Lagoon 620 User Manual

We share a common passion for the sea ; we, LAGOON, as catamaran builders and you who want to live your passion on the seven seas.

We are delighted to welcome you to the family of LAGOON catamaran owners and we congratulate you on it.

This instruction guide is intended to help you to enjoy your boat in comfort and safety. It includes the boat specifications, the equipment provided or installed, the systems on board and tips on her use and maintenance. Read this guide carefully before you put out to sea so that you can make the most of her and avoid any damage and above all any further problem. Read it and get to know your boat before using her.

In order to share with you as much new technology, new equipment or materials and company experience, our boats are constantly improved. This is why the specifications and information given are not contractual and may be modified without notice and without obligation of updating.

This instruction guide has a general purpose and may sometimes mention some equipment or accessories or deal with some points that are not relevant to your own boat ; if in doubt, refer to the inventory you were given on delivery of your boat.

If this is your first boat, or if you change to a new type of boat which you are not used to, get some training in boat control and sailing to ensure your safety and comfort. Your dealer, your international sailing association or your yacht club will be very happy to recommend local sailing schools or profesional instructors.

Although everything possible has been planned and designed with the safety of the boat and her users in mind, remember that sailing is highly dependent on the weather conditions and the sea state, and that only an experienced and very fit crew, handling a well-maintained boat, can sail satisfactorily.

The sea and wind conditions that correspond to design categories A, B, C and D are changeable and are still susceptible to the risk of unusually large waves or strong gusts of wind. Total safety cannot therefore be guaranteed, even if your boat meets the requirements of a category.

Our network of LAGOON authorized dealers will be at your disposal to help you get acquainted with your boat and will be the most qualified to take care of her maintenance.

Always read and listen to the weather forecast before you put out to sea. Make sure that the forecast sea and wind conditions will correspond to the category of your boat and that you and your crew are able to handle the boat in these conditions.

The sea and the water are not the natural environment of Man and he must respect their laws and strength.

Adapt the use of your boat to her condition that wears out with time and use. Any boat, however solid she may be, may be severely damaged if badly used. This is not compatible with a secure navigation. Always adapt the speed and direction of your boat to the conditions of the sea.

The "COLREG", international regulations for preventing collisions at sea, published by the International Maritime Organization, specify the rules relative to steering and courses, navigation lights, etc. throughout the world. Make sure you know these regulations and you have on board a manual that explains them.

In numerous countries, a licence, an authorization or a training course is requested. Make sure you have this legal authorization before you use your boat.

Always ensure an experienced professional carries out the maintenance of your boat, installs any accessories and makes any small modifications. The written authorization of the builder or his legal representative is compulsory for modifications that alter the specifications of the boat, in particular the vertical layout of the weights (installing a radar, modifying the mast, changing the engine, etc.).

The users of the boat are informed of the following :

- The entire crew must be properly trained.

- The boat must not carry a load heavier that the maximum load recommended by the builder, in particular the combined weight of food supplies, equipment not supplied by the builder and people on board.The load carried by the boat must be properly distributed.

- The water in the bilges must be maintained at a minimum.

- Stability is reduced when you add weight in the upper sections.

- In the event of heavy weather, the hatches, lockers and doors must be closed in order to minimize the risk of water coming in.

- Stability may be reduced when you tow a boat or lift heavy weights using the davits or the boom.

- Breaking waves are a serious danger to stability.

- If your boat is equipped with a life raft, read the instructions carefully.All the proper safety equipment must be carried on board (harness, flares, life raft, etc.) according to the type of boat, the country in which she is used, the weather conditions, etc.

- The crew must be familiar with the use of all the safety equipment and all emergency safety procedures (MOB, towing, etc.).

- Anyone on deck must wear a life jacket or a buoyancy aid. Please note that in some countries it is compulsory to wear an approved buoyancy aid permanently.

For essential or optional equipment (engine, electronics, etc.) refer to their respective manuals supplied with your boat.

Keep this manual in a safe place and hand it on to the new owner if you sell your boat.

Main specifications

L.O.A. ...........................................................................18,90 m / 62’

L.W.L....................................................................... 18,20 m / 59’9”

Main beam ............................................................10,00 m / 32’10”

Clearance height.....................................................31,00 m / 101’9”

Draft .............................................................................1,55 m / 5’1”

Theoritical light displacement...........................27000 kg / 59535 lbs

Theoritical maximum load displacement ..........35000 kg / 77175 lbs

Theoritical authorized maximum load................8000 kg / 17640 lbs

Bottom surface (appendages included) ..................................110 m

Water capacity ..............................................4x240 l / 4x63,5 US gal

Fuel capacity...............................................2x650 l / 2x171,5 US gal

Refrigeration unit capacity (110 V - 220 V) ............500 l / 132 US gal

Refrigeration unit capacity (24 V)..........................100 l / 26,5 US gal

Battery capacity (standard) ...........................................420 Ah (24 V)

Battery capacity (with optional extra) ............................840 Ah (24 V)

Starting battery (per engine) ...........................................50 Ah (12 V)

Generator starting battery ...............................................50 Ah (12 V)

Maxi engine power .............................................................2x150 CV

CE Certification category Number of persons

A....................................................................................................14

B....................................................................................................14

C....................................................................................................16

D ...................................................................................................30

LAGOON 62O

CONTENTS

SECTION 1 ...................................................................SAFETY

1.1 Safety equipment

1.2 Gas system safety instructions

1.3 Fire extinction

1.4 Bilge pump system

1.5 Emergency tiller

1.6 Engines

1.7 Towing

1.8 In case she capsizes

1.9 General points

SECTION 2 ..........................................................HULL / DECK

2.1 Construction

2.2 Companionway door

2.3 Access to fly helm station

2.4 Cockpit table

2.5 Gangway (optional extra)

2.6 Capstans (optional extra)

2.7 Steering gear

2.8 Windlass, anchoring

2.9 Deck wash pump (optional extra)

2.10 Davits (optional extra)

2.11 Tenderlift (optional extra)

SECTION 3....................................................RIGGING / SAILS

3.1 Sailing

3.2 Standing rigging

3.3 Running rigging

3.4 Sails Appendix

SECTION 4..........................................................ELECTRICITY

4.1 24 V system

4.2 12 V system

4.3 Inverters

4.4 110 V - 220 V system

SECTION 5..............................................................PLUMBING

5.1 Bilge pump system

5.2 Grey water system

5.3 Fresh water

5.4 Use of the marine heads

5.5 Black water holding tanks

5.6 Watermaker (optional extra)

SECTION 6................................................ACCOMMODATION

6.1 Saloon tables

6.2 Portholes and deck hatches

6.3 Floorboards

6.4 Access to the bins

6.5 Slot-in TV set (optional extra)

SECTION 7 ................................................ONBOARD UTILITY

7.1 Outside refrigerators

7.2 Microwave oven (optional extra)

7.3 Hob

7.4 Refrigerators, oven, hood

7.5 Washing machine (optional extra)

7.6 Dishwasher (optional extra)

7.7 Air conditioning (optional extra)

7.8 Icemaker (optional extra)

7.9 Grill (optional extra)

SECTION 8 .........................................................PROPULSION

8.1 Engines

8.2 Fuel

8.3 Propellers, anodes, shaft line brake

8.4 Bow thruster

SECTION 9...................……WINTER STORAGE / HANDLING

9.1 Laying up

9.2 Protection

9.3 Handling

9.4 Mast stepping, mast unstepping

SECTION 10 .................................UP KEEP / MAINTENANCE

10.1 Maintenance schedule

UPDATED 10/2013

1.1 SAFETY EQUIPMENT

1.2 GAS SYSTEM SAFETY INSTRUCTIONS

1.3 FIRE EXTINCTION

1.4 BILGE PUMP SYSTEM

1.5 EMERGENCY TILLER

1.6 ENGINES

1.7 TOWING

1.8 IN CASE SHE CAPSIZES

1.9 GENERAL POINTS

SSEECCTTIIOONN 11

SSAAFFEETTYY

SAFETY

SAFETY EQUIPMENT ON DECK

LAGOON 62O

1 - Location for life buoy.

2 - Deck eye for life line fastening.

3 - Emergency tiller.

4 - Emergency tiller cover.

5 - Location for life raft.

6 - Manual bilge pump.

7 - Extinguisher.

8 - .......................................

13 - .......................................

14 - .......................................

15 - .......................................

16 - .......................................

9 - .......................................

10 - .......................................

11 - .......................................

12 - .......................................

RECOMMENDATION

Some components do not have a pre-determined place for them. Fill-in this drawing according to your own boat safety equipments.

 1.1 Safety equipments

Before you sail, list the compulsory safety equipments.

Do not exceed the number of persons indicated in the "SPECIFICATIONS" Chapter.

The combined weight of the persons and equipment should never exceed the maximum load recommended by the builder.

LIFE LINES

- Fasten the life lines on the deck and under the bridgedeck (close to

the manhole).

LIFE RAFT

You shall use the life raft only as a last resort.

The locations for the life rafts are situated in the rear beam.

Fit your boat with life rafts in pursuance of the regulations of the country where the boat is registered.

SAFETY

LAGOON 62O

WARNING

The list of the compulsory safety equipement corresponds to a certification category, a design category as well as to the regulations in the country where the boat is registered.

WARNING

Regularly check the safety equipements is in good working order. Follow the service programme without fail. Generally speaking, take particular care of all the safety equipment of your boat.

RECOMMENDATION

Close the deck hatches and portholes before each trip.

RECOMMENDATION

Before you sail to sea, carefully read the launching instructions on the life raft.

GAS VALVES - LIFE RAFT CASE MEASUREMENTS

SAFETY

LAGOON 62O

1 - Gas valves.

(access in the cupboard on the left under the hob - Galley / hull version) (access in the cupboard on the right under the hob - Galley / saloon version)

2 - Regulator.

(access in the portside locker of the cockpit settee)

1 2

LIFE RAFT MEASUREMENTS

890 mm

530 mm

315 mm

490 mm

940 mm

Galley / saloon version

Galley / hull version

LAGOON 62O

SAFETY

 1.2 Gas system safety instructions

The gas cylinder is located in a locker of the cockpit settee. Type of cylinder 13 kg (butane), or according to current standards of your country.

Close the valves on the system and on the cylinder when the appliances are not used. Close the valves before you change cylinders and immediately in case of emergency. Never leave unattended an appliance that is working. Do not install flammable materials above or over the stove (curtains, papers, napkins etc.).

Do not use the oven or stove as back up heaters. Never obstruct the fast access to the components of the gas system. Make sure that the valves of the appliances are closed before you open the cylinder or pipe valve.

In case you smell gas or find that the burners have gone out (although appliance models cut off automatically if the flames go out), turn off the valves of the appliances. Do ventilate the boat in order to get rid of any residual gas. Find the cause of the problem.

Regularly test the gas system in order to detect any gas leak. Check all the connections using water and soap or detergent, closing the valves of the appliances and opening the valve on the cylinder. If you detect a leak, close the valve of the cylinder and repair before you use it again.

The appliances use the oxygen of the cabin and release combustible gases. Ventilate your boat when using appliances. Do not obstruct the air vents and at least leave the door open.

