USER’ S MANUAL release 1.0
This manual must be considered an integral part of the projector.
1
BEFORE CONNECTING AND USING THE PROJECTOR, IT IS IMPORTANT TO READ CAREFULLY ALL THE
INSTRUCTIONS IN THIS MANUAL.
QUALIFIED PERSONNEL ONLY, IN COMPLIANCE WITH ALL THE SECURITY LAWS, CAN DO THE
INSTALLATION, THE MAINTENANCE AND THE UTILISATION OF THIS PROJECTOR.
BEFORE CONNECTING THE PROJECTOR, MAKE SURE THAT THE FREQUENCY AND THE VOLTAGE
VALUES ARE SUITABLE AS SPECIFIED ON THE PROJECTOR.
FOR ANY DOUBT, CONTACT YOUR SUPPLIER OR SEND AN E-MAIL TO:
tech@lamposrl.it
INDEX
GENERAL DESCRIPTION OF PROJECTOR --------------------------------------------------- page 2
START-UP PROCEDURES -------------------------------------------------------------------------- page 5
WHAT’S INSIDE ----------------------------------------------------------------------------------------- page 6
DMX CHANNEL ASSIGNMENT -------------------------------------------------------------------- page 7
CONTROL SYSTEMS --------------------------------------------------------------------------------- page 9
OPTICAL SYSTEM ------------------------------------------------------------------------------------ page 12
MAINTENAINCE ---------------------------------------------------------------------------------------- page 13
TROUBLESHOOTING -------------------------------------------------------------------------------- page 15
SPARE PARTS ----------------------------------------------------------------------------------------- page 16
WARRANTY --------------------------------------------------------------------------------------------- page 16
2
GENERAL DESCRIPTION
SUPERTRACER is an intelligent followspot ideal for distance between 20 and 80mt, it has an external ballast,
zoom between 7.4° and 15.6° and it is perfectly balanced. Supertracer has a colour wheel, filter correction, frost
filter, focusing, dimmer and strobe, this effects is controller by TRACER console or by any DMX 512 controller.
As shown in the figure, the SUPERTRACER FOLLOWSPOT 2500 HTI is made up of the following parts:
1. Front opening
2. Upper lid
3. Projector body
4. Lamp compartment
5. Adjustable support bracket
6. Support bracket
7. Cooling unit
8. Bar adjustment
9. SUPERTRACER control unit on
board
10. TRACER console
TECHNICAL FEATURES AND DIMENSIONS
Voltage rating 230 V Rated current 15 A
Inductive current 7,1 Absorbed power 3080 W
Frequency 50 Hz or 60 Hz Maximum room temperature
35° C
Maximum surface
temperature
70° C
Distance from inflammable
surface
2 mt
Main mount via # 1 screw M12 Projector body length 1350 mm
Max. length complete with
bar
1500 mm
Width including bracket and
handles
360 mm
Weight of the projector 38.2kg
Weight ballast-projector
included packaging
82 kg
Ballast measure 350X254X525 mm Ballast weight 33 kg
3
REAR PANEL
As shown in the figure, the following elements ca be seen on the rear panel:
1. Rear handle
2. Serial number plate
3. DMX address area
4. Control Assignment Section
5. XLR DMX 512 in/out
6. Line and electronic fuse
7. Main power supply cable
8. ON/OFF lamp switch
9. RS232 for TRACER console
10. Projector work hour counter
ADJUSTMENT OF PROJECTOR BODY ANGLE AND REAR BAR
As shown in the figure, in order to be able to control manually the movement of the vertical axis, it’s sufficient to
loosen the knobs “A”. Thanks to the innovative reinforced bracket with teflon coated disks, you can avoid hard
adjustments and obtain smooth movement and perfect stability of the product, even in case of “release”. The
movement, enabled by the support bracket, is +/- 45° compared to the assembly position of the bracket.
In order to recline the rear bar into the desired position it is necessary to loosen the knob “B”. When the new
positioning has been made, we suggest to tighten firmly the knobs and to verify that the locking is well done before
operating directly with the projector.
