Page 1
A RICOH COMPANY
LD316/LD320d
DIGITAL IMAGING SYSTEMS
Compact, convenient and always up to the task
Combines four essential office systems, making it easy and
cost-effective for small businesses and workgroups to get more done
your document management partner
Page 2
Elevate your office to a whole new level of productivity
If you want to get more done, you need a system that
can do more for you—the Lanier LD316/LD320d. Copy,
print, scan and fax all from one conveniently compact
and powerful system. Plus, you do not have
to spend extra time setting up, maintaining and
networking four separate devices.
Create high-quality hardcopies.And save money by
sharing and archiving electronic documents.You will
also benefit from having remote management and
security functions.
Set a New, More Productive Pace
The easiest way to boost productivity is to make common
tasks simpler and more convenient. You can do it all with
the Lanier LD316/LD320d. Packed with user-friendly and
time-saving features, the Lanier LD316/LD320d satisfies
all of your document production needs—keeping
everyone’s day moving.
• Speed up production by outputting 16 pages per minute with the Lanier
LD316 and 21 pages per minute with the Lanier LD320d.
• Expand your copying and scanning capabilities with a large, ledger-sized
ou will also save time and money by k
Y
platen.
• Take advantage of virtually hands-free production by adding an optional
30-sheet Automatic Document Feeder (ADF) to the Lanier LD316 or Lanier
LD320d. Or add an optional 50-sheet Automatic Reversing Document
eeder (ARDF) to the Lanier LD320d and process two-sided documents
F
• Run job after job without interruption thanks to a generous maximum
paper capacity up to 1,600 sheets
Save paper and filing space with the ability to copy and print two-sided
•
documents with stackless duplexing on the Lanier LD320d.
• Simplify distribution with DeskTopBinder
thousands of pages of stored documents—even across numerous
folders—and easily combine them into a single document.
.
eeping more jobs in-house
™
Lite. It lets you quickly view
.
.
Page 3
Boost Your Print Production
Consolidate your printers with rapid speeds and controls
that let you perform virtually any printing task. You will
also benefit from a generous paper supply of up to 1,600
sheets that most stand-alone printers can’t match.
• Eliminate network congestion and print PDFs quickly—without opening
an application—using PDF Direct Print.
• Create documents faster than ever. Lanier’s standard intuitive Refined Print
Command Stream (RPCS) icon-based print driver lets users apply job
settings—from simple to complex—and run jobs with a single mouse click.
• Print documents created with most common business applications thanks to
standard PCL5e/6 print drivers or optional genuine Adobe
®
PostScript®3™.
Simplify Document Management
While we do not live in a paperless society, you can get
a head start with the Lanier LD316/LD320d. Advanced
scanning offers you resolutions up to 600 dpi and the
ability to conveniently convert documents to TIFF or PDF
files without the need for additional desktop systems.
• Save time, postage and overnight delivery charges by scanning hardcopy
documents and sending them directly to recipients’ e-mail addresses.
• Simplify file sharing and document archiving by scanning documents to
network folders.
• Securely share confidential documents in the form of encrypted PDFs,
rather than as hardcopies that can be lost in the mail or misplaced.
Featuring a convenient, compact footprint, the
Lanier LD316/LD320d lets you consolidate four
systems into one.
Fax and Save Time and Money
The Lanier LD316/LD320d comes with a range of faxing
options that make it easier than ever to send documents
and receive faxes without leaving your desk.
ax hardcopies quickly with a Super G3 modem that fires off pages in
F
•
as little as three seconds per page.
• Save on long-distance and international phone charges and paper costs
with Internet Fax, allowing you to send scanned documents directly to
e-mail addresses or to Internet-enabled facsimile systems.
Page 4
Use in-bound fax routing to send fax
documents directly to a PC and reduce
paper costs.
LD316/LD320d
• Reduce work interruptions and save paper by using the LAN Fax
feature to send faxes directly from your PC.
• Save on long-distance and international phone charges by using IP
Fax to send documents to another IP fax machine.
• Reduce paper use by automatically forwarding inbound faxes directly
to e-mail addresses or network folders
you when a fax has arrived.
• Save time and prevent misdials by retrieving fax numbers and e-mail
addresses from your corporate address book using the LDAP server.
. An e-mail notification alerts
Seamless Network Integration
Boost productivity and work more efficiently. The Lanier
LD316/LD320d offers advanced networking capabilities
so people can spend less time walking back and forth to
the system—and more time getting their work done.
• Connect the way you want using the standard 10BaseT/100BaseTX
Ethernet or USB 2.0 interface.
