Simplified Earth Tester

KEW 4300

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Contents

1. Safety warnings

2. Features

3. Specification

4. Instrument layout

5. Accessories

6. Getting started

6-1 Battery voltage check

6-2 Attaching Metal tip/ adapter

7. Voltage measurement

7-1 Measurement procedure

7-2 Live circuit warning

8. Earth resistance measurement

8-1 Principle of measurement

8-2 Measurement procedure

9. LCD backlight and LED light

10. Replacing batteries

･････････････････････････････････････････

･･･････････････････････････････････････････････

････････････････････････････････････････････

････････････････････････････････････････

････････････････････････････････････････････

･････････････････････････････････････････

･･･････････････････････････････

･･･････････････････････････････････

･････････････････････････････

･････････････････････････････････

････････････････････････････

･････････････････････････････

･････････････････････････････

････････････････････････････････････

10

11

11

･･････････････････････････

･･･････････････････････････ 15

11

13

13

14

15

16

18

19

1

4

5

8

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1. Safety warnings

This instrument has been designed and tested according to IEC
Publication 61010: Safety Requirements for Electronic Measuring
Apparatus. This instruction manual contains warnings and safety
rules which must be observed by the user to ensure safe operation
of the instrument and retain it in safe condition. Therefore, read
through these operating instructions before starting using the
instrument.

● Read through and understand the instructions contained in this

manual before using the instrument.

● Save and keep the manual handy to enable quick reference

whenever necessary.

● The instrument is to be used only in its intended applications.

● Understand and follow all the safety instructions contained in

the manual.
Failure to follow the instructions may cause injury, instrument
damage and/or damage to equipment under test. Kyoritsu is by
no means liable for any damage resulting from the instrument in
contradiction to this cautionary note.

The symbol # indicated on the instrument, means that the user
must refer to the related parts in the manual for safe operation of
the instrument. It is essential to read the instructions wherever the

symbol appears in the manual.

#

# DANGER : is reserved for conditions and actions that are

likely to cause serious or fatal injury.

# WARNING : is reserved for conditions and actions that can

cause serious or fatal injury.

# CAUTION : is reserved for conditions and actions that can

cause injury or instrument damage.

# DANGER





 1 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

● Never make measurement on a circuit in which the electrical

potential exceeds 300V.

● Do not attempt to make measurement in the presence of

flammable gasses. Otherwise, the use of the instrument may
cause sparking, which can lead to an explosion.

● Never attempt to use the instrument if its surface or your hand

is wet.
Be careful not to short-circuit the power line with the metal part of

●

the test leads when measuring voltage. It may cause personal injury.

● Do not exceed the maximum allowable input of any

measurement range.

Never open the Battery compartment cover during a measurement.

●

● Keep your fingers and hands behind the protective fingerguard

during measurement.

● Never attempt to make any measurement if any abnormal

conditions, such as a broken cover or exposed metal parts are
present on the instrument and test leads.

● Do not press the Test button when connecting the test leads to

the instrument.
Do not install substitute parts or make any modification to the

●

instrument. Return the instrument to your local Kyoritsu distributor
for repair or re-calibration in case of suspected faulty operation.

● Do not replace batteries if the instrument is wet.

● Ensure that the L-shaped Banana plug of MODEL7248 is firmly

inserted into the E terminal.

● Power off the instrument when opening the Battery

compartment cover for battery replacement.

● Stop using the test lead if the outer jacket is damaged and the

inner metal or color jacket is exposed.

● Ensure that the instrument is powered off after use and test

leads are disconnected. Remove the batteries if the instrument
is to be stored and will not be in use for a long period.

● Do not expose the instrument to direct sunlight, high

temperature, humidity or dew.

● Use a damp cloth with neutral detergent or water for cleaning

the instrument. Do not use abrasives or solvents.

● Do not store the instrument if it is wet.

# DANGER

# WARNING

# CAUTION





 2 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Symbols


#



Measurement categories (Over-voltage categories)

To ensure safe operation of measuring instruments, IEC 61010
establishes safety standards for various electrical environments,
categorized as O to CAT IV, and called measurement categories.
Higher-numbered categories correspond to electrical environments
with greater momentary energy, so a measuring instrument
designed for CAT III environments can endure greater momentary
energy than one designed for CAT II.
O : Circuits which are not directly connected to the mains

CAT II : Primary electrical circuits of equipment connected to an

CAT III : Primary electrical circuits of the equipment connected

CAT IV : The circuit from the service drop to the service entrance,

Instrument with double or reinforced insulation

User must refer to the explanations in the instruction

manual.

