L.A. Baby CW-35 User Manual

The Original Bedside Manor

Warnings & Instructions CW-35

Read all instructions and warnings before assembly and
use of crib. Be sure to check that parts listed below are

included before assembling this crib.
Tool needed: Hex wrench (Included in hardware kit)

Parts List Pieces per Unit

A) Side Rails 2
B) End Panels 2
C) Posture Board 1
D) Mattress (2” x 36” x 18”) 1
E) Bolts (50 mm) 12
F) Lock Washers 12
G) Barrel Nuts 12
H) Casters 4
I) Bolt 4
J) Lock Washer 4
K)Threaded Cap 4
L) Hex Wrench 2

Hardware

E

D

B

A

C

B

A

Care Instruction:

F

G

H

I

J

K
L

Step 1

E & F

E & F

Step 2

E & F

E & H

Step 3

E & F

E & F

Optional Add On

for the CW 35 compact crib

For step 1 it is easier to assemble the crib

G

F&E

B

A

B

upside down on a padded surface.

Note the location of plastic teething rail.

Insert 4 barrel nuts (I) into side rail.

Attach end panel (B) to side rail (A) using 4
bolts (E) and lock washers (F) to side rail
(A). Tighten with the hex wrench (L).

Wheels can be removed and the crib used as a rocking crib. The rocking crib feature can only be used
before the infant begins to push up on hands and knees or has reached 18 lbs whichever comes first.

The rock locks can only be used when mattress is at the highest
position, for enabling or disabling the rocking feature

Part Pieces

M) Hex Bolts 4

Rock Locks

N) Wood Feet 4

Teething rail

G

C

F&E

F&E

Attach remaining head board as you did
the first.

Selecting the mattress depth:

If this crib is for a newborn, the posture
board (C ) should be at the top. As the
baby grows the posture board should be
moved down.

For step 2 it is easier to continue with the
side rail down on a padded surface.

F&E

Align the posture board (C ) along the side
rail and between the two end panels (B).

Insert 4 barrel nuts (G) into the bottom of
the posture board.

Secure the posture board to the end
panels (B) using 4 bolts (E) and lock
washers (F). Tighten with the hex wrench
(L).

O) Washers 8
P) Nuts 4
Q) Wrench 1

M

M

N

Q

O

PON

Q

!

!

WARNING: FAILURE TO FOLLOW THESE

WARNINGS AND THE INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY OR DEATH.

NEVER use this product if there are any loose or missing fasteners,

!

loose joints, or broken parts. Check before assembly and
periodically during use. Make sure latches are secure. Contact

L.A. Baby for replacement parts.

! NEVER substitute parts

!

WARNING: Infants can suffocate.

! In gaps between a mattress too small or too thick and product

sides.

! On soft bedding.

NEVER add a mattress, pillow, comforter, or padding.

!

! Use only mattress provided by

WARNING:

manufacturer, which must be at least 38 inches long by 18 inches
wide and not more than 2 inches thick.

! This crib including side rails must be fully erected prior to use.
! When child is able to pull to standing position, set mattress/base to

lowest adjustment position and remove bumper pads, large toys,
and other objects that could serve as steps for climbing out.

! NEVER place a crib near windows where cords from blinds or

drapes may strangle a child.

! Discontinue use of the crib when child is able to climb out or

reaches a height of 35 inches (890 millimeters), the child should be
placed in a youth bed.

! If refinishing, use a non-toxic finish specified for children's

products.

! Child can become entrapped and die when improvised netting or

covers are placed on top of crib. NEVER add such items to confine
child in crib.

Insert 4 barrel nuts (I) into the remaining
side rail ((A)

Align the remaining side rail along the

A

I

G

F&E

F&E

posture board (C ) and between the two
end panels (B).

Secure the side rail using 4 bolts (E) and
lock washers (F).

To disable the rocking feature of the crib. Attach the four wooden feet (N) to the inside
of both of the headboards using the bolts, (M) washers (O) and nuts (Q).

! NEVER use a water mattress with this crib.

! Replace teething rail if damaged, cracked, or loose

! Always provide the supervision necessary for the continued safety

of your child. When used for playing, NEVER leave child
unattended

! To reduce the risk of SIDS, pediatricians recommend healthy

infants be placed on their back to sleep, unless otherwise advised
by your physician.

! CAUTION: Keep small parts and plastic bags out of reach of small

children

! NEVER use plastic shipping bags or other plastic film as mattress

covers not sold and intended for that purpose. They can cause
suffocation

Your crib may be cleaned, using a damp cloth and ordinary mild
domestic detergent. Do not use abrasives or bleach. Wipe dry.

Date of MFG.

L.A. Baby Juvenile Products

16039 Loukelton Street

City of Industry, California 91744

Toll free customer service: 800-584-3094

e-mail: [e-mail]

Step 4

H

Made in China

Ins_CW-35-U_061314

!

WARNING! Strings can cause strangulation! NEVER

Secure casters to Cradle
rocking base using bolt (I),
lock w a sher ( J ) and
threaded cap (K). Use two
allen w renc h es(L) t o
tighten.

J

I

K

To disable the rocking feature:
To stop the rocking motion, you can re-install the 4 casters or install and use the 4 "Rock Locks". If

Pos. 1

Pos. 2

using the rock locks rotate the four feet (N) until snugged up to the bottom rail. (Pos.2)

H

To enable the rocking feature:
Remove the wheels. Rotate the four feet (N) up. (Pos. 1)

!

place items with a string around a child's neck, such as hood
strings or pacifier cords

! NEVER suspend strings over a crib or attach strings to toys.

This crib conforms to applicable regulations promulgated by the
Consumer Product Safety Commission.

This crib meets new C.P.S.C. 16 CFR 1220 and A.S.T.M.
406 12a Standards.
