED

Input

Current

LED

RS-232 Serial

(RJ45)

10/100Base-T

Ethernet

(RJ45)

AC Power

Inlet

Safety Precautions

This section contains important safety and regulatory information that should be reviewed before installation. For input and output current ratings, see Power Ratings

Technical Specifications.

Only for installation and use in a Service Access Location in accordance with the following installation and use instructions.

This equipment is designed to be installed on a dedicated circuit.

Dedicated circuit must have circuit breaker or fuse protection. This product has been designed without a master circuit breaker or fuse to avoid becoming a single point of failure. It is the customer’s responsibility to provide adequate protection for the dedicated power circuit. Protection of capacity equal to the current rating of the product must be provided and must meet all applicable codes and regulations. In North America, protection must have a 10,000A interrupt capacity.

The plug on the power supply cord shall be installed near the equipment and shall be easily accessible.

Installation Orientation: SLPVxxxx-02 units are design to be installed in vertical orientation.

SecureLinx SLP Remote Power Manager 10

Always disconnect the power supply cord before opening to avoid electrical shock.

Warning! High leakage current! Earth connection is essential before connecting supply!

Warning: 208-240/230V models only: Outlets are not fused. Outlet circuit protection is provided by the building installation, which shall not exceed 30A branch circuit protection

Installing the Power Input Retention Bracket

For models with a total maximum output < 30A, it may be necessary to install the power input retention bracket prior to mounting the unit within a rack.

To install the power input retention bracket:

1. Remove the two screws attaching the IEC 60320 C19 inlet to the enclosure.

2. Assemble and attach the retention bracket to the enclosure as shown:

Figure 2-2. Retention Bracket Assembly

2: Installation

Mounting

Horizontal/Rack

1. Select the appropriate bracket mounting points for proper mounting depth within

2. Attach the brackets to these mounting points with two screws for each bracket.

3. Install the enclosure into your rack, using the slots in each bracket. The slots

Vertical

1. Attach the removable flanges to the mount points on the rear of the enclosure

2. Attach the mounting L-brackets to the flanges with the supplied screws, washers

3. Attach the top and bottom brackets to your rack.

the rack.

allow about ¼ inch of horizontal adaptability to align with the mounting holes of your rack.

using M4 screws.

and nut plates. The slots allow about 1½ inches of vertical adaptability.

SecureLinx SLP Remote Power Manager 11

Connecting to the Power Source

Attach the power cord to the unit before connecting the unit to the power source. Each outlet powers up sequentially, with a two-second delay between each outlet, eliminating a potential blown primary fuse or circuit breaker from excessive in-rush current.

To attach a power cord to the unit:

1. Plug the female end of the power cord firmly into its connector at the base.

2. Use a screwdriver to tighten the two screws on the retention bracket.

To connect to the power source:

1. Plug the male end of the power cord into the AC power source.

Connecting Devices

To avoid the possibility of noise due to arcing:

1. Keep the device’s on/off switch in the off position until after it is plugged into the outlet, or log in to the unit and turn the outlets off before connecting the devices

2: Installation

2. Connect devices to the outlets.

On 230V units, install a retention clip for each outlet; Pull the prongs out slightly and insert them into holes on the sides of the unit, then insert the device’s power cord and snap the clip over the cord.

Note: Even distribution of attached devices is recommended across the

available outlets to avoid exceeding the outlet, quad or octet ratings limitations. See

Note: The outlet retention clips on the 230V models are designed for use

with Lantronix provided cables. The retention clip may not properly fit 3rd party cables.

Always disconnect the power supply cord before opening to avoid electrical shock.

Technical Specifications on page 101 more information.

Connecting to a local Personal Computer (PC)

Serial (RS-232) port

All models are equipped with an RS-232 port (RJ45) for attachment to a PC using the supplied RJ45 to RJ45 serial rollover cable and an RJ45 to DB9F adapter. See

Technical Specifications on page 103 for more information on the RS-232 serial port.

The default values are 9600 baud, 8 data bits, 1 stop bit, no parity (9600 8N1).

