INSTRUCTION MANUAL

Laboratory Equipment Pty Ltd email: sales@labec.com.au Ph: 02 9560 2 811 • Fax: 02 9560 61 3 1

www.labec.com.au

2014

SEA Series Steam Sterilizers

Operation manual

User Registration On the inscription plate at back of the machine, you may find the unit's

model number, serial and reference number. Please double check the number and fill in the form with them, you should quote the reference number

when you are in contact with you distributors.

Model : Serial number: ________________ Reference number:_________________

*Before operating the sterilizer, please read carefully all safetycautions and instructions of operation. This operator's manual will help you understand all functions of Runyes Autoclaves as far as possible.

*Please follow carefully instructions in this operator's manual While servicing and maintaining the units.

*Please keep this manual safe for your future references.

*When error occurs during operation of the machine, please get in touch with your local distributor or us for our best qualified servicesand assistance.

SEA Series Steam Sterilizers

Operation manual

Important Information on Safety

Please plug the power in a correct voltage( according to nameplate) electrical socket. Don't use electrical outlets other than the correct voltage; otherwise it might cause fire or electric shock.

Don't wet your hands before plugging or unplugging the power cord.

Don't place your autoclave on an unstable table top, moving desk, tilted or shaking surface.

Don't cover or block the door, ventilation or radiation openings on the autoclave.

Don't put heavy stuff or liquid containers that might spill on the top of the machine.

Please unplug the power cord when the machine isn't used for a long while or when you travel, etc.

SEA Series Steam Sterilizers

Operation manual

Contents

1. Description & Usage............................................................

2. Specifications........................................................................

3. Installation.............................................................................

4. Control Panel of 8L/12L......................................................

Operation of 8L/12L

...................................................................................................................................................................................

6. Door Adjustment......................................................................

. Printer

User's Guide....................................................................

Function setup

..............................................................................................................................................................................................................................................................................................................

Maintenance & Maintain

9. .

.16

10.

Transportation

& Storage

........................................................

11. Warranty...........................................................................................

12. Accessorise

Appendix...................................................................................

Work mode form

Error code chart........................................................................

Cycle Chart & Schematics of 8L/12L................................

Pipe diagram of 8L/12L

.......................................................

Troubleshooting............................................................................

Important information..................................................................

SEA Series Steam Sterilizers

Operation manual

1. Description

Usage

Design and mark pressurizd steam autoclaves especially to meet the needs for sterilization of instruments and devices in clinics,departments in a hospital and laboratories. Operators include doctors or his/her assistance under doctors supervisions.The autoclave is computerized, user friendly and easy to operate. Its real time display show all data during the sterilization cycle. The software program provides auto diagnose, protection against over heating or over pressurizing,and thus ensure reliability of the sterilization results. Build- in condenser water collecting system prevents discharge of waste steam and keeps the machine clean and safe.

8L/12L One time pre-vacuum pressurized steam Autoclave

8L/12L uses the advanced technology of pre-vacuum and vacuum drying. It enables the hot steam to penetrate in thin tube and porous material. This product is suitable for Stomatology, ophthalmology, surgical theatres and or research laboratories to sterilize dental and surgical 135 autoclavable stuffs.

Water reservoir

Used water tank

Door knob

Fig 1-1

SEA Series Steam Sterilizers

Operation manual

2.Specifications

Chamber inner dimensions: (Diameter x Depth)-----------------------------------200Mm x 358mm Power Supply:---------------------------------------------------------------------According to the nameplate Sterilizing Temperature/Pressure--121 /(1.0-1.3) Bar (Under standard atmospheric pressure)

---------------------------------------134 /(2.0-2.4) Bar(Under standard Atmospheric pressure)

Note: Temperature/Pressure here means the chamber temperature and pressure during the phase of sterilization. The value varies under different atmospheric pressure.

Power Fuse-----------------------------------------------------------------------------------------------T12A Water reservoir capacity--------------------------------------------------------------------------3.5 liters

Environment temperature--------------------------------------------------------------------+5 +40 Relative Humidity Range--------------------------------------------------------------------------30% 75%

Figures

Package Key

Start/Stop key Select Key

Dry Key

Test Cycle Key

Used Water Outlet

Cycle Step Key

Caution & Warning

Type B Device

Grounding

Tip:

Standard atmospheric pressure: It is the atmospheric pressure at sea level. It refers to 1 Standard atmospheric pressure. The value is 0.1Mpa=1000Hpa=1.0 Bar. Atmospheric pressure decreases by higher altitude. For instance: at 3000 meters or lower, An increase of altitude of 1000 meters will result in a decrease of ATM PR .by 0.1Bar approximately.