(Functional) Earth terminal

Crossed-out wheel bin symbol (according to WEEE
Directive: 2002/96/EC) indicating that this electrical
product may not be treated as household waste, but
that it must be collected and treated separately.

power supply.

AC electrical outlet by a power cord.

directly to the distribution panel, and feeders from the
distribution panel to outlets.

and to the power meter and primary overcurrent
protection device (distribution panel).

O: Device which is
not directly
connected to the
mains power supply





 3 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

2. Features

KEW4300 is a simplified earth resistance tester (based on 2-pole
method) that can be used for various distribution lines and electrical
appliances and it also can measure AC/DC voltages. (As for AC
voltages, true rms values can be obtained.)

● Designed to meet the following safety standards

IEC 61010-1 CAT III 300V, Pollution degree 2
IEC 61010-031
IEC 61557-1, 5

● 200/ 2000Ω (2 ranges) : auto-ranging

● Warning buzzer triggered at 100Ω or less

● LED lights up when a large earth voltage is detected.

● Small test current (max 2mA) not triggering ELB

● Live circuit warning when 30V or higher voltage is detected.

(KEW4300 detects voltage even when measuring resistances.)

● LED light for illuminating measurement points

(It turns on/off automatically in relation to the ambient brightness.)

● Backlight working in conjunction with the LED light

● Glow in the dark button

● User-friendly and compact design

● Auto-power-off function is also available to power off the

instrument when 10 min pass after the last operation. This
function does not work while a continuous measurement is
performed.

● Strap for prevent drop

● User replaceable metal tips are supplied as standard accessories





 4 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

3. Specification

● Measurement range and accuracy (23ºC±5Cº, relative humidity

75% or less)

Voltage/ Earth voltage measurement

Measurement range Display range Accuracy

AC5.0 to 300.0V

(45 to 65Hz)

(425V peak or less)

DC±5.0 to ±300.0V 0.0 to ±314.9V ±1%rdg±8dgt

*AC measurement method : rms detection

* AC/DC auto-detection at 5V or higher
* DC sign appears at 5V or higher.
(H+S(C+P) terminal: positive side, E terminal : negative side)
* The LCD reads 0.0V for 0.9V or lower voltages.

Earth resistance measurement

Range

(auto-ranging)

200Ω Range

2000Ω Range 160 to 2099Ω

Measurement method: Constant current inverter

approx. 1.4mA (200Ω Range)/825Hz
approx. 0.7mA (2000Ω Range)/825Hz

Measurement

5.0 to 2000Ω

0.0 to 314.9V ±1%rdg±4dgt

For the waveforms other than sinewave
of CF<2.5, the specified accuracy

±1%f.s. should be applied.

range

Display range Accuracy

0.0 to 209.9Ω
±3%rdg±5dgt

Open voltage: Approx. 13V





 5 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

● Applicable

standards

● Location for use Altitude 2000m or less, indoor use

● LCD Segment display with backlight

● Operating

temperature and
humidity range

● Storage

temperature and
humidity range

● Withstand

voltage

● Insulation

resistance

● Auto-power-off

function

● Backlight Turns off automatically when approx 2min

● Dimensions 232(L) x 51(W) x 42(D)mm

● Weight Approx. 220g (including batteries)

● Power source Size AA, alkaline battery x 2pcs

● IEC 61010-1

● IEC 60529(IP40)

● IEC 61557-1, -5

● IEC 61326-1, 2-2

● IEC 61010-031

MODEL7248 / CAT III600V
(Alligator clip should be attached and used

in the CAT III or higher environment.)
MODEL8253 / CAT III300V
(while it is connected to the instrument)
* When the test leads are connected to the

instrument, the lower category either of

them belongs to is applied.

-10ºC to 50ºC,

80% or less (no condensation)

-20ºC to 60ºC,

75% or less (no condensation)

AC3,540V(50/60Hz)/ for 5 sec between the
electrical circuit and the enclosure

50MΩ or more/ DC1000V between the

electrical circuit and the enclosure
Auto-power-off function operates with audible

warning and powers off the instrument when
approx 10min pass after the last operation.
(This function is disabled during a resistance
measurement.)

pass after the last operation. (This function is
disabled during a measurement.)

(including the metal tip)

(The use of alkaline LR6 is recommended.)





