ELECTRIC HALF SIZE

COMPUTERIZED

CONVECTION OVEN

ECOH-PP

Installation and

Operation

Instructions

2M-W494 Rev. E 3/24/15

ECOH-PP

IL1475

SAFETY SYMBOL

These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance.

DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN

INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS

INFORMATION SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS SUPPLIER.

AS A MINIMUM, TURN OFF THE GAS AND CALL YOUR GAS COMPANY AND YOUR

AUTHORIZED SERVICE AGENT. EVACUATE ALL PERSONNEL FROM THE AREA.

IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE

CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION,

OPERATION & MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR

WARNING, TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE

CONTROL PANEL. NO USER-SERVICABLE PARTS INSIDE. REPAIRS SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY.

FOR YOUR SAFTEY

THE VICINTIY OF THIS OR ANY OTHER APPLIANCE.

POST IN PROMINENT LOCATION

WARNING

SERVICING THIS EQUIPMENT.

WARNING

RISK OF FIRE OR ELECTRIC SHOCK

DO NOT OPEN

NOTICE

Using any part other than genuine Lang factory supplied parts relieves the manufacturer of all liability.

Lang reserves the right to change specications and product design without notice. Such

revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.

Due to periodic changes in designs, methods, procedures, policies and regulations,

the specications contained in this sheet are subject to change without notice. While Lang exercises good faith efforts to provide information that is accurate, we are not

responsible for errors or omissions in information provided or conclusions reached as a

result of using the specications. By using the information provided, the user assumes all risks in connection with such use.

MAINTENANCE AND REPAIRS

Contact your local dealer for service or required maintenance. Please record the model number, serial

number, voltage and purchase & Installation Information in the area below and have it ready when you

call to ensure a faster service.

Model No.:

Serial No.:

Voltage:

Purchased From:

Location:

Purchase

Date:

1-Phase

or 3 Phase:

Installed Date:

PROBLEMS, QUESTIONS or CONCERNS

Before you proceed consult you authorized Lang service agent directory

Call the Lang Technical Service & Parts Department at 314-678-6315.

TABLE OF CONTENTS

Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Equipment Description . . . . . . . . . . . . . . . . . . . . . . . . 5

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installation

Leg Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Stacking the Oven . . . . . . . . . . . . . . . . . . . . . . . . . 7

Ventilation & Clearance . . . . . . . . . . . . . . . . . . . . . . 8

Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . 8

Oven Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Reversing the door . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Initial Start-Up

Pre-Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

General Operation & Programming

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Daily Operation . . . . . . . . . . . . . . . . . . . . . . . . . .13

Program Menu Record Table . . . . . . . . . . . . . . . . . . . 14

Programming Procedures . . . . . . . . . . . . . . . . . . . . 15-16

Maintenance / Cleaning . . . . . . . . . . . . . . . . . . . . . . 17

Troubleshooting

Symptoms & Possible Causes . . . . . . . . . . . . . . . . . .18

Wiring Diagram

ECOH-PP 208-240V WD61111-147 . . . . . . . . . . . . . . . . 19

ECOH-PP 220-380V, 240V-415V w 2SPD CE WD61111-170 . .20

ECOH-PP 220-380V, 240-415V WD61111-151 . . . . . . . . . . 21

ECOH-PP 480V WD61111-168 . . . . . . . . . . . . . . . . . . 22

Exploded View & Parts List . . . . . . . . . . . . . . . . . . . . . 24-34

NOTICE ServiceonthisoranyotherLangappliancemustbeperformedbyqualied

personnel only. Consult your Lang Authorized Service Agent Directory. You can call our tech service number 314-678-6315 or visit our website www.langworld.com for the service agent nearest you.

SPECIFICATIONS

30.2”

25.3”

30.2”

Model Height x Width x Depth Clearance from Weight (without optional stand) combustible surface Installed Shipping Freight Class

ECOH 25.3” x 30.2” x 25.3” Side: 6”, Back: 6”, Floor: 6” 185 lbs. 225lbs 85

642mm x 766mm x 643mm (84 kg) (102 kg)

766mm

25.3”

642mm

53.3”

1353mm

28.0”

711mm

STAND OPTIONAL

Front Side View Top ViewRight Side View

643mm

25.3”

642mm

28.0”

711mm

3.0”

76mm

Electrical Connection

766mm

25.3”

642mm

ElectricalSpecications

Model No VOLTS AC Hz.

MOTOR

AMPS PHASE

AMPS 3PH/

NTRAL

TOT.

AMPS

1 PH

WIRE

1 PH L1 L2 L3

ECOH-PP2/4BK 240/415 50/60 3.3 3PH 11 7.8 11 10.5 10.5 12

ECOH-PP208BK 208 60 3.3 1/3 7.8 38 8 23 21 23 10

ECOH-PP208BR 208 60 3.3 1/3 7.8 38 8 23 21 23 10

ECOH-PP-208V 208 60 3.3 1/3 7.8 38 8 23 21 23 10

ECOH-PP-240V 240 60 2.6 13 7.8 33 8 20 18 20 12

ECOH-PP208WB 208 60 3.3 1/3 7.8 38 8 23 21 23 10

ECOH-PP240BK 240 60 2.6 1/3 7.8 33 8 20 18 20 12

ECOH-PP240WB 240 60 2.6 1/3 7.8 33 8 20 18 20 12

IL1454

20.8” 529m

WIRE

3 PH

EQUIPMENT DESCRIPTION

Exterior Construction

The Top, Front, Back, and Sides are constructed of stainless steel with an aluminized bottom.

The oven exterior dimensions are:

30” (76.2 cm) Wide,

25.25” (74.3 cm) High,

26.5” (67.31 cm) Deep.

The oven door comes standard with a high temperature insulated window equipped with a polycarbonate handle.

The oven cavity is insulated with high

temperature insulation for efciency

and reduced heat loss.

Door Handle

Controls

Interior Construction

The oven is designed for ve shelves and comes with ve Chrome Plated

Racks.

The interior cooking chamber is constructed of stainless steel with dimensions of:

15” (38.1 cm) Wide, 20” (50.84 cm) High, 21” (53.38 cm) Deep.

Width

Depth

Back-Up Controls

Motor Cover

Height

IL1455

NOTICE

Operation

The ECOH oven is a forced air convection oven with a vented oven cavity.

The air is driven by a 1/3 HP fan motor.

Controls

Pre-Programmable Product Selections

Independent Shelf Timers for each Shelf.

Shelf Compensation Timing for uniform baking.

Technical

Oven operates as shipped 208V, or 240V (single or three phase), or 480V (three phase).

The oven can be shipped with a Power Cord and Plug attached, but must be specied upon ordering

(part number is listed in the Parts portion of this manual).

Floor space required is 42” (106.68cm) Wide, 32.5” (82.55cm) Deep.

The oven weighs approximately 225 lb. (102.5 Kilograms).

The ovens are stackable, stacking kit available upon request.

The data plate is on the back side of the oven above the power cord.

The oven voltage, wattage, serial number, wire size, and clearance

specicationsareonthedataplate.Thisinformationshouldbecarefullyread

and understood before proceeding with the installation.

CAUTION

UNPACKING

Receiving the Oven

Upon receipt, check for freight damage, both visible and concealed. Visible damage should be noted on the freight bill at the time of delivery and signed by the carrier’s agent. Concealed loss or damage means it does not become apparent until the merchandise has been unpacked. If concealed loss or damage is discovered upon unpacking, make a written request for inspection by the carrier’s agent within 15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Star Manufacturing Company. File your claim with the carrier.

Location

Prior to un-crating, move the oven as near to its intended location as practical. The crating will help protect the unit from the physical damage normally associated with moving it through hallways and doorways.

