WS-9055TWC
Wireless 433 MHz
Weather Station
Instruction Manual
TABLE OF CONTENTS
Topic Page
Quick Setup 3-5
Inventory of Contents 6-7
Detailed Setup Guide
Battery Installation 7
Setting the Time 8
Features
Minimum and Maximum
Temperatures
Resetting Minimum and
Maximum Temperatures
Adding additional remote
temperature sensors
(optional)
Weather Forecast 12
Weather Icons 13-14
Tendency Arrow 14
Mounting 15-16
Troubleshooting 16-18
Maintenance and Care 18-19
Specifications 19-20
Warranty Information 21-26
9
10
10-11
2
QUICK SETUP
Hint: Use good quality Alkaline
Batteries and avoid rechargeable
batteries.
1. Have the indoor temperature
station and remote temperature
sensor 3 to 5 feet apart.
2. Batteries should be out of both
units for 10 minutes.
3. Place the batteries into the
remote temperature sensor first
then into the indoor temperature
station.
(All remote temperature sensors must
be started before the indoor
temperature station)
4. DO NOT PRESS ANY
BUTTONS FOR 15 MINUTES.
In this time the indoor temperature
station and remote temperature sensor
3
will start to talk to each other and the
display will show both the indoor
temperature and an outdoor
temperature. If the indoor
temperature station does not display
both temperatures after the 15
minutes please retry the set up as
stated above. After both indoor and
outdoor temperatures are displayed
for 15 minutes you can place your
remote temperature sensor outdoors
and set your time.
The remote temperature sensor
should be placed in a dry, shaded
area. The remote temperature sensor
has a range of 80 feet. Any walls that
the signal will have to pass through
will reduce distance. An outdoor
wall or window can have up to 30
feet of resistance and an interior wall
can have up to 20 feet of resistance.
4
Your distance plus resistance should
not exceed 80 ft. in a straight line.
NOTE: Fog and mist will not harm
your remote temperature sensor but
direct rain must be avoided.
To complete the set up of your indoor
temperature station after the 15
minutes have passed please follow the
steps in the detailed set up guide on
page 8.
INVENTORY OF CONTENTS
1.
The indoor weather station (Figure
1)
2.
The remote temperature sensor
(TX6U) and mounting bracket.
(Figure 2)
3.
3 each, 1/2” Philips screws.
4.
One strip of double sided adhesive
tape.
5.
Instruction Manual and Warranty
Card.
5
Figure 1
ADDITIONAL EQUIPMENT
(not included)
1.
1 Philips screwdriver.
2.
2 Fresh AA Alkaline batteries.
3.
2 Fresh AA Alkaline batteries
DETAILED SETUP
GUIDE
Battery Installation
Figure 2
Holder
6
1. Install 2 AA batteries in the remote
temperature sensor. Make sure they
do not spring free, or start-up
problems may occur.
2.
Install 2 AA batteries in the indoor
weather station. Do not press any
buttons for
at least
fifteen
minutes.
Setting the time
1. Press and hold the “SET” key for 4
seconds.
2. The hour will flash.
3. Press and release the “+” key to
advance the hour.
4. Press and release the “SET” key.
5. The minute is flashing.
6. Press and release the “+” key to
advance the minutes.
7
7. Press and release the “SET” key to
exit programming.
FEATURES
Minimum and Maximum
Temperatures
1.
Press and release the “MIN/MAX”
button, “MAX” appears between the
indoor and remote temperatures.
2.
The recorded maximum indoor and
remote temperature is displayed.
3.
Press and release the “MIN/MAX”
button.
4.
“MIN” appears between the indoor
and remote temperatures.
5.
The recorded minimum temperature
is displayed.
6.
Press and release the “MIN/MAX”
button to exit min/max mode.
7.
To view optional additional sensors,
press and release the “CH” button
8
while viewing the minimum or
maximum temperatures.
Resetting Min and Max Temperatures
To reset both the minimum and
maximum temperatures—press and
hold the “MIN/MAX” button for 5
seconds.
Adding Additional Remote
Temperature Sensors (optional)
The WS-9055U is able to receive
signals from 3 different remote
temperature sensors. Following are
some brief instructions for the basic
set-up of remote temperature sensor
units with the WS-9055U. These extra
remote temperature sensors can be
purchased through the same dealer as
this unit, or by contacting La Crosse
Technology directly. A TX6U will
monitor temperature only, a TX3U
9
will monitor temperature and display
the temperature on its LCD, and the
TX3UP will monitor the temperature
of water or soil via a probe.
When setting up multiple remote
temperature sensors, it is important to
remove the batteries from all existing
units in operation, then to insert
batteries first into all the remote
temperature sensors. Second install
batteries into the indoor weather
station and do not press any buttons
for ten minutes. Transmission
problems will arise if this is not done
correctly.
To view the temperature of a different
remote temperature sensor unit, press
and release the “CH” button. A shift
from one number to the next should
be observed in the OUTDOOR LCD.
