Lantronix 2100 User Manual

IntelliBox®-I/O 2100

Command Reference

Part Number 900-475

Revision B March 2012

Copyright and Trademark

© 2012 Lantronix. All rights reserved. No part of the contents of this book may be transmitted or
reproduced in any form or by any means without the wr itten permission of Lantron ix. Printed in the
United States of America.

Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of The Open
Group. Windows is a trademark of Microsoft Corporation.

Contacts

Lantronix Corporate Headquarters

167 Technology Drive
Irvine, CA 92618, USA

Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]

Technical Support

Online: www.lantronix.com/support

Sales Offices

For a current list of our domestic and international sales offices, go to the Lantronix web site at

www.lantronix.com/about/contact

.

Disclaimer

The information in this guide may change without notice. The manufacturer assumes no
responsibility for any errors that may appear in this guide. For the latest revision of this product
document, please check our online documentation at www.lantronix.com/support/documentation

Revision History

Date Rev. Comments

May 2007 A Initial Document.
March 2012 B Updated for firmware v1.4.0.0.R2.

.

IntelliBox-I/O 2100 Command Reference 2

Table of Contents

List of Figures _____________________________________________________________4
List of Tables ______________________________________________________________5

1: About This Guide 6

Chapter Summaries ________________________________________________________6
Conventions ______________________________________________________________6
Additional Documentation ____________________________________________________7

2: Overview 8

XML Architecture and Device Control ___________________________________________8
Command Line Interface _____________________________________________________8

3: Command Line Interface 9

Configuration Using Telnet ___________________________________________________9
Configuration Using Serial Ports _______________________________________________9

Serial Command Mode ___________________________________________________9

Serial Recovery ________________________________________________________9
Navigating the CLI Hierarchy ______________________________________ __________10
Using Keyboard Shortcuts and CLI ____________________________________________11
Understanding the CLI Level Hierarchy ________________________________________11

4: Configuration Using XML 14

XML Configuration Record Document Type Definition _____________________________14
Quick Tour of XML Syntax __________________________________________________15

Declaration ___________________________________________________________15

Element Start and End Tags ______________________________ _______________15

Element Attributes _____________________________________________________15
Record, Group, Item, and Value Tags _________________________________________16
Importing and Exporting an XML Configuration File _______________________________17
Best Practices ____________________________________________________________18

Importing _____________________________________________________________ 18

Exporting ____________________________________________________________19

Passwords in the XML File _______________________________________________19
XML Configuration Groups __________________________________________________20
XML Status Record Groups and Items _________________________________________34

5: Commands and Levels 48

IntelliBox-I/O 2100 Command Reference 3

List of Figures

Figure 3-1 CLI Level Hierarchy______________________________________________________12
Figure 3-2 Login Level Commands___________________________________________________12
Figure 3-3 Enable Level Commands__________________________________________________13
Figure 4-1 DTD for XCRs __________________________________________________________14
Figure 4-2 XML Example __________________________________________________________15
Figure 4-3 XML Group Example_____________________________________________________16
Figure 4-4 XML Example of Multiple Named Values _____________________________________16
Figure 4-5 XML Example of Multiple Items_____________________________________________17
Figure 4-6 XML Example with Multiple Groups _________________________________________17
Figure 4-7 XML Example of Supplying Passwords_______________________________________20

IntelliBox-I/O 2100 Command Reference 4

List of Tables

Table 4-8 XCR Groups ____________________________________________________________20
Table 4-9 XSR Groups and Items____________________________________________________34
Table 5-1 Commands and Levels____________________________________________________49

IntelliBox-I/O 2100 Command Reference 5

1: About This Guide

This guide describes how to configure the IntelliBox-I/O 2100 using the Command Line Interface
(CLI) and/or Extensible Markup Language (XML). It is written for software developers and system
integrators.

Chapter Summaries

This table lists and summarizes each chapter and appendix.

Chapter Summary

Chapter 2: Overview
Chapter 3: Command Line Interface

Chapter 4: Configuration Using XML

Chapter 5: Commands and Levels

Conventions

The table below lists and describes the conventions used in this book.

Convention Description

Bold text Default parameters.
Italic text Required values for parameters
Brackets [ ] Optional parameters.
Angle Brackets < > Possible values for parameters.
Pipe | Choice of parameters.

Gives an overview of CLI and XML.
Lists commands and describes how to use CLI to

configure the IntelliBox.
Lists XCR groups and items and describes how to use

XCRs to configure the IntelliBox.
Provides an index of the CLI Command Hierarchy with

hyperlinks to the corresponding command details.

Warning Warning: Means that you are in a situation that could cause

equipment damage or bodily injury. Before you work on any
equipment, you must be aware of the hazards involved with electrical
circuitry and familiar with standard practices for preventing
accidents.

Note Note: Means take notice. Notes contain helpful suggestions, information,

or references to material not covered in the publication.

Caution Caution: Means you might do something that could result in faulty

equipment operation, or loss of data.

Screen Font
(Courier New)

CLI terminal sessions and examples of CLI input.

IntelliBox-I/O 2100 Command Reference 6

Additional Documentation

Visit the Lantronix web site at www.lantronix.com/support/documentation for the latest
documentation and the following additional documentation.

Document Description

IntelliBox-I/O 2100 User Guide Information about the IntelliBox hardware, testing the IntelliBox,

DeviceInstaller Online Help Instructions for using the Lantronix Windows-based utility to locate

1: About This Guide

and integrating the IntelliBox device into your product.

the IntelliBox and to view its current settings.

Secure Com Port Redirector
User Guide

Com Port Redirector
Quick Start and Online Help

Instructions for using the Lantronix Windows-based utility to create
secure virtual com ports.

Instructions for using the Lantronix Windows-based utility to
create virtual com ports.

IntelliBox-I/O 2100 Command Reference 7

2: Overview

Evolution OS™ is the Lantronix cutting-edge operating system that supports three convenient
configuration methods: Web Manager, Command Line Interface (CLI), and Extensible Markup
Language (XML). For more information ab ou t th e Web Ma nag er , see the IntelliBox-I/O 2100 User
Guide at the Lantronix website.

XML Architecture and Device Control

XML is a fundamental building block for the future gr owth of Machine-to-Machine (M2 M) networks.
Evolution supports XML configuration records that make configuring the device server easy for
users and administrators. XML configuration records are easy to edit with a a standard text editor
or an XML editor.

For a brief overview of XML, see Chapter 4: Configuration Using XML . It provides rules on basic
XML syntax, a guide to the specific XML tags used, and a guide to using XML configuration
records.

Command Line Interface

Making the edge-to-enterprise vision a reality, Evolution OS™ uses industry-standard tools for
configuration, communication, and control. For example, the Evol ution OS™ uses a command l ine
interface (CLI) whose syntax is very similar to that used by data center equipment such as routers
and hubs.

For details of the CLI, see Chapter 5: Commands and Levels. It provides an index of the CLI
Command Hierarchy with links to the corresponding command details. The CLI provides
commands for configuring, monitoring, and controlling the device server.

IntelliBox-I/O 2100 Command Reference 8

3: Command Line Interface

This chapter describes accessing the IntelliBox by using Telnet, SSH, or serial ports to configure
the IntelliBox, navigating the Comma nd Line I nt er fa ce (C LI) , typ ing key bo ar d sh or tcu ts , and
moving between the levels.

It contains the following sections:

 Configuration Using Telnet
 Configuration Using Serial Ports
 Navigating the CLI Hierarchy
 Using Keyboard Shortcuts and CLI
 Understanding the CLI Level Hierarchy

Refer to Chapter 5: Commands and Levels for a complete list of levels, commands, and
descriptions.

Configuration Using Telnet

To access and configure the device server by using a Telnet session over the network, you must
first establish a Telnet connection. You can also establish a Telnet connection by clicking the
Telnet Configuration tab in DeviceInstaller. See the DeviceInstaller Online Help for more
information, available on our website www.lantronix.com/support/downloads

.

To access the IntelliBox by using Telnet, perform the following steps.

1. Click Start > Run. The Run dialog box displays.

2. Type cmd in the dialog box and press OK.

3. Type telnet x.x.x.x (x.x.x.x is the IP address). The IntelliBox is online when the
command prompt (>) displays. You are at the root level of the CLI.

Note: Depending on the level of security, a password may be requ ire d.

Configuration Using Serial Ports

Serial Command Mode

The serial port can be configured to operate in command mode permanently or to be triggered
under specified conditions. See the line <line> Level command description for more
information.

Serial Recovery

In this mode, the normal boot process is interrupted, allowing recovery from unknown or incorrect
configuration settings. While the back door is active, the CLI prompt is chang ed to “>>” (instead of
“>”) and the Web Manager is inaccessible. These serve as an important indication that the device
boot processes has been temporarily ha lte d. T o com plete the boot process, terminate the serial
CLI session (with the exit command).

IntelliBox-I/O 2100 Command Reference 9

To configure the Lantronix device server locally using a serial port, connect a terminal or a PC
running a terminal emulation program to one of the device server's serial ports. Configure the
terminal for 9600 baud, 8-bit, no parity, 1 stop bit, and no flow control.

1. Power off the device.

2. Press and hold down the exclamation point (!) key.

3. Power on the device. After about ten seconds, the exclamation point will display on the
terminal or PC screen.

4. Type xyz within 5 seconds to display the CLI prompt.

Navigating the CLI Hierarchy

The CLI is organized into a hierarchy of levels. Each level has a group of commands for a specific
purpose. For example, to configure a setting for the FTP server, one would navigate to the FTP
level, which is under the configuration level.

 To move to a different level—Enter the name of the level from within its pa rent level. For

example, to enter the tunnel level, type tunnel <number> at the enable prompt. This
displays: <enable> tunnel <number>#.

3: Command Line Interface

 To ex it and re tu rn to o ne leve l hi gher—Type exit and press the Enter key. Typing exit at the

login level or the enable level will close the CLI session. If Line — Command Mode is
specified as Always, a new session starts immediately.

 To view the current configuration at any level—Type show.
 To view the list of co mmands available at the cu rrent level—Type the que stion mark "?". Items

within < > (e.g. <string>) are required parameters.

 To view the available commands and explanations—Type the asterisk ( *).
 To view the list of commands available for a partial command—Type the partial command

followed by the question mark "?". For example: <tunnel-1>#echo? displays a list of all
echo commands at the tunnel level.

 To view available commands and their explanations for a partial command—Type the partial

command followed by the asterisk ( *). For example: <tunnel-1>#echo* displays a list of all
echo commands and descriptions at the tunnel level.

 To view the last 20 commands entered at the CLI—Type show history.

IntelliBox-I/O 2100 Command Reference 10

Using Keyboard Shortcuts and CLI

One useful shortcut built into Evolution OS™ is that the complete text of a command does not
have to be entered to issue a command. Typing just enough characters to uniquely identify a
command, then hitting enter, can be used as a short cut for a command. For example, at the
enable level, "sh" can be used for the "show" command.

Tab Completion is also available. Typing the first few characters of a command, then hitting the
<tab> key displays the first command that begins with those characters. Hitting the <tab> key
again displays the next command that begins with the original characters typed. You can press
<Enter> to execute the command or you can backspace to edit any parameters.

The following key combinations are allowed when configuring the device server using the CLI:

 Ctrl + a: place cursor at the beginning of a line
 Ctrl + b: backspace one character
 Ctrl + d: delete one character
 Ctrl + e: place cursor at the end of the line
 Ctrl + f: move cursor forward one character
 Ctrl + k: delete from the current position to the end of the line

3: Command Line Interface

 Ctrl + l: redraw the command line
 Ctrl + n: display the next line in the history
 Ctrl + p: display the previous line in the history
 Ctrl + u: delete entire line and pl ace cursor at start of prompt
 Ctrl + w: delete one word back
 Ctrl + z: a shortcut for the exit command
 Esc + b: move cursor back one word
 Esc + f: move cursor forward one word

Understanding the CLI Level Hierarchy

The CLI hierarchy is a series of levels. Arranging commands in a hierarchy of levels provides a
way to organize and group similar commands, provide different levels of security, and reduce the
complexity and number commands and options presented to a user at one time.

When you start a command line session, you begin at the login level. This level can be password
protected and provides access to hig h lev el sta tu s, a few diag no stic commands, and the enable
level. Further device information and configuratio n are accessed via the enable level.

The enable level can also be password protected and is the gateway to full configuration and
management of the device server. There are comma nds for gathering and effecting all elements of
device status and configuration, as well as commands that take you to additional levels. For
instance, tunnel specific status and configuration is found under the "tunnel" level, and network
specific status and configuration commands are found under the "configuration" level.

An overview of the levels in the IntelliBox is presented in Figure 3-1.

IntelliBox-I/O 2100 Command Reference 11

Figure 3-1 CLI Level Hierarchy

(login) enable

ssh

ethernet linkif 1

lpd <number>

rss

line <line>

io

chem

<number>

configure

modbus

device

filesystem

lpd

ip

arp

eventtrak
(number)

ftp

host <number>

http

ip filter

query port

terminal

<number>

tcp

snmp

syslog

tunnel <line> accept

connect

disconnect

modem

packing

serial

icmp

cli

match

<number>

task <number>

udp

tftp

ssl

3: Command Line Interface

Commands at the login level, shown in Figure 3-2, do not affect curr en t confi gur ation settin gs and
are not displayed initially. If you type <?>, you will see the login sub-commands. These commands
provide diagnostic and status information only.

>?
clrscrn enable
exit ping <host>
ping <host> <count> ping <host> <count> <timeout>
show show history
show ibio2100 trace route <host>

Figure 3-2 Login Level Commands

>

IntelliBox-I/O 2100 Command Reference 12

3: Command Line Interface

To configure the , you must be in the enable level and any of its sub-levels. Figure 3-3 shows the
enable level commands.

Figure 3-3 Enable Level Commands

>enable
<enable>#?
auto show interfaces auto show processes
auto show xsr chem <number>
clear interfaces counters clear query port counters
clear xsr counters clrscrn
configure connect
connect line <line> device
disable exit
filesystem io
kill line <line> kill ssh <session>
kill telnet <session> line <line>
lpd no clear interfaces counters
no clear query port counters no clear xsr counters
nslookup nslookup <host>
ping <host> ping <host> <count>
ping <host> <count> <timeout> reload
reload factory defaults secret xcr dump
secret xcr dump <group list> secret xcr export <file>
secret xcr export <file> <group list> show
show history show hosts
show ibio2100 show interfaces
show ip sockets show processes
show sessions show xsr
ssh ssh <optClientUsername> <host>
ssh <optClientUsername> <host> <port> ssl
telnet <host> telnet <host> <port>
trace route <host> tunnel <line>
write xcr dump
xcr dump <group list> xcr export <file>
xcr export <file> <group list> xcr import <file>
xcr import <file> <group list> xcr list
xsr dump xsr dump <group list>
xsr export <file> xsr export <file> <group list>
xsr list

<enable>#

See the Chapter 5: Co mmands and Leve ls at the end of this document for a com plete list of levels,
commands, and descriptions.

IntelliBox-I/O 2100 Command Reference 13

4: Configuration Using XML

<!DOCTYPE configrecord [
<!ELEMENT configrecord (configgroup+)>
<!ELEMENT configgroup (configitem+)>
<!ELEMENT configitem (value+)>
<!ELEMENT value (#PCDATA)>
<!ATTLIST configrecord version CDATA #IMPLIED>
<!ATTLIST configgroup name CDATA #IMPLIED>
<!ATTLIST configgroup instance CDATA #IMPLIED>
<!ATTLIST configitem name CDATA #IMPLIED>
<!ATTLIST value name CDATA #IMPLIED>
]>

The device server provides an Extensible Markup Language (XML) interface that you can use to
configure device server devices. Every configuration setting that can be issued from the device
server Web Manager and CLI can be specified using XML.

The device server can import and export configuration settings as an XML docu ment known as an
XML Configuration Record (XCR). An XCR can be imported or exported via the CLI, a Web
browser, FTP, or the device server filesystem. An XCR can contain many configuration settings or
just a few. For example, it might change all of the configurable parameters fo r a device server, or it
may only change the baud rate for a single serial line. Using XCRs is a straightforward and flexible
way to manage the configuration of multiple device server devices.

XML Configuration Record Document Type Definition

An XML document type definition (DTD) is a description of the str uct ur e an d cont en t of an XML
document. It verifies that a document is valid. XCRs are exported using the DTD shown in

Figure 4-1.

Figure 4-1 DTD for XCRs

The device server DTD rules state the following:

 The XML document element is a <configrecord> element. This is the root element.
 A <configrecord> must have one or more <configgroup> elements and can have a

version attribute.

 A <configgroup> must have one or more <configitem> elements and can have name and

instance attributes.

 A <configitem> element must have one or more <value> elements and can have a name

attribute.

 A <value> element can have only data and can have a name attribute.
 The name attrib ute identifies a group, item, or value. It is always a quoted string.
 The instance attribute identifies the specific option, like the serial port number. The “instance”

attribute is always a quoted string.

IntelliBox-I/O 2100 Command Reference 14

Notes:

<?xml version=”1.0” standalone=”yes”?>
<configrecord>
<configgroup name = “serial command mode” instance = “1”>

<configitem name = “mode serial string”>

<value>disable</value>

</configitem>
</configgroup>
</configrecord>

 The name fo r each <con fig gr oup> ( s pecified with th e n ame attr ibu te) is the group

name listed in the Web Manager XCR groups or with the “xcr list” CLI command.
See the IntelliBox-I/O 2100 User Guide for more information about the Web
Manager XCR groups.

 An empty or missing <value> element in each present <configgroup> clears the

setting to its default.

Quick Tour of XML Syntax

Declaration

The first line, <?xml version=”1.0” standalone=”yes”?>, is called the XML declaration. It
is required and indicates the XML version in use (normally version 1.0). The remainder of the file
consists of nested XML elements, some of which have attributes and content.