Keep the taps of the empty cylinders turned off and the cylinders disconnected. Keep the protections, lids, covers and taps in their places. Store the empty and spare cylinders on the deck or in a locker with a ventilation to the open air. Do not use the gas cylinder storage place to store other equipment. Only use the proper locker to store the gas cylinders.

Regularly check and replace the rubber tubings that link the cylinder to one end of the circuit and the stove to the other one, depending on the standards and regulations in force in your country. Pay particular attention to keep in good condition the screw thread of the cylinder on which the regulator is. Check the condition of the regulator every year and change it if necessary. Use regulators identical to the ones that are fitted.

Have the repairs carried out by someone skilled.

WARNING

- Never use a flame to detect leaks.

- Do not smoke, do not use a naked flame when you change the gas cylinder.

1 - Emergency exit.

2 - Extinguisher.

3 - Release pull handle of engine extinguisher.

4 - Engine extinguisher.

5 - Distress flares.

6 - First aid kit.

7 - VHF (optional extra).

8 - .........................................

9 - .........................................

10 - .........................................

11 - .........................................

12 - .........................................

13 - .........................................

14 - .........................................

15 - .........................................

SAFETY

INDOOR SAFETY EQUIPMENT

LAGOON 62O

RECOMMENDATION

Some elements do not have a pre-determined place for them. Fill-in this drawing according to your own boat safety equipments.

Galley / saloon version

Galley / hull version

Fixed extinguishing system for the engine bilge (access in the engine bilges).

 1.3 Fire extinction

The boat has a fixed extinguishing system meant only for the engine bilges as standard equipment. Check that mounted fire extinguishers have their pins removed before unberthing. Nota : replacing the pins in mounted fire extinguishers is recommended during prolonged work in the engine holds in order to avoid any untimely activation.

Be sure :

- To equip the boat with extinguishers in pursuance of the regulations

of the country where your boat is registered.

- To have the extinguishers checked according to the instructions given.

- To refill or replace the extinguishers by similar equipment if the

extinguishers have been used or are out of date.

- To ensure the extinguishers are accessible when people are on

board.

- To fill-in the drawing opposite, indicating the locations for the

extinguishers.

Before each trip to sea, tell the crew : . where the extinguishers are and how they work, . where the release pull handles of the extinguishers in the engine bilges are, . where the emergency exits are.

ESSENTIAL PRUDENCE RULES

Never :

- Obstruct access to the emergency exits.

- Obstruct safety controls (fuel valves, gas valves, power switches).

- Obstruct the access to the extinguishers placed in cupboards or lockers.

- Leave the boat unattended when a stove or heater is in use.

- Use gas lamps in the boat.

- Alter any of the boat's systems (electricity, gas or fuel).

- Fill up a tank or change a gas cylinder when an engine is running or a stove or heater is on.

- Smoke while handling fuels or gas.

Do not install free hanging curtains or other fabrics near to or above cooking appliances or other naked flame devices.

Make sure that holds are clean at all times and regularly check that there are no fumes or fuel and gas leaks. Flammable products should not be stored in the engine bilge. Nonflammable products stored in the engine bilges should be fastened to prevent them from falling on the machine and obstructing access.

SAFETY

LAGOON 62O

WARNING

Use only CO2 extinguishers to fight electrical fires. Evacuate the area immediately after discharging the product to prevent asphyxia. Ventilate before entrering.

WARNING

Should you replace components of the fire extinction system, only proper components with the same designation or with equivalent technical capacities and fire resistance should be used.

PULL HANDLES OF FUEL VALVES - ENGINE BILGE EXTINGUISHER

SAFETY

LAGOON 62O

1 2

1 - Cut off device of generator

tank fuel supply (portside).

2 - Release mechanism of

portside engine bilge extinguisher.

3 - Cut off device of portside

tank fuel supply.

Access by the pull handles under the hob in the galley in the portside hull aft.

1 2

1 - Cut off device of portside

tank fuel supply.

2 - Release mechanism of

portside engine bilge extinguisher.

3 - Cut off device of generator

tank fuel supply (portside).

Access by the pull handles behind the hatch under the bedside storage at the aft end of the port hull.

4 - Release mechanism of

starboard engine bilge extinguisher.

5 - Cut off device of starboard

tank fuel supply.

Access through the hole behind the WC in the starboard hull aft.

Galley / saloon version

Galley / hull version

4 5

1 - Release mechanism of

engine bilge extinguisher.

2 - Cut off device of tank

fuel supply.

3 - Cut off device of generator

tank fuel supply.

Access in the port and starboard rear cabins under the berths.

6 cabins version

1 2

PROCEDURE TO FOLLOW IN THE EVENT OF FIRE

- Stop the engine if it is running.

- Cut off the power supply, the fuel supply and the gas supply if

necessary.

- Cut off all sources of air (smother the fire using blankets).

- Hold the extinguisher upright and aim at the heart of the fire.

If fire has broken out in an engine bilge :

- Stop the engine if it is running.

- Cut off the power supply, the fuel supply and the gas supply if

necessary.

- Shut off the air supply using towels to block off the engine air inlets,

intakes and outlets.

- Set off the extinguishing product using the engine extinguisher

release pull handle (access by the pull handle under the hob in the galley (portside hull aft), and the one in the hole at the bottom of the stairs to the owner's study (starboard hull aft).

- Make sure that the fire is completely under control.

- Open the bilge access hatch to make any necessary repairs.

 1.4 Bilge pump system

ELECTRIC BILGE PUMPS The Lagoon 620 is fitted with one automatic start electric bilge pump per hull and one per engine compartment. These electric pumps work on 24 V electricity, even when the general battery switch is turned to OFF.

These four bilge pumps may be switched to manual operation from the 24 V electrical panel.

MANUAL BILGE PUMPS In case of electric bilge pump slowdown or failure, it is possible to use the manual bilge pumps. They are located on the sides of the aft setteee in the cockpit. They suck up water from the hull sump wells. Two manual bilge pumps are located in the front lockers. They suck up water from the front compartments.

PROCEDURE TO FOLLOW IN THE EVENT OF HULL BREACH Make sure that the electric bilge pumps are on. If it is not enough to reduce the water level, get a crew member to work one of the manual pumps.

SAFETY

LAGOON 62O

RECOMMENDATION

Always keep an extinguisher handy in case the fire should start again.

EMERGENCY TILLER - "MANHOLE" HATCHES

SAFETY

LAGOON 62O

1 - "Manhole" hatch. 2 - Steering ram.

3 4

3 - "Manhole" hatch. 4 - Hammer to break the glass

in the event of capsizing.

5 - Valve of the steering ram.

6 - Emergency tiller. 7 - Screw + fastening nut of

tiller.

8 - Valve of the ram in by-

pass position.

Galley / saloon version

Galley / hull version

 1.5 Emergency tiller

The emergency tiller is stored in a locker. It shall be kept easily accessible.

To operate the tiller :

- Use a winch handle and unscrew one of the tiller covers situated on one of the aft transom extensions.

- Insert the tiller into the rudder stock, making sure it is well fitted into the tiller head block.

- Insert the fastening screw across the stock and tighten the nut (access by the engine bilge).

- Turn to the by-pass position the ram valve situated in the engine bilge of the concerned side. The rudder is then isolated from the steering system.

 1.6 Engines

Stop the engines before diving or swimming around the boat. The blades of a propeller are sharp and may cause very important damages when spinning. Do not try to remove a fishing net or line caught in the propeller when the lattter is rotating.

Before weighing anchor or leaving a dock, check that the propeller is working in both positions forward and backward (presence of a shaft line brake). In the event of unusual noise or vibrations from the propeller, stop the engine immediately. If the problem persists, contact the builder or your nearest supplier.

In the event of the use of a folding propeller, read carefull the manufacturer's instructions for use and maintenance.

 1.7 Towing

Tow another boat at a reduced speed and as smoothly as you can. Be particularly careful when throwing or catching the towing line (it may catch on the propellers).

 1.8 Capsizing

IN THE EVENT OF CAPSIZING : Four "Manhole" hatches are provided for under the companionway stairs in the hulls - and in the fore parts of the hull if lay-out done this way. Remove the stairs to accede to them. There is a hammer to break the glass near each hatch and at the bottom of the life raft lockers.

You can have access to the life rafts on the rear beam (refer to the beginning of the chapter).

 1.9 General points

Know where your crew members are and inform them before any handling on the boat. Handle the boat with caution and always wearing shoes.

SAFETY

LAGOON 62O

SSEECCTTIIOONN 22

HHUULLLL DDEECCKK

2.1 CONSTRUCTION

2.2 COMPANIONWAY DOOR

2.3 ACCESS TO FLY HELM STATIONS

2.4 COCKPIT TABLE

2.5 GANGWAY (OPTIONAL EXTRA)

2.6 CAPSTANS (OPTIONAL EXTRA)

2.7 STEERING GEAR

2.8 WINDLASS, ANCHORING

2.9 DECK WASH PUMP (OPTIONAL EXTRA)

2.10 DAVITS (OPTIONAL EXTRA)

2.11 TENDERLIFT (OPTIONAL EXTRA)

DECK FITTING

HULL DECK

LAGOON 62O

COMPANIONWAY DOOR

HAND OPENING OF THE ’ACCESS

HATCH TO THE FLY

SWITCH (IN COCKPIT)

TO OPEN THE ’ACCESS

HATCH TO THE FLY

SWITCH (IN FLY)

TO OPEN THE ’ACCESS

HATCH TO THE FLY

LAGOON 62O

 2.3 Access to the fly helm stations

You will have access to the fly helm stations with stairs from the cockpit. You can slide shut this access. The opening of the access hatch to the fly can be electricallyoperated (optional extra). The electric opening operates on 24 V (the 24 V / 12 V inverter switch being on).

Regularly rinse the slide rails with fresh water.

 2.4 Cockpit table

You can install the cockpit table de cockpit either in high or low position. Change its legs (stored in a cockpit locker) to pass from one position to the other.

 2.1 Construction

The LAGOON 620 is made of balsa cored sandwich and made under vacuum using quadraxial glass roving and resin-impregnated marine plywood.

The deck is made of balsa cored sandwich with plywood inserts where deck fittings are installed. The deck to hull joint is glued and screwed.

 2.2 Companionway door

The sliding door can be locked in three different positions : closed, ajar (airing position) and open. You can lock it from the inside of the saloon with a latch on the jamb of the door.

HULL / DECK

HULL

DECK

RECOMMENDATION

While sailing, block the sliding door locking it.

AVERTISSEMENT

Do not let the hull's large plexiglass windscreens come into contact with fenders or hawsers: surface damage would be irreparable.

GANGWAY CONTROLS

GANGWAY (OPTIONAL EXTRA) - CAPSTAN (OPTIONAL EXTRA)

HULL DECK

LAGOON 62O

CAPSTAN

FUSE OF HYDRAULIC

SYSTEM (GANGWAY)

CAPSTANS CIRCUIT

BREAKER

1 - Gangway fuse + capstan circuit breaker. 2 - Gangway control. 3 - Gangway. 4 - Electric engine of the gangway.

LAGOON 62O

HULL / DECK

HULL

DECK

 2.5 Gangway (optional extra)

The gangway is operated by a hydraulic ram. It is automatically energized as soon as the board general battery switch is on the ON position. The gangway control is on the side of the portside aft transom extension. Press simultaneously both buttons to operate it. Press OFF to stop it. A remote control is available on board as well.