SEA Series Steam Sterilizers

Operation manual

3.Installation

The Autoclave should be installed in a drafty place allowing minimum 10 cm space at all sides and 20 cm at the top. The radiation openings at the side of the machine should not be blocked. The Autoclave should be placed on a leveled counter top.(Fig 3-1)

If the front of the machine is lower than the back the control will display E3 (E3 means it does not dry completely) There fore, you may be possible to adjust the height by adjusting foot pad of the frout of Autoclave. And you can adjust the balance according to the Horizon.

369

439

Fig 3-1

575

Fig 3-2

Caution:

SEA Series Steam Sterilizers

Operation manual

Prepare the machine before use

We have installed the in the chamber(Fig3-3).

draining filter

You should clean the when use the autoclave

draining filter

for a long time.The instruction shows you how to clean it. Please refer to P17.

Before using the device, you should make electrical connections by using the power cord that comes with the unit. Insert the hollowed end of the power cord in to inlet of the machine and plug the other end on a power outlet. Caution: The power supply can afford 1800VA load. Ok, you can turn on the autocalve now.

Caution: The power supply must afford at least 1800VA load.

Fig 3-4

Fig 3-3

Tips: Before using the Autoclave, please check on the local atmospheric pressure. If the pressure is lower than 0.095 Mpa or the Altitude is higher than 500 meters, you will need to contact your distributor who should reconfigure the controller in the device.

SEA Series Steam Sterilizers

Operation manual

4.Control Panel of 8L/12L

Control Panel of 8L (Fig4-1)

1 Pressure Display

It displays chamber relative pressure in real time during a cycle. The unit is per Bar.

2 Temperature

It displays chamber temperature during a cycle.The unit is per Degrees Centigrade

3 State display/Error Codes

It displays all the states of autoclave. ( Look at the state form) Error Codes when alarm goes on. You may correct the error accordingly by looking it up in the page of error codes and its corrections.

Caution: In case of faults, please contact your distributor or the manufacturer immediately.

4 SELECT key

Program choose key. It is used for choosing the temperature. You can choose the right program according to the temperature that instrument can afford. You can also choose B program, it can

sterilize medical cotton.

Package choose key. It is used for choosing two types mode of package. According to fact, you can choose wrapped or unwrapped. Non-package use one time vacuumize, package use B-standard vacuumize.

6 Test key

It is used for choosing the test program. If you push the button the indication light of B&D goes on, and it means that you have chosen this testing program when you push again, the indication light of Leak goes on, it means that you have chosen this program.

Fig 4-1

7109

812

5 PACKAGE key

SEA Series Steam Sterilizers

Operation manual

7 D R Y key

This key selects the Fast sterilization cycle. With unwrapped instruments, you may use the fast cycle by pressing the DRY key once, the indication light goes on and it indicates that machine is in fast cycle mode. Using autoclave made by Runyes, you may still use this selection to shorten the cycle time.

8 STEP key

This is a post cycle selection key. When a sterilize cycle completes, you may press this key to keep on working or stop working The indication light goes on, and it means that when the cycle is complete, the heating element will stop before the chamber door is opened. When the indication light is off, it means that the chamber will be kept warm after completing a

cycle and heating up time is shorter during next cycle. If you don’t want to start the last

cycle, you need to press STEP key once.Then the indication light will be off.

When you choose the right program, push this button then it starts a cycle. Keeping pressing the key 3seconds before desiccation phase, the cycle of sterilization will be quitted. Then it will enter 3 minutes dryness. In this program if you press the key again, the program of dryness will be over at any moment. If you press the key at the end of dryness, the cycle will be quitted directly.

When the water volume is low, the light is glinting.

When the light goes on, the machines gets ready for sterilization,and the operator can press

start key to start a cycle.

Working light. It means sterilize program is working .

