AUTOMIZER

HELPING-HAND

OPERATOR’S MANUAL

AUTOMIZER

OPERATOR’S MANUAL

HELPING-HAND

Liability

Labrie Enviroquip Group assumes no liabilty for any incidental, consequential, or other liability that might result from the use of the information contained in this document.

All risks and damages, incidental or otherwise, arising from the use or misuse of the information contained herein are entirely the responsability of the user.

Although careful precaution has been taken in the preparation of this document, Labrie Enviroquip Group assumes no responsiblity for errors or omissions.

January 2017

Liability ........................................................................................ ii

Table of Contents ........................................................................ v

Introduction ................................................................................ 1

Pre-Operating Instructions ........................................................................................................................................................... 1

A Note about Warranty ................................................................................................................................................................... 1

Mission Statement ........................................................................................................................................................................... 1

Vision Statement ............................................................................................................................................................................... 1

Introducing the AUTOMIZERTM HELPING-HAND ........................................................................................................................... 2

Product Overview ...................................................................................................................................................................... 2

Key Features of the A

Multiplexed System .................................................................................................................................................................. 5

Standard Limited Product Warranty .......................................................................................................................................... 6

To Contact Labrie Plus .................................................................................................................................................................... 8

In the U.S. ...................................................................................................................................................................................... 8

In Canada ...................................................................................................................................................................................... 8

UTOMIZER

Safety ........................................................................................... 9

Conventions ....................................................................................................................................................................................... 9

Basic Safety Notions ........................................................................................................................................................................ 9

Responsibilities ............................................................................................................................................................................... 10

Employer Responsibilities ................................................................................................................................................... 10

Employee Responsibilities ................................................................................................................................................... 11

Things to Do .................................................................................................................................................................................... 12

Things to Avoid .............................................................................................................................................................................. 12

General Precautions ..................................................................................................................................................................... 13

Fire ...................................................................................................................................................................................................... 15

Safety Kits ......................................................................................................................................................................................... 15

Location of Safety and Informative Decals ........................................................................................................................... 16

Decals on Body ........................................................................................................................................................................ 16

Decals on Tailgate .................................................................................................................................................................. 24

Decals outside Cab ................................................................................................................................................................. 25

Decals inside Cab .................................................................................................................................................................... 26

Multiplexed Switch Actuators ............................................................................................................................................ 31

Multiplexed Indicator Tops ................................................................................................................................................. 32

Safety Features ............................................................................................................................................................................... 32

Back Up Alarm .......................................................................................................................................................................... 32

Body Safety Prop ..................................................................................................................................................................... 32

Tailgate Safety Prop ............................................................................................................................................................... 33

Camera System (optional) ................................................................................................................................................... 36

Tailgate Holding Valve .......................................................................................................................................................... 37

Safety Lockout Tests ..................................................................................................................................................................... 37

Hopper Door Proximity Switch Test ................................................................................................................................ 38

Arm Fully Retracted Limit Switch Test ............................................................................................................................ 39

Packer Fully Retracted Proximity Switch Test .............................................................................................................. 40

Crusher Panel Up Proximity Switch Test (if equipped) ............................................................................................. 41

Arm Parked Limit Switch Test ............................................................................................................................................ 41

Quick Reference Lockout Chart ......................................................................................................................................... 42

Cleanliness ....................................................................................................................................................................................... 42

Locking Out and Tagging Out the Vehicle ........................................................................................................................... 43

HELPING-HAND ............................................................................................................. 5

vi Table of Contents

Shutting Down the Vehicle ........................................................................................................................................................ 44

Starting Up the Vehicle ................................................................................................................................................................ 45

Driving the Vehicle ........................................................................................................................................................................ 46

Driving Speed ........................................................................................................................................................................... 46

Right-Hand Side Driving Position ..................................................................................................................................... 47

Controls and Indicators ............................................................. 49

Labrie’s Multiplexed System ...................................................................................................................................................... 49

Main Page .................................................................................................................................................................................. 50

Main Menu ................................................................................................................................................................................. 57

Operational Diagram of the Multiplexed System ....................................................................................................... 67

Control Panel ................................................................................................................................................................................... 69

Hydraulic Pump Switch ......................................................................................................................................................... 70

Body Up Switch ........................................................................................................................................................................ 70

Body Down Switch ................................................................................................................................................................. 71

Tailgate Up Switch .................................................................................................................................................................. 71

Tailgate Down Switch ............................................................................................................................................................ 71

Packer Multi-Cycle Switch .................................................................................................................................................... 71

Rubrail Lights Switch ............................................................................................................................................................. 71

Hopper Work Light Switch .................................................................................................................................................. 72

Strobe Light Switch ................................................................................................................................................................ 72

Crusher Panel Down Switch (optional) ........................................................................................................................... 72

Crusher Panel Up Switch (optional) ................................................................................................................................. 72

10-Second Inhibit Switch ..................................................................................................................................................... 73

Auto-Packing Switch .............................................................................................................................................................. 73

Auto-Neutral Switch (optional) .......................................................................................................................................... 73

Hydraulic Alarm Switch (optional) .................................................................................................................................... 73

In-Cab Packer Control Station ................................................................................................................................................... 74

Stop Push-Button (red) ......................................................................................................................................................... 74

Pack Push-Button (green) .................................................................................................................................................... 74

Retract Push-Button (yellow) .............................................................................................................................................. 75

Auxiliary Packer Control Station ............................................................................................................................................... 75

Stop Button ............................................................................................................................................................................... 76

Pack Button ............................................................................................................................................................................... 76

Retract Button .......................................................................................................................................................................... 76

Bucket Control Button ........................................................................................................................................................... 76

Crusher Panel Down Switch ................................................................................................................................................ 77

Crusher Panel Up switch ...................................................................................................................................................... 77

Joystick Controls ............................................................................................................................................................................ 77

Arm Joystick .............................................................................................................................................................................. 77

Cab Dashboard ............................................................................................................................................................................... 79

Parking Brake ............................................................................................................................................................................ 79

Arm Extended Warning Lights ........................................................................................................................................... 80

Operating the AUTOMIZER

Daily Inspection .............................................................................................................................................................................. 83

Approaching the Vehicle ..................................................................................................................................................... 83

Visual Inspection ..................................................................................................................................................................... 84

Starting the Vehicle ................................................................................................................................................................ 84

Body Inspection Procedure ................................................................................................................................................. 85

Arm Inspection Procedure ................................................................................................................................................... 85

Inspecting Right-Hand Side Driving Controls .............................................................................................................. 89

Adjusting Mirrors .................................................................................................................................................................... 90

Setting the Floor Riser ........................................................................................................................................................... 90

HELPING-HAND ............................... 83

Table of Contents vii

Inspection Sheet ..................................................................................................................................................................... 92

Loading and Packing .................................................................................................................................................................... 93

Planning your Route .............................................................................................................................................................. 93

Safety while Using the Packing System .......................................................................................................................... 94

Loading Refuse ........................................................................................................................................................................ 94

Packer Description ................................................................................................................................................................. 95

Loading Procedure ................................................................................................................................................................. 95

Pack on the Go ......................................................................................................................................................................... 99

Unloading ....................................................................................................................................................................................... 100

Unloading Procedure .......................................................................................................................................................... 100

Unloading Corrective Actions .......................................................................................................................................... 101

Unloading Emergency Actions ........................................................................................................................................ 103

Emergency Actions ..................................................................................................................................................................... 103

Hydraulic Oil Spill .................................................................................................................................................................. 103

End-of-the-Day Cleaning and Inspection ........................................................................................................................... 104

Daily Hopper Cleaning ........................................................................................................................................................ 104

Daily Chassis Cleaning ........................................................................................................................................................ 105

Water Trap Bleeding ............................................................................................................................................................ 106

Troubleshooting Quick Reference ......................................................................................................................................... 106

viii Table of Contents

Introduction

The purpose of this manual is to introduce operators to the procedures involved in properly operating the A

UTOMIZER

regarding maintenance procedures, refer to the A

UTOMIZER

Pre-Operating Instructions

It is imperative that you carefully review this manual prior to operating and/or servicing your new A

UTOMIZER

Upon receipt of your new A H

AND unit, perform a complete lubrication.

Mechanisms must be properly lubricated. Factory lubrication is adequate for production and transport purposes only. In addition, the return filter element must be replaced after 50 hours of use.

A Note about Warranty

HELPING-HAND. For information

HELPING-HAND Maintenance Manual.

HELPING-HAND.

UTOMIZER

HELPING-

Do not forget to complete the owner’s registration form and to send it to Labrie Enviroquip Group. Also, make sure you indicated the “In service” date on that form. This date will be used to start the warranty period. Otherwise, the date of delivery from the factory will be used instead.

Mission Statement

Labrie Enviroquip Group is dedicated to providing innovative designs, customized quality equipment and elite customer service.

Vision Statement

The Labrie Enviroquip Group Team will successfully lead the way the world views waste management. We will excel at enhancing our community and protecting the global environment. We are committed to being a profitable company for our customers, shareholders and employees.

2 Introduction

Introducing the AUTOMIZERTM HELPING-HAND

IMPORTANT: Read and thoroughly understand this Operator’s Manual before using the vehicle.

The AUTOMIZERTM HELPING-HAND is a straight-frame, side-loading vehicle, manufactured to the highest standards, and designed to collect residential and commercial refuse and recycling materials.

This vehicle is a modified version of the standard Labrie A equipped with a H

AND

arm maneuvers smoothly with exacting precision, and is easy to operate in narrow space.

ELPING-HAND

Also, this arm is easier to maintain than the R A

UTOMIZER

. Along with this modification, bigger clean-out traps have been added on both sides of

arm1. Thanks to carefully engineered hydraulics, the HELPING-

IGHT-HAND

UTOMIZER

arm which usually equips the

the truck and a simplified and shortened hydraulic circuit has been installed under the body for best performance and efficiency.

UTOMIZER

carts without exiting the cab. The H

HELPING-HAND vehicles are designed to allow a single person to collect waste in roller

ELPING-HAND

arm can extend up to 10 ft. and lift up to 400 lbs

when fully extended.

On the productivity side, the A

UTOMIZER

HELPING-HAND can make 180 pickups per hour on

average thanks to its auto-packing functionality.

The A

UTOMIZER

HELPING-HAND also comes with the electronic multiplexed system designed to make the collection process more efficient and the troubleshooting process more orderly and manageable.

Once the body of the A

UTOMIZER

HELPING-HAND is full, all its content is unloaded at a waste

management landfill or other appropriate site (e.g. transfer station, incinerator, recycling station).

. It has been modified to be

Product Overview

The AUTOMIZERTM HELPING-HAND is equipped with an automated arm (Figure 1-5) controlled by the operator using the in-cab joystick.

Figure 1-1

1. Some units may be equipped with an optional lifting bucket (Figure 1-2) in lieu of a HELPING-HAND

The A

UTOMIZER

ELPING-HAND

arm.

Introduction 3

Another version of the AUTOMIZERTM comes with an optional lifting bucket instead of a HELPING-

AND

gripper assembly. This bucket may be used for manual collection of residential waste, recyclables and organics. It is controlled using either the in-cab joystick or the packer control station located next to the right-hand side folding door.

Figure 1-2

Body’s main components are the hopper (Figure 1-3), the packer (Figure 1-3), the 2 packer cylinders (Figure 1-4), the crusher panel (Figure 1-3) and the tailgate (Figure 1-5).

The hopper is the area of the body where the waste is dumped. The packer is the piece of equipment that pushes the waste into the body. Retraction and extension of the packer are made possible by 2 double-acting cylinders. The crusher panel is used to crush large pieces of waste materials. The tailgate is the rear door that prevents waste from exiting the body during collection. At landfill site, the tailgate is fully raised to enable the discharge of the waste.

UTOMIZER

equipped with the optional lifting bucket

Figure 1-3

Hopper (left); packer (right)

Crusher panel

4 Introduction

Figure 1-4

Figure 1-5

Packer cylinders

Automated arm (left); tailgate (right)

In the cab, you will find a control panel, a monitor, one or two joysticks, and all the switches that control most of the truck’s functions (Figure 1-6).

