LANPARTE LA3D-S User Manual

USER MANUAL

Contact us for further questions

www.lanparte.com

LA3D-S manual

HONGKONG LANPARTE TECHNOLOGY LIMITED

Email:[e-mail]
Tel:[phone]

Fax:[phone]

ADD:NO.39 2nd Xin an road

Changan Town Dongguan Guangdong China

DETACHABLE WIRED CONTROL GIMBAL

3-Axis Handheld Gimbal for Smartphone

LA3D-S

LA3D-S

1 Appearance and Design

Attention !

Be sure to install smartphone before turning on power

Pitch axis adjustment screw

1/4 -20 thread

hole inside

Counterweight

Smartphone clamp

(fits smartphones up to 3.1”wide)

1

Inverted Mode indicator

Micro USB port

for setting and

firmware upgrade

2pcs 18350

Li-ion batteries

Power button

2 Compatible With

Compatible with iPhone 4, 4s, 5, 5s, 6, 6s,
6 plus, 6s plus and similar size smartphone

3 Package Content

Serial No.

Product Name

QTY

3-Axis handheld gimbal platform

Gimbal handle

18350 Li-ion battery

Handle extender

Wired control cable(1.5m)

Micro USB cable (For battery charger)

Smartphone clamp

Battery charger

UP

LEFT

Power

indicator

Mode

RIGHT

DOWN

Speed

dial

Mode indicator

8

8

9

Counter weight

9

32
