Lanier IS760D User Manual

Quick Installation Guide

ADC058S

Please read the Safety Information in the Operating Instructions before using this machine. It contains important information related to USER SAFETY and PREVENTING MACHINE PROBLEMS.

Image Scanner

Confirming the Installation

Environment

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

The scanner location should be carefully chosen because environmental conditions greatly affect its performance.

WARNING

• Make sure the wall outlet is near the machine

and easily accessible so that in event of an emergency it can be unplugged easily.

CAUTION

• Keep the machine away from humidity and

dust. A fire or an electric shock might occur.

• Do not place the machine on an unstable

or tilted surface. If it topples over, it could cause injury.

Optimum Environment Conditions

Recommended temperature and humidity

ADC122S

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Power Connection

Connect the power cord to a power source with the following specifications:

Product Specifications

North America

Europe

Electrical Outlet Requirements

North America

Europe

G417-17/G418-17

power supply rating:

AC 120V, 60Hz, 2A

G418-27

power supply rating:

AC 220-240V, 50/60Hz, 1A

G417-17/G418-17

Electrical Outlet Requirements:

AC 120V, 60Hz, min.10A

G418-27

Electrical Outlet Requirements:

AC 220-240V, 50/60Hz, min.5A

Space Required for Installing the Scanner

Make sure that the scanner is in a location where there is enough space to provide a clearance as illustrated below, and also provide a comfortable working area in the front.

. 100mm (4inch) or more

ADC115S

Checking the Contents of the Box

○○○○○○○○○○○○○○○○○○○

Check the contents of the box according to the following list. If one or some items are missing, please contact your sales or service representative.

Quick Installation Guide (this sheet)

CD-ROM

Power Cord

Tool

Cleaning Cloth

Safety Instruction Sheet

Two Caps

Remove the plastic bag. Lift the scanner and move it to the place where you want to install it.

○○○○○○○○○○○○○○○○○○○○○○

Disengaging the Lock

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Remove two lock screws fixed on the back of this machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Installing the Scanner

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Remove the tape.

CAUTION

• This scanner weighs approximately 33 kg.

• Make sure to lift it carefully with two persons

or more so as to minimize physical strain. Careless lifting, reckless handling or allowing it to drop down can cause injury.

• When transporting over long distances,

please consult an authorized dealer.

Take out the scanner main unit.

ADC057S

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Turn the caps 90 degrees.

Lift the Pressure Panel, and carefully pull out the Background Panel that is fixed with the Velcro.

Important

❒ Save the box and cushioning material in

which the scanner was packed so that they can be used if it is necessary to transport the scanner in the future.

Open the automatic document feeder (ADF) and remove the protective sheet on the contact glass.

Return the removed Background Panel to where it was.

Reference

❒ Regarding how to set the Background Panel,

please refer to a note on the back of the Pressure Panel.

Set the lock lover to the “Unlock” position.

Installing the TWAIN/ISIS Driver

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Preparation

Log on to the computer as a member of the Administrators group, for installation to Windows 2000/XP, Windows Server 2003, or Windows NT

4.0.

This machine can be used both as a TWAIN scanner and an ISIS scanner. A TWAIN driver and its applications (DeskTopBinder Lite, etc) are to be installed for the TWAIN scanner, and an ISIS driver and its applications (QuickScan, etc), are to be installed for the ISIS scanner.

Important

❒ Before starting "Found New Hardware Wizard,"

it is necessary to install the TWAIN/ISIS driver. If the "Found New Hardware Wizard" started before the installation, click the [Cancel] button to discontinue the wizard and then install the TWAIN/ISIS driver.

Start Windows, and then insert the supplied CD-ROM labeled “Scanner Driver(s), Utilities and Operating Instructions ” into the CD-ROM drive of the client computer.

The CD-ROM Launcher screen appears.

When installation does not start automatically

A Auto Run might not automatically work with

certain operating system settings. In this case, launch “Setup.exe” located in the CDROM root directory.

Click [TWAIN DRIVER] or [ISIS DRIVER].

The installer of the TWAIN/ISIS driver starts. Follow the instructions on the screen.

Power off the computer after the installation is completed.

Important

❒ When the machine is moved from a cold

location to a warm location, sudden temperature changes cause condensation inside of the scanner. Wait one hour or more before turning on the scanner to allow the condensation to evaporate.

Environments to Avoid

Important

❒ Do not set up the scanner in any of the fol-

lowing types of locations. It may be the cause of the malfunction.

• In a location exposed to direct sunlight

• In a location where the scanner will be sub-

jected to blowing air or radiant heat, such as near an air conditioner or heater

• In a location near other electronic devices,

such as a radio or television set

• In a location subject to extreme tempera-

tures or humidity

• Near a humidifier

2004 10 G418-8600

. 800mm (31.5inch) or more

ADC116S

Note

ADC082S

❒ Use a coin to remove the screws.

