Page 1

Operator Guide

5222/5227

next level document solutions

Network Interface

Page 2

When ordering supplies or requesting service for your copier, you will need to provide the model and serial number of your machine.

Please take a moment to enter your model and serial numbers here.

MODEL NUMBER: __________________________

SERIAL NUMBER: __________________________

To order supplies, call: ( )

To request service, call: ( )

Customer Vision® -

Our commitment to your

complete satisfaction

Important:

Please read and understand this manual prior to using it. Pay special attention to the Safety Information. Parts of this manual are subject to chang e without prior notice. In no event will the company be liable for direct, indirec t, special, incidental, or consequentia l damages as a result of handling or operating the machine.

Trademarks:

Microsoft™, W indows™, and MS-DOS™ are registered trad em arks of Microsoft Corporation. PostScript™ is a reg i ste r ed tr ad e mark of Adobe Systems Incorporat ed . Other product na mes used herein are for identification purpose s only and might be trademarks of

their resp ective companies. We disclaim any and all rights in those areas.

As an Energy Star Partner, Lanier Worldwide, Inc. has determined that this product meets the Energy Star guidelines for energy efficiency.

Printed in the U.S.A.

Page 3

Table of Contents

Chapter 1 - Introduction

Introduction .............................................................................................1-1

Features ...................................................................................... 1-1

Setting Up the Printer in a Network.............................................................1-2

Printing without Using a Print Server ...............................................1-2

Printing with a Windows NT Server .................................................1-3

Printing as a NetWare Print Server ..................................................1-4

Chapter 2 - Windows 95/98 Configuration

Configuring Windows 95/98 ......................................................................2-1

Preparing to Use the TCP/IP Protocol for Printing ..............................2-2

Preparing to Use the NetBEUI Protocol for Printing ............................2-3

Installing the Multi Direct Print Application ....................................... 2-4

Setting Up the Printer Driver ...........................................................2-5

Uninstalling the Multi Direct Print Application ...................................2-6

Table of Contents

Chapter 3 - Windows NT 4.0 Configuration

Preparing for a Network Connection............................................................ 3-1

Preparing to Use the TCP/IP Protocol for Printing ..............................3-2

Preparing to Use the NetBEUI Protocol for Printing ............................3-3

Installing the Multi Direct Print Application ....................................... 3-4

Setting Up the Printer Driver ...........................................................3-5

Unistalling the Multi Direct Print Application ..................................... 3-6

Setting Up a Client Computer .....................................................................3-7

Windows 95/98 ............................................................................3-7

Windows NT 4.0 ..........................................................................3-8

Configuring LPR Port Printing .....................................................................3-9

Chapter 4 - NetWare Configuration

Installing the NIC Setup Tool ...................................................................... 4-1

Installing the PRINTER MANAGER FOR ADMINISTRATOR ..................4-1

Running the NIC Setup Tool ...........................................................4-2

Quick Setup Using the NIC Setup Tool Wizard..............................................4-3

Netware 3.x - Advanced Settings ...............................................................4-6

Setting Up as Print Server ..............................................................4-6

Setting Up as Remote Printer ..........................................................4-8

Netware 4.x, 5- Advanced Settings...........................................................4-11

Setting Up as Print Server ............................................................4-11

Setting Up as Remote Printer ........................................................4-14

Setting Up a Client Computer ................................................................... 4-17

Windows 95/98 .......................................................................... 4-17

Windows 3.1x ............................................................................ 4-18

Page 4

Table of Contents

Chapter 5 - Macintosh Configuration

Configuring Macintosh .............................................................................. 5-1

Changing to EtherTalk ................................................................... 5-1

Configuring the Printer .................................................................. 5-2

Changing Printer Name .................................................................. 5-2

Changing Zone ............................................................................. 5-2

Chapter 6 - Additional Functions

Multi Direct Print...................................................................................... 6-1

Select Printer ............................................................................... 6-1

Network ...................................................................................... 6-3

Configuring NIC with Web Browser ............................................................ 6-4

Going to the Top Page .................................................................. 6-5

Assigning IP Address with ARP+PING........................................................ 6-7

Remote Maintenance by Telnet (mshell) ...................................................... 6-8

Operation Flow ............................................................................ 6-8

Command List .............................................................................. 6-9

SNMP ....................................................................................................6-16

Understanding Displayed Information.........................................................6-17

Print Job Information ...................................................................6-17

Print Log Information ...................................................................6-18

Network Statistical Information .....................................................6-19

Configuring Network Interface Card ...............................................6-20

Message List ..........................................................................................6-22

System Log Information ...............................................................6-22

Precautions ............................................................................................6-27

Connecting a Dial Up Router to a Network ......................................6-27

When Printing PostScript from Windows ........................................6-27

When Printing with Netware .........................................................6-27

When Using DHCP .......................................................................6-28

When Using the NIC Setup Tool ....................................................6-29

Network Configuration Page .....................................................................6-30

Chapter 7 - Specifications

Agency Certifications ............................................................................... 7-1

Specifications .......................................................................................... 7-2

Index

Index of Network Interface Terms ................................................................I-3

Warranty

New Machine Warranty and Limitation of Liability .......... inside back cover

Page 5

Introduction

Chapter 1

Page 6

Chapter Overview

This Chapter covers:

•“Introduction” on page 1-1

•“Setting Up the Printer in a Network” on page 1-2

Introduction

Page 7

Introduction

This manual contains detaile d instructions on configuring your printer for using as a network printer. The actual procedures may differ depending on your network environment. Use the procedures for your network environment.

Introduction

Features

Note: The procedures written in this manual assume that you are a network administrator. Be sure to consult your network administrator before doing any configuration.

Note: Refer to the manual that comes with the printer for information on physically installing the Network Interface Board and cabling.

Support for 100BASE-TX and 10BASE-T

•

The Network Interface Board is compatible with NetWa re (IPX/SPX), Windows NT

•

(TCP/IP, NetBEUI), Windows 95/98 (TCP/IP, NetBEUI),and Macintosh (AppleTalk) protocols. This allows you to use the printer in a network that uses different protocols and operating systems.

A computer used as a dedicated print server is not required, because the Network

•

Interfac e Board can be configur ed as a NetWare print server.

The Network Interface Board can connect the printer to the network without requiring

•

its own power supply as the Network Interface Board is installed inside the printer.

Introduction 1 - 1

Page 8

Setting Up the Printer in a Network

Printing without Using a Print Server

You do not have to use a print server. The actual procedure differs depending on your operating system.

1 - 2 Introduction

Page 9

Printing with a Windows NT Server

When Windows NT Server or Workstation is the opera ting system being used on the print server, TCP/IP or NetBEUI protocols are used.

Setting Up the Printer in a Network

Note: For instructions on setting up TCP/IP or NetBEUI in a Windows NT environment, refer to Chapter 3.

Introduction 1 - 3

Page 10

Setting Up the Printer in a Network

Printing as a NetWare Print Server

The Network Interface Board allows you to set up your print er in a NetWare environment as a print server or a r emote printer. A dedicated NetWare print server is not required. If a dedicated print server is being used, you should conf igure your printer as a remote printer.

The actual procedures for configuring your printer may differ depending on the version of NetWare.

NetWare 3.x

•

NetWare 4.x,

•

The actual proc edures for configuring your client computer m ay differ depending on the operating system.

Windows 95/98

•

Windows 3.1x

•

1 - 4 Introduction

Page 11

Configure as Remote Printer

Setting Up the Printer in a Network

The actual procedures for configuring your printer may differ depending on the version of NetWare.

NetWare 3.x

•

NetWare 4.x, 5

•

The actual proc edures for configuring your client computer m ay differ depending on the operating system.

Windows 95/98

•

Windows 3.1

•

Introduction 1 - 5

Page 12

Setting Up the Printer in a Network

Notes:

1 - 6 Introduction

Page 13

Windows 95/98

Configuration

Chapter 2

Page 14

Chapter Overview

This chapter covers:

•“Preparing to Use the TCP/IP Protocol for Printing” on page 2-2

•“Preparing to Use the NetBEUI Protocol for Printing” on page 2-3

•“Installing the Multi Direct Print Applic ation” on page 2-4

•“Setting Up the Printer Driver” on page 2-5

•“Uninstalling the Multi Direct Print Application” on page 2-6

Windows 95/98 Configuration

Page 15

Configuring Windows 95/98

You can use your printer as a network printer with Windows 95 and Windows 98 using the Multi Direct Pri nt application, and TCP/IP or NetBEUI protocols. This c hapter explains how to configure your printer and Windows.

Configuring Windows 95/98

The Multi Direct Print Application supports the TCP/IP protocol and the NetBEUI protocol. Consult your network administrator before selecting the protocol.

Limitation

When you use the NetBEUI protocol, you cannot print to a printer which is located on the other side of a router .

Note: You can use both TCP/IP and NetBEUI protocols in a computer. To use both protocols you must first install them.

Windows 95/98 Configuration 2 - 1

Page 16

Configuring Windows 95/98

Preparing to Use the TCP/IP Protocol for Printing

T o use the TCP/IP protocol to print, the network must be configured as descr ibed below.

Configuring the Printer

Configure your printer to use the TCP/IP protocol.

Confirm that the TCP/IP protocol is set to be act ive . (Th e factory default is active)

•

Assign an IP address and make other settings required for using the TCP/IP

•

protocol.

For more information on how to make the above settings, refer to the Operator Guide for your printer.

Note: After setting the IP address, use the PING command to confirm that it has been set correctly.

1. Click [Start], point to [Programs], and then click [MS-DOS Prompt]. Enter the following. (Example IP addre ss is 192.168.15.16)

C:> ping 192.168.15.16

If the address has been configured correctly, the following message appears.

Reply from 192.168.15.16: bytes=32 time<10ms TTL=32

If the address has been configured incorrectly, the following message appears.

Request timed out.

Configuring a Windows 95/98 Computer

Follow these steps to configure a Windows 95/98 computer to use the TCP/IP protocol.

Double-click the [Networ k] icon of [Control Panel], and confirm that “TCP/IP” is in the

[The following network components are installed] box of [Configuration] tab.

If TCP/IP is not installed, click [Add] of [Configuration] tab, and install it.

•

Configure the TCP/IP protocols with the appropriate IP address, subnet mask and other

settings.

Confirm with your network administr ator that the settings are correct.

•

2 - 2 Windows 95/98 Configuration

Page 17

Preparing to Use the NetBEUI Protocol for Printing

T o use the NetBEUI protocol to print, the network must be configured as describe d below.

Configuring the Printer

Configure your printer to use the NetBEUI pro tocol.

Confirm that the NetBEUI protocol is set to be active. (The factory default is active.)

•

For more information on how to make the above settings, refer to the Operator Guide for your printer.

Configuring a Windows 95/98 Computer

Install the NetBEUI protocol into a Windows 95/98 computer, and configure NetBEUI as the default protocol.

Double-click the [Networ k] icon in the [Control Panel], and confirm that “NetBEUI” is in

the [The following network compon ent s are installed] list of [Configuration] tab.

If NetBEUI is not installed, click [Add] of [Configuration] tab, and install it.

•

Configuring Windows 95/98

Configure the NetBEUI protoc ol as the default protocol. Click the [Configuration] tab,

select “NetBEUI” in the [The following network compone nts are installed] list, and click [Properties]

Click the [Advanced] tab, select [Set this protocol to be the default protocol], and click

[OK].

Click [OK] to close the [Network] dia log.

After confirming the message to restart, click [Yes]

Windows 95/98 Configuration 2 - 3

Page 18

Configuring Windows 95/98

Installing the Multi Direct Print Application

Follow these instructions to install Multi Direct Print. Preparation: You must restart the computer after installing Multi Direct Print. Be sure to close all

applications before beg inning the installation process.

Note: You must install Multi Direct Print and the appropriate printer driver in order to print. If you print, usi ng the TCP/IP protocol, to be able to browse the printer via the network, PRINTER MANAGER FOR CLIENT needs to be installed. If the installer starts automatically with the AutoRun program, you can install both of the se pr ograms. For more informati on on how to install these programs, refer to the Operator Guide for your printer.

Insert the CD-ROM that comes with the print er into your computer's CD-ROM drive.