Un-crating

The oven will arrive completely assembled inside a wood frame and strapped to a skid. Cut the straps and remove the wood frame.

The oven can now be removed from the skid.

THE UNIT IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION.

ANY STAND, COUNTER OR OTHER DEVICE ON WHICH OVEN WILL BE LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE OVEN.

SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN CUT.

Leg

Mounting Hole

4” Leg

INSTALLATION

16” or 28”

Stand

Cardboard

Leg Installation

4” legs are available for single countertop installations. Single and double deck installations require 16” or 28” stand installation, casters may also be used in certain situations.

To install the 4” legs, place some

cardboard on the oor and gently tip

the unit onto its back. Fasten the four, 4” legs into the threaded holes located on the bottom of the unit. Gently lift the oven into its operating position.

IL1430

16” & 28” stand installation, after following the assembly instructions that were provided with the stand, gently lower unit on to some cardboard as shown here. Align the stand with the bottom of the unit and secure with the hardware provided. With the assistance of carefully raise the unit to its vertical position.

Stacking the Ovens

Two alignment pins (pn: 2C-20108-11) are needed if you intend on stacking two ECOH on each other as shown. These pins must be requested at the time of purchase, or call your Lang authorized service agent, or Lang parts department at 314-678-6315.

Having completed the previous step remove any and all button plugs from the lower unit, so the upper unit will lay properly.

Lay the upper unit on its back and screw the alignment pins into the two rear holes.

With assistance lift the upper unit onto the lower unit, being certain that the alignment pins go into the alignment holes, as shown here.

NOTE: Each unit must have separate electrical connections

Alignment Pins

pn: 2C-20108-11

Alignment Hole

IL1431

INSTALLATION continued

Ventilation and Clearances

Standard minimum clearance from combustible construction is as follows.

4” from side

4” from back

6” from oor

• These ovens may be set directly, without legs, on a curbed base or non-combustible oor.

• If the oven is set without legs on a non-combustible oor or a curbed base, maintain a 4-inch back

clearance.

• If the oven is set directly against a non-combustible back wall, maintain a 6-inch clearance to the oor.

• Do not install the oven closer than 12 inches from an uncontrolled heat source (char broiler etc.) on the right side.

• Keep the area free & clear of combustible material, and do not obstruct the ow of combustion or

ventilation air.

• The installation of any components such as a vent hood, grease extractors, and/or re extinguisher

systems, must conform to the applicable nationally recognized installation standards.

NOTICE The installation of any components such as a vent hood, grease

extractors,reextinguishersystems,mustconformtotheir applicable National, State and locally recognized installation standards.

WARNING

Electrical Connection

The electrical connection must be made in accordance with local codes or in the absence of local codes with NFPA No. 70 latest edition (in Canada use: CSA STD. C22.1).

The electrical service entrance is provided by a 1 1/4-inch knockout at the oven back directly behind the control compartment. A grounding lug is provided at the rear service entrance.

Certain units are provided with or can be purchased with a Cord & Plug kit (Part number 9Q-ECOH- CK). This kit includes a 48” cord with a NEMA L15-30P plug and is for 3 Phase units ONLY. In stacked situations each units needs to have separate cord & plug assemblies.

Oven Voltage

The Lang Model ECOH ovens can be operated on 208, 240-volt (single or three phase), or 240/415V,

480-volt (three phase only) source. The Amp draw, KW rating, and phasing can be found in specication

section of this manual or on the nameplate attached to the unit..

THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH.

INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT MUST BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE CODES.

Reversing the door

1. Disconnect oven from power.

2. Remove the top and bottom door hinge covers (4) by removing the two 10-32 Phillip head screws (8).

3. Remove the top door hinge bracket (1) from the oven by removing the two ¼-20 Phillip head screws (7). The hinge should now slide off of the door pin (this will now be your right hand lower hinge)

4. Lift the door off the bottom pin and set aside.

5. Remove the bottom door hinge bracket (2) by removing the two ¼-20 Phillip head screws (7) (this will now be your upper right hand hinge).

6. Remove the lower hinge mounting plate (9) by pulling it from behind the leg pad adapter on the bottom of the oven.

7. Remove the two Phillips head screws in the bottom right corner of the oven, where the new hinge will be placed.

8. Slide the hinge mounting plate (9) into place and mount the hinge bracket (this should be your old upper hinge) using two ¼-20 (7) Phillips head screws.

9. Remove the two Phillips head screws in the upper right corner of the oven where the new hinge will be placed.

10. Rotate the door 180° and slide the door pin into the bottom hinge bracket.

11. Slide the upper door hinge (1) onto the upper door pin and then screw into place using two ¼-20 Phillip head screws.

12. Place the top and bottom door hinge covers (4) back on the oven using two 10-32 Phillip head screws (8).

IL1426

ECOH HINGE RELPACEMENT KIT

pn: Q9-50313-030

ITEM NO. QTY. PART NO. DESCRIPTION

3 4 5

6 7 8 9

50313-031

EH-267

70201-19

70201-01

20109-43

20109-15

eh-198-1

CR30-148

EH-265-1

1 1 EH-266-1

INSERT BEARINGS (ITEMS "5") INTO THE HINGES (ITEMS "1" & "2") AS SHOWN THEN REAM WITH A .508 REAMER.

HINGE PIN WELDMENT EH HINGE COVER

BOTTOM HINGE PLATE ASSY UPPER HINGE COVER FOR EH EH HINGE - TOP - FOR SVC KIT EH HINGE - BOTTOM - FOR SVC KIT

INITIAL START UP

Pre-Power On

After the oven is installed and connected to power, prior to turning on, verify the following

• The door opens and closes freely

• All racks are in the oven correctly

• All packing materials have been removed from the inside of the oven

Power On

Once the oven has been turned on verify that the blower wheel is spinning freely in a clockwise position and that the elements are heating properly.

Switch the back-up controls on and make certain it can run the unit,

Conrm that the thermostat

knob in the back-up controls is move freely.

Blower Wheel

NOTICE

USB Connection

Units are now supplied with a USB connection, located with the the Back-Up Controls. This is for future programming needs of your unit and is not part of the units initial start-up or daily operation.

Back-Up Controls

IL1456

Duringtherstfewhoursofoperationyoumaynoticeasmallamountofsmoke

coming from the oven, and a faint odor from the smoke.

Thisisnormalforanewunitandwilldisappearaftertherstfewhoursofuse.

General Operation & Programming cont.

ECOH-PP Control Panel

The control panel consists of the following items. Detailed operational descriptions are given later this section.

Power Switch: Turns the oven on and off

Alpha Numeric Display: Displays your interface with the computer.

Product Select Button: Each button can be

programmed for a specic menu, see programming section to see how.

Shelf Select Button: Press to select which shelf the product will be placed on. “A” is the top position, “E” is the bottom position.

Manual Program Button: Used when product being cooked is for one time only.

Read / Clear Button: Used to read programs, clear programs, and to access program menus.

Typical Operation Sequence

Action Result

Turn power switch to ON.

Press a product button.

Beeper sounds briey.

Open the oven doors and load the product. Close the door and press the product button again.

Press the shelf button(s) which correspond to the shelf positions, which the product is loaded (A equals the top shelf and E equals the bottom shelf).

Beeper sounds continuously.

Press the ashing shelf button(s).

Open oven door and remove the product, which corresponds to

ashing shelf button(s).

Control panel comes on; display says “SELECT PRODUCT or READ/CLEAR TO

PROGRAM.

Display says “PRODUCT X PREHEATING TO XXX F”. Motor starts and

oven begins preheating to the programmed temperature.

Display says “READY

SELECT PRODUCT TO START ”.