Introduction 5

Figure 1-6

Inside the A

UTOMIZER

ELPING-HAND

cab

Key Features of the AUTOMIZERTM HELPING-HAND

The AUTOMIZERTM HELPING-HAND comes with a series of key features, such as:

 Body roof and sides made of A1011 GR80 steel, body floor and hopper section made of 100%

Hardox 450 steel, delivering ultimate strength at the lowest possible body weight

 Hardox liners on floor and sides (optional)  10-foot arm extension  Arm lifting capacity at full extension: 400 lbs  Reinforced body walls  Tapered body  Oversized clean-out doors on both sides of the truck  Multiplexed control system with on-board diagnostic tool

Multiplexed System

The AUTOMIZERTM HELPING-HAND is equipped with an electronic monitoring system called the Multiplexed System.

The Multiplexed system used by Labrie is a CAN-based system that integrates a monitor, a control panel and a number of electronic modules. This whole system has been designed to help you operate your unit in an efficient and easy way. See Labrie’s Multiplexed System on page 49 for more details.

IMPORTANT: AUTOMIZER

HELPING-HAND units must be operated by only one person.

6 Introduction

Standard Limited Product Warranty

Subject to the other provisions hereof, LABRIE ENVIROQUIP GROUP, hereinafter called “Labrie” warrants that all new Labrie products (the “Product”) shall be free of defects in material and workmanship under normal use and service for a period of ONE (1) YEAR after delivery to the first registered customer/end-user.

WITHOUT LIMITATION TO THE OTHER PROVISIONS HEREOF, THIS PRODUCT WARRANTY DOES NOT COVER:

 Any and all components or parts of the Product, including without limitation the vehicle chassis,

which are not manufactured and installed by Labrie, whether or not they are covered by an original manufacturer’s or supplier’s warranty;

 Paint;  Damages resulting from abuse, misuse of the Product or from negligence or accidents;  Damages resulting from use of the Product other than for its intended purpose or in a manner

other than its intended normal use and service;

 Damages caused by improper maintenance of the Product including, without limitation, failure to

comply with the maintenance requirements set forth in the Product’s Parts and Maintenance Manual;

 Damages caused by the operation of the Product with parts or components known by the

customer/end-user to be defective or in need of maintenance;

 Parts, components or systems which have been modified without the express authorization of

Labrie or of an authorized Labrie distributor;

 Repairs which are not completed or otherwise expressly authorized by Labrie or an authorized

Labrie distributor;

 Repairs or modifications which have been authorized by Labrie or an authorized Labrie

distributor that are performed by personnel which is not qualified to perform such repairs or modifications;

 Normal wear item parts including, without limitation, oils, fluids, filters, tracks, rollers, wear shoes,

tailgate seals, chains, divider blades and normal wear of the steel structure;  Any and all adjustments and maintenance resulting from normal use and service of the products. For the purposes of this warranty, normal use and service means the operation of the new Product for

fifty (50) hours per week for its intended purpose and in compliance with the operation and maintenance instructions which are provided by Labrie in the Product’s operation and maintenance manuals. It is the customer/end-user’s responsibility to make sure that all operators are familiar and comply with the operation manual and the warning decals on the Product.

In the event a part or component of the Product fails or becomes defective during the warranty period and, in the opinion of Labrie, such failure or defect results from Labrie’s material or workmanship, the part or component shall be repaired or replaced by Labrie or an authorized distributor at no cost provided that the unit is brought to an authorized distributor’s service facility. However, the aforementioned repair or replacement of parts or components may be performed by the customer/ end-user as provided herein if specifically authorized by Labrie or an authorized Labrie distributor.

Introduction 7

Because the Product is engineered to work only with genuine Labrie parts and components, this warranty shall be void and of no effect if i) the Product is modified other than by Labrie or by an authorized Labrie distributor or other than in accordance with a specific authorization and instructions from Labrie or from an authorized Labrie distributor or ii) if parts and components of any other manufacturer are used as substitutes for genuine Labrie parts and components.

LABRIE MAKES NO WARRANTY AS TO MERCHANTIBILITY, FITNESS FOR USE, LEGALITY OF OPERATION IN ANY JURISDICTION OR ANY IMPLIED WARRANTY OF ANY KIND OR NATURE. LABRIE SHALL NOT BE LIABLE FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND OR NATURE. NO OTHER PERSON, FIRM, CORPORATION, INCLUDING THE LABRIE DISTRIBUTOR, CAN BIND LABRIE TO ANY WARRANTY OTHER THAN THIS WARRANTY OR OTHERWISE MODIFY SAID WARRANTY.

Labrie reserves the right to redesign and/or discontinue the manufacture of parts, components, and Products.

This limited warranty may be transferred to subsequent end-users within fifteen (15) days of the Product transfer provided that Labrie is notified in writing within the said fifteen (15) day period.

8 Introduction

To Contact Labrie Plus

In the U.S.

Address: 1198 Shattuck Industrial Blvd.

LaFayette, GA 30728

Toll Free: 1-800-231-2771

Telephone: 1-920-233-2770

General Fax: 1-920-232-2496

Sales Fax: 1-920-232-2498

Parts and warranty: During business hours, 8:00 AM to 6:00 PM Eastern Standard Time

Technical Support Service: Available 24 hours

In Canada

Address: 175A Route Marie-Victorin

Toll Free: 1-877-831-8250

Telephone: 1-418-831-8250

Service Fax: 1-418-831-1673

Parts Fax: 1-418-831-7561

Parts and warranty: During business hours, 8:00 AM to 5:00 PM Eastern Standard Time

Technical Support Service: Available 24 hours

Website: www.labriegroup.com

E-mail (Sales Dept.): sales@labriegroup.com

E-mail (Customer Service): service@labriegroup.com

Levis, QC G7A 2T3

IMPORTANT: For technical support and parts ordering, the serial number of your vehicle is required. Therefore,

Labrie Enviroquip Group recommends to keep record of the information found on the VIN plate,

which is located in the cab.

Safety

Safety is always of prime importance when operating any type of equipment. All operators working with the

2R-III features detailed in this section.

must be aware of the safety practices and

NOTE: This section also applies to AUTOMIZER

equipped with the optional bucket instead of the gripper assembly.

Conventions

Danger!

Warning!

Caution!

Indicates a hazardous situation which, if not avoided, will result in serious injury or death.

Indicates a hazardous situation which, if not avoided, could result in serious injury or death.

Indicates a hazardous situation which, if not avoided, may result in minor or

moderate injury.

units

Basic Safety Notions

The following safety notions are related to the use of the 2R-III use of the vehicle remains the user’s responsibility. He must heed all safety notions described in this manual and on the decals affixed to the vehicle.

. It is important to point out that the safe

10 Safety

Danger!

Always be aware of the vehicle’s surroundings to make sure that no pedestrians, passersby, bystanders, or other people or vehicles are in any way exposed to any danger caused by the use of the 2R-III

Never get in the hopper area when the engine is running. Only authorized personnel may do so following a lockout/tagout procedure (see Locking Out and Tagging Out the Vehicle on page 43).

Responsibilities

Safety is everybody’s responsibility. Both employer and employee must play their part to ensure the safety of the operator, the vehicle, and its immediate surroundings.

Employer Responsibilities

It is the responsibility of the employer:

 To ensure that the 2R-III

including all applicable regulations, the Occupational Safety and Health Act (

American National Standards Institute (  To ensure that employees are qualified for operating the vehicle and its equipment, and that they

all take safety measures before using them.  To properly maintain all mobile equipment to meet all provincial/state and federal safety

standards.  To provide all employees – both operators and maintenance personnel – with proper training that

includes safe vehicle operation procedures and ensure that those procedures are monitored on a

continuous basis.  To keep the vehicle maintained and properly adjusted to meet the manufacturer’s standards and

recommendations. For help or for more information, please contact the manufacturer or any of its

authorized representatives.  To keep records of all vehicle breakdowns and malfunctions as well as any inspection and

maintenance.  To ensure that all failures or malfunctions that may be affecting the safe use of the vehicle are

repaired before the vehicle is put back into service.

 To meet the appropriate lighting requirements for night shift work (if permitted).  To regularly accompany the vehicle operator and take measures to ensure the smooth and safe

operation of the vehicle.

 To make sure that the backup alarm works properly when the vehicle is in reverse.  To take necessary measures in case of report of damage or malfunction made by an employee.

is operated in accordance with all safety requirements and codes,

ANSI).

OSHA), and the

Safety 11

 To establish a “lockout/tagout” procedure and ensure its application any time inspection, repair

or maintenance is performed on the vehicle, regardless of whether it takes place on the road or in the garage.

 To provide necessary safety equipment and apparel.  To ensure that all vehicle safety features, such as tailgate props, are properly used by all personnel

when operating or servicing the vehicle.

IMPORTANT: Do not allow operation of the 2R-III

immediately.

Employee Responsibilities

It is the responsibility of the employee:

 To enforce all safety measures to meet the requirements established by the employer.  To operate the 2R-III  To carefully read this manual.  To ensure, prior to and during operation of equipment, the following:

• During all phases of dumping or packing process, area is clear of persons, including time when tailgate is open and/or closed. Operator is to instruct persons tailgate.

• Manufacturer’s recommended operating and safety instructions are taken into account.

 To use the vehicle only as intended.  To obey proper operating procedures, safety guidelines and warning decals.  To perform a daily vehicle inspection that includes all operating systems, all vehicle safety

equipment (parking brake, lights, back-up alarm, horns, tires, safety interlock switches, etc.) and safety decals.

 To immediately report any malfunction or damage to the vehicle to the employer or supervisor.

only after having received instruction and training.

if damaged or malfunctioning. Have all repairs performed

NOT to cross under an open

IMPORTANT: Under no circumstances should you operate damaged or malfunctioning equipment. Report all

malfunctions to your supervisor immediately.

 To ensure that all mirrors, windows and lights are clean and properly adjusted prior to operating

the vehicle.

 To ensure that all cameras and monitors, if installed, are properly adjusted and function correctly.  To make sure that nobody is near the vehicle before activating any of the controls, and to be

prepared to stop at any indication of possible danger.

 To use extreme caution when operating machine in dangerous areas such as: slopes, overhangs,

high walls, ridges or ditches.

 To always utilize the vehicle’s safety features, such as tailgate props.  To wear all safety equipment prescribed by your employer.

IMPORTANT: Safety is always of prime importance when operating any type of equipment. All operators working

with the 2R-III

must be aware of the safety practices and features detailed in this section.

12 Safety

IMPORTANT: Do not use damaged equipment.

NOTE: This section also applies to AUTOMIZER

the gripper assembly.

units equipped with the optional bucket instead of

Things to Do

 Inspect the body and all systems at the beginning of each day.  Make sure that the area is clear of people or obstructions.

IMPORTANT: Be extremely cautious in areas where small children may be present.

 Wear safety glasses and footwear, gloves, and any other safety equipment when loading and

packing refuse.

 Check if mirrors, windows, lights, and monitor equipment are clean and properly adjusted.  Check for explosive trash (e.g. television sets, paint cans, fluorescent light tubes, etc.).  Use caution when driving with an unevenly distributed load.  Inspect for overhead hazards (e.g. power lines) prior to hoisting the body or climbing on it.  Always use the body safety prop when servicing under the body.  Always use the tailgate safety prop before entering the area between the main body and the

tailgate.

 Obey all warning and operation stickers.  Make sure all safety interlock systems are functioning properly.  Keep hands, floors, and controls free from water, grease, and mud to assure non-slip control.  Listen for strange or above normal sounds when machine is being moved or operated. Shut down

machine when safe to do and report problems to your supervisor.

Things to Avoid

 Do not operate any vehicle while under the influence of alcohol, narcotics or other intoxicants.  Do not talk on a cell phone or listen to loud music while driving.  Do not wear jewelry or loose clothing.  Do not leave the vehicle before it is brought to a complete stop and work brake or parking brake is

applied.