Element Start and End Tags

An element typically consists of two tags: start tag and an end tag that surrounds text and other
elements (element content). The start tag consists of a name surrounded by angle brackets, for
example <configrecord>. The end tag consists of the same name surrounded by angle
brackets, but with a forward slash preceding the name, for example </configrecord>.

4: Configuration Using XML

The element content can also contain other “child” elements.

Element Attributes

The XML element attributes that are name-value pairs included in the start tag after the element
name. The values must always be quoted, using single or double quotes. Each attribute name
should appear only once in an element.

Figure 4-2 shows an XML example which consists of a declaration (first line), nested elements with

attributes and content.

Figure 4-2 XML Example

IntelliBox-I/O 2100 Command Reference 15

The Evolution OS™ uses the attributes in the following subsections to label the group
configuration settings.

Record, Group, Item, and Value Tags

<?xml version=”1.0” standalone=”yes”?>
<configrecord>
<configgroup name = “serial command mode” instance = “1”>

<configitem name = “mode”>

<value>disable</value>

</configitem>
</configgroup>
</configrecord>

<?xml version=”1.0” standalone=”yes”?>
<configgroup name = “ssh server”

<configitem name = “host rsa keys”>

<value name = “public key”></value>
<value name = “private key”></value>

</configitem>
</configgroup>

A <configgroup> is a logical grouping of configuration parameters and must contain one or
more <configitem> elements. It must have a name attribute and may have an instance
attribute.

A <configitem> is a specific grouping of configuration parameters relevant to its parent group.
An item takes the name attribute and must contain one or more value elements. For example, the
line group might have parameters such as baud rate, data bits, and parity.

A value may specify the value of a configuration parameter. It may contain the name attribute. In
this example, a value of 9600 might be specified for baud rate; 7 may be specified for data bits,
and even may be specified for parity.

A name attribute identifies the group, item, or value. It is always quoted (as are all XML attributes).
For example, a group that contains serial port parameters has the name “line”.

An instance attribute identifies which of several instances is being addressed. It is always quoted.
For example, the serial port name (in the line configgroup) has the instance “1” to indicate serial
port 1 or “2” to specify serial port 2.

The following figures show examples of XML conf igu ra tio n reco rd s an d th e us e of th e
<configrecord>, <configgroup>, <configitem>, and <value> XML elements.

4: Configuration Using XML

Figure 4-3 XML Group Example

Figure 4-4 XML Example of Multiple Named Values

IntelliBox-I/O 2100 Command Reference 16

Figure 4-5 XML Example of Multiple Items

<?xml version=”1.0” standalone=”yes”?>
<configgroup name = “email” instance = “1”>

<configitem name = “to”>

<value>[e-mail]></value>
</configitem>
<configitem name = “from”>

<value>[e-mail]></value>
</configitem>

</configgroup>

<?xml version=”1.0” standalone=”yes”?>
<configgroup name = "ftp server">
<configitem name = "state">
<value>enable</value>
</configitem>
<configitem name = "admin username">
<value>admin</value>
</configitem>
<configitem name = "admin password">
<value><!-- configured and ignored --></value>
</configitem>
</configgroup>
<configgroup name = "tftp server">
<configitem name = "state">
<value>enable</value>
</configitem>
<configitem name = "allow file creation">
<value>disable</value>
</configitem>
</configgroup>

Figure 4-6 XML Example with Multiple Groups

4: Configuration Using XML

Importing and Exporting an XML Configuration File

IntelliBox-I/O 2100 Command Reference 17

An XCR can be imported or exported using the following methods:

 Filesystem—XCRs can be saved to the device server file system and imported or accessed as

needed. See Best Practices or the Filesystem Browser section in the IntelliBox-I/O 2100 User
Guide.

 CLI—XCRs can be imported (captured) or exported (dumped) directly to a Telnet, SSH, or

serial line CLI session. Capturing an XCR can be started by pasting a valid XCR directly into
the CLI prompt. Evolution OS immediately processes the configuration record, changing any

settings specified. This can be done on any level, including the root. Special tags in the XML
allow for providing root and enable level passwords so that this can also be done at the
password prompt.

 Web browser—Web Man ager can be used to import and export an XCR to the device server

file system. It can also be used to import an XCR from an external source such as your local
hard drive.

 FTP—The device server FTP server can export and import XCRs when an FTP get or put

command on the filename intellibox_io.xcr is requested. On export (FTP get of
intellibox_io.xcr), the FTP server obtains the current XCR from Evolution OS™ and sends it as
a file. On import (FTP put of intellibox_io.xcr), the FTP server processes the file by sending it
directly to the XML engine. In both cases the device server filesystem is not accessed. The file
intellibox_io.xcr is not read from or written to the file system. See FTP in the IntelliBox-I/O
2100 User Guide.

Best Practices

You can import or export an entire XCR, or just a portion of it, by specifying the group name and/or
group instances. In the examples below, import and export operations are performed from the CLI
on the local filesystem and require a XCR on the local filesystem. The Web Manager provide s th e
same functionality.

4: Configuration Using XML

Caution: Using Microsoft Word to edit and save an XCR will change the format of

the file and make it incompatible with Evolution OS. This is true even if
the file is saved as Plain Text (.txt) or an XML Docu ment (.xml). Notepa d,
a third party text editor, or a specialized XML editor should be used
instead.

Importing

The following syntax can be used to import configurations from a file:

xcr import <file>
xcr import <file> <groups and/or group:instances>

The first line imports all groups specified in the XML config record named in <file>. Any filename
is valid, and the file name and extension are not import an t.

Caution: The filename intellibox_io.xcr is not acceptable, because performing a

FTP get on that name produces the current configuration and does not
perform an FTP from the filesystem. Also, the filename intellibox_io.xsr
is not acceptable, because performing an FTP get on that name
produces the current status and does not get anything from the
filesystem.

In the second line:

 Instance follows group with a colon (see the third example on the next page).
 Multiple groups are separated with a comma.
 Any white space requires the list of groups to be quoted.
 Only the named groups get imported, even if the XCR contains additional XCR groups.

IntelliBox-I/O 2100 Command Reference 18

4: Configuration Using XML

The following syntax can be used to export configurations to a file on the device server’s file
system:

xcr export <file>
xcr export <file> <groups and/or group:instances>

The same guidelines above regarding importing configurations also apply to exporting
configurations. If no groups are specified, then the export command will export all configuration
settings to the file. If instances are specified after the groups, only those group instances are
written. If no instance is specified, all instances of that group are written.

Exporting

The following example exports only the accept mode tunneling settings for line 1 to the file
“tunnel_1.xcr” on the device server filesystem:

xcr export tunnel_1.xcr “tunnel accept:1”

The following example exports only the connect mode tunneling settings for all ports to the file
“tunnel_all.xcr” on the device server filesystem:

xcr export tunnel_all.xcr “tunnel connect”

The following example imports only the settings for line 2 from a XCR named “factory_config.xcr”
on the device server filesystem. If “factory_config.xcr” has other configuration settings, they are
ignored:

xcr import factory_config.xcr “line:2”

The following example imports only line settings for all ports from a configuration record on the
device server filesystem named “foobar.xcr”:

xcr import foobar.xcr “line”

To import only disconnect mode tunneling settings for port 1 and serial line settings for port 2 from
an XML configuration record named “production.xcr” that contains these settings (and possibly
more), issue the following command:

xcr import production.xcr "tunnel disconnect:1, line:2"

The following example imports all tunneling settings and line settings for all serial ports from a file
named xcr_file:

xcr import xcr_file "tunnel accept, tunnel connect, tunnel
disconnect, tunnel modem, tunnel packing, tunnel serial, tunnel
start, tunnel stop, line"

The following example exports only accept mode tunneling settings on serial port 1, and line
settings on serial port 2 to a file named tunnel_config_t1_l2.xcr on the device server filesystem.

xcr export tunnel_config_t1_l2.xcr "tunnel accept:1, line:2"

The following example exports connect mode tunneling and line settings for all ports to the file
tunnel_config.xcr on the device server filesystem:

xcr export tunnel_config.xcr "tunnel, line"

Passwords in the XML File

If you log in to a device server to which you will be pasting an XCR, you do not need to include
passwords in the file, because you are already logged into the device. However, if you send an
XCR to one or more devices that are password protected, you can include the appropriate
passwords in the XCR and skip the login steps.

IntelliBox-I/O 2100 Command Reference 19

The “xml paste passwords” <configgroup> name is used with the “passwords” <configitem>

<!—To supply passwords when importing via cli capture -->
<configgroup name = "xml paste passwords">
<configitem name = "passwords">
<value name = "cli login"></value>
<value name = "cli enable level"></value>
</configitem>
</configgroup>

name and “cli login” and “cli enable level” values to specify the passwords to use when the device
has been configured with password protection. The password value is clear text. To protect the
password, establish an SSH connection to the device server. Figure 4-7 shows an example.

Figure 4-7 XML Example of Supplying Passwords

XML Configuration Groups

4: Configuration Using XML

Table 4-8 lists the Intellibox XCR groups in alphabetical order. This table indicates the various

group items, as well as some possible value names and options.

Note: Any instance of < in the table may be read as < (the html encoded form for

less than) and any instance of > may be read as > ( the html encoded form for gr eater
than).

Table 4-8 XCR Groups

Group Name Group Item Value Name Value Options Additional

Information

arp arp delete ip address Remove an entry

from the ARP
table. Specify the
entry by its IP
address.

arp entry ip address

mac address

timeout Default: 60

seconds

IntelliBox-I/O 2100 Command Reference 20

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

cli login password Value is SECRET,

hidden from user
view.

enable level password Value is SECRET,

hidden from user
view.

quit connect line Accepts text

containing control
characters, for
example,
<control>
A represents
control-A Default:
<control>L

device cpu speed

short name
long name
serial number Read only.
firmware version Read only.

email
(Attribute of
“instance” is a
number.)

ethernet
(Attribute of
“instance” is
“eth0”.)

to Multiple addresses

may be separated
with semicolons.

cc Multiple addresses

may be separated

with semicolons.
from
reply to
subject
message file
overriding domain
server port Default: 25
local port <Random>,

...

priority urgent, high, normal,

low, very low

trigger inpu t name xio1, xio2

level high, low
speed auto, 10, 100 Default: auto
duplex auto, half, full Default: auto

Default:
<Random>

Default: normal

IntelliBox-I/O 2100 Command Reference 21

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

event trak
(Attribute of
“instance” is a
number.)

match
(Attribute of “instance” is
a number.)

task
(Attribute of “instance” is
a number.)

string

wildcard

timeout milliseconds

case sensitive no, yes

rss trace matches <None>,

...

description

activity none, ping, output

ping address

output control exclusive, logical-or

rss trace steps enable, disable

rss trace triggers enable, disable

rss trace ping

responses

enable, disable

IntelliBox-I/O 2100 Command Reference 22

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

event trak
(Attribute of
“instance” is a
number.)

(continued)

step
(Attribute of “instance” is
a number.)

name <None>,

...

activity

advance upon

advance timeout

value

advance timeout

units

fallback timeout

value

fallback timeout

units

fallback timeout

enabled

fallback if input high

to low

fallback if input low

to high

fallback if matched

string

fallback if trigger a

fallback if trigger b

fallback if output

data present

fallback if accepted

connection

fallback if accepted

disconnection

fallback if ping

response

upon fallback send

trigger

upon advance send

email

upon advance email

subject

IntelliBox-I/O 2100 Command Reference 23

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

event trak
(Attribute of
“instance” is a
number.)

(continued)

ftp server state enable, disable Default: enable

host
(Attribute of
“instance” is a
number.)

http
authentication uri

(Attribute of
“instance” is the
URI.)

step
(Attribute of “instance” is
a number.) (continued)

admin username Default: admin
admin password Value is SECRET,

name
protocol telnet, ssh Default: telnet
ssh username
remote address
remote port Default: 0
user delete name Deletes an HTTP

realm
type
user

(Attribute of “instance” is
the user name.)

upon advance clear

receive buffer

upon advance send

line

upon advance send

data

upon advance send

file name

upon advance send

trigger

upon advance rss

upon advance rss

title

hidden from user
view.

Authentication URI
user. The value
element is used to
specify the user for
deletion.

password

IntelliBox-I/O 2100 Command Reference 24

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

http server state enable, disable Default: enable

port <None>, ... Default: 80
secure port <None>, ... Default: 443
secure protocols ssl3, tls1.0, tls1.1 May contain zero,

one, or more of the
values, separated
by commas.
Default: ssl3,
tls1.0, tls1.1

max timeout Default: 10

seconds
max bytes Default: 40960
logging state enable, disable Default: enable
max log entries Default: 50
log format Default: %h %t

"%r" %s %B

"%{Referer}i"

"%{User-Agent}i"

icmp state enable, disable Default: enable
input output

(Attribute of
“instance” is a
number.)

input output direction output, input

control force closed, force

open, normal

rss trace transitions enable, disable

IntelliBox-I/O 2100 Command Reference 25

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

interface
(Attribute of
“instance” is
eth0”)

ip

ip filter delete entries enable, disable If enabled, deletes

bootp enable, disable Default: disable
dhcp enable, disable Default: enable
ip address <None>, ... Accepts an IP

address and mask

as either: (1) IP

address only

(192.168.1.1) gets

a default mask, (2)

CIDR

(192.168.1.1/24),

or (3) Explicit mask

(192.168.1.1

255.255.255.0).

default gateway <None>, ... Accepts in IP

address in dotted

notation, like

192.168.1.1.
hostname
domain
dhcp client id Set the identi ty of

the client device.

primary dns <None>, ... Accepts in IP

address in dotted
notation, like

192.168.1.1.
secondary dns <None>, ... Accepts in IP

address in dotted
notation, like

192.168.1.1.
multicast time to live Default: 1 hops

any existing
entries before
adding “filter
entry”.

filter delete ip address Deletes a specific

IP filter entry.

net mask Deletes a specific

IP filter entry.

filter entry ip address If configured, is a

specific IP
address.

net mask If configured, is a

specific net mask.

IntelliBox-I/O 2100 Command Reference 26

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

line
(Attribute of
“instance” is a
number.)

lpd
(Attribute of
“instance” is a
number.)

modbus tcp server state enable, disable Default: disable

query port state

name
interface rs232, rs485 half-

duplex, rs485 full-

duplex
termination enable, disable Default: disable
state enable, disable Default: depends

protocol none, tunnel, ppp,

lpd
baud rate Default: 9600 bits

parity even, none, odd Default: none
data bits 7, 8 Default: 8
stop bits 1, 2 Default: 1
flow control none, hardware,

software
xon char Accepts a control

xoff char Accepts a control

banner enable, disable Default: enable
binary enable, disable Default: disable
soj enable, disable Default: disable
eoj enable, disable Default: disable
formfeed enable, disable Default: disable
convert newline enable, disable Default: disable
soj text
eoj text
queue name

additional port <None>, ... Default: <None>
response timeout Default: 3000

Default:

on instance
Default:

per second

Default: none

character, for
example,
<control>
A represents
control-A Default:
<control>Q

character, for
example,
<control>
A represents
control-A Default:
<control>S

milliseconds

IntelliBox-I/O 2100 Command Reference 27

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

rss feed enable, disable Default: disable

persist enable, disable Default: disable
max entries Default: 100

serial command
mode
(Attribute of
“instance” is a
number.)

snmp state enable, disable Default: enable

mode
echo serial string
serial string
signon message
wait time

read community Value is SECRET,

hidden from user
view. Default:
public

write community Value is SECRET,

hidden from user
view. Default:

private
system contact
system name Default: <Default>
system description Default: <Default>
system location
traps state enable, disable Default: enable

primary destination
secondary

destination

IntelliBox-I/O 2100 Command Reference 28

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

ssh client delete known hosts enable, disable If enabled, deletes

any existing hosts

before adding

“known host”.
known host delete name Specify the known

host to delete.
known host

(Attribute of “instance” is
required for the known
host name)

delete client users enable, disable If enabled, deletes

client user
(Attribute of “instance” is
required for the user
name)

ssh command
mode

ssh server host rsa keys public key

state enable, disable
port
max sessions

host dsa keys public key

delete authorized users
authorized user delete name
authorized user

(Attribute of “instance” is
required for the
authorized user name)

public rsa key
public dsa key

any existing client

users before

adding “client

user”.

password
remote command
public rsa key
private rsa key
public dsa key
private dsa key

private key

private key

password
public rsa key
public dsa key

IntelliBox-I/O 2100 Command Reference 29

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

ssl RSA certificate certificate Enter the text of

the certificate.

private key Enter the text of

the private key.

If configured and

not exporting

secrets, exports

only a placeholder.
DSA certificate certificate Enter the text of

the certificate.

private key Enter the text of

the private key.

If configured and

not exporting

secrets, exports

only a placeholder.
delete all cas enable, disable If enabled, deletes

any existing

trusted cas before

adding “trusted

ca”.

syslog state enable, disable Default: disable

host
local port Default: 514
remote port Default: 514
severity log level none, emergency,

alert, critical, error,
warning, notice,
information, debug

tcp resets enable, disable Default: enable

ack limit Number of packets

send data standard , expedited Default: standard

telnet command
mode

state enable, disable Default: enable
port Default: 23
max sessions Default: 3

Default: none

received before an

ACK is forced.

Default: 3 packets

IntelliBox-I/O 2100 Command Reference 30

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

terminal
(Attribute of
“instance” is
either “network”
or a number.)

tftp server state enable, disable Default: enable

tunnel accept
(Attribute of
“instance” is a
number.)

terminal type Default:

UNKNOWN
login connect menu enable, disable Default: disable
exit connect menu enable, disable Default: disable
send break Accepts a control

character, for

example,

<control>

A represents

control-A
break duration Default: 500

milliseconds
echo enable, disable Default: enable

allow file creation enable, disable Default: disable
accept mode disable, always, any

character, start
character, modem
control asserted,

modem emulation
local port <None>, ... Default: <None>
protocol tcp, ssh, telnet, tcp

aes, ssl
tcp keep alive <None>, ... Default: 45000

aes encrypt key Value is SECRET,

aes decrypt key Value is SECRET,

flush serial enable, disable Defa ult: disable
block serial enable, disable Default: disable
block network enable, disable Default: disable
password password Value is SECRET,

prompt enable, disable Default: disable
email connect <None>, ... De fault: <None>
email disconnect <None>, ... Default: <None>

Default: always

Default: tcp

milliseconds

hidden from user
view.

hidden from user
view.

hidden from user
view.