• Work wirelessly with optional Wireless LAN and Bluetooth
Eliminate time-consuming manual meter reading and reporting with
•
Lanier @Remote Intelligent Management System.
• Empower administrators with Web SmartDeviceMonitor
Web Image Monitor
status, settings and more from their desktops.
™
. Both allow users to monitor system
™
™
and
interfaces.
Your Environmental Partner
Instantly send any document at no cost to any network destination
through the powerful Lanier Scan-to technology.
Lanier’s Refined Print Command Stream (RPCS) is an easy-to-use, iconbased print driver that enables you to apply and save special settings.
Protect Your Sensitive Data
Whether you work with paper or electronic documents—
whether you go wireless or direct connect—you can be
confident that all your data is secure.
Protect sensitive information and prevent unauthorized use by
•
controlling system access with several methods of User
Authentication.
• Confidently store frequently used e-mail addresses and fax numbers
right on the system. Advanced address book encryption ensures they
remain secure
• Protect printed documents by using Mask Type for Copying to embed
messages that appear if a document is copied.
.
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, without
compromising productivity
echnology
• Quick Start-Up (QSU)
• Power-saving Sleep Mode
• Duplex and Combine Copy Modes
• Toner Recycling
• Low Noise Levels
• Minimal Ozone Emissions
• Restriction of Hazardous Substances Compliant (RoHS)
T
, including:
Page 5
A RICOH COMPANY
A RICOH COMPANY
Fax: Send and receive paper and
electronic faxes, and forward inbound
faxes to e-mail or network folders.
Optional Internal One-bin Tray
(LD320d):
from print output or faxes with an
additional 100-sheet output tray.
Lights up when output is present.
1 x 250-sheet Paper Tray
(LD316), 2 x 250-sheet Paper
Trays (LD320d):
and accommodates paper weights
up to 24 lb.–ensure long print runs
between paper changes.
Optional Storage Cabinet: Keep
supplies handy in the spacious
storage cabinet.
Separate copy output
User-adjustable
LD316/LD320d
Lanier LD316/LD320d Digital Imaging Systems
Optional 30-sheet Automatic
Document Feeder or 50-sheet
Automatic Reversing
Document Feeder (LD320d):
Handle multi-page originals with
ease, up to 11” x 17” in size.
Ledger Size Platen: Easily copy
and scan documents up to
11” x 17” in size.
Easy-to-read Control Panel:
Simplify everyday, complex tasks
with operation controls that make
it easy for anyone to walk up and
confidently use the system.
100-sheet Bypass Tray: Quickly
and easily copy or print on
different paper stocks and sizes.
Optional 1 or 2 x 500-sheet
Paper Trays:
to 1,350 sheets on the LD316 or
1,600 sheets on the LD320d.
Maximize the time between refills
and hold up to five different sizes
or orientations of paper.
Boost paper capacity
Multiple configurations for maximum creativity.
LD316: Base model with optional
30-sheet ADF, standard 250-sheet
Paper Tray and standard 100-sheet
Bypass Tray.
LD316spf: Base model with standard
copy, print, scan and fax capabilities,
optional 30-sheet
1 x 250-sheet and optional 2 x 500-sheet
Paper Trays, plus optional Cabinet Stand.
ADF
standard
,
LD320d: Base model with optional
50-sheet ARDF, standard 2 x 250-sheet
standard 100-sheet Bypass
,
ays
r
T
aper
P
ray.
ay and optional One-bin
r
T
T
LD320dspf: Base model with
standard copy, print, scan and fax
capabilities
optional 50-sheet
,
ARDF
standard 2 x 250-sheet and optional
2 x 500-sheet Paper Trays, standard
plus optional Cabinet Stand.