WORKING POSITION
SUPERTRACER FOLLOWSPOT 2500 can work in all positions.
MECHANICAL SAFETY GUARDS
A bipolar cut-off switch is located between the lamp compartment and the cooling unit. This safety switch cuts off
the power to the projector if the top lid is opened.
4
NOISE LEVEL
After the projector has been powered up and the initial configuration takes place, the noise produced by the
projector is primarily due to its cooling system. The noise level is much lower than the limit of 70 db A permitted by
law.
PACKING
The projector is shipped and delivered in a cardboard box made of KRAFT cardboard and semi-chemical additivefree paper, in compliance with BSFV Class 3 standards for waste disposal.
The projector is completely assembled, placed in the box inside a polyethylene bag and held firmly in place with
polyurethane foam packing material. The box is stapled shut.
Even though the packing provides complete protection from rain, it must not be exposed to inclement weather or
humidity.
No more than three identical boxes can be stacked one on top of the other.
Keep the original packing for possible shipments in the future.
STORAGE
The projector, in its original packing, must be kept in covered, dry areas with a temperature between –10°C and
+50°C.
HANDLING
The projector, with or without packing, must be handled with care.
Lifting and handling must be carried out with special equipment. Do not expose the projector, with or without its
packing, to brusque accelerated or decelerated movements, knocks, dragging, or other stress caused by
unsuitable handling.
The projector in its packing can be seriously damaged if it falls or suffers a blow during transportation.
HANDLE WITH CARE!
ADMISSIBLE ENVIRONMENTAL CONDITIONS
The projector was engineered and produced to function in covered dry areas with an air temperature ranging
between 0° and 35° C, and with a humidity level between 30 and 90%.
Sharp changes in room temperature may generate condensation inside the projector which can harm the projector.
Therefore, switch on the projector only after it has undergone a period of gradual adaptation to the room
temperature.
5
START – UP PROCEDURES
POSITIONING AND INSTALLATION
Follow these steps for opening the package and installing the projector in its working position:
• Place the projector near the place it will be installed.
• Open the package and remove the anchoring elements, accessories, and User manual.
• Carefully read the instructions in the manual.
• Arrange tripod or stand or any other adequate support.
• In case of tripod or stand, position the projector on an horizontal plane and mount before the rotation pivot
in the middle of the adjustable anchoring bracket.
• Using and adequate lifting equipment, complete the mounting on the stand or any other adequate support.
• Tighten the M12 bolts and insert a device to prevent them from accidentally loosening.
• Make sure all adjustable parts are locked firmly in place in the desired position.
You must verify the stability of the support elements when the projector is in working condition.
Do not install the projector where there are objects located at a distance of less than 20 centimetres from
the cooling unit.
POWER SUPPLY
Use the cable provided inside the special junction box. The power line must be protected by a differential magneto
thermal circuit breaker, while metal parts that might be electrically charged through the projector must be grounded.
SUPERTRACER 2500 absorbs 3080W at 230V. Makes sure the projector does not pull the cable in all different
working positions, and that sources of heat are not placed in the vicinity.
Connect the fixture to the mains with the enclosed power cord and plug. See the table for the colours of
the connection-cable.
When in doubt, consult a qualified electrician.
Be careful with your operations. With a high voltage you can suffer a dangerous electric shock when
touching the wires! Inside the projector, the ignitor circuit have very high voltage, over 5Kv.
The User must ensure that the power supply is provided with a highly sensitive differential circuit breaker
30m/A to protect the projector from indirect contacts, and that the grounding system PE is working
properly.
Don’t power the projector with a dimmer circuit
6
LAMP INSTALLATION
• Switch off projector
• Loosen the cheese-headed screw hexagon built in front and
on the back of the projector of the top lid and remove the lid.
• Remove the lamp from the packing and carefully read the
Manufacturer’s instructions.
• Insert the lamp into the socket
• Block the wire contact firmly to avoid low efficiency
connection.