If the instal ler starts automatically, you can use it to ins tall Multi Direct Print , and set up

•

the printer driver, and then go to procedure 6.

Open [Control Panel], and double click the [Add/Remove Programs] icon.

In the [Install/Uninstall] tab, click [Install].

Click [Next >].

Enter the name of the CD-ROM drive in the [Command line for installation pro-gr am] box,

followed by “:\NETWORK\MDP\DISK1\SETUP” (do not include the quotation marks), and then click [Finish].

Note: An example would be “D:\NETWORK\MDP\DISK1\SETUP” when the drive lett e r is “D”.

After the [Welcome] dialog appears, click [Next >].

After the [Setup C omplete] dialog appears, cli ck [Yes, I want to restart my computer now.],

and click [Finish].

The computer restarts, and Multi Dire ct Print can now be used. If you select “No”, be

•

sure to restart the computer manually before starting Multi Direct Print for the first time.

2 - 4 Windows 95/98 Configuration

Page 19

Setting Up the Printer Driver

Using Multi Direct Print to print is not possible until the printer driver is in-stal led and the correct port selected.

Preparation: The target printer must be turne d on before starting the installation process.

Install the printer drivers.

If the printer drivers have already been installed, you can proceed to the next step.

•

Any port can be selected during the installation, however, LPT1 is recommended.

•

In the [Printe rs] window, highlight the icon of the printer you want to use by clicking it. On

the [File] menu, click [Properties].

Click the [Details ] tab, a nd then click [Add Port].

Configuring Windows 95/98

In the [Add Port] box, click [Other], and select [LAINER Multi Direc t Print] by clicking it,

and then click [OK]

The [Select Prin ter] d ia log ap p ear s, and t he prin t ers w hich can p rin t wi th TCP /IP are

•

displayed.

Limitation:

•

If PRINTER MANAGER FOR CLIENT is not installed in your computer, printers which can print with TCP/IP are not displayed.

The printers which have replied to a broadcast from the computer are listed here. To

•

print to a printer that is not on this list, or to directly e nter the port name, highlight

Printer]

To print using the NetBEUI protocol, click [NetBEUI].

Select the printer you want to use by clicking it, and click [Next >].

You can identify the “Printer Name” and “Address” on the “configuration page” printed

•

by the printer.

Confirm that the Port name of the print er is correct, and click [Next >].

If you did not select a printer with procedure 6, you must enter the Port name.

•

by clicking it, and click

[Next >]

, and then enter the port name with pr ocedure

[New

Windows 95/98 Configuration 2 - 5

Page 20

Configuring Windows 95/98

Inputting Port Name for use with TCP/IP Protocol

Enter the IP address of the Network Interface Board into the [IP address] box.

You can enter the host name or a domain name instead of an IP address into the [Host

•

Name] box.

Limitation: You cannot use a host name that begins with “%%”.

•

When you use DHCP to assign I P addresses to Network Interface Boards, you can use a

•

printer name (Current Host name on the network configuration page) as the host name.

Inputting Port Name for use with NetBEUI Protocol

Print a configuration page, and confirm the Network path name.

For information on printing a confi guration page, refer to the Operator Guide for your

•

printer.

Enter the printer's Ne twork path name in form of “%%Computer name \Shar e name”. Do not enter “\\” as head characters but “%%”.

Confirm the port name in the [Port Name] box, and click [Finish].

In the [Printer Port s] dialog, click [Clos e].

Confirm that the port name is displa yed in t he [Print t o the followi ng port( s)] box a nd ' mar k

is inside the check box. Then click [OK].

Configuration is complete .

•

When you print, the printing procedure is no different. When you select the printer

•

configured here, the computer automatically uses Multi Direct Print.

Uninstalling the Multi Direct Print Application

Open [Control Panel], and double click the [Add/Remove Programs] icon.

Wit h [Install/Uninstall] tab, select [Lanier Multi Direct Pr int] by clicking it, and click [Add/

Remove].

After a confirmation messa ge appears, click [Yes].

UninstallShield remov es all of the components of the Multi Direct Print application.

•

When the uninstallat ion is complete, restart your computer.

2 - 6 Windows 95/98 Configuration

Page 21

Windows NT 4.0

Configuration

Chapter 3

Page 22

Chapter Overview

This Chapter covers:

•“Preparing for a Network Connection” on page 3-1

•“Setting Up a Client Computer” on page 3-7

•“Configuring LPR Port Printing” on page 3-9

Windows NT 4.0 Configuration

Page 23

Preparing for a Network Connection

Y ou c an use your printe r as a network printe r with Windows NT 4.0 using the Multi Dir ec t Print application, and TCP/IP or NetBEUI protocols. This chapter explains how to configure your printer and Wi ndows NT.

Preparing for a Network Connection

Basic Procedure

Selecting the protocol

TCP/IP NetBEUI

Assigning the IP address

TCP/IP NetBEUI

Windows 95/98

Configuring Windows environme nt

Installing the Multi Direct Print

Installing the Printer Driver

Changing the port

Preparation: The Multi Direct Print Applica tion supports the TCP/IP protocol and the NetBEUI protocol. Consult with your network administrator before selecting the protocol.

Limitation: When you use the NetBEUI protoco l, you c annot print to a printer which is located on the other side of a router.

Note: You can use both TCP/IP and NetBEUI protocols in a computer. To use both protocols you must first install them.

Windows NT 4.0 Configuration 3 - 1

Page 24

Preparing for a Network Connection

Preparing to Use the TCP/IP Protocol for Printing

Follow these instructions to con figure the Network Int erfa ce Board and Wind ows NT to use the TCP/IP protocol.

Configuring the Printer

Configure your printer to use the TCP/IP protocol.

Confirm that the TCP/IP protocol is set to be act ive . (Th e factory default is active)

•

Assign an IP address and make other settings required for using the TCP/IP protocol.

•

After setting the IP address, use the PING command to confir m that it has been set correctly.

1. Cli ck [Start], point to [Programs], and then click [Command Prompt].

2. Enter the following. (Example IP address is 192.168.15.16) C:> ping 192.168.15.16

If the address has been configured correctly, the following message appears.

Reply from 192.168.15.16: bytes=32 time<10ms TTL=32

If the address has been configured incorrectly, the following message appears.

Request timed out.

____

Configuring a Windows NT Computer

Follow these steps to configure a Windows NT to use the TCP/IP protocol.

Double-click the [Networ k] icon of [Control Panel], and confirm that “TCP/IP Protocol” is

in the [Network protocols ] box of the [Protoc ols] tab.

If the TCP/IP protocol is not instal led, click [Add] in the [Protocols] tab, and install it.

•

Configure the TCP/IP protocols with the appropriate IP address, subnet mask and other

settings.

Confirm with the network administr ator that the settings are correct.

•

Click the [Services] tab, and confirm that the “Microsoft TCP/IP Printing” is installed

If “Microsoft TCP/IP Printing” is not installed, click [Add] in the [Service s] tab, and

•

install it. For additional help in installing and configuring network services, refer to the Windows NT online help.

3 - 2 Windows NT 4.0 Configuration

Page 25

Preparing for a Network Connection

Preparing to Use the NetBEUI Protocol for Printing

Follow these instructions to con figure the Network Int erfa ce Board and Wind ows NT to use the NetBEUI protocol.

Configuring the Printer

Configure your printer to use the NetBEUI pro tocol.

Confirm that the NetBEUI protocol is set to be active. (Th e factory default is active.)

•

Configuring a Windows NT Computer

Install the NetBEUI protocol into a W indows NT computer, and e nter the LAN adapter number (Lana Number).

Double-click the [Networ k] icon in the [Control Panel], and confirm that “Net-BEUI

Protocol” is in the [Network protocols] box of the [Protocols] tab.

If the NetBEUI protoc ol is not installed, click [Add] in the [Protocols] tab, and install it.

•

For more information, refer to the Windows NT online help.

Change the Lana Number. Click the [Services] tab, select the [NetBIOS interface] of the

[Network Services] box, and click [Properties].

Select the La na Number corresponding [Nbf protocol] of the [Network route] headline, and

click [Edit].

Enter “0” as the Lana N umber.

If the other protocol's Lana Number is configured with “0”, you must change the Lana

•

Number w ith a number other than “0”.

Click [OK].

Click [close], and close the [Network] dialog.

After confirming the message fo r restart, click [Yes].

When you change the Lana Number, You must restart your computer.

•

Windows NT 4.0 Configuration 3 - 3

Page 26

Preparing for a Network Connection

Installing the Multi Direct Print Application

Follow these instructions to install Multi Direct Print.

Y ou must restar t your computer after installi ng Multi Direct Print. Be sure to close all

•

applications before begi nning the installation process.

You must install Multi Direct Print and the appropria te printer driver in order to print.

•

If you print, using the TCP/IP protocol, to be able to browse the printer via the network, PRINTER MANAGER FOR CLIENT needs to be installed. If the installer starts automatically with the AutoRun program, you can install both of these programs.

T o install this software you must be logged on as a member of the

•

Administrators group.

Insert the CD-ROM that comes with your print er into your computer's CD-ROM drive.

If the instal ler starts automatically, you can use it to ins tall Multi Direct Print , and set up

•

the printer driver, and then go to step 6.

Open [Control Panel], and double click the [Add/Remove Programs] icon.

In the [Install/Uninstall] tab, click [Install].

Click [Next >].

Enter the name of the CD-ROM drive in the [Command line for installation pro-gr am] box,

followed by “:\NETWORK\MDP\DISK1\SETUP” (do not include the quotation marks), and then click [Finish].

An example would be “D:\NETWORK\MDP\DISK1\SETUP” when the drive letter is

•

“D”.

After the [Welcome] dialog appears, click [Next >].

After the [Setup C omplete] dialog appears, cli ck [Yes, I want to restart my computer now.],

and click [Finish].

The computer restarts, and Multi Dire ct Print can now be used. If you select “No”, be

•

sure to restart your computer manually before starting Multi Direct Print for the first time.

3 - 4 Windows NT 4.0 Configuration

Page 27

Setting Up the Printer Driver

Using Multi Direct Print to print is not possible until the printer driver is installe d and the correct port is selected.

The target printe r must be turne d on before starting the installation process.

•

Install the print er drivers.

If the printer drivers have already been installed, you can proceed to the next step.

•

Any port can be selected during the installation, however, LPT1 is recommended.

•

In the [Printe rs] window, highlight the icon of the printer you want to use by clicking it. On

the [File] menu, click [Properties].

Click the [Ports] tab, and click [Add Port].

In the [Available Printer Ports] box, highlight [LANIER Multi Direct Print] by clicking it,

and then click [New Po rt]. The [S el ect Prin te r] dialog appears, and the printers which can print with TCP/IP are displayed.

Preparing for a Network Connection

If PRINTER MANAGER FOR CLIENT is not installed in your computer, printers

•

which can print with TCP/IP are not displayed.

The printers which have replied to a broadcast from the computer are listed here. To

•

print to a printer that is not on this list, or to directly e nter the port name, highlight [New Printer] by clicking it, and click [Next >]. Then, enter the port name with procedure 7.

To print using the NetBEUI protocol, click [NetBEUI].

Select the printer you want to use by clicking it, and click [Next >].

You can identify the “Printer Name” and “Address” on the “configuration page” printed

•

by the printer.

Confirm that the Port name of the print er is correct, and click [Next >].

If you did not select a printer with Step 6, you must enter the Port na me.

•

Windows NT 4.0 Configuration 3 - 5

Page 28

Preparing for a Network Connection

Inputting the Port Name for use with the TCP/IP Protocol

Enter the IP address of the Network Interface Board into the [IP address] box.

You can enter the host name or a domain name instead of an IP address into the [Host

•

Name] box.

You cannot use a host name that begins with “%%”.

•

When you use DHCP to assign I P addresses to Network Interface Boards, you can use a

•

printer name (Current Host name on the network configuration page) as the host name.

Inputting the Port Name for use with the NetBEUI Protocol

Print a configuration page, and confirm the Network path name.

For information on printing a confi guration page, refer to the Operator Guide for your

•

printer.

Enter the printer's Ne twork path na me in for m of “%%Computer name \Share na me ”. Do not enter “\\” as head characters but “%%”.

Confirm the port name in the [Port Name] box, and click [Finish].