IntelliBox-I/O 2100 Command Reference 31

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

tunnel connect
(Attribute of

“instance” is a
number.)

tunnel
disconnect

(Attribute of
“instance” is a
number.)

connect mode disable, always, any

character, start
character, modem
control asserted,

modem emulation
remote address
remote port
local port <Random>,

...
protocol tcp, udp, ssh, telnet,

tcp aes, udp aes, ssl
ssh username Username must

tcp keep alive <None>, ... Default: 45000

aes encrypt key Value is SECRET,

aes decrypt key Value is SECRET,

reconnect time Default: 15000

flush serial enable, disable Defa ult: disable
block serial enable, disable Default: disable
block network enable, disable Default: disable
email connect <None>, ... De fault: <None>
email disconnect <None>, ... Default: <None>
output select output

mode logical or, exclusive

control
stop character Accepts a control

modem control enable, disable Default: disable
timeout Default: 0

flush serial enable, disable Defa ult: disable

Default: disable

Default:
<Random>

Default: tcp

correspond to a
configured ssh
client user.

milliseconds

hidden from user
view.

hidden from user
view.

milliseconds

character, for
example,
<control>
A represents
control-A

milliseconds

IntelliBox-I/O 2100 Command Reference 32

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

tunnel modem
(Attribute of
“instance” is a
number.)

tunnel packing
(Attribute of
“instance” is a
number.)

tunnel serial
(Attribute of
“instance” is a
number.)

tunnel start
(Attribute of
“instance is a
number.”

tunnel stop
(Attribute of
“instance is a
number.”

echo pluses enable, disable Default: disable
echo commands enable, disable Default: enable
verbose response enable, disable Default: enable
response type text, numeric Default: text
error unknown

commands
incoming connection disabled, automatic,

connect string
display remote ip enable, disable Default: disable
packing mode disable, timeout,

timeout Default: 1000

threshold Default: 512 bytes
send character Accepts a control

trailing character Accepts a control

dtr asserted while

buffer size
start character import/export
echo enable import/export

stop character import/export
echo enable import/export

enable, disable Default: disable

Default: disabled

manual

Default: disable

send character

milliseconds

character, for
example,
<control>
A represents
control-A Default:
<control>M

character, for
example,
<control>
A represents
control-A

Default: asserted
connected,
continuously
asserted,
unasserted, truport

disable

disable

while connected

IntelliBox-I/O 2100 Command Reference 33

4: Configuration Using XML

Group Name Group Item Value Name Value Options Additional

Information

xml import
control

restore factory
configuration

delete cpm groups enable, disable
cpm group delete name
delete http authentication

uris

http authentication uri
delete

reboot enable, disable Reboots after

name Deletes the

enable, disable Deletes existing

http authentication

uris before

importing new

ones.

specified http

authentication uri.

importing.

XML Status Record Groups and Items

Table 4-9 lists the supported XML Status Record (XSR) groups and items. These groups and

items show the status of the device in XML form and can only be exported. The XSR schema
differs slightly from the XCR groups and items in that the XSR allows groups within groups.

Currently, the only XSR groups that contain any sub groups are buffer pools and tunne l. The buffer
pools group has the following sub groups:

 Protocol stack
 Ethernet driver
 Line

The tunnel group has the following sub groups:

 Tunnel Modem

Table 4-9 XSR Groups and Items

Group Name Item Name Value Name Valid Values

arp
(Attribute of “instance” is

“eth0”.)

buffer pool this group contains other

arp entry ip address

mac address
age
type dynamic

static

groups: ethernet driver,
line #, protocol stack.

IntelliBox-I/O 2100 Command Reference 34

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

device product info product type

serial number
firmware version
uptime
permanent config saved

unsaved

email
(Attribute of “instance” is a

number.)

email log
(Attribute of “instance” is a

number.)
ethernet driver

(Within group “buffer pool”.)

eventtrak
(Attribute of “instance” is a

number.)

filesystem filesystem size

success sent

sent with retries
failed
queued
entry time

log

buffer headers total

free

used

max used
cluster pool cluster size

total

free

used

max used
task description
current step
step name

available clean

available dirty

used total

used data

busy
entries file count

directory count

system count

open count

lock count

share count

IntelliBox-I/O 2100 Command Reference 35

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

filesystem (continued) banks current A

B
firmware begin
firmware end
firmware erase cycles
bank a begin
bank a end
bank a erase cycles
bank b begin
bank b end
bank b erase cycles

ftp status running

inactive

admin username admin
connections rejected

accepted

last client ip address

port

hardware cpu type

speed

hardware id hardware id
memory flash size

ram size

http state enabled

disabled

ports
max timeout
max bytes
logging entries

bytes

http log entry

(Attribute of “instance” is a
number.)

totals entries

bytes

IntelliBox-I/O 2100 Command Reference 36

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

icmp in messages

messages discarded
errors
destination unreachable
time exceeded messages
parameter problems
source quench requests
redirects
ping requests
ping replies
timestamp requests
timestamp replies
address mask requests
address mask replies

out messages

messages discarded
errors
destination unreachables
time exceeded messages
parameter problems
source quench requests
redirects
ping requests
ping replies
timestamp requests
timestamp replies
address mask requests
address mask replies

inputs and outputs xio1 configured as

state
control

xio2 configured as

state
control

Relay configured as

state
control

IntelliBox-I/O 2100 Command Reference 37

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

interface
(Attribute of “instance” is

“eth0”.)

generic status no link

link up

disabled

unknown
errors (error text)

none

ethernet (Present only for
eth0.)

arp encapsulation ARPA

default gateway
network mask
domain
mac address
hostname
ip address
last change
mtu
primary dns
secondary dns

speed 10

100
duplex full

half

type ARPA
timeout

IntelliBox-I/O 2100 Command Reference 38

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

interface
(Attribute of “instance” is

“eth0”.) (Continued.)

transmit octets

unicast
non unicast
discards
errors
broadcast packets
multicast packets
filtered packets
deferred
multiple retries
one retry
underflows
late collisions
retry errors
carrier lost errors

receive octets

unicast
non unicast
discards
errors
broadcast packets
multicast packets
filtered packets
unknown protocol
framing errors
overflows
crc errors
missed frame errors

IntelliBox-I/O 2100 Command Reference 39

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

ip state enabled

disabled

default ttl
forwarded
route discards
in receives

header errors
address errors
unknown protocols
discarded
delivered

out requests

discards
discards no route

reassembly timeout

needed
success
failures

fragments needed

failures
success

ip sockets ip socket protocol UDP

TCP
rx queue
tx queue
local address
local port
remote address
remote port
state

IntelliBox-I/O 2100 Command Reference 40

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

line
(Attribute of “instance” is a

number.)

line <number> (within group
“buffer pool”.)

receiver bytes

breaks
parity errors
framing errors
overrun errors
no receive buffer errors
queued bytes
flow control n/a

stop

go

transmitter bytes

breaks
queued bytes
flow control n/a

stop

go

line levels cts asserted

not asserted
rts asserted

not asserted
dsr asserted

not asserted
dtr asserted

not asserted

buffer headers total

free
used
max used

cluster pool cluster size

total
free
used
max used

IntelliBox-I/O 2100 Command Reference 41

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

line (With no instance.)
(Within group “line” with
instance.)

lpd
(Attribute of “instance” is a

number.)

memory main heap condition clean

state enable

disable

protocol none

ppp

tunnel

baud rate Any value from 300 to

230400.

parity even

none

odd

data bits 7

8

stop bits 1

2

flow control hardware

none

software

xon char
xoff char
jobs printed
bytes printed
current client ip address
current client port
last client ip address
last client port

corrupt
total memory
available memory
fragments
allocated blocks

internal buffer heap cond ition clean

corrupt
total memory
available memory
fragments
allocated blocks

IntelliBox-I/O 2100 Command Reference 42

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

modbus local slave totals pdus in

pdus out
exceptions

modbus tcp server
(Attribute of “instance” is

“permanent” or “additional”.)

processes process

protocol stack (within group
“buffer pool”)

query port status enabled

rss url

state down

up

binding

no port

local port
totals uptime

pdus in
pdus out
connections
cpu %

(Attribute of “instance” is a
number.)

buffer headers total

cluster pool cluster size

last connection ip address

in discoveries

out discovery replies

data entries

stack used
stack size
thread name

free
used
max used

total
free
used
max used

disabled

port

unknown queries
erroneous packets

errors

bytes

IntelliBox-I/O 2100 Command Reference 43

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

sessions line

(Attribute of “instance” is a
number.)

ssh
(Attribute of “instance” is

the ssh session number.)

telnet
(Attribute of “instance” is

the telnet session
number.)

ssh state active

local port
totals uptime

syslog state enable, disable

host
severity to log
messages failed
messages send

baud
parity none

even

odd
data bits 7

8
stop bits 1

2
flow control none

hardware

software
local port
remote ip address
remote port
duration
local port
remote ip address
remote port
duration

waiting

disabled

bytes in
bytes out

IntelliBox-I/O 2100 Command Reference 44

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

tcp retransmission algorithm vanj

timeout minimum
timeout maximum

connections maximum

open active
open passive
failed
resets
established

errors in
resets in

out

segments in

out
retransmitted

telnet state active

waiting

disabled

local port
totals uptime

bytes in
bytes out

last connection local ip address

local port
remote ip address
remote port

tftp state enabled, disabled

creation enabled, disabled
downloaded
uploaded
not found
errors read

write
unknown

last client ip address

port

IntelliBox-I/O 2100 Command Reference 45

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

tunnel
(Attribute of “instance” is a

number.)

aggregate completed connects

completed accepts
disconnects
dropped connects
dropped accepts
octets from serial
octets from network
connect connection time
accept connection time
connect dns address

changes
connect dns address

invalids

current connect
connections

(As many as present.)

current accept
connections

(As many as present.)

local ip address
local port
remote ip address
remote port
uptime
octets from serial
octets from network
connect dns address

changes
connect dns address

invalids
local ip address
local port
remote ip address
remote port
uptime
octets from serial
octets from network

IntelliBox-I/O 2100 Command Reference 46

4: Configuration Using XML

Group Name Item Name Value Name Valid Values

tunnel modem (within group
“tunnel”)

udp in unknown ports

xsr out bytes

echo commands enable

disable

verbose response enable

disable

response type text

numeric

error unknown commands disable

enable

incoming connection disabled

automatic

manual

in datagrams
in errors
out datagrams

lines
elements

errors

IntelliBox-I/O 2100 Command Reference 47

5: Commands and Levels

Click the level in the tree structure and it will take you to the command list for that level.

root

• enable (enable)

• chem 1 (chem:1)

• chem 2 (chem:2)

• chem 3 (chem:3)

• chem 4 (chem:4)

• configure (config)

• arp (config-arp)

• cli (config-cli)

• eventtrak 1 (config-eventtrak:1)

• match 1 (config-eventtrak-match:1.1)

• match 2 (config-eventtrak-match:1.2)

• match 3 (config-eventtrak-match:1.3)

• task 1 (config-eventtrak-task:1.1)

• task 2 (config-eventtrak-task:1.2)

• task 3 (config-eventtrak-task:1.3)

• eventtrak 2 (config-eventtrak:2)

• match 1 (config-eventtrak-match:2.1)

• match 2 (config-eventtrak-match:2.2)

• match 3 (config-eventtrak-match:2.3)

• task 1 (config-eventtrak-task:2.1)

• task 2 (config-eventtrak-task:2.2)

• task 3 (config-eventtrak-task:2.3)

• ftp (config-ftp)

• host 1 (config-host:1)

• host 2 (config-host:2)

• http (config-http)

• icmp (config-icmp)

• if 1 (config-if:eth0)

• link (config-ethernet:eth0)

• ip (config-ip)

• ip filter (config-filter)

• lpd 1 (config-lpd:1)

• lpd 2 (config-lpd:2)

• modbus (modbus)

• query port (config-query_port)

• rss (config-rss)

• snmp (config-snmp)

• syslog (config-syslog)

• tcp (config-tcp)

• terminal 1 (config-terminal:1)

• terminal 2 (config-terminal:2)

• terminal network (config-terminal:network)

• tftp (config-tftp)

• udp (config-udp)

• device (device)

• filesystem (filesystem)

• io (io)

IntelliBox-I/O 2100 Command Reference 48

5: Commands and Levels

accept (tunnel-accept:2) level commands

connections.

accept mode any character

Enables the tunneling server to accept tunneling connec­tions only when a

accept mode disable

Disables accept mode tunneling.

accept mode modem control asserted

Enables the tunneling server to accept tunneling connec­tions when the modem

accept mode modem emulation

Enables modem emulation for accept mode tunnel ing.

accept mode start character

Enables accept mode tunneling when the configured start
character

bytes.

aes decrypt key text <text>

Sets the accept tunnel AES decrypt key with up to 16
bytes.

aes encrypt key <hexadecimal>

Sets the accept tunnel AES encrypt key with up to 16
bytes.

aes encrypt key text <text>
bytes.

block network disable

Forwards (tunnels) network data in accept mode tunne­ling.

• line 1 (line:1)

• line 2 (line:2)

• lpd (lpd)

• ssh (ssh)

• ssl (ssl)

• tunnel 1 (tunnel:1)

• accept (tunnel-accept:1)

• output select (tunnel-accept-output_select:1)

• connect (tunnel-connect:1)

• output select (tunnel-connect-output_select:1)

• disconnect (tunnel-disconnect:1)

• modem (tunnel-modem:1)

• packing (tunnel-packing:1)

• serial (tunnel-serial:1)

• tunnel 2 (tunnel:2)

• accept (tunnel-accept:2)

• output select (tunnel-accept-output_select:2)

• connect (tunnel-connect:2)

• output select (tunnel-connect-output_select:2)

• disconnect (tunnel-disconnect:2)

• modem (tunnel-modem:2)

• packing (tunnel-packing:2)

• serial (tunnel-serial:2)

Table 5-1 Commands and Levels

accept mode always Enables the tunneling server to always accept tunneling

aes decrypt key <hexadecimal>

Sets the accept tunnel AES decrypt key with up to 16

Sets the accept tunnel AES encrypt key with up to 16

IntelliBox-I/O 2100 Command Reference 49

5: Commands and Levels

block network enable

Discards all data coming in from the accept mode tunnel
block serial disable

Forwards (tunnels) serial data in accept mode tunneling.

block serial enable

Discards all data coming in from the serial interface before
forwarding

clrscrn

Clears the screen.

default accept mode

Restores the default accept mode as "always".

default protocol

Restores the default protocol as "TCP".

alive timeout.

email connect <number>

Sets an email profile to use to send an email alert upon
establishing

email disconnect <number>

Sets an email profile to use to send an email alert upon
exit

Returns to the tunnel level.

flush serial disable

Characters already in the serial data buffer are retained
upon establishing

mode tunneling

kill connection

Disconnects the active accept mode tunneling connection.

local port <number>

Sets the port to use for accept mode tunneling.

no aes decrypt key

Removes the accept tunnel AES decrypt key.

no aes encrypt key

Removes the accept tunnel AES encrypt key.

accept mode tunnel.

no email disconnect

Discontinues sending email alerts upon closing an accept
mode tunnel.

no local port

Uses the default port number as the local port for accept
mode tunneling.

no tcp keep alive

Disables the accept mode TCP keep alive timeout.

output select

Enters the next lower level.

password

Enters the next lower level.

protocol ssh

Uses SSH protocol for accept mode tunneling.

protocol ssl

Uses SSL protocol for accept mode tunneling.

protocol tcp

Uses TCP protocol for accept mode tunneling.

protocol tcp aes

Uses TCP protocol with AES encryption for accept mode
tunneling.

ling.

rss trace connections disable

Disables RSS Trace of accept mode connections.

rss trace connections enable

Enables RSS Trace of accept mode connections.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

show status

Displays tunnel accept status.

tcp keep alive <milliseconds>

Enables TCP keep alive for accept mode tunneling and
sets the timer.

write

Stores the current configuration in permanent memory.

accept (tunnel-accept:1) level commands

before forwarding

default tcp keep alive Restores the default 45 second accept mode TCP keep

closing

flush serial enable Flushes the serial data buffer upon establish ing an acc ept

no email connect Discontinues sending email alerts upon establishing an

protocol telnet Uses Telnet protocol (with IAC) for accept mode tunne-

show history

IntelliBox-I/O 2100 Command Reference 50

5: Commands and Levels

accept mode always

Enables the tunneling server to always accept tunneling

accept mode any character

Enables the tunneling server to accept tunneling connec­tions only when a

accept mode disable

Disables accept mode tunneling.

tions when the modem

accept mode modem emulation

Enables modem emulation for accept mode tunnel ing.

accept mode start character

Enables accept mode tunneling when the configured start
character

aes decrypt key <hexadecimal>

Sets the accept tunnel AES decrypt key with up to 16
bytes.

aes decrypt key text <text>
bytes.

aes encrypt key <hexadecimal>

Sets the accept tunnel AES encrypt key with up to 16
bytes.

aes encrypt key text <text>

Sets the accept tunnel AES encrypt key with up to 16

block network disable

Forwards (tunnels) network data in accept mode tunne­ling.

before forwarding

block serial disable

Forwards (tunnels) serial data in accept mode tunneling.

block serial enable

Discards all data coming in from the serial interface before
forwarding

clrscrn

Clears the screen.

default accept mode

Restores the default accept mode as "always".

default protocol

Restores the default protocol as "TCP".

default tcp keep alive

Restores the default 45 second accept mode TCP keep
alive timeout.

email connect <number>

Sets an email profile to use to send an email alert upon
establishing

closing

exit

Returns to the tunnel level.

flush serial disable

Characters already in the serial data buffer are retained
upon establishing

flush serial enable

Flushes the serial data buffer upon establish ing an acc ept
mode tunneling

kill connection

Disconnects the active accept mode tunneling connection.

local port <number>

Sets the port to use for accept mode tunneling.

no aes decrypt key

Removes the accept tunnel AES decrypt key.

no aes encrypt key

Removes the accept tunnel AES encrypt key.

no email connect

Discontinues sending email alerts upon establishing an
accept mode tunnel.

mode tunnel.

no local port

Uses the default port number as the local port for accept
mode tunneling.

no tcp keep alive

Disables the accept mode TCP keep alive timeout.

output select

Enters the next lower level.

connections.

accept mode modem control asserted Enables the tunneling server to accept tunneling connec-

Sets the accept tunnel AES decrypt key with up to 16

bytes.

block network enable Discards all data coming in from the accept mode tunnel

email disconnect <number>

no email disconnect Discontinues sending email alerts upon closing an accept

Sets an email profile to use to send an email alert upon

IntelliBox-I/O 2100 Command Reference 51

5: Commands and Levels

password

Enters the next lower level.

protocol ssh

Uses SSH protocol for accept mode tunneling.

protocol ssl

Uses SSL protocol for accept mode tunneling.

protocol tcp

Uses TCP protocol for accept mode tunneling.

protocol tcp aes

Uses TCP protocol with AES encryption for accept mode
tunneling.

protocol telnet

Uses Telnet protocol (with IAC) for accept mode tunne­ling.

rss trace connections disable

Disables RSS Trace of accept mode connections.

rss trace connections enable

Enables RSS Trace of accept mode connections.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show status

Displays tunnel accept status.

sets the timer.

write

Stores the current configuration in permanen t memory.

arp (config-arp) level commands

add <IP address> <MAC address>

Adds an entry to the ARP table, mapping an IP address to
a MAC address.

clrscrn

Clears the screen.

default timeout

Restores the default ARP cache timeout.

exit

Exits to the configuration level.

remove <IP address>

Removes an entry from the ARP cache.

remove all

Removes all entries from the ARP cache.

show

Displays the current configuration.

show cache

Displays the ARP cache table.

