La cross technology WS-7048U User Manual

WS-7048U
WIRED RAIN METER
Instructional Manual
        
Introduction:
Thank you for purchasing this innovative Wired Rain Meter for display of rainfall data through a connected wired rain gauge. With two easy to use function keys, this innovative product is ideal for use in the home or office.
Wired Rain Meter
        
Hanging Hole
RESET
Rain Gauge Foldout Stand
RESET
Features:
Three displays of rainfall quantity
Transmission of rainfall data through a connected wired rain
gauge
Rainfall unit display in inch or millimeter
Manual and auto reset of rainfall data
Auto OFF function
Wall mounting or table standing
Setting Up:
Note:
When opening the battery cover make sure that the batteries do not spring free from the contacts since this will cause start and transmission problems.
Battery Change: It is recommended to replace the batteries in the unit on an annual basis to ensure optimum accuracy.
Batte
Rain Gauge Wire
1. Connect the wire of the rain gauge to the jack of the Rain Meter
2. Observing the correct polarization, insert 2 x AA, IEC LR6
batteries into the compartment at the back of the Rain Meter and replace the cover.
3. All segments of the LCD will light up briefly. Then 0.00 inch or
0.00mm (default in inch units) will be displayed in all 3 counters. If the “0.0” is not displayed after a few seconds, remove the batteries and wait for at least 10 seconds before reinserting them.
4. Place the rain gauge in an appropriate location (wire length is 33
feet/ 10 meters)
r
r
Counte
Counter
Counte
Keys Function: The simple design of this product features two RESET keys.
RESET 1 Key: Press for 5 seconds to reset the rainfall data of counter 1 to “0”
RESET 2 Key: Press for 5 seconds to reset the rainfall data of counter 2 to “0”
Pressing both the RESET 1 and RESET 2 keys: Changes the display between inch and mm
Display of rainfall data: When raining, the rainfall data will be collected through the rain gauge and transmitted to the Rain Meter (receiver) in counter 1, 2, and “AUTO”.
Counter 1 & 2
The rain quantity data will be displayed in counters 1 and 2. New rain data will be added to the previous records and unless the counters are manually reset by pressing RESET 1 or RESET 2 key, the rain data will increase continuously to a maximum of 999.99 inch or 9999.9 mm. Above this amount, the data in counters 1 and 2 will be overflowed and start from 0.
Counter “AUTO”
The rain quantity data will also be displayed and added to the previous recorded data in the “AUTO” counter. The rain data cannot be reset manually.
Note: If no rain is recorded during a period of 2 hours the “AUTO” counter will display the last recorded data. The “AUTO” counter will automatically reset to 0.00 inch or 0.0 mm when rain begins again.
Auto Off Function: The Rain Meter will automatically power OFF when no rain has been recorded the last 12 hours and no keys have been pressed during that period.
Note: When measurable rain begins again or a button is pressed the Rain Meter will automatically power ON and the counters will display:
Counter 1 and 2:
New rain data will be collected and added to the last record before the Rain Meter was automatically powered down.
Counter AUTO:
The counter will automatically reset to 0.00 inch or 0.0 mm and begin displaying current rain data.
Positioning The Rain Meter: The Rain Meter can be positioned on a flat surface or on a wall.
Foldout Table Stand
The foldout table stand is located on the backside of the Rain Meter. Carefully pull out the stand and place the Rain Meter in the desired location.
Wall Mounting
Place a screw in the desired location leaving the head extended about ¼” from the wall. Hang the Rain Meter on the screw ensuring that the Rain Meter locks into place.
Positioning The Rain Gauge
Position the connected rain gauge outdoor to collect rainfall data (maximum length of wire: 33 feet/ 10m). Ensure that the rain gauge is placed in a secure and flat location where it can properly collect properly rain quantity without obstruction. Ensure also that the rain gauge is securely mounted at the appropriate location otherwise it may not transmit accurate rainfall data.
Maintenance
Avoid placing the units in locations prone to extreme
temperatures, vibration and shock since these may cause damage and inaccurate readings.
When cleaning the display and casing of the Rain Meter
use a soft damp cloth only. Do not use solvents or scouring agents as they may mark the casing and LCD.
Do not submerge the Rain Meter in water.
Immediately remove all low powered batteries to avoid
leakage and damage. Replace only with new batteries of the recommended type.