9 START/STOP key

10 WATER indication light

11 READY indication light

12 RUNNING indication light

SEA Series Steam Sterilizers

Operation manual

5. Operation of 8L/12L

Please connect the power cord before you start the operation. Press the mains power switch at right lower corner of the front panel. The power switch light turns on indicating that electric power is connected. All keyboards goes on, automatically examine. It will indicate error code and alarm when examine failed. Itwill indicate Ld when pass examination.

5.1 Fill water

If the water level is lower than the lowest water level. When the power switch is on, select the sterilize program, the water indication light may glinting while alarm Beeps. At this time, you need torefill the reservoir. Please open the water tank and pour water into it by container. Please pay attention to the water level during filling water, you should stop filling when the surface is close to the red water level mark.

1.Distilled water must be good for prolonging life of the machine.

2.Don't tilt the autoclave where there is water in the reservoir.

3.The used water tank should be emptied frequently. You should evacuate the used water reservoir usually when water reservoir is empty.

Fig 5-1

SEA Series Steam Sterilizers

Operation manual

5 .2 Start a cycle

When water indication light is off, the machine can be started.

5.2.1Press SELECT to choose one of the programmes. The key toggles among the cycles at 121 ,134 and B+ mode. One of the indication lights turns on to show the programme you selected.(Fig 5-2)

5.2.2 You may need to select instruments package mode. According to the instrument you put into the chamber whether it is bareness or sop up, press package to select package mode.

5.2.3 You may select DRY key when starts the fast sterilization cycle. Press DRY key, it will reduce the sterilization time. If you press the butoon"DRY" on the panel, there are three selections, 1min(with 1min LED on), 5min(with 5min LED on) , and 10min(with two LEDs off).

5.2.4 After selecting above steps, put the instruments into the Steam Sterilizer which need sterilize.

Caution: Instruments that are ready to sterilize should be placed in the tray not touching one another allowing space for steam to pass through. It is suggest that the tray holder be used to put the tray with instruments inside the chamber to avoid burning injuries.

Fig 5-3

Fig 5-2

SEA Series Steam Sterilizers

Operation manual

Fig 5-4

5.2.5 After the instruments are loaded, you may close andlock the chamber door by turning the door knob clockwiseto its locking position. The ready indication light goeson. (Fig 5-

4) Caution: The door knob must be turned to its lock position,

otherwise, there might be steam leak during a cycle and the alarm goes on and displays error code E6 . If the chamber is in keep warm mode, it is sometimes difficult to close the chamber door because there is still steam inside. You can keep the door open for a while until steam and moisture is vaporized, and the door is easy to close. You may also push the door inwards with some force while turning the door knob to its locking position. If there is still steam leak after you did the above, you may try to read just the door mechanism by a spanner as per item

6. Door adjustments.

5.2.6 Press START/STOP key, the ready light goesoff and display HE the machine starts a sterilization cycle.It takes about 30-60 minutes to complete an automatic cyclethat includes heating up, sterilizing and drying. The cycle timedepends on the volume of the instruments loaded, the chamber temperature at the beginning of the cycle and the cycle program you selected.

5.2.7 When a cycle completes, the display Ed the indication light RUNNING Turns off and the indication light READY turnson with sounds. At this time you may then open the chamber door andunload

the instruments which are sterilized. (Fig 5-6) At mean time,temperature indicate prt , it means that it is performing print,whether you have install printer, the process can not be omitted. But youneedn't care about it. It will not effect the process of opening the doorand unloading the instruments. The indication will disappear whenprinting is over.

Fig 5-6

Fig 5-5

SEA Series Steam Sterilizers

Operation manual

Attention: To ensure autoclave's on the safe side, When water level low alarm sounds, Please be advised add some water first. When you add the water, please don't forget to let condenser water out.

Caution: Always use the tray holder to load or unload the tray with instruments in it, in order

to avoid burning injuries.

If you didn't press STEP key during a cycle and the indication light is off, it means that the machine is keep warm mode.The sterilization Chamber is keeping warm. This will enable faster cycle that follows.

If you press STEP key before the end of sterilization, STEP indication light goes on, it means that the machine is last time cycle. The chamber starts to cool down completely before the chamber door is open. It should normally be used during the very last cycle of the day.

5.2.8 If you decide to stop using the autoclave for a while, pleaseturn the main power switch off, or unplug the power cord should you not want to use the machine for a long time.