Displays the last 20 commands entered during the current
CLI session.

timeout <seconds>

Sets the ARP cache timeout.

write

Stores the current configuration in permanen t memory.

chem 1 (chem:1) level commands

auto show statistics

Continuously displays email statistics.

cc <email addresses>

Sets Cc addresses for email alerts.

chem <number>

Enters the configure email level.

clear log

Clears all entries from the mail log.

clear mail counters

Sets the email counters to zero.

clrscrn

Clears the screen.

exit

Exits to the enable level.

file
sage body

from <email address>

Sets the From address for email alerts.

local port <number>

Sets local port used to send email alerts.

local port random

Sets local port (used to send email alerts) to random.

no cc

Removes the Cc addresses for email alerts.

no clear mail counters

Restores the email counters to the aggregate values.

empty.

tcp keep alive <milliseconds>

show history

Enables TCP keep alive for accept mode tunneling and

<file>

no file Removes the file name, so the message body will be

IntelliBox-I/O 2100 Command Reference 52

Specifies a text file, the contents of which will be the mes-

no from

Removes From address for email alerts.

no overriding domain

Removes the overriding domain name option.

no replyto

Removes Reply-To address for email alerts.

no subject

Removes subject used for email alerts.

no to

Removes To address for email alerts.

no trigger

Disables the trigger to send an email.

overriding domain <domain>

Sets a domain name that will be used when connecting to
an SMTP server to

priority high

Sets X-Priority for email alerts to 2.

priority low

Sets X-Priority for email alerts to 4.

priority normal

Sets X-Priority for email alerts to 3.

priority urgent

Sets X-Priority for email alerts to 1.

priority very low

Sets X-Priority for email alerts to 5.

replyto <email address>

Sets Reply-To address for email alerts.

send

Sends an email using the current settings.

server port <number>

Sets the port used by the SMTP server.

show

Displays email settings.

show history

Displays the last 20 commands entered during the current
CLI session.

show log

Displays the email log.

show statistics

Displays email statistics.

subject <string>

Sets the subject for email alerts.

to <email addresses>

Sets email address to which the email alerts will be sent.

an email.

write

Stores the current configuration in permanen t memory.

chem 2 (chem:2) level commands

auto show statistics

Continuously displays email statistics.

cc <email addresses>

Sets Cc addresses for email alerts.

chem <number>

Enters the configure email level.

clear log

Clears all entries from the mail log.

clear mail counters

Sets the email counters to zero.

clrscrn

Clears the screen.

exit

Exits to the enable level.

file
sage body

from <email address>

Sets the From address for email alerts.

local port <number>

Sets local port used to send email alerts.

local port random

Sets local port (used to send email alerts) to random.

no cc

Removes the Cc addresses for email alerts.

no clear mail counters

Restores the email counters to the aggregate values.

empty.

no from

Removes From address for email alerts.

no overriding domain

Removes the overriding domain name option.

no replyto

Removes Reply-To address for email alerts.

no subject

Removes subject used for email alerts.

5: Commands and Levels

trigger <xio1/xio2> <high/low>

<file>

no file Removes the file name, so the message body will be

Specifies input name and voltage level to trigger sending

Specifies a text file, the contents of which will be the mes-

IntelliBox-I/O 2100 Command Reference 53

5: Commands and Levels

no to

Removes To address for email alerts.

no trigger

Disables the trigger to send an email.

overriding domain <domain>

Sets a domain name that will be used when connecting to
an SMTP server to

priority high

Sets X-Priority for email alerts to 2.

priority low

Sets X-Priority for email alerts to 4.

priority normal

Sets X-Priority for email alerts to 3.

priority urgent

Sets X-Priority for email alerts to 1.

priority very low

Sets X-Priority for email alerts to 5.

replyto <email address>

Sets Reply-To address for email alerts.

send

Sends an email using the current settings.

server port <number>

Sets the port used by the SMTP server.

show

Displays email settings.

show history

Displays the last 20 commands entered during the current
CLI session.

show log

Displays the email log.

show statistics

Displays email statistics.

subject <string>

Sets the subject for email alerts.

to <email addresses>

Sets email address to which the email alerts will be sent.

trigger <xio1/xio2> <high/low>

Specifies input name and voltage level to trigger sending
an email.

write

Stores the current configuration in permanen t memory.

chem 3 (chem:3) level commands

auto show statistics

Continuously displays email statistics.

cc <email addresses>

Sets Cc addresses for email alerts.

chem <number>

Enters the configure email level.

clear log

Clears all entries from the mail log.

clear mail counters

Sets the email counters to zero.

clrscrn

Clears the screen.

exit

Exits to the enable level.

sage body

from <email address>

Sets the From address for email alerts.

local port <number>

Sets local port used to send email alerts.

local port random

Sets local port (used to send email alerts) to rando m.

no cc

Removes the Cc addresses for email alerts.

no clear mail counters

Restores the email counters to the aggregate values.

no file

Removes the file name, so the message body will be
empty.

no from

Removes From address for email alerts.

no overriding domain

Removes the overriding domain name option.

no replyto

Removes Reply-To address for email alerts.

no subject

Removes subject used for email alerts.

no to

Removes To address for email alerts.

no trigger

Disables the trigger to send an email.

overriding domain <domain>

Sets a domain name that will be used when connecting to
an SMTP server to

file <file>

IntelliBox-I/O 2100 Command Reference 54

Specifies a text file, the contents of which will be the mes-

priority high

Sets X-Priority for email alerts to 2.

priority low

Sets X-Priority for email alerts to 4.

priority normal

Sets X-Priority for email alerts to 3.

priority urgent

Sets X-Priority for email alerts to 1.

priority very low

Sets X-Priority for email alerts to 5.

replyto <email address>

Sets Reply-To address for email alerts.

send

Sends an email using the current settings.

server port <number>

Sets the port used by the SMTP server.

show

Displays email settings.

show history

Displays the last 20 commands entered during the current
CLI session.

show log

Displays the email log.

show statistics

Displays email statistics.

subject <string>

Sets the subject for email alerts.

to <email addresses>

Sets email address to which the email alerts will be sent.

an email.

write

Stores the current configuration in permanent memory.

chem 4 (chem:4) level commands

auto show statistics

Continuously displays email statistics.

cc <email addresses>

Sets Cc addresses for email alerts.

chem <number>

Enters the configure email level.

clear log

Clears all entries from the mail log.

clear mail counters

Sets the email counters to zero.

clrscrn

Clears the screen.

exit

Exits to the enable level.

file
sage body

from <email address>

Sets the From address for email alerts.

local port <number>

Sets local port used to send email alerts.

local port random

Sets local port (used to send email alerts) to random.

no cc

Removes the Cc addresses for email alerts.

no clear mail counters

Restores the email counters to the aggregate values.

empty.

no from

Removes From address for email alerts.

no overriding domain

Removes the overriding domain name option.

no replyto

Removes Reply-To address for email alerts.

no subject

Removes subject used for email alerts.

no to

Removes To address for email alerts.

no trigger

Disables the trigger to send an email.

Sets a domain name that will be used when connecting to
an SMTP server to

priority high

Sets X-Priority for email alerts to 2.

priority low

Sets X-Priority for email alerts to 4.

priority normal

Sets X-Priority for email alerts to 3.

priority urgent

Sets X-Priority for email alerts to 1.

5: Commands and Levels

trigger <xio1/xio2> <high/low>

<file>

no file Removes the file name, so the message body will be

Specifies input name and voltage level to trigger sending

Specifies a text file, the contents of which will be the mes-

overriding domain <domain>

IntelliBox-I/O 2100 Command Reference 55

5: Commands and Levels

priority very low

Sets X-Priority for email alerts to 5.

replyto <email address>

Sets Reply-To address for email alerts.

send

Sends an email using the current settings.

server port <number>

Sets the port used by the SMTP server.

show

Displays email settings.

show history

Displays the last 20 commands entered during the current
CLI session.

show log

Displays the email log.

show statistics

Displays email statistics.

subject <string>

Sets the subject for email alerts.

to <email addresses>

Sets email address to which the email alerts will be sent.

trigger <xio1/xio2> <high/low>

Specifies input name and voltage level to trigger sending
an email.

write

Stores the current configuration in permanen t memory.

cli (config-cli) level commands

clear ssh counters

Sets the SSH counters to zero.

clear telnet counters

Sets the Telnet counters to zero.

clrscrn

Clears the screen.

default quit connect line

Restores the default string used to quit the "connect line "
command.

enable level password

Sets or removes the enable-level password by challenging
and prompting.

exit

Exits to the configuration level.

and prompting.

no clear ssh counters

Restores the IP SSH counters to the aggregate values.

no clear telnet counters

Restores the IP Telnet counters to the aggregate values.

quit connect line <string>

Sets the string used to quit the "connect line " command.

Displays the last 20 commands entered during the current
CLI session.

show ssh

Displays the SSH server settings.

show telnet

Displays the Telnet settings and statistics.

ssh disable

Disables the SSH Server.

ssh enable

Enables the SSH Server.

sessions.

ssh port <number>

Sets the local port that the SSH server uses.

telnet disable

Disables the Telnet Server.

telnet enable

Enables the Telnet Server.

telnet max sessions <number>

Sets the maximum concurrent incoming Telnet sessions.

telnet port <number>

Sets the local port that the Telnet server uses.

write

Stores the current configuration in permanen t memory.

configure (config) level commands

Changes to the command level for ARP configuration and
status.

clear host <host>

Removes an entry from the DNS Cache

cli

Change to menu level for CLI configuration and statu s

clrscrn

Clears the screen.

login password Sets or removes the CLI login password by challenging

show history

ssh max sessions <number>

arp

Sets the maximum allowed concurrent incoming SSH

IntelliBox-I/O 2100 Command Reference 56

eventtrak <number>

Changes to the command level for EventTrak configura-

tion.

exit

Exits to the enable level.

ftp

Enters the ftp level.

host <number>

Change to config host level

http

Enters the http level.

icmp

Changes to the command level for ICMP configuration
and status.

if <instance>

Changes to the interface configuration level.

ip

Changes to the command level for IP configuration and
status.

ip filter

Enters the config-filter level.

kill ssh <session>

Kills SSH session with index from "show sessions"

kill telnet <session>

Kills Telnet session with index from "show sessions"

lpd <line>

Enters the configure lpd level.

modbus

Changes to the modbus configuration level.

query port

Enters the query port level.

rss

Change to menu level for RSS configuration and status

show

Displays system information.

show history

Displays the last 20 commands entered during the current
CLI session.

snmp

Enters the snmp level.

syslog

Enters the syslog level.

status.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

tftp

Enters the tftp level.

Changes to the command level for UDP configuration and
status.

write

Stores the current configuration in permanen t memory.

connect (tunnel-connect:2) level commands

aes decrypt key <hexadecimal>

Sets the connect tunnel AES decrypt key with up to 16
bytes.

aes decrypt key text <text>

Sets the connect tunnel AES decrypt key with up to 16
bytes.

aes encrypt key <hexadecimal>
bytes.

bytes.

block network disable

Forwards (tunnels) network data in connect mode tunne­ling.

block network enable

Discards all data coming in from the connect mode tunnel
before forwarding

block serial disable

Forwards (tunnels) serial data in connect mode tunneling.

Discards all data coming in from the serial interface before
forwarding

clrscrn

Clears the screen.

connect mode always

Enables the tunneling server to always establish tunneling

5: Commands and Levels

tcp Changes to the command level for TCP configuration and

udp

Sets the connect tunnel AES encrypt key with up to 16

aes encrypt key text <text>

block serial enable

Sets the connect tunnel AES encrypt key with up to 16

IntelliBox-I/O 2100 Command Reference 57

5: Commands and Levels

connections.

connect mode any character

Enables the tunneling server to establish a tunneling con­nection when a

connect mode disable

Disables connect mode tunneling.

connect mode modem control asserted

Enables the tunneling server to make tunneling connec­tions when the modem

connect mode modem emulation

Enables modem emulation for connect mode tunne lin g.

start character

default connect mode

Restores the default connect mode as "disable".

default local port

Uses a random port number as the local port for establish­ing tunneling

default protocol

Restores the default protocol as "TCP".

default reconnect time

Restores the default reconnect time value for connect
mode tunneling.

default tcp keep alive

Restores the default 45 second connect mode TCP keep
alive timeout.

establishing

email disconnect <number>

Sets an email profile to use to send an email alert upon
closing

exit

Returns to the tunnel level.

flush serial disable

Characters already in the serial data buffer are retained
upon establishing

mode tunneling

tion.

local port <number>

Sets a specific port for use as the local port.

no aes decrypt key

Removes the connect tunnel AES decrypt key.

no aes encrypt key

Removes the connect tunnel AES encrypt key.

no email connect

Discontinues sending email alerts upon establishing a
connect mode tunnel.

no email disconnect

Discontinues sending email alerts upon closing a connect
mode tunnel.

tunneling connections.

no remote port

Removes the remote port used to establish tunnel con­nections.

no ssh username

Removes the SSH user name.

no tcp keep alive

Disables the connect mode TCP keep alive timeout .

output select

Enters the next lower level.

protocol ssh

Uses SSH protocol for connect mode tunneling.

protocol ssl

Uses SSL protocol for connect mode tunneling.

protocol tcp

Uses TCP protocol for connect mode tunneling.

protocol tcp aes

Uses TCP protocol with AES encryption for connect mode
tunneling.

protocol telnet

Uses Telnet protocol (with IAC) for connect mode tunne­ling.

protocol udp

Uses UDP protocol for connect mode tunneling.

connect mode start character Enables connect mode tunneling when the configured

email connect <number>

flush serial enable Flushes the serial data buffer upon establish ing a conne ct

kill connection Disconnects the active connect mode tunneling connec-

no remote address Removes the remote host address used to establish

Sets an email profile to use to send an email alert upon

IntelliBox-I/O 2100 Command Reference 58

protocol udp aes

Uses UDP protocol with AES encryption for connect mode

tunneling.

reconnect time <milliseconds>

Sets the reconnect time value for tunneling connections
established by the

with.

remote port <number>

Sets the remote port to use for connect mode tunneling.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show status

Displays tunnel connect status.

ssh username <text>

Sets the SSH user name for use when establishing tunne­ling connections

tcp keep alive <milliseconds>

Enables TCP keep alive for connect mode tunneling and
sets the timer.

write

Stores the current configuration in permanen t memory.

connect (tunnel-connect:1) level commands

bytes.

aes decrypt key text <text>

Sets the connect tunnel AES decrypt key with up to 16
bytes.

aes encrypt key <hexadecimal>

Sets the connect tunnel AES encrypt key with up to 16
bytes.

aes encrypt key text
bytes.

block network disable

Forwards (tunnels) network data in connect mode tunne­ling.

block network enable

Discards all data coming in from the connect mode tunnel
before forwarding

block serial disable

Forwards (tunnels) serial data in connect mode tunneling.

block serial enable

Discards all data coming in from the serial interface before
forwarding

clrscrn

Clears the screen.

Enables the tunneling server to always establish tunneling
connections.

connect mode any character

Enables the tunneling server to establish a tunneling con­nection when a

connect mode disable

Disables connect mode tunneling.

connect mode modem control asserted

Enables the tunneling server to make tunneling connec­tions when the modem

connect mode modem emulation

Enables modem emulation for connect mode tunne lin g.

connect mode start character

Enables connect mode tunneling when the configured
start character

default connect mode

Restores the default connect mode as "disable".

ing tunneling

default protocol

Restores the default protocol as "TCP".

default reconnect time

Restores the default reconnect time value for connect
mode tunneling.

default tcp keep alive

Restores the default 45 second connect mode TCP keep
alive timeout.

