CALIBER　60 / 90 / ZG　Parts acceptable List

○ NOMAL ● OPTION

№ ENGLISH JAN 60 90 ZG

1194 5x35 Drag Bolt 4955439703014 ○ ○ ○

94903-1 Anthivibration rubber 4955439735695 ○ ○

96881 2x5x2.3mm F Ball Bearing 4955439721193 ○ ○ ○

96882 3x7x3mm F Ball Bearing 4955439721209 ○

96883 3x8x4mm F Ball Bearing 4955439721216 ○ ○ ○

96884 4x7x2.5mm F Ball Bearing 4955439721223 ○ ○ ○

96885 4x9x4mm F Ball Bearing 4955439721230 ○

96886 5x11x5mm F Ball Bearing 4955439721247 ○ ○ ○

96887 5x14x5mm F Ball Bearing 4955439721254 ○ ○ ○

96889 7x17x5mm Ball Bearing 4955439721278 ○ ○ ○

96890 10x16x12mm OneWay Bearing 4955439721285 ○

96891 10x19x5mm Ball Bearing 4955439721292 ○ ○ ○

96893 12x24x6mm Ball Bearing 4955439721315 ○ ○ ○

96894 3x7x3mm Ball Bearing 4955439721322 ○

96896 4x9x4mm Brg 4955439761649 ○ ○

96897 3x8x4mm Brg 4955439761656 ○

96946 12x18x0.15mm Shim 4955439725436 ● ● ●

CA3028-02 Nipple(For Fuel Tank) 4955439751435 ○

CA3067A Tail Rotor Grip(CA5/CA30) 4955439869482 ○

CA5051-60 Tail Support Pipe(600mm) 4955439864180 ○

CA6001 Yoke(Seesaw head) 4955439720394 ○

CA6002 Center Hub 4955439720400 ○

CA6003A Seesaw 4955439725481 ○

CA6004 Spindle Shaft(Seesaw head 4955439720424 ○

CA6005 Main Rotor Grip 4955439720431 ○

CA6006 Grip Arm 4955439720448 ○

CA6007 Mixing Lever 4955439720455 ○

CA6008 Stabilizer Blade 4955439720462 ○ ○ ○

CA6008-01 Stabilizer Blade Decal 4955439732021 ○ ○

CA6009 Shaft Cover(Seesaw head) 4955439720479 ○

CA6010 Main Mast 4955439720486 ○

CA6011 Seesaw Damper 4955439720493 ○ ○

CA6012 Mast Stopper 4955439720509 ○ ○ ○

CA6013A Slide Block(A) 4955439766040 ○ ○ ○

CA6014 Slide Block(B) 4955439720523 ○ ○ ○

CA6015 Washout Arm 4955439720530 ○ ○ ○

CA6016A Swash Plate(CALIBER 90) 4955439761502 ○ ○ ○

CA6017 Washout Arm Link 4955439720554 ○ ○ ○

CA6018 Elevator Lever(A) 4955439720561 ○

CA6019 Elevator Lever(B) 4955439720578 ○

CA6019-01 Elevator Shaft 4955439734629 ○

CA6020 Aileron Lever 4955439720585 ○

CA6021 Main Mast Holder 4955439720592 ○

1/6 【2006.3.22改定】

CALIBER　60 / 90 / ZG　Parts acceptable List

○ NOMAL ● OPTION

№ ENGLISH JAN 60 90 ZG

CA6023 Head Linkage(Seesaw head) 4955439720615 ○

CA6024 Drive Belt 4955439720622 ○

CA6025 Clutch Shaft 4955439720639 ○

CA6026A Drive Pulley(32T) 4955439793343 ○ ○ ○

CA6027A Clutch Drum(CALIBER 60/90) 4955439794326 ○ ○

CA6028 Clutch 4955439720660 ○

CA6029 Fan Belt 4955439720677 ○

CA6030 Engine Mount 4955439720684 ○

CA6031 Cooling Fan 4955439720691 ○

CA6032 Cooling Fan Holder 4955439720707 ○

CA6033 Cooling Fan Cover 4955439720714 ○

CA6034 Servo Linkage 4955439720721 ○

CA6035 Servo Set Plate 4955439720738 ○ ○ ○

CA6036 Counter Pulley(60T) 4955439720745 ○

CA6037 Counter Gear 4955439720752 ○ ○ ○

CA6038 Counter Shaft 4955439720769 ○ ○ ○

CA6039 Tail Drive Pulley(18T) 4955439720776 ○ ○ ○

CA6040 Tail Pitch Ring 4955439720783 ○ ○ ○

CA6041A Tail Out Put Shaft 4955439754061 ○ ○ ○

CA6042A Tail Pulley Case(Set)(CALIBER 90) 4955439761519 ○ ○ ○

CA6042-01A Tail Pulley Case(CALIBER 90) 4955439761526 ○ ○

CA6042-02A Tail Pitch Lever Stay(Brg)(CALIBER 90) 4955439761533 ○ ○

CA6043 Tail Drive Belt 4955439720813 ○ ○

CA6043-21 ZG Tail Drive Belt 4955439864197 ● ● ○

CA6044 Tail Pitch Lever(A) 4955439720820 ○ ○ ○

CA6045 Tail Pitch Lever(B) 4955439720837 ○ ○ ○

CA6046 Tail Pitch Lever(C) 4955439720844 ○ ○ ○

CA6047A Tail Case Holder(CALIBER 90) 4955439761540 ○ ○ ○

CA6048 Rudder Servo Holder 4955439720868 ○ ○ ○

CA6049 Tail Boom Holder 4955439720875 ○ ○ ○

CA6050 Horizontal Fin Holder 4955439720882 ○ ○ ○

CA6051-01 Tail Support End 4955439734643 ○ ○

CA6051-02 Carbon Tail Support Pipe(60&90) 4955439742143 ○ ○

CA6051-03 Carbon Tail Support Pipe(50&60&90) 4955439742150 ○ ○

CA6052 Skid Damper 4955439720905 ○ ○ ○

CA6053 Tail Linkage Guide 4955439720912 ○ ○

CA6054 Carbon Linkage Rod 4955439720929 ○ ○

CA6054-7 Tail Linkage Guide(With Strap)4pc 4955439864203 ○

CA6054-88 Carbon Linkage Rod(875mm) 4955439864210 ○

CA6055 Body Mount 4955439720936 ○ ○

CA6055-1 Grommet (For body) 4955439723418 ○ ○ ○

CA6056 Ladder Frame(A) 4955439720943 ○ ○

CA6057A Ludder Frame(B)(CALIBER 90) 4955439761557 ○ ○