In the [Printer Port s] dialog, click [Clos e].

Confirm that the port name is displa yed in t he [Print t o the followi ng port( s)] box a nd ' mar k

is inside the check box. Then click [OK].

Configuration is complete .

•

When you print, the printing procedure is no different. When you select the printer

•

configured here, the computer automatically uses Multi Direct Print.

Unistalling the Multi Direct Print Application

Open [Control Panel], and double click the [Add/Remove Programs] icon.

In the [Install/Uninstall] tab, select the [RICOH Multi Direct Print] by clicking it, and click

[Add/Remove].

After a confirmation message appears, click [Yes]. UninstallShield removes all of the

components of the Multi Direct Print appl ic ation.

When the uninstallat ion is complete, restart your computer.

3 - 6 Windows NT 4.0 Configuration

Page 29

Setting Up a Client Computer

This section d escribes the procedures for setting up a client in a network t hat uses Windows NT Server or Windows NT Workstation as a print server.

Windows 95/98 Windows NT 4.0

Explanation of this section as sumes that the client has already been configured to communicate with a Win dows NT p rint se rver. Do not pr oceed wit h the f ollowing instr ucti ons unt il the clie nt has been set up and configured correctly.

Windows NT 4.0 Print Server

Setting Up a Client Computer

Windows 95/98

T o print from Windows 95/98, you must install the pr inter driver and change the printer port to the print server.

Install the print er driver as a local printer.

Any port can be selected during the installation, however, LPT1 is recommended.

•

Click [Start], point to [Settings], and then click [Printers ].

Select the icon of the printe r you want to use by clicking it. On the [File] menu, click

[Properties].

Click the [Details ] tab, the n click [Add Port].

Click [Network], then click [Browse].

On the network tree, double-click the name of the computer used as the print server.

The printers attached to the network are displayed.

•

Select the name of the printer you want to use by clicking it, then click [OK].

Windows NT 4.0 Configuration 3 - 7

Page 30

Setting Up a Client Computer

Click [OK].

Confirm that the port name is displ ayed in the [Print to the following port] box, then click

[OK]

Windows NT 4.0

Use the [Printers] window to set up the printer.

Click [Start], point to [Settings], and then click [Printers ].

Double-click the [Add Printer] icon.

This launches the Add Printer W izard.

•

Click [Network printer server], and click [Next >].

In the [Shared Printers] box, double-click the name of the computer used as a print server.

The printers attached to the network are displayed.

•

Highlight the print er you want to use by clicking it, and click [OK].

If the printer driver is not insta lle d in the print server, a message appears. If a driver has

•

been installed on the client, click [OK], and follow the instructions on the screen.

There is a Windows NT printe r drive r in the CD-ROM that comes with the printer.

•

Select whether you use this printer as the default printer, and click [Next >].

After install ation is complete, click [Finish].

The icon of the newly installed print er appears in the [Printers] window.

•

3 - 8 Windows NT 4.0 Configuration

Page 31

Configuring LPR Port Printing

This section explains the proce dure for printing to a LPR port from Windows NT.

The TCP/IP protocols must be installed and configured correctly.

•

The following inst ructions assume that the printer drivers have already been installed.

•

This is a procedure to change the printer port to LPR.

•

Click [Start], point to [Settings], and then click [Printers ].

Select the icon of the printe r you want to use by clicking it. On the [File] menu, click

[Properties].

Click the [Ports] tab, then click [Add Port].

In the [Available Printer Ports] box, select [LPR Port] by clicking it, and then click [New

Port].

Configuring LPR Port Printing

If “LPR Port” does not appear, “Microsoft TCP/IP Printing” has not been installed.

•

Enter the IP address of the Network Interface Board into the [Name or address of server

providing lpd] box.

Enter “lp” into the [Name of printer or print queue on that server] box, and click [OK].

Click [Close].

Confirm that the port name is displayed in the [print to the following port(s)] box and the '

mark is inside the check box. Then click [OK].

Windows NT 4.0 Configuration 3 - 9

Page 32

Configuring LPR Port Printing

Notes:

3 - 10 Windows NT 4.0 Configuration

Page 33

Chapter 4

NetWare Configuration

Page 34

Chapter Overview

This Chapter covers:

•“Installing the NIC Setup Tool” on page 4-1

•“Quick Setup Using the NIC Setup Tool Wizard” on page 4-3

•“Netware 3.x - Advanced Settings” on page 4-6

•“Netware 4.x, 5- Advanced Settings” on page 4-11

•“Setting Up a Client Computer” on page 4-17

NetWare Configuration

Page 35

Installing the NIC Setup Tool

This chapter describes how to confi gure your printer to use as a print server or a remote printer in a NetW are environment.

NetW ar e must be set to acti ve using the opera tion panel of your pr inter. For information on how to set it, refer to the Operator Guide for your printer.

A utility called the NIC Setup Tool is provided to configure your printer to work in a NetWare environment. Installing the PRINTER MANAGER FOR ADMINISTRATOR, and how to run the NIC Setup Tool on your computer. This se ction describes how to install the PRINTER MANAGER FOR ADMINISTRATOR, and how to run the NIC Setup T ool.

Limitations:

NetWare 3.x, 4.x or 5 must be functiona l to run the NIC Setup Tool.

•

The NIC Setup Tool is supported to work with the following operation systems.

•

Microsoft Windows 95/98 Microsoft Windows NT 4.0

Installing the NIC Setup Tool

Installing the PRINTER MANAGER FOR ADMINISTRATOR

Follow these steps to install the PRINTER MANAGER FOR ADMINISTRATOR. You should install the PRINTER MANAGER FOR ADMINISTRATOR on your computer. If you

install it on a file se rve r and exec ute it via the network, it might not work co rrectly. Be sure to close all applications before starting the installation procedure.

Insert the CD-ROM that comes with your print er into your computer's CD-ROM drive.

Note: If the installer starts automatically, you can use it to install the PRINTER MANAGER FOR ADMINISTRATOR, and go to procedure 6.

Open [Control Panel], and double click the [Add/Remove Programs] icon.

In the [Install/Uninstall] tab, click [Install].

Click [Next].

Enter the name of the CD-ROM drive in the [command line for installation program] box,

followed by “\NETWORK\PRINTMAN\AD-MIN\ DISK1\SETUP” (do not include the quotation marks) and then click “Finish”.

Note: An example would be “D:\NETWORK\PRINTMAN\AD-MIN\ DISK1\SETUP” when the drive name is “D”.

After the [Welcome] dialog appears, click [Next].

NetWare Configuration 4 - 1

Page 36

Installing the NIC Setup Tool

The Software License Agree ment appea rs. After reading through all of the contents by

clicking [PageDown], click [Yes] to agree with the License Agreement.

Select a directory in which it is to be installed, and click [Next].

If you change the displayed directory, click [Browse] to select another one.

•

The installation program starts.

•

After the confirmation dia log appea rs, the installation program is complete.

•

Running the NIC Setup Tool

Click [Start], point to [Programs],

Then click [NIC Setup Tool] in the [NIC Set-up Tool] program.

4 - 2 NetWare Configuration

Page 37

Quick Setup Using the NIC Setup Tool Wizard

Using the NIC Setup Tool, you can easily set up a NetWare printing environment after physically installing the Network Interface Card into the printer. You can select [Wizard] or [Property Sheet] as an installa tion method. When you configure the Network Interface Card for the first time, use the Wizard method.

When the Wizard method is used, the Network Interface Card is configured to work as a Print Server. To confi gur e it as a remote printer, use the Property Sheet method.

Note: This section assumes that NetWare is functional and that the necessary environment for the NetWare Print Services is available.

You should install the client software released from Novell on the Windows before running the NIC Setup Tool for configuring in NDS mode or using Windows NT 4.0.

Run the NIC Setup Tool.

Click [Wiz ard] and click [OK].

The Browse dialog of the Network Interface Card appears.

•

Click [IPX protocol] .

Select the I PX address of the Ne twork Inte rface Ca rd you a re configur ing by clicking i t, and

click [Next].

If you do not know which Network Interface Card you are configur in g, print the

•

Configuration Page using the printe r's operation panel, and select the MAC address that is on the page.

Confirm that the MAC and IPX addresses are correct, and click [Finish].

Enter the printer name into the [Devic e Name] box.

The factory defaul t is RNP fol lowed by t he last 6 dig its of t he MAC addres s. We

•

recommend that you change it to something that is easier to remember or something based on the structure of your network.

Enter your comments in the [Comment] box, and clic k [Next].

The enter comments are displayed with the device name when using a utility

•

such as PRINTER MANAGER FOR ADMINISTRATOR.

NetWare Configuration 4 - 3

Page 38

Quick Setup Using the NIC Setup Tool Wizard

In the dialog for selecting a network environment, place check mark for [Net-Ware] and

remove check mark for the [TCP/IP]

Click [Next].

A dialog for configuring the NetWare environment appears.

•

Select [Bindery Mode] when print ing under the Bind ery mode, or select [ NDS Mode] when

printing under the NDS mode.

When you are using NetWare version 4.x, 5, you can select [NDS Mode].

•

In case of configuring NDS Mode, if the [NDS Mode] is unable to be selected,

•

you need to check the version of the client software released from Novell. We recommend that you install the latest version of the client software released from Novell.

In the [File Server Name] box, ent er the name of the file server in which a print server is to

be created.

Clicking [Browse], you can select a file server among those list ed in the Browse

•

dialog.

If you selected [NDS Mode], enter the name of the NDS tree in which the print server is

created into the [NDS Tre e] box, and enter the context into the [NDS Context] box.

Clicking [Browse], you can select a NDS tree and a NDS context among those

•

listed in the Browse dialogs.

As a context, object names are enter from a lower object a nd divided by a

•

period. For example, if you want to create a file server into NETWORK under DS, enter “NETWORK.DS”.

Click [Next].

Enter the name of the print server you are creating on the NetWare environment into the

[Print Server Name] box.

The factory default name is already entered. You should change it if necessary.

•

Enter the name of the Printer into the [Printer Name] box, and the name of the Print Queue

into the [Print Queue Name] box.

The factory default for Printer Name is “Print Server Name” followed by “_1”

•

and that for Print Queue Name is “Print Server Name” followed by “_Q”(quotation marks are not included). You should change them if necessary.

4 - 4 NetWare Configuration

Page 39

Quick Setup Using the NIC Setup Tool Wizard

If you selected [NDS Mode], enter the volume of the print queue into the [Queue Volume]

box.

Clicking [Browse], you can select one of those shown in the Browse dialog.

•

Click [Next].

A dialog to confirm the printing environment appears.

•

After confirming the environment, click [Next].

If you want to change the settings, click [< Back] and make the settings again.

•

Clicking [Next], the NIC Setup Tool automatically creates the Print Server, the Printer , a nd the Print Queue on NetWare.

After the conf irmation dialog appears, sele ct [Quit] and click [Finish] to exit the NIC Setup

Tool.

NetWare Configuration 4 - 5

Page 40

Netware 3.x - Advanced Settings

The actual procedures for configuring your printer differ depending on whether the Network Interface Card is configured as a print server or as a remote printer. This section describes how to configure it in the NetWare 3.x environment.

Basic Procedure

Installing the NIB Setup Tool

Print Server Remote Printer

Configuring the Network Interface Card

Configuring the NetWare

Preparation

The following procedures use the Property Sheet method in configuring the Network Interface Card. If you configure the Network Interface Card as a NetWare print server for the first time af ter physically installing it, we recommend you use the Wizard method.

Note: This section assumes NetWare is functional and that the necessary environment for the NetWare Print Service is available.

Setting Up as Print Server

Run the NIC Setup Tool.

Click [Property Shee t] and click [OK].

The Browse dialog of the Network Interface Card appears.

•

Turning the power off and on

Start the Print Server

Click [IPX protocol] .

Select the IPX addres s of the Network Interface Card which is to be configured by clicking

it, and click [Next].

Note: If you don't know which Network Interface Card you are configuring, print the Configuration Page using the printer's operation panel, and select the MAC address that is on the page.

4 - 6 NetWare Configuration

Page 41

Netware 3.x - Advanced Settings

Confirm that the MAC and IPX addresses are correct, and click [Finish].

The [NIC Setup T ool] window appears.

•

Click [Configure] .