Ethernet port

All models are equipped with a 10/100Base-T Ethernet port for attachment to an existing network. This connection allows access via Telnet, Secure Shell (SSH), or web browser.

SecureLinx SLP Remote Power Manager 12

2: Installation

The following network defaults allow unit configuration out-of-the-box through either Telnet/SSH or via a web browser:

IP address: 192.168.1.254

Subnet Mask: 255.255.255.0

Gateway: 192.168.1.1

The local PC network connection must be configured as Noted below:

Note: Contact your system administrator for instructions in reconfiguring the

network connection. Reconfiguration of your network connection may require a restart to take effect.

IP address: 192.168.1.x (where x is 2-253)

Subnet Mask: 255.255.255.0

SecureLinx SLP Remote Power Manager 13

3: Operations

User Interfaces

Two user interfaces are available: the web browser interface accessed via the HTTP/SSL enabled Ethernet connections and the command line for serial and Telnet/SSH connections.

Outlet Naming and Grouping

For commands requiring an outlet name, you may specify it in one of two ways: a predefined absolute name or a descriptive name assigned by an administrator.

Models with a Single Power Infeed

Absolute names are specified by a period (.) followed by a unit letter and outlet number.

Usernames and Passwords

The factory default has one predefined administrative user account (username/password: sysadmin/PASS) and supports a maximum of 128 defined user accounts

Note: For security purposes, it is recommended that the predefined

administrative user account be removed after a new account with administrative rights has been created.

Only an administrative-level user may perform operations such as creating/removing user accounts and command privileges, changing passwords and displaying outlet and user information. An administrator may also view the status of and control power to all outlets.

The administrator may create additional user accounts and then grant these users the right to view the status of and control power to specific outlets, groups and ports.

Usernames may contain from 1-16 characters and are not case sensitive; spaces are not allowed. Passwords may contain up to 16 characters, and are case sensitive.

Web Browser Interface

The web browser interface is constructed of three major components: the System Location bar, the User/Navigation bar and the Control Screen. The System Location bar displays the location and IP address as well as the current Control Screen title. The User/Navigation bar displays the current user and privilege level

and provides access to all monitoring and control pages. The Control Screen is

SecureLinx SLP Remote Power Manager 14

3: Operations

used to display current data and allow changes to outlet states or system configuration.

Figure 3-1. Web Browser Interface

The following sections describe each interface section/page and their use.

Logging In

Logging in via a web browser requires directing the web client to the configured IP address of the unit.

To log in by web browser:

1. In the login window, enter a valid username and password and press OK.

(Default username/password:sysadmin/PASS).

If you enter an invalid username or password, the prompt will repeat again.

You are given three attempts to enter a valid username and password combination. If all three fail, the session ends and a protected page will be displayed.

Outlet Control

The Outlet Control section offers access to the Individual and Group outlet control pages. From the Individual and Group pages, the user can review and manipulate

power control functions for all outlets and groups assigned to the current user. Both pages include the outlets absolute and descriptive names, the Outlet Status reported to the unit by the outlet, the current Control State being applied by the unit and the outlet load in amperes.

SecureLinx SLP Remote Power Manager 15

3: Operations

Available outlet and group power states may be set to on, off or reboot; the reboot operation turns the outlet(s) off, delays for a period of 15 seconds and then turns the outlet(s) on.

Individual

The Individual outlet control page displays all outlets assigned to the current user.

The user may apply on, off or reboot actions to individual, multiple or all accessible outlets.

To apply actions to individual or multiple outlets:

1. In the Individual Outlet Control section, select the desired action from the Control Action drop-down menu for each individual outlet to be changed and press

Apply.

To apply an action to all outlets:

1. In the Global Control section, select the desired action from the Control Action

drop-down menu and press Apply.

Group

The Group outlet control page displays all groups assigned to the current user as

well as the outlets for each group.

To select a group:

1. Select the group name from the drop-down menu and press Select. The page

will refresh to display all outlets associated to the selected group name.

To apply an action to a group: Select the desired action from the drop-down menu and press Apply.