• Switch on the projector to make sure the lamp is working
correctly.
• Regulate the lamp, if necessary. (The lamp holder is aligned
at the factory)
• Replace the top lid (4 screws) and firmly tighten the screws.
WHAT’S INSIDE
COLOUR WHEEL
SUPERTRACER has n°1 motorized colour wheel with n°7 adjacent dichroic filter plus open (White – Red – Yellow
– Magenta - Green – Orange – Pink).
GOBOS
Supertracer has n°1 slot for gobos holder.
Gobos holder is optional. (M-size gobo).
EFFECT WHEEL
TRACER has n°1 motorized effect wheel with CTO filter, CTB filter and Frost filter for soft beam.
FOCUS LENS
TRACER has n°1 motorized focusing coated lens, for high definition projection.
ZOOM
TRACER has manual linear zoom, from 7.4° to 15.6°.
SHUTTER
SUPERTRACER has n°4 shutter for perfect dimmer and strobe effect
7
DMX CHANNEL ASSIGNMENT
CHANNEL FUNCTION
01 COLOUR
02 COLOUR CORRECTION
03 IRIS
04 DIMMER & SHUTTER
05 FOCUSING
06 SPECIAL FUNCTION
DMX CHANNEL FUNCTIONS are described in the table.
When you address a projector keep in mind that the BASE CHANNEL (or Starting Channel) corresponds to
the first channel (the colour channel, in this case), and the other functions follow in the order described in
the table.
When using the projector with a standard DMX controller, the channels with the DIP SWITCHES of control
assignment channels set on ON can only be used with the TRACER CONSOLE, do not remove the TRACER
console for any reasons.
PROJECTOR ADDRESS
To make sure the projector functions properly , the dip-switches in the DMX ADDRESS AREA on the rear panel
must be correctly configure. Keep in mind that each SUPERTRACER occupies 6 DMX channels. Each projector
must be set separately on its own BASE CHANNEL (or STARTING CHANNEL) . The BASE CHANNEL assignment
is obtained by summing the values for each switch in the DMX SECTION (for example, to set a projector on BASE
CHANNEL #39, you must set dip-switches 32,4,2 and 1 to the ON position, because 32+4+2+1= 39). In the
Standard Operating Mode, this means the SUPERTRACER will receive signals on 6 channels following the BASE
CHANNEL, BASE CHANNEL included (for example, if the projector is set on BASE CHANNEL #39, it will receive
signals on channels #39, 40, 41, 42, 43 and 44)
8
CHANNEL 1 = COLOURS
percent values decimal values
0 > 5.9 % WHITE 0 > 15
6.3 > 9.4 % WHITE / RED 16 > 24
9.8 > 13.3 % RED 25 > 34
13.7 > 18 % RED / YELLOW 35 > 46
18.4 > 21.6 % YELLOW 47 > 55
22 > 25.5 % YELLOW / MAGENTA 56 > 65
25.9 > 29.8 % MAGENTA 66 > 76
30.2 > 33.7 % MAGENTA / GREEN 77 > 86
34.1 > 37.3 % GREEN 87 > 95
37.6 > 41.6 % GREEN / ORANGE 96 > 106
42 > 45.9 % ORANGE 107 > 117
46.3 > 49.8 % ORANGE / BLUE 118 > 127
50.2 > 53.3 % BLUE 128 > 136
53.7 > 57.3 % BLUE / PINK 137 > 146
57.6 > 61.6 % PINK 147 > 157
62 > 65.9 % PINK / WHITE 158 > 168
66.3 % MIN RAINBOW SPEED =169
66.3 > 100 % INCREASING RAINBOW SPEED 169 > 255
100 % MAX RAINBOW SPEED =255
CHANNEL 2 = COLOURS CORRECTION
percent values decimal values
0 > 19.2 % OPEN 0 > 49
19.6 > 38.8 % CTO (CORRECTION ORANGE) 50 > 99
39.2 > 58.4 % CTO + FROST FILTER 100 > 149
58.8 > 78.0 % CTB (CORRECTION BLUE) 150 > 199
78.4 > 97.6 % CTB + FROST FILTER 200 > 249
98.0 > 100 % FROST FILTER 250 > 255
CHANNEL 3 = IRIS DIAPHRAGM
percent values decimal values
0 % CLOSED =0
0 % > 100 % INCREASING DIAMETER 0 > 255
100 % OPEN =255
CHANNEL 4 = DIMMER & SHUTTER
percent values decimal values