Caution: Never try to open the chamber door if and when the pressure display doesn't show

0.0 . It is suggested that chemical indicator or bio-indicator be used for each and every cycle to ensure the reliability of each sterilization cycle run.

SEA Series Steam Sterilizers

Operation manual

5. 3 the instrument rack should be put inside the boiler as the following diagrammatic sketch shows

Fig1 Fig2

The second way:clockwise rotate the instrument rack by 90 based on the first way fig3,fig4

Fig3 Fig4

notes: the circle stamped angle is upalong

The first way: fig1,fig2

SEA Series Steam Sterilizers

Operation manual

6.Door Adjustment

Under normal circumstance the chamber door lock needs no readjustment.Once steam leaking occurs (the seal fails), you may use the spanner to turn the door seal tightener.

6.l Open the door first.

6.2 Insert the spanner in the gap beneath the plastic cover; use the spanner to lock on the adjusting nut (Fig 6-2). Turn the nut counter clockwise as the figure below (Fig 6-1). This will tighten the sealing plate.

6.3 Turn the nut until the sealing plate is tight. If the door knob is too tight, you may also turn the nut clockwise to loosen it as long as the seal does not leak.

Caution:

Never try to readjust the chamber door while the door is locked.

Fig 6-1 Fig 6-2

LOOSE

TIGHT

SEA Series Steam Sterilizers

Operation manual

7. Printer User's Guide

According to the requirement of customer, Runyes steam sterilizer can adopt prescriptive printer. Connect the printer and the steam sterilizer with prescriptive cord. Switch on the power, two lights on the printer Panel will go on, means printer has been installed.

Caution: Runyes steam sterilizer can only select micro printer offered by Runeys.

Print information explaining:

Date:Sterilize date CN:name of cycle

C.S.T:The starting time of cycle Vp1:vacuum pressure1

Pp1:The phase of pressure1 H.S.T:the starting time of sterilization.

H.E.T:the end time of sterilization. D.S.T:the starting time of drying. C.E.T:the end time of cycle.

Operator:Operator You can signature name according to

practicality instance

Caution:Chinses characters provided by Runyes.the

mini-autoclave of Runyes is only to equip with the mini-printer of Chinese characters provided by Runyes

Fig7-1

Sterilization

Records

Date : 07 . 04. 20 Cycle: 0000 1 C.N.:134 2.10

C.S.T:23: 15:16 Vp1 : 2 3:2 1:5 5

0.05 046.6

Pp1: 23:23 :57

-.80 050.1

H.S.T.:23:50:24

Max:2.24 134.6

Min:2.14 134.5 Ave:2.19 134.5 H.E.T.:00:08:27

D .S .T. : 00: 10 :44

0.30 118.5

C.E .T. : 00: 10 :45

Operator:

Resu lt: Passed

Thanks

SEA Series Steam Sterilizers

Operation manual

7.2 USB module function

7.2.1Main function: Storage of printed data of sterilization Built-in FLASH memorizer

U-disk. Download

7.2.2Basic parameters: Storage Capacity: 2M bytes Quantity of printed data could be stored: 2048 Support FAT files

7.2.3Operation instruction:

1.Turn on the power, the mode of USB will start automatically. After self-test, it goes into alert

with the indicator flickering-1 time.

2.After the sterilization cycle ends, the data of sterilizer is sent to the USB mode(The printer program should be turned on). Indicator will flicker-1 time after the data-transfer finish.

3.During the alert, insert U-disk. The mode indicator will be on, with the U-disk indicator flickering. And now, it is in the process of data-download. Don't turn the power off or draw out the USB-disk, which will cause the data lose.

4.After the download finish, USB mode indicator will flicker twice, reminding the user to draw out the U-disk.

5.During the sterilization cycle, avoid data download, or else, the data will lose.

6.Connect U-disk to computer. You will see files like _2000_, where the downloaded data is kept, following turns of Year, Month and Day. Easy to print it out.

7.USB mode terror(According to the flickering times of USB mode indicator) and solution:

Times

Definition

Solution

Self-test passed

Normal

Operation finish

Normal

No definition now.

U-disk needs formation

Format U-disk in FAT files

Not enough capacity

Delete the files in U-disk

U-disk needs formation

Format U-disk in FAT files

USB mode error

Caution: This function is optional to the demand of customer.