 Do not enter the hopper or main body unless the engine is shut off, the key is removed and there is

an out-of-service tag on the steering wheel (see Locking Out and Tagging Out the Vehicle on page 43).

 Do not hoist the body on uneven ground.  Do not back up the vehicle when the body is raised.  Do not drive with the tailgate fully open unless it is to unload refuse at the landfill.

 Do not use the body safety prop to prop a loaded body.

Safety 13

Warning!

Prior to its first use, your 2R-III sticker located on the body curbside, near the hopper. Initial lubrication carried out by Labrie Enviroquip Group is sufficient for production and transport purposes only.

General Precautions

Danger!

It is the employer’s responsibility to ensure that only qualified employees operate this vehicle.

 Read and make sure that you fully understand this manual and all safety decals before operating

this vehicle. Maintenance personnel must also read and understand the Maintenance Manual for this vehicle. In case of doubt, ask a supervisor for clarifications.

 Before every work day, inspect the body, the packing system, and any system that might

compromise public and/or operator safety.

 Verify that the accelerator pedal, the steering wheel, mirrors, brakes, and turn signals are in good

working order.

 When driving the vehicle, keep both hands on the steering wheel at all times.  Stop the vehicle completely and put on the parking brake before leaving the driving position.  When the vehicle is parked, the parking brake must be applied.  Before activating the automated arm, operators shall make sure that people and obstructions are

far away from the vehicle. Operators must be able to stop the arm at all times.

 Before activating the bucket (on units equipped with the optional bucket), operators shall make

sure that people and obstructions are far away from the vehicle. Operators must be able to stop the bucket at all times.

 2R-III

Enviroquip Group customers elect to operate the vehicle with more than one worker, additional safety items shall be installed to protect the co-worker from hazardous situations.

Operators must adhere to the following precautions at all times. Failure to do so may result in vehicle and/or property damage, personal injury, or even death.

vehicles are primarily designed to be operated by only one person. However, if Labrie

must be completely lubricated, as shown on the Lube Chart

IMPORTANT: In such cases, Labrie Enviroquip Group must be informed of every and all units that will be operated

by more than one worker. Labrie Enviroquip Group will then determine and supply, at the customer’s expense, the required safety items. For additional information, please contact LabriePlus at 1-877-831-8250 in Canada or 1-800-231-2771 in the U.S.

 Do not operate this vehicle if there are any signs of damage or incomplete repairs.  Report any doubts that you might have and any safety service requirements regarding this vehicle

to a supervisor.

14 Safety

 When removing nylon locknuts, always replace them by new ones.  Never drive this vehicle with the tailgate unlocked.  Once you have completed your collection route, park the gripper or the bucket inside the hopper.

Generally speaking, when in transport mode, always park the gripper or the bucket inside the hopper.

NOTE: The bucket must be in the DOWN position or parked alongside the body when:

(a) - the truck is parked in the garage or yard at the end of work day; (b) - the truck is parked for the night or the weekend; (c) - the truck is being repaired or serviced; (d) - the truck is on a waste collecting route. The bucket must be in the

UP position or parked in the hopper when: (a) - the truck is travelling on highways; (b) - the truck is in transit between two collecting areas; (c) - the truck is stopped for a lengthy period of time during worktime. (d) - the truck is travelling and not collecting

 For any work (including cleaning and inspection) that has to be done between the body and the

chassis, always use the body safety prop. Also, the vehicle must be parked on level ground.

 Before opening and closing the tailgate and/or raising the body, make sure that there is no one

behind the vehicle.

 Do not get into the hopper compartment or try to repair anything behind the packer when it is

moving or when the hydraulic pump is still running. Personnel authorized to get into the hopper

must first lock out and tag out the vehicle, as required by the employer. For more information, see Locking Out and Tagging Out the Vehicle on page 43.

 Never stand near or underneath a raised arm or gripper/bucket even if the arm cylinder is

equipped with a holding valve.

 Never, under any circumstances (maintenance or otherwise), stand underneath a loaded body.

Warning!

Do not operate the automated arm until you have been fully trained, and have read and understood the Operator and Maintenance Manuals supplied with this unit.

Make sure that all people and obstructions are sufficiently cleared from the automated arm before moving it. Failure to do so may result in unit and/or property damages, personal injury or death.

Make sure there is enough clearance between raised container and overhead power lines. The automated arm or the container must not come in direct contact with the electrical cables for the power to go through the unit. If the unit comes in contact with a power line, stay in the cab and keep away from any metal parts.

Safety 15

Danger!

Warning!

Fire

Never drive this vehicle if the lifting arm is not fully retracted to its home position. The unit would be simply too wide to be driven safely. Failure to fully retract the arm will result in unit and /or property damage, severe injury or even death. Warning red lights on dashboard flash when the arm is not completely retracted to its home position. units equipped with a bucket, the arm cannot be extended with the joystick. However, if for any reason, the arm is somewhat extended due to bumpy roads for example, just retract it tight against the bucket stopper by moving the joystick sideways to the left.

Remove all control levers from the proportional valve. These control levers should be used for maintenance purposes only.

Units with two driving positions: Prior to changing driving position, stop the vehicle, apply the parking brake, push the emergency button and stop the engine. Properly adjust mirrors and set driving control switches including arm control joystick (if applicable) to the new driving position before starting the engine. This will ensure that the automated arm is completely inoperative.

NOTE: On

The employer must inform and train all personnel on the measures that must be taken in case of a vehicle and/or loaded body catching fire.

Anytime a loaded vehicle is brought inside a garage, fire extinguishers shall be close at hand.

The employer must also inform employees of an appropriate place to unload the body near the maintenance facility (preferably away from traffic, surface drains, and ditches).

2R-III fire extinguisher may also be installed as an option. Each fire extinguisher must be checked regularly by qualified personnel.

Figure 2-1

vehicles are equipped with a 5-lb fire extinguisher, which is located inside the cab. A 20-lb

20-lb fire extinguisher (left); 5-lb fire extinguisher (right)

Safety Kits

A first aid kit and a triangle kit are provided with the truck.

16 Safety

Location of Safety and Informative Decals

Pay careful attention to all safety, warning and informative decals while working in and around the

2R-III call LabriePlus. Decals may vary from one unit to another depending on the options and features installed on the unit. The following is an illustrated list of decals, but not limited to.

Decals on Body

. Keep your decals clean and in good condition at all times. For replacement decals, please

84459 84458 - English/French

47304 120989 - English/Spanish

79846 - English/French

47312 84011 - English/Spanish

84010 - English/French

47260 120977 - English/Spanish

79833 - English/French

Safety 17

84470 84469 - English/French

47262

120978 - English/Spanish 79834 - English/French

84468 84467 - English/French

47270 120981 - English/Spanish

79837 - English/French

18 Safety

47280 120982 - English/Spanish

79841 - English/French

47286 84054 - English/Spanish

79844 - English/French

47282 120983 - English/Spanish

79842 - English/French

47308

84059 - English/Spanish 79847 - English/French

47314 84060 - English/Spanish

79848 - English/French

47348 84015 - English/Spanish

84014 - English/French

Safety 19

47350

84072 - English/Spanish 79850 - English/French

47422

121033 - English/Spanish 79853 - English/French

47352 84073 - English/Spanish

79851 - English/French

47424 84077 - English/Spanish

79854 - English/French

47554 79768 - English/Spanish

79856 - English/French

47562 47795 - English/Spanish

79776 - English/French

20 Safety

84187 84485 - English/French/Spanish

79781 79782 - English/Spanish

84099 - English/French

47564 47256

32411 Optional

84321 159775 - English/Spanish

84322 - French

84419 - Spanish 159761 - French

Optional

121349 121350 - French

Safety 21

97832 84447 - Spanish

159759 - French Optional

84482

22 Safety

47843 47844 - French

Safety 23

84272 159782 - Spanish

84336 - French

24 Safety

Decals on Tailgate

32307

47266 120973 - English/Spanish

79835 - English/French

32414A 84418 - Spanish

47268

120974 - English/Spanish 79836 - English/French

Optional

159760 - French

47274

47777 - English/Spanish 79839 - English/French

Optional

Decals outside Cab

Safety 25

43816 84040 - English/Spanish

79865 - English/French

47352 84073 - English/Spanish

79851 - English/French

47350

84072 - English/Spanish 79850 - English/French

47286

84054 - English/Spanish 79844 - English/French

26 Safety

Decals inside Cab

43874

159751 - English/Spanish 79826 - English/French

47312

84011 - English/Spanish 84010 - English/French

43880 47770 - English/Spanish

79828 - English/French

43790

84304 - English/Spanish 79818 - English/French

47451

84497 - English/Spanish 84026 - English/French

47276

84303 - English/Spanish 79840 - English/French

47440 84078 - English/Spanish

79855 - English/French

156067

159813 - English/French

156066

159812 - English/French

Safety 27

43882

84491 - English/Spanish 84009 - English/French

43764

84025 - English/Spanish 84024 - English/French

47877 159776 - English/Spanish

84030 - English/French

47878

Optional

156068

159814 - English/French

159777 - English/Spanish 84029 - English/French

Optional

84189 84188 - English/French

47610

84021 - English/Spanish 84020 - English/French

28 Safety

43850 84001 - English/Spanish

79822 - English/French

159766 159767 - French

169407 - English/French

104539

43910 84013 - English/Spanish

84012 - English/French

84032 - English/Spanish 84031 - English/French

Safety 29

47284

120980 - English/Spanish 79843 - English/French

43764_R4

43972

84148 - English/Spanish 79831 - English/French

43794

84147 - English/Spanish 79819 - English/French

43798

79821 - English/French

43856

79823 - English/French

30 Safety

47998 84018 - English/French

47600 47601 - French

97755 159771 - English/Spanish

97777 - English/French

47981 159773 - English/Spanish

79914 - French

84406 84407 - French

84373 84372 - English/French

43792 84023 - English/Spanish

84022 - English/French

Safety 31

Multiplexed Switch Actuators

NOTE: Multiplexed switch actuators and their location on the control panel vary according to the

options installed on the unit.

32 Safety

Multiplexed Indicator Tops

NOTE: This illustration and the preceding one were taken from the PDF file no 159535.

NOTE: 1- All symbols to be negative lens.

2- Electronic file for the symbols available on request from Labrie Enviroquip Group only.

Safety Features

Back Up Alarm

The back up alarm sounds when the truck is in reverse or when the tailgate is open.

Body Safety Prop

Safety props ensure that heavy body parts will not move inadvertently.

Setting the Body Safety Prop

The body safety prop ensures that an empty body will not lower when you are working underneath it.

Danger!

Figure 2-2

Body safety prop

Always set the body safety prop when performing maintenance underneath a raised body. Failure to do so may result in severe injury, or even death.

To set the body safety prop:

1. Make sure that there is enough clearance above the body to raise it safely.

2. Start the engine.

3. Raise the body until the safety prop is free to tilt under it.

4. Release the safety prop using the safety prop handle and position it adequately.

Safety 33

Figure 2-3

5. Lower the body until it rests on the safety prop.

6. Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 43).

You can now work safely underneath the body.

Putting the Body Safety Prop Back in Place

To put the body safety prop back in place:

Safety prop handle

1. Make sure that there is enough clearance above the body to raise it safely.

2. Start the engine.

3. Raise the body until the safety prop can move freely.

4. Put the safety prop back in its place.

5. Lower the body.

Tailgate Safety Prop

The tailgate safety prop is used to support and keep the tailgate open during inspection or maintenance procedures. It is mandatory to set the safety prop every time the tailgate is open for such purposes.

IMPORTANT: Make sure that the body is empty before installing the safety prop.

34 Safety

Danger!

Setting the Tailgate Safety Prop

To set the tailgate safety prop:

1. Make sure that the body is empty.

2. Remove the safety pins.

Figure 2-4

The tailgate safety prop shall be set each time the tailgate is open for inspection and maintenance purposes.

