Page 1
Solar Dock Dots – (1-3/8”)
Solar Dock Dots: LL
Solar Dock Dots are simply the neatest, smallest, solar lights you
have ever seen! Super Bright LEDs make these brilliant
lights
unnoticeable during the day and eliminates any tripping hazards.
Easy to install in minutes with a quick 1
super bright LED and powerful solar panel provide all night
illumination. Impress all the neighbors with these simply to install
solar
5
MODEL: LL-SDD-X
3
Lumens
stand out at night! A flush mount makes them virtually
units!
-Color Options to choose from: White, Blue, Green, Red, Amber
-SDD-X
solar
-3/8” drill bit or hole saw. A
LIGHT CHARACTERISTICS
Light Source 1-Ultra-High intensity LED
Lumens output 2-3 Lumens *Varies with Color & Conditions
Available LED Colors White, Blue, Green, Amber, Red
Light Mode Options Constant
Visible Range 50m – 300m+ Depending on Installation
Horizontal Output (degrees) 360 + Horizon
Vertical Divergence (degrees) 35-45 Degrees
LED Life Expectancy (hours) > 100,000 hrs
ELECTRICAL CHARACTERISTICS
Circuit Protection Integrated
Nominal Voltage (v) 1.2v
Autonomy (hours) 16-20hrs *On full Charge
Temperature Range -20 to 70 C
SOLAR CHARACTERISTICS
Solar Module Type Multicrystalline or Monocrystalline
Power (watts) 0.45 watts
Solar Module Efficiency (%) 16-17%
POWER SUPPLY
Battery Type High Grade NiMh – ECO Friendly
Battery Size 1/3 AAA
Battery Capacity (mAh) 120 mAhr
Nominal Voltage (v) 1.2v
Battery Service Life 1-3 years (Varies with local Environment)
Battery Service Access Yes: User Changeable / Replaceable
PHYSICAL CHARACTERISTICS
Body Material UV Stabilized Poly Carbonate
Lens Material UV Stabilized Poly Carbonate
External Lens Design Integrate Convex Optics & Diffusion
Internal Lens design 360 Deg. Convex Optics & Diffusion
Water Proof Rating IP 68
Mounting 1 – hole (1-3/8”) Diameter / (35mm)
Height 35mm
Width / Diameter 35mm Body & 42mm Lip
Weight ___G
OPTIONS
Custom Options, Sizes, & Colors Please Contact
Custom Hardware & Mounting Please Contact
* Information subject to change without notice
Lake Lite Inc.
105 W. Simon St.
Laotto, IN 46763
Phone: 260-918-2758
Fax: 260-918-3540
E-mail [email protected]
www.lakelite.com
www.solarmarinelites.com
Page 2
Solar Dock Dots – (1-3/8”)
MODEL: LL-SDD-X
42mm
42mm
Dimensions = mm
Owner Registration Card
Please fill out and affix proper postage and return this owner
registration card within 10 days to insure that yo ur new So lar Dock
Dots is covered by the limited warranty.
Purchaser’s Name .
Address .
State . Zip .
Purchase Date: . Number of Lights: .
Where Purchased (Store Name): .
Model No. LL-SDD-X
UPC No. Varies On Different Models
Lake Lite Inc.
P.O. Box 414, Laotto, IN 46763
1-3/8”
35mm
35mm
29mm
1-3/8”in
35mm
Lake Lite Inc. 1-Year Limited Warranty
The retail e r warrants the Solar lights to be fre e from defects in wo rkmanship and m aterial present
at time of shipment from the factory for a period of one year after the date of purchase by the
original pur chaser. We agree to correct s uc h defects without charge or at our o pt io n replace with a
comparabl e or superio r m o del if the product is returned to the retailer. To obtain war ranty ser v ic e ,
you must present a copy of the receipt as pr oof of purchas e . Al l costs o f removing and reinstalling
the product are you re s ponsibility. D a m age to any part s uch as by accide nt or misuse or improper
installation or by affixing any accessories, is no t co vered by this warranty. T he r e is no other
express warr anty . T he retail e r her e by disclaim s any and al l war ra ntie s, incl udin g but not lim ite d
to, those of mer chant ab ility and f itness for a particul ar purpose to the extent perm itted by law. The
duration of any implied war r anty, which cannot be disclaime d, is limited to the tim e period as
specified in the expr e s s w a r r an ty. Some state s do no allow limitation on how long an im plied
warranty lasts, so the above limitation may not apply to you. The re tailer shall not be l ia bl e fo r
incidental, conseque ntial, or spe c ial damages a r is ing out of or in co nn e c tio n with produc t use or
performance except as may otherwise be accorde d by law. Some states do no t al l o w the exclusion
of incidental or consequential damage, so the above exclusion or limitation may apply to you.
This warranty g iv es specific legal rights, and you may also have o the r rig hts, which vary fro m
state to state. This warr anty supers ede s al l prior w ar rantie s.
Lake Lite Inc.
105 W. Simon St.
Laotto, IN 46763
Phone: 260-918-2758
Fax: 260-918-3540
E-mail [email protected]
www.lakelite.com
www.solarmarinelites.com
Page 3
Solar Dock Dots – (1-3/8”)
MODEL: LL-SDD-X
Installing Batteries
1. Remove Back Cover with Screwdriver
2. Install Battery in correct position
3. Install Silicon Pad over battery
4. Install plastic cover with screw driver
5. Turn Tightly to make a good seal
(Replace with 1.2v NiCd or NiMh type Rechargeable Batteries ONLY)
Mounting to Surface
1. Mark Desired locations for mounting solar lights
2. Use 1-3/8” (35mm) diameter saw to make hole
3. Install lights into hole
4. If necessary you may use a silicone based glue to
secure light into place
Bottom View
Battery
Tools Required
Silicon Pad
1-3/8”
Cover
Storage Tips (Harsh Winters)
Extreme winter weather can reduce the life expectancy of your Solar Dock Dot
1. Extreme Cold weather can drama tically reduce the life expectancy of your rechargeable Ni-Cd or Ni-Mh battery.
2. Store your Solar Dock Dot Lite inside during cold months when your dock is not i n us e .
CAUTION: CONTAINS NICKEL-CADMIUM BATTERIES. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
Lake Lite Inc.
105 W. Simon St.
Laotto, IN 46763
Phone: 260-918-2758
Fax: 260-918-3540
E-mail [email protected]
www.lakelite.com
www.solarmarinelites.com