SEA Series Steam Sterilizers

Operation manual

8.1 Enter function setup mode:Press STEP key for 20s when on non-work state time dispaly Ld pressure dispaly 1 enter function setup mode.

8.2 Function mode setup With 7options, press SELECT key, you can select 1-7-1cycle

dispaly. The definition and display of 7 options as following Option 1 year dispaly yer press STEP or key increase press DRY

or Key decrease setup numerical value Option 2 month dispaly nth press STEP or key increase press DRY or Key decrease setup numerical value Option 3 day display day press STEP or key increase press DRY or Key decrease setup numerical value option 4 hour display hor press STEP or key increase press DRY or Key decrease setup numerical value Option 5 minute display nin press STEP or key increase press DRY or Key decrease setup numerical value

Option 6 Printing,it display Pvt ,press STEP key then you can choose the cycle between on and of . on stand for print , of stand for no printing .

Option 7 Exit,,when Eit displays,please press START/STOP to save and exit setup mode.

Option 8 sterilization time adjust,display S-T when you setup this option,the sterilization time(SP)win increase at former value.The adjustable range are following 3 kinds.One is inereased by 1 minute,Second is inereased by 2 minutes.Third is incereased by 3 minutes.

Option 9: temperature data adjust automatically option, display D-P ,When you setup this option,you can adjust the temperature more or less than 2C-3C inorder to meet your request. But we suggest user should setup under guidance of teahnician or not setup.

Press SELECT key after setup,you will come back to option 1.At this time,you must press STEP key 3 seconds in option7.Then you can start the setup of option8 and option.Otherwise it only can start cycle between option1and option7.

Caution:If some functionsetup was changed by pressing the key without intention,please switch off the power,then restart it.It will exit from the wrong setup.In this case,the function won't be affected by this.

8.Function setup

SEA Series Steam Sterilizers

Operation manual

9. Maintenance

& M

aintain

9.1 How to clean the water tank.

9.1.1 Please clean the sterilizer water tank and waste water tank regularly.

1 Empty the tanks water, please refer to item 9.2 draining the water.

2 Open the tank cover board, you can use screw driver to loosen the

five screws just as fig9-1 indication

5 Now you can start to clean the tank, use cotton to dip in some

alcohol or medical disinfectant to scour the tank wall, wash it by distilled water, then empty the tank and dry the tank.

6) After cleaning the tank, assemble the tank cover and tighten the screws.

9.2 Draining of water from the machine Drain the condenser water collector and water reservoir.

Connect the water outlet using the one end of the tube without a connector and the other end of

the tube to a drainage sink. Then turn the draining knob anti- clock wise to drain the water from the machine.(Fig 9-4)

Fig 9-4

Fig9-1

Fig9-2

Fig9-3

3 Pull up the water tank cover board by one hand,just, as

fig9-2 indication.

4 Pull up the tank cover completely and you can disassembly the

tank cover. See fig9-3 indication.

SEA Series Steam Sterilizers

Operation manual

After a long time usage, maybe some small impurity will deposit on the drain filter, it will affect vacuum and drying. All the impurity comes from the oil or dirt or dust of theinstrument which need sterilization, also maybe comes from the water. In order to prolongthe life of the drain filter, please note the following items:

If draining filter plug up, you can solve according to fig 9-5.

1 find the water filter. 2 rotate off the filter screw

5 after you clean or change a new filter shim,plug in the water filter back on the chamber connection.Notice: please put the blue rubber down and touch the chamber and rotate tighten the screw nut.

Fig9-5

3 pull out the filter from the connection..

4 take off the blue rubber which on the filter clean or change a new one as you need.

9.3 Change fuse (Fig 9-6)

1).Switch off the power.

2).Unscrew the fuse holder with a screw driver counter anti-clockwise.

3).Pull the fuse holder out with your fingers.

4).Make sure to replace the cooked fuse with a correct fuse.

5).Put back the fuse holder and screw it on clockwise with a screw driver.

6).You may use your hand to change the fuse.

Fig9-6

SEA Series Steam Sterilizers

Operation manual

9 .4. Clean the seal plate periodically. After using some time , the seal plate might have some scale build-up that might cause leaking. You should clean the seal plate periodically, using a soft cloth soaked with distilled water to wipe the rubber seal and the seal plate clean (Fig 9-7 & 9-8). If there is still leaking, you may need to take the rubber seal out for cleaning. Should the seal be broken, you need to change

with a new one.