5: Commands and Levels

remote address <text>

aes decrypt key <hexadecimal>

<text>

Sets the remote host to establish tunneling connections

Sets the connect tunnel AES decrypt key with up to 16

Sets the connect tunnel AES encrypt key with up to 16

connect mode always

default local port Uses a random port number as the local port for establish-

IntelliBox-I/O 2100 Command Reference 59

5: Commands and Levels

email connect <number>

Sets an email profile to use to send an email alert upon

email disconnect <number>

Sets an email profile to use to send an email alert upon
closing

exit

Returns to the tunnel level.

upon establishing

flush serial enable

Flushes the serial data buffer upon establish ing a conne ct
mode tunneling

kill connection

Disconnects the active connect mode tunneling connec­tion.

local port

Sets a specific port for use as the local port.

no aes decrypt key

Removes the connect tunnel AES decrypt key.

no aes encrypt key

Removes the connect tunnel AES encrypt key.

no email connect

Discontinues sending email alerts upon establishing a
connect mode tunnel.

mode tunnel.

no remote address

Removes the remote host address used to establish
tunneling connections.

no remote port

Removes the remote port used to establish tunnel con­nections.

no ssh username

Removes the SSH user name.

no tcp keep alive

Disables the connect mode TCP keep alive timeout.

output select

Enters the next lower level.

protocol ssh

Uses SSH protocol for connect mode tunneling.

protocol ssl

Uses SSL protocol for connect mode tunneling.

protocol tcp

Uses TCP protocol for connect mode tunneling.

protocol tcp aes

Uses TCP protocol with AES encryption for connect mode
tunneling.

ling.

protocol udp

Uses UDP protocol for connect mode tunneling.

protocol udp aes

Uses UDP protocol with AES encryption for connect mode
tunneling.

reconnect time <milliseconds>

Sets the reconnect time value for tunneling connections
established by the

remote address <text>

Sets the remote host to establish tunneling connections
with.

remote port <number>

Sets the remote port to use for connect mode tunneling.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

show status

Displays tunnel connect status.

ssh username <text>

Sets the SSH user name for use when establishing tunne­ling connections

tcp keep alive <milliseconds>

Enables TCP keep alive for connect mode tunneling and
sets the timer.

write

Stores the current configuration in permanent memory.

device (device) level commands

establishing

flush serial disable Characters already in the serial data buffer are retained

<number>

no email disconnect Discontinues sending email alerts upon closing a connect

protocol telnet Uses Telnet protocol (with IAC) for connect mode tunne-

show history

IntelliBox-I/O 2100 Command Reference 60

5: Commands and Levels

auto show tlog

Continuously displays the internal trouble log.

auto show upload

Continuously displays the status of firmware upload.

clrscrn

Clears the screen.

cpu speed <mhz>

Sets the CPU speed.

default cpu speed

Restores the default CPU clock rate.

default long name

Restores the default product long name.

default short name

Restores the default product short name.

exit

Exit to the enable level.

and the Web interface.

short name <name>

Sets the product short name, displayed in command mode
and the Web interface.

show

Show system information

show buffer pool

Displays information about the various buffer pools.

show codefile memory

Displays memory utilization by code files.

show delta memory

Displays differences in memory utilization by code files or
line reference.

show hardware information

Displays information about the hardware.

show history

Displays the last 20 commands entered during the current
CLI session.

show ibio2100

Show system information

Displays memory utilization by line reference for one code
file.

show memory

Displays current memory usage information.

show task memory

Displays task memory utilization.

show task state

Displays current task states.

show tlog

Displays the internal trouble log.

show upload

Displays the status of firmware upload.

write

Stores the current configuration in permanen t memory.

disconnect (tunnel-disconnect:2) level commands

character stop disable

Does not watch for a stop character to disconnect.

character stop enable

Watches for a stop character to disconnect.

clrscrn

Clears the screen.

exit

Returns to the tunnel level.

flush serial disable

Does not flush serial data upon closing a tunneling con­nection.

closed.

modem control disable

Does not watch the modem control pin to disconnect.

modem control enable

Watches the modem control pin and disconnects if it is not
asserted.

no timeout

Disables disconnect after timeout feature for tunneling
sessions.

show

Displays the current configuration.

tered during the current

CLI session.

(serial port) for the

write

Stores the current configuration in permanen t memory.

long name <name>

show linereference memory <code filename>

Sets the product long name, displayed in command mode

flush serial enable Flushes serial data buffer when a tunneling connection is

show history Displays the last 20 commands en

timeout <milliseconds>

IntelliBox-I/O 2100 Command Reference 61

Disconnects when no data has been received on the line

5: Commands and Levels

disconnect (tunnel-disconnect:1) level commands

character stop disable

Does not watch for a stop character to disconnect.

character stop enable

Watches for a stop character to disconnect.

clrscrn

Clears the screen.

exit

Returns to the tunnel level.

flush serial disable

Does not flush serial data upon closing a tunneling con­nection.

flush serial enable

Flushes serial data buffer when a tunneling connection is
closed.

modem control disable

Does not watch the modem control pin to disconnect.

modem control enable

Watches the modem control pin and disconnects if it is not
asserted.

sessions.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

timeout <milliseconds>

Disconnects when no data has been received on the line
(serial port) for the

write

Stores the current configuration in permanen t memory.

enable (enable) level commands

auto show interfaces

Show interface statistics

auto show processes

Continuously show thread runtime information

auto show xsr

Show XML Status Record counters

chem <number>

Enters the configure email level.

clear interfaces counters

Zeros interface session counters

clear query port counters

Zeros Query Port counters

clear xsr counters

Zeros XML Status Record counters

clrscrn

Clears the screen.

configure

Enters the configuration level.

connect

Show name and number for lines.

connect line <line>

Begin session on serial port.

device

Enters the device level.

disable

Exits the enable level.

exit

Exit from the system

filesystem

Enters the filesystem level.

io

Enters the I/O Manager level.

kill line <line>

Kills command mode session on the Line

kill ssh

Kills SSH session with index from "show sessions"

kill telnet

Kills Telnet session with index from "show sessions"

line <line>

Enters the line level.

lpd

Enters the lpd level.

no clear interfaces counters

Unzeros interface session counters

no clear query port counters

Unzeros Query Port counters

no clear xsr counters

Unzeros XML Status Record counters

nslookup

Lookup host information for the given host name

nslookup <host>

Return host information for the given host name

no timeout Disables disconnect after timeout feature for tunneling

<session>

<session>

IntelliBox-I/O 2100 Command Reference 62

5: Commands and Levels

ping <host>

Ping destination 5 times with 5 second timeout

ping <host> <count>

Ping destination n times with 5 second timeout

ping <host> <count> <timeout>

Ping destination n times with x timeout (in seconds)

reload

Reboot system

reload factory defaults

Reload factory defaults to permanent storage

secret xcr dump

Dump XML configuration containing secrets to the console

secret xcr dump <group list>

Dump specified XML configuration cont ain ing se cret s to
the console

secret xcr export <file>

Save XML configuration containing secrets to a file

secret xcr export <file> <group list>

Save specified XML configuration containing secrets to a
local file

show

Show system information

show history

Displays the last 20 commands entered during the current
CLI session.

show hosts

Show domain settings

show ibio2100

Show system information

show interfaces

Show interface statistics

show ip sockets

Show UDP/TCP state information

show processes

Show thread runtime information

show sessions

Show active Telnet and SSH Sessions

show xsr

Show XML Status Record counters

ssh

Enters the SSH configuration level.

ssh <optClientUsername> <host>

Begin SSH session on network .

ssh <optClientUsername> <host> <port>

Begin SSH session on network :.

ssl

Enters the SSL configuration level.

telnet <host>

Begin telnet session on network .

telnet <host> <port>

Begin telnet session on network :.

trace route <host>

Trace route to destination

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

xcr dump

Dump XML configuration to the console

xcr dump <group list>

Dump specified XML configuration to the console

xcr export <file>

Save XML configuration to a file

xcr export <file> <group list>

Save specified XML configuration to a local file

xcr import

Load XML configuration fro m a local file

xcr import

Load specified XML configuration from a local file

xcr list

List XML Configuration Record groups to the console

xsr dump

Dump XML Status Records to the console

xsr dump <group list>

Dump specified XML Status Records to the console

xsr export <file>

Save XML Status Record to a file

xsr export <file> <group list>

Save specified XML Status Record to a local file

xsr list

List XML Status Record groups to the console

eventtrak 1 (config-eventtrak:1) level commands

clrscrn

Clears the screen.

eventtrak <number>

Changes to the command level for EventTrak configura­tion.

exit

Exits to the configuration level.

<file>
<file> <group list>

IntelliBox-I/O 2100 Command Reference 63

match <number>

Changes to the command level for EventTrak Match con-

figuration.

show history

Displays the last 20 commands entered during the current
CLI session.

guration.

write

Stores the current configuration in permanen t memory.

eventtrak 2 (config-eventtrak:2) level commands

clrscrn

Clears the screen.

eventtrak <number>

Changes to the command level for EventTrak configura­tion.

exit

Exits to the configuration level.

match <number>

Changes to the command level for EventTrak Match con-

show history

Displays the last 20 commands entered during the current
CLI session.

guration.

write

Stores the current configuration in permanen t memory.

filesystem (filesystem) level commands

cat <file>

Show the contents of a file

cd <directory>

Change the current directory to the specified directory

clrscrn

Clears the screen.

compact

Compact the file system, freeing all dirty space

cp <source file> <destination file>

Copy an existing file

dump <file>

Show contents of a file as a hex dump

exit

Exits to the enable level.

format

Format the file system and lose all data

ls

Show all files and directories in the current directory

ls <directory>

Show all files and dire ctor ies in the specif ied dire ctor y

mkdir <directory>

Create a directory

mv <source file> <destinat ion f ile>

Move a file on the file system

pwd

Print working directory

rm <file>

Remove a file

rmdir <directory>

Remove a directory

show

Show file system sta t is ti c s

show history

Displays the last 20 commands entered during the current
CLI session.

show tree

Show all files and directories from current directory

tftp get ascii <source file> <destination file> <host>

Get an ascii file using TFTP

tftp get ascii <source file> <destination file> <host> <port>

Get an ascii file using TFTP

tftp get binary <source file> <destination file> <host>

Get a binary file using TFTP

tftp get binary <source file> <destination

Get a binary file using TFTP
tftp put ascii <source file> <destination file> <host>

Put an ascii file using TFTP

tftp put ascii <source file> <destination file> <host> <port>

Put an ascii file using TFTP

tftp put binary <source file> <destination file> <host>

Put a binary file using TFTP

tftp put binary <source file> <destination

Put a binary file using TFTP

5: Commands and Levels

task <number>

task <number>

Changes to the command level for EventTrak Task confi-

figuration.

Changes to the command level for EventTrak Task confi-

file> <host> <port>

IntelliBox-I/O 2100 Command Reference 64

file> <host> <port>

touch <file>

Create a file

ftp (config-ftp) level commands

admin password <string>

Sets the administrative password for the FTP server.

admin username <string>

Sets the administrative username for the FTP server.

clear counters

Zeros FTP counters.

clrscrn

Clears the screen.

default admin password

Resets the FTP password to the default (PASS).

default admin username

Resets the FTP username to the default (admin).

exit

Returns to the config level.

no clear counters

Unzeros FTP counters.

show

Displays the FTP settings and statistics.

show history

Displays the last 20 commands entered during the current
CLI session.

state disable

Disables the FTP server.

state enable

Enables the FTP server.

write

Stores the current configuration in permanen t memory.

host 1 (config-host:1) level commands

clrscrn

Clears the screen.

default protocol

Restores the default value of the protocol (Telnet).

default value,

exit

Exits to the configuration level.

host <number>

Change to config host level

name <text>

Sets the name of the host.

no name

Clears the name of the host.

no remote address

Clears the remote address of the host.

no ssh username

Clears the SSH username associated with the host.

protocol ssh

Sets the protocol to SSH.

protocol telnet

Sets the protocol to Telnet.

remote address <text>

Sets the IP address of the remote host to connect to when
this host is

remote port <number>

Sets the remote port used to connect to the host.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

ssh username <text>

Sets the username for logging into the host via SSH.

write

Stores the current configuration in permanen t memory.

host 2 (config-host:2) level commands

clrscrn

Clears the screen.

default protocol

Restores the default value of the protocol (Telnet).

default value,

exit

Exits to the configuration level.

host <number>

Change to config host level

name <text>

Sets the name of the host.

no name

Clears the name of the host.

5: Commands and Levels

default remote port Sets the remote port (used to connect to the host) to the

show history

default remote port Sets the remote port (used to connect to the host) to the

IntelliBox-I/O 2100 Command Reference 65

no remote address

Clears the remote address of the host.

no ssh username

Clears the SSH username associated with the host.

protocol ssh

Sets the protocol to SSH.

protocol telnet

Sets the protocol to Telnet.

remote address <text>

Sets the IP address of the remote host to connect to when
this host is

remote port <number>

Sets the remote port used to connect to the host.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current

CLI session.

ssh username <text>

Sets the username for logging into the host via SSH.

write

Stores the current configuration in permanen t memory.

http (config-http) level commands

auth <uri> <realm>

Creates a new HTTP server authentication directive.

auth type <uri> basic

Sets an HTTP server authentication directive to the Basic
Access

auth type <uri> digest

Sets an HTTP server authentication directive to the Digest
Access

auth type <uri> none

Sets the authentication type for an HTTP server authenti­cation directive to

auth type <uri> ssl

Sets the authentication type for an HTTP server authenti-

auth type <uri> ssl-basic

Sets the authentication type for an HTTP server authenti­cation directive

cation directive

auth user <uri> <user> <password>

Creates or modifies a user for an HTTP server authentica­tion directive.

clear counters

Sets the HTTP counters to zero.

clear log

Clears the HTTP server log.

clrscrn

Clears the screen.

default log format

Restores the HTTP Server log format string to its default
value.

default log max entries

Restores the default maximum number of HTTP Server
log entries.

accept when receiving

default max timeout

Resets the default maximum time the HTTP Server will
wait when receiving

default port

Resets the HTTP Server port to its default value.

default ssl port

Resets the HTTP Server SSL port to its default value.

delete auth <uri>

Deletes an existing HTTP Server authentication directive.

delete auth user <uri> <user>

Deletes an existing user for an HTTP Server authentica­tion directive.

exit

Returns to the config level.

log disable

Disabl es HTTP server logging.

log enable

Enables HTTP server logging.

log format <string>

Sets the log format string for the HTTP server, using the
following

max bytes <bytes>

Sets the maximum number of bytes the HTTP server ac-

5: Commands and Levels

cation directive to SSL.

auth type <uri> ssl-digest

default max bytes Resets the default maximum bytes the HTTP Server will

Sets the authentication type for an HTTP server authenti-

IntelliBox-I/O 2100 Command Reference 66

5: Commands and Levels

cepts when receiving

max timeout <seconds>

Sets the maximum timeout the HTTP server waits when
receiving a request.

no clear counters

Restores the HTTP counters to the aggregate values.

port <number>

Sets the port number the HTTP server will use.

server disable

Disables the HTTP server.

server enable

Enables the HTTP server.

show

Displays the HTTP server settings.

show auth

Displays the HTTP server authentication settings.

show history

Displays the last 20 commands entered during the current
CLI session.

show log

Displays the HTTP server log.

show statistics

Displays the HTTP statistics.

ssl port <number>

Sets the port number the HTTP server will use over SSL.

ssl3 disable

Disables SSLv3 handling.

ssl3 enable

Enables SSLv3 handling.

tls1.0 disable

Disables TLSv1.0 handling.

tls1.0 enable

Enables TLSv1.0 handling.

tls1.1 disable

Disables TLSv1.1 handling.

tls1.1 enable

Enables TLSv1.1 handling.

write

Stores the current configuration in permanen t memory.

icmp (config-icmp) level commands

auto show stats

Continuously shows ICMP statistics

clear counters

Zeros counters

clrscrn

Clears the screen.

exit

Exits to the configuration level.

no clear counters

Unzeros IP counters

show

Displays the current configuration.

the current

CLI session.

show stats

Shows ICMP statistics

state disable

Prevents ICMP packets from being sent or received.

state enable

Allows ICMP packets to be sent and received.

write

Stores the current configuration in permanen t memory.

if 1 (config-if:eth0) level commands

bootp disable

Disables BOOTP.

bootp enable

Enables BOOTP.

clear host <string>

Removes an entry from the DNS Cache

clrscrn

Clears the screen.

default gateway <IP address>

Sets the configurable gateway IP address to the default
value.

dhcp client id binary <binary>

Sets the client id allowing binary characters.

dhcp client id set

Sets the client id in text format.

dhcp disable

Disables DHCP.

dhcp enable

Enables DHCP.

dhcp renew

Force DHCP to renew

domain <text>

Sets the domain name.

show history Displays the last 20 commands entered during

<text>

IntelliBox-I/O 2100 Command Reference 67

exit

Exits to the config level.

hostname <text>

Sets the host name.

ip address <ip address/cidr>

Sets the IP address and network mask.

link

Enter link configuration level

no default gateway

Clears the default gateway.

no dhcp client id

Clears the DHCP client ID.

no domain

Clears the domain name.

no hostname

Clears the host name.

no ip address

Clears the IP address.

no primary dns

Clears the name of the primary DNS server.

no secondary dns

Clears the name of the secondary DNS server.

primary dns

<IP address>

Sets the IP address of the primary DNS server.

secondary dns <IP address>

Sets the IP address of the secondary DNS server.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show status

Show interface status

write

Stores the current configuration in permanen t memory.

io (io) level commands

clrscrn

Clears the screen.

exit

Exits to the enable level.

get <io>

Displays the value of the specified Input or Output.

no rss trace <input>

Disables RSS trace of input transitions.

rss trace <input>

Enables RSS trace of input transitions.

set <io> as input

Configures the specified I/O as an input.

set <io> as output

Configures the specified I/O as an output.

set <output> force closed

Forces the specified Output to be Closed.

set <output> force open

Forces the specified Output to be Open.

set <output> normal

Sets the specified Output for normal operation.

show

Displays information for all I/Os.

show history

Displays the last 20 commands entered during the current
CLI session.

ip (config-ip) level commands

auto show stats

Continuously shows IP statistics

clear counters

Zeros counters

clrscrn

Clears the screen.

default multicast time to live

Restores the default IP multicast time to live, which is one
hop.

exit

Exits to the configuration level.

multicast time to live <hops>

Sets the IP multicast time to live.

no clear counters

Unzeros IP counters

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show stats

Shows IP statistics

write

Stores the current configuration in permanen t memory.

ip filter (config-filter) level commands

5: Commands and Levels

IntelliBox-I/O 2100 Command Reference 68

add <ip address> <subnet mask>

Adds an entry to the IP filter table.

clrscrn

Clears the screen.

exit

Returns to the config level.

remove <ip address> <subnet mask>

Removes an entry from the IP filter table.

show

Displays the IP filter table.

show history

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanen t memory.

line 1 (line:1) level commands

auto show statistics

Continuously displays line statistics.

baud rate <bits per second>

Sets the line speed.

clear line counters

Sets the serial counters to zero.

clrscrn

Clears the screen.

command mode always

Sets the current line to always be in command mode.

command mode echo serial string disable

Disables user-defined serial boot string to be echoed in
the CLI.

command mode echo serial string enable

Enables user-defined serial boot string to be echoed in the

CLI.

command mode serial string

Enables user to enter a custom string at boot time to enter
command mode.

command mode.

command mode serial string binary <string>

Sets a binary string that can be entered at boot time to
enter command mode.

command mode signon message <string>

Sets an ASCII sign-on message that is sent from the seri­al port when the

command mode signon message binary
port when the

command mode wait time <milliseconds>

Sets boot-up wait time for command mode serial string.

data bits 7

Uses seven bits for data on the line.

data bits 8

Uses eight bits for data on the line.

default baud rate

Restores the default speed of 9600 bits per second.

default data bits

Restores the default of eight data bits.

default flow control

Restores the default of no flow control.

default interface

Restores the default interface type to this line.

default parity

Restores the default of no parity.

default protocol

Restores the default protocol on the line.

default stop bits

Restores the default of one stop bit.

default xoff char

Restores the default xoff character on this line.

default xon char

Restores the default xon character on this line.

exit

Exits to the enable level

flow control hardware

Uses hardware (RTS/CTS) flow control on the line.

flow control none

Does not provide flow control on the line.

flow control software

Uses software (xon/xoff characters) flow control on the
line.

interface rs232

Sets the line interface to RS232.

interface rs485 full-duplex

Sets the line interface to RS485 in full-duplex mode.

interface rs485 half-duplex

Sets the line interface to RS485 in half-duplex mode.