Beeper sounds briey and

display says, “SELECT OVEN SHELVES PRODUCT X”.

Display shows a countdown timer and begins to count toward zero.

Display shows “DONE

PRESS SHELF BUTTON X, REMOVE PRODUCT”,

shelf button(s) ash.

Beeper stops. Display shows

“READY SELECT PRODUCT TO START” if

no other shelves carry product or resume count down for shelves that still have product cooking.

Power Switch

AlphaNumeric Display

Product Select

Shelf Select

Manual Program

Read/Clear

IL1458

General Operation & Programming cont.

Here are some things to remember when loading your oven.

• When loading and unloading the oven, stage products and racks so the oven door is opened for the least amount of time.

• Be sure that racks are level within the oven.

• Bent or warped pans can greatly affect the evenness of the cook or bake.

• If using baker’s parchment, be sure the parchment does not blow over the product. That will create an uneven bake.

• Load each shelf evenly. Spaces should be maintained equally between the pan and oven walls, front and back.

• Do not overload pan’s this will create an uneven bake.

• For best baking results, load the oven from the center out during random loading.

ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM

COMBUSTIBLE MATERIALS.

KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS OCCUR,

CAUTION

CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR FALLS.

IL1459

IL1462

IL1463

IL1462

IL1465

IL1466

DAILY OPERATION PURPLE PLUS

CONVECTION OVENS

ECOH-PP, ECOF-PP, GCOF-PP,

EHS-PP, ECCO-PP, GCCO-PP

Daily Operation

Step 1: Turn the Power Switch on by switching

the toggle switch to the up position. Step 2: Screen will appear as below. Select the product you wish to bake by pressing the number key (0-9) for that product.

SELECT PRODUCT OR READ/CLEAR TO PROGRAM XX:XX PM XXX F

Step 3: Screen will display:

When the oven reaches the desired temperature, the screen will display:

PRODUCT 1 PREHEATING TO XXX F XX:XX PM XXX F

IL1460

Step 4: Open the oven door, place product in the oven. Close the oven door and press the program key you are using.

READY SELECT PRODUCT TO START XX:XX PM XXX F

IL1461

Step 5: The display will now read:

Press the lettered keys indicating what shelves

If you do not select a shelf, the oven will beep and the following display will appear:

NO SHELF SELECTED PRESS E TO CONTINUE

Press the E Key and the previous display will appear, again asking to select oven shelves

Step 6: Once a shelf or shelves have been selected, the display will now read:

COOKING PRODUCT XX TIER #1 XX:XX:XX SELECT PRODUCT XX:XX PM XXX F

At this time, you may select any other pre-set product program which has the same oven temperature. A lighted red light next to a numbered product key indicates that the program is compatible with the program selected, and can be run at the same time.

Step 7: When the bake time is concluded, the oven will beep and the display will read:

DONE PRESS SHELF BUTTON REMOVE PRODUCT XX:XX PM XXX F

SELECT OVEN SHELVES PRODUCT 1 XXXF XX:XX:XX XX:XX PM XXX F

you placed product on to bake (A is the top shelf).

Step 8:

Once you have completed baking on

one pre-set program, you may change to another pre-set program by pressing the Read/Clear Key.

The display will now read:

SELECT PRODUCT OR READ/CLEAR TO PROGRAM

ex: Biscuits 325°F 12:30 50% HI 100%

Temp

Time

Curve

Speed

Rate

Product

Name

Cooking

Tier 1 Tier 2 Tier 3 Tier 4

Fan

Pulse

Record your specic menu items using the table below, prior to entering them

Cooking

Temp

Cooking

Time

Cooking

Curve

Speed

Fan

Pulse

Rate

Cooking

Temp

Cooking

Time

Cooking

Curve

Speed

Fan

Record Your Menus Before Entering Your Program.

into your units program. Keep for your records.

ECOH-PP, ECOF-PP, GCOF-PP,

EHS-PP, ECCO-PP, GCCO-PP

PROGRAMMING PURPLE PLUS

CONVECTION OVENS

Pulse

Rate

Cooking

Temp

Cooking

Time

Cooking

Curve

Speed

Fan

Pulse

Rate

PROGRAMMING PURPLE PLUS CONVECTION OVENS

ECOH-PP, ECOF-PP, GCOF-PP,

EHS-PP, ECCO-PP, GCCO-PP

Before You Begin Programming

1. For programming new ovens, you must program at least one button (position 2 through 0) before you can delete or replace the sample program in position one.

2. If you are programming for the rst time after installing a new computer board, or blanking the EPROM, you must rst complete the “CPU Start Up Procedure” that came with the new computer board before programming the

product buttons

3. In preparation of programming you Purple Plus Oven, rst determine the cooking parameters you will be using

for each product to be programmed. Use the table on the following page to record your programs prior to entering them into your unit.

CPU Start Up Procedures

If you are programming for the rst time after installing a new computer board, or needed to blank the EPROM, you

will be asked to complete the “CPU Start Up Procedures”. You will be asked to identify the oven you are using, answer NO to questions regarding Steam and Rack Rotation, and 650°F max temperature.

Programming Procedures

PROGRAMMING PROCEDURES

ACTION DISPLAY

SELECT PRODUCT OR

Turn the power switch on. If the oven is already on, press the Read / Clear key until the following screen is displayed.

Enter access code “1 6 2 7 3 8”.

Select “B”.

Select a number from 0-9 and press the key corresponding to that number. PRODUCT PROGRAM MODE NOTE: If a product Key selected already has a program, the screen will read. SELECT PRODUCT

If a product Key dose not have a program, the screen will read.

Enter a desired cooking / baking temperature. The screen will automatically advance to the next display.

Enter the cooking time and then press “E” to advance to the next screen.

Enter the desired cooking curve. (Refer to sections 6.3 and 6.7 for more detail)

READ/CLEAR TO

PROGRAM

XX:XXPM XXXF

ENTER PASSWORD

OR READ/CLEAR

TO DISPLAY PRODUCT

A: SET DATE / TIME

B: PROGRAM PRODUCTS

C: EDIT ACCESS CODE

NUMBER 0-9

EDIT PRODUCT?

1=EDIT OR 2=DELETE

NXX TX XXXF CX

XX:XX:XX PXXX F-XX

ENTER COOKING TEMP

100 TO 450 F

NOX T1 XXXF

ENTER COOKING TIME

HR:MIN:SEC

NOX T1 XXXF CO

ENTER COOKING CURVE

0 TO 100% NOX T1 XXXF CXX XX:XX:XX PXXX F-XX

PROGRAMMING PURPLE PLUS CONVECTION OVENS

ECOH-PP, ECOF-PP, GCOF-PP,

EHS-PP, ECCO-PP, GCCO-PP

Programming Procedures continued

PROGRAMMING PROCEDURES CONTINUED

ENTER FAN SPEED

Select Fan speed. (Hi=1700 rpm, Low=1400)

Select Fan Pulse rate. (0 to 100%). 0=off unless calling for heat. 100=on at all time. ENTER FAN PULSE RATE NOTE: Any number between 0-100 means that the fan will be on that many number of seconds in a 100-second block. (E.g. 67%= on for 67 seconds in a 100 second block)

If your press 1 you will go through the same sequence as outlined above. If you press 2 the next display will automatically appear.

1=HI 2=LOW NOX T1 XXXF CXX XX:XX:XX PXXX F-XX

1 TO 100%

NOX T1 XXXF CXX

XX:XX:XX PXX F-XX

CONTINUE TO TIER 2

1=YES 2=NO NOX T1 XXXF CXX XX:XX:XX PXXX F-XX

If you wish to continue programming a separate menu item, press “B” and repeat the sequence. If you have completed your programming requirments, press Read/Clear butotn until the next display apprears

To begin using your oven, press the appropriate Product Select button. Refer to your Daily Operations Section of your Operations Manual to learn how to use your program.