Fig 9-7 Fig 9-8

Remark: providing with seal packing collar for life.

9.4.1 Change of the seal You will need a flat screw driver without a sharp tip. Pay attention about head of the flat

screw driver. The install step according to Fig 9-9.

Fig 9-9

1). Hold the edge of the seal with one hand and insert the screw driver beneath the seal with your other hand and then pull out the seal slowly.

2). Once a section of the seal is out, you may pull the whole seal out slowly with both of your hands.You can now clean the seal groove and the seal. If the seal is broken or damaged, you must replace it with a new one.

3). After the groove and the seal are cleaned, you may remount the seal back in place

Caution: The seal should be mounted evenly inside the groove with first 4 positioning points in place. You may use your hand to press the seal in place evenly.

4). Attention: When inserting the seal, the inner edge might evaginate. You may use a screw driver to press the edge down in the groove.

Caution: Power the machine off and let it cool down before you change the seal and avoid any burning injuries.

SEA Series Steam Sterilizers

Operation manual

9.5Cleaning Steam generator

9.5.1 Aim: Clean the steam generator and steam pipe, to avoid the furring block the pipe.

9.5.2 Description: 20 min cleaning + 10 min drying

9.5.3 Purpose: to clean the steam generator furring, take it out of the machine through pre vacuum.

9.5.4 Operation: when the machine is inactivity, press SELECT for 5 seconds, the B&D light and LEAK light will go on at mean time, it means you chose the cleaning cycle. Close the door and press START, it will start to clean.

9.5.5 Cleaning remind: after cleaning, every 100 cycles, B&D light and LEAK light will go on at the mean time and glitter. Remind you to clean the steam generator.

Friendly remind: Cleaning function will not affect the autoclave cycle, only remind message.

Fig 9-10

SEA Series Steam Sterilizers

Operation manual

10.Transportation

Storage

10.1 Preparation for transportation and storage.Power the machine off, unplug the power cord and let the chamber cool down.

10.2 The autoclave should be transported and stored in the follow conditions: Temperature:

-40 ~ +55Humidity: 85% Atmospheric pressure: 500Hpa ~ 1060 Hpa

Caution: Don't drag the machine while moving.

11.Warranty

The manufacturer provides a warranty for repair at not change to the customer for two years after the invoice date with presentation of the invoice. Followings are the disclaimers:

11.1 Damage due to improper moving, installing and operating the machine;

11.2 Damage due to dismantling the machine by unauthorized personal;

11.3 Don't have guarantee of end user.

11.4 Inappropriate operation on the machine without following the operator's manual

11.5 Damage caused by power surge, fire or other external matters.

SEA Series Steam Sterilizers

Operation manual

12. Accessories

1 2

3 4

7 8 9

SEA Series Steam Sterilizers

Operation manual

1). Instrument tray rack 1 pc and Instrument tray 3 pc .

2). Power cord. 1 pc. 8). Fuse 2 pc .

3). Mainboard Fuse 1 pc.

4). Water outlet tube 1 pc.

5). Tray holder 1 pc.

9).Draining O ring 2 pc .

10). Level instrument 1 pc.

11). Door adjustment spanner 1 pc.

6).Filtrable net 1 pc.

7).Sealing ring 1 pc.

SEA Series Steam Sterilizers

Operation manual

Appendix.

Form1 Cycle mode Chart

Item

Digital display

Mode

Description

Pre-heating

Preparation and conditioning of the autoclave

Heating

Chamber is being heated and pressurized

Cycle time

Sterilizing

Counting down of sterilizing

Dr_

Venting

Chamber starts to vent and dry

Drying time

Drying

Instruments are being dried.

Ed_

Complete

Cycle is complete and chamber door can be opened

Faults & Error codes

Error codes

Displays error codes, resets and alarm

LE_

Balance state

When change the state, the pressure of inside and outside the Autoclave should be the same.