 6 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

● Operating Error

Operating error (B) is an error obtained within the rated operating

conditions, and calculated with the intrinsic error (A), which is an
error of the instrument used, and the error (Ei) due to variations.
According to IEC61557, the maximum operating error should be

within ±30%.

● Operating error at earth resistance measurements (IEC61557-5)

2

2

Formula: B= ±(|A|+1.15 x √E

2

+E

2

+E

)

3

4

A Reference condition
E
E

E

Normal operating position ±90º

1

Variation due to changing the supply voltage (until the

2

Battery symbol
Variation due to changing the temperature

3

appears)

(-10ºC to 50ºC)

E

Variation due to series interference voltage

4

16•2/3Hz, 50Hz, 60Hz, DC: 10V

400Hz: 3V

E

Variation due to resistance of the probes and auxiliary

5

earth electrode resistance

E1 : It is not applicable to digital testers.
E

: It is not applicable to simplified earth testers.

5

Measurement range within which the maximum operating error

±30% applies: 5.00Ω to 2000Ω.

● Number of measurement

(measuring for 5 sec and take a pause for 25 sec)

Function Resistor

for test

Number of measurement

(within effective battery voltage
range)

Earth measurement 10Ω Approx. 3000 times





 7 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

4. Instrument layout

(1) Instrument Body

9

2

1

Name Details

H+S(C+P) terminal

1

2 LED light

3

Ambient light sensor

4 Test button

5 Warning LED

6 LCD

7 Power button

8 E terminal

9

Protective fingerguard

3

4

5 6

To connect the replaceable metal tip MODEL8072

has been installed and delivered.

To illuminate the measurement spots

The light turns on/off automatically in relation to

ambient brightness.

To sense ambient brightness for turning on/ off

the light

To conduct resistance measurement

Measurement is conducted when the button is held

down.

To give warnings for live circuit (blinking red)

and for large earth voltage (blinking yellow)

LCD with backlight

The backlight turns on/off automatically in relation

to ambient brightness.

To power on/ off the instrument.

The button should be held down for 1 sec or longer.

To connect the test lead MODEL7248

It is a part providing protection against electrical

shock and ensuring the minimum required air and

creepage distances.





 8 

7

8

Fig. 4-1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

(2) LCD

Fig. 4-2

● Symbols displayed on the LCD

Indicate the batteries need to replace.

Show the measured results.

Appear when the measured result exceeds the display

● Symbol displayed at earth measurements

● Symbols at voltage/ earth voltage measurements

range.

Resistance : >2099Ω

Voltage :

Indicate the end of a measurement with frozen
measured result.

Blink to give a warning for live circuit

A unit of earth resistance

“AC” for alternate voltages and “DC” for direct voltages

・

A unit of voltage

Polarity sign for negative voltages

> 314.9V (“-OL” for negative DC voltages)





 9 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

5. Accessories

● Test leads

(1) MODEL7248 – with Alligator clip and Flat test bar

(2) Banana plug, both ends, black

L-shaped
Bananaplug

(3) Alligator clip (4) Flat test bar

＋　　　　　　

Protectivefingerguard

＋

Fig.5-2

● Tip metal tips for H+S(C+P) terminal

(1) MODEL8072

Fig. 5-4

Standard metal tip
installed at a shipment.

(2) MODEL8253 (3) MODEL8017

Fig. 5-5 Fig. 5-6

Fig. 5-1

Fig. 5-3

Metal tip with plastic molded

Long type and helpful to access
the distant measurement spot

● Others

(1) Carrying case
(2) Strap
(3) Size AA alkaline battery x 2 pcs
(4) Instruction manual





 10 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

6. Getting started

6-1 Battery voltage check

(1) Please refer to “10. Replacing batteries” in this manual and

insert batteries in KEW4300.

(2) Hold down the Power button at least 1 sec and power on

KEW4300.

* A long press of 1 sec or longer is required to power on/ off the

instrument. It is to prevent a malfunction.

(3)

The battery voltage is extremely low when the “ “ symbol
appears at the upper left corner on the LCD. Replace the
batteries with reference to “10. Replacing batteries” to carry out
further measurements.

The use of size AA alkaline battery is recommended. The Battery
symbol may not appear correctly when the other types of batteries
are used.

6-2 Attaching metal tip/ adapter

The metal tip for the H+S(C+P) terminal and the adapters for
MODEL7248 to be connected to the E terminal are replaceable
depending on applications.