The holes left by the removed screws are to be covered by the caps. Put the leg stopper of the caps into the holes vertically.

ADC084S

ADC071S

The removed screws are to be kept fixing on the back of the Pressure Panel.

ADC086S

ADC025S

Note

❒ Don't power on the computer before the step

procedure, “8. Detecting the Scanner”.

About TWAIN driver help

After you have installed the TWAIN driver, [(Model Name) TWAIN V4] will be created under [Programs] of the [Start] menu. Help files for the TWAIN driver can be displayed from here.

Notes on using the TWAIN scanner are provided in “Readme.txt.” Be sure to read them before use.

Connecting to the Computer

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

This scanner can be connected to the computer with a SCSI and/or USB interface.

You can connect the scanner to two computers at the same time. One with the SCSI interface, and one with the USB 2.0 interface. Though, you cannot use the scanner at the same time from two computers. Interfaces are switched automatically when you change from one of the computer to the other.

Important

❒ The SCSI interface of this unit is of the 50-

pin half-pitch (pin-type) type. Connect a shielded SCSI-2 compliant with ANSI standards or a SCSI-3 (Ultra-SCSI) cable.

❒ It is possible that malfunction occurs or data

is lost when more than one SCSI ID's exists simultaneously. Adjust the settings such that the SCSI ID of this unit does not coincide with the ID of another SCSI device.

❒ Keep the total length of the SCSI cable in-

cluding the cable inside the PC to a maximum of 1.5m (4.9 feet) when using the SCSI-3 (Ultra-SCSI) and 3m (9.8 feet) when using the SCSI-2.

❒ Some combinations of the SCSI board of

your computer and daisychained peripherals might cause an incorrect operation. Please contact and ask your service representative about the recommended SCSI board.

❒ If you connect this unit to other SCSI devices

through a daisy chain, it may not work properly. In this case, connect only this unit to the computer.

Connecting the SCSI Interface (When the Scanner is at the End of the Daisy Chain)

Shut down the computer and all of the SCSI connected devices.

Daisy chain the computer, scanner and SCSI connected devices.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

When you do not use the USB connection

Changing the DIP Switch settings enables highspeed data transfer. This is available with SCSI connection, the USB and the optional IEEE1394 connection cannot be used with this setting.

A Set the DIP Switch NO.2 to the OFF position.

SCSI synchronous transmission is enabled.

Set the SCSI ID by rotating the Rotary Switch.

ADC017S

Connecting the SCSI Interface (When the Scanner is not at the End of the Daisy Chain)

Shut down the computer and all of the SCSI connected devices.

Daisy chain the computer, scanner and SCSI connected devices.

Connecting the Power Code

When you do not use the USB connection

Changing the DIP Switch settings enables highspeed data transfer. This is available with SCSI connection, the USB and the optional IEEE1394 connection cannot be used with this setting.

A Set the DIP Switch NO.2 to the OFF position.

SCSI synchronous transmission is enabled.

Set the SCSI ID by rotating the Rotary Switch.

ADC017S

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

This section explains how to connect this machine to a power source, using a bundled AC power cord.

WARNING

• Do not use with a power source with a voltage

different from the specified voltage. Do not use a power outlet with multiple devices plugged in. These could create the risk of fire or electric shock.

• Avoid the use of an extension cord.

• Do not damage, break, twist or modify the

Power Cord. Placing heavy objects on the cord, pulling on or bending it excessively can damage the Power Cord, creating the risk of fire or electric shock.

• Never touch or unplug the power plug with wet

hands. This can create the risk of electric shock.

CAUTION

Connecting the USB Interface

Note

❒ Please use the recommended USB cable. Using

other cables might occur an irregular operation. As for the recommended cables, please ask your service representative.

Open the cover of the switch box on the lower left of the frontside of the scanner.

Note

❒ Push the knob of the cover to the left and pull

the cover to open.

Confirm the DIP Switch NO.2 is in the ON position.

• When unplugging from an outlet, be sure to

grasp the plug when pulling. Never pull on the cord. This could damage the cord creating the risk of fire or electrical shock.

Confirm that the power switch is set to off.

ADC124S

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Confirm the lock screws on the back of this machine are removed and the holes left by the removed screws are covered with the cap, and confirm that the lock lever is set to the "Unlock" position.

ADC089S

Important

❒ Turning the power on leaving the lock lever

to the "Lock" position and/or turning the power on without removing the screws could result not only in failure in scanning but in malfunction of this machine.

Push the power cord plug all the way into the power connector on this machine.

Note

❒ Be sure to use the power cord that comes with

this machine.

ADC026S

Detecting the Scanner

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Power on the scanner.

ADC125S

Start the computer.

The installation completes here for the computer with the operation systems, Windows 95 and Windows NT4.0. For the computer with other operation systems, “Plug & Play” detects the scanner and the “Found New Hardware Wizard” automatically starts.