The property sheet appears.

•

Click the [NetWare] tab, and make the following settings.

In the [Print Se rver N am e] b o x, en ter the n am e of the print ser ver.

•

In the [File Server Name] box, enter the name of the file se rver in which a print

•

ser v e r is to be created. Click [Browse] to select a file server among those listed in the Browse dialog.

In the [Print Server Operation Mode] group, click [As Print Server].

•

Click [OK] to close the property sheet.

•

After a confirmation dialog appears, click [OK].

•

In the [NIC] menu, click [Exit] to exit the NIC Setup Tool.

Enter “PCONSOLE” from the command prompt. F:> PCONSOLE

Create a print queue as follows.

If you use a currently defined print queue, proceed to the step 12.

•

In the [Available Options] menu, select [Print Queue Information].

•

Press {Insert} and enter a print queue name.

•

Press {Esc} to return to the [Available Options] menu.

•

Create a printer as follows.

In the [Available Options] menu, select [Print Server Information].

•

T o create a new print server, press {Insert} and en ter a print server name. If you

•

use an currently defined print server , select one of the print servers shown in the [Print Server] list.

NetWare Configuration 4 - 7

Page 42

Netware 3.x - Advanced Settings

Important

Use the same name as that specified in the NIC Setup Tool.

•

In the [Print Server Information] menu, select [Print Server Configuration].

•

In the [Print Server Configuration menu], select [Printer Configuration].

•

Sel e ct the pr i nter wh i c h is indi c ated as “Not Installed”.

•

If you change the name of the printer, enter a new name.

•

A name “Printer x” is as signed to the printer. x sta nds for the number of the

•

selected printer.

As Type, select [Remote Parallel, LPT1]. The IRQ, Buffer size, Starting form,

•

and Queue servi ce mode are automat ically configured.

Press {Esc}, and click [Yes] in the confirmation dialog.

•

Press {Esc} to return to the [Print Server Configuration Menu].

•

Assign print queues to the crea ted printer as follows.

In the [Print Server Configuration Menu], select [Queues Serviced By Printer].

•

Select the printer created in the Step 12.

•

Press {Insert} to sele ct a queue se rviced by t he printer. You can se lect more than

•

one queue at a time.

Follow the instructions on the screen to make other necessary settings.

•

When you have finished the above steps, make sure that the queues are

•

assigned.

Press {Esc} until “Exit?” appears, and se lect [Yes] to exit PCONSOLE.

Turn the printer power OFF and ON.

T o confirm if the printer is configured correctly, enter as follows fro m the

•

command prompt. F:> USERLIST

If the printer works as configured, the name of the print server appears as an

•

attached user.

Setting Up as Remote Printer

Run the NIC Setup Tool.

Click [Property Shee t] and click [OK].

The Browse dialog of the Network Interface Card appears.

•

Click [IPX protocol] .

Select the IPX addres s of the Network Interface Card which is to be configured by clicking

4 - 8 NetWare Configuration

Page 43

Netware 3.x - Advanced Settings

it, and click [Next].

If you do not know which Network Interface Card you are configur in g, print the

•

Configuration Page using the printe r's operation panel, and select the MAC address that is on the page.

Confirm that the MAC and IPX addresses are correct, and click [Finish].

[NIC Setup Tool] window appears.

•

Click [Configure] .

The property sheet appears.

•

Click the [NetWare] tab, and make the following settings.

In the [Print Se rver N am e] b o x, en ter the n am e of the print ser ver.

•

In the [File Server Name] box, enter the name of the file se rver in which a print

•

server is to be created. Clicking [Browse], you can select a file server among those listed in the Browse dialog.

In the [Print Server Operation Mode] group, click [As Remote Printer].

•

In the [Remote Printer No.] box, enter the printer number. Important Use the

•

same printer number as that to be created in the printer server.

Click [OK] to close the property sheet.

•

After a confirmation dialog appears, click [OK].

•

In the [NIC] menu, click [Exit] to exit the NIC Setup Tool.

Enter “PCONSOLE” from the command prompt. F:> PCONSOLE

Create a print queue as follows.

If you use a currently defined print queue, proceed to the step 12.

•

In the [Available Options] menu, select [Print Queue Information].

•

Press {Insert} and enter a print queue name.

•

Press {Esc} to return to the [Available Options] menu.

•

Create a printer as follows.

In the [Available Options] menu, select [Print Server Information].

•

T o create a new print server, press {Insert} and en ter a print server name. If you

•

use an currently defined print server , select one of the print servers shown in the [Print Server] list. Use the same name as that spec ified in the NIC Setup Tool.

In the [Print Server Information] menu, select [Print Server Configuration].

•

In the [Print Server Configuration menu], select [Printer Configuration].

•

Select the pri nter which is indicated as “Not In stalle d”. Use the same number as

•

that specified as Remote Printer No. using the NIC Setup Tool.

NetWare Configuration 4 - 9

Page 44

Netware 3.x - Advanced Settings

If you change the name of the printer, enter a new name. A name “Printer x” is

•

assigned to the printer. x stands for the number of the selected printer.

As Type, select [Remote Parallel, LPT1]. The IRQ, Buffer size, Starting form,

•

and Queue servi ce mode are automat ically configured.

Press {Esc}, and click [Yes] in the confirmation dialog.

•

Press {Esc} to return to the [Print Server Configuration Menu].

•

Assign print queues to the crea ted printer as follows.

In the [Print Server Configuration Menu], select [Queues Serviced By Printer].

•

Select the printer created in the Step 12.

•

Press {Insert} to sele ct a queue se rviced by t he printer. You can se lect more than

•

one queue at a time.

Follow the instructions on the screen to make other necessary settings. When

•

you have finished the above steps, make sure that the queues are assigned.

Press {Esc} until “Exit?” appea rs, and Se lect [Yes] to exit PCONSOL E.

Start the print serve r by inputting as follows from the console of the NetWare Server.

If it is running, restart it after exiting it.

•

To exit, To start,

If the printer works as configure d, “Waiting for job” appears.

•

CAREE: unload pserver

CAREE: load pserver print_ser ver_na me

4 - 10 NetWare Configuration

Page 45

Netware 4.x, 5- Advanced Settings

To use Net Ware 5

Load the IPX protocol into the file server in advance.

•

You cannot use the NDPS (Novell Distributed Print Servic es ) mod e.

•

Basic Procedure

Installing the NIB Setup Tool

Print Server Remote Printer

Configuring the Network Interface Board

Configuring the NetWare

Netware 4.x, 5- Advanced Settings

Turning the power

off and on

Preparation

This section assumes NetWare is functional and that the nece ssary environment for the NetWare Print Service is available. You should install the client software released from Novell on the Windows before running the NWAdmin.

Setting Up as Print Server

You can set up the print server using the NDS or Bindery mode in NetWare 4.x, 5. The following procedure is for setting up the print server using the NDS mode in NetWare 4.1. When you set up the print server using the Bindery mode, use the NIC Setup Tool Wizard.

Start the Print Server

Run the NIC Setup Tool.

Click [Property Shee t] and click [OK].

The Browse dialog of the Network Interface Card appears.

•

Click [IPX protocol] .

NetWare Configuration 4 - 11

Page 46

Netware 4.x, 5- Advanced Settings

Select the IPX addres s of the Network Interface Card which is to be configured by clicking

it, and click [Next].

Note: If you don't know which Network Interface Card you are configuring, print the Configuration Page using the printer's operation panel, and select the MAC address that is on the page.

Confirm that the MAC and IPX addresses are correct, and click [Finish].

[NIC Setup Tool] window appears.

•

Click [Configure] .

The property sheet appears.

•

Click the [NetWare] tab, and make the following settings.

In the [Print Se rver N am e] b o x, en ter the n am e of the print ser ver.

•

In the [File Server Name] box, enter the name of the file se rver in which a print

•

server is to be created.Clicking [ Browse], you can select a file server among those listed in the Browse dialog.

In the [NDS Context] box, enter the context in which the print server is to be

•

created. Clicking [Browse], you can select a context among those listed in the Browse dialog.

Object names must be enter from a lower level and divided by a period. For

•

example, if you want to create a file server into NETWORK under DS, enter “NETWORK. DS”.

In the [Print Server Operation Mode] group, click [As Print Server].

•

Click [OK] to close the property sheet.

•

After a confirmation dialog appears, click [OK].

•

In the [NIC] menu, click [Exit] to exit the NIC Setup Tool.

From Windows, run NWAdmin.

The actual NWAdmin programs diffe r depending on the version of it and that of

•

the operating system. Run the NWADMIN.EXE except the following cases. When you are using the NetWare 4.11 or higher on Windows 3.1x, run the NWADMN3X.EXE. When you are using the IntranetWare on Windows95/98, run the NWADMN95.EXE. When you are using the Net-Ware 5, run the NWADMN32.EXE.

The NWAdmin programs are located in the PUBLIC directory in the SYS

•

volume. The NWADMN95.EXE is located in the PUBLIC\WIN95 directory.The NWADMN32.EXE is located in the PUBLIC\WIN32 directory.

4 - 12 NetWare Configuration

Page 47

For more information on NWAdmin, see the documentation that comes with the

•

NetWare.

Create a print queue as follows.

Select the con tai ner o bje ct the pr int queu e is locat ed in am o ng t hose i n the

•

directory tree, and click [Crea te] in the [Object] menu.

In the [Class of new object] box, click “Print Queue” to highlight it, and click

•

[OK].

In the [Print Queue name] box, enter the name of the print queue.

•

In the [Print Queue Volume] box, click Browse button.

•

In the [Available objects] box, click the volume in which the print queue is

•

created to highlight it, and click [OK].

Select the vo lum e on th e file s erver specified in the NIC Set u p Tool.

•

After confirming the settings, click [Create].

•

Create a printer as follows.

Select the container object the printer is located in, and click [Create] in the

•

[Object] menu.

In the [Class of new object] box, click “Printer” to highlight it, and click [OK].

•

When you are using the NetWare 5, click “Printer (Non NDPS)”.

In the [Printer name] box, enter the name of the prin ter.

•

Click [Define additiona l proper ties] to place ' mark, and click [Create].

•

Netware 4.x, 5- Advanced Settings

Assign print queues to the crea ted printer as follows.

Click [Assignments], and click [Add] in the [Assignments] group.

•

In the [A vaila ble obje cts] box, clic k the queue create d in the step K to high-li ght

•

it, and click [OK].

Click [Configuration], and in the [Printer type] box, select [Parallel] using the

•

drop-down menu, and then click [Communication].

Click [Manual load] in the [Communication type] group, and click [OK].

•

After confirming the settings, click [OK].

•

Create a print server as follows.

Select the context spe cified using the NIC Set up Tool, and in the [Obj ect] menu,

•

click [Create].

In the [Class of new object] box, click “Print Server” to highlight it, and click

•

[OK]. When you are using the NetWare 5, click “Print Sever (Non NDPS)”.

In the [Print Server name] box, enter the name of the print server.

•

Use the same n am e as th at speci fied u sing the N IC Setup Tool.

•

Click [Define additiona l proper ties] to place ' mark, and click [Create].

•

Assign the printer to the cre ated print server as follows.

NetWare Configuration 4 - 13

Page 48

Netware 4.x, 5- Advanced Settings

Click [Assignments], and click [Add] in the [Assignments] group.

•

In the [Available obje cts] box , cli ck the queue cr eated i n the s tep 11 to high-light

•

it, and click [OK].

After confirming the settings, click [OK].

•

Turn the printer power OFF and ON.

T o confirm if the printer is configured correctly, enter as foll ows from the

•

command prompt. F:> NLIST USER /A/B

If the printer works as configured, the name of the print server appears as an

•

attached user.

Setting Up as Remote Printer

Run the NIC Setup Tool.

Click [Property Shee t] and click [OK].

The Browse dialog of the Network Interface Card appears.

•

Click [IPX protocol] .

Select the IPX addres s of the Network Interface Card which is to be configured by clicking

it, and click [Next].

If you do not know which Network Interface Card you are configur in g, print the

•

Configuration Page using the printe r's operation panel, and select the MAC address that is on the page.

Confirm that the MAC and IPX addresses are correct, and click [Finish].

[NIC Setup Tool] window appears.

•

Click [Configure] .