DANGER
Always attach and use the M-8253 and the Alligator clip to use
this instrument in the CAT III or higher environments. The other
metal tips: M-8072, M-8017 and the Flat test bar have a large
exposed metal and may short the equipment under test. It may
cause a malfunction of the equipment under test, a fire or fatal/
serious injuries to the user or the people around.

(1) Replaceable metal tip
The metal tips are replaceable depending on applications.
[Available tip metal tips]

1. MODEL8072 : Standard metal tip installed at a shipment

2. MODEL8253 : Metal tip with plastic molded

3. MODEL8017 : Long type and helpful to access the distant

#

measurement spot





 11 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

[How to replace the parts]

Flat test bar

Detach the metal tip by turning the red plastic parts counter

clockwise.

Install the metal tip you want to use into the hexagon hole, and

turn the red plastic parts clockwise to tighten firmly.

MODEL 8072

MODEL 8253

六角穴

Internal

メネジ

thread

Hexagon
hole

先端金具

Metal tip

MODEL 8017

Fig. 6-1

(2) Test leads

Either of the following adapters should be connected to the cord
with Banana plug, both ends.

[Adapters for MODEL7248]

1. Alligator clip

2. Flat test bar
[How to connect]
Firmly insert and connect the adapter to the end of the cord with

Banana plug, both ends.

Alligator clip

Banana plug, both ends

Fig. 6-2

DANGER

#

To avoid getting electrical shocks, ensure that test leads are
disconnected from the instrument when replacing the metal tip or
adapter for test leads.





 12 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

7. Voltage measurement

# DANGER

● Never apply voltages exceeding 300V, max over-voltage

protection, to this instrument.

● Keep your fingers and hands behind the protective fingerguard

during measurement.

7-1 Measurement procedure

(1) Connect the test leads to the instrument.
Plug the L-shaped Banana plug of MODEL7248 into the E

terminal as illustrated below.

Fig. 7-1

(2) Connect the adapter for test leads to the earth side of the circuit

under test and the metal tip (H+S(C+P) terminal) to the line side
respectively. Connecting that in reverse is also fine if the circuit
under test is not earthed.

Caution
Do not press
the Test button.

Fig. 7-2





 13 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

(3) The measured voltage is displayed on the LCD.

Take the reading without pressing the Test button. The
instrument judges DC or AC and shows “DC” or “AC” sign on the
LCD.

* When negative DC voltages are detected at the H+S(C+P)

terminal, the negative polarity sign “-“ appears to the left of the
measured value.

* The LCD does not show “DC”, “AC” nor sign when the

measured values are less than 5V.

The LCD shows “>314.9V” when the measured value exceeds
the display range (over range) and it shows “-OL” for negative DC
voltages.

7-2 Live circuit warning

The warning LED starts blinking red with audible warning when the
measured value is 30V or higher.

LED starts blinking. (Red)

Fig.7-3

* The instrument does not carry out resistance measurements

even the Test button is held down while the live circuit warning is
activating.





 14 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

8. Earth resistance measurement

Primary

This instrument can measure the earth resistances of distribution
line, internal wiring and electrical appliance.

DANGER

● Never apply inputs exceeding 300V between the measuring

terminals at earth voltage measurements.

● No voltage should be applied between the measuring terminals

during earth resistance measurements.

8-1 Principle of measurement

This instrument carries out earth resistance measurements based
on the fall-of-potential method. This is a simplified earth resistance
tester and uses the existing earth systems (with a sufficiently
low earth resistance) such as buried metal pipes like main water
pipe, common earth for commercial power supply and a lightning
electrode on buildings and performs measurements based on the
2-pole measurement method.

The AC constant current
“I” is applied between the
measurement object “Rx”
(earth electrode) and the
existing electrode “re” to
obtain the earth resistance
value “Rx + re” and find out
the voltage “V” between the
E and H+S(C+P) terminals.
See Fig. 8-1.

Rx + re = V / I

The resistance “re” of the existing earth electrode with which
H+S(C+P) terminal is connected is added to the true resistance
“Rx” of the measured object, and displayed as the measured result.
Re (measured value) = Rx + re

#

Constant current
generator

E
terminal

Earthing system
under test

I→

Voltmeter

Earth electrode

Secondary

H+S (C+P)
terminal

Fig.8-1

If the value of “re” is already known, deduct it from the measured
value “Re” to determine “Rx” value.
Rx (true resistance value) = Re – re





 15 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

8-2 Measurement procedure

(1) Connect the test leads to the instrument.
Plug the L-shaped Banana plug of MODEL7248 into the E

terminal as illustrated below.

