Lakeside Foodservice 139 Specifications
Open Pan & Tray Racks
Spec. #
AIA #
Specifications
Unit shall be of all-welded construction and shall accommodate 18” x 26” (457 x 660 mm) pans or 14” x
18” (356 x 457 mm) pans and trays. Corner upright legs and top and bottom frame shall be of .104 x
3/4” x 1-1/4” angle stainless steel. Pan/tray ledges shall be of 16-gauge stainless steel and shall be
welded to upright legs front and back. Top and bottom corner frame joints shall have 16-gauge
reinforcing gussets welded in place for extra rigidity. Unit shall have a 16-gauge 1/2” x 1/2” angle
stainless steel horizontal brace welded to upright legs at open ends front and back. Casters shall be 5”
(127 mm) diameter swivel stem type, mounted to corner legs for upright stability. Unit shall be NSF listed.
Lit# 0602 OPTRS Lakeside reserves the right to modify specifications or discontinue models without prior notification. Printed in the U.S.A.
Standard Series - Stainless Steel
Item #
Quantity
Durable, Efficient Storage System
With All-welded Stainless Steel
Construction.
•
Fully assembled.
•
Both channel and angle style ledges are
electronically welded to the uprights to
withstand continual use. Tie bars are welded to
the uprights for added rigidity.
•
A variety of casters are available from
economical 4” (102 mm) corner stem to heavy
duty 5” (127 mm) recessed plate with No-Mark
®
polyurethane wheels.
•
Welded stainless steel design is easy to
sanitize and maintain.
Ideal for...
•
Hotels, central kitchens, hospitals and schools.
•
Refrigerated or dry storage.
•
Convenient sheet pan and tray transport.
Lakeside Manufacturing, Inc.
4900 West Electric Avenue • West Milwaukee, WI 53219 U.S.A.
800-558-8565 • 414-902-6400 • Fax 414-902-6446 • www.eLakeside.com
PR-2
Optional Accessories
• Set of four each corner leg bumpers.
• Welded pan top rod.
• Set of two each brake casters.
Model 139
Open Pan & Tr ay Racks
Standard Series - Stainless Steel
Spec. # AIA #
Lit# 0602 OPTRS Lakeside reserves the right to modify specifications or discontinue models without prior notification. Printed in the U.S.A
.
AutoCAD drawings available through KCL CADalog
Model
Pan Capacity Ledge Description Overall Size
Lake-Glide
®
Casters
Case
Weight
Full Half Type Spacing Width W D H Type Dia. Lbs. (Kg)
127 24 ea. 48 ea. Channel
1-7/16” 1/2” 21” 29-1/4” 43-1/2”
Corner
Stem
5”
56 (25.4)
(37) (13) (533) (743) (1105) (127)
128 35 ea. 70 ea. Channel
1-7/16” 1/2” 21” 29-1/4” 58-1/2”
Corner
Stem
5”
73 (33.1)
(37) (13) (533) (743) (1486) (127)
129 41 ea. 82 ea. Angle
1-7/16” 1/2” 21” 29-1/4” 68-1/2”
Corner
Stem
5”
78 (35.4)
(37) (13) (533) (743) (1740) (127)
137 11 ea. 22 ea. Angle
3” 1-5/16” 21” 29-1/4” 43-1/2”
Corner
Stem
5”
53 (24)
(76) (33) (533) (743) (1105) (127)
138 16 ea. Angle
3” 1-5/16” 21” 29-1/4” 58-1/2”
Corner
Stem
5”
70 (38.8)
(76) (33) (533) (743) (1486) (127)
139 20 ea. 40 ea. Angle
3” 1-5/16” 21” 29-1/4” 68-1/2”
Corner
Stem
5”
80 (36.3)
32 ea.
Measurements in ( ) denote metric millimeters, unless otherwise specified.
Model 163
Model 172
D
D
W W
H
H
D
W
H
Model 129
158
159
162
163
172
173
182
(76) (33) (533) (743) (1740) (127)
157 7 ea.
Dimensions
21”
14 ea. Angle
5” 1-5/16”
10 ea.
12 ea.
37 ea.
41 ea.
18 ea.
20 ea.
11 ea.
12 ea.
20 ea.
24 ea.
74 ea.
82 ea.
36 ea.
40 ea.
22 ea.
24 ea.
Channel
Channel
Angle
Angle
Angle
Angle
Angle
Angle
(127)
5”
5”
(127)
(127)
1-7/16”
1-7/16”
(37)
3”
3”
5”
5”
183 (127)
(127)
(76)
(76)
(37)
(33)
(33)
(33)
1-5/16”
1-5/16”
1/2”
1/2”
(13)
(13)
1-5/16”
1-5/16”
1-5/16”
1-5/16”
(33)
(33)
(33)
(33)
21” 29-1/4” 43-1/2”
21”
21”
21”
21”
21”
21”
21”
(533)
(533)
(533)
(533)
(533)
(533)
(533)
(533)
(533)
(743)
29-1/4”
29-1/4”
(743)
(743)
26-1/4”
(667)
26-1/4”
26-1/4”
26-1/4”
26-1/4”
26-1/4”
(667)
(667)
(667)
(667)
(667)
(1105)
58-1/2”
(1486)
68-1/2”
(1740)
62-1/2”
(1588)
67-1/8”
(1705)
62-1/8”
(1578)
67-1/8”
(1705)
62-1/8”
(1578)
67-1/8”
(1705)
Corner
Stem
Corner
Stem
Corner
Stem
Recessed
Plate
Recessed
Plate
Recessed
Plate
Recessed
Plate
Recessed
Plate
Recessed
Plate
5”
(127)
5”
5”
5”
5”
5”
5”
5”
5”
(127)
(127)
(127)
(127)
(127)
(127)
(127)
(127)
45
57
62
75
82
77
80
60
65
(20.4)
(25.9)
(28.1)
(34)
(37.2)
(34.9)
(36.3)
(27.2)
(29.5)
Lakeside Manufacturing, Inc.
4900 West Electric Avenue • West Milwaukee, WI 53219 U.S.A.
800-558-8565 • 414-902-6400 • Fax 414-902-6446 • www.eLakeside.com
PR-2