Table 3-1. Outlet State/Control State Field Values

Outlet State Control State Description

On On Outlet is on

Off Off Outlet is off

Off Pend On Outlet is off and about to turn on in

response to a sequence timer

Off Reboot Outlet is off and a Reboot action has

been initiated

On Idle On A restart has occurred – Last Control

State has been maintained

Off Idle Off A restart has occurred – Last Control

State has been maintained

On Wake On A power-loss has occurred –

Wakeup State has been applied

Off Wake Off A power-loss has occurred –

Wakeup State has been applied

On/Wait Off Outlet state in transition – Re-query

of outlet status required

Off/Wait On Outlet state in transition – Re-query

SecureLinx SLP Remote Power Manager 16

3: Operations

Outlet State Control State Description

of outlet status required

On/Error varies Error State – Outlet should be off but

current is sensed at the outlet

Off/Error varies Error State – Outlet should be on but

no current is sensed at the outlet

Off/Fuse On Outlet should be on but a blown fuse

has been detected.

No Comm varies Communication to the outlet has

been lost*

* Control State will be applied when communication is re-established

Environmental Monitoring

The Environmental Monitoring section offers access to the Input Load page. This

section is available to administrative level users and users with Environmental Monitoring view rights.

Input Load

The Input Load page displays the absolute and descriptive name and the cumulative

input load in amperes of all devices attached to the unit at the time the page was loaded. This page will refresh automatically every 10 seconds.

Sensors

The Sensors page displays the temperature/humidity sensor’s absolute and

descriptive names. The sensor page also displays temperature/humidity sensor readings in degrees Celsius and percent relative humidity. This page will refresh automatically every 10 seconds.

Configuration

The Configuration section offers access to all unit configuration options including System, Network, Telnet/SSH, HTTP/SSL, Serial Port, Outlets, Groups, Users, FTP, SNTP/Syslog,SNMP, LDAP, TACACS+ and Email. This section is available to administrative level users only.

System

The System configuration page is used for reference of system information such as

Ethernet NIC Serial Number, Ethernet MAC address and system firmware and hardware revisions as well as assignment and maintenance of the system location and unit descriptive names.

For description names, up to 24 alphanumeric and other characters (ASCII 33 to 126 decimal – spaces and colon characters are not allowed) are allowed.

Note: Spaces may be used for the location description only.

Creating a descriptive system location name:

1. Enter a descriptive name and press Apply. Configuring the Input Current LED display orientation:

SecureLinx SLP Remote Power Manager 17

3: Operations

1. Select Normal or Inverted from the drop-down menu and press Apply.

Enabling or disabling strong password requirements:

1. The SLP supports enforcement of strong passwords for enhanced security. When enabled, all new passwords must be a minimum of 8 characters in length with at least one uppercase letter, one lowercase letter, one number and one special character.

2. Acceptable strong passwords:

n0tOnmyw@tch

john2STI?

H3reUgo!

Note: Strong password requirements also enforce a minimum change of four

character positions when defining new strong passwords.

3. Select Enabled or Disabled from the Strong Passwords drop-down menu and press Apply.

Note: The strong password requirement is applied against all new

passwords.

Enabling or disabling the external reset button:

1. Select Enabled or Disabled from the External Reset Button drop-down menu and press Apply.

Setting the temperature scale: Select Celsius or Fahrenheit from the Temperature Scale drop-down menu and

press Apply. Creating a pre-login banner:

1. Click on the Login Banner link.

2. On the subsequent Login Banner page, enter a pre-login banner and press Apply.

Note: The pre-login banner may be up to 2070 characters in length and is

displayed prior

to the login prompt. If left blank, no system banner will be

displayed prior to login prompt.

Creating a descriptive unit name:

1. Click on the Tower Names link.

2. On the subsequent page, enter a descriptive name and press Apply.

Creating a descriptive input feed name:

1. Click on the Input Feed Names link.

2. On the subsequent Input Feed Names page, enter a descriptive name and press Apply.

SecureLinx SLP Remote Power Manager 18

3: Operations

Creating a descriptive outlet name:

1. Click on the Outlet Names link which will open the Outlets configuration page.

Outlets on page 22 for additional information on creating descriptive outlet

See names.

