Page 1
Table of Contents Part Number Index
Fertilizer Spreader
FSP500, FSP700 & FSP1000
24974
309-065P
Parts Manual
Read the Operator's manual entirely.When
you see this symbol, the subsequent
instructions and warnings are serious - follow
without exception.Your life and the lives of
others depend on it!
© Copyright 2008 Printed 01/31/08
Cover photo may show optional equipment not
supplied with standard unit.
Page 2
Table of Contents Part Number Index
Table of Contents
Section 1: Introduction.................................................4
Using This Manual...............................................................4
Manual Replacement Information.......................................4
Manual Revisions................................................................4
Touch-up Paint....................................................................4
Hardware Legend................................................................5
Replacement Hardware......................................................5
Serial Numbers...................................................................5
Part Number Service Coding..............................................5
Section 2: Complete Assembly....................................6
Complete Assembly............................................................6
Section 3: Drivelines.....................................................8
Driveline (311.001) Eurocardan..........................................8
Section 4: Gearbox......................................................10
Gearbox (322.002)............................................................10
Section 5: Labels.........................................................12
Label Placement...............................................................12
Section 6: Options.......................................................14
Hopper Cover....................................................................14
Part Number Index.......................................................16
© Copyright 2008. All rights reserved.
Land Pride provides this publication “as is” without w arranty of any kind, either e xpressed or implied.While every precaution has been taken in the preparation of this manual,
Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land
Pride reserves the right to revise and improve its products as it sees fit.This publication describes the state of this product at the time of its publication, and may not reflect
the product in the future.The illustrations in this manual are not intended for safe and proper assembly or disassembly of equipment.The illustrations are intended for
ordering parts only.
All other brands and product names are trademarks or registered trademarks of their respective holders.
2 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Land Pride is registered trademark.
Printed in the United States of America.
Page 3
Table of Contents Part Number Index
C
Complete Assembly.......................................................6
D
Driveline (311.001) Eurocardan.....................................8
G
Gearbox (322.002).......................................................10
H
Hopper Cover...............................................................14
L
Label Placement..........................................................12
Alphabetized Table of Contents
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 3
Page 4
Table of Contents Part Number Index
4 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Page 5
Table of Contents Part Number Index
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 5
Page 6
Land Pride Section 2: Complete Assembly
Table of Contents Part Number Index
Complete Assembly
Applies to FSP1000, FSP500, FSP700
25692
6 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Page 7
Section 2: Complete Assembly Land Pride
Table of Contents Part Number Index
Complete Assembly
Applies to FSP1000, FSP500, FSP700
RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg25692
COSMO ENTRAINER330.0011.
COSMO SPRING PIN 8X40305.0012.
COSMO RING RUBBER304.0133.
COSMO LOWER AGITATOR619.0024.
COSMO SCREW TTQST 10X20300.0445.
HOPPER FSP500 PLASTIC COMPLETE817-756C6.
HOPPER FSP700 PLASTIC COMPLETE817-757C6.
HOPPER FSP1000 PLSTIC COMPLETE817-758C6.
COSMO LEVER LOCK KNOB302.0037.
COSMO RIGHT LEVER604.0018.
COSMO WSHR FLT 10.5X21 UNI6592303.0099.
COSMO NUT HEX M10 UNI 5588301.01010.
COSMO RUBBER GRIP304.00811.
COSMO LEFT LEVER604.00212.
COSMO SCRW HX HD 12X35 UNI5739300.02413.
COSMO FRAME "PIN" STYLE613.00314.
COSMO DRIVELINE311.00115.
COSMO LEFT TIE ROD602.00216.
NUT HEX M10X1.5 PLT803-279C17.
COSMO LEFT SHUTTER605.00618.
COSMO RIGHT SHUTTER605.00519.
COSMO RIGHT TIE ROD602.00120.
COSMO G-BOX322.00221.
COSMO HX SCKT HD CP SCRW 8X16300.01422.
COSMO NUT HEX M8 UNI 5588301.01223.