Safety pin

3. Start the engine.

4. Turn the pump ON (see Hydraulic Pump Switch on page 70).

5. With the Tailgate Up switch on the in-cab control panel (see Tailgate Up Switch on page 71),

raise the tailgate about 3 feet (enough to raise the safety prop).

Danger!

6. Pull the safety prop upward and set it down (see Figure 2-5).

Prior to raising the tailgate, make sure that no one is standing behind the vehicle and that the body is empty.

Safety 35

Figure 2-5

7. Lower the tailgate onto the safety prop using the Tailgate Down switch (see Tailgate Down

Putting the Tailgate Safety Prop Back in Place

To put the tailgate safety prop back in its home position:

1. Start the engine.

2. Turn the pump ON (see Hydraulic Pump Switch on page 70).

3. Raise the tailgate by about 3 feet (see Tailgate Up Switch on page 71).

4. Raise the tailgate safety prop (see Figure 2-6).

Pulling the safety prop upward (left) and setting it down (right)

Switch on page 71).

Figure 2-6

5. Release your grip on the safety prop to set it in its home position.

Raising the tailgate safety prop

36 Safety

Figure 2-7

6. With the Tailgate Down switch on the in-cab control panel (see Tailgate Down Switch on

7. Put the safety pins back in place.

Setting the safety prop in its home position

page 71), fully close and lock the tailgate. The

TAILGATE OPEN message on the monitor should disappear.

Camera System (optional)

2R-III where they can be installed on the truck: inside the hopper (Figure 2-8, left), on the central righthand side post (Figure 2-9), on the tailgate (Figure 2-8, right), and on the left-hand side mirror.

Figure 2-8

units can be equipped with up to four (4) cameras. The following are examples of location

Camera inside hopper (left) and on tailgate (right)

Safety 37

Figure 2-9

Camera on central RHS post

The operator can switch from one camera to the other using a selector switch located on the 7” LCD color monitor installed in the cab.

Refer to the camera manufacturer’s manual for more information.

NOTE: On some units, the right-hand side camera may be installed on the right-hand side rail instead

of on the central right-hand side post at the rear of the hopper.

Tailgate Holding Valve

Located behind the left rubrail panel near the tailgate, this holding valve ensures that the tailgate will not open during the packing cycle.

Safety Lockout Tests

The safety lockout tests are part of your daily inspection. Successful completion of these tests ensures that your unit is safe to operate. If any of these tests fail, do not operate your unit until the appropriate adjustment or service has been completed.

IMPORTANT: Your 2R-III

your supervisor and/or maintenance department if you have questions or you are in doubt.

unit may be equipped with other safety lockout options not mentioned herein. Consult

38 Safety

Hopper Door Proximity Switch Test

Successful completion of this test ensures that the Hopper Door proximity switch is working properly (see Figure 2-10). If the hopper door is open, all hydraulic functions should become inoperative.

Warning!

Figure 2-10

Hopper Door proximity switch

For this test, proceed as follows:

1. Open the hopper door.

To do so, just slide the spring-loaded latch to the left and pull open the door (see Figure 2-11).

Injury or death may occur if you attempt to enter the body while the packer blade or arm is working.

Figure 2-11

2. Ensure that the warning message “Pump: Hopper Door Not Closed” appears on the multiplexed

3. Verify that the hydraulic system has been rendered inoperative by activating one of the control

Spring-loaded latch

monitor screen (see Figure 3-1) and that both Pump button and Hopper Door Open indicator on the control panel are flashing red.

buttons, such as the Tailgate Up button on the control panel.

4. If the hydraulic system is still operative, the Hopper Door proximity switch may need to be

adjusted or replaced. Refer to the Limit and Proximity Switches section in the Maintenance Manual for proper procedure.

Arm Fully Retracted Limit Switch Test

Successful completion of this test ensures that the Arm Extended warning lights on the dashboard flash red when the arm is moved away from its parked position.

Safety 39

Warning!

For this test, proceed as follows:

1. Park the vehicle on safe, level ground.

You should have sufficient room to drive approximately 100 yards (92 m) forward.

2. Extend the arm a few inches.

3. Check that the Arm Extended warning lights on the dashboard (see Figure 3-30) flash red.

4. Drive the vehicle forward and increase engine speed to over 1,000 RPM.

5. Check that the buzzer sounds and the warning message “Arm not Stowed” appears on the

monitor screen.

6. Stop the vehicle and retract the arm to its “home” position. The “Arm Not Stowed” message on

the monitor screen should disappear and the warning lights should turn off. The buzzer should also stop sounding.

7. If the Arm Extended warning lights on the dashboard do not flash red or the “Arm Not Stowed”

message does not appear on the monitor screen when the arm is extended and the vehicle engine exceeds 1,000 RPM, the Arm Fully Retracted limit switch (see Figure 2-12) may need to be adjusted or replaced. Refer to the Limit and Proximity Switches section in the Maintenance Manual.

Never drive the vehicle if the automated arm is not parked alongside the truck. The vehicle would be too high and/or too wide to be driven safely. Failure to fully retract the arm could result in unit and/or property damage, personal injury or even death. Warning lights on the dashboard flash red when the arm is extended. arm cannot be extended with the joystick. However, if for any reason, the arm is somewhat extended due to bumpy roads for example, just retract it tight against the bucket stopper by moving the joystick sideways to the left.

NOTE: On units equipped with a bucket, the

IMPORTANT: Do not operate the 2R-III

may occur.

with an inoperative or malfunctioning arm limit switch. Injury or death

NOTE: On units with a bucket, the arm cannot be extended. If the bucket is down against the bucket

stopper and the truck is rolling faster than 25 km/h, the in-cab buzzer will sound. In such a situation, the operator has to pull over in a safe and convenient location and raise the bucket until it is safely parked inside the hopper.

40 Safety

Figure 2-12

Arm Fully Retracted limit switch

Packer Fully Retracted Proximity Switch Test

Successful completion of this test ensures that the packer reaches its “home” position or the packer cylinder does not remain pressured up or abruptly bottom out at the “home” position.

For this test, proceed as follows:

1. Empty all refuse from the body.

2. Start a pack cycle.

3. Observe the “home” position of the packer when the cycle is complete.

4. If the packer stops before reaching the “home” position or the packer cylinder remains pressured

up or abruptly bottoms out at the “home” position, the Packer Fully Retracted proximity switch (see Figure 2-13) may need to be adjusted or replaced. Refer to the Limit and Proximity Switches section in the Maintenance Manual.

NOTE: Packer must reach its home position for the crusher panel to be operative (if equipped).

Figure 2-13

Packer proximity switches

Packer fully retracted

proximity switch

Packer fully extended

proximity switch

Safety 41

Crusher Panel Up Proximity Switch Test (if equipped)

NOTE: This test only applies to units equipped with a lifting bucket.

Successful completion of this test ensures that the bucket operation is disabled when the crusher panel is not in its stowed position.

For this test, proceed as follows:

1. Start the truck.

2. Engage the hydraulic pump (see Hydraulic Pump Switch on page 70).

3. If it is not already done, fully lower the bucket.

4. Lower the crusher panel using the auxiliary packer control station (see Auxiliary Packer Control

Station on page 75).

5. Try to raise the bucket with the bucket control button on the auxiliary packer control station.

NOTE: If you use the joystick to raise the bucket, the simple press on the deadman switch (see Figure

3-27) will cause the crusher panel to rise.

6. If the bucket tilts beyond 45° against its stowed position while the crusher panel is down, the

Crusher Panel Up proximity switch (see Figure 2-14) may need to be adjusted or replaced. Refer to the Limit and Proximity Switches section in the Maintenance Manual.

Figure 2-14

Crusher panel up proximity switch

Arm Parked Limit Switch Test

Successful completion of this test ensures that the crusher panel (if equipped) will not move when the gripper/bucket is parked in the hopper.

For this test, proceed as follows:

1. Start the truck.

42 Safety

2. Engage the hydraulic pump (see Hydraulic Pump Switch on page 70).

3. With the crusher panel in the up position and the gripper/bucket in the parked position inside

the hopper, try to lower the crusher panel. The crusher panel should not move.

4. If it does move while the gripper/bucket is in parked position inside the hopper, the arm parked

limit switch (see Figure 2-15) may need to be adjusted or replaced. Refer to the Limit and Proximity Switches section in the Maintenance Manual.

Figure 2-15

Arm parked limit switch

Quick Reference Lockout Chart

Hopper door open Pump circuit cut out - all controls

Arm not fully retracted Arm Extended warning lights flash

Packer not in “home” position Crusher panel (if equipped) disabled

inoperative

Crusher panel (if equipped) not in “home” position

Gripper/bucket parked in hopper

Cleanliness

Cleanliness is part of safety. Ensure that the equipment works properly by removing any compacted garbage in the packer area after each body unloading.

Clean all the lights and safety decals so you and the surrounding pedestrians and drivers will be aware of the truck at all times. Use the hoe to rake dirt out of clean-out traps on each side of the vehicle.

Arm controls disabled; bucket stops at mid-stroke position

Crusher panel (if equipped) disabled

Safety 43

Figure 2-16

Clean-out trap

Locking Out and Tagging Out the Vehicle

For any inspection, repair or general maintenance being done on the vehicle, whether on the road or at the shop, it is the employer’s responsibility to establish and see to the application of a proper lockout and tagout procedure.

To lock out and tag out an 2R-III

1. Park the vehicle on safe level ground, and apply the parking brake (see Figure 2-17).

vehicle:

Figure 2-17

Parking brake sign

2. Make sure that the body is completely unloaded.

3. Switch off the hydraulic pump.

4. Turn off the engine, remove the key from the ignition, store it in a safe and controlled area

(preferably on yourself), and tape over the ignition switch.

5. Turn off and lock the master switch.

6. Chock all wheels.

IMPORTANT: The battery set of the 2R-III

off.

is equipped with a master switch (see Figure 2-18) that must be turned

44 Safety

Figure 2-18

7. Put an “OFF SERVICE” tag on the driver’s wheel and on the front windshield.

8. Use safety props to block any system that could move by gravity (open tailgate, raised body, etc.).

9. Drain all air tanks.

10. Verify and inspect any security device and/or mechanism to make sure that there is no bypass

Master switch

and that they are all functional.

Shutting Down the Vehicle

If the vehicle has to be stored for an extended period of time, follow the chassis manufacturer’s shutdown and maintenance requirements.

Also:

1. Park the vehicle on a hard level surface, and apply the parking brake (see Figure 2-17).

2. Make sure that all moving parts are in their home position (tailgate, arm, hopper, packer, etc.).

3. Turn off, in sequence, the hydraulic pump (see Figure 2-21), the electrical system, the engine and

the master switch (see Figure 2-18).

4. Drain all air tanks (see Figure 2-19).

Figure 2-19

Drain valves on air tank (left) and water trap (right)

Manual drain

Automatic drain

Starting Up the Vehicle

Apply this procedure to start up your vehicle:

1. Make sure no system will engage and/or start to operate as you start the engine.

2. Make sure the shut-off valve on the hydraulic tank is fully open before starting the vehicle

(see Figure 2-20).

Safety 45

Figure 2-20

NOTE: The hydraulic tank model may vary according to the options installed.

Warning!

Suction line shut-off valve

Failure to fully open the main valve will cause immediate damage to the pump, even if the pump is turned off.

3. Start the engine according to the chassis manufacturer’s recommendations.

4. Once the engine is started, wait for air pressure to build up to at least 70 PSI.

5. Engage the hydraulic system by pressing the pump switch (see Figure 2-21).

The pump switch turns from blue to green.

Figure 2-21

Hydraulic pump switch

46 Safety

IMPORTANT: Do not operate or move the vehicle until air pressure has reached 70 PSI.

6. Turn ON all light switches.

7. If needed, report any defective system to the maintenance personnel.

Driving the Vehicle

The 2R-III The right-hand side steering wheel makes waste collection easier by a single person. It is provided along with an accelerator pedal, a foot brake pedal, a turn signal control and a horn. Before using the right-hand side driving position make sure that all controls are properly set.