Creating a descriptive serial port name:

1. Click on the Serial Port Names link which will open the Serial Port configuration

page. See

Serial Port on page 21 for additional information on creating

descriptive serial port names.

Creating a descriptive Environmental Monitor name:

1. Click on the Environmental Monitor Names link.

2. On the subsequent Environmental Monitor Names page, enter a descriptive

name and press Apply.

Creating descriptive sensor names:

1. Click on the Sensor Names link.

2. On the Sensor Names page, enter a descriptive name and press Apply.

Network

The Network configuration page is used for maintenance of the network interface.

From this page an administrator may configure the IP address, subnet mask and gateway address as well as view the link status, speed and duplex value.

The following network defaults allow unit configuration out-of-the-box through either Telnet/SSH or web browser:

IP address: 192.168.1.254

Subnet Mask: 255.255.255.0

Gateway: 192.168.1.1

The initial local PC network connection must be configured as noted below:

Note: Contact your system administrator for instructions in reconfiguring the

network connection. Reconfiguration of your network connection may require a restart to take effect.

IP address: 192.168.1.x (where x is 2-253)

Subnet Mask: 255.255.255.0

Note: The unit must be restarted after network configuration changes. See

Performing a warm boot on page 57.

Enabling or disabling DHCP support:

1. Select Enabled or Disabled from the DHCP drop-down menu and press Apply.

Setting the IP address, subnet mask, gateway or DNS address:

1. In the appropriate field, enter the IP address, subnet mask, gateway address or

DNS address and press Apply.

SecureLinx SLP Remote Power Manager 19

3: Operations

Telnet/SSH

The Telnet/SSH configuration page is used to enable or disable Telnet and SSH support and configure the port number that the Telnet or SSH server watches. For more information on SSH see

Enabling or disabling Telnet or SSH support:

1. Select Enabled or Disabled from the appropriate Server drop-down menu and press Apply.

Changing the Telnet or SSH server port number:

1. In the appropriate Port field, enter the port number and press Apply.

Note: The default port numbers are: port 23 for Telnet, and port 22 for SSH.

Enabling or disabling SSH server authentication methods:

The SLP SSH server supports two authentication methods for security and validation:

Password and Keyboard-Interactive.

Password is an authentication method where the SSH client gathers

username/password credentials and makes the authentication request to the SSH server with the credentials. The Password method is controlled by the SSH client.

Advanced Operations on page 66.

Keyboard-Interactive is an authentication method where the SSH server controls an

information field followed by one or more prompts requesting credential information from the SSH client. The client gathers credential information keyed-in by the user and sends it back to the server. The Keyboard-Interactive method is controlled by the SSH server.

Individual enabling and disabling of the Password and Keyboard-Interactive authentication methods are supported to allow an SSH client to be forced to use a specific method. Although both methods are available, by enabling the KeyboardInteractive method and disabling the Password method, the SSH client is forced to used Keyboard-Interactive, which is required to display the login banner.

Note: At least one authentication method must be enabled.

1. Select the Password checkbox and/or the Keyboard-Interactive checkbox and

press Apply.

HTTP/SSL

The HTTP/SSL configuration page is used to enable or disable HTTP and SSL support, configure the port number that the HTTP server watches and responds to, selection of the method of authentication used and SSL access level. For more information on SSL see

Enabling or disabling HTTP or SSL support:

Advanced Operations on page 65.

1. Select Enabled or Disabled from the appropriate Server drop-down menu and

press Apply.

Changing the HTTP server port number:

1. In the HTTP Port field, enter the port number and press Apply.

SecureLinx SLP Remote Power Manager 20

3: Operations

Note: The default port number for HTTP is 80.

Setting the HTTP authentication method:

The HTTP server supports two authentication methods for security and validation of the username-password – Basic and MD5 digest.