The property sheet appears.

•

Click the [NetWare] tab, and make the following settings.

In the [Print Se rver N am e] b o x, en ter the n am e of the print ser ver.

•

In the [File Server Name] box, enter the name of the file se rver in which a print

•

ser v e r is to be created.

as follow s.

4 - 14 NetWare Configuration

Page 49

Clicking [Browse], you can select a file server among those list ed in the Browse

•

dialog.

In the [NDS Context] box, enter the context in which the print server is to be

•

created.

Clicking [Browse], you can select a conte xt among those listed in the Browse

•

dialog.

Object names must be entered from a lower level and divided by a period. For

•

example, if you want to create a file server into NETWORK under DS, enter “NETWORK. DS”.

In the [Print Server Operation Mode] group, click [As Remote Printer].

•

In the [Remote Printer No.] box, enter the number of the printer.

•

Use the same number as that of the printer to be created in the print server.

•

Click [OK] to close the property sheet.

•

After a confirmation dialog appears, click [OK].

•

In the [NIC] menu, click [Exit] to exit the NIC Setup Tool.

From Windows, run NWAdmin.

Netware 4.x, 5- Advanced Settings

The actual NWAdmin programs diffe r depending on the version of it and that of

•

The NWAdmin programs are located in the PUBLIC directory in the SYS

•

volume. The NWADMN95.EXE is located in the PUBLIC\WIN95 directo ry. The NWADMN32.EXE is located in the PUBLIC\WIN32 directory.

Create a print queue as follows.

Select the con tai ner o bje ct the pr int queu e is locat ed in am o ng t hose i n the

•

directory tree, and click [Crea te] in the [Object] menu.

In the [Class of new object] box, click “Print Queue” to highlight it, and click

•

[OK].

In the [Print Queue name] box, enter the name of the print queue.

•

In the [Print Queue Volume] box, click Browse button.

•

In the [Available objects] box, click the volume in which the print queue is

•

created to highlight it, and click [OK].

After confirming the settings, click [Create].

•

Create a printer as follows.

Select the container object the printer is located in, and click [Create] in the

•

[Object] menu.

In the [Class of new object] box, click “Printer” to highlight it, and click [OK].

•

NetWare Configuration 4 - 15

Page 50

Netware 4.x, 5- Advanced Settings

When you are using the NetWare 5, click “Printer (Non NDPS)”.

In the [Printer name] box, enter the name of the prin ter.

•

Click [Define additiona l proper ties] to place mark, and click [Create].

•

Assign print queues to the crea ted printer as follows.

Click [Assignments], and click [Add] in the [Assignments] group.

•

In the [Available obje cts] box , cli ck the queue cr eated i n the s tep 11 to high-light

•

it, and click [OK].

Click [Configuration], and in the [Printer type] box, select [Parallel] using the

•

drop-down menu, and then click [Communication].

Click [Manual load] in the [Communication type] group, and click [OK].

•

After confirming the settings, click [OK].

•

Create a print server as follows.

Select the context spe cified using the NIC Set up Tool, and in the [Obj ect] menu,

•

click [Create].

In the [Class of new object] box, click “Print Server” to highlight it, and click

•

[OK]. When you are using the NetWare 5, click “Print Sever (Non NDPS)”.

In the [Print Server name] box, enter the name of the print server.

•

Use the same n am e as th at speci fied u sing the N IC Setup Tool.

•

Click [Define additiona l proper ties] to place ' mark, and click [Create].

•

Assign the printer to the cre ated print server as follows.

Click [Assignments], and click [Add] in the [Assignments] group.

•

In the [Available objects] box, click the queue crea ted in the step 12 to high-

•

light it, and click [OK].

In the [Printers] group, click the printer assigned and to high-light it, and click

•

[Printer N umb e r].

Enter the printer number and click [OK].

•

Use the same number as that specified as Remote Printer No. using the NIC

•

Setup T ool.

After confirming the settings, click [OK].

•

Start the print serve r by inputting as follows from the console of the NetWare Server.

If it is running, restart it after exiting it.

•

To exit CAREE: unload pserver To start CAREE: load pser ver pr int _s erver_name

4 - 16 NetWare Configuration

Page 51

Setting Up a Client Computer

This section describes how to set up a client computer when you use a NetWare print server. This section assumes that the client has NetWare cl ient applications installed and is correct ly configured to communicate with a NetWare print server. If not, install the necessary applications before sta rting the setting up procedure.

Windows 95/98

Follow these steps to set up a Wi ndows 95/98 client.

•

Install the print er driver of the printer you want to use as “Local printer”.

For more information on installing the printer driver, refer to the Operator Guide

•

for your printer.

Any port is selected during the installation, however, LPT1 is recommended.

•

Setting Up a Client Computer

Click [Start], point to [Settings], and then click [Printers ].

In the [Printers] window, select the icon of the printer you want to use by clicking it.

On the [File] menu, click [Properties].

Click [Details] tab, and click [Add Port].

Click [Network] and click [Browse].

On the network tree, double-click the name of the computer used as the print server.

The names of the printers attached to the network are displayed.

•

Click the queue you want to print to highlight it, and click [OK].

Click [OK].

In the [Print to the following port] box, a network path to the printer appears.

•

Click [OK] to close the printer 's property, and again, open it.

Click the [Printer Settings] tab.

Remove the ' marks from the [Form feed] and the [Enable banner] check boxes.

You should not check these boxes, since they should be specified using the

•

printer driver. If they are checked, the printer might not print correctly.

NetWare Configuration 4 - 17

Page 52

Setting Up a Client Computer

When Using the PostScript Printer Driver

Follow these steps to set up for the PostScript Printe r Driver

Click the [PostScript] ta b.

•

Click [Advanced].

•

Remove the ' marks from the [Send CTRL+D before job] and the [Send

•

CTRL+D after job] check boxes.

Click [OK] to close the propert y.

Windows 3.1x

Follow these steps to set up a Wi ndows 3.1x c lient.

Install the print er driver of the printer you want to use as “Local printer”.

For more information on installing the printer driver, refer to the Operator Guide

•

for your printer.

Double-click the [Pr inters] icon of [Control Panel].

In the [Installe d Printers] box, select the printer driver you want to use by clicking it, and

then, click [Connect].

In the [Ports] box, click [LPT1] to highlight it, and click [Network].

The Network driver dialog appears.

•

In the [Ports] box, click [LPT1] to highlight it, and in the [Resources] box, click the queue

you want to print to highlight it.

You should log in to the print server in order to see the pri nt queues.

•

Click [Capture].

The specified queue is captured to the LPT1.

•

Click [LPT Settings].

The [NetWare Settings] dialog appears.

•

4 - 18 NetWare Configuration

Page 53

Setting Up a Client Computer

Remove the × marks from the [Form feed] and the [Enable banner] check boxes.

You should not check these boxes, since they should be specified using the

•

printer driver. If they are checked, the printer might not print correctly.

Click [OK] to close the [NetWare Settings] dialog.

Close the Network driver.

Click [OK] to close the [Connect] dialog.

Click [Close] to close the [Printers] dialog.

NetWare Configuration 4 - 19

Page 54

Setting Up a Client Computer

Notes:

4 - 20 NetWare Configuration

Page 55

Chapter 5

Macintosh Configuration

Page 56

Chapter Overview

This chapter co vers :

•“Changing to EtherTalk” on page 5-1

•“Configuring the Print er” on page 5-2

•“Changing Printer Name” on page 5-2

•“Changing Zone” on page 5-2

Macintosh Configuration

Page 57

Configuring Macintosh

This chapter explains how to configu re a networ k printer in a Macintosh EtherT alk environment. The actual procedu res to configure a network printer are slightly different depending on the version of the Mac OS. This chapter describe s how to configure your printer for Mac OS 8. If you are using a different version, refer to the manual that comes with your version of the Mac OS for more information.

Configuring Macintosh

Basic Procedure

Changing to EtherTalk

Configuring the Printer

Changing Printer Names

Changing Zone

Note: To print from a Macintosh, the optional PostScript 3 is required.

Changing to EtherTalk

Follow these steps to configure a Macintosh computer to use EtherTalk.

Open [Control Panels] , and double-click the [AppleTalk] icon.

Select “Ethernet” from the [Connect via] pop-up menu.

If you change zones, select a name from the [zone ] pop-up menu.

Close the [AppleTalk] control panels.

Restart the Macintosh.

Macintosh Configuration 5 - 1

Page 58

Configuring Macintosh

Configuring the Printer

Use the operation panel to activate the EtherTal k protocol (factory default is active).

Changing Printer Name

If the network has several sa me model printe rs, the names will be the same.

will have their names changed slightly in the

Printers that have the same name will have their names changed slightly in the Chooser. For example, three printers named “printer” will appear in the chooser as “printer0”, “printer1” and “printer2”.

Use applications such as Appl e Pr inter Uti lity or Las erW ri ter Utili ty t o chang e printe r names in the Macintosh EtherTalk environment. These utilities are distributed by Apple Computer, Inc.

Changing Zone

It may be necessary to change the zone configuration. Use applications such as Apple Printer Utility or LaserWriter Utility to change the zone configuration in the Macintosh EtherTalk environment. These utilities are distributed by Apple Computer, Inc.

•

Follow these steps to use the Apple Printer Utility.

•

have the same name

If your Macintosh is configured to use TCP/IP, you can change the zone con-

figuration with a Web browser.

Insert the CD-ROM that comes with the printer int o your computer's CD-ROM

drive. Copy the “Zone Name.ps” file in the “Zone Name” folder to the hard disk. Open the copi ed “Zone Name ps” file using a text editor, and change the

“NewZone”, which is in the second line from the bottom, to the name of the

new zone.

%!PS-Adobe2.0%

Title: Changing Zone (EtherNet only)

%%CreationDate: T ue Dec 16 1997

%%EndComments

true 0 startjob not {ERROR}if

(%EtherTalk%) << /EtherTalkZone (NewZone) >> setdevparams

%%EOF Save the “Zone Name.ps”. Run the Apple Printer Utility, and select the printer for which the new zone

name is to be used. Select the [Send PostScript File] in the [Utilities] menu, and send the “Zone

Name.ps” to th e prin t e r.

5 - 2 Macintosh Configuration

Page 59

Additional Functions

Chapter 6

Page 60

Chapter Overview

This Chapter covers:

•“Multi Direct Print” on page 6-1

•“Configuring NIC with Web Browser” on page 6-4

•“Assigning IP Address with ARP+PING” on page 6-7

•“Remote Maintenance by Telnet (mshell)” on page 6-8

•“SNMP” on page 6-16

•“Understanding Displayed I nformation” on page 6-17

•“Message List” on page 6-22

•“Precautions” on page 6-27

•“Network Configuration Page” on page 6-30

Additional Functions

Page 61

Multi Direct Print

Multi Direct Print is a Windows program that allows you to print on a Peer-to-Peer network. This program allows you to print directly to a network printer,

OS Protocol Stack

Microsoft Windows 95/98 The Microsoft version of TCP/IP that comes

Microsoft Windows NT 4.0

Note: If your printer is in the middle of wa rming up or printing, an error message

might appear a certain t ime a fter you reque st a pr int job . You can change how l ong

the printer should wait to display the message by clicking [Port Settings] in the

[Details] tab on Windows 95/98, and [Configure Port] in the [Ports] tab on

Windows NT4.0.

Multi Direct Print

even if there is no print s erve r.

with Windows. The Microsoft version of NetBEUI that comes with Windows.

Select Printer

A list of available printers appears on this screen.

1 2 3

4 5

Additional Functions 6 - 1

Page 62

Multi Direct Print

1. Printer Name

The contents of this list are diffe rent for TCP/IP and NetBEUI proto cols. If you selecte d [TCP/ IP], the printer name of the Netwo rk Inter face Card appeared . If yo u select ed [Net B E UI], the computer name of the Network Interface Card appeared.

Note: The printer name can be found on the printer configuration page.

Note: The printer name is set to “RNP” and the last 6 digits of the MAC address

of the Network Interface Card. For example, a board with a MAC address of

00:00:74:62:5C:65, would be named RNP625C65. You can change this name to

something more convenient.

2. Address

Note: The form of the Network path name is “%% computer name \ name of

printer type”.

