1
300Mbps Outdoor Wireless
Bridge/WISP
User Guide
（ideal for LF-R800）
Version：V2.0.0
2
COPYRIGHT & TRADEMARKS
Copyright © 2012 Shenzhen Lafalink Technologies Co,. LTD.
Specifications are subject to change without notice. is a registered
trademark of LAFALINK TECHNOLOGIES CO., LTD. Other brands and product
names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used
to make any derivative such as translation, transformation, or adaptation without
permission from LAFALINK TECHNOLOGIES CO., LTD. Copyright © 2010
LAFALINK TECHNOLOGIES CO., LTD.
All rights reserved.
http://www.lafalink.com
3
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following
measures: •
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or tv interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
4
uncontrolled environment. This device and its antenna must not be co-located or
operating in conjunction with any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable
to only Mobile Configurations. The antennas used for this transmitter must be
installed to provide a separation distance of at least 20 cm from all persons and must
not be co-located or operating in conjunction with any other antenna or transmitter.”
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
5
National Restrictions
2400.0-2483.5 MHz
Country Restriction Reason/remark
Bulgaria
General authorization
required for outdoor use
and public service
France
Outdoor use limited to 10
mW e.i.r.p. within the band
2454-2483.5 MHz
Military Radiolocation use.
Refarming of the 2.4GHz
band has been ongoing in
recent years to allow current
relaxed regulation. Full
implementation planned
2012
Italy
If used outside of own
premises, general
authorization is required
Luxembourg None
General authorization
required for network and
service supply(not for
spectrum)
Norway Implemented
This subsection does not
apply for the geographical
area within a radius of 20 km
from the centre of
Ny-Ålesund
Russian Federation Only for indoor applications
Note: It’s not used outdoors in France.
6
Package Content
The following items should be found in your package:
One 300M Wireless CPE LF-R500
One 12V1A Power Adapter
One PoE Injector
One Mounting Kits
One Quick Installation Guide
Note
：
Make sure that the package contains the above items. If any of the
listed items are damaged or missing, please contact your distributor.
7
Contents
Chapter 1 Product Review
......................................................................................................
8
1.1 Overview of the Product
...............................................................................................
8
1.2 Features
..........................................................................................................................
8
Chapter 2 Hardware Installation
..........................................................................................
10
2.1 LED Explanation
..........................................................................................................
10
2.2 Interfaces and button
..................................................................................................
10
2.3 System Requirements
................................................................................................
11
i
2.4 Environment Requirements
.......................................................................................
11
Chapter 3 Connecting the Device
.......................................................................................
12
3.1 Connecting the Device
...............................................................................................
12
Chapter 4 Wireless Mode
.....................................................................................................
17
Chapter 5 Gateway Mode
.....................................................................................................
19
Chapter 6 Bridge Mode
.........................................................................................................
22
Chapter 6 Wireless ISP Mode
..............................................................................................
25
8
Chapter 1 Product Review
Thank you for choosing LF-R500 2.4GHz High Power Wireless Outdoor CPE
1.1 Overview of the Product
The LF-R800 2.4GHz High Power Wireless Outdoor CPE is dedicated to Outdoor
wireless network solutions. The LF-R800 2.4GHz High Power Wireless Outdoor CPE
will allow you to connect your network with other wireless devices wirelessly, sharing
Internet Access, files and fun, easily and securely. The high power design will also
help you build a more stable link or cover more area outdoors.
The LF-R800 2.4GHz High Power Wireless Outdoor CPE provides 3 operation
modes for multi-user to access the Internet: Gateway, Bridge and WISP Client Mode.
In Gateway mode, it can access the Internet via an DSL/Cable Modem, while
sharing data wirelessly. In bridge mode it can bridge another wireless singals. In
WISP client router mode, it works as a WISP CPE and can access the Internet
wirelessly via your WISP.
The LF-R800 2.4GHz High Power Wireless Outdoor CPE provides multiple
protection measures. It can be set to turn off wireless network name (SSID)
broadcast so that only stations that have the SSID can be connected. The AP
provides wireless LAN 64/128/152-bit WEP encryption security, and WPA/WPA2 and
WPA-PSK/WPA2-PSK authentication, as well as TKIP/AES encryption security.
The LF-R800 2.4GHz High Power Wireless Outdoor CPE complies with the IEEE
802.11n and IEEE 802.11g/b standards so that the data transmission rate is up to
150Mbps. The wireless transmission range can extend up to tens of kilometers.
1.2 Features
Complies with IEEE 802.11 b/g/n, IEEE 802.3, IEEE 802.3u standards.
Wireless Data transfer rates up to 300Mbps.
Supports Gateway Bridge, WISP Client operation mode.
High output transmit power and receive sensitivity optimized.