In the Wizard, select [Sear ch for a suitable driver for my device [recommended]], and continue the “Found Ne w Hardware Wizard” to the end, according to the instruction on the displa y.

Note

❒ When an instruction to set the Windows system

CD-ROM appears on the display in the course of the installation, follow the instruction accordingly.

❒ Even when “No approval of the logo test” ap-

pears on the display, you can continue the installation by clicking [continue].

Note

ADC018S

❒ Connect the SCSI cable to either one side of the

connectors.

Open the cover of the switch box on the lower left of the front side of the scanner.

Note

❒ Push the knob of the cover to the left and pull

the cover to open.

Confirm the DIP Switch NO.3 is in the OFF position.

ADC019S

ADC020S

Open the cover of the switch box on the lower left of the front side of the scanner.

Note

❒ Push the knob of the cover to the left and pull

the cover to open.

Set the DIP Switch NO.3 to the ON position.

ADC021S

Built-in SCSI terminator is disabled.

Note

ADC080S

❒ If the DIP Switch NO.2 is set to OFF, set it to

ON. The scanner will not be detected if the switch is set to OFF.

Connect the USB cable to the USB connector.

ADC022S

Connect the other side of the cable to the USB connector on your computer.

Insert the power plug into the power outlet.

Appendix: Turning the Power On/Off

○○○○○○○○○

Turning the Power On when Connected with SCSI Interface

Turn the power on from the farthest devices from the computer on the daisy chain. Start the computer last.

Note

❒ The scanner will not be detected if you start the

computer first.

○○○○○○○○○○○○○○

Turning the Power On when Connected with USB Interface

There is no order to turn on the power when you connect the scanner with USB Interface. You can turn on either the scanner or the computer first.

○○○○○○○○○

GB GB EN USA

Turning the Power Off

There is no order to turn off the power. You can turn off either the scanner or the computer first.

Quick Installation Guide

Image Scanner

Operating Instructions

Guide to Components

Setting up the Scanner

Installing Software

Setting Originals

Using the TWAIN Driver

Appendix

Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the Safety

Information in this manual before using the machine.

Introduction

This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference.

Two kinds of size notation are employed in this manual. With this machine refer to the inch version.

Important

Contents of this manual are subject to change without prior notice. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages as a result of handling or operating the machine.

Caution

Certain options might not be available in some countries. For details, please contact your local dealer. Some illustrations in this manual might be slightly different from the machine.

The supplier shall not be responsible for any damage or expense that might result from the use of parts other than genuine parts from the supplier with your office products.

Do not copy or print any item for which reproduction is prohibited by law. Copying or printing the following items is generally prohibited by local law: bank notes, revenue stamps, bonds, stock certificates, bank drafts, checks, passports, driver's licens-

es. The preceding list is meant as a guide only and is not inclusive. We assume no responsibility for its

completeness or accuracy. If you have any questions concerning the legality of copying or printing certain items, consult with your legal advisor.

Power Source

Color Scanner: 120V, 60Hz, 10A or more Please be sure to connect the power cord to a power source as above.

Trademarks

Adobe, PostScript, and Acrobat are trademarks of Adobe Systems Incorporated. QuickScan™ is a trademark of Pixel Translations and Captiva Software Corporation.

PixTools

and ISIS® are registered trademarks of Pixel Translations and Captiva Software Corporation. Pentium is a registered trademark of Intel Corporation. MS, Microsoft, and Windows are registered trademarks of Microsoft Corporation. Other product names used herein are for identification purposes only and might be trademarks of their

respective companies. We disclaim any and all rights to those marks.

The proper names of the Windows operating systems are as follows:

• The product name of Windows

• The product names of Windows

Microsoft Microsoft Microsoft

• The product names of Windows

Microsoft Microsoft

Windows® 2000 Professional

Windows® 2000 Server

Windows® 2000 Advanced Server

Windows® XP Home Edition

Windows® XP Professional

95 is Microsoft® Windows® 95

98 is Microsoft® Windows® 98

Me is Microsoft® Windows® Millennium Edition (Windows Me)

2000 are as follows:

XP are as follows:

• The product names of Windows Server™ 2003 are as follows:

Microsoft® Windows Server™ 2003 Standard Edition Microsoft Microsoft

• The product names of Windows

Microsoft Microsoft

Windows Server™ 2003 Enterprise Edition

Windows Server™ 2003 Web Edition

Windows NT® Workstation 4.0

Windows NT® Server 4.0

NT 4.0 are as follows:

TABLE OF CONTENTS

Safety Information ................................................................................................. 1

Safety During Operation............................................................................................. 1

Energy Star Program ............................................................................................. 4

Manuals for This Scanner .....................................................................................5

How to Read This Manual .....................................................................................6

1. Guide to Components

Guide to This Scanner...........................................................................................7