The Basic method utilizes Base64 encoding to encode and deliver the usernamepassword over the network to the HTTP server for decoding and authentication. This basic method is supported by all web browsers and offers a minimum level of security.

Note: The Base64 algorithm is widely-known and susceptible to packet-

sniffer attack for acquisition of the encoded username-password string.

The MD5 digest method provides stronger protection utilizing one-way encoded hash numbers, never placing the username-password on the network. Instead, the sending browser creates a challenge code based on the hash algorithm, provided username-password and unique items such as the device IP address and timestamp, which is compared against the HTTP server internal user database of valid challenge codes. The MD5 digest method offers a higher level of security than the Basic method but at present is not supported by all browsers.

Note: MD5 is known to be fully supported by Internet Explorer 5.0+

Select Basic or MD5 from the Authentication drop-down menu and press Apply. Setting SSL access level

SSL access may be configured as optional or required. The default access level is set to optional.

Optional –Both non-secure (HTTP) and SSL encrypted connections (HTTPS) are

allowed access.

Required – ONLY SSL encrypted connections (HTTPS) are allowed access.

Select Optional or Required from the Secure Access drop-down menu and press Apply.

Serial Port

The Serial Port configuration page is used for maintenance of the serial port.

Setting the data rate for all serial ports:

1. Select the serial port data rate from the drop-down menu and press Apply.

Note: The default values are 9600 baud, 8 data bits, 1 stop bit, and no parity

(9600 N 8 1).

Setting the serial port timeout value:

1. Enter the timeout value (in minutes) in the Connection Timeout field and press

Apply.

Creating a descriptive serial name:

1. Click on the Edit link in the Action column next to the port to be configured.

SecureLinx SLP Remote Power Manager 21

3: Operations

2. On the subsequent Serial Port Edit page, enter the descriptive name. Up to 24

alphanumeric and other typeable characters (ASCII 33 to 126 decimal, spaces

and colon characters are not allowed) are allowed. Press Apply.

Note: Port names ‘1’ thru ‘64’ and ‘CONSOLE’ are reserved syste m names

and may not be used.

Enabling or disabling serial port active signal checking:

1. Click on the Edit link in the Action column next to the port to be configured.

2. On the subsequent Serial Port Edit page, select On or Off from the DSR Check drop-down menu and press Apply.

Outlets

The Outlets configuration page is used for assignment and/or editing of outlet

descriptive names and wakeup states.

Setting the outlet sequencing interval:

1. Enter the sequencing interval (in seconds) in the Sequencing Interval field and

press Apply.

Setting the outlet reboot delay:

2. Enter the reboot interval (in seconds) in the Reboot Delay field and press Apply.

Editing the outlet descriptive name:

1. Click on the Edit link in the Action column next to the outlet to be configured.

2. On the subsequent Outlet Edit page, enter the descriptive name. Up to 24

alphanumeric and other typeable characters (ASCII 33 to 126 decimal, spaces

and colon characters are not allowed) are allowed. Press Apply.

Changing the outlet wakeup state:

1. Click on the Edit link in the Action column next to the outlet to be configured.

2. On the subsequent Outlet Edit page, select On, Off, or Last from the Wakeup State drop-down menu and press Apply.

Setting the outlet Post-On delay:

3. Click on the Edit link in the Action column next to the outlet to be configured.

4. On the subsequent Outlet Edit page, enter the outlet Post-On delay (in seconds) in the Post-On Delay field and press Apply.

Groups

The Groups configuration page is used for creation and deletion of group and assignment of outlets to groups.

Creating a group:

SecureLinx SLP Remote Power Manager 22

3: Operations

1. Enter a descriptive group name in the Group Name field. Up to 24 alphanumeric

and other typeable characters (ASCII 33 to 126 decimal, spaces and colon

characters are not allowed) are allowed. Press Apply.

Removing a group:

1. Click on the Remove link in the Action column for the group to be removed and

press Yes on the subsequent confirmation window.

Adding and Deleting outlets from a group:

1. Press the Edit link in the Action column for the associated group.

2. On the subsequent Group Edit page, select or deselect outlets to be included in

that group. Press Apply.