A: SET DATE / TIME

B: PROGRAM PRODUCTS

C: EDIT ACCESS CODE

SELECT PRODUCT OR

READ/CLEAR TO

PROGRAM

XX:XXPM XXXF

MAINTENANCE

• Oven interiors should be wiped down daily and thoroughly cleaned weekly using warm water and mild detergent. DO NOT use caustic cleaners.

• The appliance should be thoroughly checked at six-monthly intervals by a qualied technician (heating unit, mechanical stability, corrosion...) with particular emphasis on all control and safety devices.

CLEANING

• Always start with a cold oven.

• The stainless exterior can easily be cleaned using stainless steel cleaner.

• Always follow the cleaner manufacturer’s instructions when using any cleaner.

• Care should be taken to prevent caustic cleaning compounds from coming in contact with the fan wheel.

• The oven racks, rack slides, may be cleaned outside the oven cavity using oven cleaner.

• Using any harsh chemicals will result in the removal of the ETC coating and etching of the porcelain below it. The oven interior should only be cleaned using a mild soap and a non metal scouring pad.

DO NOT use caustic cleaners.

• Always apply stainless steel cleaners when the oven is cold and rub in the direction of the metal’s grain.

KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR

HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC.

WARNING

MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS

MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE

CAUTION

CAREFULLY READ THE WARNING AND FOLLOW THE DIRECTIONS ON

NEVER LEAVE A CHLORINE SANITIZER IN CONTACT WITH STAINLESS

CLOTHING.

THE LABEL OF THE CLEANER TO BE USED.

STEEL SURFACES LONGER THAN 10 MINUTES. LONGER CONTACT CAN CAUSE CORROSION.

Troubleshooting

Symptoms & Possible Causes

The following are charts of Symptoms and Possible Causes to aid in diagnosing faults with your unit.

Refer to the symptoms column to locate the type of failure then to the Possible Cause for the items to be checked.

To test for a possible cause refer to test to identify test procedures. Test indicated with an “*” should be done by a Lang factory authorized service representative.

Symptoms Possible Cause

No power to cord outlet

Power indicator is not lit

Oven will not heat

Oven motor will not run

Product burning

Product is under done

Oven unplugged from outlet

Failed Power cord or plug

Failed power switch

Failed indicator light

Power Switch is not “ON”

Failed Transformer

Failed Probe

Failed Circuit board

Failed Contactor

Failed Over-temperature Thermostat

Failed Element

Power Switch is not “ON”

Failed Transformer

Failed Contactor

Failed Motor

Product is cooked too long

Failed Probe

Failed Circuit board

Product is not cooked long enough

Failed Probe

Failed Circuit board

Possible Cause Test

Product is cooked too long

Failed Probe Check probe for proper resistance*

Failed Circuit board

Failed Transformer

Failed Contactor

Failed Motor

Failed or disconnected safety thermostat

Failed Element

No test available, operational condition

Conrm that Circuit board is getting

correct voltage and putting out correct voltage*

Check both Primary and Secondary coils for correct voltage*

Remove the wires from the contactor coil and check for continuity across the contactor coil connection*

Ensure the contactor moveable points move freely up and down*

Conrm that motor is getting correct

voltage*

Check across the thermostat connectors for continuity*

Conrm that Elements are getting

correct voltage and have continuity*

NOTICE If an item on the list is followed by an asterisk (*), the work should be done by

a Lang factory authorized service representative.

USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY

LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY INJURY

CAUTION

TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES.

NOTICE ServiceonthisoranyotherLangappliancemustbeperformedbyqualied

personnel only. Consult your Lang Authorized Service Agent Directory. You can call our tech service number 314-678-6315 or visit our website www.langworld.com for the service agent nearest you.

BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS APPLIANCE

WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE

WARNING

REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC POWER SUPPLY.

REVISIONS

24VAC

JP11 = HEAT JP12 = HI SP MOTOR JP13 = LO SP MOTOR JP14 = OPT STEAM JP21 = RTD JP35 = DOOR SW JP37 = ON-OFF GP3 = CHASSIS GROUND GP4 = CHASSIS GROUND JP41 = RS232 CONNECTOR

24 POLE

TERMINAL BLOCK

DWN. BY :

DESCRIPTION:

CAD FILE :

STEAM BACKUP SWITCH

JP11

JP1 JP2

RTD

DWG. NO:

2500W

REV. BY :

2M-61111-147

2726JP21JP22JP23JP24JP3JP4

WHTWHT

CONTROL FRONT & DISPLAY

BLUE

RED

DWN. DATE :

DLG

FROM ACAD

11-03-03

W/D EH PP WITH 2 SPEED MOTOR 208/240VAC

OVEN CONTROL

JP41

BLUE

REV. DATE :

ECO REV. DESCRIPTION DATE

BACKUP

RELAY

CNO

240V

JP20JP19JP18JP17JP16JP15JP14JP13JP12

POWER

JP34JP30 JP40JP35 JP36 JP37 JP38 JP39

JP33

JP32

JP31

JP8 JP9JP6JP5 JP7

DOOR SWITCH

C NC

CONTACTOR

24VAC

CONTACTOR

RED

BACKUP

TSTAT

"STEAM"

FROM

CONTROL

XFMR

MOTOR

TERMINAL

BLOCK

GROUND LUG

"HEAT" FROM

CONTROL

VAC

SOLENOID

STEAM VALVE

(WHEN PRESENT)

XFMR

2332

BACKUP SWITCH

12/24

24VAC LOW

24VAC HI

6485 C WIRE TO POWER SWITCH NC WAS NO 1/14/2008

7806 D

ADDED CONTACTOR #2, REVISED JP1 BOARD WIRING TO MATCH PRODUCTION

7947 E

ADD SNUBBER ON CONTACTOR #2, REVISE XFMR WIRING, ADD XFMR NOTE, REV KW & AMP VALUES

XFMR WIRED FOR 208VOLTS TO CHANGE TO 240V DISCONNECT RED 208 LEAD & CONNECT ORANGE 240 LEAD

208

240

MOTOR

NOCNC

MOTOR

CNC NO

FROM CONTACTOR #1

TO TERM BLOCK DO NOT CONNECT BOTH

208

240

XFMR WIRED FOR 208VOLTS TO CHANGE TO 240V DISCONNECT RED 208 LEAD & CONNECT BLUE 240 LEAD TO TERM BLOCK DO NOT CONNECT BOTH

BLUE

RED

BLACK

HI-LIMIT DISC-STAT

FROM

CONTACTOR #1

T7-T4

S ER VIC E CO NN EC TIONS

TH RE E PH AS E S ING LE P HA S E

APPR.

4/2/2009 DJS

5/19/2009 DJS

L1 L 2 L3 L 1 L2

1-4 2 -5 3-6 1-3-5 2-4 -6

K W A MP S

L1 -L2 L2 -L3 L3- L1 TO TA L L 1 L2 L 3 1 P HA SE

E CO H

V OL TS

20 8 2 .5 2 .5 2 .8 7 .8 22 .1 20 .8 22 .1 37 .5 24 0 2 .5 2 .5 2 .8 7. 8 19 .1 18 .0 1 9.1 3 2.5

CHK. BY :

SHEET

CHK. DATE :

REV:

CONTROL FRONT

& DISPLAY

STEAM BACK-UP SWITCH

24VAC

JP20JP19JP18JP17JP16JP15JP14JP13JP12JP11

OVEN CONTROL

2726JP21JP22JP23JP24JP3JP4 JP1 JP2

JP41

RTD

2500W

WHT

BLUE

RED

JP8 JP9JP6JP5 JP7 JP33JP31 JP32 JP34JP30 JP40JP35 JP36 JP37 JP38 JP39

HEAT

CONTACTOR

RED

BLUE

WHT

24VAC

OPT.