Understanding Indicators ...........................................................................................9

DIP Switches ............................................................................................................10

2. Setting up the Scanner

Confirmations Before the Setup.........................................................................11

Location, Space and Environment ...........................................................................11

Disengaging the lock for transportation....................................................................13

Installing Options.................................................................................................16

Installing the Image-Processing Unit........................................................................ 16

Installing the IEEE1394 Interface Board ..................................................................18

Connecting to the Computer ..............................................................................21

Connecting with SCSI Interface ...............................................................................21

About the SCSI Interface .......................................................................................21

Setting the SCSI ID ............................................................................................... 22

Setting the SCSI ID Automatically .........................................................................23

Connecting the SCSI Cable (When the Scanner is at the End of the Daisy Chain) Connecting the SCSI Cable (When the Scanner is not at the End of the Daisy Chain)

Using the Scanner only with the SCSI Connection ...............................................27

Connecting with USB Interface ................................................................................28

Connecting with IEEE1394 Interface .......................................................................29

Connecting to a Power Source...........................................................................31

Turning the Power On/Off ...................................................................................33

Turning the Power On when Connected with SCSI Interface ..................................33

Turning the Power On when Connected with USB/IEEE1394 Interface .................. 33

Turning the Power Off .............................................................................................. 33

Using the Hard Reset Switch..............................................................................34

...24 ...26

3. Installing Software

Installing TWAIN Driver .......................................................................................35

System Requirements.............................................................................................. 35

Installing TWAIN Driver............................................................................................36

Installing DeskTopBinder Lite ............................................................................38

System Requirements.............................................................................................. 38

Installing DeskTopBinder Lite .................................................................................. 39

Installing ISIS Driver ............................................................................................40

System Requirements.............................................................................................. 40

Installing ISIS Driver................................................................................................. 41

Installing QuickScan............................................................................................43

System Requirements.............................................................................................. 43

Installing QuickScan................................................................................................. 43

4. Setting Originals

Sizes and Weights of Recommended Originals................................................45

Original Sizes Available for Auto Detection.............................................................. 46

Originals that Require Special Care .........................................................................47

Placing Originals..................................................................................................48

Placing the Original on the Exposure Glass.............................................................48

Placing the Originals in the ADF ..............................................................................49

Changing the Color of the Background Panel ..................................................52

Changing the Color of the Background Panel for the ADF ......................................52

Changing the Color of the Background Panel for the Exposure Glass .................... 54

5. Using the TWAIN Driver

Procedure Breakdown.........................................................................................57

Scanning Originals ..............................................................................................58

What You Can Do with the TWAIN Driver ..........................................................60

Functions of the TWAIN Driver ................................................................................ 60

6. Appendix

Troubleshooting...................................................................................................63

Error Indicators......................................................................................................... 63

When the Original is Jammed or Double Fed in the ADF ........................................64

When the Originals are Not Fed Correctly ...............................................................66

When Scanning is Not Performed as Expected ....................................................... 66

When an Error Message Appears ............................................................................67

When in Installation and Other Problems................................................................. 70

Cleaning................................................................................................................71

Cleaning the Original Table Cove ............................................................................72

Cleaning Under the Pressure Panel......................................................................... 73

Cleaning Under the Background Panel....................................................................74

Cleaning Inside the ADF Cover................................................................................76

Cleaning the Ventilation Panel ................................................................................. 77

Moving and Transporting the Scanner ..............................................................78

Moving Over Short Distances .................................................................................. 78

Transporting the Scanner......................................................................................... 79

Disposing of the Scanner....................................................................................81

How Data Size Changes Depending on Scan Area and Resolution................82

When

[

Binary(Text)

When [Gray Scale] or [256 Colors] is Selected............................................................ 83

When [8 Colors] or [8 Colors(Photo)] is Selected ........................................................83

When [16770K colors] is Selected.............................................................................. 84

], [

Binary(Photo)

], [

Binary(Auto Image)

Options ................................................................................................................. 85

Image Processing Unit Type B................................................................................. 85

IEEE1394 Interface Unit Type IS760 .......................................................................85

Specifications.......................................................................................................86

, or

]

[

Binary(Text/Photo)

is Selected

]

...82

INDEX......................................................................................................... 88

Safety Information

When using this machine, the following safety precautions should always be followed.

Safety During Operation

In this manual, the following important symbols are used:

WARNING:

CAUTION:

Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury.

Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.

R WARNING:

• Connect the Power Cord directly into a wall outlet and never use an extension cord.

• Disconnect the power plug (by pulling the plug, not the cable) if the power cable or plug becomes frayed or otherwise damaged.

• To avoid hazardous electric shock or laser radiation exposure, do not remove any covers or screws other than those specified in this manual.

• Turn off the power and disconnect the power plug (by pulling the plug, not the cable) if any of the following conditions exists:

• You spill something into the equipment.

