1 Turn off the computer
2 Remove the old keyboard
and mouse
Caution!
If you have previously installed other keyboard or mouse
drivers on your computer,please remove them first!
(Use Windows
®
Add/Remove Programs in the Windows
®
Control Panel.) Do not proceed with installation until you
have removed these old drivers.They may interfere with
the proper operation of your new keyboard and mouse.
3 Connect the keyboard
and mouse receiver
cables
4 Install the batteries in the
keyboard and the mouse
Refer to the battery diagram inside the battery compartment.
Note where the positive and negative ends of the batteries
are to be inserted.
Mouse cable is green and has a mouse icon.
Keyboard cable is purple and has a keyboard icon.
between the receiver
and keyboard and mouse
Press the connect button on the receiver,then press the
reset button on the mouse. Next, press the connect button
on the receiver again, and press the reset button on
the keyboard. Note: you only have 10 seconds from
the time you press the receivers button to press the mouse
or keyboard reset buttons.
7 Install the software
1. Insert the software CD into the CD-ROM drive
of the computer.
2. Follow the on-screen instructions to finish installing
the software (double click on the “SETUP”icon
if installation does not start automatically).
8 Troubleshooting
If your keyboard or mouse does not work, try the following:
Remove the old mouse and keyboard drivers.
Refer to step 2.
Check cable connections. The receiver’s keyboard cable
plugs into the PS/2 keyboard port on the back of the
computer. The receiver’s mouse cable plugs into the PS/2
mouse port. Refer to step 3.
Check battery installation. Refer to the battery diagram
inside the battery compartments. Refer to step
4. Battery life is 2-6 months, depending on usage.
Establish communications. Keep the distance between
the receiver and the keyboard and mouse within 1 meter
(1.5 meters max). Some objects may affect the operating
distance or completely block the signal. Metallic surfaces
will shorten transmission distances. Refer to step 6.
Page 3
®
Wireless Desktop
Low Battery Lights
If the light in the front of the mouse or the top left of the keyboard does not go on when you move the mouse or press
a key,the voltage of the battery is low. Please replace your batteries. Expected battery life is 2 to 6 months depending
on usage. Refer to the Battery Warning document located on the CD for more information on battery safety.
Maintenance of your Wireless Desktop
• You may clean the surface of the Mouse and Keyboard with a soft damp cloth.
• Do not use any harsh or abrasive cleaners
• Before using any chemical cleaners, please test the results on the bottom of the device.
Warranty and FCC
This product comes with a limited 2-year warranty and is FCC compliant. For more information, please read the included
Product Warranty and FCC document located on the software CD.
Customer Service
If you need additional help with your product, contact Labtec at (702) 269-3612 or on the web at: www.labtec.com.
© 2003 Labtec.All rights reserved.Labtec, the Labtec logo, and other Labtec marks are owned by Labtec and may be registered.
All other trademarks are the property of their respective owners.
Page 4
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following meas ures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outl et on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