If it does not work, check CF8 fuse situated in the service room of the foredeck.

 2.6 Capstans (optional extra)

They are automatically energized as soon as the board general battery switch is on the ON position. The capstan controls are at the bottom of the side of the portside and starboard aft transom extension.

If they do not work, check their circuit breakers situated in the service room of the foredeck.

For the sake of safety, a switch at the portside helm station makes possible to switch off the capstans as well as the windlass and all the electric winches.

 2.7 Steering gear

The steering system consists of two steering wheels, a hydraulic drive system with manual pumps on the helms and hydraulic rams for the rudders.

The suspended rudders are fitted with stainless steel stocks. Each steering wheel works independently.

You have access to the helm and rams through the engine bilges.

Only WD 40 should be used to maintain nylon ertalon or teflon bushings.

Refer to section 1.5 for operating the emergency tiller.

ANCHORING

LAGOON 62O

WINDLASS

CIRCUIT

BREAKER

WINDLASS

CONTROL

STROP MADE FAST

ONTO THE CHAIN

STROP FASTENING

TO THE FORE BEAM

STROP INSIDE THE

ANCHOR ROLLER

1 - Electric windlass. 2 - Electric windlass remote control. 3 - Electric windlass circuit breaker. 4 - Electric windlass control + chain counter. 5 - Electric windlass switching-off device.

HULL DECK

 2.8 Windlass, anchoring

The electric windlass works with the 24 V domestic batteries. Operate the windlass from the helm station or with the control in a locker to starboard on the foredeck.

In the event of the electric windlass failure to operate, check its circuit breaker in the service room on the foredeck. For the sake of safety, a switch at the portside helm station makes possible to switch off the electric windlass as well as the capstans and all the electric winches.

Refer to the manufacturer's instructions for windlass maintenance.

PREPARING ANCHORING Set the strop fastening it to the chainplates at the ends of the main beam. Insert the strop inside the stem anchor roller. Make fast the strop to the central cleat when lowering the chain.

ANCHORING Have your boat head wind and without speed. Pay out the chain while moving back slowly. Secure the chain on the strop. Release the chain until the strop is taut.

LIFTING THE ANCHOR Ensure that the chain is properly set on the gypsy. Activate the windlass in the upward position. Slowly go near the anchor using the engine (do not use the windlass force to winch up the boat). Visually check the final metres until the anchor makes contact with the anchor roller. Check the position of the anchor on the stemhead fitting. In the event of electrical failure, use the winch handle on the windlass to lift the anchor. Nota : the boat is fitted with a chain counter. The standard measurement "Zero" corresponds to the position of the anchor ready to be dropped. Refer to instructions for its use and maintenance.

HULL / DECK

HULL

DECK

LAGOON 62O

RECOMMENDATION

Before anchoring, check the depth of water, the power of the current and the quality of the bottom.

RECOMMENDATION

The electric windlass should be used with one or two engines running.

WARNING

Windlass operations are dangerous :

- Always keep the ground takle clear and free.

- Always proceed with care, wearing gloves and always wearing shoes.

- Make sure that nobody leans on the windlass when operating the control.

DECK WASH PUMP (OPTIONAL EXTRA)

HULL DECK

LAGOON 62O

1 - Intake to connect hose. 2 - Deck wash pump (24 V). 3 - Valve to select fresh water / sea water. 4 - "Gardena" type connector (not provided). 5 - Circuit breaker / switching on device.

 2.9 Deck wash pump (optional extra)

The deck wash pump is located in the service room of the foredeck. It provides sea water or fresh water from portside tanks (access to the selection valve through service room).

You start it on the 24 V electrical panel.

Push the plastic rim of the intake to connect or disconnect the "Gardena" type connector (not provided).

HULL / DECK

HULL

DECK

LAGOON 62O

DAVITS (OPTIONAL EXTRA) - TENDERLIFT (OPTIONAL EXTRA)

HULL DECK

LAGOON 62O

RADIOCONTROL + CONTROL

OF THE DAVITS

OR THE TENDERLIFT

1 - Fuse. 2 - Ram + control. 3 - Davits.

FUSE OF THE SYSTEM

(DAVITS)

DAVITS

TURNBUCKLE OF THE

TENDERLIFT

 2.11 Tenderlift (optional extra)

The tenderlift is operated by a electric strut. It is automatically energized as soon as the domestic general battery switch is set to ON. Its control is in the cockpit aft locker. An optional radiocontrol is delivered with the boat. Switch off the radiocontrol after using it. If it does not work, check the fuse located in the fore deck service room.

When sailing, secure the tender resting on the cradles.

HULL / DECK

HULL

DECK

LAGOON 62O

WARNING

The davits are designed to support a maximum load of 400 kg and a tender which is maximum 4,50 metres long.

 2.10 Davits (optional extra)

The davits are operated by an electric ram. They are automatically energized as soon as the domestic general battery switch is set to ON. If it does not work, check CF8 fuse situated in the service room of the fore deck.

INSTALLING A TENDER ONTO THE DAVITS Fix the davit rope hooks to the front and rear parts of the tender. Remove the equipment from the tender and remove the water drain plug. Operate the control in the aft locker in the cockpit.

LAUNCHING A TENDER FROM THE DAVITS Put the water drain plug back into position in the tender. Tie up the tender. Operate the control in the aft locker in the cockpit.

When sailing, remove the tender engine and store it on board the boat. Install onboard the tender all the safety equipment in pursuance of the regulations of the country where your boat is registered.

WARNING

Nobody should be on board or under the tender during manoeuvres carried out with the davits. Tie up the tender during manoeuvres.

WARNING

The tenderlift is designed to support a maximum load of 350 kg and a tender which is maximum 4.60 metres long.

DANGER

It is strictly prohibited to sail when the tenderlift is in a position other than the utmost raised one. When sailing, the tenderlift shall imperatively be fastened in the up position with the turnbuckles .

3.1 SAILING

3.2 STANDING RIGGING

3.3 RUNNING RIGGING

3.4 SAILS APPENDIX

SSEECCTTIIOONN 33

RRIIGGGGIINNGG SSAAIILLSS

RIGHTING MOMENT

RIGGING SAILS

LAGOON 62O

Illustration of the difference of the righting moment existing between a 10 m monohull and catamaran.

d: distance between centre of the bottom and centre of gravity.

RMmax : Weight of the boat x d (RMmax : moment of maximum uprighting)

RRMMmmaaxx mmoonnoohhuullll ::

10 tons x 0,5 meter

:: 55 ttoonnss..mmeetteerr

RRMMmmaaxx ccaattaammaarraann ::

10 tons x 3 meters

:: 3300 ttoonnss..mmeetteerr

CATAMARAN Weight of the boat : 10 tons

MONOHULL Weight of the boat : 10 tons

D : 3 meters

D : 0,5 meter

LAGOON 62O

RIGGING / SAILS

RIGGING

SAILS

 3.1 Sailing

BEWARE A catamaran is about 6 times more resistant to heeling than a monohull. In naval architecture, it is referred to as uprighting moment (multiplication of the weight of the boat by the transversal distance between the centre of gravity and the centre of flotation (or bottom). See the illustration on the opposite page.

This fact has real consequences as for the sailing and sail trimming of a catamaran.

The fact that the boat does not heel may mask overcanvassing, which may be very dangerous for the crew and the boat. Therefore you MUST permanently keep a close eye on the speed of the true wind, and trim the sail surface according to the latter as a matter of priority. The below-mentioned trims apply in a calm sea. When the sea is brown, you shall reduce earlier by 10% as far as the speed of true wind is concerned. And as a general rule,it is absolutely imperative to permanently try to ease up the boat rather than to stress her.

You will always try to have the forward edges of the sails facing the apparent wind, and to have the sail not sheeted home, so that the airflow behind the sail may be laminar, that is to say so that it may go off the aft part of the sail without any disruption.

In case you shouldn't follow the recommendations below, it might be dangerous for the boat and the crew, and, in case of an accident, the manufacturer's responsibility would not be involved.

TRIMMING WHEN CLOSE HAULED (between 75 and 50° of true wind)

WWiinndd ffoorrccee ggiivveenn iinn aappppaarreenntt wwiinndd

FFrroomm 00 ttoo 1166 kknnoottss

: Full sail ; sheet traveller 30 cm above the centre line of the boat, mainsail sheeted with a slightly open leech (boom on the centre line of the boat). The genoa is trimmed so that it skims the spreader, the genoa traveller is set so that the angle of the genoa sheet is the continuation of a straight line that goes through the sheet clew and the luff, at 40% of its height.

FFrroomm 1166 ttoo 2200 kknnoottss

: Full sail ; the sheet traveller goes up 60 cm above the centre line of the boat, mainsail sheeted with a leech a little more open (boom always in line : therefore you must ease off the sheet). The genoa traveller remains at the same place but the sheet is adjusted so that the leech is 10 cm far from the spreader.

FFrroomm 2200 ttoo 2266 kknno

ottss

: 1 reef, full genoa ; the sheet traveller goes back to 30 cm above the centre line of the boat. The genoa traveller remains at the same place but the sheet is eased off so that the leech is 20 cm far from the spreader.

FFrroomm 2266 ttoo 3300 kknnoottss

: 1 reef, 75% of the genoa ; the sheet traveller goes up 60 cm above the centre line of the boat. The genoa traveller remains at the same place or slightly goes forward but it is adjusted so that the leech makes a propeller shape where the upper part let some air go off in increases of wind.

FFrroomm 3300 ttoo 3366 kknnoottss

: 2 reefs, staysail ; the sheet traveller is back 30 cm above the centre line of the boat, the sheet is 50 cm eased off and the boom is leeward.

SAILS

RIGGING SAILS

LAGOON 62O

 Sails

Sail surface close hauled....................................243 m

/ 2615 sq.ft

Fully battened mainsail.......................................139 m2/ 1496 sq.ft

Cruising square top mainsail...............................146 m2/ 1571 sq.ft

Furling genoa..........................................................91 m2/ 980 sq.ft

Spinnaker (optional extra) ...................................300 m2/ 3229 sq.ft

Gennaker (optional extra)....................................190 m2/ 2045 sq.ft

Furling staysail (optional extra) ...............................48 m2/ 517 sq.ft

I............................................................................23,320 m / 76’49”

J ........................................................................... 6,289 m / 20’63”

P...........................................................................24,700 m / 80’01”

E.............................................................................8,260 m / 27’09”

LAGOON 62O

RIGGING / SAILS

RIGGING

SAILS

FFrroomm 3366 ttoo 4455 kknnoottss

: 3 reefs, staysail to be shortened. The sheet traveller is on the centre line of the boat, the sheet is 1 metre eased off and the boom is leeward.

FFrroomm 4455 ttoo 5555 kknnoottss

: 3 reefs only (or try sail, or lying to), the traveller is on the centre line of the boat, the sheet is 1 metre eased off and the boom is leeward. The boat would be more at ease scudding in such a weather.

OOvveerr 5555 kknnoottss

: lying to, sea anchor, or preferably scudding.

TRIMMING WHEN DOWN WIND (between 75 and 130° of true wind)

FFrroomm 00 ttoo 2233 kknnoottss

: Full sail ; the traveller can be set at different places ranging from 1 metre off the centre line of the boat to the end of the track, depending on the angle of the wind, the sheet is eased off so that the boom may be leeward and 50 cm far from the traveller in dead calm then up to 2 metres when the wind strengthens.