0 % BLACK-OUT =0
0 % > 52.5 % LIGHT LEVEL, FROM 0 TO MAX 0 > 134
52.9 % STROBE EFFECT MIN SPEED =135
52.9 > 95.3 % INCREASING RAINBOW SPEED 135 > 243
95.3 % STROBE EFFECT MAX SPEED =243
96.1 % > 100 % OPEN (MAX LIGHT LEVEL) 245 > 255
CHANNEL 5 = FOCUSING
percent values decimal values
0 % MAX FOCUS =0
0 > 100 % adjustable focus from FAR to NEAR 0 > 255
100 MIN FOCUS =255
CHANNEL 6 = SPECIAL FUNCTION
percent values decimal values
0 > 29.4 % LAMP OFF (AFTER 20 SEC.) 0 > 75
44.7 > 54.9 % RESET (AFTER 5 SEC.) 114 > 140
71 > 100 % LAMP ON (INSTANT) 181 > 255
NOTE: (In standard version of SUPERTRACER, the LAMP is permanent ON)
9
CONTROL SYSTEMS
TRACER CONTROL UNIT
SUPERTRACER comes with a control unit mounted on the adjustable bar and connected to the projector by
means of a proper cable through 9 pin din connector. The TRACER CONTROL UNIT is powered at low voltage 12
Volts directly by the projector and it is able to control the fixture in all its functions.
It is necessary to know that SUPERTRACER can be controlled by practically all types of controllers on the market
that can execute the standard DMX 512 protocol. Controller-projector and projector-projector connections require a
two-core screened cable provided with CANNON PLUGS AND SOCKETS. SUPERTRACER can use both 3 or 5
pin CANNON plugs and sockets because it comes with 3- and 5 pin CANNON SERIAL PORTS. The ground braid
on the screened cable must be connected to just one end of the cable. The projector and cables must not be
installed near overhead ducts for electrical cables or intense magnetic fields.
CONTROL FROM TRACER CONTROL UNIT
In this mode, the projector is controlled directly from the on-board TRACER control unit.
To better understand the working, we suggest to read carefully this paragraph and, if possible, to operate step by
step directly on the TRACER console or to refer to the TRACER console drawing.
COLOUR SECTION
Colours are controlled from here.
Quick- select keys can be used to project the corresponding colour.
Two-colour beams are projected when two adjacent keys are pressed simultaneously.
When the Rainbow/Fixed Colours key is pressed, the projector will do the rainbow effect. Rotation speed is
controlled by the colour section slider when the Rainbow LED is switched on. This function may be switched off by
pressing the Rainbow/Fixed Colours key again or any of the quick-select COLOUR keys.
FILTER CORRECTION SECTION
Temperature correction filters and frost filter are controlled from here.
The colour temperature correction filter keys is used to set primary colours (5600°K), warm colours (3200°K CTO)
or cold colours (6500°K CTB). The FROST filter key is used to obtain soft beam using.
10
DIMMER /SHUTTER SECTION
This section contains the controls for light beam characteristics: INTENSITY, my means of the DIMMER, and
STROBE EFFECT, using the variable speed SHUTTER.
Note that the action of the slider for this section depends on the position of the Dimmer/Strobe selector. When the
Dimmer LED is on, the slider adjusts the intensity of the beam. When the Strobe LED is on, the slider controls the
strobe effect speed.
The two Blackout keys on both sides of the DIMMER / SHUTTER SECTION open or close the shutter
instantaneously. This function has priority over the other keys in this section, when the black-out function is active
the LED over the two blackout keys flashes.