3. Comments

Commen ts that are regi ste red on the Ne twork In terface Card

[Refresh]

Click to refresh the contents of the display. When refreshing, the name of this button changes to [Stop]. Click on it to stop the refresh.

[About]

Version and copyright information.

Protocol

Select to display the printers whic h can pr int using the selected protocol.

6 - 2 Additional Functions

Page 63

Network

Multi Direct Print

When you select a printer with the [Select Printer] dialog, the Port name is entered automatically.

Host name

If you print, usin g the TCP/I P protoc ol, to se lec t a printe r using a hos t na me or a doma in n a me, enter the nam e here. In-put the I P address into the [IP address] box when selecting a printer by IP ad-dress.

You cannot use a host name that begins with “%%”.

Note: When you use DHCP to assign IP ad-dresses to Network Interface Cards,

you can use a printer name (Current Host name on the network configuration

page) as the host name.

IP address

If you print, using the TCP/IP protocol. Ente r the IP address of the printer.

Printer name

Enter the printer's Network pat h name in form of “%%Computer name \Share name”. Do not enter “\\” as head characters but “%%”.

Additional Functions 6 - 3

Page 64

Configuring NIC with Web Browser

The Network Interface Card functions as a Web server in addit ion to allowing a printer to function as a network printer. You can use a Web browser to view the printer status and configure the Network Interfa c e Card.

Configuring the Printer

This facility requires TCP/I P to be installed. After the printer has been configure d to use the TCP/ IP protocol, it will be possible to adjust the settings using a web browser.

Operating System Browser Requirements

OS Browser

Miscrosoft Windows 95/98 Microsoft Internet Explorer 3.03/4.0

Microsoft Windows NT 3.51/4.0

Nescape Navigator 3.0/4.0

Mac OS 7.6.1-8.1

Solaris 2.5 - 2.6

Using Windows NT 3.51 with Internet Explorer 3.02 may cause problems.

•

Sometimes after clicking [Back], the previous page may not appear. In this case, click

•

[Refresh] or [Reload]. The text on the screen may disappe ar or be align ed incorrect ly if the f ont size sett ing s of

•

the browser are set to be to o large . It is recommended that you us e a font siz e equal to or

smaller than “10 point” with Netscape Navigator, and “Medium” or smaller with

Internet Explorer.

6 - 4 Additional Functions

Page 65

Going to the Top Page

After launching your Web browser, enter the IP address of the printer. See the example below. This example is for the English version. http://192.168.15.16/

(In this example. the IP address of the Network Interface Card is 192.168.15.16.)

Note: If a DNS server is u sed in the networ k, you c an enter the host name as a n URL. For example, http://webmoni tor.netprinter. com/. In order to do this, you must the register the IP address and host name of the Network Int erface Card with the DNS server. Consult the network administrator for information on how to do this.

Note: If the network uses proxy servers, the browser may run slowly.

Configuring NIC with Web Browser

1 2

Header Button

You can register favorite URLs with [URL]. To view the help section, click [Help].

Important: It costs to use the browser to access a website.

The help file is stored on the CD-ROM in HTML format.

•

Menu Button

Buttons to configure the Network Inte rfa ce Card and confirm the status of the printer.

When you click [Network Config], a dialog appear s requesting the user name and

•

password. Enter only the password in this dialog. The factory default password is

“password”. The password is the same as that used in the remote maintenance (mshell) and that used

•

in the NIC Setup Tool. If you change a password on the Web browser, the other

passwords are also changed.

Represent ation A rea

Displays the name and comments of the Network Interface Card, and the status of the printer.

Additional Functions 6 - 5

Page 66

Configuring NIC with Web Browser

Linking the address (URL) to the [Help] button

Y ou can l ink th e addre ss (URL) o f the [Help] b utton to th e help file s on y our computer or on a Web server.

Copy the help file on the CD-ROM to the desired location. The hel p files are located in

•

folders labe led with abbreviate d language names. For example, English help files are in

the "EN" folder. Be sure to copy the entire “EN” folder to the n e w lo ca ti o n . Using a web browser, navigate to the Top Page and click [Network config].

•

Enter your password, (it is not necessary to enter a user name) and cl ick [OK].

•

Enter the path to th e help file in the [Help URL] box. If you copied the help file to

•

"C:\HELP\EN" then ent er "f ile:/ /C: /HELP/ ". For exa mple i f you copi ed t he file to a web

server and the address ( URL) that will be linked to the help files is "http://a.b.c.d/HELP/

EN/index.html", enter "http://a.b.c.d/HELP/". Click [Apply].

•

When a warning message appears, select to continue configuring this procedure.

6 - 6 Additional Functions

Page 67

Assigning IP Address with ARP+PING

Using TCP/IP, you can assign the IP address using ARP and PING. The following example is for a BSD UNIX workstation (SunOS 4.x).

ARP+PING should be set to active in the network boot configuration before assigning the IP address using ARP+PING. For how to set it to active, refer to the Operating Instructions for your printer.

Use the ar p command to assign the IP address to the MAC address of the Network Interface

Card.

# arp -s 192.168.15.16 00:00:74:62:5C:65

•

192.168.15.16 is the IP address, 00:00:74:62:5C:65 is the MAC address.

•

Assign the IP address using the PING command.

# ping 192.168.15.16

•

Use the PING com mand again, to confirm the address.

# ping 192.168.15.16

•

If the address has been configured correctly, the following message appears.

192.168.15.16 is alive

•

If the address has been configured incorrectly, the following message appears.

no answer from 192.168.15.16

•

How to Confirm the MAC Address

The MAC address (Ethernet address) of the Network Interface Card is required in order to use ARP and PING to assign the IP address.iThe MAC address can be seen on the printer configuration page.

Additional Functions 6 - 7

Page 68

Remote Maintenance by Telnet (mshell)

You can view the printer status and configu re the Network Interface Card using telnet. You should specify a password so that only the network administrator, or a person having network administrator privi leges, can use remote maintenance (mshell).

Operation Flow

The following is a sample procedure in using Telnet.

Limitation Only one person at a time can be logged on to do remote maintenance.

Using the IP address or host name of the printer, start telnet.

% telnet IP_address

•

In order to use the host name instead of the I P address, you must wr ite it to the /e tc /hosts

•

file.

Enter the password.

The factory default is “password”.

•

Enter a command.

Finish telnet.

msh> logout

•

When the configuration is revised, a confirmation message requests whether or not the

changes should be saved.

Enter “yes” to save the changes, and press {Enter}.

If you do not want to save the changes, enter “no” and press {Enter}. If you want to

•

make additional changes, enter “return” at the command line, and press {Enter}. If the “Can not write NVRAM inf ormati on” message appears, the c hanges a re no t saved.

•

Repeat the steps above. The Network Interface Card is reset automatically when the settings are changed.

•

When the Network Interface Card is reset, the active print job which has already been

•

sent to the printe r, will finish printing. However, jobs that have not been sent yet will be

cancelled.

6 - 8 Additional Functions

Page 69

Command List

This is a list of commands that can be used by means of remote maintenance.

TCP/IP Address

Use the ifconfig command to configure TCP/IP (IP address, subnet mask, broadcast address, default gateway address).

Reference

msh> ifconfig

Configuration

msh> ifconfig le0 parameter address

Remote Maintenance by Telnet (mshell)

Note: Enter “help”, to see a list of commands that can be used. msh> help

Note: Enter “help command_name”, to display information on the syntax of that

command. msh> help command_name

Parameter Configuration Item

no parameter IP address

netmask aubnet mask

gateway default gateway address

The following is an example for configur ing an IP address of 192.168.15.16.

msh> ifconfig le0 192.168.15.16

The following is an example for configur ing a subnet mask of 255.255.255.0.

msh> ifconfig le0 netmask 255.255.255.0

This affects the conf iguration of the Network Board of the IP address that is used.

•

T o enter an address using hexadecimal, add “0x” to the first command.

•

Subne t Mask

A number used to mathematically “mask” or hide the IP address on the network by eliminating those parts of the address that are alike for all the machines on the network.

Default Ga te w a y Ad dres s

A gateway is a connection or interchange point that connects two networks. A gateway address is for the router or host computer used as a gateway.

T o get the above addresses, contact your network administ rator.

•

Additional Functions 6 - 9

Page 70

Remote Maintenance by Telnet (mshell)

Access Control

Use the acce ss command to view and co nfi g ure access control.

Reference

msh> acces s

Configuration

msh> access parameter address

Parameter Configuration Method

control Access Control Address

mask Access Control Mask

Notes:

The Access Control Address and the Access Control Mask are used to limit access to the

•

computer used for printing by denying access to users based on their IP address. If it is

not necessary to limit access, set the Access Control Mask to “0.0.0.0”. When the Access Control Address matches masked result of the IP address computer

•

attempting to print, print jobs from that IP address can be accepted by the Network

Interface Card. For example, if you assign 192.168.15. 16 as the Access Control Address to the Network

•

Interface Card, the combination of the Access Control Mask and the IP addresses that

can print are as follows. The XXX is a variable that means any number from 1 to 255 is

acceptable.

Access Control Mask IP Addresses that can

Access the Printer

255. 0. 0. 0 192.XXX.XXX.XXX

255.255. 0. 0 192.168.XXX.XXX

255.255.255. 0 196.196. 15.XXX

255.255.255.255 192.168. 15. 16

6 - 10 Additional Functions

Page 71

Remote Maintenance by Telnet (mshell)

Network Boot

Use the set command to configure a network boot.

msh> set parameter {on | off}

“On” means active and “Off” means inactive.

Parameter Configuration Method

ping ARP+PING

tftp RARP+TFTP

bootp BOOTP

dhcp DHCP

When you use RARP+TFTP, BOOTP, DHCP, the server also needs to be configured.

•

DHCP takes precedence over all other settings.

•

on | off}

Protocol

Use the set comm an d to allow /p re ve n t remo t e acce s s for eac h prot o col.

msh> set protocol {up | down}

Notes:

If you prohibit remote access using TCP/IP and then logout, you cannot use remote

•

access. If this was a mistake, you can use the printer operation panel to allow access by

TCP/IP. When you prevent access via TCP/IP, you are also prevented from using lpr, ftp, rsh,

•

diprint, and web.

Protocol Description

appletalk UP means active and Down

tcpip

netware

netbeui

lpr

ftp

rsh

diprint

web

means inactive.

Additional Functions 6 - 11

Page 72

Remote Maintenance by Telnet (mshell)

Status of Printer

The following commands can be used to get information about the current status of the printer.

msh> command

Command Information that is

Displayed

status Status of printer.

Information about the print job.

info Information about the paper

tray, output tray, emulation and program of printer.

prnlog (ID) Lists the last 10 print jobs

netstat Information on NIC

Note:

More information on the print job is displayed when the ID number is added after the

•

prnlog command.

Information about the Network Interface Card Configuration Settings

Use the show command to display the Network Interface Card configuration settings.

msh> show [-p ]

Note:

Add “-p” to the show command to have the information displayed one screen at a time.

•

System Log Information

Use the syslog command to display information stor e d in the printer's system log.

Note: msh> syslog

6 - 12 Additional Functions

Page 73

Remote Maintenance by Telnet (mshell)

SNMP

Use the snmp command to display and edit SNMP configuration settings such as the community name.

Note:

You can configure from No. 1 to 10 SNMP settings.

•

The factory default settings for No. 1 and 2 are as follows.

•

Number 1 2

community name public admin

IP address 0.0.0.0 0.0.0.0

access type read-only

Display

Shows the SNMP information and available protocols.

msh> snmp ? msh> snmp [-p] [registered_number]

Notes:

If the -p option is added, you can view the displays one by one.

•

If the registered number is not added, you can view the status of all the registered

•

numbers.

Community Name Configuration

You can set the community name of the Network Interface Card.

msh> snmp number name community_name

trap off

read-write trap off

Note

The community name must consist of 15 characters or less.

•

Additional Functions 6 - 13

Page 74

Remote Maintenance by Telnet (mshell)

Access T ype Configuration

You can select the access type from those lis ted below.

msh> snmp number type access_type

Protocol configur ation

You should use the following command to set the protocols to active or inactive. If you set a protocol to inactive, you cannot use all the registered numbers for it.

