LaCie Ethernet Disk mini
Gigabit Ethernet & USB 2.0
Network Hard Drive
d2 Design by Neil Poulton
Universal Solution
With Gigabit Ethernet for file sharing and USB 2.0 for
personal storage, the versatile Ethernet Disk mini works
with or without a network. Universally accessible on
every wired or wireless network, this drive is capable
of sharing files between Windows, Mac and Linux users.
If there is no network available, the Ethernet Disk mini
can be used with your PC or Mac without any file system
limitations. It also comes with an additional USB 2.0
port for attaching an extra hard drive to cost-effectively
expand your network’s storage capacity.
Easy To Set Up & Use
The user-friendly Wizard Install with Auto IP
configuration quickly and easily sets up your Ethernet
Disk mini. The full-featured yet intuitive web-based
administration interface allows for configuring your
network settings including user profiles and security
permissions. Only authorized users can log on to
specific shared folders. For ultimate convenience, the
LaCie Ethernet Disk mini can be accessed via web
browsers, FTP or the network neighborhood.
Home & Small Office Network
The Ethernet Disk mini can be used as a simple, costeffective data server. PC, Mac and Linux users can
simultaneously and securely store and share office files
throughout the entire network. The impressive network
performance, especially with the Jumbo Frame support,
makes this solution perfect as a fast, centralized backup
location. Encased in sturdy, heat-dissipating aluminum,
its unique cooling system offers safe, near-silent
operation.
Ideal For Home Entertainment
Store and exchange your music, photos and videos with
the LaCie Ethernet Disk mini. Easily play your digital
media content on any UPnP™ AV-compatible digital
media adapter (DMA) without the need for a computer.
Ideal for streaming digital media content, the Ethernet
Disk mini can act as your multimedia server.
100GB
100,000 photos or
100 hours of MPEG-2 video or
30,000 audio tracks***
*
=
• Share & store files over a Gigabit Ethernet network
• Use as a personal hard drive via USB 2.0
• Back up home or office data to a fast, central location
• Stream multimedia content on your home entertainment network****
Page 2
Features
UPnP™ A/V
Laptop
Mac
TV
Router
Ethernet Disk mini
Digital Media Adaptor
PC
USB Expansion Drive
Stereo
• Gigabit Ethernet & USB 2.0 interface
• Expandable capacity through a USB host port
• Users & share level permissions
• Jumbo Frame support
• Quick & easy IP configuration
• Upright, stackable or rack-mountable
Box Content
• LaCie Ethernet Disk mini
• Ethernet cable
• USB 2.0 cable
• External power supply
• Drive stand for upright use
• LaCie Utilities CD-ROM with User Manual
• Quick Install Guide
System Requirements
• Ethernet switch or router
• PC or Mac equipped with an Ethernet network
adapter or a USB 2.0 port
• G4 Power Mac/PC with Pentium II 233Mhz
processor or higher
• Web browser (Explorer, Safari, Firefox, etc.)
Gigabit Ethernet
USB expansion
USB to computer
Power connector
Capacity*
Item Number
Interface
Rotational Speed
Cache
Expansion Port
Network Protocols
320GB 500GB
301137 301138
Gigabit Ethernet 10/100/1000 & USB 2.0
7200rpm
8MB or greater 16MB
1 x USB 2.0 for additional storage & camera support
File Server: SMB (Windows/Linux), AFP (Mac), FTP Server, HTTP for online browsing,
UPnP™ A/V & Apple Bonjour
Network Setting
Supported OS
Software
Dimensions (WxHxD)
Weight
Warranty
*1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 10–15% less).
**only over Ethernet and not compatible with LaCie ‘1-Click’ Backup software.
***Calculations are based on 1MB per photo; 1GB/hour of MPEG-2 compressed video and 3MB per 3-minute song.
****via UPnP™ AV-compatible digital media player (DMA)
©2007, LaCie. The LaCie logo is a trademark of LaCie. Other product and brand names mentioned
herein may be trademarks or registered trademarks of their respective owners. Specifications and
appearance are given as guidelines and are subject to change without notice. www.lacie.com 071015
Wizard Install with automatic IP configuration (DHCP client-compatible),
Web-based management
Windows 98SE**, Windows Me**, Windows 2000, Windows XP (SP1 & SP2), Windows VistaTM;
Mac OS 9.x**, Mac OS 10.2; Linux 2.4 or higher
LaCie IP Configurator (for mapping drives on the network); LaCie ‘1-Click’ Backup software
160 x 173 x 44 mm / 6.3 x 6.8 x 1.7 in.
1500 g / 3.3 lbs.
3 years limited
LaCie Ethernet Disk mini
