Lacanche LAE 010 TPK User Manual
Hob top option
PLANCHA
LAE 010 TPK
EN 10-2016
MulticookerChargrill Electric fryerGas burners InductionCeramic Hob Plancha
MulticookerChargrill Electric fryerGas burners InductionCeramic Hob Plancha
Item No. P U I
LAE 010 TPK 2,2 kW
230 V1N~ 50 Hz + T / E
400 V3N~ 50 Hz + T / E
9,50
5,50
Contents
TECHNICAL DATA 48
INSTALLER’S MANUAL 50
INSTALLING/ POSITIONING 51
ELECTRICAL CIRCUIT DIAGRAM 52
USER’S MANUAL 54
USE 55
CLEANING AND MAINTENANCE 57
► Plancha mild-steel .
► Dimensions 515 mm x 360 mm.
► 35-micron satin-nish chrome coating.
► The heat is generated by a 2200 W resistor, controlled by the thermostat.
► Limit-control plate protection.
Plancha : Optional plate, smooth grill plate to the left or right of the central cooking surface
Accessories :
► Removable anti-splash screen.
► A scraper.
Compliance with European regulations (EC):
Low Voltage Directive: 2014/35/EC.
Electromagnetic Compatibility (EMC) Directive: 2014/30/EC.
TECHNICAL DATA
28
EN 10-2016
MulticookerChargrill Electric fryerGas burners InductionCeramic Hob Plancha
Hob top option
«LAE 010 TPK»
INSTALLER’S MANUAL
Appliances must be installed in a workmanlike manner in accordance with the instructions in this
manual and locally applicable regulations.
This manual should be handed over to the user after installation.
29