Access Type Type of Access which is Permitted

read Read only access is permitted

write Read and write access is permitted

trap User is notified of trap message

no All access is denied

msh> snmp {ip | ipx} {on | off}

“On” means activ e an d “Off” means inactive

•

If you want to change the protocol settings for each registered number, use the following command. Make sure that the protocol set to inactive using the above command, cannot set to be active using this command.

msh> snmp number active {ip | ipx} {on | off}

Access Configuration

You can configure an address of a host depending on the protoc ols used. The Network Interface Card accepts r equests only from hosts having ad-dre sses with access types of “read-only” or “read- write”. Enter “0” to have the Network Interface Card accept requests from any host without requiring a specific type of access.

The following example shows how set the protocol for an address.

msh> snmp number {ip | ipx} address

Note

When using the TCP/IP protocol, enter ip followed by a space and then the IP address.

•

When using the IPX/SPX protocol, enter ipx followed by a space and then the IPX

•

address followed by a decimal and then the MAC address of the Network Interface

Card.

6 - 14 Additional Functions

Page 75

Remote Maintenance by Telnet (mshell)

The following is an example of how to configure regist r ation number 3 with the IP address

192.168.15.16.

msh> snmp 3 ip 192.168.15.16

The following is an example of how to configure regist r ation number 3 with the IPX address 7390A448, and the MAC address 00:00:74:62:5C:65.

msh> snmp 3 ipx 7390A448.000074625C65

Changing the Password

Use the passwd command to change the remote maintenance password.

Be sure not to forget or lose the password.

•

The default factory passwor d is “password”.

•

Enter “passwd”.

msh> passwd

•

Enter the current pass word .

Old password:

•

Enter the new password.

New password:

•

Note: The password must consist of 3 to 8 alphanumeric characters and symbols.

Upper and lower case characters are considered unique. For example, R is

different from r.

The password is the same as that used in the configuration of the Network

Interface Card using a Web browser and that used in the NIC Setup Tool. If you

change a password on the mshell, the other passwords are also changed.

Enter the new password once again.

Retype new password.

•

Additional Functions 6 - 15

Page 76

SNMP

The Network Interface Card functions as a SNMP (Simple Network Management Protocol) agent using the UDP and IPX protocols.

Using the SNMP manager you can get information about the printer. The factory default community names are “public” and “admin”. You can get MIB information using these community names.

Limitation

The kinds of supported MIBs differ depending on your printer.

Supported MIBs

MIB-II

•

PrinterMIB

•

HostResourceMIB

•

LanierPrivateMIB

•

-Bold

6 - 16 Additional Functions

Page 77

Understanding Displayed Information

This section describes how to read the dis played information on the status of the Network Inte rface Card.

Print Job Information

The status of the print job can be viewed using the following commands.

mshell

Item Name Description

ID Number of the print request.

Source Name of the host requesting the print

job.

Process Type of print command.

Status Status of print job.

Active: Printing of being prepared for printing. Waiting: Waiting to be transferred to the printer.

Time The time when the print request was

received.

Additional Functions 6 - 17

Page 78

Understanding Displayed Information

Print Log Information

This is a record of jobs that have been printed up to now. The most recent ten records are displayed. This record can be displayed with the following commands.

mshell

Item Name Description

ID Number of the print request.

Source Name of the host requesting the print job.

Process Type of print command.

Bytes Size of the file in bytes.

Result Communication results.

OK: Indicates the print job was completed correctly. NG: Indicates the print job was not completed normally. Canceled: rcp, rsf, or lrp print commands were stopped. A problem occurred with the printing application. This message does not appear when ftp or PRINTER is used.

Time The time when the print request was received.

User The user name, workstation name, or address of

the host that sent the print job.

Address IP address

Process Type of print command used.

Print Start Time Time of print process was started.

Print End Time Time print process was completed.

Open Count Number of print process that the application made.

Eof Count Reception number of files unit.

Data Size Number of bytes of received data.

6 - 18 Additional Functions

Page 79

Network Statistical Information

This section is about the informat ion provided about the Network Interface Card. Detailed information about the words used to describe the status of the Network Interface Card are described below.

mshell

Item Name Description

System elapsed time Time that passed since the NIC started.

Total Printing Time Total time spent in processing the print data.

Total Open Count Total open (printing process) count that

Understanding Displayed Information

application required.

Current Connection Count

Total Connection Count

Print Error Count Number of times the printing process sent an

Access Error Count Number of times the connection was refused

Print Request Full Count

Number of print jobs connecting with the NIC.

Total number of print jobs sent to the NIC.

error message

because of the value of the access control.

Number of times a connection was refused because the number of print requests exceeded the number of allowed sessions.

Additional Functions 6 - 19

Page 80

Understanding Displayed Information

Configuring Network Interface Card

Network Interface Card settings can be displayed and confirmed using the commands below.

mshell

Item Name Description

Common Mode Protocol Up/Down AppleTalk TCP/IP NetWare NetBEUI NVRAM version Device name Comment Location Contact Soft switch

Up means active, Down means inactive.

Internal version number

AppleTalk Mode Net Object Type Zone

AppleTalk protocol in selection Network number Macintosh printer name Type of printer Name of the zone that the printer belongs to.

6 - 20 Additional Functions

Page 81

Understanding Displayed Information

Item Name Description

TCP/IP Mode ftp lpr rsh diprint web telnet download EncapType Network boot Filter Max DSTs Address Netmask Broadcast Gateway AccessCtrl AccessMask Time server Home page URL Home page link name SNMP

Up means active, Down means inactive

Frame type Network boot Internal parameter

IP address Subnet mask Broadcast address Default gateway address Access control address Access control mask

URL of homepage URL of help page Protocol used with SNMP

NetWare Mode Encap Type RPRINTER number RPRINTER name Print server name File server name Context name Switch Mode NDS/Bindery Packet negotiation Print timeout

NetBEUI Mode Switch Mode Direct print Notification Workgroup name Computer name Comment Share name 1

(This value is fixed) Frame type. Remote printer number. Remote printer name Print server name Name of the connect file server Context of print server

Active mode (This vale is fixed)

Time of the job timeout.

(This value is fixed)

(This value is fixed) (This value is fixed) Notices of finishing to print. Name of the workgroup. Name of the computer Comment. Share name. (name of the printer type.

Shell mode Mode of remote maintenance tool.

Additional Functions 6 - 21

Page 82

Message List

System Log Information

This is a list of messages recorded to the printer's system log. The system log can be viewed using the syslog command.

You can use the following methods to view the system log.

mshell Network Configuration Page: Configure PCL for the Printer Language, and push the switch

on the Network Interface Card for five seconds.

Message when Network Interface Card Starts or Restarts

Item Name Description

LANIER Network Interface Card ver.x.x.x Version number of the NIC

PRINTER SYSTEM “System Name” ver.x.x.x

Attach FileServer=”file server name” Printer is attached to “file server name”

Current Interface Speed:xxxMbps Speed of the network (10Mbps or 100

Current IPX address Current IPX address

FrameType=”frame type name” Frame type name is configured to be

NetBEUI Computer Name=”compter name”

Start httpd Web server has been started.

Start npmpd for IPX npmpd for IPX protocol has be started.

Start npmpd for TCP/IP npmpd for TCP/IP protocol has be

Start smpd direct print mode (NetBEUI) You can print from a client on the

System name and version of the printer

as the nearest server

Mbps)

used on NetWare.

NetBEUI Computer Name is defined as computer name.

started.

Windows network via the print server.

Start snmpd Ver 2.0 SNMP agent of the displayed version has

been started.

Vendor=, Country=, Lang= Vendor, country code, and language.

6 - 22 Additional Functions

Page 83

Netware - When the Networking Interface Board is Started

When Working as a Pri nt Se rv er

Item Name Description

Message List

Access to NetWare server File server name denied. Either there is no account for this print server on the NetWare server or the password was incorrect.

Attach to print queue print queue name. Attach to the print queue.

File server is empty The file server is not registered. Register

Open log file “file name” Specified log file has been opened.

Printer: printer name” has no queue The print queue is not assigned to the

Print queue “print queue name” cannot be serviced by printer 0, “print server name”

The print server received error “error number” during attempt to log in to the network. Access to the network was denied. Verify that the printer server name and password are correct.

Cannot log in to the file server. Confirm that the print server is registered on the file server. If a password is specified for the print server, delete it.

your file server using the utility.

Logged in to the file server with NDS or BINDERY mode.

printer. Using NWAdmin, assign the print queues to the printer and then restart it.

Print services are not available for the print queue. Confirm the volume of the print queue exists on the specified file server.

Cannot log in to the file server. The print server is not registered or the password is specified. Register the print server with out specifying a password.

When Working as a Remote Printer

Item Name Description

Cannot create service connection Cannot establish a connection with the

file server. Your request may exceed the maximum number of connections that the file server can deal with at a time.

Cannot find rprinter (“print server name”/”printer number”)

Establish a connection with the printer server, “print server name”.

Additional Functions 6 - 23

Printer having the number of displayed on the print server does not exist. Confirm the number of the printer register to the print server.

Connection with the printer server has been established.

Page 84

Message List

Item Name Description

No local target for “print server name” Cannot get routing information on the

file server. If a different frame type is configured from that used on the network, you should select “Auto Select” as a name type.

Required file server “file server name” not found.

Required printer server “printer server name” cannot be found.

Unable to attach to print server “print server name”

Cannot find the required file server.‘

Cannot find the printer server. COnfirm the name of the print server.

Cannot connect to the print server. The print server refuses a connection for some reason. Confirm the configuration of the print server.

NetBEUI When the Network Interface Card is Started

Item Name Description

Back to default name (computer name) The same computer name is detected on

the network. As unable to add computer name to the suffix, computer name back to default name. Configure a new computer name that is unique.

Print session full Cannot accept the print session.

Required computer name (COmputer name) is a duplicated name

The same computer name is detected on the network. The start job determines the computer name by adding the computer name to the suffix (0,1,...) Configure a new computer name that unique.

TCP/IP

When the Address is Configured

Item Name Description

Invalid gateway address The Gateway address is not correct for

the specified IP address.

6 - 24 Additional Functions

Page 85

When Using LPR

Item Name Description

filter data error Some data cannot be handled by the

lost connection The connection was cut by a

print request full Cannot accept the print request (max 5

printer permission denied Cannot get a permission to use the

Message List

filter option. COnfirm the file code and the settings of the filter option.

counterpart. Check the printer to which you request to print.

session). Confirm the status of the printer with mshell, and print it again after the print request becomes less than 5 sessions.

printer. Confirm the access rights with the access control address and the access control mask.

printer refuse Something is wrong with your printer.

Confirm the status of the printer.

Additional Functions 6 - 25

Page 86

Message List

When Using SNMP

Item Name Description

Exit snmpd The agent is complete. Reset the printer

or turn the printer off and on.

recvfrom: packet discarded, length (reception packet length) > (Packet size), from addr <Address of partner point>

session <Community name appointed> Name> from <Address>

snmpin: Bad use of session <community Name> from <Address>

snmpin: error in snmpdecipher, code (<ErrorNo.>)

snmpin: error in snmpservsend, code (<ErrorNo.>)

The received packet was ignored since the length of the packet exceeds the limit. Confirm whether the administrator station sent a packet whose length is longer than 1025 bytes.

The community name of the received packet is not defined. Confirm that the community name of the administration station is the same as that specified to the printer.

The community name of the received packet is not the same as that of the administration station. Confirm the community name specified to the printer.

An error occurred on the received packet. Check if the number of the objects sent from the administration station ism ore than 31 and if there are wrong MIB requests.

Cannot send a response packet. Normally this message is followed by other messages.

snmpin:pkt too large,code (<Error number>)

snmpin: error in sending too large request back,code (<Error number>),giving up

snmpin:received bad version The version of the received packet is

6 - 26 Additional Functions

The response packet to the request is too big to send. Reduce the number of the objects per request.

The packet notifying the error is too big to send. Reduce the number of the objects per request.

invalid. Confirm that the version of the administration station is the version 1(0).

Page 87

Precautions

Connecting a Dial Up Router to a Network

Correspondence Method on Network Administration

Filter the packets so that they do not pass over the dial up router.