In all the cases, you will avoid having more than one batten chafing against the upper shroud, in the fairest points of saling. The genoa is eased off in order to have its average front edge facing the apparent wind.

FFrroomm 2233 ttoo 2288 kknnoottss

: 1 reef, full genoa. The trimmings are similar.

FFrroomm 2288 ttoo 3333 kknnoottss

: 2 reefs, staysail.The trimmings remain similar.

FFrroomm 3333 ttoo 3388 kknnoottss

: 2 reefs, staysail shortened. The trimmings

remain similar.

FFrroomm 3388 ttoo 4455 kknnoottss

: 3 reefs (or mainsail lowered and a little more

staysail), staysail shortened. The trimmings remain similar.

FFoomm 4455 ttoo 5555 kknnoottss

: mainsail lowered, staysail shortened, sheeted

enough in order not to flap.

OOvveerr 5555 kknnoottss

: scudding, depending on the sea, you will set mooring ropes from one transom extension to the other one in order to reduce the speed of the boat.

CRUISING SQUARE TOP MAINSAIL

WARNING

If there is a radar aerial on the mast, keep an eye on the genoa when you put about or gybe in order to avoid any risk of damage.

WARNING

A cruising square top mainsail is more powerful than a standard mainsail. Shorten the sails earlier, depending on the wind conditions (about 5 knots before).

RUNNING RIGGING

RIGGING SAILS

LAGOON 62O

14 A-B

13 A-B

1 - Spinnaker / gennaker halyard (optional extra).

2 - Mainsheet.

3 - Reef pendant 3.

4 - Luff pendant - reef 3.

5 - Mainsail topping lift.

6 - Reef pendant 1.

7 - Reef pendant 2.

8 - Main halyard.

9 - Luff pendant - reef 1.

10 - Luff pendant - reef 2.

11 - Staysail sheet.

12 - Genoa sheet.

13A-B - Spinnaker / gennaker sheet + spinnaker guy.

14A - Portside control lines for mainsheet traveller.

14B - Starboard control lines for mainsheet traveller.

WARNING

The main traveller control lines shall not be used with the first winch: there exists a risk for the sheave to break (reason: too important an angle.) Do use the second winch only.

 3.2 Standing rigging

The LAGOON 620 is fitted with a mast with swept back spreaders ; it was adjusted by the shipyard and the mast manufacturer when it was first stepped. The cables stretch a little during the first sailings. Therefore it is advisable to have the mast inspected and adjusted by a specialist.

Before you put out to sea, it is essential to make sure that the standing rigging is in good condition : inspect the gooseneck, turnbuckles, and check the condition of the shrouds.

To hoist a crew member up to the top of the mast, use the man hoisting halyard. Belay the crew member with a bowline on the bosun's chair ring (do not use snap shackle or shackle).

RIGGING / SAILS

RIGGING

SAILS

LAGOON 62O

RECOMMENDATION

Any intervention on the standing rigging comes within a specialist remit.

DDeessccrriippttiioonn ooff tthhee rrooppeess lleennggtthh ((mm)) ddiiaammeettrree ((mmmm))

Genoa halyard on jammer 25 10

Genoa sheet 20 x 2 16

Staysail halyard on jammer 18 10

Staysail sheet 12 x 2 14

Main halyard 90 16

Mainsail topping lift 62 14

Main sheet 50 14

Main traveller adjusting rope 2 x 22 12

Reef 1 26 14

Reef 2 35 14

Reef 3 45 14

Cunningham 1 13 12

Cunningham 2 18 12

Cunningham 3 20 12

Lazy jack 2 x 30 10

Spinnaker guy 25 x 2 12

Spinnaker / gennaker sheet 42 x 2 14

Spinnaker / gennaker halyard 100 14

WARNING

The man hoisting halyard which is the only one to be authorized for this purpose, is only meant to hoist a crew member up to the top of the mast.

RUNNING RIGGING

RIGGING SAILS

LAGOON 62O

1 - Spinnaker guy.

2 - Gennaker / spinnaker sheet.

3 - Gennaker / spinnaker block.

4 - Main traveller control lines.

5 - Main traveller.

6 - Spreader lighting (fly lights). 7 - Deck floodlights. 8 - Boom lighting. 9 - Bimini lighting. 10 - Switch to switch off the windlass, electric winches,

genoa and fore staysail furling systems.

7 8 9 10

 3.4 Sails

STANDARD MAINSAIL

To hoist the standard mainsail :

- Point your boat into wind with engine in gear.

- Make sure that the mainsheet is eased off and the reefs are free.

- Open the jammer.

- Hoist the sail being careful for the battens not to get jammed in the lazy-jacks.

- Make fast the halyard with the jammer.

- Trim the mainsail according to the wind and sea conditions.

To lower the standard mainsail :

- Haul up.

- Tighten the topping lift.

- Slacken off the halyard, lower the mainsail then furl it.

- Tighten the sheet.

REEFING A SAIL For each of the three reefs, there is a pendant on the leech and one on the tack.

- Make the mainsail closer to the eye of the wind, either steering the boat or using the traveller.

- Ease off the mainsheet.

RIGGING / SAILS

RIGGING

SAILS

LAGOON 62O

 3.3 Running rigging

The mainsail, genoa and staysail sheets, the topping lift, the reefing lines, the mainsail and spinnaker halyards, the control lines for the main traveller are led back to the manoeuvre station.

The headsail roller furlers are switched on, switched off from the helm stations. In case of problem, refer to the instructions given in APPENDIX.

SHEET WINCHES AND MANOEUVRE WINCHES (MANUAL OR

ELECTRIC) (OPTIONAL EXTRA)

The circuit breakers of the electric winches are in the service room of the foredeck. Out of a concern for safety, all the electric winches can be switched off with a switch on the portside helm station (the capstans and windlass can also be switched off).

RECOMMENDATION

Have at least 3 turns on the winch. Electrical winches generate an extremely powerful force and you should use them with much care. Never force when you find a jamming point. When using the winches, keep your hands away. After use, shut the switch covers.

WARNING

Refer to the manufacturer's instructions to remove the winches and put them back. Improper refitting may result in accidents (for example : kick of the crank handle).

CRUISING SQUARE TOP MAINSAIL - MAINSHEET FUSE

LAGOON 62O

RIGGING SAILS

FASTENING OF THE

CRUISING SQUARE

TOP MAINSAIL

MAINSHEET FUSE

1 - Headboard traveller.

2 - Halyard block.

(to be fastened onto the headboard eye)

3 - Cruising square top mainsail.

- Tighten the topping lift.

- Slacken off the halyard.

- Tighten the tack pendant of the reef concerned till the lowest possible point, then close the jammer.

- Do the same for leech pendant of the concerned reef.

- Sway up the mainsail, then close the jammer.

- Slacken off the topping lift.

REEF SHAKING OUT

- Make the mainsail closer to the eye of the wind, either steering the boat or using the traveller.

- Ease off the mainsheet.

- Tighten the topping lift.

- Ease off the tack and leech reef pendants.

- Hoist the mainsail, then close the jammer.

- Slacken off the topping lift.

CRUISING SQUARE TOP MAINSAIL The cruising square top mainsail halyard is lashed on the eyelet of the sail, not on the headboard traveller. The square top will be properly set automatically once the sail is hoisted up.

FITTING OF THE MAINSAIL CRUISING SQUARE TOP SYSTEM Refer to the drawing on the opposite page.

- Remove the pin of the headboard car (mark A).

- Make the 2 strand tackle as per the drawing on the opposite page.

- Put back the headboard car pin (Mark A), adding the sheave.

The length of the headboard line is adjusted to the right dimension for

a new sail at the sailmaker's. The lashing (Mark D) makes possible to make up for the possible lengthening of the rope due to ageing.

Nota : this system is patented by the INCIDENCES sailmaker.

FUSE OF THE MAINSHEET The mainsheet is fitted with a "fuse" in fabric which ''informs'' you of overcanvassing. In case the "fuse" breaks, immediately reduce the surface of the mainsail.

Two spare "fuses" are supplied with the boat. Replace the fuse that is used as soon as possible, the sail being lowered.

RIGGING / SAILS

RIGGING

SAILS

LAGOON 62O

WARNING

A cruising square top mainsail has a more important power than a standard mainsail. Shorten the sail earlier depending on the wind conditions (about 5 knots before).

GENOA - STAYSAIL ELECTRIC FURLERS

RIGGING SAILS

LAGOON 62O

1 - Circuit breaker for genoa + staysail electric furlers.

2 - Control of genoa and staysail electric furlers.

ELECTRONIC BOX FOR

FURLER CONTROL

GENOA TIGHTENING

TRAVELLER

CONTROLS OF THE GENOA

AND STAYSAIL FURLERS

GENOA AND STAYSAIL SAIL SETTING Pay attention to the way the drum winds up : the genoa UV protection must be outside.

The genoa halyard has an extension linked to it through a whipping (figures on page 44).

- Hoist the genoa until the halyard whipping appears level with the tension adjustment track.

- Furl the genoa. The halyard can then be slackened.

- Separate the halyard from its extension.

- Have both of them fixed on each side of the tension adjustment traveller.

- Block the locker.

- Harden moderately the halyard until the traveller locks automatically one or two notches lower. Once the genoa is completely unwounded, you will be able to adjust its definitive tension using a tightening rope, more important than the halyard extension.

If the genoa is kept wound when the boat is not used, slip the halyard one notch tighter on the track in order to release the tension of the halyard on the masthead sheave.

GENOA AND STAYSAIL USE Once the sheet is home, unfurl the genoa or staysail using the switch at the helm station.

The domestic batteries supply power to the genoa and staysail furlers. Their circuit breakers are in the service room of the foredeck.

GENOA LOWERING the genoa must absolutely be furled.

- Have the genoa halyard extension fixed in the lower hook of the tension adjustment traveller then pass it in the available mast foot block with a direct return to a winch on the wheelhouse.

- Hoist the halyard (about 5 cm) before letting the traveller go down.

- Release the traveller locker doing a ninety-degree turn.

- Slip the halyard to the winch.

- This group of elements is no longer under tension.

- Release the halyard and its extension from the tension adjustment traveller and tighten them together with a solid whipping (in order to get one single halyard).

- Harden moderately the halyard using the winch.

- Unwind the genoa to haul down.

RIGGING / SAILS

RIGGING

SAILS

LAGOON 62O

RECOMMENDATION

To furl or unfurl the headsails, be preferably down wind.

RECOMMENDATION

When you shift the tack and depending on the sailing trim of the boat, use the electric furler and set the tack in line with the headsail.

WARNING

When the mainsail is shortened and reefed down twice, you must replace the genoa by the staysail.

RIGGING SAILS

GENOA - STAINSAIL + EMERGENCY INSTRUCTIONS - GENNAKER

LAGOON 62O

- Remove the protective cover on the stardboard side of the furling system.

- Insert a winch handle and turn to furl or unfurl the sail.

GENOA - STAYSAIL

Manual emergency

instructions

WHIPPING LINKING THE

HALYARD TO ITS EXTENSION

TRAVELLER LOCKER

OPEN

The whipping must resist to the tension when hoisting.