10
Weather Forecast
The weather forecasting feature is
estimated to be 75% accurate. The
weather forecast is based solely upon the
change of air pressure over time. The WS9055U averages past air-pressure readings
to provide an accurate forecast, creating a
necessity to disregard all weather
forecasting for 12-24 hours after the unit
has been set-up, reset, or moved from one
altitude to another (i.e. from one floor of a
building to another floor). In areas where
the weather is not affected by the change
of air pressure, this feature will be less
accurate.
Weather Icons
There are 3 possible weather icons that
will be displayed in the FORECAST
LCD:
11
Sunny—indicates that
the weather is expected
to improve (not that the
weather will be sunny).
Sun with Clouds—
indicates that the
weather is expected to
be fair (not that the
weather will be sunny
with clouds).
Clouds with Rain—
indicates that the
weather is expected to
get worse (not that the
weather will be rainy).
The weather icons change when the unit
detects a change in air pressure. The icons
change in order, from “sunny” to “partly
sunny” to “cloudy” or the reverse. It will
not change from “sunny” directly to
12
“rainy”, although it is possible for the
change to occur quickly. If the symbols
do not change then the weather has not
changed, or the change has been slow and
gradual.
Weather Tendency Arrows
Other possible displays in the
FORECAST LCD are 2 weather tendency
arrows, one that points up (on the left side
of the LCD) and one that points down (on
the right side of the LCD). These arrows
reflect current changes in the air pressure.
An arrow pointing up indicates that the air
pressure is increasing and the weather is
expected to improve or remain good. An
arrow pointing down indicates that the air
pressure is decreasing and the weather is
expected to become worse or remain
poor. No arrow means the pressure is
stable.
13
MOUNTING
Note:
To achieve a true temperature
reading, avoid mounting in direct
sunlight. We recommend that you mount
the remote temperature sensor on a Northfacing wall. The sending range is 80ft;
obstacles such as walls, concrete, and
large metal objects will reduce the range.
Place both units in their desired location
before permanently mounting.
Remote Temperature Sensor
Remove the mounting bracket from the
remote temperature sensor. Mount the
bracket in the desired location with either
screws or adhesive tape. Insert remote
temperature sensor into mounting bracket.
Indoor Weather Station
The indoor weather station comes with
the table stand already mounted. If you
wish to use the table-stand all that is
14
required is to place the indoor weather
station in an appropriate location.
To wall mount the indoor weather station
first remove the table stand. Next insert
an appropriate screw in your desired
location. Using the integrated hanging
hole on the back of the unit, slip indoor
weather station over the screw and pull
down to secure.
TROUBLESHOOTING
NOTE: For problems not solved, please
contact La Crosse Technology via e-mail
or phone, or visit our website,
www.lacrossetechnology.com
Problem: The LCD is faint
Solution: Replace batteries
Problem: No outdoor temperature is
displayed.
15
Solution:
1. Remove all batteries, reinsert into
remote temperature sensor first, then
into the indoor weather station.
2. Place remote temperature sensor
closer to the indoor weather station.
3. Be sure all batteries are fresh.
4. Place remote temperature sensor and
indoor weather station in position so
the straight-line signal is not passing
through more than two or three
walls.
Problem: Temperatures do not match if
units are placed next to each other.
Solution:
Each temperature sensor is manufactured
to be accurate to within 1 degree plus or
minus and under normal conditions, so
two sensors could be as much as 2
degrees different. However, the difference
can be exaggerated further because the
sensors are designed for different working
environments. The indoor sensor is less
responsive to ambient air currents because
16
of the shielding effect of the display's
case. In addition, the case can act as a
heat sink to absorb and store heat from
external sources (i.e. handling of the case
or radiant heat). Also, the much greater
range of the outdoor temperature sensor
requires a different calibration curve than
the indoor range. Error is usually greater
at the extreme ends of a range, making it
harder to compare different ranges with
different curves. Under non-laboratory
conditions, it is difficult to compensate
for the above factors and obtain an
accurate comparison.
MAINTENANCE AND CARE
INSTRUCTIONS
• Extreme temperatures, vibration, and
shock should be avoided to prevent
damage to the units.
• Clean displays and units with a soft,
damp cloth. Do not use solvents or
17
scouring agents; they may mark the
displays and casings.
• Do not submerge in water.
• Do not subject the units to
unnecessary heat or cold by placing
them in the oven or freezer.
• Opening the casings invalidates the
warranty. Do not try to repair the
unit. Contact La Crosse Technology
repairs.