Users

The Users configuration page is used for creation and removal of usernames,

assignment of accessible outlets and group, assignment of privilege levels and the changing of user passwords.

Creating a new user:

1. Enter a user name in the Username field. Up to 24 alphanumeric and other

typeable characters (ASCII 33 to 126 decimal, spaces and colon characters are not allowed) are allowed.

2. Enter a password for the new user in the Password and Verify Password fields.

For security, password characters are not displayed. Press Apply.

Removing a user:

1. Click on the Remove link in the Action column for the user to be removed and

press Yes on the subsequent confirmation window.

Changing a user password:

1. Click on the Edit link in the Action column for the associated user.

2. On the subsequent User Edit page, enter the new password in the Password

and Verify Password fields. For security, password characters are not displayed.

Press Apply.

Changing a user’s access privilege level:

There are six defined access privilege levels; Admin, Power User, User, RebootOnly, On-Only and View-Only:

 Admin: Full-access for all configuration, control (On, Off, Reboot)

, status and serial/Pass-Thru ports.

 Power User: Full-access for all control (On, Off, Reboot), status and

serial/Pass-Thru ports.

 User: Partial-access for control (On, Off, Reboot), status of

assigned

outlets, groups and serial/Pass-Thru ports.

 Reboot-Only: Partial access for control (Reboot), status and Pass-Thru of

SecureLinx SLP Remote Power Manager 23

3: Operations

assigned outlets, groups and serial/Pass-Thru ports.

 On-Only: Partial-access for control (On) , status and Pass-Thru of

assigned

outlets, groups and serial/Pass-Thru ports.

 View-Only: Partial-access for status and Pass-Thru of assigned

outlets,

groups and serial/Pass-Thru ports.

The administrator may also grant administrative privileges to other user accounts, allowing the SLP to have more than one administrative-level user.

Note: You cannot remove administrative privileges from the Admin user

unless another user has already been given administrative access level privileges created.

1. Click on the Edit link in the Action column for the associated user.

2. On the subsequent User Edit page, select Admin, Power-User, User, Reboot-

Only, On-only or View-Only from the Access Level drop-down menu and press Apply.

Granting or removing Environmental Monitoring viewing privileges:

1. Click on the Edit link in the Action column for the associated user.

2. On the subsequent User Edit page, select Yes or No from the Environmental Monitoring drop-down menu and press Apply.

Adding and Deleting outlet access:

1. Click on the Outlets link in the Access column for the associated user.

2. On the subsequent User Outlets page, select or deselect outlets to be accessed by the user and press Apply.

Adding and Deleting group access:

1. Click on the Groups link in the Access column for the associated user.

2. On the subsequent User Groups page, select or deselect group to be accessed by the user and press Apply.

Adding and deleting serial port access:

1. Click on the Ports link in the Access column for the associated user.

2. On the subsequent User Ports page, select or deselect ports to be accessed by the user and press Apply.

FTP

The FTP configuration page is used for setup and maintenance of all settings required to perform an FTP firmware upload. See

Uploading Firmware on page [100]

for more information on uploading firmware.

Setting the FTP Host IP Address:

1. Enter the IP address in the Host IP Address field and press Apply.

Setting the FTP username:

SecureLinx SLP Remote Power Manager 24

3: Operations

1. Enter the FTP server username in the Username field, and press Apply.

Setting the FTP password:

1. Enter the FTP server password in the Password field, and press Apply. Setting the file path:

1. Enter the path of the file to be uploaded in the Directory field, and press Apply. Setting the filename for upload:

1. Enter the filename of the file to be uploaded in the Filename field, and press

Apply.

Testing the FTP upload configuration:

This test validates that the unit is able to contact and log onto the specified FTP server, download the firmware file and verify that the firmware file is valid for this unit.

1. Press Test.

Enabling or disabling automatic updates:

The SLP features the ability to schedule automation firmware updates. When enabled the SLP will regularly check the FTP servers for a new firmware image and upload it.