Form2 Work mode chart

Sterilize mode, as following form(8L/12L)

134 C package

134 C

non package

121 C

package

121 C

non package

134B+

BD test

Vacuum test cycle

CLEAN test

Sterilizing temperature

134

121

134

Sterilizing pressure

2.10

1.10

2.10

Classes

SSSSS

Pre-heating min

0-7

Vaccumize time min

44444

Clean 20

Admission time min

55555

Drying

Sterilizing time min

46162018

3.5

Keep pressure 10

Drying time min

1010101010

Quick drying time

1/5

Total time min

30(21/25)

38(29/33)

42(33/37)

52(43/47)

50(41/45)

26.51430

SEA Series Steam Sterilizers

Operation manual

For

m 3 ERROR CODE CHART

Serial number

Code

Error

Solution

Sensor error

Examine sensor

Super pressure(>2.6 Bar)

Examine inner temperature sensor

Chamber temperature(>145 C)

Examine outer temperature sensor

Constant temperature and constant pressure failed

Rerun parameter autoadjust program

Puts the steam defeat(20S<0.3Mba)

Inspect puts the steam valve, the vacuum valve

Door is opened when on working

Examine door switch

Steam generator ultra warm(>240 C)

Inspect steam generator temperature sensor

Pre-heating failed(>20 min)

Examine the electric connection of temperature sensor, heat ring and heat stick

Admission defeat(>30 min)

Examine electric connection of heat stick, Admission pipeline

SEA Series Steam Sterilizers

Operation manual

Fig 1.

( Bar)

2.0

1.0

0.5

Time

-1.0

1 2 3 4 5 6 7

1-2 Pre-heating 4-5 Venting 2-3 Pre-vacuum 5-6 Drying 3-4 Sterilizing 6-7 Pressure balance

1-7 Sterilizing cycle

Cycle Chart at 134

2.0

Time

1 2 3 4 5 6 7

1-2 Pre-heating 4-5 Venting 2-3 Pre-vacuum 5-6 Drying 3-4 Sterilizing 6-7 Pressure balance

1-7 Sterilizing cycle

1.0

-1.0

Cycle Chart at 121

( Bar)

SEA Series Steam Sterilizers

Operation manual

Cycle Chart & Schematics of 8L/12L

SEA Series Steam Sterilizers

Operation manual

Piping diagram of 8L/12L

Fig 2.

Two pass valve

Vacuum pump

Condense pipe

two position three pass valve

Chamber temperature sensor

Exhaust solenoid valve

Normally open valve

Draning water solenoid valve

Normally open valve

waste water tank

waste water drain connection

Steam

generator

Pressure sensor

Chamber

Steam solenoid valve

Normally closed valve

water tank

manual water filling exit

Safety valve

drain connection

Let in air pump

Let in air solenoid valve

Normally closed valve

Air filter

SEA Series Steam Sterilizers

Operation manual

Troubleshooting

1.During venting or drying, the thump sounds. It means that the condensed water collector is full. You must drain the water from The collector.

2.Hissing from the chamber door. (Solving this problem according to item 8 Door Adjustment)

3.During a cycle, a banging sounds and large steam leaks from the chamber door and displays E6 code. Please verify whether the door knob is properly turned and locked. If the steam

leaks at the beginning of a cycle, you need to change the seal according to instructions at page 18.

4.When a cycle completes, there are water drops on the instruments.

You may correct the problem by:

1). Please check the drain filter.

2). Reduce the load of the instrument in the chamber, especially the porous and dressing and

other water absorbent materials.

3). You may also wait for a while at the end of a cycle Ed for better drying result. The

autoclave will continue heating the chamber until you open the door.

SEA Series Steam Sterilizers

Operation manual

Important information

1.The autoclave must be installed on a leveled counter top.

2.When operated at a higher elevation of more than 500 meters,The machine must be

reprogrammed. Please get in touch with your distributor for instructions.

3.Distilled water must be used to prolong the life of the machine.

4.The radiation openings in the machine must not be blocked or covered.

5.Instruments should be placed on the tray allowing space between one another and thus

allowing steam to pass through.

6.Condensed water collector must be emptied from time to time.It should be emptied when

refilling the water reservoir.(Draining of the collector can be followed as per item 9.2)

7.Chamber door knob must be turned to its locking position.

8.Never try to open the chamber door before pressure displays 0.0 .

9.To avoid burning injuries, power off the machine and let it cool down before replacing the seal.

10.No dragging when the machine is moving.

11.Power connection must be grounded properly.

12.Must be provided enough power.(1800VA)

13.While the temperature of outside is lower, please pre-heating the machine without instruments for 30minutes before sterilize.

LABEC AA-12S User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
