LaMotte LSCV User Manual
CHRO MIUM TEST KIT
MODEL LSCV • CODE 7678-01
QUANTITY CONTENTS CODE
60 mL *Sulfuric Acid, 5N *7681-H
10 g *Chromium Reagent Powder *V-6276-D
15 mL *Sodium Azide, 5% *7683-E
30 mL Potassium Permanganate, 0.5% 7682-G
60 mL Deionized Water 5115PS-H
1 Pipet, 0.5 mL, plastic, w/cap 0369
1 Pipet, plain, glass, w/cap 0341
1 Pipet, 1 mL, plastic 0354
2 Test Tubes, 5 mL, glass, w/caps 0230
1 Graduated Cylinder, 50 mL, glass 0418
1 Erlenmeyer Flask, 125 mL, glass 0431
1 Spoon, 0.05 g, plastic 0696
1 Test Tube Holder 1113
1 Chromium Comparator, 0.1-1.5 ppm 7679
*WARNING: Reagents marked with an * are considered to be potential health
hazards. To view or print a Material Safety Data Sheet (MSDS) for these
reagents go to www.lamotte.com.To obtain a printed copy, contact LaMotte by
e-mail, phone or fax.
To order individual reagents or test kit components, use the specified code
number.
USE OF THE OCTET COM PARA TOR
L
Mott
The Octet Comparator contains eight permanent
color standards. A test sample is inserted into the
openings in the top of the comparator. The
sample can then be compared to four color
standards at once, and the value read off the
comparator. For optimum color comparison, the
comparator should be positioned between the
operator and a light source, so that the light
enters through the special light-diffusing screen
in the back of the comparator. Avoid viewing the
comparator against direct sunlight or an
irregularly lighted background.
PRO CE DURES
HEXAVALENT CHROMIUM
1. Fill test tube (0230) to 5 mL line with sample water.
2. Use the 0.05 g spoon (0696) to add one level measure of *Chromium
Reagent Powder (V-6276). Cap and shake for one minute. Wait five
minutes.
3. Insert test tube into the Chromium Comparator (7679). Match
sample color to a color standard. Record as ppm Hexavalent
Chromium (Cr+6).
