TLP-F02 User Manual
V1.0
Description Remote Control / Transmitter
Model TLP-F02
AppearanceΚ
Material:
Material Specification Color
PCB Two layers Green
Faceplate PC Black
Casing ABS Black
Button 2 1 Red / 1 Gray
Laipac Technology, Inc. | www.laipac.com | Tel: 1-(905)762-1228 Fax: 1-(905)763-1737
1
Page 2
Specifications
Frequency
Modulation type
Channel Spacing
Distance
433.9MHz
ASK
±250KHz
25~120M (Depending on
sensitivity)
Battery
Current
DC 12V
5.6mA ± 0.5mA
FCC Approved: Rule Parts 15.231
Application Notes
1. TLP-F02 Diagram
Receiver's
Encoding
Setting Switch
Button
Input
Encoder
(HT12E)
2. TLP-F02 Encoding Circuit
SW2
1
2
3
4
5
6
7
8
SW DIP-8
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
9
U3
A0
A1
A2
A3
A4
A5
A6
A7
VSS
HT12E
VDD
DOUT
OSC1
OSC2
TE
AD11
AD10
AD9
AD8
18
17
16
15
14
13
12
11
10
R1
10K
RF
RF
"ON " BU TTO N
ROSC 1M
D1
VBAT
"OFF" BUTTON
Laipac Technology, Inc. | www.laipac.com | Tel: 1-(905)762-1228 Fax: 1-(905)763-1737
2
Page 3
3. Receiver Side Reference Circuit
SW1
1
2
3
4
5
6
7
8
SW D IP-8
+5V
U2
1
NC
16
15
14
13
12
11
10
9
2
A0
3
A1
4
A2
5
A3
6
A4
7
A5
8
A6
9
A7
10
VSS
HT12D
NC
VDD
OSC1
OSC2
DIN
A11
A10
20
19
18
VT
A9
A8
ROSC 43K
17
16
15
14
13
12
11
U1
1
Gnd
2
Digit al Output
3
Linear Out
4
Vcc
RLP434A
ANT
Gnd
Gnd
Vcc
8
7
6
5
E1
ANTENNA
1
+5V
C1
0.1u
4. Transmitter and Receiver Status table
Transmitter Side Receiver Side
“ON”
Button
Pressed released 0 0 X X 0 0 X X
x pressed 1 0 X X 1 0 X X
“OFF”
Button
AD8 AD9 AD10 AD11 A8 A9 A10 A11
released released Power off Hold the status when button
pressed
Note:
Please refer to the datasheets of HT12E and HT12D for detailed information
about encoding and decoding circuit.