When the blackout LED is flashing, just press any one of the two blackout keys and the projector will return to
either dimmer or strobe status (depending on the position of the dimmer/strobe selector).
IRIS SECTION
This section provides beam DIAMETER controls.
Beam diameter is controlled directly with the slider. The beam is blocked completely when the slider is
set to 0. Press the Open key to open or close the iris immediately. The beam can be opened to the
desired diameter using the slider.
FOCUS SECTION
By pressing one of two keys (“+” or “-“), the beam can be perfectly focused at the desired distance.
SPECIAL FUNCTION
Tracer function, as the name suggest, concerns the beam positioning.
HOW IT WORKS: when the blackout key is pressed, the Blackout and Tracer LED flash simultaneously. In fact, the
TRACER function only works when the projector is in BLACKOUT mode.
At this point, when the TRACER key is pressed and held down, the IRIS is at the minimum aperture and the
DIMMER starts opening at minimum speed. In this phase the TRACER key directly controls the dimmer.
Keeping the key pressed, light intensity increases, When the key is released, intensity decreases, As a result, the
operator can easily get exactly the right intensity for undetectable tracing.
Once the projector has been correctly positioned, simply pressing the Blackout key the beam instantly is on target
with the preset light intensity and beam diameter.
11
CASCADE CONTROL FROM THE TRACER CONSOLE
When several projectors are connected by cable, the console on the first projector can control all functions on the
following projectors. For this reason, the projectors must be connected with a standard DMX cable, IN/OUT 3 or 5
pin connectors. Each projector must have its own TRACER console connected.
This system can be used to control an indefinite number of projectors in perfect synchronism.
FIRST MASTER: all the dip switches of the control assignment section and the DMX address area must be set on
OFF, but the dip switch nr. 7 of the control assignment section set on ON.
OTHER SLAVES: all the dip switches of the control assignment section and the DMX address area must be set on
OFF, but the dip switch nr. 1 of the DMX address area set on ON.
CASCADE CONTROL FROM ANY DMX 512 LIGHTING DESK
This control system is identical to the previous one with the only difference that all projectors must be set to SLAVE
mode (all 5 DIP-SWITCHES of the CONTROL ASSIGNMENT SECTION set to OFF).
MIXED CONTROL
Mixed control means that the projectors are driver by any DMX console, but allows the operator to decide the
functions to use directly from the projector.
The projector can receive the signal from any DMX CONTROLLER and from the TRACER CONSOLE at the
sometime. The dip switches of the control assignment section set on OFF area controlled by the DMX
CONTROLLED. The dip switches of the control assignment section set on ON area controlled by the TRACER
CONSOLE.
12
OPTICAL SYSTEM
The SUPERTRACER FOLLOWSPOT 2500 is provided with a high-efficiency optical system made of mirror, optic
condenser and two anti-flare lenses. This system lets SUPERTRACER FOLLOWSPOT 2500 project an extremely
powerful and homogenous light beam.
The SUPERTRACER use OSRAM HTI 2500W/SE lamp. Socket G22+cable 240000 lumen 6000K 600h
Diameter at 7.4°: 0.130 for distance
Diameter at 15.6°: 0.275 for distance
Linear zoom from 7.4° to 15.6°
LENS ADJUSTMENT
The SUPERTRACER FOLLOWSPOT 2500 is furnished with lens system that lets you create beams of different
sizes. It is a manual zoom that let SUPERTRACER 2500 produce beams of different sizes.
With projector ON, in order to obtain the desired beam aperture, it is sufficient to act on the control knob, visible on
the left picture and located on the side of the projector body.
By pressing one of two keys (“+” or “-“) of the TRACER CONSOLE or any other dmx controller, the beam can be
perfectly focused at the desired distance.
13
MAINTENANCE
Safety guards, lenses and filters must be replaced if they are visibly damaged to the point that they
become ineffective (i.e.: if they have deep slashes or cuts)..