• You suspect that your equipment needs service or repair.

• Your equipment's cover has been damaged.

• Disposal can take place at our authorized dealer or at appropriate collection sites.

• Keep the machine away from flammable liquids, gases, and aerosols. A fire or an electric shock might occur.

• Make sure the wall outlet is near the machine and easily accessible so that in event of an emergency it can be unplugged easily.

• Do not use with a power source with a voltage different from the specified voltage. Do not use a power outlet with multiple devices plugged in. These could create the risk of fire or electric shock.

• Avoid the use of an extension cord.

• Do not damage, break, twist or modify the Power Cord. Placing heavy objects on the cord, pulling on or bending it excessively can damage the Power Cord, creating the risk of fire or electric shock.

• Never touch or unplug the power plug with wet hands. This can create the risk of electric shock.

• Never remove any covers or screws other than those specified in this manual. The inside of the scanner contains high-voltage components that can cause electrical shock. Have all inspections, adjustments, and repairs inside the scanner performed by an authorized dealer only.

• Do not attempt to modify this scanner in any way. Modification can cause fire or electrical shock.

R CAUTION:

• Protect the equipment from dampness or wet weather, such as rain, snow, and so on.

• Unplug the Power Cord from the wall outlet before you move the equipment.

While moving the equipment, you should take care that the Power Cord will not be damaged under the equipment.

• When you disconnect the power plug from the wall outlet, always pull the plug (not the cable).

• Do not allow paper clips, staples, or other small metallic objects to fall inside the equipment.

• For environmental reasons, do not dispose of the equipment or expended supply waste at

household waste collection points. Disposal can take place at an authorized dealer or at appropriate collection sites.

• The inside of the machine could be very hot. Do not touch the parts with a label indicating the "hot surface". Otherwise it could cause a personal burn.

• Our products are engineered to meet high standards of quality and functionality, and we recommend that you only use the expendable supplies available at an authorized dealer.

• Keep the machine away from humidity and dust. A fire or an electric shock might occur.

• Do not place the machine on an unstable or tilted surface. If it topples over, it could cause

injury.

• When unplugging from an outlet, be sure to grasp the plug when pulling. Never pull on the cord. This could damage the cord creating the risk of fire or electrical shock.

• When disconnecting the power cord, always make sure to hold onto the plug. Do not pull on the power cord itself. This can cause damage to the cord, fire or electrical shock.

• Be careful not to pinch your fingers when closing the Automatic Document Feeder (ADF).

• This scanner weighs approximately 72.8 lbs.

• Make sure to lift it carefully with two persons or more so as to minimize physical strain.

Careless lifting, reckless handling or allowing it to drop down can cause injury.

• When transporting over long distances, please consult an authorized dealer.

Energy Star Program

As an ENERGY STAR Partner, we have determined that this machine model meets the ENERGY STAR Guidelines for energy efficiency.

The ENERGY STAR Guidelines intend to establish an international energy-saving system for developing and introducing energy-efficient office equipment to deal with environmental issues, such as global warming.

When a product meets the ENERGY STAR Guidelines for energy efficiency, the Partner shall place the ENERGY STAR logo onto the machine model.

This product was designed to reduce the environmental impact associated with office equipment by means of energy-saving features, such as Low-power mode.

❖❖❖❖ Low-Power mode

This unit automatically lowers its power consumption at a predetermined time (approximately 15 minutes) after the last operation was performed. To operate the unit from this mode, see the instructions below.

• Method for clearing

• Put a document on the Original Table.

• Open the cover of the Automatic Document Feeder (ADF).

• Lift the Pressure Panel.

• Follow the instructions from the PC.

Note

❒ The Low-Power mode does not work in the following conditions.

• When an error occurs.

• When a document is placed on the Original Table.

❖❖❖❖ Specifications

Low-Power mode Power consumption Approx. 8W

Transitional interval 15 minutes

Manuals for This Scanner

The following manuals describe the operational and maintenance procedures of this machine.

To enhance safe and efficient operation of this scanner, all users should read and follow the instructions carefully.

❖❖❖❖ Quick Installation Guide

Describes how to install the scanner.

❖❖❖❖ Operating Instructions (this manual)

Provides all of the information how to install, set up, and use the scanner. This manual is provided as a PDF file.

Note

❒ There is a CD-ROM that comes with this scanner.

How to Read This Manual

Symbols

The following set of symbols is used in this manual.

WARNING:

This symbol indicates a potentially hazardous situation that might result in death or serious injury when you misuse the machine without following the instructions under this symbol. Be sure to read the instructions, all of which are described in the Safety Information section.

CAUTION:

This symbol indicates a potentially hazardous situation that might result in minor or moderate injury or property damage that does not involve personal injury when you misuse the machine without following the instructions under this symbol. Be sure to read the instructions, all of which are described in the Safety Information section.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed, originals might be damaged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates information or preparations required prior to operating.