GENNAKER

FURLING SYSTEM

RIGGING / SAILS

RIGGING

SAILS

LAGOON 62O

GENNAKER Remove the forward lifelines when using the gennaker (risk of damage). Before getting under the way, take advantage of a windless period of time and hoist the gennaker.

- Secure the swivel to the gennaker headboard.

- Secure the furling system to the tack clew.

- Put the furling system to the boomsprit with a snap shackle.

- Secure the halyard to the headboard swivel.

- Hoist the gennaker.

Use the furling system line to furl or unfurl the gennaker.

Gennaker sheets

- Secure the sheets to the gennaker clew.

- Have the sheets go on the outside of the stay and shrouds and above the guardrails.

- Make fast the sheet leading blocks to the chainplates.

- Reroute the sheets to the genoa sheet winches.

WARNING

In some sailing trims, the gennaker may hide the fore navigation lights.

WARNING

Unrig the gennaker when not in use (risk of being UV damaged and inadvertently unfurled).

4.1 24 V SYSTEM

4.2 12 V SYSTEM

4.3 INVERTERS

4.4 110 V - 220 V SYSTEM

SSEECCTTIIOONN 44

EELLEECCTTRRIICCIITTYY

24 V ELECTRICAL PANELS - BOARD CUT OUT - ALTERNATORS

ELECTRICITY

LAGOON 62O

24 V PANEL

MULTIFUNCTION SCREEN GENERAL BOARD CUT OUT

BILGE PUMP PANELS

1 - Coupled alternator (24 V).

2 - Engine alternator (12 V).

2244 VV PPAANNEELL It groups the different 24 V functions onboard: lighting, grey water pumps, electric heads, deck wash pump (optional extra), refrigeration units, pressure water pumps, inverters, diesel oil transfer pump.

BBIILLGGEE PPUUMMPP PPAANNEELLSS The four small panels situated near the 110 V - 220 V panel control the bilge pumps. The switch on the left makes three positions possible: automatic start, OFF and manual operation. The switch on the right makes possible to stop the alarm.

MMUULLTTIIFFUUNNCCTTIIOONN SSCCRREEEENN A touch screen on the chart table gives access to :

- The jauges of the fresh water and fuel tanks.

- The consumption (amperes) and voltage (volts) of the batteries.

- The control of the navigation lights, anchor lights, deck lights...

- The switching on of the electronics.

- The switching on of all the lightings on board.

- The start of the fuel transfer pump.

ELECTRICITY

LAGOON 62O

RECOMMENDATION

We recommend that you keep the bilge pumps in the automatic start position with alarm. We advise you to carry out a test of the bilge pumps each time before you put out to sea.

 4.1 24 V system

BATTERIES The battery bank supplies the boat with 24 V and is located in the service room of the foredeck. The whole 24 V circuit is energized when you turn to the ON position the manual cut-out under the chart table.

BATTERY RECHARGING You recharge the battery bank with a coupled alternator (110 Ah / 24 V) or a battery charger (220 Ah / 24 V).

BATTERY CHARGERS (OPTIONAL EXTRA) The battery chargers are located in the service room of the foredeck. The 110 V - 220 V / 24 V chargers recharge the domestic batteries.

OPERATION The battery chargers can be used with the shore power socket #1 or the operating generator. Turn the HIGH LOAD selector to SHORE or GENERATOR. Make sure their circuit breakers on the electrical panel are properly set.

Nota : the battery chargers can remain in operation even when the boat is not energized in 24 V.

CONTROL OF THE 24 V CONSUMING APPLIANCES The control of the 24 V consuming appliances is distributed between three areas :

LAGOON 62O

ELECTRICITY

MANUAL OPERATION OF THE FUNCTIONS USING THE CPU MONITOR SCREEN

42 31

MULTIPLEXING SYSTEM

MONITOR SCREEN

(CPU MONITOR SCREEN)

THE WAY IT APPEARS

EXAMPLE OF THE

AVAILABLE FUNCTIONS /

'CONTROLS' MENU

EXAMPLE OF THE

AVAILABLE FUNCTIONS /

'MONITORING' MENU

876 111095

Nota : when the connection module of the called component is red, a failure is signalled ; you shall follow the instructions shown on the screen.

IN CASE THE TOUCH-SENSITIVE SCREEN SHOULD NOT WORK PROPERLY:

In case the multifunction touch-sensitive screen should not work properly, it is possible to control the functions using the multiplexing system monitor screen (CPU monitor screen) located under the chart table, or if all else fails, straight pressing the Eplex Modules.

1° Action using the CPU monitor screen: (refer to the illustrations on the opposite page)

1 - Access to the 'Controls' and 'Monitoring' functions. 2 - Back to the welcome screen. 3 - Voltage of the service batteries. 4 - 'Controls' menu: access to lightings and electronics. 5 - 'Monitoring' menu: access to information about Tanks

and Batteries.

6 - Selection of the functions available in the 'Controls' menu. 7 - Information monitor screen. 8 - Access to the selected function (ON / OFF).

9 - Selection of the functions available in the 'Monitoring' menu. 10 - Information monitor screen. 11 - Inactive.

ELECTRICITY

LAGOON 62O

ELECTRICITY

MANUAL OPERATION OF THE FUNCTIONS PRESSING THE EPLEX MODULES

MULTIPLEXING SYSTEM

MONITOR SCREEN (CPU

MONITOR SCREEN)

ELECTRICITY

LAGOON 62O

- On the black box on the right (mark B on the photo), mark the diodes as follows (mark 3, from left to right) : 1 : Portside navigation light 2 : Starboard navigation light 3 : Stern light 4 : Steaming light 5 : Anchorage lights 6 : Masthead light / Deck spotlight 7 : Spreader spotlights 8 : Spotlights on rear beam 9 : Outside soft lights 10 : Three color lights

- Press the button on the right (mark 5) to scroll the diodes up to the one to be selected.

- Press the button on the left (mark 4) to validate the manual operation of the selected function.

To access the "manual override" function of the automatic pilot, its relay must be shunted. In order to do this, disconnect the two blue terminals (mark 6) and then connect them to each other.

2° In case the CPU monitor screen should have a problem, straight press the Eplex Modules: (Refer to illustrations on the opposite page)

Access to the Eplex Modules in the cabinet under the chart table.

- Shunt the screen by removing the 6 Ah fuse (mark 1).

- On the black box on the left (mark A on the photo), mark the diodes as follows (mark 2, from left to right) : 1 : Inside soft lights 2 : Under water spotlights 3 : 24 V electronics: supply for the screens at the helm stations and chart table, GPM 400. 4 : 12 V electronics: Sea Talk, VHF, camera, ST 70 5 : Radar 6 : Radar

- Press the button under the diode concerned. When the diode is continuously lit up, the function works.

Please note: when you remove the fuse, the functions that are multifunction touch-sensitive screen managed turn to OFF and shall be manually restarted, according to the procedure.

LAGOON 62O

ELECTRICITY

12 V CUTOUT - SERVICE ROOM - 24 V CONNECTING STRIP

1 - Cut out - battery coupling (12 V). 2 - Cut out - portside engine (12 V).

3 - 24 V / 220 V - 1500 Va inverter as standard. 4 - Battery bank. 5 - Electronic box for furler control. 6 - 24 V / 220 V - 5000 Va inverter (optional extra).

7 - 220 V / 12 V - 35 Ah charger. 8 - 220 V / 12 V - 100 Ah chargers.

9 - Bow thruster. 10 - 24 V / 220 V - 5000 Va inverter (optional extra). 11 - 24 V / 220 V - 1500 Va inverter as standard. 12 - Multiplexage. 13 - DC panel supply. 14 - Supply for battery switch of the battery bank. 15 - 24 V power box.

16 - Bow thruster relay. 17 - Electric system

(gangway, davits, tenderlift). 18 - Generator dividing box. 19 - Automatic pilot. 20 - Gas electrovalve (US 110 V version).

3 654 7 8

10 11 12 13 14 15

16 17

 4.2 12 V system

BATTERIES The 12 V batteries supplying the two engines and the generator respectively are in each engine bilge and the service room of the foredeck. Each one has its own cut-out at its side. A voltage alarm is set on the master shunt.

For safety reasons, a system of coupling the engine batteries (cut-out located in the portside engine compartment) makes possible the start of the engine the battery of which is failing.

BATTERY RECHARGING The battery bank is recharged with the engine alternators or a battery charger.

BATTERY CHARGERS The battery chargers are located in the service room of the foredeck. The 110 V - 220 V / 12 V charger recharges the engine and generator batteries.

OPERATION The battery chargers can be used with the shore power # 1 or the working generator. Set the HIGH LOAD selector to SHORE or GENERATOR. Make sure their circuit breakers on the electrical panel are properly positioned.

CONTROL OF THE 12 V CONSUMING APPLIANCES You can control the 12 V consuming appliances on the multifunction screen on the chart table. These consuming appliances (camera, VHF, radio...) work in 12 V via a 24 V / 12 V inverter.

 4.3 Inverters

The boat is standard fitted with a 24 V / 220 V - 1500 Va inverter for the galley electrical appliances. As optional extra, she can be fitted with a 5000 Va inverter. The inverters are located in the service room. They supply the UTILITY bus.

OPERATION They are operated from the electrical panel. Make sure their circuit breakers on the 24 V electrical panel are properly positioned.

ELECTRICITY

LAGOON 62O

24 V SYSTEM

LAGOON 62O

ELECTRICITY

24 V AUTOMATIC FUSES

ELECTRICITY

LAGOON 62O

24 V FUSES - ELECTRIC BOX IN

ADMISHIPS CABIN TO PORT

24 V FUSES - ELECTRIC BOX IN

ADMISHIPS CABIN TO STARBOARD

The fuses of some elements are in electric boxes located behind the headboards in the aft cabin to starboard and in the admiships cabin to port (double bed version) or at the back of the cabinet between the two beds (bunk bed version). These elements are energized using the 24 V general cutout.

Nota : the LIGHTING fuses on the electrical panel are only for a part of the saloon lighting and outside lightings (bimini, spreaders, etc.).

ELECTRICITY

LAGOON 62O

12 V SYSTEM

RECAPITULATION OF THE 12 V AND 24 V COMPONENTS

ELECTRICITY

LAGOON 62O

CHARGE AAND EELECTRIC CCONVERSION

220 V or 110 V / 24 V - 100 Ah Charger As optional extra : recharge of the 24 V service battery bank (refer to 110 V / 220 V recapitulation) 220 V / 12 V charger (3 connections) With the optional generator to recharge the 12 V generator battery and the two 12 V engine batteries 24 V - 110 Ah coupled alternator Recharge in 24 V of the service battery bank 24 V / 12 V electronic inverter With the electronics 24 V / 12 V car-radio inverter With the car-radio optional extra

BATTERIES // CCONSUMING AAPPLIANCES

24 VV ddirect ccurrent Voltage SStarti

ng uup PProtection

Service batteries 24 V (420 Ah as standard, 840 Ah as optional extra)

Recharge of the service batteries by a coupled alternator (24 V) per engine + 220 V / 24 V - 100 Ah chargers (optional extra)

Navigation electronics 24 V Multifunction screen Utility lighting 24 V Multifunction screen Navigation light 24 V Multifunction screen Lighting 24 V Multifunction screen Fridge in cockpit 24 V 24 V Electrical panel 24 V Electrical panel Fridge on fly 24 V 24 V Electrical panel 24 V Electrical panel Electric heads 24 V 24 V Electrical panel 24 V Electrical panel Deck wash pump 24 V 24 V Electrical panel 24 V Electrical panel Winches 24 V 24 V Domestic Electricity room Windlass (directly on the batteries) 24 V 24 V Domestic Electricity room Capstans 24 V 24 V Domestic Electricity room Davits / Tenderlift 24 V Gangway 24 V : hydraulic pump Bow thruster 24 V : hydraulic pump

12 VV ddirect ccurrent VVoltage Engine start batteries (12 V - 50 Ah) x 2

Recharge of engine battery by engine alternator + 220 V / 12 V charger

Generator start battery (12 V - 50 Ah) x 1

Recharge of generator battery by generator alternator + 220 V / 12 V charger

Electronic control of engine 12 V connected on engine start battery once "on"

Cameras Hub (network terminal) 12 V VHF powered by a 24 V / 12 V inverter Car-radio

ELECTRICITY

LAGOON 62O

GENERATOR - SHORE POWER SUPPLY - CHARGERS - INVERTERS

1 - Generator start battery.