The lamp must be replaced if damaged, cracked or deformed by the heat
PLANNED MAINTENANCE
OPERRATION FREQUENCY RESPONSIBLE ACTION
Optical efficiency test
600 hours User
M1
Lamp replacement
600 hours " "
M2
Surface temperature test
Quarterly " "
M3
Cleaning
Every two months " "
M4
Testing for safety breaker circuit
on general electric system
Monthly " "
Check life-saving safety device by
pressing its "T" bottom
Check damage to cables due to
mobile use projector
Once a year " " Replace cable if damage
General service check of projector Every two years Authorized technician
Always use original spare parts to ensure safe and proper functioning of the projector.
Do not make changes to the projector. A modified projector
Requires a new CE marking
M1 OPTICAL EFFICIENCY TEST
Use the controller to focus the beam on a flat surface, keeping the Iris and Dimmer at 100%. If the spot is not
homogeneous, follow these steps:
• Remove knob A, making sure the projector keeps its current position.
• Insert a screw driver in the hold and turn clockwise or counter clockwise to optimise the horizontal position
of the lamp compared to the optical system.
• Replace the knob A and firmly tighten.
• Remove the PVC plug on the bottom of the projector. Insert a screw driver in the hole and turn it clockwise
or counter clockwise to optimise the vertical position of the lamp compared to the optical system. Replace
the plug.
M2 LAMP REPLACEMENT
The lamp must be replaced with the same type of lamp and according to the same frequency. A less efficient lamp
jeopardizes projector performance. Replace the lamp as follows:
• When the projector is cold, turn off the ON/OFF SWITCH and remove the POWER SUPPLY to cut the
electricity
• Remove the top lid.
• Remove the lamp from the lamp holder.
• Remove the new lamp from its packing and carefully read the manufacturer’s instructions
• Inserting new lamp in its lamp holder
• Block the wire contact firmly to avoid low efficiency connection.
• Replace the top lid and firmly tighten the knobs.
• Switch on the projector to make sure the lamp is working correctly.
14
M3 SURFACE TEMPERATURE TEST
Before you check the temperature, make sure the projector is in the full operating mode (wait about 20 minutes
after switching on the projector). Use a contact probe to measure the surface temperature on the projector’s metal
case and determine the hottest area at the bottom’s projector (nearest to the lamp). The temperature must be less
than 70°. Otherwise, check the cooling system.
M4 CLEANING
Cleaning must be carried out when the projector is cool disconnected from the power supply with the general
power switch turned off, and the ON/OFF switch on the rear panel switched OFF.
FREQUENCY
It is recommended to clean the projector every two months to ensure efficiency and performance. If the projector is
used in particularly smoky or dusty areas, clean the projector more frequently.
Cleaning Procedures
1 Open the top lid by unscrewing the knob and removing it from its seat.
2 Use a vacuum cleaner to remove dust.
3 Use a soft cloth (non fabric) and pH neutral (pH7 ) liquid detergent to clean mirror and lens surface. Make sure
you remove all residual traces. Never touch the lamp directly with your hands or materials that can leave greasy
traces.
4 Follow the same steps to clean the other internal parts of the projector.
5 Make sure the cleaning procedure did not damage any internal part or modified their correct position
6 Replace the top lid and firmly tighten the knob.
If the projector is operated in ordinary working conditions and the user follows the planned maintenance operations
established by the Manufacturer, it should last for three years
When the projector is discarded, it must be disposed of according to recycling laws.
15
TROUBLESHOOTING
*Before switching ON the projector, identify and remove the causes that made the safety fuse intervene.
Call your area dealer or feel free to contact the Manufacturer for any additional assistance.
PROBLEM POSSIBLE CAUSE SOLUTION
No mains power supply
Make sure the mains power is ON and the circuit breaker has
not been triggered
No power to projector
Make sure the switch on the back of the projector is ON
Make sure the top lid is tightly closed
Projector does not turn
ON
Burned-out fuse
Replace the burned-out fuse* Use the type of fuse as
indicated on the side of the projector
Lamp does not ignite
Burned-out or faulty lamp
Lamp switch
Lid protection
Replace the lamp
Control lamp switch on position “On”
Lid protection is positioned correctly
An optical element is
damaged
Switch OFF the power and check lenses. If damaged call an
authorized technician.