Note

This symbol indicates precautions for operation, or actions to take after abnormal operation.

Limitation

This symbol indicates numerical limits, functions that cannot be used together, or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[]

Keys that appear on the machine's display panel.

[]

Keys and buttons that appear on the computer's display.

{}

Keys built into the machine's control panel.

{}

Keys on the computer's keyboard.

1. Guide to Components

Guide to This Scanner

1. ADF (Automatic Document Feed-

er)

Allows you to automatically load multiple originals into this machine.

2. Paper Thickness Changeover Le-

ver

When you scan the thick originals — originals thicker than 128g/m — with the ADF, set the paper thickness changeover lever to your side. After scanning, return the switch to the back side.

(242.5bls)

3. Original Table

Set originals here to be loaded into this machine using ADF.

4. Output Table

The originals that have been loaded by the ADF are output here after scanning.

5. Original Stopper

Stops the originals scanned by the ADF.

6. Rotary Switch

Use to set SCSI ID.

ADC002S

7. DIP Switches

Use to set the operation mode of this scanner. ⇒ p.10 “DIP Switches”

8. Hard Reset Switch

This switch resets the power to the scanner. Use this switch when validate the settings of the DIP Switches or the Rotary Switch.

9. Indicators

Indicates the status of this machine. ⇒ p.9 “Understanding Indicators”

10. {

{Clear Modes}}}} key

{{

Press this key to stop the manual scanning.

11. {

{Start}}}} key

{{

Press this key to start the manual scanning

12. Power Switch

Turns this machine's power on and off.

Guide to Components

ADC003S

1. Pressure Panel

Holds the originals down on the Exposure Glass.

2. Background Panel for Exposure

Glass

Panel to set the background color for the original in black or white when you place the original on the exposure glass. ⇒ p.54 “Changing the Color of the Background Panel for the Exposure Glass”

3. ADF Exposure Glass

Scans the originals when they are loaded by the ADF.

4. Exposure Glass

Set the original here when you do not use the ADF scanning.

5. ADF Cover

Open when clearing the misfed originals or cleaning the rollers.

6. Lock Screw

This is to lock the scanning parts inside when you transport this machine. Remove this screw when you set up this machine.

7. USB 2.0 Interface Connector

Used for connection of an USB cable. The USB interface board is alternatively used with the optional IEEE1394 interface board.

8. Lock Lever

Set this lever to the “Lock” position when you transport this machine.

9. SCSI Interface Connector

Used for connection of a SCSI Cable.

10. SD Card Slot

Used for an authorized customer engineer's maintenance only.

11. Power Connector

For connection of the bundled AC power code.

Guide to This Scanner

Understanding Indicators

This section explains how to interpret the indicators in front of this machine.

ADC126S

Indicators On Blink Off

Status of Power Power On Low-Power mode Power Off

Machine Busy Scanning operation

Documents in place

Error detection Error No error or the

Scan Wait SADF When SADF mode or

Sometimes it looks like blinking.

in progress

Originals are set to the ADF

during standby for the manual scan

No originals are set to the ADF

current status

All indicators on: For a short while after you turned on the power, or pressed the Hard Reset key.

All indicators blinking: System error. Contact your service representative.

Description of the Error indicator on: See p.63 “Error Indicators”

Guide to Components

DIP Switches

Change only the switches No. 1 to 3. Do not change the other switches.

ADC005S

SW No. Function OFF ON

SCAM

disable enable

2 SCSI synchronous transmission enable

3 SCSI termination enable disable

(system usage)

SCAM: SCSI Configured Automatically. Protocol to set SCSI ID automatically.

always

Do not make changes.

OFF

disable

Important

❒ SCSI ID will not be configured even if you set SCAM to enable, when more

than one of this scanner with the SCAM function enabled are connected to the daisy chain. In this case, disable the SCAM by setting the DIP Switch No.1 ON, and set the SCSI ID with the Rotary Switch.

❒ The USB and the optional IEEE1394 connection cannot be used when the SCSI

synchronous transmission is set. You can turn the DIP Switch No.2 OFF (SCSI synchronous transmission enabled) when using the scanner only with the SCSI connection.

❒ A malfunction with SCSI synchronous transmission may occur if you use a

SCSI cable longer than recommended, or a cable out of the standard. In that case, turn the DIP Switch No.2 ON (SCSI synchronous transmission disabled).

❒ When the scanner is connected to the middle of the daisy chain, set the DIP

Switch No.3 ON.

2. Setting up the Scanner

This section explains how to setup the scanner to get it ready for use, and how to make necessary connections.

Confirmations Before the Setup

Location, Space and Environment

❖❖❖❖ Location

WARNING:

• Make sure the wall outlet is near the machine and easily accessible so that in event of an emergency it can be unplugged easily.