The MAC address of the prin ter do ing the fil te ring is p rinte d on the print er c onfigura tion

•

page. Refer to the Operating Instructions for information on printing a configurat ion

page. See the instructions below for inf ormation on confi guring the prin ter if the router cannot

•

be configured.

Correspondence Method by Configuration of Printer (when using NetWare)

Following the setup method in this manua l, configure the file server.

Set the frame type for a NetWare environment.

Precautions

Correspondence Method by Configuration of Printer (when not using NetWare)

While not printing, the Network Interface Card sends packets on the net-work. Set the

NetWare to inactive.

When Printing PostScript from Windows

When printing PostScript from Windows, refer to the Operating Instructions that comes with the optional PostScript 3, and configure using the Network Interface Card with your printer driver.

When Printing with Netware

Configuration of Form Feed

When using NetWare, it is not necessary to configure for form feed. However, should not want to perform form feed, configure accor ding to OS as follows.

In case of Windows 3.1x, remove a check of [Form feed] in [Network Settings] dialog.

•

In case of Windo ws95/98, you remove a che ck of [Form feed ] with [Pr inter Setti ngs] tab

•

of property of printer.

Configuration of Banner Page

Please do not configure of banner page on NetWare. If you do not want to add the banner page, configure according to OS using it as follows.

In case of Windows 3.1x, remove a check of [Enable banner] in [Network Settings]

•

dialog.

Additional Functions 6 - 27

Page 88

Precautions

When Using DHCP

In case of Windows95/98, remove a check of [Enable banner] with [ Printer Settings] tab

•

of property of printer.

Printing after Resetting the Printer

After resetting the remote printer, the printer will be cut off from the print server for about 30-40 seconds before connecting again. Due to NetWare specification, print jobs may be accepted, but they will not be printed dur ing this tim e. When using the printer as a r emote pr inter, wait about two minutes after resetting the pri nter before attempting to print.

The following points are important when using DHCP (Dynamic Host Configuration Protocol).

Supported Systems

Windows NT Server 4.0 can be configured as a DHCP server.

Give the Printer a Static Address

Configure the DHCP server so the printer has a static address.

When multiple DHCP servers exist, turn an equal rese rvation into all DHCP server . A

•

Network Interface Card works by information from DHCP server replied to in the first

place.

Follow these steps to provide the prin ter with a static IP address.

Start the DHCP manager.

Select the scope that will be used, and on the [Scope] menu, click [Reservation].

Enter the IP address into [IP Addr ess ].

Enter the MAC address of the Network Interface Card into [Unique Identifier].

Do not use hyphens to separate the numbers.

•

If you don't know the MAC address, it can be f ound on the “configuration page” printed

•

by the printer.

Enter a name and comment into the [Client Name] and [Client Comment] boxes.

Click [Add].

An IP address is reserved.

•

Click [Close], to close dialog.

6 - 28 Additional Functions

Page 89

The Others

When you click [Active Lease] on the [Scope] menu of DHCP manager, a list of client

•

leases appears. When the reserved IP address is not assigned to a Network Interface

Board, a client name of this dialog appears as the name that was enter into with [Add

Reserved Clients] dialog. When the reserved IP address is assigned to a Network

Interface Card and comes to use it, an appearing cl ien t name changes in a printer name

configured by Network Interfac e Card. However, only 13 characters appear here from

the beginning of printer name.

•

When IP address is not assigned by the DHCP server, the Network Interface Card uses

•

11.22.33.44 as temporary IP address. You can confirm the printer's IP address on the

network configuration page. Because 11.22.33.44 is a special IP address, you cannot print using this addre ss.

•

When Using the NIC Setup Tool

If the Network Inter face Car d is not browsed using the TCP/I P prot ocol, che ck to see if the TCP/IP environment is correctly co nfi gured in your computer

Precautions

Additional Functions 6 - 29

Page 90

Network Configuration Page

You can confirm the network informatio n on the network configuration page.

Confirm that the printe r is online.

Push the switch on the Network Interf ace Card for two seconds, and release it.

The network configuration pag e is printed.

•

If you push the switch for five seconds, the syst em log information is printed.

Item Description Item

Node Number Soft Switch Printer Name

TCP/IP (Up) IP Address Netmask Gateway AccessCtrl AccessMask Auto IP (NBoot) Mode EncapType Current Hostname Current IP Address Current Netmask Current Gateway

NetWare (Up) IPX Address EncapType RPRINTER number Print Server Name File Server Name Mode

00:00:74:62:5c:65 0x41dc NET_PRINTER

192.168.015.016

255.255.255.000

000.000.000.000

000.000.000.000. (0x00000000)

000.000.000.000. (0x00000000) DHCP 0x40 0x01 DIX Ethernet II NET_PRINTER

192.168.015.018

255.255.255.000

000.000.000.000

7390A448:000074625C65 Auto 0 PSERV.NETWORK.DS FAREE Print Server

NetBEUI (Up) Switch Workgroup Name Computer Name Share Name Current Path Name

AppleTalk (Up) Mode Net Object Type Zone

6 - 30 Additional Functions

0x66 WORKGROUP NET_PRINTER IPSio_NX700 \\NET_PRINTER\IPSio_NX700

EtherTalk phase 2 0x3f7a IPSio NX700 LaserWriter *

Page 91

MAC address

Printer name

TCP/IP

•

NetWare

Network Configuration Page

IP address Subnet mask Default gateway addres s Access control address Access control mask Network boot (Command boot) Frame typ e *: The current configuration is displayed in DHCP active.

NetBEUI

AppleTalk

IPX address

•

Frame typ e

•

Remote printer number

•

Print server name

•

Name of the connect file serve r

•

Active mode

•

(this value is fixed)

•

Workgroup name

•

Computer name

•

Share name

•

Network path name

•

Network number

•

Macintosh printer name

•

The type of printer

•

Name of the zone that pr inter belong

•

Additional Functions 6 - 31

Page 92

Network Configuration Page

Notes:

6 - 32 Additional Functions

Page 93

Specifications

Chapter 7

Page 94

Chapter Overview

This chapter co vers:

•“Agency Ce rtif ic ation s ” on page 7-1

•“Specifications” on page 7-2

Specifications

Page 95

Agency Certifications

FCC

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecti on against harmful interference in a residential installation. This equipment generates, uses and can radia te radio interference to radio communications .

However, there is no guarantee that interference will not occur in a parti cular installation. If this equipment does cause harmful interference to radio or television receptio n, whic h can be determined by t urning the equipment OFF and ON, the user is encouraged to try to correct the interfere nc e by one or more of the following measures:

Re-orient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipm ent int o an ou tlet o n a circu it dif fe rent f rom t hat to which t he

•

receiver is connected. Consult the dealer or an experience d radio/TV technician for help.

•

Agency Certifications

WARNING:

CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED

BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

CAUTION When installed in a 100BaseTX environment, properly shielded and grounded cables (STP) and connectors must be used for connections to host computer (and/or peripheral) in order to meet FCC emission limits.

Declaration of Conformity

Product Name: Printer Controller Model Number: Type 185 E Responsible Party: Ricoh Corpora tion Address: 5 Dedrick Place, West Caldwell, NJ 07006 Telephone number: 973-882-2000 This device complies with part 15 of FCC Rules.

Canada

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.

Specifications 7 - 1

Page 96

Specifications

Item Description

LAN Interface 100BASE-TX, 10BASE-T

Frame Type EthernetII, IEEE802.2, IEEE802.3, SNAP

Protocol

SNMP MIB-II, PrinterMIB, HostResourceMIB, LanierPrivateMIB

IPX/SPX

NetWare 3.11, 3.12, 3.2, 4.1, 4.11, 5, IntranetWare

TCP/IP

Windows 95 WIndows 98 Windows NT 4.0

NetBEUI

Windows 95 Windows 98 Windows NT 4.0

AppleTalk

Mac OS 7.1 or later

7 - 2 Specifications

Page 97

Index

Page 98

Chapter Overview

Use the index to quick ly locate specific information about different topics.

Index

Page 99

Index of Network Interface Terms

Agency ce rtifications

Client computer

set up windows 3.1 windows 95/98

Configure

remote printer

Configuring

windows 95/98 Configuring macintosh Configuring NetBEUI

Printer

windows 95/98 computor Configuring TCP/IP

printer ConfiguringTPC/IP

windows 95/98 computer

3-7

2-3

2-2

4-17

4-18

1-5

4-17

2-1

DHCP

using Dial up router to network

connecting Displayed information

6-28

6-27

IP address

assigning with arp+ping

LPR port printing

configure

3-9

7-1

6-17

5-1

2-2

6-7

2-3

Macintosh

change printer name changing zone ethertalk

printer configure Message list Multi direct print

network

uninstall Multi direct print application

installing Multi direct printing

select printer

5-1

6-22

6-3

2-6

2-4

6-1

5-2

5-1

5-2

NetBEUI

protocol for printing NetBEUI protocol

configure for windwos NT

computer

preparing for printing Netware 3.x-advanced settings

print server se t up

remote printer set up Netware 4.x, 5

advanced settings

print server set up remote printer set up

Network connectio n

mult i direct p r in t app l ication

preparing

printer driver set up

printer drivers set up

unistalling multi direct print

Network statistical infor ma tion Netwrok configurati on page NIC

configure with web browser

configuring

running setup tool

3-1

application

6-20

4-6

4-2

3-3

2-3

3-3

4-8

3-4

3-6

6-30

4-11

3-5

6-19

6-4

4-14

3-4

4-1

4-3

NIC setup tool

quick set up running

Port name

NetBEUI protocol

Port name input

TCP/IP protocol Prin t lo g in f or mation Printer

set up in network Printer driver

set up Printer manager for administrator

installing Printing

netware prin t s er v er

with windows nt server

without print server

2-5

4-1

2-5

6-18

1-2

2-5

1-2

1-4

1-3

Remote prin ter

configure

1-5

SNMP Specifications System log in f or mation

6-16

7-2

6-22

TCP/IP

configure prin ter

configure windows NT compu ter

3-2

TCP/IP protocol

preparing for printing TCP/IP protocol for printing Telnet (mshell)

maintenance

6-8

3-2

2-2

Index I- 1

Page 100

Index of Network Interface Terms

I - 2 Index

Lanier 5227 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Introduction

Features

Setting Up the Printer in a Network

Printing without Using a Print Server

Printing with a Windows NT Server

Printing as a NetWare Print Server

Configuring Windows 95/98

Preparing to Use the TCP/IP Protocol for Printing

Preparing to Use the NetBEUI Protocol for Printing

Installing the Multi Direct Print Application

Setting Up the Printer Driver

Uninstalling the Multi Direct Print Application

Preparing for a Network Connection

Preparing to Use the TCP/IP Protocol for Printing

Preparing to Use the NetBEUI Protocol for Printing

Installing the Multi Direct Print Application

Setting Up the Printer Driver

Inputting the Port Name for use with the TCP/IP Protocol

Unistalling the Multi Direct Print Application

Setting Up a Client Computer

Windows 95/98

Windows NT 4.0

Configuring LPR Port Printing

NetWare Configuration

Installing the NIC Setup Tool

Installing the PRINTER MANAGER FOR ADMINISTRATOR

Running the NIC Setup Tool

Quick Setup Using the NIC Setup Tool Wizard

Netware 3.x - Advanced Settings

Setting Up as Print Server

Setting Up as Remote Printer

Netware 4.x, 5- Advanced Settings

Setting Up as Print Server

Setting Up as Remote Printer

Setting Up a Client Computer

Windows 95/98

Windows 3.1x

Macintosh Configuration

Configuring Macintosh

Changing to EtherTalk

Configuring the Printer

Changing Printer Name

Changing Zone

Additional Functions

Multi Direct Print

Select Printer

Network

Configuring NIC with Web Browser

Going to the Top Page

Assigning IP Address with ARP+PING

Remote Maintenance by Telnet (mshell)

Operation Flow

Command List

SNMP

Understanding Displayed Information

Print Job Information

Print Log Information

Network Statistical Information

Configuring Network Interface Card

Message List

System Log Information

Precautions

Connecting a Dial Up Router to a Network

When Printing PostScript from Windows

When Printing with Netware

When Using DHCP

When Using the NIC Setup Tool

Network Configuration Page

Specifications

Agency Certifications

Specifications

Index

Index of Network Interface Terms