Driving Speed

If the cab of the vehicle has been modified by Labrie Enviroquip Group (right-hand side driving position) for door-to-door waste collection, the maximum speed limit while driving at the right-hand side is, if permitted, 20 mph (32 km/h). Therefore, it is recommended to drive on the left-hand side for any long distance driving (if the truck is equipped with a left-hand side driving position).

may be equipped with two (2) steering wheels, one on the left and one on the right.

Figure 2-22

NOTE: If the cab has been modified by the chassis manufacturer, the operator MUST follow the

Cab modified by Labrie

Parking brake

chassis manufacturer’s recommendations.

Warning!

If the vehicle has to be parked for an extended period of time, always apply the parking brake (see Figure 2-22).

Safety 47

Right-Hand Side Driving Position

The following procedure applies ONLY to cabs that had been modified by Labrie Enviroquip Group. It must be followed at the beginning, but also at the end of the collection route in order to revert to the left-hand side driving position.

NOTE: This procedure applies only to vehicles that had been modified by Labrie Enviroquip Group

and that are equipped with dual driving position. Some units are designed only with a single driving position.

If the cab has been modified by the chassis manufacturer, the operator MUST ignore the following procedure and rather follow the chassis manufacturer’s recommendations.

Before using the right-hand side driving position, do the following:

1. Drive the vehicle to the beginning of the collection route with the left-hand side steering wheel.

2. Stop the vehicle and apply the parking brake.

3. Press the emergency stop button on the packer control station.

4. Turn off the engine.

5. Move to the right-hand side driving position.

6. Shift the driving position switch to the right (see Figure 2-23).

All the electrical accessories of the right-hand side driving position are then enabled.

Figure 2-23

7. Enable the right-hand side joystick by moving the joystick selector switch to the right (if

8. Adjust mirrors properly (see Figure 2-24).

Driving position switch

installed).

48 Safety

Figure 2-24

Adjusting mirrors

Controls and Indicators

The AUTOMIZER controls and indicators that allow easier operation of the different functions that come with the vehicle. These controls and indicators are mainly located on the in-cab control panel and on the dashboard.

Labrie’s Multiplexed System

Labrie has equipped your AUTOMIZER H

AND unit with a CAN bus-based multiplexed system,

which integrates a monitor, a control panel, a joystick, and a set of electronic modules. This whole system has been designed to help you operate your unit in an efficient and easy way. Labrie’s multiplexed system is reliable and safe, and it requires less wiring harnesses to operate. It can also monitor various function status of the body and display warning and caution messages.

Through its monitor (see Figure 3-1), Labrie’s multiplexed system informs you of any malfunctions that may occur during the operation of the truck. Various caution and warning messages can be displayed on the monitor, depending on the seriousness of the situation. Yellow-highlighted messages indicate that caution should be used while red-highlighted messages indicate a warning situation that must be dealt with quickly.

HELPING-HAND has a series of

HELPING-

Figure 3-1

Monitor

50 Controls and Indicators

Each time the operator turns the ignition key on, a complete bit test of the multiplexed system is conducted. This test takes about 5 seconds to complete.

NOTE: A flashing green light on the monitor indicates that the power is on. This light should be

blinking steadily at 2 Hz during normal operation. If it blinks at a faster rate, it is a sign of a problem with the monitor. A flashing red light on the monitor is also a sign of a problem. Call LabriePlus for support.

The logo of Labrie Enviroquip Group appears momentarily on the monitor screen at the start of the system (see Figure 3-2).

Figure 3-2

NOTE: If the Welcome Screen with the Labrie logo stays on continuously, there may be a

Labrie logo on the monitor screen

communication problem between the monitor and the master control module. Report this problem to the maintenance personnel.

NOTE: The monitor screen works even if the engine is not started. All it needs is electrical power.

However, if you start the engine, the monitor will reboot to reflect the changes caused by the starting of the truck.

Main Page

The next page that comes up after the Welcome Screen is the Main Page (see Figure 3-3). Here you will find a link that will give you access to the Main Menu (see Main Menu on page 57). Any warning or error messages that may occur while the truck is being operated are also displayed on this page. The following optional indicators, when provided, are also found on the Main Page : Cart Counter, Time and Date Indicator and Hydraulic Oil Temperature Indicator.

Cart Counter (optional)

This indicator tells you how many carts have been emptied so far. If your vehicle is equipped with two arms, the number of carts emptied is shown for each of these arms (right and left counters).

Controls and Indicators 51

Figure 3-3

Press the far right button to reset the counter display to zero.

Time and Date Indicator (optional)

A time and date indicator may be found on the upper left-hand side corner of the screen. The availability of this indicator is based on the chassis on which the body is mounted. If the chassis provides real-time clock information through J1939 bus, time and date will appear on the screen. To set the Time and Date indicator, go to the Main Menu and choose Time Adjust.

Hydraulic Oil Temperature Indicator (optional)

This optional indicator, when provided, shows you the current hydraulic oil temperature. This indicator is found on the upper right-hand side corner of the screen.

Cart counter

Warning and Caution Messages

On the monitor screen, yellow-highlighted messages indicate that caution should be used and redhighlighted messages indicate a warning situation that must be dealt with quickly.

Figure 3-4

See Table 1 for a list of warning and caution messages. Please note that this list is not exhaustive.

Warning and caution messages on monitor

52 Controls and Indicators

Table 1 Warning messages (cont’d)

Warning and Caution Messages Solution

Arm Up:Chute Bad Pos. Place Chute in Correct Position

Arm Up:Crusher Not Raised Raise Crusher Panel

Arm:Auxiliary Deadman ON Release Auxiliary Deadman

Arm:Body Raised Lower Body

Arm:Hopper Door Not Close Close Hopper Door

Arm:Pump Not Started Engage Pump

Arm:Tailgate Unlocked Lock Tailgate

AutoDump:Cab EStop Pull Out Cab EStop Button

AutoDump:Pump Not Started Engage Pump

Body:Pump Not Started Engage Pump

Buzzer:Arm Not Stow Retract Arm to Stowed Position

Buzzer:Body Raised Lower Body

Buzzer:TailGate Unlocked Lock Tailgate

Chute:Arm Too High Lower Arm

Chute:Crusher Not Up Raise Crusher

Chute:Pump Not Started Engage Pump

Crusher:Arm Too High Lower Arm

Crusher:Chute Bad Pos. Move Chute to Correct Position

Crusher:Hopper Door Not Closed Close Hopper Door

Crusher:Packer Not Retracted Retract Packer

Crusher:Pump Not Started Engage Pump

ESTOP:Aux. Cab EStop Pull Out Aux. Cab EStop Button

ESTOP:Cab Emergency Stop Pull Out Cab EStop Button

FullEject:Cab EStop Pull Out Cab EStop Button

FullEject:Packer Not Retracted Retract Packer

FullEject:Pump Not Started Engage Pump

Table 1 Warning messages (cont’d)

Warning and Caution Messages Solution

Gripper Open:Arm Too High Lower Arm

High Hydraulic Oil Temp. Turn Off Engine and Refer to your

Low Hydraulic Oil Add Hydraulic Oil

Packer Extend:Air Weigh Signal Unload Body

Packer:Already Extended Refer to Maintenance Personnel or

Packer:Already Retracted Refer to Maintenance Personnel or

Packer:Extend Too Long Check Extend Prox

Packer:Pump Not Started Engage Pump

Controls and Indicators 53

Maintenance Personnel

LabriePlus

Packer:Retract Too Long Check Retract Prox

Pump Not Started:Aux. Cab EStop Pull Out Aux. Cab EStop Button

Pump Not Started:Cab EStop Pull Out Cab EStop Button

Pump Not Started:Hopper Door Open Close Hopper Door

Pump Not Started:Main Air Pressure Let the Air Build Up to Required

Pressure

Pump Not Started:RPM Too High Lower Engine Speed Below

900 RPM

Pump Stop:Main Air Pressure Let Air Build Up to Req’d Pressure

Pump:Aux. AutoDump Switch ON Release Aux. AutoDump Switch

prior to Engaging Pump

Pump:Aux. ChuteToLeft Switch ON Release Aux. ChuteToLeft Switch

prior to Engaging Pump

Pump:Aux. ChuteToRight Switch ON Release Aux. ChuteToRight Switch

prior to Engaging Pump

Pump:Aux. CloseGripper Switch ON Release Aux. CloseGripper Switch

prior to Engaging Pump

Pump:Aux. Deadman Switch ON Release Aux. Deadman Switch prior

to Engaging Pump

Pump:Aux. OpenGripper Switch ON Release Aux. OpenGripper Switch

prior to Engaging Pump

54 Controls and Indicators

Table 1 Warning messages (cont’d)

Warning and Caution Messages Solution

Pump:BodyLower Switch ON Release BodyLower Switch prior to

Pump:BodyRaise Switch ON Release BodyRaiseSwitch prior to

Pump:CrusherDown Switch ON Release CrusherDown Switch prior

Pump:CrusherUp Switch ON Release CrusherUp Switch prior to

Pump:Hopper Door Not Close Close Open Door

Pump:J1 AutoDump Switch ON Release J1 AutoDump Switch prior

Engaging Pump

to Engaging Pump

Engaging Pump

to Engaging Pump

Pump:J1 ChuteToLeft Switch ON Release J1 ChuteToLeft Switch

prior to Engaging Pump

Pump:J1 ChuteToRight Switch ON Release J1 ChuteToRight Switch

prior to Engaging Pump

Pump:J1 CloseGripper Switch ON Release J1 CloseGripper Switch

prior to Engaging Pump

Pump:J1 Deadman Switch ON Release J1 Deadman Switch prior to

Engaging Pump

Pump:J1 OpenGripper Switch ON Release J1 OpenGripper Switch

prior to Engaging Pump

Pump:J2 AutoDump Switch ON Release J2 AutoDump Switch prior

to Engaging Pump

Pump:J2 ChuteToLeft Switch ON Release J2 ChuteToLeft Switch

prior to Engaging Pump

Pump:J2 ChuteToRight Switch ON Release J2 ChuteToRight Switch

prior to Engaging Pump

Pump:J2 CloseGripper Switch ON Release J2 CloseGripper Switch

prior to Engaging Pump

Pump:J2 Deadman Switch ON Release J2 Deadman Switch prior to

Engaging Pump

Pump:J2 OpenGripper Switch ON Release J2 OpenGripper Switch

prior to Engaging Pump

Table 1 Warning messages (cont’d)

Warning and Caution Messages Solution

Pump:Packer Extend Switch ON Release Packer Extend Switch prior

Pump:Packer Retract Switch ON Release Packer Retract Switch prior

Pump:PTO Not OK Refer to Maintenance Personnel or

Pump:RPM Too High Lower Engine Speed Below

Pump:TailgateDown Switch ON Release TailgateDown Switch prior

Pump:TailgateUp Switch ON Release TailgateUp Switch prior to

Controls and Indicators 55

to Engaging Pump

LabriePlus

900 RPM

to Engaging Pump

Engaging Pump

Pump:Trans. Not OK Refer to Maintenance Personnel or

LabriePlus

Raise Body:Air Susp. Not Down Lower Air Suspension

Raise Body:Arm Not Stow Retract Arm to Stowed Position

Raise Body:Tag Not Down Lower Tag

Raise Body:Tailgate Not Open Open Tailgate

Raise Body:Truck Moving Bring Truck to a Standstill

Service Oil Filter #1 Replace Oil Filter #1

Service Oil Filter #2 Replace Oil Filter #2

Tag:Move Tag switch to Tag Up Raise Tag

Tailgate Up:Truck Moving Bring Truck to a Standstill

Tailgate:Pump Not Started Engage Pump

Wrong Driver Position Change Driver Position Switch to

Correct Position

56 Controls and Indicators

Table 2 Error messages (cont’d)

Button Pack 12 is disconnected Refer to Maintenance

Button Pack 13 is disconnected Refer to Maintenance

Button Pack 14 is disconnected Refer to Maintenance

Button Pack 15 is disconnected Refer to Maintenance

CAN Error Level 1 Refer to LabriePlus

CAN Error Level 2 Refer to LabriePlus

Error Messages Solution

Personnel or LabriePlus

CAN Error Level 3 Refer to LabriePlus

Comm. Lost with Master Refer to Maintenance

Personnel or LabriePlus

Module 11 is disconnected Refer to Maintenance

Personnel or LabriePlus

Module 11 not Connected Refer to Maintenance

Personnel or LabriePlus

Module 20 is disconnected Refer to Maintenance

Personnel or LabriePlus

Module 20 not Connected Refer to Maintenance

Personnel or LabriePlus

Module 30 is disconnected Refer to Maintenance

Personnel or LabriePlus

Module 30 not Connected Refer to Maintenance

Personnel or LabriePlus

Module 50 is disconnected Refer to Maintenance

Personnel or LabriePlus

Table 2 Error messages (cont’d)

Error Messages Solution

Module 50 not Connected Refer to Maintenance

Module 60 is disconnected Refer to Maintenance

Module 60 not Connected Refer to Maintenance

Should the system issue a warning or caution message, it will appear on the Main Page.