Malfunctioning of the
electronic circuit
Contact an authorized technician
The beam is not well
defined (Faulty
projection)
The lenses are dirty
Switch OFF the power and clean the parts as explained in the
cleaning paragraph
In case of DMX control:
malfunctioning of the
DMX cable
Replace the cable and check the line before switching ON
again the projector
In case of DMX control:
wrong addressing
Check the DMX area and CONTROL ASSIGNEMENT area
and reconfigure the dip-switches correctly
Malfunctioning electronic
circuit
Contact an authorized technician
The projector does not
respond to controller
signals
Malfunctioning motor or
transmission
Contact an authorized technician
Remove the dirt and check to see if the cooling system is
working properly
Discontinuous
projector functioning
Safety thermostat has
been triggered
The fan stopped functioning. Contact authorized technician
Noisy projector Mechanical wear
Identify the source of noise and remove the cause or contact
an authorized technician
16
SPARE PARTS
When ordering spare parts for the projector remember to mention the model and serial number which can be found
on the plate at the rear of the projector.
Call your area dealer or feel free to contact the manufacturer for any additional assistance.
SPARE PART LIST
LENSES ORDER FROM REAR TO FRONT
PAR35 Spherical mirror d.88mm
VL00735 Aspheric lens d.73mm
VL00290 Focusing lens d.98mm
LEN60 Frontal lens d.200mm
PL07 G22 socket
AL06 N°1 ballast 50/60Hz (1/2 ballast)
OB13 Capacitor 80microF (1/2 capacitor)
EA00012 Power supply filter 25A
EI00042 Rélé 230V 2x40A
MOT43/2 Stepper motor (specified the function when order)
MOR03 Ceramic buckler
VEN02/P 120mm FAN 230V (for ballast)
MO00017 Projector big special FAN, with capacitor
EI00045 Lever safety switch
EE00111 Master electonic board for 5 stepper motors
EE00103 PCB with dip-switches
EEPROM for Master PCB Supertracer (STRACER7)
EE00148 TRACER/SUPERTRACER consolle
EE00130 PCB distribution (fastom)
EE00145 PCB power supply (buckler)
AB00143 Lamp ignitor MSR-HTI 2500W
EA00011 Work counter hour (50/60Hz to be specified when order)
IR00006 Only iris (professional iris)
VM00005 Plastic handle (big)
VOL05 Lateral plastic handle
VP00063 Focusing belt 1400 MXL 025
GM01050 Supertracer support bracket
GM00276 Colours wheel
GM00995 Correction filters wheel
On request is available complete spare sparts list with images for Supertracer (send e-mail please)
WARRANTY
SUPERTRACER is guaranteed against any manufacturing defects or material flaws. If defects or breakdowns
occur during the warranty period, the manufacturer, directly or through its agents. After inspection and according to
its own unquestionable judgment, the manufacturer will repair or replace the defective part.
No goods can be returned, for any reason without previous authorisation from the manufactured, and the transport
charges, to and from LAMPO are at the cost of the client.
The warranty is not valid in the following cases:
1 If the projector was used improperly or with negligence, or if it was damaged and repaired and/or modified to the
point of jeopardizing safe functioning.
2 If the projector is used in conditions other that those specified in this manual.
3 If non-original spare parts are used.
4 All malfunctioning and breakdowns caused by acts of God, negligence, and improper use, and parts subject to
wear are not covered by the warranty.
The improper use of this projector, cancel the guarantee and our responsibility. All the information have been written and driven
with extreme care; however, we do not engage us any responsibility for contingent errors or omissions. We reserve the right to
modify and/ or improve our product as we retain necessary, without subsequent warning or notice. It is forbidden any complete
or partial reproduction of this handbook, if not expressly authorized.
Loading...