COSMO SPRDR DSK W/STNLS STL VN610.01924.
COSMO STAINLESS STL DIST.VANE601.00225.
COSMO RND HD SCRW 8X16 UNI5731300.03026.
COSMO PIN HAIR COTTER307.00127.
COSMO SELF LOCK NUT M12301.00828.
COSMO PIN LOWER LINK633.00129.
COSMO LATERAL SLIDE RH622.03030.
COSMO LATERAL SLIDE CENTER622.02731.
COSMO LATERAL SLIDE LH622.03132.
COSMO PLATE BOTTOM HOPPER614.00233.
COSMO SCREW TSEI 8X20300.04034.
COSMO WASHER 8X24303.01335.
COSMO NUT HEX M8 UNI 5588301.01236.
COSMO SELF LOCK NUT M12301.00837.
WASHER FLAT 13X25 UNI6592303.02638.
COSMO BUFFER WHEEL304.01139.
COSMO AGITATOR FRAME UPPER613.00940.
HHCS M12X1.75X55 GR 8.8802-654C41.
Use Rivets Furnished by Customer
to Install
Use Rivets Furnished by Customer
to Install
Use Rivets Furnished by Customer
to Install
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 7
Page 8
Land Pride Section 3: Drivelines
Table of Contents Part Number Index
Driveline (311.001) Eurocardan
Applies to FSP1000, FSP500, FSP700
18111
8 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Page 9
Section 3: Drivelines Land Pride
Table of Contents Part Number Index
Driveline (311.001) Eurocardan
Applies to FSP1000, FSP500, FSP700
RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg18111
COSMO DRIVELINE311.001
*
EC YOKE ASSEMBLY (TRACT. END)10210101.
EC CROSS ASSEMBLY (U JOINT)10010202.
EC INSIDE TUBE WITH YOKE1991034N3.
EC OUTSIDE TUBE WITH YOKE1981032N4.
DECAL DANGER PTO DRIVELINE818-552C5.
DECAL DANGER GUARD MISS PTO818-540C6.
EC COMPLETE PUSH-PIN KIT15810387.
DRIVELINE SHIELD SAFETY CHAIN0443218.
EC STIFFENING RING12112339.
EC STANDARD SOFT CONE178100310.
EC INNER TUBE187103111.
EC OUTER TUBE177003112.
EC TUBE BEARING (OUTER)178100513.
EC TUBE BEARING (INNER)178100414.
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 9
Page 10
Land Pride Section 4: Gearbox
Table of Contents Part Number Index
Gearbox (322.002)
Applies to FSP1000, FSP500, FSP700
22166
10 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Page 11
Section 4: Gearbox Land Pride
Table of Contents Part Number Index
Gearbox (322.002)
Applies to FSP1000, FSP500, FSP700
RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg22166
COSMO G-BOX322.002
*
COSMO SPRING PIN 8X40305.0011.
OUTPUT SHAFT COWLING304.0022.
COSMO GREASE NIPPLE306.0023.
COSMO UPPER SHELL314.0024.
COSMO BALL BEARING OUTPUT TOP310.0015.
COSMO INTERNAL RETAINER RING313.0116.
WASHER 25X35X0,5 DIN 988303.0117.
COSMO PINION GEAR316.0038.
COSMO SPLIT PIN305.0039.
COSMO SPLINE KEY326.00310.
COSMO OUTPUT SHAFT323.00911.
COSMO EXTERNAL RETAINER RING313.01012.
COSMO BALL BEARING IN/OUTPUT310.00213.
COSMO LOWER SHELL314.00114.
SELF LOCKING NUT M6301.00915.
COSMO INPUT SHAFT OILSEAL309.00116.
COSMO INPUT SHAFT323.00817.
COSMO SPACER INPUT SHAFT329.01118.
COSMO G-BOX322.00219.
COSMO HEX HEAD CAP SCREW300.02620.