For example, if the following caution message “Pump Not Started: Main Air Pressure” is issued by the system, it will appear on the Main Page of the monitor. An action that could be taken by the operator, when faced with such a situation, would be to wait until the required main air pressure level is reached.

For a specific problem or condition that requires special attention, the multiplexed system can alert the operator to a possible cause, which appears in bold and large print on the monitor screen (active cause). The operator should check if the problem stems from the highlighted or active cause. One possible cause is highlighted at a time. What is shown in light and small print in the lower part of the screen are causes that have already been dealt with (non active causes) [see Figure 3-5].

Controls and Indicators 57

Personnel or LabriePlus

Figure 3-5

NOTE: If the system detects a problem, a beep will sound and a message will appear on the monitor

Example of a possible cause

screen.

NOTE: To go back to the Main Page or Main Menu, press “Esc” as needed until the desired page is

displayed.

Main Menu

To access the Main Menu, press the far left button when the Main Page is displayed.

58 Controls and Indicators

When the Main Menu is displayed, you can have access to the following sections:

 Multicycle  I/O Status  Program Version  Pump Usage (optional)  Time Adjust (available according to chassis)

Displayed in the lower center of the screen is an indicator that monitors traffic on the network. This indicator is called Network Load, and it shows values that reflect such traffic.

NOTE: The higher the network load value is, the heavier the traffic is on the network.

To exit this page and return to the Main Page, press “Esc”. To choose a section from the Main Menu, highlight the desired section using the up/down arrows and press the “OK” button.

Multicycle

The monitor used in Labrie’s multiplexed system is user-friendly. Say you want to change the multicycle settings of the packer. All you have to do is select

MAIN MENU by pressing the

corresponding button at the bottom left corner of the monitor. From the displayed menu, choose the option

SELECT THE NUMBER OF CYCLES. If need be, use the arrow to choose that option and press

“OK”. The multicycle settings can be changed from two to eight cycles. Choose the desired number of cycles and press “OK”. It could not be easier!

Figure 3-6

Multicycle page

NOTE: The packer multicycle function has been preset at the factory to carry out three cycles.

When the

MULTICYCLE switch on the control panel is on and the packer is activated, the packer will

move according to the default number of cycles (that is 3) or to the number of cycles you chose (up to 8 cycles).

Controls and Indicators 59

Figure 3-7

To test the new settings of the packer:

1. On the control panel press the MULTICYCLE switch and the green START CYCLE button.

2. Once the packer has completed its cycles and come to a stop, switch OFF the hydraulic pump

The number of cycles needs to be adjusted depending on the type of collection route used by the vehicle. For example, in a residential area, if the houses are numerous and close one to another, it may be required to increase the number of cycles. This will allow the hopper to be clear for the next house pickup.

Control panel

Multicycle switch

and turn OFF the engine.

Start cycle button

Pump switch

Each time the packer completes a full cycle, the proximity switch located on the right-hand side, behind the packer, sends a signal to the electronic controller. The controller then counts the amount of cycles that the packer does, and will stop the packer after the preset amount of cycles has been reached.

I/O Status

In this section, you will find helpful information to troubleshoot body-related problems that you may face during your day-to-day tasks. These problems can be of any nature, from hydraulic to mechanical, electrical or pneumatic.

Select the control module corresponding to the part of the truck that needs to be checked.

For example, if you want to check all functions that are found in the cab, choose module #10. For all functions that pertain to the chassis, choose module #20, etc.

To choose a particular module, use the up/down arrows to select it and press “OK”.

NOTE: Pressing “OK” can be done two ways: either press the far right button or the “OK” button.

Press “Esc” to return to the preceding page.

60 Controls and Indicators

Figure 3-8

Input Status

The Input Status page is accessible from the Module I/O Status page. After selecting the desired module and pressing “OK”, the Input Status page of the selected module is displayed (see Figure 3-9).

Figure 3-9

Module I/O Status page

Input Status page

The Input Status page contains a set of rectangles. Each of these rectangles represents input elements, which in turn correspond to a particular function of the truck. For example, if you select rectangle I00, a short description appears in the lower part of the screen, which indicates that this rectangle relates to the input element coming from the service brake pressure switch.

NOTE: Each rectangle is numbered and relates to a specific function of the truck. However, for a given

number, the related function may vary from truck to truck.

Table 3 Colored rectangles

Rectangles

(inputs)

Function Status

Blue Inactive

Green Active

Press “Esc” to return to the preceding page.

Press the “Output” button to display the Output Status page.

Output Status

The Output Status page (Figure 3-10) is accessible from the Input Status page.

Controls and Indicators 61

Figure 3-10

Output Status page

The rectangles on this page are used to check the status of different outputs.

NOTE: Each rectangle is numbered and relates to a specific function of the truck. However, for a given

number, the related function may vary from truck to truck.

Table 4 Colored rectangles

Rectangles

(outputs)

Function Status

Blue Inactive

Green Active

Red Closed short-circuit

Yellow Open circuit

Press “Esc” to return to the preceding page.

Press the “Force” button to display the Force page.

NOTE: To go back to the Main Page or Main Menu, press “Esc” as needed until the desired page is

displayed.

Force

The Force page is accessible from the Output Status page. Just press the corresponding button to access the Force page.

62 Controls and Indicators

But before the Force page is displayed, a warning message appears on the monitor screen (see Figure 3-11).

Figure 3-11

Warning message

This message stays on for 15 seconds. Then an “OK” prompt appears on the lower right-end corner of the screen.

IMPORTANT: It is very important to read this message entirely before accessing the next page.

Figure 3-12

Warning message w/ “OK” prompt

Press “OK” to go to the Force page or “Esc” to return to the preceding page.

After pressing “OK”, the Force page appears on the screen.

Controls and Indicators 63

Figure 3-13

As no input function can be forced to be active or inactive, the operator must press the “Output” button to go to the following page (see Figure 3-14).

Figure 3-14

Force page (input)

Force page (output)

The Force page allows the operator to force a function to be overridden, that is, to make an inactive function active and an active function inactive.

This page contains a set of rectangles. Each of these rectangles is numbered and corresponds to a specific function of the truck.

Colors are used to indicate whether the corresponding function is active or not:

 a blue rectangle means the corresponding function is inactive  a green rectangle means the corresponding function is active

Also:

 a red rectangle means there is a closed short-circuit  a yellow rectangle means there is an open circuit

A white-bordered rectangle means that this rectangle is selected. Use the directional arrows to select a specific rectangle or function. When a rectangle is selected, a short description of the corresponding function appears at the bottom of the screen.

After selecting a rectangle:

 press “ON” to activate the corresponding function (rectangle turns from blue to green)

64 Controls and Indicators

 press “OFF” to deactivate the corresponding function (rectangle turns from green to blue)  press “RESET” to have the software control the status of the corresponding function

NOTE: To cancel changes made in this page and restore the default values, all you have to do is cut

power to the multiplexed system by turning the ignition key off.

NOTE: To go from a module to another (e.g. from module 10 to 20), the operator has to go back to the

Module I/O Status page (see Figure 3-8) and select module 20.

Press “Esc” to return to the preceding page.

Joystick

The Joystick page is accessible from the Module I/O Status page (see Figure 3-8). From that page select “Joystick” using up/down arrows and press “OK”. The Joystick page opens (see Figure 3-15).

Figure 3-15

The Joystick page allows the operator to check if all functions of the joystick are working correctly. If one joystick is installed on your vehicle, it will be represented on the monitor screen by joystick 127. However, if two joysticks are installed on your vehicle, any of the two joystick numbers (127 and 72) can represent either joystick on the screen.

If you press a joystick button, the corresponding button on the monitor will turn green. If nothing happens, there may be a communication problem between the joystick and the master control module. Refer to the maintenance personnel or LabriePlus.

Also, if you move the joystick backwards, forwards or sideways, you should see the values under the illustration changing. If no change occurs when moving the joystick, a communication problem between the joystick and the master control module may be the cause. Refer to the maintenance personnel or LabriePlus.

Joystick page

Press “Esc” to return to the preceding page.

J1939

The J1939 page is useful when you need some specific information (e.g. current gear, road speed, brake status).

Controls and Indicators 65

Figure 3-16

Your vehicle is equipped with 2 different CAN-based communication buses:

 the J1939 bus, which is used for the chassis equipment; and  the CANopen bus, which is used for the body.

These 2 communication buses are completely independent of one another, except for some specific data that are transferred from the chassis J1939 bus to Labrie’s multiplexed system, where they are used. These specific data are the following:

 selected gear  current gear  road speed  engine RPM  brake  parking brake

Press “Esc” to return to the preceding page.

J1939 page

Module Software Version

On the Module Software Version page, you will find the software version currently used by each of the modules installed on the truck and by the master control module.

Figure 3-17

Program Version page

66 Controls and Indicators

With the information on this page it is possible for the operator or maintenance personnel to determine the electrical schematic number pertaining to a specific vehicle. Looking at Figure 3-17 above you will notice the following digit string 8-6-5-1 between, for example, 10 and R1. As all Labrie electrical schematics begin with ZS00, you simply add those digits to that base number to get the corresponding electrical schematic number. So, in this case, the electrical schematic number is ZS008651.

Press “Esc” to return to the preceding page.

Pump Usage

This section contains an optional hour meter that tracks pump usage for maintenance purposes.

Press “Esc” to return to the preceding page.

Time Adjust

This section allows you to set the Time and Date indicator.

Press “Esc” to return to the preceding page.

NOTE: To go back to the Main Page or Main Menu, press “Esc” as needed until the desired page is

displayed.

Operational Diagram of the Multiplexed System

Labrie Enviroquip Group has elaborated a document that illustrates the way the multiplexed system works. Particularly, it visually shows how this system reacts to different situations and how it manages the various lockouts that are on the A

UTOMIZER

understanding related ladder logic diagrams much easier. The following are the first two pages of this document. If you are interested in receiving the entire document, call LabriePlus (see To Contact Labrie Plus on page 8).

HELPING-HAND. It also makes reading and

Controls and Indicators 67

68 Controls and Indicators

Control Panel

The control panel is located at the center of the cab for easy access during collection and operation.

On a truck with two driving positions, this control panel is mounted on a pivotal support which can be turned by hand.

The following is a description of the control switches and indicators that are on the control panel.

Controls and Indicators 69

Figure 3-18

Figure 3-19

Control panel (part 1)

Hydraulic

pump

Packer

multi-cycle

Control panel (part 2)

Crusher

panel up

Crusher

panel down

Rubrail

lights

Inhibit 10 sec.

Auto-

packing

Strobe

lights

Work lights

Body up

Body down

Auto

Neutral

Hydraulic

alarm

Tailgate up

Tailgate

down

NOTE: The switches and indicators on the control panel vary according to the options installed on the

vehicle.

70 Controls and Indicators

Hydraulic Pump Switch

This switch (see Figure 3-18), also known as PTO switch, engages and disengages the hydraulic pump, all the body functions (packing, body up/down, tailgate up/down) and the joystick that controls the arm. Note that the switch turns green when the pump is engaged.