2 - Generator.

3 - Separator drain valve.

4 - Air extractor of service room.

5A - Generator sea water filter.

5B - Generator sea water inlet valve.

6 - Generator fuel filter.

7 - Water / gas separator.

8 - Fuel tanks.

9 - Fuel / generator stop pull handle.

10 - Circuit breakers of the shore power sockets + shore power sockets.

11 - 24 V / 220 V inverter.

12 - 12 V / 220 V inverter.

13 - 220 V / 12 V battery charger.

14 - 220 V / 24 V battery chargers.

15 - Generator exhaust pipe.

16 - 24 V - 12 V inverter (access behind bilge pump panel).

17 - Diesel oil transfer pump (Starboard tank to port tank).

Galley / saloon version

Galley / hull version

15 16

3 4

ELECTRICITY

LAGOON 62O

 4.4 110 V - 220 V system

SHORE POWER A shore power socket is located in the portside aft transom of cockpit. It supplies power to the 110 V - 220 V system and the battery chargers. A second shore power socket, dedicated to air conditioning, is fitted nearby if the boat is fitted with the air conditioning optional extra.

Before you plug in or unplug the boat/shore power supply cable, switch off the shut off device connected to the shore supply. Connect the boat/shore power supply cable in the boat before connecting it to the shore supply socket. Unplug the boat/shore supply cable on shore first. Close the protecting cover of the shore supply socket when the plug is not in use. The shore power socket is protected by a circuit breaker located in the portside engine bilge.

DANGER

Never let the end of the boat/shore supply cable

hang in the water ; the result may be an electric field

liable to hurt or kill the swimmers nearby.

220 V SHORE POWER SOCKET N°1 50A SHORE POWER SOCKET N°2 50A

GENERATOR The generator is located in the service room of the foredeck. Its function is to re-supply the batteries via the charger and supply 110 V - 220 V electricity on board.

On the boats fitted with 110 V - 60 HZ, 75% of the generator power are for the equipments remaining in 220 V - 60 Hz and 25% for the equipments working in 110 V - 60 Hz.

The generator is supplied by the port fuel tank.

OPERATION You can start the generator either on the generator or by its control on the electrical panel. Make sure its fuel pull handle (access under the hob in the galley galley / hull version - and by the pull handles behind the hatch under the bedside storage at the aft end of the port hull - galley / saloon version) and its sea water cooling valve (access under the floor of the port forward cabin) are open.

For the generator use and maintenance, refer to the instruction guide.

DIESEL OIL TRANSFER PUMP In case of intensive use of the generator supplied by the port tanks, use the transfer pump that makes possible the fuel circulation from the starboard to the port tank.

Read information about its operation in chapter PROPULSION.

ELECTRICITY

LAGOON 62O

110 V - 220 V ELECTRICAL PANELS

Galley / saloon versionGalley / hull version

1 - 110 V - 220 V protection panel.

2 - 110 V - 220 V selection panel.

3 - Starting / stop control of the inverter.

4 - Genera board cut out.

5 - Starting / stop control of the watermaker (optional extra).

6 - Starting / stop control of the inverter (optional extra).

7 - Starting / stop control of the generator.

8 - Circuit breakers of household appliances.

ELECTRICITY

LAGOON 62O

CONTROL OF THE 110 V - 220 V CONSUMING APPLIANCES

111100 VV - 222200 VV SSEELLEECCTTIIOONN PPAANNEELL This panel has 3 switches which enable you to choose the supply source for the different 110 V - 220 V consuming appliances on board.

CONFORT - UTILITY SELECTOR :

- Allows the use of the appliances grouped together on the CONFORT

- UTILITY bus using 110 V - 220 V current coming from the generator, shore or inverter (automatic start of the inverter when it is selected).

PUISSANCE AC - AC HIGH LOAD SELECTOR :

- Allows the use of the appliances grouped together on the PUISSANCE AC - AC HIGH LOAD bus of the 110 V - 220 V protection electrical panel, using 110 V - 220 V current coming from the generator or shore.

CLIMATISATION - AIR COND SELECTOR :

- Allows the use of air conditioning, on the CLIMATISATION - AIR COND bus, using 110 V - 220 V current coming from the shore power socket # 2 or generator.

111100 VV - 222200 VV PPRROOTTEECCTTIIOONN PPAANNEELL This area groups together 3 buses of circuit-breakers of the 110 V 220 V appliances and equipments. Each of these buses has a major circuit breaker and several individual circuit breakers. This panel allows you to choose the supply source of the consuming appliances.

CONFORT - UTILITY :

- Groups together the 110 V - 220 V consuming appliances that are likely to be supplied by the inverter.

PUISSANCE AC - AC HIGH LOAD :

- Groups the heavy 110 V- 220 V consuming appliances that need the generator start up or shore power suply.

CLIMATISATION - AIR COND :

- Attributed to air conditioning for the starting up of the system.

PPAANNEELL OOFF TTHHEE CCIIRRCCUUIITT BBRREEAAKKEERRSS OOFF TTHHEE HHOOUUSSEEHHOOLLDD AAPPPPLLIIAANNCCEESS The 110 V - 220 V kitchen appliances have a dedicated circuit breaker panel. This panel is located under the cockpit companionway in the galley (version with the galley at the aft of the port hull), and behind a hatch at the back of the aft cabinet between the two berths of the central cabin in the port hull (version with galley in the saloon).

Nota : all the circuit breakers of the 110 V - 220 V system are differential circuit breakers. Therefore you do not need fuses for this system on board.

ELECTRICITY

LAGOON 62O

220 VOLT - 50HZ ELECTRICAL SYSTEM - STANDARD EQUIPMENT

ELECTRICITY

LAGOON 62O

ELECTRICITY

USE OF THE 110 V - 220 V POWERED APPLIANCES

TO SWITCH ON THE APPLIANCES In order to be able to use the 110 V - 220 V powered appliances (washing machine, watermaker, etc), it is advisable :

- To make sure that the circuit breakers are turned to OFF on the 110 V - 220 V selection panel.

- Switch on the 110 V - 220 V source (start the generator or connect the shore power socket # 1 to shore).

- Select this source on the electrical panel so that this source can supply the boat (110 V - 220 V Selection electrical panel).

- Push the circuit breaker of the appliance to be used (washing machine, watermaker, etc.) on the electrical panel. After this, start the appliance with its own controls.

To start 110 V - 220 V elements, wait for 10 to 15 seconds between the start up of each new component (in order to allow the generator to become stabilized and be able to give the power necessary for the starting up).

TO STOP THE 110 V - 220 V POWERED APPLIANCES To stop the 110 V - 220 V powered appliances (washing machine, watermaker,etc) it is advisable to do as follows :

- Stop the appliance with its own controls.

To stop 110 V - 220 V elements, wait for 10 to 15 seconds between the stop of each new component (in order to allow the generator to become stabilized).

- On the electrical panel, turn off the circuit breaker of the appliance that is used.

- Turn to OFF the 110 V - 220 V source selector (generator or shore power socket # 1).

- Stop the generator or disconnect the shore power socket.

WARNING

Before turning the 100 V - 220 V source selector to OFF, make sure no other appliance is working (danger of an electric arc that would destroy the commutator and risk of damaging the generator).

RECAPITULATION # 1 / 110 V - 220 V COMPONENTS

ELECTRICITY

LAGOON 62O

GENERATOR

Generator power 17,5 kva European Version The generator gives 100% of its power in 220 V - 50 Hz (AIR CONDITIONING, UTILITY and 220 V HIGH LOAD buses) Generator power 17,5 kva US Version The generator gives 75% of its power in 220 V (AIR COND and 220 V HIGH LOAD buses)

The generator gives 25% of its power in 110 V (UTILITY and 110 V HIGH LOAD buses)

SHORE PPOWER SSOCKET

HIGH LOAD Shore power socket

European Version

A 50 Ah simple shore power socket - connection in the port aft transom extension (220 V - 50 Hz)

AIR COND Shore power socket

European Version

A 50 Ah simple shore power socket - connection in the port aft transom extension (220 V - 50 Hz)

HIGH LOAD shore power socket

US Version

Utilisation of the two 110 V phases to supply 220 V power on board.

ELECTRIC DDISTRIBUTION

UTILITY BUS 110 V or 220 V Supplied by generator, shore or inverter (optional extra 1 or 2) HIGH LOAD BUS 110 V or 220 V Supplied by generator or shore AIR COND BUS 110 V or 220 V Supplied by generator or shore

CHARGE AAND EELECTRIC CCONVERSION

220 V or 110 V / 24 V - 100 Ah charger Optional : recharge of the service bank by generator or shore

220 V / 12 V charger (3 connexions) Automatically comes with the optional generator to recharge the 12 V battery, the generator and the two 12 V engine batteries

Standard inverter 24 V / 220 V - 1500 Va Utility inverter OPTIONAL EXTRA 24 V / 220 V - 5000 Va

CONSUMING AAPPLIANCES Operating vvoltage 220 VV bboat 1110 VV bboat

Galley fridge 220 V Standard inverter ----Hood 220 V Standard inverter ----Piezzo hob and oven 220 V Standard inverter -----

Icemaker 220 V or 110 V UTILITY Bus UTILITY Bus Microwave oven - Grill 220 V or 110 V (without grill) UTILITY Bus UTILITY Bus HIFI Bose 220 V or 110 V UTILITY Bus UTILITY Bus TV 220 V or 110 V UTILITY Bus UTILITY Bus Dishwasher 220 V or 110 V UTILITY Bus HIGH LOAD Bus Cockpit grill 220 V or 110 V HICH LOAD Bus HIGH LOAD Bus Washing machine 220 V or 110 V HIGH LOAD Bus HIGH LOAD Bus Water heater 220 V HIGH LOAD Bus HIGH LOAD Bus in 220 V (double phase) Watermaker 220 V HIGH LOAD Bus HIGH LOAD Bus in 220 V (double phase) Diving compressor 220 V HIGH LOAD Bus HIGH LOAD Bus in 220 V (double phase) Air cond. 220 V AIR COND.Bus AIR COND Bus in 220 V (double phase)

PRINCIPLE FOR THE 50 Ah - 250 V CONNECTION TO THE SHORE POWER FOR A US VERSION BOAT

The boat is fitted with a 50 Ah plug socket for the air conditioning system (L1 + L2 + N + E).