ALL POLE

DISCONNECT

POWER

BACKUP RELAY

Red 30

Red

240V

Yellow 16

Yellow 18

Yellow 17

Red 30

Yellow 19

BACK-UP SWITCH

Blue 28

Black 31

BLK 26

Red 29

240

Red

Yellow

Black 3

BLK 24

Red 2

240

BLK 25

Yellow

6485

7806

BACK-UP

Orange

Yellow 23

SAFETY

CONTACTOR

Red 2

Black 3

White 10

Black 9

TSTAT

Yellow

White 10

Red 11

"STEAM" FROM CONTROL

MOTOR

Brown

24VAC

"HEAT" FROM

CONTROL

VAC

SOLENOID

STEAM VALVE (WHEN PRESENT)

24VAC LOW

24VAC

Red 12

CNC NO

MOTOR

NOCNC

Blue 13

MOTOR HIHI

Black 9

Red 11

Brown

HI-LIMIT

TSTAT

Red 14

NC C NO

T7-T4

DR:

BDM

CK:

± 1/64 ANGLES

± .5°

UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES

SCALE:

REVISION BLOCK

ADDED FAN PICTORIALLY

REV JP1 WIRING TO MATCH PROD

JP11 = HEAT JP12 = HI SP MOTOR JP13 = LO SP MOTOR JP14 = OPT STEAM JP21 = RTD JP35 = DOOR SW

GROUND LUG

JP37 = ON-OFF GP3 = CHASSIS GROUND GP4 = CHASSIS GROUND JP41 = RS232 CONNECTOR

24 POLE TERMINAL BLOCK

2.3

3.0

Three Phase

L2 L3 N

1.9

2.2

VOLTS

220/380

240/415

PURPLE-PLUS

LANG MANUFACTURING

DATE:

10-6-98

TITLE:

10-20-98

.X ± .05

TO FIT

NEXT HIGHER ASSY.

W/D EH PP WITH 2 SPEED CE

220/380 & 240/415 VAC

DATE:

TOLERANCES

DECIMALSFRACTIONS

.XX ± .03

.XXX ± .015

ENGMFG DATEDR:DESCRIPTIONREV ECN NO.

1-18-99BJMADDED SAFETY CONTACTORC

AMPSKW

8.6

9.17 9.19

DRAWING NUMBER

2M-61111-170

1/14/2008

4/3/2009

NL3L2L1

3.4

4.15

REV

JMM

DJS

10.7

.75

.99

12.5

DESCRIPTION / MATERIALITEMQTY PART NUMBER

CREATED BY STUART R. CARTIER

SHEET

REVISIONS

gnirutcafunaM

ynapmoC

CAV42

LORTNOC

TNORF

YALPSID &

EULB

DER

: YB .NWD

GLD

:NOITPIRCSED

: ELIF DAC

DACA MORF

MAETS

PU-KCAB

HCTIWS

726212PJ22PJ32PJ42PJ3PJ4PJ 1PJ2PJ

DTR

W0052

THW

: YB .VER

: ETAD .NWD

30-42-11

02PJ91PJ81PJ71PJ61PJ51PJ41PJ31PJ21PJ11PJ

LORTNOC NEVO

8PJ9PJ6PJ5PJ7PJ33PJ13PJ23PJ43PJ03PJ04PJ53PJ63PJ73PJ83PJ93PJ

14PJ

TAEH

ROTCATNOC

DER

EULB

: ETAD .VER

151-11116-BO

CONCN

CAV42

PUKCAB

YALER

V042

deR

REWOP

PU-KCAB

TATST

HCTIWS ROOD

01 deR

ROTOM

egnarO

32 nworB

ROTOM

9 kcalB

2 deR

3 kcalB

: YB .KHC

CAV 514/042 & 083/022 - DEEPS 2 HTIW PP HE D/W

TEEHS:ON .GWD

03 deR

61 wolleY

81 wolleY

71 wolleY

"MAETS"

MORF

LORTNOC

"TAEH"

MORF

LORTNOC

CAV

DIONELOS

EVLAV MAETS

: ETAD .KHC

:VER

HCTIWS

03 deR

91 wolleY

CAV42

WOL

)TNESERP NEHW(

21 deR

CAV42

nworB

OCE.VERNOITPIRCSE

5846F

PU-KCAB

82 eulB

13 k

calB

KLB

deR

042

deR

wolleY

ROTOM

ONCCN

ROTOM

CCNON

IHIH

9 kcalB

11 deR

TATST

3 kcalB

KLB

2 deR

042

KLB

wolleY

31 eulB

41 deR

4T-7T

TIMIL-IH

SNOISIVER

.WEIV LAIROTCIP

GUL DNUORG

TCERROC HTIW HCTIWS ROOD EHT DECALPER

= 12PJ

TAEH = 11PJ

ROTOM PS IH = 21PJ

ROTOM PS OL = 31PJ

MAETS TPO = 41PJ

DTR

WS ROOD = 53PJ

FFO-NO = 73PJ

DNUORG SISSAHC = 3PG DNUORG SISSAHC = 4PG

ROTCENNOC 232SR = 14PJ

ELOP 42

KCOLB LANIMRET

EVORPPA

8002/71/

SULP-ELPRUP

STEAM BACKUP SWITCH

24VAC

CONTROL FRONT & DISPLAY

RED

DWN. BY :

DLG

DESCRIPTION:

CAD FILE :

FROM ACAD

JP11 JP12 JP13 JP14 JP15 JP16 JP17 JP18 JP19 JP20

JP2JP1

OVEN CONTROL

JP22 JP21 26 27

JP23

JP41

JP4 JP3 JP24

RTD

2500W

WHT

BLUE

11-24-03

DWG. NO:

REV. BY :

DWN. DATE :

W/D EH PP 480V - MOTOR 480VAC

RED

BLUE

2M-61111-168

JP40

JP39

JP38JP37JP36JP35

JP30 JP34JP32JP31 JP33JP7

JP6 JP9JP8

JP5

REV. DATE :

24VAC

CONTACTOR

DOOR SWITCH

CONTACTOR

24VAC

POWER

BACKUP

RELAY

NO C

240V

BACKUP

TSTAT

NCC

"STEAM"

FROM

CONTROL

XFMR

CHK. BY :

MOTOR

3 3

TERMINAL

BLOCK

SHEET

"HEAT"

FROM

CONTROL

XFMR

CHK. DATE :

VAC

SOLENOID

STEAM VALVE

(WHEN PRESENT)

REV:

BACKUP

SWITCH

12/24

24VAC

NC C NO

24VAC HI

FROM CONTACTOR #1

E CO H 48 0 2.5 2. 5 2. 8 7. 8 9 .5 9. 0 9 .5 N /A

REV. DATE/ECO DESCRIPTION OF CHANGE DR

C 1/17/2008 WIRE TO POWER SWITCH NC WAS NO JMM

4/2/2009

240

MOTOR LO

BLUE

MOTOR

NONC C

RED

BLACK

HI-LIMIT DISC STAT

ADDED CONTACTOR #2, REVISED JP1 BOARD WIRING TO MATCH PRODUCTION

ECO 7806

5/21/2009

ADDED SNUBBER TO CONTACTOR #2, REV KW & AMP VALUES, REMOVE SINGLE PHASE INFO

ECO 7947

240

480

FROM

CONTACTOR #1

T7-T4

JP11 = HEAT JP12 = HI SP MOTOR JP13 = LO SP MOTOR JP14 = OPT STEAM JP21 = RTD JP35 = DOOR SW JP37 = ON-OFF GP3 = CHASSIS GROUND GP4 = CHASSIS GROUND JP41 = RS232 CONNECTOR