Fig.8-2

(2) Connection
Connect the instrument as illustrated below.

POWER

H+S(C+P)

re

E

LOAD

Rx

N

L

E

Fig.8-3Measuring the earth resistance

ofload

DANGER

#

Fig.8-4Measuringthe earth

resistanceofwallsocket

● Always use a voltage detector for testing the earth side of the

commercial power supply.

● Do not use this instrument for testing the earth side of the

commercial power supply. It is dangerous because the LCD may
not show the measured voltage even the circuit under test is in
live if the earth of the electrode under test is loose/ disconnected
or the connection of the test leads is not proper.

(3) Checking the earth voltage
Check the earth voltage displayed on the LCD without pressing

the Test button.





 16 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

● The displayed value should be less than 10V.

The warning LED starts blinking yellow when the earth voltage

is 10V or higher. (The LED starts blinking at 3V or higher if the
frequency of the earth voltage is 400Hz.)

LED starts blinking.

10V or higher: yellow
30V or higher: red

Fig.8-5

Ensue that the systems connected to the earth electrode under
test are turned off to get the earth voltages lower when the
warning LED for earth voltage starts blinking. Otherwise, accurate
measured results can not be obtained. The warning LED for earth
voltage may not light up if the frequency is over 400Hz.

● The warning LED starts blinking red with audible warning when

the voltage of 30V or higher is detected. Earth resistance
measurements can not be carried out by pressing the Test
button while the live circuit warning is activating.

(4) Measurement
Press the Test button. The LCD shows the measured result.

The instrument carries out an earth resistance measurement
while the Test button is held down. The buzzer sounds when the

measured value is less than 100Ω.

The measurement is halted when the Test button is released,
and the measured data freezes on the LCD. (The “

appears on the LCD.) A short press of the Test button while the
result is being displayed on the LCD gets the instrument entered
into the Voltage measurement mode.

● The LCD shows “>2099Ω” when the measured result exceeds

the display range. (Over range)

● The instrument automatically enters into the voltage

measurement mode when sensing the live circuit during a
resistance measurement and activates the warning function.

● If an earth resistance measurement is continued at low battery

level with Battery symbol on the LCD, the instrument may be
powered off suddenly.

” symbol





 17 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

9. LCD backlight and LED light

the instrument.

The LCD backlight and the LED light on this instrument turn on/off
automatically in relation to ambient brightness. These lights keep
on for about 15 sec once they turn on. The Ambient light sensor as
shown in the below figure senses the ambient brightness.

Ambient light sensor

Fig.9-1

● Dirt on the surface of the sensor may interfere the proper

operation of the lights. Keep the sensor clean.

● The sensitivity of the sensor is not adjustable. Cover the sensor

with your hand or finger if you need to turn on the lights. The
lights keep on for about 15 sec once they turn on.

[Turning off the Auto-light mode]

The following procedure is for setting the lights always off.

1. Ensure that the instrument is powered off.

2. Hold down the Power button for 1 sec while the Test button is
held down and power on the instrument.

3. Now the Auto-light mode is disabled. Repeating above steps

1.& 2. restores the mode.

The number of beep when powering on the
instrument is different depending on the
selected light mode. The selected mode
will not be reset even after powering off the
instrument.

Number of beep Light mode

Once Auto

Twice Always off

Buzzer sounds
when powering on

Fig.9-2

Pi･･･





 18 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

10. Replacing batteries

When the Battery symbol appears on the LCD, replace the batteries
with new ones.

DANGER

Never open the Battery compartment cover if the instrument is wet.

●

● Do not attempt to replace batteries during a measurement.

In order to avoid getting an electrical shock, ensure that the
instrument is powered off and the test leads are disconnected
from the instrument before replacing the batteries.
Always install the Battery compartment cover when starting a

●

measurement. Otherwise, it may cause an electrical shock hazard.

● Do not mix new and old batteries or mix different types of

batteries.

● Install batteries in correct polarity as marked inside.

(1) Power off the instrument and disconnect the test leads from the

instrument.

(2) Loosen the screw at the backside of the instrument and remove

the Battery compartment cover.

(3) Remove all the old batteries. Install two new batteries in correct

polarity.

The use of two, size AA alkaline batteries or alkaline batteries

(LR6) is recommended.

(4) Install the Battery compartment cover and tighten the screw.

#

CAUTION

#

Fig.10-1





 19 

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com