The power cable that is provided is a 3G 10mm² with : On the boat side : a 50 Ah socket (3 L + E). On the shore side : a 50 Ah plug (3L + E).

A 50 Ah four-pole residual current device is located on the line in the existing box. At the end of the 50 Ah residual current device the domestic system is connected to both Live wires. The 'Neutral' on the plug socket is connected to the residual currrent device, not to the domestic system. The 'Earth' on the plug socket is connected to the domestic 'Earth' via a simple connector.

If the marina has no 50 Ah – 3L + E socket, it would be proper to use the Marinco 167 RYN - Y Adapter, connecting it to two 30 Ah - 125 V sockets.

RECAPITULATION # 2 / 110 V - 220 V COMPONENTS

ELECTRICITY

LAGOON 62O

220 V SYSTEM

LAGOON 62O

ELECTRICITY

110 V SYSTEM

ELECTRICITY

LAGOON 62O

5.1 BILGE PUMP SYSTEM

5.2 GREY WATER SYSTEM

5.3 FRESH WATER

5.4 USE OF THE MARINE HEADS

5.5 BLACK WATER HOLDING TANKS

5.6 WATERMAKER (OPTIONAL EXTRA)

SSEECCTTIIOONN 55

PPLLUUMMBBIINNGG

BILGE PUMP SYSTEM

PLUMBING

LAGOON 62O

1 - Forward compartment manual bilge pump. 2 - Outlet valve of forward compartment towards the sump. 3 - Grey water tank. 4 - Automatic start mechanisms of the electric bilge pump. 5 - Electric bilge pump / sump. 6 - Hull sump. 7 - Drain valve of engine bilge towards the sump. 8 - Electric bilge pump / engine bilge. 9 - Rear manual bilge pump. Each hull has the same components. Nota : each valve in the boat is identified.

SEA-COCK

OPEN

SEA-COCK

CLOSED

7 9

4 5

7 8

Nota: the same layout can be observed

in the other versions.

 5.1 Bilge pump system

A main sump is under the floorboard of each hull. The fore and aft compartments are linked to these sumps by a bilge pipe and a valve (access under the floorboards).

Each fore compartment is drained by a manual pump. Each sump is drained by :

- A cockpit manual pump.

- An electric pump with a manual or automatic start (on the electrical panel).

An automatic start for a low level starts the pump but not the alarm (draining of the bilge pipes). An automatic start for a higher level starts the alarm then. Nota : the electric bilge pump automatically works even if the 24 V system has been switched off.

Each of the engine bilges has an electric pump with a manual or automatic start.

 5.2 Grey water system

The grey waters are grouped together in a collecting tank in each hull. They collect the waste waters of the basins and showers of the shower rooms.

The grey water tanks are emptied by automatic start pumps (switching on from the 24 V panel).

We advise you should regularly clean the filters (access to them by removing the clips of the covers).

PLUMBING

LAGOON 62O

RECOMMENDATION

Regularly check the valves and sea-cocks for proper operation and watertightness. Regularly make sure the strumboxes and bilges are perfectly clean.

RECOMMENDATION

The drain pipe valves in the forward and engine compartments shall be in normal closed position.

WARNING

The bilge pump system is not designed to provide buoyancy to the boat in case of damage. The bilge pump system is designed to drive out the water being either sea spray or leaks but absolutely not the water coming through a hole in the hull, this hole being the result of a damage.

FRESH WATER SYSTEM

PLUMBING

LAGOON 62O

1 - Port forward tank.

2 - Port aft tank.

3 - Deck filler.

4 - Water heater.

5 - Pressure water pump.

6 - Water unit stop valve.

7 - Valve for shore fresh water supply.

8 - Shore fresh water supply.

9 - Starboard forward tank.

10 - Starboard aft tank.

11 - Transfer valve.

12 - Deck shower valves.

4 5

Nota: the same layout can be observed

in the other versions.

 5.3 Fresh water

TANKS Each hull has a pressure water pump and two tanks linked together, but independent between the port and starboard hulls. To prevent any handling mistake, never fill the water and fuel tanks at the same time. During filling, avoid handling contaminants near the fillers. Open and close the filler caps with the suitable key. Check the filler cap seals for condition during filling. The tanks are fitted with overflow outlets and vents. Never insert the water filling hose deep down into the system in order to prevent any over-pressure in the systems.

The tanks are fitted with inspection hatches therefore it is possible to clean the inside.

Nota : the capacity of the fresh water tank(s) indicated on the page 'SPECIFICATIONS' may be not completely usable depending on the trim and load of the boat.

SYSTEM The pressure water pumps get to work via their breakers on the electrical panel. In case of failure of the pressure water pump, set its breaker to OFF and open the transfer valve situated in the starboard engine bilge so that the tank and working pressure water pump can take over.

WATER GAUGE

Check the gauges via the multifunction touch screen.

SHORE FRESH WATER SUPPLY The shore fresh water supply is located in the port aft transom extension. To use the marina fresh water :

- Connect the shore supply.

- Set the breakers of the pressure water pumps to OFF.

- Open the shore supply valve (access by port engine bilge).

- Open the transfer valve (access by starboard engine bilge).

WATER-HEATER Each water heater (one per hull) has a capacity of 60 litres. The water heaters automatically work once their respective engines are running, or on 220 V supply after the shore power supply is plugged or after the generator started.

PLUMBING

LAGOON 62O

RECOMMENDATION

- Pay attention to the quality of the water for the filling up.

- Check if it is drinking water.

- If the boat is not used for long, purify the tanks and pipes with proper treatment.

RECOMMENDATION

- Never operate water system equipment when the valves are closed or when the tanks are empty (the electrical equipment may be damaged).

- Check the different water filters for condition.

BACK WATER TANKS

PLUMBING

LAGOON 62O

5 64

1 - Black water tank. 2 - Drain bung hole on deck. 3 - Vent.

4 - Fresh water tank inlet. 5 - Electrovalve / fresh water inlet. 6 - Drain valve on hull.

BLACK WATER TANK SYSTEM

Nota: the same layout can be observed

in the other versions.

Make sure the GALLEY breaker on the HIGH LOAD bus of the electrical panel and WATER HEATER breaker on the "household appliances" panel (situated under the companionay stairs in the galley) are switched on.

The hot water temperature is pre-set using the thermostatic tap situated on the water heaters (access under the aft floorboards of the galley to portside and the owner's study to starboard).

 5.4 Use of the marine heads

ELECTRIC MARINE HEADS You rinse them using the fresh water in the port tanks for the heads in the port hull and the starboard tanks for the heads in the starboard hull. Make sure the breakers of the water pressure pump and heads are on (24 V electrical panel).

In order to avoid clogging the heads, use absorbent paper only.

For the use and maintenance of the electric heads, refer to the instruction guide.

 5.5 Black water tanks

The heads are fitted with black water tanks. To use them, make sure the drain valve on the bowl is closed in order to avoid any inadvertent discharge (the valve is closed when the handle is perpendicular with the pipe).

You have access to the tanks by the showers and by the WC (behind the mirror) in the starboard rear hull.

To empty a black water tank :

- In an authorized area, open the drain valve to empty the tank through gravity.

- In a marina equipped with an organic waste suction system, put the suction hose into the tank through the deck filler. Start the pump of the suction system.

The filler cap is opened and closed with an appropriate key. When the tank has been emptied, check the cap seal for condition then close the filler.

Regularly rinse the black water tanks.

PLUMBING

LAGOON 62O

RECOMMENDATION

Use the suction systems in marinas to empty your holding tanks. In order to respect environment, do not discharge your holding tanks near the shore.

WARNING

Ask for information about the laws in force in your country or your marina about discharging your waste waters from heads into the sea.

WATERMAKER

PLUMBING

LAGOON 62O

1 - Watermaker. 2 - Valve to select port / starboard tank. 3 - Watermaker low pressure pump. 4 - Sea water supply valve of watermaker. 5 - Watermaker pre-filters. 6 - Starting / stop control of the watermaker.

 5.6 110 V / 220 V watermaker (optional extra)

The boat may be fitted with a water maker as an optional extra. It is situated in the engine bilge of the starboard hull.

OPERATION The watermaker works when the generator is on. Open the sea water supply valve (access under the owner's cabin floor, to starboard).

To switch on the watermaker:

- Check the switching on of the GALLEY breaker situated on the HIGH LOAD bus of the 110 V - 220 V electrical panel.

- Check the switching on of the WATERMAKER breaker situated on the "household appliances" panel, under the cockpit companionway stairs in the galley.

- Start the watermaker using its control unit next to the electrical panels in the saloon.

The watermaker system is fitted with a 3 way valve to supply fresh water to the port or starboard tanks. This valve is in the engine bilge in the starboard hull.

Check the level of fresh water in the tanks when the watermaker is working.

For the use and maintenance of the watermaker, refer to the instruction guide.

PLUMBING

LAGOON 62O

RECOMMENDATION

The watermaker shall be used exclusively in clear waters, when moored or sailing.

6.1 SALOON TABLES

6.2 PORTHOLES AND DECK HATCHES

6.3 FLOORBOARDS

6.4 ACCESS TO THE BINS

6.5 SLOT-IN TV SET (OPTIONAL EXTRA)

SSEECCTTIIOONN 66

AACCCCOOMMMMOODDAATTIIOONN

SPECIFIC ACCOMMODATION

ACCOMMODATION

LAGOON 62O

DECK HATCH LOCKING

(Knob of left handle in open position.)

(Knob of right handle in closed position.)

SUCTION PADS FOR

THE FLOORBOARDS

ACCESS TO THE BINS SLOT-IN TV SET

 6.4 Access to the bins

Lift the cockpit companionway stairs to galley in order to open the cupboard giving access to the bins.

 6.5 Slot-in television set (optional extra)

The saloon is equipped with a an optional television set slot-in the backrest of the portside settee. The saloon is fitted with an optional TV. The slot-in TV can be fitted into the port settee back for the version with the galley in the port hull.

Steadily press the switch behind the backrest of the portside settee in order to have the television set out, then make it turn.

USE Select the supply source (Inverter, Generator or shore power socket # 1 from the UTILITY selector of the 110 V - 220 V selection panel.

For the use and maintenance of the television set, refer to the instruction guide.

ACCOMMODATION

LAGOON 62O

 6.1 Saloon tables

The heights of the two saloon tables can be adjusted independently using the switches behind the starboard settee backrest.

 6.2 Portholes and deck hatches

The deck hatches have locking systems to keep them closed. At anchor, intermediate opening positions make possible to ventilate the boat. The deck hatches are fitted with a blind and mosquito net system to be used event when the hatch is open. They must be handled with care. The portholes are fitted with blinds.

 6.3 Floorboards

The floorboards can be lifted up to have access to the different technical components on board. Use the suction pad provided for this purpose.