,
ay
r
T
One-bin
,
Page 6
DIGITAL IMAGING SYSTEMS
A RICOH COMPANY
A RICOH COMPANY
LD316/LD320d
SPECIFICATIONS
NGINE/COPIER SPECIFICATIONS
E
onfiguration
C
canning ElementFlatbed with CCD Array Image Sensor
S
oner
T
ystem Memory
S
Document Feeder Optional 30-sheet ADF
opy Resolution
C
rayscale
G
xposure AdjustmentManual & Automatic
E
Quantity Indicator 1-99
Original Type Sheet/Book
Original Size Up to 11" x 17"
opy Size
C
opy Type
C
arm-Up Time
W
First-Copy Speed 6.5 Seconds
Continuous Copy 16 copies/minute (LD316)
Speed 21 copies/minute (LD320d)
ecovery Time
R
from Auto Off)
(
ower Source
P
Dimensions (WxDxH) 21.6" x 22.4" x 16.5" (LD316)
Weight 7
tandard Paper
S
Capacity 250 Sheets x 2 Trays (LD320d)
ptional Paper
O
Capacity 500 Sheets x 2 Trays
Paper Size 5.5" x 8.5" to 11" x 17"
Paper Weight 16 to 24 lb. Bond (Paper Trays)
Output Tray Capacity 250 Sheets
Reduction Ratios 50%; 65%; 78%; 93%
Enlargement Ratios 121%; 129%; 155%
Zoom 50% to 200% in 1% increments
COPIER FEA
Auto Paper Selection, Auto Reduce/Enlarge, Auto Start, Auto Tray
Switching*, Combine Copy (2 in 1, 4 in 1), Electronic Sort, Image
Rotation, Photo Mode, Rotate Sorting*, Series Copy
(50), User Tools
es optional Paper Bank on the LD316.
*Requir
Lanier, a world of difference
The Lanier philosophy is embodied in Customer Vision®: a commitment we make every day. It means
seeing the business through your eyes, responding to your needs, and exceeding your expectations.
.lanier.com
www
orldwide, Inc.
Lanier W
©2007 Lanier Worldwide, Inc. All rights reserved. Windows®and Windows®95/98/Me/NT4.0/2000/XP are registered trademarks of Microsoft Corporation. Macintosh®, Mac®OS and AppleTalk®are registered trademarks of Apple Computer, Inc. Adobe®and PostScript®are registered trademarks of Adobe Systems, Inc. PCL®is a registered trademark of Hewlett-Packard Company. RPCS™ is a trademark of Ricoh Company Ltd.
All other trademarks are the property of their respective owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice.
Products are shown with optional features. Printed in U.S.A. on recycled paper.
onsole
C
ry Process (dual component)
D
6 MB (std./max.)
1
(LD316/LD320d)
ptional 50-sheet ARDF (LD320d)
O
00 x 600 dpi
6
56 Levels
2
.5" x 8.5" to 11" x 17"
5
lain Paper, Envelopes, Postcards
P
6 Seconds
2
ess than 10 seconds
L
20 V/60 Hz
1
23.1" x 22.4" x 22" (LD320d)
8 lbs. (LD316)
103 lbs. (LD320d)
50 Sheets x 1 Tray (LD316)
2
00-sheet Bypass Tray
1
00 Sheets x 1 Tray or
5
14 to 43 lb. Bond/90 lb. Index
(Bypass Tray)
20 to 24 lb. Bond (Duplex Unit)
100-sheet One-bin Tray (Optional
for LD320d)
TURES
2300 Parklake Drive NE, Atlanta, GA 30345
, User Codes
PRINTER SPECIFICATIONS (optional)
rint Speed
P
CPU RM5231 400 MHz
Memory Capacity 384 MB standard
Standard Interfaces Ethernet 10BaseT/100BaseTX,
Optional Interfaces IEEE 802.11b Wireless LAN,
etwork ProtocolTCP/IP; IPX/SPX; AppleTalk; SMB
N
etwork OperatingWindows
N
tilities
U
Page Description Standard RPCS™, PCL5e/6
Languages Optional Adobe®PostScript®3
Print Resolution 600 x 600 dpi
onts for PCL5e/635 Intellifonts, 10 TrueType Fonts,
F
onts for PS3
F
6 ppm (LD316)
1
1 ppm (LD320d)
2
USB 2.0
™
, IEEE 1284 Parallel
Bluetooth
®
x/NT4.0/2000/Me/XP/ Server 2003
9
®
Macintosh
Mac®OS X Classic,
Mac
Novell
5
S
H
SCO OpenServer 5.0.6 /5.0.7,
RedHat Linux 6.x/7.x/8.x/9.x/
Enterprise and IBM AIX V4.3 & 5L
V
m
S
Monitor
DeskTopBinder
1
1
OS 8.6 or later,
®
OS X Native: v.10.1 or later
®
NetWare 3.12, 3.2, 4.1, 4.11,
.0, 5,1, 6, 6.5, UNIX filters for Sun
olaris 2.6/7/8/9/10
P-UX 10.x/11.x/11iv2,
ersion 5.1/5.2 /5.3, SAP R/3 3.x or later,
ySAP ERP2004 or later
martDeviceMonitor
™
, Web SmartDeviceMonitor™,
™
Lite
™
Web Image
,
™
Bitmap, 13 International Fonts
36 Roman Fonts
PRINTER FEATURES
Automatic Tr
LD320d), Envelope Printing, Watermarks
(
*Requir
ay Select, Auto Tray Switching*, Duplex Printing
es optional Paper Bank on the LD316.