SPECIFICATIONS
Transmitting
Frequency
Measuring Temperatures
Indoor Weather
Station
Remote
Temperature
Sensor
433MHz
32°F to 156.2°F with
0.2 °F resolution
(0°C to 69.0°C with
0.1°C resolution)
-21.8 °F to 156.2°F
with 0.2°F resolution
(-29.9°C to 69.0°C
with 0.1°C resolution)
18
Temp accuracy
Transmitting
range
Temperature check
Indoor Every 10 seconds
Outdoor Twice in 10 minutes
Batteries—(Alkaline recommended)
Remote
Temperature
Sensor
Indoor Weather
Station
Dimensions: (L x W x H)
Indoor Weather
Station
Remote
Temperature
Sensor
Battery life Approximately 1 year
+/- 1°F (+/- .5°C)
Maximum 80 feet
(25m) open space
2 x AA, 1.5V
2 x AA, 1.5V
5.5” x 3.2” x 1.25”
(140 x 81 x 32 mm)
1.57 x 0.85 x 5.00 in.
(128 x 40 x 23 mm)
19
WARRANTY INFORMATION
La Crosse Technology, Ltd provides a 1year limited warranty on this product against
manufacturing defects in materials and
workmanship.
This limited warranty begins on the original
date of purchase, is valid only on products
purchased and used in North America and
only to the original purchaser of this
product. To receive warranty service, the
purchaser must contact La Crosse
Technology, Ltd for problem determination
and service procedures. Warranty service
can only be performed by a La Crosse
Technology, Ltd authorized service center.
The original dated bill of sale must be
presented upon request as proof of purchase
to La Crosse Technology, Ltd or La Crosse
Technology, Ltd’s authorized service center.
La Crosse Technology, Ltd will repair or
replace this product, at our option and at no
charge as stipulated herein, with new or
reconditioned parts or products if found to
20
be defective during the limited warranty
period specified above. All replaced parts
and products become the property of La
Crosse Technology, Ltd and must be
returned to La Crosse Technology, Ltd.
Replacement parts and products assume the
remaining original warranty, or ninety (90)
days, whichever is longer. La Crosse
Technology, Ltd will pay all expenses for
labor and materials for all repairs covered by
this warranty. If necessary repairs are not
covered by this warranty, or if a product is
examined which is not in need or repair, you
will be charged for the repairs or
examination. The owner must pay any
shipping charges incurred in getting your La
Crosse Technology, Ltd product to a La
Crosse Technology, Ltd authorized service
center. La Crosse Technology, Ltd will pay
reasonable return shipping charges to the
owner of the product.
Your La Crosse Technology, Ltd warranty
covers all defects in material and
workmanship with the following specified
exceptions: (1) damage caused by accident,
21
unreasonable use or neglect (including the
lack of reasonable and necessary
maintenance); (2) damage occurring during
shipment (claims must be presented to the
carrier); (3) damage to, or deterioration of,
any accessory or decorative surface; (4)
damage resulting from failure to follow
instructions contained in your owner’s
manual; (5) damage resulting from the
performance of repairs or alterations by
someone other than an authorized La Crosse
Technology, Ltd authorized service center;
(6) units used for other than home use (7)
applications and uses that this product was
not intended or (8) the products inability to
receive a signal due to any source of
interference.. This warranty covers only
actual defects within the product itself, and
does not cover the cost of installation or
removal from a fixed installation, normal
set-up or adjustments, claims based on
misrepresentation by the seller or
performance variations resulting from
installation-related circumstances.
22
LA CROSSE TECHNOLOGY, LTD WILL
NOT ASSUME LIABILITY FOR
INCIDENTAL, CONSEQUENTIAL,
PUNITIVE, OR OTHER SIMILAR
DAMAGES ASSOCIATED WITH THE
OPERATION OR MALFUNCTION OF
THIS PRODUCT. THIS PRODUCT IS
NOT TO BE USED FOR MEDICAL
PURPOSES OR FOR PUBLIC
INFORMATION. THIS PRODUCT IS
NOT A TOY. KEEP OUT OF
CHILDREN’S REACH.
This warranty gives you specific legal rights.
You may also have other rights specific to
your State. Some States do no allow the
exclusion of consequential or incidental
damages therefore the above exclusion of
limitation may not apply to you.
23
For warranty work, technical support, or
information contact:
La Crosse Technology
2809 Losey Blvd. S.
La Crosse, WI 54601
Phone: 608.782.1610
Fax: 608.796.1020
e-mail:
support@lacrossetechnology.com
(warranty work)
sales@lacrossetechnology.com
(information on other products)
web:
www.lacrossetechnology.com
Questions ? Instructions? Please visit:
www.lacrossetechnology.info/9055
24
FCC DISCLAIMER
This device complies with part 15 of the
FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause
harmful interference.
(2) This device must accept any
interference received, including
interference that may cause
All rights reserved. This handbook must not
be reproduced in any form, even in excerpts,
or duplicated or processed using electronic,
mechanical or chemical procedures without
written permission of the publisher.
This handbook may contain mistakes and
printing errors. The information in this
handbook is regularly checked and
corrections made in the next issue. We
accept no liability for technical mistakes or
printing errors, or their consequences.
All trademarks and patents are
acknowledged.
undesired operation.
25
Loading...