Please do not make any attempt to make any repairs to the
units. Return them to their original point of purchase for repair by qualified personnel. Opening and tampering with the units will invalidate the warranty.
Specifications Rainfall display range: 0 to 9999.99 inch/ 0 to 9999.9 mm (overflow and will automatically
restart from zero) Rain meter data updating: immediate when raining Transmission period-Rain Sensor: immediate when raining Rain gauge wire length: about 33 feet/ 10 meters Power source: 2 x AA, IEC LR6 1.5V batteries
Rain Meter dimensions (LxWxH)
Rain Meter: 3.62”x1.22”x4.52”/ 92x31x15mm Rain Sensor: 5.51”x2.75”x5.39”/140x70x137mm
Liability Disclaimer
The manufacturer and supplier cannot accept any responsibility
for any incorrect readings and any consequences occurring should an inaccurate reading take place.
This product is not to be used for medical purposes or for public
information.
This product is designed for strict home use as an indication of
rain quantities and is not 100% accurate. Readouts given by this product should be taken only as an indication and not as being totally accurate.
The specifications of this product may change without prior
notice.
This product is not a toy. Keep out of the reach of children.
No part of this manual may be reproduced without written
consent of the manufacturer.
WARRANTY INFORMATION
La Crosse Technology, Ltd provides a 1-year limited warranty on this product against manufacturing defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only on products purchased and used in North America and only to the original purchaser of this product. To receive warranty service, the purchaser must contact La Crosse Technology, Ltd for problem determination and service procedures. Warranty service can only be performed by a La Crosse Technology, Ltd authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center.
La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of La Crosse Technology, Ltd and must be returned to La Crosse Technology, Ltd. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. La Crosse Technology, Ltd will pay all expenses for labor and materials for all repairs covered by this warranty. If necessary repairs are not covered by this warranty, or if a product is examined which is not in need or repair, you will be charged for the repairs or examination. The owner must pay any shipping charges incurred in getting your La Crosse Technology, Ltd product to a La Crosse Technology, Ltd authorized service center. La Crosse Technology, Ltd will pay ground return shipping charges to the owner of the product to a USA address only.
Your La Crosse Technology, Ltd warranty covers all defects in material and workmanship with the following specified exceptions: (1) damage caused by accident, unreasonable use or neglect (including the lack of reasonable and necessary maintenance); (2) damage occurring during shipment (claims must be presented to the carrier); (3) damage to, or deterioration of, any accessory or decorative surface; (4) damage resulting from failure to follow instructions contained in your owner’s manual; (5) damage resulting from the performance of repairs or alterations by someone other than an authorized La Crosse Technology, Ltd authorized service center; (6) units used for other than home use (7) applications and uses that this product was not intended or (8) the products inability to receive a signal due to any source of interference.. This warranty covers only actual defects within the product itself, and does not cover the cost of installation or removal from a fixed installation, normal set-up or adjustments, claims based on misrepresentation by the seller or performance variations resulting from installation-related circumstances.
LA CROSSE TECHNOLOGY, LTD WILL NOT ASSUME LIABILITY FOR INCIDENTAL, CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH THE OPERATION OR MALFUNCTION OF THIS PRODUCT. THIS PRODUCT IS NOT TO BE USED FOR MEDICAL PURPOSES OR FOR PUBLIC INFORMATION. THIS PRODUCT IS NOT A TOY. KEEP OUT OF CHILDREN’S REACH.
This warranty gives you specific legal rights. You may also have other rights specific to your State. Some States do no allow the exclusion of consequential or incidental damages therefore the above exclusion of limitation may not apply to you.
For warranty work, technical support, or information contact:
La Crosse Technology
2809 Losey Blvd. S.
La Crosse, WI 54601
Phone: 608.782.1610
Fax: 608.796.1020
e-mail:
support@lacrossetechnology.com
(warranty work)
sales@lacrossetechnology.com
(information on other products)
web:
www.lacrossetechnology.com