GROUND LUG

24 POLE TERMINAL BLOCK

PURPLE-PLUS

S ER VIC E CO NN EC TION S

TH RE E PH AS E S ING LE P HA S E

L1 L 2 L3 L1 L 2

1-4 2- 5 3-6 N /A N /A

K W A MP S

L1 -L2 L 2-L 3 L3 -L1 TO TA L L1 L2 L 3 1 P HA S E

V OL TS

DJS

See

Door Assembly

Panel Assembly

See

See Body Assembly

See

Controller Assembly

ECOH Complete Assembly

SK2320 Rev. B 6/1/2009

PARTS LIST March 24, 2015, Rev E

Model No: ECOH & RCOH, AP, PP & PT CONTROLS

Commercial & Marine Half Size Economy Convection Oven

Fig No PART NO Qty DESCRIPTION Application

2N-11090-20

2N-11090-21 ELMNT EHS 240V 7.5KW

2N-11090-22 ELMNT EHS OVEN 480VAC 7.5KW 440VM, 480V, 480VM 2N-11090-23 ELMNT EHS OVEN 208VAC 5.0 KW RCOHAP-208KR, RCOHRAP208KR, RCOHPT-208CF, RCOH-AP-208CF 2N-11090-24 ELMNT EHS OVEN 240VAC 5.0 ECOH-AP240CF, RCOHAP-240CF, RCOHPT-240CF 2E-30500-15 2E-30500-07 TRM BLOCK 3PLELRGE 125AMP ECOHPT208CFR, RCOHPT-208CF, RCOHPT-240CF, RCOHAP-208CF

2E-30500-09 TRM BLOCK 3 POLE SMALL 95

3 2E-30700-06 1 CONTC3POLE35A, 24VAC

4 2C-20102-08 2 SCRW PHD ST 8-32X.375

Q9-60101-767 Q9-EHPAP-GFA PANEL EH 220/380V ACCU-PLUS FA ECOH-AP208FA, ECOH-AP2/3FA Q9-EHPAPRT-C PANEL EH 208/240V AP W/RT30 RCOHAP-208KR, RCOHAP-208V, RCOHRAP208KR

Q9-EHPAP-U PANEL EH 480 VOLT ACCU-PLUS ECOH-AP-480M, 480V, RCOHAP-480V, 480VM, RCOHRAP-480M, 480V

Q9-EHPPP-C

Q9-EHPPP-C-W1 PANEL EH 208/240V PP ECOH-PP-208V, 208BK, 208WB, 240BK, 240WB, (After 6-01-2009)

Q9-EHPPP-C-S

Q9-EHPPT-C PNEL ASSY EHS-PT 208/240/480V ECOH-PT, RCOHPT (Before 6-01-2009) Q9-EHPPT-C-W1 PANEL EH 208/240V PT ECOH-PT, RCOHPT (After 6-01-20090 Q9-EHPPP-CE PANEL EH PURPLE PLUS - CE ECOH-PP2/4BK

6 2U-71500-06 1 BLOWER WHEEL EHS OVEN ALL

2U-30200-16

2U-30200-17 MTR 1/3HP208/240V1PH2SPD

8 2E-41100-12 1 SENSOR EHS OVEN 450 DEG ALL

9 Q9-EH-268 AR EH COOLING FAN ASSY

10 Q9-EH-268-2 1 AIR DUCT BACK

11 Q9-EH-268-1 1 AIR DUCT FRONT

12 2C-20103-02 6 SCRW SM PLT 10 X .5 PHLSL

ELMNT EHS 208V 7.5KW 208V/208VM

240V, ECOH-AP208FA, ECOH-AP2/3FA, ECOH-PP2/4BK, ECOH-AP-2/3,

TRM BLOCK 4 POLE 115AMP ECOH-AP-2/3

PANEL EH 208/240V ECOH-AP-208, 208M, 240V, 208DR

PANEL EH 208/240V PURPLE w/COOLING FAN ASSY

PANEL EH 208/240V PURPLE w/o COOLING FAN ASSY

MOTOR 1/3HP 460V/1/60HZ 2SP

RCOHAP-2/3V

ECOH-AP-208V/208M/240V/208DR, ECOH-AP-480V480/M, RCOHAP208V/VM, RCOHAP-240VM, RCOHAP-440VM, RCOHAP-480V/VM, RCOHAP-480V/480M, RCOHRAP-480V/480M, RCOHPT-440VM

ECOH-AP-208V/VM, 240V/VM, 440M, 480V/VM, ECOH-AP2/3FA, ECOHAP208CF, ECOH-AP208DR, ECOH-PP208/240V, ECOH-PT-208/240V

ECOH-AP-208V/VM, 240V/VM, 440M, 480V/VM, ECOH-AP2/3FA, ECOHAP208CF, ECOH-AP208DR,

ECOH-PP-208V, 208BK, 208WB, 240BK, 240WB (Before 6-01-2009)

ECOH-PP-208V, 208BK, 208WB, 240BK, 240WB

ECOH-AP-480V, ECOH-AP-480M, ECOH-PT-480V, ECOH-PT480CF, ECOH-PT480MF, RCOHAP-480V, RCOHAP-480M, RCOHRAP-480M, RCOHRAP-480V, RCOHPT-440VM, RCOHPT-480CF

ECOH-AP-208M, ECOHAP-208V, ECOH-AP-240V, ECOH-AP208DR, ECOH-PP-208V, ECOH-PP208BK, ECOH-PP208WB, ECOH-PP240BK, ECOH-PP240WB, ECOH-PT-208V, ECOH-PT-240V, ECOH-PT208CF, ECOH-PT208MF, ECOH-PT208NT, ECOH-PT208RF, ECOH-PT208SZ, ECOH-PT208V7, ECOH-PT208WA, ECOH-PT208WD, ECOH-PT240SZ, ECOH-PT240WD, ECOHPT208CF, ECOHPT208CFC, ECOHPT208CFR, RCOHAP-208KR, RCOHAP-208V, RCOHPT-208CF, RCOHPT-208V, RCOHPT-240CF, RCOHRAP208KR, ECOH-AP208FA, ECOH-AP2/3FA, ECOH-PP2/4BK, ECOH-AP-240CF

ECOH-PP-208/240V, ECOH-PT-208/240/480V, RCOHPT-208/240CF/ 480CF, ECOH-PP2/4BK

ECOH-PP-208/240V, ECOH-PT-208/240/480V, RCOHPT-208/240CF/480CF

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1 INCLUDE MODEL AND SERIAL NUMBER OF 2

Some items are included for illustrative purposes only and in certain instances may not be available.