CAUTION:

• Keep the machine away from humidity and dust. A fire or an electric shock might occur.

• Do not place the machine on an unstable or tilted surface. If it topples over, it could cause

injury.

Place the scanner on a level, stable, vibrating-free surface.

• Allowable inclination of the surface for installation is within 0.2inch (when measuring difference of heights between one end and the other of this machine, compared to a level surface).

❖❖❖❖ Space

Make sure that the scanner is in a location where there is enough space to provide the clearance as illustrated below, and also provide a comfortable working area in the front.

ADC120S

4 inch (100 mm) or more

31.5 inch (800 mm) or more

Setting up the Scanner

❖❖❖❖ Environment

Important

❒ Do not set up the scanner in any of the following types of locations. It may

be the cause of the malfunction.

• In a location exposed to direct sunlight

• In a location where the scanner will be subjected to blowing air or radi-

ant heat, such as near an air conditioner or heater

• In a location near other electronic devices, such as a radio or television

set

• In a location subject to extreme temperatures or humidity

• Near a humidifier

Set up the scanner in a location where the temperature and humidity will fall within the ranges shown below.

ADC123S

Important

❒ Save the box and cushioning material in which the scanner was packed so

that they can be used if it is necessary to transport the scanner in the future.

❒ When the machine is moved from a cold location to a warm location, sud-

den temperature changes cause condensation inside of the scanner. Wait one hour or more before turning on the scanner to allow the condensation to evaporate.

Confirmations Before the Setup

Disengaging the lock for transportation

In this section, we explain how to disengage the lock after you take the scanner out of the package for transportation.

Remove two lock screws fixed on the back of this machine.

AAAA

ADC082S

Note

❒ Use a coin to remove the lock screws.

❒ Be sure to remove the lock screws. Turning the power on without remov-

ing the screws could result not only in failure in scanning, but in malfunction of this machine.

Cover both holes left by the removed screws with the caps.

BBBB

A Put the leg stopper of the caps into the holes vertically.

ADC084S

B Turn the caps 90 degrees.

Setting up the Scanner

he removed lock screws are to be kept on the back of the Pressure Panel

CCCC

as follows: A Lift the Pressure Panel and carefully pull out the Background Panel that

is fixed with the Velcro.

ADC071S

B The removed screws are to be kept fixing on the back of the Pressure

Panel.

ADC086S

C Return the removed Background Panel to where it was.

Reference

Regarding how to set the Background Panel, please refer to the step B -

of p.54 “Changing the Color of the Background Panel for the Expo-

sure Glass”.

Turn the lock lever on the back of this machine to the “Unlock” position.

DDDD

ADC025S

Confirmations Before the Setup

Note

❒ Be sure to set the lock lever to the “Unlock” position. Turning the power

on leaving the lock lever to the “Lock” position could result not only in failure in scanning but in malfunction of the machine.

Setting up the Scanner

Installing Options

Installing the Image-Processing Unit

Important

❒ Touch any metallic material before touching the image-processing unit to re-

move static from your body.

Note

❒ Use the accessory tool to remove or fix the screws.

Turn OFF the power to this product and disconnect all cables connected to

AAAA

the product, including the power cable.

Remove the three screws on the lower back surface of the product.

BBBB

ADC009S

Pull out the scanner control unit by pulling the black ribbon on the center

CCCC

of the board.

ADC010S

Important

❒ The control unit is heavy. Please take care not to drop it when pulling it

out.

Remove the seven screws on the cover of the scanner control unit.

DDDD

ADC064S

Open the cover of the scanner control unit.

EEEE

Installing Options

ADC011S

Connect the connector at the bottom surface of the image-processing unit to

FFFF

the connector of the scanner control unit, and fix with one accessory screw.

ADC012S

Check that it is connected tightly, check that there are no foreign objects

GGGG

such as metal on the scanner control unit.

Close the scanner control unit cover and fix with seven screws, then insert

HHHH

the scanner control unit into the main unit.

Note

❒ Be sure to place the scanner on the level surface when inserting the scanner

control unit.

❒ Insert the scanner control unit till you see the screw holes.

Setting up the Scanner

Fix the scanner control unit with three screws.

IIII

Removed cables must connect in former state.

JJJJ

Installing the IEEE1394 Interface Board

Important

❒ Touch any metallic material before touching the IEEE interface board to re-

move static from your body.

Note

❒ The optional IEEE 1394 interface board is alternatively used with the USB in-

terface board.

Turn OFF the power to this product and disconnect all cables connected to

AAAA

the product, including the power cable.

Remove the three screws on the lower back surface of the product.

BBBB

ADC009S

Pull out the scanner control unit by pulling the black ribbon on the center

CCCC

of the board.

ADC010S

Important

❒ The control unit is heavy. Please take care not to drop it when pulling it

out.

Remove the seven screws on the cover of the scanner control unit.