5: Commands and Levels

command mode serial string <string>

<string>

Sets a string that can be entered at boot time to enter

Sets a binary sign-on message that is sent from the serial

IntelliBox-I/O 2100 Command Reference 69

5: Commands and Levels

line <line>

Enters the line level.

lpd <line>

Enters the configure lpd level.

name <text>

Sets the name for this line.

no clear line counters

Restores the serial counters to the aggregate values.

no command mode

Disables command mode for the current line.

no command mode serial string

Prevents the user-defined serial boot string from being
used to enter

no command mode signon message

Clears the signon message displayed at boot time and
when entering

no name

Removes the name of this line.

parity even

Uses a parity bit on the line for even parity.

parity none

Does not use a parity bit on the line.

parity odd

Uses a parity bit on the line for odd parity.

protocol lpd

Applies Line Printer Daemon (LPD) protocol on the line.

protocol lpd or tunnel

Applies LPD or tunnel protocol on the line.

protocol modbus ascii

Applies Modbus ASCII protocol on the line.

protocol modbus rtu

Applies Modbus RTU protocol on the line.

protocol none

Uses no protocol on the line.

protocol tunnel

Applies tunnel protocol on the line.

reassert

Asserts line status with current configured values.

show

Displays the current status.

show command mode

Shows the command mode settings for the current line.

show history

Displays the last 20 commands entered during the current
CLI session.

show line

Displays the current configuration.

show statistics

Shows the line statistics.

state disable

Disables the line so data cannot be sent/received.

state enable

Enables the line so data can be sent/received.

stop bits 1

Uses one stop bit after data on the line.

stop bits 2

Uses two stop bits after data on the line.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

termination disable

Refrains from terminating the line.

mode.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

xoff char <control>

Sets the xoff character for use with software flow control
on this line.

xon char <control>

Sets the xon character for use with software flow control
on this line.

line 2 (line:2) level commands

auto show statistics

Continuously displays line statistics.

baud rate <bits per second>

Sets the line speed.

clear line counters

Sets the serial counters to zero.

clrscrn

Clears the screen.

command mode always

Sets the current line to always be in command mode.

termination enable Enables 120 ohm line termination in RS485 half-duplex

IntelliBox-I/O 2100 Command Reference 70

command mode echo serial string disable

Disables user-defined serial boot string to be echoed in

command mode echo serial string enable

Enables user-defined serial boot string to be echoed in the
CLI.

command mode serial string

Enables user to enter a custom string at boot time to enter
command mode.

command mode serial string <string>

Sets a string that can be entered at boot time to enter
command mode.

command mode serial string binary <string>

Sets a binary string that can be entered at boot time to
enter command mode.

al port when the

command mode signon message binary <string>

Sets a binary sign-on message that is sent from the serial
port when the

command mode wait time <milliseconds>

Sets boot-up wait time for command mode serial string.

data bits 7

Uses seven bits for data on the line.

data bits 8

Uses eight bits for data on the line.

default baud rate

Restores the default speed of 9600 bits per second.

default data bits

Restores the default of eight data bits.

default flow control

Restores the default of no flow control.

default interface

Restores the default interface type to this line.

default parity

Restores the default of no parity.

default protocol

Restores the default protocol on the line.

default stop bits

Restores the default of one stop bit.

default xoff char

Restores the default xoff character on this line.

default xon char

Restores the default xon character on this line.

exit

Exits to the enable level

flow control hardware

Uses hardware (RTS/CTS) flow control on the line.

flow control none

Does not provide flow control on the line.

flow control software

Uses software (xon/xoff characters) flow control on the
line.

interface rs232

Sets the line interface to RS232.

interface rs485 full-duplex

Sets the line interface to RS485 in full-duplex mode.

interface rs485 half-duplex

Sets the line interface to RS485 in half-duplex mode.

line

Enters the line level.

lpd

Enters the configure lpd level.

name <text>

Sets the name for this line.

no clear line counters

Restores the serial counters to the aggregate values.

no command mode

Disables command mode for the current line.

no command mode serial string

Prevents the user-defined serial boot string from being
used to enter

when entering

no name

Removes the name of this line.

parity even

Uses a parity bit on the line for even parity.

parity none

Does not use a parity bit on the line.

parity odd

Uses a parity bit on the line for odd parity.

protocol lpd

Applies Line Printer Daemon (LPD) protocol on the line.

5: Commands and Levels

the CLI.

command mode signon message <string>

Sets an ASCII sign-on message that is sent from the seri-

<line>

<line>

no command mode signon message Clears the signon message displayed at boot time and

IntelliBox-I/O 2100 Command Reference 71

protocol lpd or tunnel

Applies LPD or tunnel protocol on the line.

protocol modbus ascii

Applies Modbus ASCII protocol on the line.

protocol modbus rtu

Applies Modbus RTU protocol on the line.

protocol none

Uses no protocol on the line.

protocol tunnel

Applies tunnel protocol on the line.

reassert

Asserts line status with current configured values.

show

Displays the current status.

show command mode

Shows the command mode settings for the current line.

show history

Displays the last 20 commands entered during the current
CLI session.

show line

Displays the current configuration.

show statistics

Shows the line statistics.

state disable

Disables the line so data cannot be sent/received.

state enable

Enables the line so data can be sent/received.

stop bits 1

Uses one stop bit after data on the line.

stop bits 2

Uses two stop bits after data on the line.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

termination disable

Refrains from terminating the line.

mode.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanent memory.

on this line.

xon char <control>

Sets the xon character for use with software flow control
on this line.

link (config-ethernet:eth0) level commands

clrscrn

Clears the screen.

default duplex

Restores the default duplex setting, which is auto.

default speed

Restores the default speed setting, which is auto­negotiate.

duplex auto

Sets duplex mode to auto.

duplex full

Sets duplex mode to full.

duplex half

Sets duplex mode to half.

exit

Exit back to interface configuration level

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

speed 10

Sets the speed of the Ethernet link to 10 Mbps.

speed 100

Sets the speed of the Ethernet link to 100 Mbps.

speed auto

Sets the speed of the Ethernet link to auto-negotiate.

write

Stores the current configuration in permanen t memory.

lpd (lpd) level commands

auto show <line>

Continuously displays lpd status for the specified line.

clrscrn

Clears the screen.

exit

Exits to the enable level.

5: Commands and Levels

termination enable Enables 120 ohm line termination in RS485 half-duplex

xoff char <control>

Sets the xoff character for use with software flow control

IntelliBox-I/O 2100 Command Reference 72

5: Commands and Levels

kill <line>

Kills the current print job on the specified line.

show <line>

Displays lpd status for the specified line.

show history

Displays the last 20 commands entered during the current
CLI session.

lpd 1 (config-lpd:1) level commands

banner disable

Disables printing banner for all print jobs. Only print the
banner when a

banner enable

Enables printing banner for all print jobs.

racters and

binary enable

Treats print job as binary. Sends data byte-for-byte to the
printer.

capture disable

Redirects serial output back to the line.

capture enable

Redirects serial output from the line to this CLI session.

clrscrn

Clears the screen.

convert newline disable

Disables converting single new line and carriage return
characters to

convert newline enable

Enables converting single new line and carriage return
characters to

eoj disable

Disables sending the end-of-job string after each print job.

eoj enable

Enables sending the end-of-job string after each print job.

eoj text binary <binary>

Sets the end-of-job text allowing for binary characters.

eoj text set <text>

Sets the end-of-job text.

exit

Exits to the configuration level.

formfeed disable

Disables the printer from advancing to the next page at
the end of each

of each print job.

kill

Ends the current print job on this lpd line.

line <line>

Enters the line level.

lpd <line>

Enters the configure lpd level.

no eoj text

Removes the end-of-job strin g.

no queue name

Removes the queue name.

no soj text

Removes the start-of-job string.

queue name

Sets the name of the queue that this lpd line belongs to.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

show statistics

Displays statistics and status inform ation for this lpd line.

job.

soj enable

Enables sending the start-of-job string after each print job.

soj text binary <binary>

Sets the start-of-job text allowing for binary characters.

soj text set <text>

Sets the start-of-job text.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

test print <number of lines>

Prints lines of text directly to the lpd line.

tunnel <line>

Enters the tunnel level.

binary disable Treats print job as ascii text. Filters out all non-ascii cha-

formfeed enable Forces the printer to advance to the next page at the end

<text>

show history

soj disable Disables sending the start-of-job string after each print

IntelliBox-I/O 2100 Command Reference 73

5: Commands and Levels

write

Stores the current configuration in permanen t memory.

lpd 2 (config-lpd:2) level commands

banner disable

Disables printing banner for all print jobs. Only print the
banner when a

banner enable

Enables printing banner for all print jobs.

binary disable

Treats print job as ascii text. Filters out all non-ascii cha­racters and

printer.

capture disable

Redirects serial output back to the line.

capture enable

Redirects serial output from the line to this CLI session.

clrscrn

Clears the screen.

characters to

convert newline enable

Enables converting single new line and carriage return
characters to

eoj disable

Disables sending the end-of-job string after each print job.

eoj enable

Enables sending the end-of-job string after each print job.

eoj text binary <binary>

Sets the end-of-job text allowing for binary characters.

eoj text set <text>

Sets the end-of-job text.

exit

Exits to the configuration level.

formfeed disable

Disables the printer from advancing to the next page at
the end of each

formfeed enable

Forces the printer to advance to the next page at the end
of each print job.

kill

Ends the current print job on this lpd line.

line

Enters the line level.

lpd

Enters the configure lpd level.

no eoj text

Removes the end-of-job string.

no queue name

Removes the queue name.

no soj text

Removes the start-of-job string.

queue name <text>

Sets the name of the queue that this lpd line belongs to.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show statistics

Displays statistics and status inform ation for this lpd line.

job.

soj enable

Enables sending the start-of-job string after each print job.

soj text binary <binary>

Sets the start-of-job text allowing for binary characters.

soj text set <text>

Sets the start-of-job text.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

test print

Prints lines of text directly to the lpd line.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

match 1 (config-eventtrak-match:2.1) level commands

case sensitive no

Sets EventTrak monitoring to be insensitiv e to case, so

binary enable Treats print job as binary. Sends data byte-for-byte to the

convert newline disable Disables converting single new line and carriage return

<line>

<line>

soj disable Disables sending the start-of-job string after each print

<number of lines>

IntelliBox-I/O 2100 Command Reference 74

5: Commands and Levels

either a or A will

case sensitive yes

Sets EventTrak monitoring to be case sensitiv e, requiring
an exact match.

clrscrn

Clears the screen.

default case sensitive

Sets the default EventT rak mo nitor i ng case sens itiv ity ,
which is not case

default timeout milliseconds

Restores the default EventTrak monitoring timeout.

exit

Exits to the EventTrak level.

match <number>
figuration.

no string

Removes the EventTrak monitoring match string.

no wildcard

Removes the EventTrak wildcard character.

rss trace matches disable

Turns off RSS tracing of EventTrak string matches.

matches the string.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

string binary <binary>

Sets the EventTrak monitoring match string allowing for
binary characters.

string set <text>

Sets the EventTrak monitoring match string.

task <number>

Changes to the command level for EventTrak Task confi­guration.

data that might

wildcard <text>

Sets the EventTrak monitoring wildcard character. Where
it is placed in the

write

Stores the current configuration in permanen t memory.

match 1 (config-eventtrak-match:1.1) level commands

case sensitive no

Sets EventTrak monitor ing to be insen sit ive to case, so
either a or A will

an exact match.

clrscrn

Clears the screen.

which is not case

default timeout milliseconds

Restores the default EventTrak monitoring timeout.

exit

Exits to the EventTrak level.

match <number>

Changes to the command level for EventTrak Match con­figuration.

no string

Removes the EventTrak monitoring match string.

no wildcard

Removes the EventTrak wildcard character.

rss trace matches disable

Turns off RSS tracing of EventTrak string matches.

rss trace matches enable

Turns on RSS tracing to post each time EventTrak
matches the string.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

binary characters.

Changes to the command level for EventTrak Match con-

rss trace matches enable Turns on RSS tracing to post each time EventTrak

timeout milliseconds <number>

case sensitive yes Sets EventTr ak monitoring to be case sensitive, requiring

default case sensitive Sets the default EventTrak monitoring case sensitivity ,

Sets the EventTrak monitoring timeout milliseconds. Old

string binary <binary>

IntelliBox-I/O 2100 Command Reference 75

Sets the EventTrak monitoring match string allowing for

5: Commands and Levels

string set <text>

Sets the EventTrak monitoring match string.

task <number>

Changes to the command level for EventTrak Task confi­guration.

timeout milliseconds <number>

Sets the EventTrak monitoring timeout milliseconds. Old
data that might

it is placed in the

write

Stores the current configuration in permanen t memory.

match 2 (config-eventtrak-match:2.2) level commands

case sensitive no

Sets EventTrak monitor ing to be insen sit ive to case, so
either a or A will

case sensitive yes

Sets EventTrak monitoring to be case sensitiv e, requiring
an exact match.

clrscrn

Clears the screen.

default case sensitive

Sets the default EventTrak monitoring case sensitivity ,
which is not case

default timeout milliseconds

Restores the default EventTrak monitoring timeout.

exit

Exits to the EventTrak level.

figuration.

no string

Removes the EventTrak monitoring match string.

no wildcard

Removes the EventTrak wildcard character.

rss trace matches disable

Turns off RSS tracing of EventTrak string matches.

matches the string.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

string binary <binary>

Sets the EventTrak monitoring match string allowing for
binary characters.

string set

Sets the EventTrak monitoring match string.

task
guration.

timeout milliseconds <number>

Sets the EventTrak monitoring timeout milliseconds. Old
data that might

wildcard <text>

Sets the EventTrak monitoring wildcard character. Where
it is placed in the

write

Stores the current configuration in permanen t memory.

match 2 (config-eventtrak-match:1.2) level commands

case sensitive no

Sets EventTrak monitor ing to be insen sit ive to case, so
either a or A will

an exact match.

clrscrn

Clears the screen.

default case sensitive

Sets the default EventTrak monitoring case sensitivity ,
which is not case

default timeout milliseconds

Restores the default EventTrak monitoring timeout.

exit

Exits to the EventTrak level.

match <number>

Changes to the command level for EventTrak Match con­figuration.

wildcard <text>

match <number>

rss trace matches enable Turns on RSS tracing to post each time EventTrak

Sets the EventTrak monitoring wildcard character. Where

Changes to the command level for EventTrak Match con-

<text>

<number>

case sensitive yes Sets EventTr ak monitoring to be case sensitive, requiring

Changes to the command level for EventTrak Task confi-

IntelliBox-I/O 2100 Command Reference 76

5: Commands and Levels

no string

Removes the EventTrak monitoring match string.

no wildcard

Removes the EventTrak wildcard character.

rss trace matches disable

Turns off RSS tracing of EventTrak string matches.

rss trace matches enable

Turns on RSS tracing to post each time EventTrak
matches the string.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

string binary <binary>
binary characters.

string set <text>

Sets the EventTrak monitoring match string.

guration.

timeout milliseconds <number>

Sets the EventTrak monitoring timeout milliseconds. Old
data that might

wildcard <text>

Sets the EventTrak monitoring wildcard character. Where
it is placed in the

write

Stores the current configuration in permanen t memory.

match 3 (config-eventtrak-match:2.3) level commands

either a or A will

case sensitive yes

Sets EventTrak monitoring to be case sensitiv e, requiring
an exact match.