7.1 OUTSIDE REFRIGERATORS

7.2 MICROWAVE OVEN (OPTIONAL EXTRA)

7.3 HOB

7.4 REFRIGERATORS, OVEN, HOOD

7.5 WASHING MACHINE (OPTIONAL EXTRA)

7.6 DISHWASHER (OPTIONAL EXTRA)

7.7 AIR CONDITIONING (OPTIONAL EXTRA)

7.8 ICEMAKER (OPTIONAL EXTRA)

7.9 GRILL(OPTIONAL EXTRA)

SSEECCTTIIOONN 77

OONNBBOOAARRDD UUTTIILLIITTYY

LAYOUT OF THE GALLEY COMPONENTS

ON BOARD UTILITY

LAGOON 62O

1 - Refrigerator / freezer. 2 - Traditional oven. 3 - Gas valves. 4 - Hood. 5 - Hob. 6 - Microwave oven. 7 - Cockpit refrigerator. 8 - Icemaker. 9 - Electric grill in cockpit. 10 - Breakers for "household appliances". 11 - Gas bottle and regulator.

GAS VALVES

Galley / hull version

Galley / saloon version

 7.1 Outside refrigerators

The boat is fitted with a cockpit refrigerator and a fly refrigerator as an optional extra.

Switch ON the FRIGO breaker situated on the 24 V electrical panel.

For the use and maintenance of the fly and cockpit refrigerators, refer to the instruction guide.

 7.2 Microwave oven (optional extra)

The boat is fitted with a microwave oven as an optional extra.

Check the GALLEY breaker situated on the UTILITY bus of the 110 V 220 V electrical panel is set to "ON". Check the MICROWAVE breaker situated on the "Household appliances" panel (see chapter ELECTRICITY, page 63) are set to "ON".

SUPPLY Select the source of supply (5000 Va Inverter, Generator or shore power socket # 1) from the UTILITY selector of the 110 V - 220 V selecting panel.

For the use and maintenance of the oven, refer to its instruction guide.

 7.3 Hob

The boat is standard fitted with a gas cooking hob. The gas valves are situated in the cupboard on the left under the hob

- Galley / hull version and in the cupboard on the right under the hob

- Galley / saloon version. The gas bottles are situated in the end lockers of the cockpit seat.

The hob has an electric ignition. The inverter that supplies ignition is automatically operated when the 24 V system on board is switched on.

 7.4 Galley refrigerator, oven, hood

The boat is standard fitted with an oven, a refrigerator / freezer and a hood as an optional extra.

Their inverters are automatically operated when the 24 V system on board is switched on. Check their breakers situated on the "Household appliances" panel (see chapter ELECTRICITY, page 63) are set to "ON". Defrost then drain the refrigerator / freezer before the 24 V system on board is off.

For the use and maintenance of the refrigerator / freezer, oven and hood, refer to the relevant instruction guide.

ON BOARD UTILITY

LAGOON 62O

RECOMMENDATION

Shut the gas valves and the regulator tap when you do not use the hob.

WASHING MACHINE - DISHWASHER

ON BOARD UTILITY

LAGOON 62O

1 - Washing machine. 2 - Dishwasher. 3 - Water supply manifold. 4 - Washing machine / dishwasher breakers.

Nota : the manifold is located under the sink and distributes water to sink, refrigerator, dishwasher and washing machine.

WASHING MASCHINE /

DISHWASHER BREAKERS

MANIFOLD DISTRIBUTES

HOT / COLD WATER

Galley / hull version

Galley / saloon version

Galley / hull version

Galley / saloon version

1 2

 7.5 Washing machine (optional extra)

The boat may be fitted as an optional extra with a washing machine. The washing machine is located in a cabinet on the outer side of the galley (galley / hull version) or in a cabinet in front of the hob (hull / saloon version).

The port tanks supply fresh water to the washing machine. Check its valve on the manifold under the sink is open. The washing machine and the sink have a common draining system (galley / hull version) or under the floor in the port aft cabin (galley / saloon version).

Check the GALLEY breaker on the HIGH LOAD bus of the 110 V - 220 V electrical panel is set to "ON". Check its breaker located on the "household appliances" panel (see chapter ELECTRICITY, page 63) is set to "ON".

POWER SUPPLY Select the power source (Inverter, Generator or shore power socket #

1) from the HIGH LOAD selector on the 110 V - 220 V selection panel. Start the washing machine.

For the use and maintenance of the washing machine, refer to its instruction guide.

 7.6 Dishwasher (optional extra)

The boat may be fitted as an optional extra with a dishwasher. The dishwasher is located in a cabinet on the outer side of the galley (galley / hull version) or in the cupboard on the left of the companionway (galley / saloon version).

The port tanks supply fresh water to the washing machine. Check its valve on the manifold under the sink is open. The dishwasher and the sink have a common draining system (galley / hull version) or under the floor in the port aft cabin (galley / saloon version).

Check the GALLEY breaker on the HIGH LOAD bus of the 110 V - 220 V electrical panel, or the GALLEY breaker on the UTILITY bus of the 110 V - 220 V electrical panel with the 5000 Va inverter optional extra is set to "ON". Check its breaker located on the "household appliances" panel (see chapter ELECTRICITY, page 63) is set to "ON".

POWER SUPPLY Select the power source (Inverter, Generator or shore power socket # 1 from the UTILITY or HIGH LOAD selector - depending on the inverter optional extra - on the 110 V - 220 V selection panel. Start the dishwasher.

For the use and maintenance of the dishwasher, refer to its instruction guide.

ON BOARD UTILITY

LAGOON 62O

RECOMMENDATION

Do not use the washing machine when sailing.

RECOMMENDATION

Do not use the dishwasher when sailing.

6 7

AIR CONDITIONING

ON BOARD UTILITY

LAGOON 62O

1 - Unit heater. 2 - Starting control. 3 - Sea water intake valve. 4 - Air conditioning component breakers. 5 -

Valve to have the glycol system under pressure again

. 6 - Air conditioning unit. 7 - Air conditioning evacuation.

Nota: the same layout can be observed

in the other versions.

 7.7 Air conditioning (optional extra)

The boat may be fitted with air conditioning as an optional extra. The air conditioning unit consists of two compressors located in the starboard engine bilge. It is an ice water circulation system. There are unit heaters in every cabin and in the saloon ceiling.

Before you start the system :

- Open the sea water circulation system (suction valve) in the starboard engine bilge.

Check the cooling pump and circulation pump breakers and the electronical management breakers (access in the engine bilge, under the watermaker location) are set to "ON". Check the breakers of the different components on the AIR CONDITIONING bus of the 110 V - 220 V electrical panel are set to "ON".

POWER SUPPLY Select the supply source (Generator or shore power socket # 2 using the AIR CONDITIONING selector on the 110 V - 220 V selection panel.

Start the air conditioning unit and set the temperature and ventilation desired on the air conditioning controls in the areas concerned.

Please note: in case the pressure should drop, open the filling valve located before the manometer in the starboard engine bay, so as to have some additional pressure in the system (one bar maximum).

ON BOARD UTILITY

LAGOON 62O

Caution: this system conveys water, not glycol.

- First make sure the water unit works.

- In case the pressure should drop again and again, seek advice from a specialist.

For the draining, use and maintenance of the air conditioning system, refer to its instruction guide.

 7.8 Icemaker (optional extra)

The boat may be fitted as an optional extra with an icemaker located in the cockpit. The port tank supplies it with water.

Open the fresh water valve located behind the icemaker. Turn the switch at the bottom of the icemaker on “ON”.

Check the GALLEY breaker located on the UTILITY bus of the 110 V 220 V electrical panel is set to "ON". Check its breaker located on the "Household appliances" panel (see chapter ELECTRICITY, page 63) is set to "ON".

POWER SUPPLY Select the supply source (Inverter, Generator or shore power socket # 1 using the UTILITY selector on the 110 V - 220 V selection panel.

For the use and maintenance of the icemaker, refer to its instruction guide.

GRILL

ON BOARD UTILITY

LAGOON 62O

 7.9 Grill (optional extra)

The boat may be fitted with a grill, as an optional extra, in the cockpit.

Check the GALLEY breaker located on the HIGH LOAD bus of the 110 V

- 220 V electrical panel is set to "ON". Check its breaker located on the "Household appliances" panel (see chapter ELECTRICITY, page 63) is set to "ON".

POWER SUPPLY Select the supply source (Inverter, Generator or shore power socket # 1 using the A.C. HIGH LOAD selector on the 110 V - 220 V selection panel.

Before using it, pour water into the grease tray under the grate.

For the use and maintenance of the grill, refer to its instruction guide.

ON BOARD UTILITY

LAGOON 62O

8.1 ENGINES

8.2 FUEL

8.3 PROPELLERS, ANODES, SHAFT LINE BRAKE

8.4 BOW THRUSTER

SSEECCTTIIOONN 88

PPRROOPPUULLSSIIOONN

PROPULSION

PLACE OF THE ENGINES

LAGOON 62O

1 - Fuel tanks.

2 - Fuel closing pull handle.

3 - Sea water filter.

4 - Fuel filter.

5 - Engine water inlet valve .

6 - Engine.

7 - Expansion tank.

8 - Diesel oil tank fillers.

9 - Engine starting panel.

10 - E-key.

Each hull has the same components.

Nota : each valve in the boat is identified.

COUPLING CIRCUIT

BREAKER

Nota: the same layout can be observed

in the other versions.

 8.1 Engines

ACCESS You have access to the engines through the transom extension hatches.

STARTING

Before starting the engines :

- Check the fuel valves are open (see place following version page 14).

- Open the valves of the engine cooling systems.

- Switch on the electric system turning their engine cutouts to ON (access in the engine bilges).

- Sweep the e-key in front of the engine starting panel at the port helm station. The warning lights on the panel and controls turn green.

- Start the port or starboard engines pressing the “START/STOP” button on the starting panel. Please note: When “IGNITION” is 'on', it means the ignition was switched on. To shift from the port to the starboard helm station, change the port station controls to neutral position, then shift to the starboard station and press the “STATION” button under the controls.

It is possible to lock the helm station you wish , keeping the “STATION” button pressed.

Carefully read the engine instruction guide supplied with the boat ; it gives you detailed explanations as to the best use of the engines and relative operations.

ENGINE START WITH BATTERY COUPLING

In case one of the start battteries is not available :

- Turn to the ON position the coupling cutout (port engine bilge).

- Start the engine concerned.

- Turn the coupling cutout back to the OFF position.

Nota: in the standard configuration, the engine batteries are recharged by their respective engines.

MAINTENANCE OF THE ENGINES Follow the instructions for maintenance appearing in the guide supplied with the engines.

ENGINE WATER SUCTION VALVES The engine water suction valves (access in the engine bilges) shall absolutely be open before starting the engine.

Keep the strainers of both engine in the best possible state of cleanliness. Brush the stainers when the boat is carenned.

PROPULSION

LAGOON 62O

RECOMMENDATION

Stop the engine before opening the hatches. In case you have to intervene when the engine is running :

- Stay away from belts and mobile parts.

- Be careful with full clothes, long hair, rings, etc.. (they may be caught).

- Wear appropriate clothes (gloves, caps, etc.).

RECOMMENDATION

At anchor, lock the start of the engines using the e-key.

FUEL - ENGINE COOLING

PROPULSION

LAGOON 62O

1 - Release mechanism of the starboard engine

bilge extinguisher. 2 - Cut off device of the starboard tank supply. 3 - Cut off device of the generator tank supply (portside). 4 - Release mechanism of the port engine bilge

extinguisher. 5 - Cut off device of the port tank supply. 6 - Fuel filter. 7 - Sea water filter. 8 - Engine water suction valve.

Galley / hull version Galley / saloon version

1 2

Lagoon 620 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