PARTS LIST March 24, 2015, Rev E

Model No: ECOH & RCOH, AP, PP & PT CONTROLS

Commercial & Marine Half Size Economy Convection Oven

Fig No PART NO Qty DESCRIPTION Application

13 2U-30200-46 1 MTR W/FAN AXIAL 220VAC70C

14 2C-20109-31 4 SCRW S/S 8-32 X 1-3/4 T/H PHIL

15 Q9-60102-1368 MTR COVER EH (EH-141) & HRDW ALL

2A-72500-02

2A-72500-05 LEG 4 W/BOLT DOWN ADJ ECOH-AP-208M, RCOHAP-440/480VM, RCOHRAP-480M

9Q-ECOH-C4

Q9-EHS-4C CASTERS (SET OF 4)

17 2P-72901-17 2 CSRT SWVL W/BRK 35/16TRD RCOHAP-208KR, RCOHAP-480V, RCOHPT-208CF 18 2P-72900-04 2 CSTER RIGID 3,5/16WTRD RCOHAP-208KR, RCOHAP-480V, RCOHPT-208CF 19 2C-20301-10 2 NUT HEX 6-32 PLTD ECOH, RCOH 20 2C-20101-65 2 SCRW MS PLT 10-32 X .25 THD ECOH, RCOH 21 Q9-EH-356 1 SWITCH BRACKET ECOH, RCOH 22 2C-20101-17 2 SCRW RND MS 6-32X1 PLTD ECOH, RCOH

2E-30301-17

Q9-51100-18 SWITCH ARM, MICRO ECOH, RCOH 24 2P-51001-12 1 SPRG COMPRSN.665ID X 1.4 LONG ECOH, RCOH 25 Q9-EH-250 1 WELD SWITCH ARM ECOH, RCOH 26 Q9-EH-350 1 SWITCH PLUNGER - ASSY ECOH, RCOH 27 Y9-70701-18 1 KNOB ASSY 450° ECOH-AP, ECOH-PT, ECOH-PP, RCOH-AP, RCOH-PT 28 Q9-60102-112 1 SWITCH DOOR - ASSY EH ECOH-PP-208V

Q9-60101-765 29

Q9-60101-766 ECOH-PP / EHS-PP CNTRL FRONT ECOH-PP 30 Q9-51100-53 1 DOOR ASSY EHS/GHS WINDOW ALL

2B-50200-83 31

2B-50200-83-1 EH RACK SLIDE - PICADILLY ECOH-AP240RS NI 2B-50200-34 5 RACK HALF SIZE OVENS ECOH-AP, ECOH-PT, ECOH-PP, RCOH-AP, RCOH-PT NI 2C-20108-01 2 STACKING PINS ALL NI 2E-31200-02 1 LUG GROUNDING UL APPROVED ALL NI 2E-31800-01 6 CB 250V50A 1 POLE CRLNGSW RCOHAP-208KR, RCOHAP-208V, RCOHPT-208CF NI 2E-31800-04 2 CB 480V 50A 3 POLE RCOHAP-480V NI 2E-31800-04 1 CB 480V 50A 3 POLE RCOHPT-440VM

NI 2E-60101-75 1 EHS CORD KIT BK/DENNY’S ECOH-PP208BK, ECOH-PP2/4BK, ECOH-PT208PC, ECOH-AP240CF NI 2K-70801-03 1 SNAP BUSH 3/8 SB375-4 BLK ECOH-PP-208V NI 2K-70801-04 AR SNAP BUSH 3/4 SB750-10 ECOH NI 2M-61111-135 1 WD EHS-AP 208V-240VAC ECOH-AP-208V NI 2M-61111-148 1 WD EHS-PP 208-240VAC 2SPD ECOH-PP-208V NI 2M-61111-163 1 WD EHS-AP 480V ECOH-AP-480M NI Q9-60102-97 1 DOOR SEAL EH w/ mnting hardware NI Q9-EH-550 1 WIRING HARNESS, ELEMENT ALL NI Q9-EH-551 1 WIRING HARNESS, HIGH VOLT ALL NI Q9-EH-553 1 WIRING HARNESS, LOW VOLT ALL NI Q9-EH-554 1 WIRING HARNESS, PWR SWITCH ALL

LEG 4 SS MM ECOH-AP208DR, ECOH-PT208V7

CASTERS (SET OF 4) sold as an accessory with most units

SWT MICRO PLUNGER XLH V-27971 & W-48418, Pre 2007

ECOH-PT / EHS-PT CNTROL FRONT ECOH-PT, RCOH-PT

RACK SLIDE EHS ECOH-AP, ECOH-PT, ECOH-PP, RCOH-AP, RCOH-PT

ECOH-PP-208/240V, ECOH-PT-208/240/480V, RCOHPT-208/240CF/480CF

RCOHAP-208KR, RCOHAP-208V, RCOHAP-480V, RCOHPT-208CF, RCOHPT-208V, RCOHPT=240CF, RCOHPT-480CF

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 2 INCLUDE MODEL AND SERIAL NUMBER OF 2

Some items are included for illustrative purposes only and in certain instances may not be available.

ECOH Body Assembly

SK2325 Rev. D 3/24/2015

PARTS LIST March 24, 2015, Rev E

Model No: ECOH & RCOH, AP, PP & PT BODY PANELS

Commercial & Marine Half Size Economy Convection Oven

Key

Number

1 Q9-60102-136 1 BODY TOP EH & HRDW ALL 2 Q9-60102-1361 1 BODY BACK EH & HRDW ALL 3 Q9-EH-119-2 1 FIREWALL - ASSY ALL 4 Q9-EH-W1237 1 SAFETY STAT BOX ASSY ALL EXCEPT MARINE APPLICATIONS 5 Q9-EH-136 1 SAFETY STAT COVER ALL 6 2K-70801-04 1 SNAP BUSH 3/4 SB750-10 BLK ALL 7 2C-20103-02 2 SCRW SM PLT 10 X .5 PHLSL ALL 8 Q9-60102-1364 1 BODY R/H SIDE EH & HRDW ALL 9 2C-20104-41 4 SCRW MACH 1/4-20X5/8 H/H ALL 10 Q9-EH-209 1 MOTOR MOUNT ALL 11 2C-20202-08 4 WSHR PLT 5/16 LOCK SPLIT ALL 12 2C-20201-09 4 WSHR PLT 5/16 FLAT SAE ALL 13 2C-20301-06 4 NUT HEX 5/16-18 PLTD ALL 14 Q9-EH-104-2 1 BOTTOM SPOT WELD ALL 15 Q9-EH-215-2 1 FRONT - ASSY REVERSIBLE ALL 16 Q9-EH-452-2 1 BAFFLE STD ALL 16 Q9-EH-452-3 1 BAFFLE ASSY STEAM STEAM 17 Q9-EH-374-3 1 CAN ASSY STD -[NEW RACK ALL 18 Q9-60102-1365 1 BODY L/H SIDE EH & HRDW ALL

Part

Number

Qty Per

Description

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1 INCLUDE MODEL AND SERIAL NUMBER OF 1

Some items are included for illustrative purposes only and in certain instances may not be available.

MARINE APPLICATION

ECOH, RCOH Door Assembly

SK2321

Rev. A 3/1/2012

PARTS LIST March 24, 2015, Rev E

Model No: ECOH & RCOH, AP, PP & PT DOOR ASSEMBLY

Commercial & Marine Half Size Economy Convection Oven

Key

Number

1 2R-50800-12 1 DOOR T HANDLE 11 1/2 LNG ALL 2 Q9-60102-1362 1 OUTER DOOR EH NO/LOGO ALL 3 2Q-71301-04 1 WINDOW ASSY 9-5/8X16-5/8 ALL 4 2H-60106-17 1 INSULATION KIT EHS DOOR - ALL 5 Q9-EH-267 2 HINGE COVER ALL 6 Q9-EH-266 1 HINGE BOTTOM ALL 7 2C-20109-15 4 SCRW PHD MS SS 10-32X1/2 ALL 8 2P-70201-01 2 BRNZBR.505IDX.8750DX.175 ALL 9 Q9-EH-265 1 HINGE TOP ALL 10 2P-70201-19 2 BRNZBRFLN1/2IDX5/8ODX3/8 ALL 11 Q9-50313-031 2 HINGE PIN - WELD ALL 12 Q9-60102-370 1 DOOR LATCH ASSY MARINE MODELS 13 2C-20109-30 2 SCRW MS SS 10-32 X .75 PH FLT ALL 14 2C-20109-43 2 SCRW SS 1/4-20 S 3/4 FLTHD PHIL ALL

COMPLETE DOOR ASSY Q9-51100-53 1 COMPLETE DOOR ASSY W/WINDOW ALL Q9-F6-423 1 COMPLETE DOOR ASSY W/OUT WINDOW

Part

Number

Qty Per

Description

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1 INCLUDE MODEL AND SERIAL NUMBER OF 1

Some items are included for illustrative purposes only and in certain instances may not be available.