1. Select Enabled or Disabled from the drop-down menu and press Apply.

Setting the automatic update scheduled day:

1. Select the desired day for the automatic update from the drop-down menu and

press Apply.

Setting the automatic update scheduled hour:

1. Select the desired hour for the automatic update from the drop-down menu and

press Apply.

Enabling or disabling the FTP server:

The SLP features the ability to upload and download system configuration files to ease implementation across multiple SLP devices. See

Advanced Operations for

more information on configuration upload and download.

1. Select Enabled or Disabled from the drop-down menu and press Apply.

Note: The FTP server must be enabled for configuration upload or download.

SNTP/Syslog

3. The SNTP/Syslog configuration page is used for setup and maintenance of

SNTP and Syslog support. For additional information and configuration requirements for Syslog support, see

Logging on page 93.

Setting the SNTP server address:

SecureLinx SLP Remote Power Manager 25

3: Operations

1. Enter the IP address or hostname in the Primary and/or Secondary Host field and

press Apply.

Setting the Local GMT offset:

1. Select the local offset from GMT value from the drop-down menu and press

Apply.

Setting the Syslog server address:

1. Enter the IP address or hostname in the Primary and/or Secondary Host field and

press Apply.

Changing the Syslog server port number:

1. In the Syslog Port field, enter the port number and press Apply.

SNMP

The SNMP configuration page is used for setup and maintenance of all settings

required to enable SNMP support as well as access to the trap configuration pages. For additional information on SNMP support and detailed descriptions of available

traps, see SNMP on page 68.

Note: Traps are generated according to a hierarchical architecture; i.e. if a

Tower (Unit) Status enters a trap condition, only the Tower Status trap is generated. Infeed and Outlet Status traps are suppressed until the Tower Status returns to Normal.

Enabling or disabling SNMP support:

1. Select Enabled or Disabled from the drop-down menu and press Apply.

Setting the community strings:

1. Enter the community string in the appropriate field and press Apply.

Community strings may be 1 to 24 characters

Setting the trap timer:

1. Enter a trap timer value in the Error Trap Repeat Time field and press Apply.

The Error Trap Repeat Time value may be 1 to 65535 (in seconds).

Setting trap destinations:

1. Enter an IP address or hostname in the appropriate Trap Destination field and

press Apply.

Setting IP restrictions:

1. Select No Restrictions or Trap Destinations Only from the IP Restrictions drop-down menu and press Apply.

Note: When Trap Destinations Only is selected, SNMP Manager GET and

SET requests are only allowed from the IP addresses of the defined traps destinations.

Setting the SNMP SysName, SysLocation or SysContact objects:

SecureLinx SLP Remote Power Manager 26

3: Operations

1. In the appropriate field, enter the SysName, SysLocation or SysContact objects

and press Apply.

Enabling or disabling tower (unit) traps:

1. Click on the Tower Traps link.

2. On the subsequent page, select or deselect the desired traps and press Apply.

Configuring input feed traps:

1. Click on the Input Feed Traps link.

2. On the subsequent Input Feed Traps page, select or deselect the desired traps

and press Apply.

3. For Load traps, enter a maximum load value for the infeed in the High Load

Threshold field and press Apply.

The High Load Threshold value may be 0 to 255 (in amperes).

Configuring outlet traps:

1. Click on the Outlet Traps link.

2. On the subsequent Outlet Traps page, select or deselect the desired traps and

press Apply.

Enabling or disabling Environmental Monitor traps:

1. Click on the Environmental Monitor Traps link.

2. On the subsequent page, select or deselect the desired traps and press Apply.

Configuring the Temperature-Humidity sensor traps:

1. Click on the Sensor Traps link.

2. On the subsequent page, select or deselect the desired traps and press Apply.

3. For Temp traps, enter a minimum and maximum threshold value for the sensor in

the appropriate field and press Apply.

The threshold value may be 0 to 127 degrees Celsius OR 32 to 254 degrees Fahrenheit.

4. For Humid traps, enter a minimum and maximum threshold value for the sensor

in the appropriate field and press Apply.

The threshold value may be 0 to 100 (in percent relative humidity).