 Press the switch to activate the hydraulic pump.  Press the same switch again to deactivate the hydraulic pump.

NOTE: Do not close the main shut-off valve on the hydraulic tank even if the PTO switch is turned off.

The pump is always turning whatever the engine RPM. It is very important not to let the pump run dry or without oil. Otherwise, the pump will be seriously damaged or even destroyed.

Figure 3-20

IMPORTANT: In case of a leak in the hydraulic system, and if the vehicle has to be driven somewhere else,

Main shut-off valve

take off the drive shaft between the pump and the engine. Call maintenance facility and refer to the Maintenance Manual.

Body Up Switch

This control switch (see Figure 3-19) is used to raise the body. Press and keep down this switch to raise the body to the desired height.

IMPORTANT: Before using this switch, make sure that the truck is parked on safe level ground and inspect for

overhead hazards, such as power lines.

When the body is off the frame a buzzer starts sounding.

Danger!

Always use the provided body safety prop when performing maintenance under a raised body. Failure to do so may result in severe injury or even death.

Controls and Indicators 71

Body Down Switch

This control switch (see Figure 3-19) is used to lower the body. Press and keep down this switch to lower the body to the desired height. When the body touches the rod of the limit switch fixed to the frame, the buzzer stops sounding.

Tailgate Up Switch

This control switch is used to raise the tailgate. Press and keep down this switch to raise the tailgate to the desired height.

IMPORTANT: Before using this switch, make sure that the truck is parked on safe level ground.

NOTE: Remove both tailgate-locking pins before using this control switch.

Warning!

When the tailgate is unlocked, both Tailgate Up and Tailgate Down switches flash red and a buzzer sounds. Also, the message “Buzzer: Tailgate Unlocked appears on the monitor screen.

Do not drive the vehicle when the tailgate is not fully closed.

Tailgate Down Switch

This control switch is used to lower the tailgate. Press and keep down this switch to completely close the tailgate or to lower it until it rests on the tailgate safety prop.

NOTE: When the tailgate is completely closed, put both tailgate-locking pins back to their place.

When the tailgate is unlocked, both Tailgate Up and Tailgate Down switches flash red and a buzzer sounds. Also, the message “Buzzer: Tailgate Unlocked appears on the monitor screen.

Packer Multi-Cycle Switch

This switch (see Figure 3-18) allows the packer to run a preset number of cycles (from 2 to 8, 3 being the default setting) with just a push of the green button (see Figure 3-23). Cycles can be stopped anytime by pressing the red button (see Figure 3-22) or by turning OFF the multi-cycle control switch. When turning OFF this switch, the packer completes the ongoing cycle, gets back to the fully retracted position and then stops.

Rubrail Lights Switch

This switch (see Figure 3-18) turns ON/OFF the rubrail lights.

 Press the switch once to turn ON the rubrail lights (switch turns green).

72 Controls and Indicators

 Press the switch again to turn OFF the rubrail lights (switch turns blue).

Hopper Work Light Switch

This switch (see Figure 3-19) turns ON/OFF the hopper work light.

 Press the switch once to turn ON the hopper work light (switch turns green).  Press the switch again to turn OFF the hopper work light (switch turns blue).

Strobe Light Switch

This switch (see Figure 3-19) turns ON/OFF the strobe lights and the amber flashing lights.

 Press the switch once to turn ON the strobe lights and the amber flashing lights (switch turns

green).

 Press the switch again to turn OFF the strobe lights and the amber flashing lights (switch turns

blue).

Crusher Panel Down Switch (optional)

Press and keep down this switch (see Figure 3-18) to lower the crusher panel (see Figure 3-21) to the desired position.

The crusher panel is an option that may be installed on an A your unit is equipped with this option, we suggest you to use it only for bulky items. In many cases, unnecessary use will slow down the operation. Bulky items can be maintained in place with the crusher panel while the packer crushes them.

The crusher panel can be lowered upon the refuse to prevent it from popping up in front of the packing ram, thus increasing the compaction effect during the load breaking sequence.

To help during the unloading process, a good amount of garbage should be left in front of the packer and under the lowered crusher panel as you finish your collection route. Once the body is raised at landfill, you can activate the packing ram to help clear whatever could be jammed in the hopper. This procedure can also be done without the crusher panel.

Crusher Panel Up Switch (optional)

Press and keep down this switch (see Figure 3-18) to raise the crusher panel to the desired position.

Figure 3-21

Crusher panel

UTOMIZER

HELPING-HAND vehicle. If

10-Second Inhibit Switch

This switch (see Figure 3-18), also known as gripper auto-close override, allows the operator to momentarily open the gripper in the hopper to let the object that it holds fall into the hopper. It also allows the operator to pick up elevated carts.

To enable this feature, press the Inhibit switch. This switch will then turn from blue to green.

Then press the Gripper Open button on the joystick (see Figure 3-27). The gripper will open for 10 seconds, then close automatically.

To deactivate this feature, press the Inhibit switch again. This switch will then turn from green to blue.

Controls and Indicators 73

Caution!

The inhibit feature overrides all safety features. The operator must be aware of all applicable safety instructions and all potential consequences related to its misuse. Major equipment damage and/or injury may occur in case of misuse of this feature.

Auto-Packing Switch

The auto-packing switch (see Figure 3-18) enables the packer to automatically start cycling 2 seconds after the gripper or bucket reaches the mid-height position on its way up. If the packer is cycling at the time the arm moves a container towards the hopper (or the bucket with its contents moves towards the hopper), the packer retracts immediately to its fully retracted position no matter where it was in the hopper. This is to prevent waste from being dumped onto the packer. The only exception is that the packer will not retract if, for 3 consecutive packer cycles, the fully extended proximity switch is not reached.

When the auto-packing feature is used simultaneously with the multi-cycle feature (see Packer Multi- Cycle Switch on page 71), the packer will run the preset number of cycles until the arm lifts a new container towards the hopper (or the bucket brings another load towards the hopper). The multicycle feature is then reset.

When a cycle has been interrupted and the packer has returned to its home position, cycling resumes 2 seconds after the gripper or bucket reaches the mid-height position on its way up.

Auto-Neutral Switch (optional)

The auto-neutral system is available on units equipped with an Allison electronic transmission. The auto-neutral allows the operator to shift from “drive” to “neutral” automatically without touching the shifter lever. For more information on this, refer to the chassis manufacturer’s manual.

The optional auto-neutral switch is located on the in-cab control panel (see Figure 3-19).

 Press this switch once to activate this feature (switch turns green).  Press this switch again to deactivate this feature (switch turns blue).

Hydraulic Alarm Switch (optional)

When provided, the hydraulic alarm switch is located on the in-cab control panel (see Figure 3-19).

74 Controls and Indicators

This feature is used to monitor the temperature inside the hydraulic system as well as the level of hydraulic oil inside the tank. If the oil temperature gets too high or the level of hydraulic oil gets too low, the hydraulic alarm switch LED will blink red at 1Hz, meaning that a correction must be applied quickly. On the multiplexed monitor, either warning message “High Hydraulic Oil Temp” or “Low Hydraulic Oil” will appear.

 A green switch means this feature is engaged.  A blue switch means this feature is not engaged.

NOTE: This switch should always be engaged.

In-Cab Packer Control Station

The AUTOMIZER console. This control station is used to operate the packer and has three big colored push-buttons on it. The operator can use these buttons to extend or retract the packer or to immediately stop packer extension/retraction when needed. The following is a short description of those three push-buttons:

HELPING-HAND is equipped with a packer control station located on the cab

Stop Push-Button (red)

The Emergency Stop button (see Figure 3-22) will stop all hydraulic functions on the truck (body up/down, tailgate up/down, packing, etc.). Pressing the red button will make the packer and the automated arm stop where they are. The red button has to be manually pulled out and the pump switch pressed again to reactivate the hydraulic system.

Figure 3-22

Stop push-button

Pack Push-Button (green)

The packer start cycle button (see Figure 3-23) activates the packer for one complete cycle. A complete cycle takes about 12 seconds.

Controls and Indicators 75

Figure 3-23

Pack push-button

Retract Push-Button (yellow)

The packer retract button (see Figure 3-24) will retract the packer to its “home” position, that is where it was at the beginning of its stroke. This control is useful when the body is full and the material prevents the packer from reaching the end of its stroke. Manual retraction of the packer is necessary to bring back the packer.

Figure 3-24

Retract push-button

Auxiliary Packer Control Station

NOTE: This control station is only found on AUTOMIZER

The auxiliary packer control station is located next to the right-hand side folding door (Figure 3-25).

units equipped with a bucket.

76 Controls and Indicators

Figure 3-25

Auxiliary packer control station

Stop Button

The Emergency Stop button will stop all hydraulic functions on the truck. Pressing the red button will make the packer and the bucket stop where they are. The red button has to be manually pulled out and the pump switch pressed again to reactivate the hydraulic system.

Stop button

Pack button

Retract button

Bucket control

button

Crusher panel

down button

Crusher panel up

button

Pack Button

The packer start cycle button activates the packer for one complete cycle. A complete cycle takes about 12 seconds.

Retract Button

The packer retract button will retract the packer to its “home” position, that is where it was at the beginning of its stroke.

Bucket Control Button

This button controls the up and down movements of the bucket. Turn it to the left to raise the bucket, to the right to bring it down.

NOTE: The bucket will stop at mid-height on its way up if you turn this button to the left when the

crusher panel is down.

Controls and Indicators 77

Crusher Panel Down Switch

Use this button to lower the crusher panel. Button must be kept pressed to activate panel movement.

NOTE: This button is inoperative if the bucket is not in its “home” position, that is right against the

bucket stopper.

Crusher Panel Up switch

Use this button to raise the crusher panel. Button must be kept pressed to activate panel movement.

Joystick Controls

Arm Joystick

The joystick is used to control the Helping-HandTM arm of the AutomizerTM. It can be located either on the console at the center of the cab or near the right-hand side door. In some units, two joysticks are installed in the cab: one on the console, the other near the right-hand side door.

Figure 3-26

The controls on the joystick are the handle, the deadman switch and the buttons on the device’s front and back (see Figure 3-27).

 The handle is used to control the horizontal and vertical movements of the arm’s two main

components.

 The lower front buttons allow the operator to control the opening and closing movement of the

gripper: the right button is used to open the gripper; the left button to close the gripper.

Arm joysticks

78 Controls and Indicators

 The upper front buttons are used to control the chute (standard setup) if such a device is installed

on the vehicle. The left button moves the chute to the left side of the hopper while the right button moves it to the right side. If no chute is installed on the vehicle, other functions can be controlled by these buttons based on the type of setup that is installed (crusher panel, packer, etc.).

NOTE: The chute is a piece of equipment that is optional. It can only be installed on a “co-mingle” type

vehicle.

 The buttons on the back of the joystick can be used to control the crusher panel (standard setup):

the left button used to raise it, the right button to lower it. If the crusher panel is controlled using the control panel instead of the joystick, other functions can be operated by these buttons based on the type of setup that is installed on the truck (packer, work lights, Auto-Dump

, etc.).

 The deadman switch is used as a safety device to ensure that every movement of the arm is

absolutely wanted and controlled by the operator. That is, if the operator is not pressing the deadman switch while trying to move the arm with the joystick, no movement will occur. With such a safety feature, an accidental movement of the joystick will not be transmitted to the arm. So an operator who wants to move the automated arm with the joystick must therefore press the deadman switch.

Joysticks operate at 45° and 90° angles. As a result, you can perform two functions at the same time; for example, you can move the arm and the gripper simultaneously.

Figure 3-27

IMPORTANT: Deadman switch must be depressed to activate in/out and up/down commands.

Automated arm joystick

Handle

gripper control

buttons

Programmable

buttons based

on chosen

options

Deadman

switch

Programmable

buttons based

on chosen

options

 Shift the joystick forward at 90° toward the gripper down lettering (see Figure 3-28) to lower the

gripper.