ECOH-PP

Purple Plus Controller

ECOH-PT & RCOH-PT

Platinum Controller

SK2324 Rev. A 6/21/2010

PARTS LIST March 24, 2015, Rev E

Model No: ECOH & RCOH, PP & PT CONTROL ASSEMBLY

Commercial & Marine Half Size Economy Convection Oven

Key

Number

1 2M-60301-117 1 SWITCH LBL EH 4X20 ECOH-PP 2M-60301-118 1 SWITCH LBL EH PLATINUM ECOH-PT, RCOHPT 2 Q9-60101-7665 1 ECOH-PP / EHS-PP CNTRL FRNT W/PROTO ECOH-PP Q9-EH-516-1 1 CONTORL PANEL - EH-PT ECOH-PT-208V 3 2A-20504-01 4 SPACER NYLON #6 1/4 X 7/8 ECOH-PP 2A-20504-02 4 SPACER NYLON #6 1/4 X 1” ECOH-PT, RCOH-PT 4 2E-30303-06 1 SWT TOG ON-ON DPDT BLK ECOH-PP, ECOH-PT, RCOH-PT 5 2J-40102-A24 1 DSPLY 4X20 MDL.DA170-001 (NO CABLE) ECOH-PP 2J-40102-25 1 DSPLY 320X240 DB170-001 ECOH-PT, RCOH-PT 6 2C-20205-02 4 .140#6IDX.2500DX.032 ALL 7 2C-20301-10 2 NUT HEX 6-32 PLTD ECOH-PP 2C-20301-10 4 NUT HEX 6-32 PLTD ECOH-PT, RCOH-PT 8 2C-20103-02 4 SCRW SM PLT 10 X .5 PHLSL TP A ALL 9 Q9-EH-519 1 COMPUTER STRIP HOLDER ECOH-PP 10 Q9-60101-7661 1 ECOH-PP / EHS-PP FRNT W/LABEL ECOH-PP Q9-60101-7662 1 ECOH-PT / EHS-PT FRNT W/LABEL ECOH-PT, RCOH-PT 11 Q9-60101-765 1 ECOH-PT / EHS-PT CONTROL FRONT ECOH-PT, RCOH-PT Q9-60101-766 1 ECOH-PP / EHS-PP CONTROL FRONT ECOH-PP 12 2J-31110-13 1 CABLE ASSY - RIBBON 12 PT ECOH-PP, ECOH-PT, RCOH-PT NI 2M-60301-128 1 PRODUCT STRIP PURP COMP ECOH-PP 2M-60301-W128 1 PRODUCT STRIP PURP BK ECOH-PP208BK, ECOH-PP240BK NI OB-60301-46 1 OBS PRDCT STRIP-BLU/PURP COMPH ECOH-PP

Part

Number

Qty Per

Description

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE

INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

ECOH PP/PT Controller Panel

SK2323 Rev. A 7/6/2010

PARTS LIST March 24, 2015, Rev E

Model No: ECOH & RCOH, PP & PT CONTROL PANEL ASSEMBLY

Commercial & Marine Half Size Economy Convection Oven

Key

Number

1 Q9-EH-495 1 COMPUTER CONTROL SLIDE ECOH-PP, ECOH-PT, RCOH-PT 2 Q9-EH-495-1 1 SLIDE CLIP A ECOH-PP, ECOH-PT, RCOH-PT 3 Q9-EH-505 1 COMPONENT MOUNT C,P,PP ECOH-PP, ECOH-PT, RCOH-PT 4 2E-30700-06 1 CONTC3POLE35A24VAC50/60HZ ECOH-PP, ECOH-PT, RCOH-PT 5 2J-31110-W1 1 USB PNL MNT CABLE TO SOCKET 6 2E-31400-07 1 XFORMR120-208-240/24V40VA ECOH-PP, ECOH-PT, RCOH-PT 7 Q9-EH-507 1 TERMINAL BLOCK MOUNT ECOH-PP, ECOH-PT, RCOH-PT 8 2E-30503-01 1 TRM BLOCK 24 POS QK CON ECOH-PP, ECOH-PT, RCOH-PT 9 2E-30701-05 3 CONTC 2POLE 30A 24VAC P & ECOH-PP, ECOH-PT, RCOH-PT 2E-30701-05 4 CONTC 2POLE 30A 24VAC P & ECOH-PP2/4BK 10 2E-30600-02 1 RELAY 240VAC 3FORMC FLNG ECOH-PP, ECOH-PT, RCOH-PT 2E-30600-07 1 RELAY 240VAC FLANGE MNT ECOH-PP2/4BK 11 2E-30303-06 2 SWT TOG ON-ON DPDT BLK ECOH-PP, ECOH-PT, RCOH-PT 2E-30303-19 2 SWT TOG ON-ON DPDT BLK ECOH-PP2/4BK 12 2T-30402-27 1 STAT ADJ 450 DEG 48 PILOT ECOH-PP, ECOH-PT, RCOH-PT 13 Q9-EH-509 1 SWITCH BRACKET ECOH-PP, ECOH-PT, RCOH-PT 14 PS-40102-W26 1 MAIN BOARD, MDL.CA170-001 ECOH-PP, ECOH-PT, RCOH-PT 15 Q9-50307-47 1 CPU MOUNT ECOH-PP, ECOH-PT, RCOH-PT 16 2A-20501-01 5 SPCR FBR 1/4 OD #8 ID 3/8 ECOH-PP, ECOH-PT, RCOH-PT 17 2C-20301-10 2 NUT HEX 6-32 PLTD ECOH-PP, ECOH-PT, RCOH-PT 18 Y9-31400-26-1 1 XFORMR 208-240/24-12 40VA ECOH-PP, ECOH-PT, RCOH-PT 2E-31400-28 2 XFORMR208-240/24VCT 40VA ECOH-PP2/4BK 19 2E-41800-02 2 PCB GUIDE 6.675 LG EHPPP-C, EHPPT-C, 20 Q9-EH-513 1 24V TANSFORMER SHIELD ECOH-PP, ECOH-PT, RCOH-PT 21 2C-20306-03 4 AVK CAD 10-32 1ST GRP ECOH-PP, ECOH-PT, RCOH-PT 22 Q9-EH-495-2 1 SLIDE CLIP B ECOH-PP, ECOH-PT, RCOH-PT NI Q9-40102-51-1 1 FILTER BOARD PHANTOM NI Q9-ECCOPPP-C 1 PANEL ECCO 208/240V ECOH-PP NI Q9-ECCOPPT-C 1 PANEL ECCO 208/240V ECOH-PT NI Q9-ECCOPPT-U 1 PANEL ECCO 480V PLATINUM ECOH-PT NI 2E-30303-05 1 SWT PLATE ON/OFF NI 2E-30500-15 1 TRM BLOCK 4 POLE 115AMP ECOH-PP2/4BK, ECOH-PT2/3NT NI 2E-30702-02 1 CONTC 4POLE 24V 25FLA CE ECOH-PP2/4BK NI Q9-40705-03 VARIES SNUB-ALL-LO VOLT (PUSH) ON

Part

Number

Qty Per

Description

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE

INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

Lang ECOH-PP Operators Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