clrscrn

Clears the screen.

default case sensitive

Sets the default EventTrak monitoring case sensitivity ,
which is not case

default timeout milliseconds

Restores the default EventTrak monitoring timeout.

exit

Exits to the EventTrak level.

match <number>

Changes to the command level for EventTrak Match con­figuration.

no string

Removes the EventTrak monitoring match string.

no wildcard

Removes the EventTrak wildcard character.

rss trace matches disable

Turns off RSS tracing of EventTrak string matches.

rss trace matches enable

Turns on RSS tracing to post each time EventTrak
matches the string.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

string binary <binary>

Sets the EventTrak monitoring match string allowing for
binary characters.

string set <text>

Sets the EventTrak monitoring match string.

task <number>

Changes to the command level for EventTrak Task confi­guration.

timeout milliseconds
data that might

wildcard <text>

Sets the EventTrak monitoring wildcard character. Where
it is placed in the

write

Stores the current configuration in permanen t memory.

match 3 (config-eventtrak-match:1.3) level commands

case sensitive no

Sets EventTrak monitor ing to be insen sit ive to case, so

Sets the EventTrak monitoring match string allowing for

task <number>

case sensitive no Sets EventTrak monitor ing to be insen sit ive to case, so

Changes to the command level for EventTrak Task confi-

show history

<number>

IntelliBox-I/O 2100 Command Reference 77

Sets the EventTrak monitoring timeout milliseconds. Old

5: Commands and Levels

either a or A will

case sensitive yes

Sets EventTrak monitoring to be case sensitiv e, requiring
an exact match.

clrscrn

Clears the screen.

default case sensitive

Sets the default EventTrak monitoring case sensitivity ,
which is not case

default timeout milliseconds

Restores the default EventTrak monitoring timeout.

exit

Exits to the EventTrak level.

match <number>
figuration.

no string

Removes the EventTrak monitoring match string.

no wildcard

Removes the EventTrak wildcard character.

rss trace matches disable

Turns off RSS tracing of EventTrak string matches.

matches the string.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

string binary <binary>

Sets the EventTrak monitoring match string allowing for
binary characters.

string set <text>

Sets the EventTrak monitoring match string.

task <number>

Changes to the command level for EventTrak Task confi­guration.

data that might

wildcard <text>

Sets the EventTrak monitoring wildcard character. Where
it is placed in the

write

Stores the current configuration in permanen t memory.

modbus (modbus) level commands

additional port <number>

Sets an additional TCP server port.

clrscrn

Clears the screen.

default response timeout

Restores the default Modbus Response Timeout.

exit

Exits to the config level.

kill connection <index>

Kills modbus connection selected by index from show
connections.

no additional port

Removes the additional TCP server port.

response timeout <milliseconds>

Sets the Modbus Response Timeout in milliseconds.

show

Displays the current configuration.

show connections

Displays connections.

show history

Displays the last 20 commands entered during the current
CLI session.

show statistics

Displays statistics.

tcp server state disable

Disables the Modbus TCP Server.

tcp server state enable

Enables the Modbus TCP Server.

modem (tunnel-modem:2) level commands

clrscrn

Clears the screen.

connect string <text>

Sets the CONNECT string used in modem emulation.

default incoming connection

Default disables incoming netw ork connecti ons .

default response type

Default uses text type responses.

Changes to the command level for EventTrak Match con-

rss trace matches enable Turns on RSS tracing to post each time EventTrak

timeout milliseconds <number>

Sets the EventTrak monitoring timeout milliseconds. Old

IntelliBox-I/O 2100 Command Reference 78

5: Commands and Levels

display remote ip disable

The incoming RING has nothing following it.

display remote ip enable

The incoming RING is followed by the IP address of the
caller.

echo commands disable

Does not echo modem commands.

echo commands enable

Echoes modem commands.

echo pluses disable

Does not echo the +++ characters when entering modem
command mode.

mand mode.

error unknown commands disable

Returns OK on unknown AT commands.

error unknown commands enable

Returns an error upon unknown AT commands.

exit

Returns to the tunnel level.

incoming connection automati c

Automatically answer incoming network connections.

incoming connection disabled

Disable incoming network connections.

network connection.

no connect string

Removes optional CONNECT string information for mod­em emulation.

reassert

Asserts tunnel modem status with current configured val­ues.

response type numeric

Uses numeric type responses.

response type text

Uses text type responses.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

status

Displays tunnel modem status.

verbose response disable

Does not send Modem Response Codes.

verbose response enable

Sends Modem Response Codes out on the Serial Line.

write

Stores the current configuration in permanen t memory.

modem (tunnel-modem:1) level commands

clrscrn

Clears the screen.

connect string <text>

Sets the CONNECT string used in modem emulation.

default incoming connection

Default disables incoming netw ork connecti ons .

default response type

Default uses text type responses.

display remote ip disable

The incoming RING has nothing following it.

display remote ip enable

The incoming RING is followed by the IP address of the
caller.

echo commands disable

Does not echo modem commands.

echo commands enable

Echoes modem commands.

echo pluses disable

Does not echo the +++ characters when entering modem
command mode.

mand mode.

error unknown commands disable

Returns OK on unknown AT commands.

error unknown commands enable

Returns an error upon unknown AT commands.

exit

Returns to the tunnel level.

incoming connection automatic

Automatically answer incoming network connections.

incoming connection disabled

Disable incoming network connections.

echo pluses enable Echoes the +++ characters when entering modem com-

incoming connection manual Wait for an ATA command before answering an incoming

echo pluses enable Echoes the +++ characters when entering modem com-

IntelliBox-I/O 2100 Command Reference 79

5: Commands and Levels

incoming connection manual

Wait for an ATA command before answering an incoming

no connect string

Removes optional CONNECT string information for mod­em emulation.

ues.

response type numeric

Uses numeric type responses.

response type text

Uses text type responses.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

status

Displays tunnel modem status.

verbose response disable

Does not send Modem Response Codes.

verbose response enable

Sends Modem Response Codes out on the Serial Line.

write

Stores the current configuration in permanen t memory.

output select (tunnel-connect-output_select:2) level commands

clrscrn

Clears the screen.

default mode

Requires exclusive control of the output for connect mode
connection.

exit

Exits to the next higher level.

mode exclusive control

Requires exclusive control of the output for connect mode

mode logical-or

Does not require exclusive control of the output for con­nect mode connection.

connection is up.

output <text>

Selects an output to enable while the connect mode con­nection is up.

show

Shows the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanen t memory.

output select (tunnel-accept-output_select:2) level com man ds

clrscrn

Clears the screen.

default mode

Requires exclusive control of the output for accept mode
connection.

exit

Exits to the next higher level.

connection.

mode logical-or

Does not require exclusive control of the output for accept
mode connection.

no output

Discontinues enabling any output while the accept mode
connection is up.

output
nection is up.

show

Shows the current configuration.

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanen t memory.

output select (tunnel-connect-output_select:1) level commands

network connection.

reassert Asserts tunnel modem status with current configured val-

connection.

no output Discontinues enabling any output while the connect mode

mode exclusive control Requires exclusive control of the output for accept mode

<text>

Selects an output to enable while the accept mode con-

show history

IntelliBox-I/O 2100 Command Reference 80

5: Commands and Levels

clrscrn

Clears the screen.

default mode

Requires exclusive control of the output for connect mode
connection.

exit

Exits to the next higher lev el.

mode exclusive control

Requires exclusive control of the output for connect mode
connection.

nect mode connection.

no output

Discontinues enabling any output while the conn ect mo de
connection is up.

output <text>

Selects an output to enable while the connect mode con­nection is up.

show

Shows the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanent memory.

output select (tunnel-accept-output_select:1) level com man ds

clrscrn

Clears the screen.

connection.

exit

Exits to the next higher level.

mode exclusive control

Requires exclusive control of the output for accept mode
connection.

mode logical-or

Does not require exclusive control of the output for accept
mode connection.

no output

Discontinues enabling any output while the accept mode
connection is up.

nection is up.

show

Shows the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanent memory.

packing (tunnel-packing:2) level commands

clrscrn

Clears the screen.

default packing mode

Sets to default packing mode, which is "Disable"

default threshold

Restores the default threshold.

default timeout

Restores the default packing mode timeout.

exit

Returns to the tunnel level.

no send character

Removes the send character for packing mode.

no trailing character

Removes the trailing character for packing mo de.

packing mode disable

Disables packing. Data is sent to the network when re­ceived.

packing mode send character

Sets packing mode to accumulate data and transmit it
upon receiving the

packing mode timeout

Sets packing mode to accumulate data and transmit it
after a specified

send character <control>

Sets the send character for packing mode.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current

mode logical-or Does not require exclusive control of the output for con-

default mode Requires exclusive control of the output for accept mode

output <text>

Selects an output to enable while the accept mode con-

IntelliBox-I/O 2100 Command Reference 81

CLI session.

threshold <bytes>

Sets the threshold (byte count). If the queued data reach­es this threshold

timeout <milliseconds>

Sets the timeout value for packing mode in milliseconds.

trailing character <control>

Sets the trailing character for packing mod e.

write

Stores the current configuration in permanen t memory.

packing (tunnel-packing:1) level commands

clrscrn

Clears the screen.

default packing mode

Sets to default packing mode, which is "Disable"

default threshold

Restores the default threshold.

default timeout

Restores the default packing mode timeout.

exit

Returns to the tunnel level.

no send character

Removes the send character for packing mode.

no trailing character

Removes the trailing character for packing mo de.

packing mode disable

Disables packing. Data is sent to the network when re­ceived.

packing mode send character

Sets packing mode to accumulate data and transmit it

upon receiving the

packing mode timeout

Sets packing mode to accumulate data and transmit it
after a specified

send character <control>

Sets the send character for packing mode.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

threshold <bytes>

Sets the threshold (byte count). If the queued data reach­es this threshold

timeout <milliseconds>

Sets the timeout value for packing mode in milliseconds.

trailing character <control>

Sets the trailing character for packing mod e.

write

Stores the current configuration in permanen t memory.

query port (config-query_port) level commands

clrscrn

Clears the screen.

exit

Returns to the config level.

show

Displays statistics and information about the query port.

show history

Displays the last 20 commands entered during the current
CLI session.

state disable

Disables response to 77FE requests.

state enable

Permits response to 77FE requests.

write

Stores the current configuration in permanen t memory.

root level commands

clrscrn

Clears the screen.

enable

Enters the enable level.

exit

Exit from the system

ping <host>

Ping destination 5 times with 5 second timeout

ping <host> <count>

Ping destination n times with 5 second timeout

ping <host> <count> <timeout>

Ping destination n times with x timeout (in seconds)

show

Show system information

Displays the last 20 commands entered during the current
CLI session.

5: Commands and Levels

show history

show history

IntelliBox-I/O 2100 Command Reference 82

5: Commands and Levels

show ibio2100

Show system information

trace route <host>

Trace route to destination

rss (config-rss) level commands

clear rss

Clear the RSS Feed data

clrscrn

Clears the screen.

default max entries

Restores the default number of RSS feed entries.

exit

Exits to the configuration level.

feed disable

Disables RSS feed.

feed enable

Enables RSS feed.

max entries <number>

Sets the maximum number of RSS feed entries.

persist disable

Disables RSS feed data persistence.

persist enable

Enables RSS feed data persistence.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show status

Display the RSS Feed status

write

Stores the current configuration in permanen t memory.

serial (tunnel-serial: 2) level comma nds

port.

clrscrn

Clears the screen.

default buffer size

Restores the default buffer size.

default dtr

Restores default DTR control, asserted while connected.

connection is active.

dtr continuously asserted

Asserts DTR regardless of any connections.

dtr unasserted

Does not assert DTR.

exit

Returns to the tunnel level.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanen t memory.

serial (tunnel-serial: 1) level comma nds

buffer size <bytes>

Sets the size of the buffer for data read from the serial
port.

clrscrn

Clears the screen.

default buffer size

Restores the default buffer size.

default dtr

Restores default DTR control, asserted while connected.

dtr asserted while connected

Asserts DTR whenever a connect or accept mode tunnel
connection is active.

dtr continuously asserted

Asserts DTR regardless of any connections.

dtr unasserted

Does not assert DTR.

exit

Returns to the tunnel level.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanen t memory.

snmp (config-snmp) level commands

buffer size <bytes>

dtr asserted while connected Asserts DTR whenever a connect or accept mode tunnel

Sets the size of the buffer for data read from the serial

IntelliBox-I/O 2100 Command Reference 83

5: Commands and Levels

clrscrn

Clears the screen.

community ro <string>

Sets the SNMP read-only community string.

community rw <string>

Sets the SNMP read-write community string.

contact <string>

Sets the SNMP system contact information.

default description

Restores the SNMP system description to its default.

description <string>

Sets the SNMP system description.

exit

Returns to the config level.

host <ip address>

Sets the primary SNMP trap host.

host <ip address> <ip address>

Sets the primary and secondary SNMP trap hosts.

location <string>

Sets the SNMP system location.

name <string>

Sets the SNMP system name.

no community ro

Clears the SNMP read-only community.

no community rw

Clears the SNMP read/write community.

no contact

Clears the SNMP server contact.

no host <ip address>

Deletes the designated SNMP server trap host.

no host <ip address> <ip address>

Deletes the designated SNMP server trap hosts.

no location

Clears the SNMP server location.

no name

Clears the SNMP server name.

server disable

Disables the SNMP server.

server enable

Enables the SNMP server.

show

Displays the SNMP server settings.

show history

Displays the last 20 commands entered during the current
CLI session.

traps disable

Disables the sending of SNMP trap messages.

traps enable

Enables the sending of SNMP trap messages.

write

Stores the current configuration in permanen t memory.

ssh (ssh) level commands

client server <server>

Set Client Server RSA or DSA key

client server <server> <key>

Set Client Server RSA or DSA key

client user <user> <command>

Set Client User, command and RSA or DSA keys

client user <user> <password> <command>

Set Client User with password, command and optional
RSA or DSA keys

client us­er <user> <password> <command> <public> <private>

Set Client User with password, command and RSA or
DSA keys

client user

generate dsa 1024

Generate DSA public and private keys

client user

generate dsa 512

Generate DSA public and private keys

client user <user> generate dsa 768

Generate DSA public and private keys

client user <user> generate rsa 1024

Generate RSA public and private keys

client user <user> generate rsa 512

Generate RSA public and private keys

client user <user> generate rsa 768

Generate RSA public and private keys

clrscrn

Clears the screen.

exit

Exits to the enable level.

host

Sets RSA or DSA public and/or private keys

host <key>

Sets RSA or DSA public or private key

host <public> <private>

Sets RSA or DSA public and private keys

host generate dsa 1024

Generate DSA public and private keys

host generate dsa 512

Generate DSA public and private keys

<user>
<user>

IntelliBox-I/O 2100 Command Reference 84

5: Commands and Levels

host generate dsa 768

Generate DSA public and private keys

host generate rsa 1024

Generate RSA public and private keys

host generate rsa 512

Generate RSA public and private keys

host generate rsa 768

Generate RSA public and private keys

host user <user> <password>

Sets Host username and password

host user <user> <password> <public>

Sets Host username, password and either a RSA or DSA
public key.

host user <user> <password> <public> <public>

Sets Host username, password and both RSA and DSA
public keys.

no client server <server>

Remove Client Server

no client server <server> dsa

Remove Client Server DSA key

no client server <server> rsa

Remove Client Server RSA key

no client user <user>

Remove Client User

no client user <user> command

Remove command from Client User

no client user <user> dsa

Remove Client User DSA key

no client user <user> rsa

Remove Client User RSA key

no host dsa

Removes DSA public and private keys

no host rsa

Removes RSA public and private keys

no host user <user>

Remove a host user

show

Show SSH settings

show client server <server>

Show Client Server RSA and DSA keys

show client user <user>

Show information for a client user

show history

Displays the last 20 commands entered during the current
CLI session.

show host dsa

Show full DSA public key

show host rsa

Show full RSA public key

show host user <user>

Show information for a host user

write

Stores the current configuration in permanen t memory.

ssl (ssl) level commands

authority

Adds an Authority Certificate.

clrscrn

Clears the screen.

dsa

Adds DSA Certificate and Private Key.

exit

Exits to the enable level.

generate dsa

Generates a new Self-Sig ned DS A Certifi cate.

generate rsa

Generates a new Self-Signed RSA Certificate.

no dsa

Removes DSA Certificate and Private Key

no intermediate authority <cert>

Removes an Intermediate Authority Certificate.

no rsa

Removes RSA Certificate and Private Key

no trusted authority <cert>

Removes a Trusted Authority Certificate.

rsa

Adds RSA Certificate and Private Key.

show

Displays Certificate Information.

show authority

Displays Authority Certificate Information.

show history

Displays the last 20 commands entered during the current
CLI session.

write

Stores the current configuration in permanent memory.

syslog (config-syslog) level co mma nds

clrscrn

Clears the screen.

IntelliBox-I/O 2100 Command Reference 85

default local port

Restores the default syslog local port.

default remote port

Restores the default syslog remote port.

exit

Returns to the config level.

host <IP address>

Sets the address of the syslog recipient.

level <severity>

Sets the minimum severity of events that will be logged.

local port <number>

Sets the syslog local port.

no host

Removes the address of the syslog recipient.

no level

Disables logging of all events.

remote port <number>

Sets the syslog remote port.

show

Displays the syslog settings and statistics.

show history

Displays the last 20 commands entered during the current
CLI session.

state disable

Disables syslog logging.

state enable

Enables syslog logging.

write

Stores the current configuration in permanen t memory.

task 1 (config-eventtrak-task:2.1) level commands

activity none

Sets the EventTrak task activity to None.

output pin.

activity ping

Sets the EventTrak task activity to send a ping once per
second.

clrscrn

Clears the screen.

default activity

Sets the default EventTrak task activity, which is None.

default description

Removes the description of an EventTrak control task.

default output control

Sets the default EventTrak output control, which is Exclu­sive.

description <text>

Sets the description of an EventTrak control task. It will
appear in

exit

Exits to the EventTrak level.

figuration.

no ping address

Removes the EventTrak ping address.

output control exclusive

Sets the EventTrak output control to exclusive, so if the
activity is to

output control logical-or

Sets the EventTrak output control to be Logical-Or, so it
may be combined

ping address <text>
activity is to send

rss trace ping resp onses disable

Turns off RSS tracing of EventTrak ping responses.