DDDD

ADC064S

Open the cover of the scanner control unit.

EEEE

Installing Options

ADC011S

Remove the USB 2.0 interface board fixed with 6 screws.

FFFF

ADC077S

Setting up the Scanner

Connect the IEEE1394 interface board to the extension connector. Fix the

GGGG

board with four accessory screws from inside, two accessory screws from outside.

ADC014S

Check that it is connected tightly, check that there are no foreign objects

HHHH

such as metal on the scanner control unit.

Close the scanner control unit cover and fix with seven screws, then insert

IIII

the scanner control unit into the main unit.

Note

❒ Be sure to place the scanner on the level surface when inserting the scanner

control unit.

❒ Insert the scanner control unit till you see the screw holes.

Fix the scanner control unit with three screws.

JJJJ

Removed cables must connect in former state.

KKKK

Connecting to the Computer

This scanner can be connected to the computer with either a SCSI, USB, or IEEE1394 interface. An optional board will be required to connect with IEEE1394.

Important

❒

Do not turn the power of the scanner ON before the software installation. If you run the "Found New Hardware Wizard" beforehand, you will not be able to install the software correctly. When the "Found New Hardware Wizard" started before the installation, click the [

Connecting with SCSI Interface

Standard, you can connect the scanner to two computers at the same time. One with the SCSI interface, and one with the USB 2.0 interface. Though, you cannot use the scanner at the same time from two computers. Interfaces are switched automatically when you change from one of the computer to the other.

When the IEEE1394 interface board of the option is installed, you can connect the scanner to three computers at the same time. One with a SCSI interface, and two with the optional IEEE1394 interface. Though, you cannot use the scanner at the same time from three computers. Interfaces are switched automatically when you use any one of the computers.

Cancel

] button to discontinue the wizard.

About the SCSI Interface

Connection of this scanner to the SCSI (Small Computer System Interface) is as follows:

• This scanner is compliant for SCSI-3. You can daisy chain with SCSI-1/2 compliant devices as well. The SCSI connecter of this scanner is male 50pin halfpitch pin type. Use the shielded SCSI-2/3 cable compliant with ANSI (American National Standard Institute). Confirm in advance that some combination of the SCSI cable and SCSI board on the computer may cause an incorrect scanner operation.

• This scanner is compliant for SCAM (SCSI Configured Automatically). If you use SCAM corresponding to SCSI board and driver for your computer, the SCSI ID will be set automatically. ⇒ p.23 “Setting the SCSI ID Automatically”

• This scanner has a built-in terminator. Set the DIP switches properly when you connect the scanner with the SCSI interface.

Important

❒

Using other cable than ANSI compliant SCSI-2/3 shielded cable, may possibly bring about malfunction or electromagnetic wave interference above VCCI rules.

❒

Connect a SCSI cable shorter than 4.9feet (1.5m) for the SCSI-3 (Ultra-SCSI), and a

9.8feet (3m) cable for the SCSI-2, including the cable length inside your computer.

❒ Some combinations of the SCSI board of your PC and daisy-chained periph-

erals might cause an incorrect operation. Please contact and ask your service representative about the recommended SCSI board.

Setting up the Scanner

Setting the SCSI ID

Open the cover of the switch box on the lower left of the frontside of the

AAAA

scanner.

ADC015S

Note

❒ Push the knob of the cover to the left and pull the cover to open.

Confirm the DIP Switch No.1 to the OFF position.

BBBB

ADC069S

SCAM function is disabled.

Set the SCSI ID by rotating the Rotary Switch.

CCCC

ADC017S

Note

❒ Press the Hard Reset Switch if you changed the SCSI ID while the power is

ON. ⇒ p.34 “Using the Hard Reset Switch”

Connecting to the Computer

Setting the SCSI ID Automatically

Note

❒ If you use the SCSI board without SCAM function or the SCSI ID is overlap-

ping with the other SCSI device, set the SCSI ID manually.

Open the cover of the switch box on the lower left of the frontside of the

AAAA

scanner.

ADC015S

Note

❒ Push the knob of the cover to the left and pull the cover to open.

Set the DIP Switch No.1 to the ON position.

BBBB

ADC016S

SCAM function is enabled.

Setting up the Scanner

Connecting the SCSI Cable (When the Scanner is at the End of the Daisy Chain)

Shut down the computer and all of the SCSI connected devices.

AAAA

Daisy chain the computer, scanner and SCSI connected devices.

BBBB

ADC018S

Note

❒ Connect the SCSI cable to either one side of the connectors.

Open the cover of the switch box on the lower left of the frontside of the

CCCC

scanner.

ADC015S

Note

❒ Push the knob of the cover to the left and pull the cover to open.

Set the DIP Switch No.3 to the OFF position.

DDDD

ADC019S

Built-in SCSI terminator is enabled.

+ 70 hidden pages