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 11
Page 12
Land Pride Section 5: Labels
Table of Contents Part Number Index
Label Placement
Applies to FSP1000, FSP500, FSP700
25693
12 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Page 13
Section 5: Labels Land Pride
Table of Contents Part Number Index
Label Placement
Applies to FSP1000, FSP500, FSP700
RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg17571
DECAL FERT. SPREADING CHART818-764C1.
DECAL DANGER TOXIC CHEMICAL818-541C2.
DECAL NOTICE FERT PTO INFO818-542C3.
DECAL DANGER GUARD MISS PTO818-540C4.
DECAL DANGER PTO DRIVELINE818-552C5.
DECAL DANGER THROWN OBJ FERT818-539C6.
DECAL FSP1000 BROWN848-091C7.
DECAL FSP700 BROWN848-090C8.
DECAL FSP500 BROWN848-089C9.
DECAL LP W/TREE 19" - 2 COLOR818-895C10.
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 13
Page 14
Land Pride Section 6: Options
Table of Contents Part Number Index
Hopper Cover
Applies to FSP1000, FSP500, FSP700
22168
14 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Page 15
Section 6: Options Land Pride
Table of Contents Part Number Index
Hopper Cover
Applies to FSP1000, FSP500, FSP700
RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg22168
FSP500 HOPPER COVER890-988C1.
FSP700 HOPPER COVER890-989C1.
FSP1000 HOPPER COVER890-990C1.
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 15
Page 16
Table of Contents Part Number Index
Part Number Index
The Part Number Index is a numeric index of all part numbers included in this manual.The index shows what page(s) the part is used on.
PagePart Number
PagePart Number
9044321 ......................
91001020 ....................
91021010 ....................
91211233 ....................
91581038 ....................
91770031 ....................
91781003 ....................
91781004 ....................
91781005 ....................
91871031 ....................
91981032N ..................
91991034N ..................
7300.014 .....................
7300.024 .....................
11300.026 .....................
7300.030 .....................
7300.040 .....................
7300.044 .....................
7301.008 .....................
11301.009 .....................
7301.010 .....................
7301.012 .....................
7302.003 .....................
7303.009 .....................
11303.011 .....................
7303.013 .....................
7303.026 .....................
11304.002 .....................
7304.008 .....................
7304.011 .....................
7304.013 .....................
7, 11305.001 .....................
11305.003 .....................
11306.002 .....................
7307.001 .....................
11309.001 .....................
11310.001 .....................
11310.002 .....................
7, 9311.001 .....................
11313.010 .....................
11313.011 .....................
11314.001 .....................
11314.002 .....................
11316.003 .....................
7, 11322.002 .....................
11323.008 .....................
11323.009 .....................
11326.003 .....................
11329.011 .....................
7330.001 .....................
7601.002 .....................
7602.001 .....................
7602.002 .....................
7604.001 .....................
7604.002 .....................
7605.005 .....................
7605.006 .....................
7610.019 .....................
7613.003 .....................
7613.009 .....................
7614.002 .....................
7619.002 .....................
7622.027 .....................
7622.030 .....................
7622.031 .....................
7633.001 .....................
7802-654C ...................
7803-279C ...................
7817-756C ...................
7817-757C ...................
7817-758C ...................
13818-539C ...................
9, 13818-540C ...................
13818-541C ...................
13818-542C ...................
9, 13818-552C ...................
13818-764C ...................
13818-895C ...................
13848-089C ...................
13848-090C ...................
13848-091C ...................
15890-988C ...................
15890-989C ...................
15890-990C ...................
13dwg17571 ..................
9dwg18111 ..................
11dwg22166 ..................
15dwg22168 ..................
7dwg25692 ..................
16 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 01/31/08
Page 17
Table of Contents Part Number Index
This Page Intentionally Left Blank
01/31/08 FSP500, FSP700 & FSP1000 Fertilizer Spreader 309-065P 17
Page 18
Great Plains Manufacturing, Inc.
Corporate Office: P.O. Box 5060
Salina, Kansas 67402-5060 USA
www.landpride.com
Loading...