EventTrak task.

rss trace steps disable

Turns off RSS tracing of EventTrak task steps.

rss trace steps enable

Turns on RSS tracing of each step taken by an EventTrak
task.

rss trace triggers disable

Turns off RSS tracing of EventTrak task triggers.

rss trace triggers enable

Turns on RSS tracing of triggers emitted by this EventTrak
task.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current

5: Commands and Levels

activity output <number>

match <number>

rss trace ping responses enable Turns on RSS tracing of ping responses received by this

Sets the EventTrak task activity to control the designated

Changes to the command level for EventTrak Match con-

Sets the EventTrak ping address to be used when the

IntelliBox-I/O 2100 Command Reference 86

5: Commands and Levels

CLI session.

step <letter>

Changes to the command level for EventTrak Task Step
configuration.

task <number>

Changes to the command level for EventTrak Tas k confi­guration.

write

Stores the current configuration in permanen t memory.

task 1 (config-eventtrak-task:1.1) level commands

activity none

Sets the EventTrak task activity to None.

activity output <number>
output pin.

activity ping

Sets the EventTrak task activity to send a ping once per
second.

clrscrn

Clears the screen.

default activity

Sets the default EventTrak task activity, which is None.

default description

Removes the description of an EventTrak control task.

default output control

Sets the default EventTrak output control, which is Exclu­sive.

description <text>

Sets the description of an EventTrak control task. It will
appear in

exit

Exits to the EventTrak level.

match <number>
figuration.

no ping address

Removes the EventTrak ping address.

activity is to

output control logical-or

Sets the EventTrak output control to be Logical-Or, so it
may be combined

ping address <text>

Sets the EventTrak ping address to be used when the
activity is to send

rss trace ping responses disable

Turns off RSS tracing of EventTrak ping responses.

EventTrak task.

rss trace steps disable

Turns off RSS tracing of EventTrak task steps.

rss trace steps enable

Turns on RSS tracing of each step taken by an EventTrak
task.

rss trace triggers disable

Turns off RSS tracing of EventTrak task triggers.

rss trace triggers enable

Turns on RSS tracing of triggers emitted by this EventTrak
task.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

configuration.

task <number>

Changes to the command level for EventTrak Task confi­guration.

write

Stores the current configuration in permanen t memory.

task 2 (config-eventtrak-task:2.2) level commands

activity none

Sets the EventTrak task activity to None.

activity output <number>

Sets the EventTrak task activity to control the designated
output pin.

Sets the EventTrak task activity to control the designated

Changes to the command level for EventTrak Match con-

output control exclusive Sets the EventTrak output control to exclusive, so if the

rss trace ping responses enable Turns on RSS tracing of ping responses received by this

step <letter>

Changes to the command level for EventTrak Task Step

IntelliBox-I/O 2100 Command Reference 87

activity ping

Sets the EventTrak task activity to send a ping once per

second.

clrscrn

Clears the screen.

default activity

Sets the default EventTrak task activity, which is None.

default description

Removes the description of an EventTrak control task.

default output control

Sets the default EventTrak output control, which is Exclu­sive.

description
appear in

exit

Exits to the EventTrak level.

match <number>

Changes to the command level for EventTrak Match con­figuration.

no ping address

Removes the EventTrak ping address.

output control exclusive

Sets the EventTrak output control to exclusive, so if the
activity is to

output control logical-or

Sets the EventTrak output control to be Logical-Or, so it
may be combined

activity is to send

rss trace ping responses disable

Turns off RSS tracing of EventTrak ping responses.

rss trace ping responses enable

Turns on RSS tracing of ping responses received by this
EventTrak task.

rss trace steps disable

Turns off RSS tracing of EventTrak task steps.

rss trace steps enable

Turns on RSS tracing of each step taken by an EventTrak
task.

rss trace triggers disable

Turns off RSS tracing of EventTrak task triggers.

rss trace triggers enable

Turns on RSS tracing of triggers emitted by this EventTrak
task.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

step <letter>

Changes to the command level for EventTrak Task Step
configuration.

task <number>

Changes to the command level for EventTrak Task confi­guration.

write

Stores the current configuration in permanen t memory.

task 2 (config-eventtrak-task:1.2) level commands

activity none

Sets the EventTrak task activity to None.

activity output <number>

Sets the EventTrak task activity to control the designated
output pin.

second.

clrscrn

Clears the screen.

default activity

Sets the default EventTrak task activity, which is None.

default description

Removes the description of an EventTrak control task.

default output control

Sets the default EventTrak output control, which is Exclu­sive.

description <text>

Sets the description of an EventTrak control task. It will
appear in

exit

Exits to the EventTrak level.

5: Commands and Levels

<text>

ping address <text>

show history

Sets the description of an EventTrak control task. It will

Sets the EventTrak ping address to be used when the

activity ping Sets the EventTrak task activity to send a ping once per

IntelliBox-I/O 2100 Command Reference 88

5: Commands and Levels

match <number>

Changes to the command level for EventTrak Match con­no ping address

Removes the EventTrak ping address.

output control exclusive

Sets the EventTrak output control to exclusive, so if the
activity is to

may be combined

ping address <text>

Sets the EventTrak ping address to be used when the
activity is to send

rss trace ping responses disable

Turns off RSS tracing of EventTrak ping responses.

rss trace ping responses enable

Turns on RSS tracing of ping responses received by this
EventTrak task.

rss trace steps disable

Turns off RSS tracing of EventTrak task steps.

rss trace steps enable

Turns on RSS tracing of each step taken by an EventTrak
task.

rss trace triggers disable

Turns off RSS tracing of EventTrak task triggers.

Turns on RSS tracing of triggers emitted by this EventTrak
task.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

step <letter>

Changes to the command level for EventTrak Task Step
configuration.

task
guration.

write

Stores the current configuration in permanen t memory.

task 3 (config-eventtrak-task:2.3) level commands

activity none

Sets the EventTrak task activity to None.

output pin.

activity ping

Sets the EventTrak task activity to send a ping once per
second.

clrscrn

Clears the screen.

default activity

Sets the default EventTrak task activity, which is None.

default description

Removes the description of an EventTrak control task.

default output control

Sets the default EventTrak output control, which is Exclu­sive.

description <text>

Sets the description of an EventTrak control task. It will
appear in

exit

Exits to the EventTrak level.

figuration.

no ping address

Removes the EventTrak ping address.

output control exclusive

Sets the EventTrak output control to exclusive, so if the
activity is to

output control logical-or

Sets the EventTrak output control to be Logical-Or, so it
may be combined

ping address
activity is to send

rss trace ping responses disable

Turns off RSS tracing of EventTrak ping responses.

rss trace ping responses enable

Turns on RSS tracing of ping responses received by this

figuration.

output control logical-or Sets the EventTrak output control to be Logical-Or, so it

rss trace triggers enable

<number>

activity output <number>

match <number>

Changes to the command level for EventTrak T as k confi-

Sets the EventTrak task activity to control the designated

Changes to the command level for EventTrak Match con-

<text>

IntelliBox-I/O 2100 Command Reference 89

Sets the EventTrak ping address to be used when the

5: Commands and Levels

EventTrak task.

rss trace steps disable

Turns off RSS tracing of EventTrak task steps.

rss trace steps enable

Turns on RSS tracing of each step taken by an EventTrak
task.

rss trace triggers disable

Turns off RSS tracing of EventTrak task triggers.

rss trace triggers enable

Turns on RSS tracing of triggers emitted by this EventTrak
task.

show

Displays the current configuration.

Displays the last 20 commands entered during the current
CLI session.

step <letter>

Changes to the command level for EventTrak Task Step
configuration.

task <number>

Changes to the command level for EventTrak Task confi­write

Stores the current configuration in permanen t memory.

task 3 (config-eventtrak-task:1.3) level commands

activity none

Sets the EventTrak task activity to None.

activity output <number>

Sets the EventTrak task activity to control the designated
output pin.

second.

clrscrn

Clears the screen.

default activity

Sets the default EventTrak task activity, which is None.

default description

Removes the description of an EventTrak control task.

sive.

description <text>

Sets the description of an EventTrak control task. It will
appear in

exit

Exits to the EventTrak level.

match <number>

Changes to the command level for EventTrak Match con­figuration.

no ping address

Removes the EventTrak ping address.

activity is to

may be combined

ping address <text>

Sets the EventTrak ping address to be used when the
activity is to send

rss trace ping responses disable

Turns off RSS tracing of EventTrak ping responses.

rss trace ping responses enable

Turns on RSS tracing of ping responses received by this
EventTrak task.

rss trace steps disable

Turns off RSS tracing of EventTrak task steps.

Turns on RSS tracing of each step taken by an EventTrak
task.

rss trace triggers disable

Turns off RSS tracing of EventTrak task triggers.

rss trace triggers enable

Turns on RSS tracing of triggers emitted by this EventTrak
task.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show history

guration.

activity ping Sets the EventTrak task activity to send a ping once per

default output control Sets the default EventTrak output control, which is Exclu-

output control exclusive Sets the EventTrak output control to exclusive, so if the

output control logical-or Sets the EventTrak output control to be Logical-Or, so it

rss trace steps enable

IntelliBox-I/O 2100 Command Reference 90

step <letter>

Changes to the command level for EventTrak Task Step

configuration.

task <number>

Changes to the command level for EventTrak Task confi­guration.

write

Stores the current configuration in permanen t memory.

tcp (config-tcp) level commands

an ACK is forced.

auto show stats

Continuously shows TCP statistics

clear counters

Zeros TCP counters

clrscrn

Clears the screen.

default ack limit

Restores the default ack limit of 3 packets.

default send data

Sets TCP to send data in accordance with standards.

exit

Exits to the configuration level.

no clear counters

Unzeros TCP counters

ports.

resets enable

Sends TCP RSTs upon connection to unused ports.

send data expedited

Sets TCP to send data whenever the window is sufficient­ly open, for improved

send data standard

Sets TCP to send data in accordance with standards.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

show stats

Shows TCP statistics

write

Stores the current configuration in permanent memory.

terminal 1 (config-terminal:1) level commands

break duration <milliseconds>

Sets how long a break should last when it is being sent to
the line.

clrscrn

Clears the screen.

default break duration

Restores the break duration to the default value (500 ms).

default terminal type

Sets the default terminal type, "UNKNOWN".

echo disable

Disables echoing of characters received on the line back
to the line.

to the line.

exit

Exits to the configuration level.

exit connect menu disable

On the login connect menu, removes the menu item allow­ing the user to exit

exit connect menu enable

On the login connect menu, inserts the menu item allow­ing the user to exit

line <line>

Enters the line level.

login connect menu disable

Disables the login connect menu, so a user will get the
CLI immediately

menu rather than the

lpd <line>

Enters the configure lpd level.

no send break

Removes the configured send break charac ter.

preview connect menu

Shows the layout of the connect menu with current set-

5: Commands and Levels

ack limit <packets>

resets disable Does not send TCP RSTs upon connection to unused

Sets the number of packets that must be received before

echo enable Enables echoing of characters received on the line back

login connect menu enable Enables the login connect menu, so a user will get the

IntelliBox-I/O 2100 Command Reference 91

tings.

send break <control>

Sets the optional send break character.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

terminal type <text>

Sets the terminal type.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

terminal 2 (config-terminal:2) level commands

break duration <milliseconds>

Sets how long a break should last when it is being sent to
the line.

clrscrn

Clears the screen.

default break duration

Restores the break duration to the default value (500 ms).

default terminal type

Sets the default terminal type, "UNKNOWN".

echo disable

Disables echoing of characters received on the line back

to the line.

echo enable

Enables echoing of characters received on the line back
to the line.

exit

Exits to the configuration level.

ing the user to exit

exit connect menu enable

On the login connect menu, inserts the menu item allow­ing the user to exit

line <line>

Enters the line level.

login connect menu disable

Disables the login connect menu, so a user will get the
CLI immediately

menu rather than the

lpd <line>

Enters the configure lpd level.

no send break

Removes the configured send break charac ter.

tings.

send break <control>

Sets the optional send break character.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

terminal type <text>

Sets the terminal type.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

terminal network (config-terminal:network) level commands

break duration <milliseconds>

Sets how long a break should last when it is being sent to
the line.

clrscrn

Clears the screen.

default break duration

Restores the break duration to the default value (500 ms).

default terminal type

Sets the default terminal type, "UNKNOWN".

5: Commands and Levels

exit connect menu disable On the login connect menu, removes the menu item allow-

login connect menu enable Enables the login connect menu, so a user will get the

preview connect menu Shows the layout of the connect menu with current set-

IntelliBox-I/O 2100 Command Reference 92

5: Commands and Levels

echo disable

Disables echoing of characters received on the line back

echo enable

Enables echoing of characters received on the line back
to the line.

exit

Exits to the configuration level.

ing the user to exit

exit connect menu enable

On the login connect menu, inserts the menu item allow­ing the user to exit

line <line>

Enters the line level.

login connect menu disable

Disables the login connect menu, so a user will get the
CLI immediately

menu rather than the

lpd <line>

Enters the configure lpd level.

no send break

Removes the configured send break charac ter.

tings.

send break <control>

Sets the optional send break character.

show

Displays the current configuration.

show history

Displays the last 20 commands entered during the current
CLI session.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

terminal type <text>

Sets the terminal type.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

tftp (config-tftp) level commands

allow file creation disable

Prohibits the TFTP server from creating files on the file
system.

allow file creation enable

Enables the TFTP server to create files on the file system.

clear counters

Sets the TFTP counters to zero.

clrscrn

Clears the screen.

exit

Returns to the config level.

no clear counters

Restores the TFTP counters to the aggregate values.

show

Displays the TFTP settings and statistics.

show history

Displays the last 20 commands entered during the current
CLI session.

state disable

Disables the TFTP server.

state enable

Enables the TFTP server.

write

Stores the current configuration in permanen t memory.

tunnel 1 (tunnel:1) level commands

accept

Enters the accept level for this tunnel.

auto show statistics

show connection statistics

clear accept counters

Zeros accept counters

clear aggregate counters

Zeros aggregate counters

clear all counters

Zeros all tunnel counters

clear connect counters

Zeros connect counters

to the line.

exit connect menu disable On the login connect menu, removes the menu item allow-

login connect menu enable Enables the login connect menu, so a user will get the

preview connect menu Shows the layout of the connect menu with current set-

IntelliBox-I/O 2100 Command Reference 93

5: Commands and Levels

clrscrn

Clears the screen.

connect

Enters the connect level for this tunnel.

disconnect

Enters the disconnect level for this tunnel.

echo start character disable

Disables forwarding (tunneling) of the start character.

echo start character enable

Enables forwarding (tunneling) of the start character.

echo stop character disable

Disables forwarding (tunneling) of the stop character.

echo stop character enable

Enables forwarding (tunneling) of the stop character.

exit

Exits to the enable level.

line <line>

Enters the line level.

lpd <line>

Enters the configure lpd level.

modem

Enters the modem level for this tunnel.

no clear accept counters

Unzeros accept counters

no clear aggregate counters

Unzeros aggregate counters

no clear all counters

Unzeros all tunnel counters

no clear connect counters

Unzeros connect counters

no start character

Removes the start character.

no stop character

Removes the stop character.

packing

Enters the packing level for this tunnel.

serial

Enters the serial level for this tunnel.

show

Displays tunneling configurati o n.

show history

Displays the last 20 commands entered during the current
show statistics

show connection statistics

start character <string>

Sets the start character.

stop character <string>

Sets the stop character.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

tunnel 2 (tunnel:2) level commands

accept

Enters the accept level for this tunnel.

auto show statistics

show connection statistics

clear accept counters

Zeros accept counters

clear aggregate counters

Zeros aggregate counters

clear all counters

Zeros all tunnel counters

clear connect counters

Zeros connect counters

clrscrn

Clears the screen.

connect

Enters the connect level for this tunnel.

disconnect

Enters the disconnect level for this tunnel.

echo start character disable

Disables forwarding (tunneling) of the start character.

echo start character enable

Enables forwarding (tunneling) of the start character.

echo stop character disable

Disables forwarding (tunneling) of the stop character.

echo stop character enable

Enables forwarding (tunneling) of the stop character.

exit

Exits to the enable level.

line <line>

Enters the line level.

lpd <line>

Enters the configure lpd level.

CLI session.

IntelliBox-I/O 2100 Command Reference 94

modem

Enters the modem level for this tunnel.

no clear accept counters

Unzeros accept counters

no clear aggregate counters

Unzeros aggregate counters

no clear all counters

Unzeros all tunnel counters

no clear connect counters

Unzeros connect counters

no start character

Removes the start character.

no stop character

Removes the stop character.

packing

Enters the packing level for this tunnel.

serial

Enters the serial level for this tunnel.

show

Displays tunneling configurati o n.

show history Displays the last 20 commands

entered during the current

CLI session.

show statistics

show connection statistics

start character <string>

Sets the start character.

stop character <string>

Sets the stop character.

terminal <line>

Enters the configure-terminal level.

terminal network

Enters the configure-terminal level for the network.

tunnel <line>

Enters the tunnel level.

write

Stores the current configuration in permanen t memory.

udp (config-udp) level commands

auto show stats

Continuously shows UDP statistics

clear counters

Zeros counters

clrscrn

Clears the screen.

exit

Exits to the configuration level.

no clear counters

Unzeros IP counters

show history

Displays the last 20 commands entered during the current
CLI session.

show stats

Shows UDP statistics

write

Stores the current configuration in permanen t memory.

5: Commands and Levels

IntelliBox-I/O 2100 Command Reference 95