LDAP

The LDAP configuration page is used for setup and maintenance of all settings

required to enable LDAP support. For additional information and configuration requirements, see LDAP on page 76.

Enabling or disabling LDAP support:

1. Select Enabled or Disabled from the LDAP drop-down menu and press Apply.

SecureLinx SLP Remote Power Manager 27

3: Operations

Changing the LDAP server port:

1. Enter the port number in the LDAP Port field and press Apply.

Setting the LDAP server address:

1. Enter the IP address or hostname in the Primary and/or Secondary Host field and

press Apply.

Note: If LDAP over TLS/SSL is enabled, MD5 binding is disabled.

Enabling or disabling LDAP over TLS/SSL:

1. Select Yes or No from the Use TLS/SSL drop-down menu and press Apply.

Setting the LDAP bind password type:

1. Select Simple or MD5 from the Bind Type drop-down menu and press Apply.

Note: If MD5 binding is enabled, LDAP over TLS/SSL is disabled.

For more information on LDAP bind password types, see Setting the LDAP bind

password type on page 79.

Setting the search bind Distinguished Name (DN):

1. Enter the fully-qualified distinguished name (FQDN) in the Search Bind field and

press Apply.

Setting the search bind password for Distinguished Name (DN):

1. Enter the Search Bind password in the Search Bind Password field and press

Apply.

Setting the user search base Distinguished Name (DN):

1. Enter the User Search Base DN in the User Search Base DN field and press

Apply.

Setting the user search filter:

1. Enter the User Search Filter in the User Search Filter field and press Apply.

Setting the group membership attribute:

1. Enter the group membership attribute in the Group Membership Attribute Field

and press Apply.

Setting the group membership value type:

1. Select the appropriate value from the drop-down menu and press Apply.

Configuring the authentication order:

1. Select Remote -> Local or Remote Only from the drop-down menu and press Apply.

Note: Lantronix recommends NOT setting the authentication order to

Remote Only until the LDAP has been fully configured and tested.

SecureLinx SLP Remote Power Manager 28

3: Operations

Configuring LDAP groups:

1. Click on the LDAP Groups at the bottom of the page.

Creating an LDAP group:

1. Enter a descriptive group name in the LDAP Group Name field. Up to 24

alphanumeric and other typeable characters (ASCII 33 to 126 decimal) are

allowed; spaces are not allowed. Press Apply.

Removing an LDAP group:

1. Click on the Remove link in the Action column for the group to be removed and

press OK on the subsequent confirmation window.

Changing and LDAP group’s access privilege level:

1. Click on the Edit link in the Action column for the associated LDAP Group.

2. On the subsequent LDAP Group-edit page, select Admin, User, On-Only or

View-Only from the Access Level drop-down menu and press Apply.

For more information on access privilege levels, see Users on page 23.

Granting or removing Environmental Monitoring viewing privileges:

1. Click on the Edit link in the Action column for the associated LDAP Group.

2. On the subsequent LDAP Group-edit page, select Yes or No from the

Environmental Monitoring drop-down menu and press Apply.

Adding and Deleting outlet access:

1. Click on the Outlets link in the Action column for the associated LDAP Group.

2. On the subsequent LDAP Group-Outlets page, select or deselect outlets to be

accessed by the LDAP Group and press Apply.

Adding and Deleting outlet group access:

1. Click on the Groups link in the Action column for the associated LDAP Group.

2. On the subsequent LDAP Group-Groups page, select or deselect outlet groups

to be accessed by the LDAP Group and press Apply.

Adding and Deleting serial port access:

1. Click on the Ports link in the Action column for the associated LDAP Group.

2. On the subsequent LDAP Group-Ports page, select or deselect ports to be

accessed by the LDAP Group and press Apply.

TACACS+

The TACACS+ configuration page is used for setup and maintenance of all settings required to enable TACACS+ support. For additional information and configuration requirements, see TACACS+ on page 29.

Enabling or disabling TACACS+ support:

SecureLinx SLP Remote Power Manager 29

+ 79 hidden pages