 Shift the joystick forward at 45° between the gripper down and arm extend lettering to lower the

gripper and extend the arm.

 Shift the joystick toward the streetside at 90° to the arm retract lettering to retract the arm only.

Controls and Indicators 79

 Shift the joystick backward at 45° between the gripper up and arm retract lettering to raise the

gripper and retract the arm at the same time.

 Shift the joystick backward at 90° to the gripper up lettering to raise the gripper only.  Shift the joystick toward the curbside at 90° to the arm extend lettering to extend the arm only.

NOTE: The joystick can also control the up and down movements of the bucket. Move the joystick

forward to lower the bucket, backward to raise it.

Figure 3-28

Automated arm joystick control

Cab Dashboard

The following is a short description of the dashboard buttons and warning indicator lights.

Parking Brake

The parking brake must be used every time the AUTOMIZER position other than at regular traffic stops (see Figure 3-29).

HELPING-HAND is stopped on idle

80 Controls and Indicators

Figure 3-29

Parking brake button

Arm Extended Warning Lights

There are 2 Arm Extended warning lights on the dashboard (see Figure 3-30). When they are flashing, they indicate that the arm is not completely retracted alongside the hopper. Do not move the vehicle in such a situation. Retract the arm until these lights stop flashing before moving the vehicle.

Figure 3-30

Arm Extended warning lights

NOTE: The above picture shows a cab setup that may be different from the one installed on your truck.

This picture is for illustration purpose only.

Warning!

Never drive this vehicle if the automated arm is not parked alongside the truck or inside the hopper. Failure to retract the arm completely could result in unit and/or property damage, personal injury or even death. Both Arm Extended warning lights (see Figure 3-30) flash when the arm is extended and stop flashing when it is retracted completely.

Controls and Indicators 81

82 Controls and Indicators

Operating the

UTOMIZER

A HELPING-HAND

The different methods, procedures and necessary actions to operate the A are presented in this section.

Warning!

Before operating the A the operator must be completely familiar with all safety procedures and the location, operation and functions of all controls and indicators related to the operation of the unit.

You must complete the daily inspection before starting the vehicle. It is your responsibility to report any malfunctions or concerns to your supervisor and maintenance personnel.

Consult with your supervisor for specific rules of driving the A

You must read and understand the Operator’s Manual before operating the vehicle and its equipment.

UTOMIZER

HELPING-HAND.

HELPING-HAND

HELPING-HAND,

Obey all speed restrictions and regulations.

Daily Inspection

Approaching the Vehicle

As you approach the vehicle, look for any object under or against the vehicle and check the surroundings for people, other vehicles, as well as ground and overhead obstructions. Ensure that the truck is parked at the most convenient place where you will have all the clearance required to perform a complete start-of-theday inspection. While doing the daily inspection, look for any structural damage, inspect tires and check the hydraulic tank for air leaks.

84 Operating the AUTOMIZER

Visual Inspection

Before starting the vehicle, the operator MUST perform a visual inspection of the truck. Ensure the engine is not running and the parking brake is set.

HELPING-HAND

NOTE: Some of the items mentioned in this manual are optional and may not be found on your

AUTOMIZER

HELPING-HAND.

As part of the visual inspection, you must:

 Ensure the cleanliness of lamps, safety decals, camera lenses, mirrors, windows, and the vehicle in

general.

 Ensure that safety equipment is available on board (i.e. fire extinguisher, first-aid kit).  Ensure there is no structural damage.  Ensure that there is no unusual wear, distortion, cracking, leaning, leaking on the vehicle.  Ensure that the hydraulic oil level (sight gauge on tank) is as recommended (cylinders must be

collapsed).

 Ensure that the hydraulic cylinders do not leak and mounting pins are secure.  Ensure that the hydraulic tank shut-off valve is fully open.  Ensure there is no mechanical problem: structure, rollers, hinges, door locks, wear items, etc.

Report any defective system to maintenance personnel.

 Ensure there are no leaks, cracks or other types of problems on the frame area, fuel tank, hydraulic

tank, air tanks (air tanks must be drained every day), cleaning trap and wheels.  Ensure that the tailgate is fully closed and BOTH tailgate safety pins are in place. Once the visual inspection is over, you must start the engine to check if the systems are working

properly.

Starting the Vehicle

To start the AUTOMIZER

1. Before starting the engine, check the following items:

1 a. Transmission shifter is on neutral. 1 b. Parking brake is on (see Parking Brake on page 79). 1 c. Hydraulic system is off (see Hydraulic Pump Switch on page 70).

2. Start the vehicle as stated in the chassis manufacturer’s manual.

3. Switch ON the pump to engage the hydraulic system (see Hydraulic Pump Switch on page 70).

Air pressure has to be at a minimum of 70 PSI.

4. Turn ON all light switches.

5. If required, move the truck to an appropriate area to perform the daily inspection.

6. Report any defective system to the maintenance personnel.

HELPING-HAND:

Body Inspection Procedure

Exit the cab to continue your inspection. Bring a rag along to clean all accessible lights, stickers, camera lenses, etc. Check for mechanical problems: rollers, hinges, door-locking mechanisms, wear items, etc. Report any defective system to the maintenance personnel.

Operating the AUTOMIZER

HELPING-HAND 85

NOTE: Some of the items mentioned in this manual are optional and may not be found on your

AUTOMIZER

HELPING-HAND.

As part of the body inspection procedure, do the following:

1. Activate the packer for a full cycle.

2. Check the automated arm operation.

Danger!

NOTE: If your unit is equipped with a bucket, check that it works properly by using both the in-cab

Do not stand directly in the path of the arm while performing the inspection.

joystick and the bucket operating button on the packer control station next to the folding door. Use them to raise and lower the bucket to verify good functioning. While testing, stay away from the bucket and make sure no one stands near or in the path of this equipment.

3. Check if both tailgate safety pins are in place.

If need be, put them back in place to lock the tailgate properly.

4. As you walk along the side of the truck, clean all safety decals.

5. Check the frame area, fuel tank and air tanks (air tanks must be drained every day), cleaning traps

and wheels for leaks, cracks and other types of problems.

6. At the front end, check lights and mirrors.

7. Go around and check lights, clean camera lenses, stickers, lights, etc.

8. Check for hydraulic leaks.

Arm Inspection Procedure

On a daily basis, perform a visual inspection of the automated arm looking for leaks, cracks or premature wear of the moving parts. Refer to the Lubrication section in the Maintenance Manual for detailed greasing points.

86 Operating the AUTOMIZER

HELPING-HAND

Figure 4-1

Danger!

Automated arm

Do not stand directly in the path of the arm while performing the inspection.

Warning!

Apply the lockout/tagout procedure at all times. See Locking Out and Tagging Out the Vehicle on page 43

Apply the following inspection procedure:

1. Make sure to park the vehicle on safe, level ground.

2. Ensure that the parking brake is set.

3. Start the engine and engage the hydraulic pump (See Hydraulic Pump Switch on page 70).

4. Fully extend the arm.

NOTE: If your unit is equipped with a bucket, extension of the arm is not possible.

5. Turn OFF the hydraulic pump and the engine.

6. Lock out and tag out the vehicle (See Locking Out and Tagging Out the Vehicle on page 43).

7. Perform a visual inspection of the following items:

• Mounting bolts;

• Plastic gliders;

Operating the AUTOMIZER

HELPING-HAND 87

• Gripper (left); bucket (right)

88 Operating the AUTOMIZER

• Hoses and connections;

• Cylinders.

8. Check for loose nuts and bolts.

9. Check gripper rubber stripes (std.) or pads (opt.) for cracks, wear, or damage.

HELPING-HAND

Figure 4-2

10. Check limit switches. Refer to the Maintenance Manual for more details.

Optional rubber pads

Operating the AUTOMIZER

HELPING-HAND 89

Figure 4-3

Figure 4-4

Gripper/bucket limit switch

Mid-height limit switch (left), parked limit switch (right)

Inspecting Right-Hand Side Driving Controls

NOTE: This section applies only to cabs modified by Labrie Enviroquip Group. If your cab has not

been modified by Labrie Enviroquip Group, please refer to your cab manufacturer’s recommendations.

Enter the right-hand side cab extension and operate the corresponding driving controls. Report any defective system to the maintenance personnel.

To inspect the right-hand side driving controls:

1. Turn the steering wheel to the left then to the right as you slowly move the vehicle forward.

2. Stop the vehicle by applying the foot brake.

3. Engage the parking brake and try to get the vehicle moving by throttling up with the right-hand

side accelerator pedal.

4. Throttle down to idle, step on the foot brake and disengage the parking brake.

5. Apply the temporary handbrake (if equipped) and try to get the vehicle moving by throttling up

with the right-hand side accelerator pedal.

6. Apply the parking brake.

90 Operating the AUTOMIZER

You must follow the inspection sheet provided by your employer. If your employer does not have any, ask his permission to use the inspection sheet on page 92.

Adjusting Mirrors

HELPING-HAND

Every time you use the AUTOMIZER

HELPING-HAND, you must adjust the mirrors to make sure that

you have all-around visibility from either driving position.

The following diagrams show the ideal mirror adjustments for both driving positions.

Figure 4-5

Mirror adjustment from left and right driving positions

Setting the Floor Riser

NOTE: This section applies only to cabs modified by Labrie Enviroquip Group. If your cab has not

been modified by Labrie Enviroquip Group, please refer to your cab manufacturer’s recommendations.

In the A

UTOMIZER

HELPING-HAND, the right-hand side driving position can be equipped with a height-adjustable floor riser. This riser makes your stand-up driving more efficient by giving you a better field of view, a more comfortable driving position, and a safer non-slippery surface to stand on. Also, its grid pattern allows drainage of any type of mud or snow that can be stuck under your boots.

Labrie recommends the use of this aluminum platform in its horizontal position at all times when driving from the right-hand side.

To set the floor riser:

1. With the floor riser in vertical position, release the latch and pull down the floor riser to its

horizontal position (see Figure 4-6).

Labrie AUTOMIZER HELPING-HAND Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Liability

Table of Contents

Introduction

Pre-Operating Instructions

A Note about Warranty

Mission Statement

Vision Statement

Product Overview

Key Features of the AUTOMIZERTM HELPING-HAND

Multiplexed System

Standard Limited Product Warranty

To Contact Labrie Plus

In the U.S.

In Canada

Safety

Conventions

Basic Safety Notions

Responsibilities

Employer Responsibilities

Employee Responsibilities

Things to Do

Things to Avoid

General Precautions

Fire

Safety Kits

Location of Safety and Informative Decals

Decals on Body

Decals on Tailgate

Decals outside Cab

Decals inside Cab

Multiplexed Switch Actuators

Multiplexed Indicator Tops

Safety Features

Back Up Alarm

Body Safety Prop

Tailgate Safety Prop

Camera System (optional)

Tailgate Holding Valve

Safety Lockout Tests

Hopper Door Proximity Switch Test

Arm Fully Retracted Limit Switch Test

Packer Fully Retracted Proximity Switch Test

Crusher Panel Up Proximity Switch Test (if equipped)

Arm Parked Limit Switch Test

Quick Reference Lockout Chart

Cleanliness

Locking Out and Tagging Out the Vehicle

Shutting Down the Vehicle

Starting Up the Vehicle

Driving the Vehicle

Driving Speed

Right-Hand Side Driving Position

Controls and Indicators

Labrie’s Multiplexed System

Main Page

Main Menu

Operational Diagram of the Multiplexed System

Control Panel

Hydraulic Pump Switch

Body Up Switch

Body Down Switch

Tailgate Up Switch

Tailgate Down Switch

Packer Multi-Cycle Switch

Rubrail Lights Switch

Hopper Work Light Switch

Strobe Light Switch

Crusher Panel Down Switch (optional)

Crusher Panel Up Switch (optional)

10-Second Inhibit Switch

Auto-Packing Switch

Auto-Neutral Switch (optional)

Hydraulic Alarm Switch (optional)

In-Cab Packer Control Station

Stop Push-Button (red)

Pack Push-Button (green)