SCANNER SPECIFICATIONS (optional)
Scanning Speed Scan-to-Email/Folder/Network:
Scanning Resolution 600 dpi
Grayscale 256 Levels
Scan Area Up to 11" x 17"
d Interfaces
Standar
Optional Interfaces IEEE 802.11b Wir
Protocol TCP/IP
File Formats TIFF; PDF
43 ipm @ 200 dpi, Letter Size
net 10BaseT/100BaseTX
Ether
eless LAN
SCANNER FEATURES
Black & White Scanning, Duplex Scanning (LD320d), Embedded
Scan-to-Email, Image Rotation, Network TWAIN Scanning,
Scan-to-Folder (SMB/NCP/FTP), ScanRouter Lite
SECURITY FEA
User Authentication*, SNMP v3, Mask Type for Copying, Encrypt
Address Book*
*Requires Print/Scan Kit or All-in-One Kit.
TURES
FAX SPECIFICATIONS (optional)
ircuit
C
ompatibility
C
Resolution 200 x 100/200/400 dpi
Compression Method MH, MR, MMR, JBIG
Scanning Speed 30 ppm (Standard/Detail Modes)
Modem Speed 33.6Kbps – 2,400 bps w/Auto Fallback
Transmission Speed G3: 3 seconds/page (w/MMR)*,**
emory
M
Memory Backup 1 hour
Quick Dials 32
Speed Dials 150
Group Dials 10 (max.100 per group)
D Code Programming4Digits
I
ser Function Key3keys
U
**Based on ITU-Test Chart #1 in standard mode.
**Approximate speed is per page at 33.6Kbps and dependent on optimal line
. Customer performance may vary by location.
quality
AX FEATURES
F
A1 Short Protocol, Authorized Reception, Auto Reduction,
Batch Transmission, Battery Backup, Dual Access, Duplex Fax
Transmission (LD320d), Error Correction Mode, Inbound Fax
outing*, IP Fax*, Internet Fax (T.37)*, LAN Fax*, Manual Reception,
R
age Retransmission, Parallel Memory Transmission, Reception
P
ime Printing, Restricted Access, Send Later, Serial Broadcasting,
T
Substitute Reception
*Requires optional All-in-One Kit
STN, PBX
P
TU-T G3
I
16 ppm (Fine Mode)
3: 2 seconds/page (w/JBIG)*,**
G
MB (320 Sheets*)
4
ACCESSORIES
F2000 Automatic Document Feeder
D
Original Size 5.5" x 8.5" to 11" x 17"
Original Weight 14 to 28 lb. Bond
Original Capacity 30 Sheets
Dimensions (WxDxH) 21.6" x 18.5" x 3.55"
eight
W
DF2010 Automatic Reversing Document Feeder
Original Size 5.5" x 8.5" to 11" x 17"
Original Weight Simplex Original: 10 to 34 lb. Bond;
Original Capacity 50 Sheets
Dimensions (WxDxH) 21.6" x 18.5" x 5.1"
Weight 22.05 lbs.
PS450 Paper Bank*
Paper Capacity
Paper Size 5.5" x 8.5" to 11" x 17"
Paper Weight 16 to 28 lb. Bond
Dimensions (WxDxH) 21.6" x 20.5" x 10.6"
Weight 55.1 lbs.
*Configuration with Small Cabinet recommended.
PS460 Paper Bank*
Paper Capacity 500 Sheets x 1 Tray
Paper Size 5.5" x 8.5" to 11" x 17"
Paper Weight 16 to 28 lb. Bond
Dimensions (WxDxH) 21.6" x 20.5" x 5.3"
eight
W
*Configuration with Medium Cabinet recommended.
Type PT340 One-Bin Tray (LD320d only)
Paper Size
Paper Weight 16 to 28 lb. Bond
Paper Capacity 100 Sheets
Dimensions (WxDxH) 8.5" x 18.9" x 4.1"
ray
T
eight
W
5.4 lbs.
1
(LD320d only)
Duplex Original: 17 to 28 lb. Bond
500 Sheets x 2 T
rays
26.05 lbs.
5.5" x 8.5" to 11" x 17"
13.2" x 15.4" x 1.7"
3.5 lbs.
L2331
Loading...
