STDF-3

CONTENTS

FIG.1 HOUSING · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
FIG.2 PAPER FEED COVER · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4
FIG.3 PAPER TAKE-UP SECTION· · · · · · · · · · · · · · · · · · · · · · · · · · · · 6

• INDEX· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 8

– 1 –

FIG. 1 HOUSING

3A7

⁄

‚

‹

°

›

´

ˆ

fl

¤

´

‡

fi

HAD

2

HAU

¨

5

7

‡

3

‰

#

9
8

4

HAD

¨

HAU

HAU

HAD

*

6

1

$

)

HCB

HAU

HAD

Ï

„

0

Í

Î

Å

&

!

^

HAU

HAU

Ø

ˇ

HAD

Œ

%

¨

Á

HAD

@

Á

·

∏

HAD

HAU

)

(

HCB

– 2 –

FIG. 1 HOUSING

Ref.

SP Part. No. Description

No.

'

1 3A702010 BASE,ADF 1 1 1
2 3A702050 STAY,BASE 1 1 1
3 3A702060 FRONT RETAINER,BASE 1 1 1
4 3A702070 REAR RETAINER,BASE 1 1 1
5 3A702080 FRONT WORK PLATE,BASE 1 1 1
6 3A702090 REAR WORK PLATE,BASE 1 1 1
7 3A702100 FRONT SHAFT,RETAINER BASE 1 1 1
8 3A702110 REAR SHAFT,RETAINER BASE 2 2 2
9 3A702120 SPRING,PAPER FEED 2 2 2

10 3A702140 MOUNT,PCB DRIVER 1 1 1

'

11 3A702150 ACTUATOR,ORIGINAL DETECTION 1 1 1
12 3A702190 MOUNT,ORIGINAL DETECTION 1 1 1
13 3A702200 RETAINING PIN,PAPER FEED 1 1 1
14 3A703010 LEFT HINGE 1 1 1
15 3A703020 RIGHT STAY,HINGE 1 1 1
16 3A703030 RETAINER,HINGE 1 1 1
17 3A703040 FULCRUM PIN,HINGE 1 1 1

'

18 3A704010 LOWER FRONT COVER 1 1 1

'

19 3A704020 LOWER REAR COVER 1 1 1
20 3A704040 FRONT MOUNT,COVER 2 2 2
21 3A705020 LABEL,ORIGINAL SIZE(METRIC) 1 1
21 3A705030 LABEL,ORIGINAL SIZE(INCH) 1
22 3A705040 LABEL,ORIGINAL CURSOR(METRIC) 1 1
22 3A705050 LABEL,ORIGINAL CURSOR(INCH) 1

'

23 3A706010 TABLE,ORIGINAL 1 1 1

'

24 3A706020 FRONT CURSOR,ORIGINAL TABLE 1 1 1

'

25 3A706030 REAR CURSOR,ORIGINAL TABLE 1 1 1

'

26 3A706040 COVER,ORIGINAL TABLE 1 1 1
27 3A706050 RACK,ORIGINAL TABLE 2 2 2
28 3A706060 ACTUATOR,ORIGINAL TABLE 1 1 1

'

29 3A708060 MAT,ORIGINAL HOLDER 1 1 1
30 3A727030 WIRE,INTERFACE 1 1 1
31 3A727040 JUNCTION WIRING,SIZE DETECTION 1 1 1

'

32 3A728010 DRIVER PCB 1 1 1
33 3AL06090 CUSHION,ORIGINAL GUIDE 2 2 2
34 34806150 STOPPER 5 2 2 2
35 34920190 GROUND PLATE,FIXING UNIT 1 1 1

'

36 35327400 SWITCH,FEED 2 2 2
37 63511220 STOP RING,4 4 4 4
38 65907210 GEAR 20,CASSETTE 1 1 1

Quantity

230V120V 240V

Ref.

SP Part. No. Description

No.

39 M1203200 OPEN BUSHING,OCB-375 1 1 1
40 M2105040 NYLON CLAMP 6N,NK-6N 1 1 1
41 M2105720 MINIATURE CLAMP,UAMS-05-2 1 1 1
42 M2108000 SPACER,KGLS-3S 3 3 3
43 M2108080 SPACER,KGPS-3S 1 1 1
44 M2109050 LOCKING WIRE SADDLE,LWS-2Y 3 3 3

3A7

Quantity

230V120V 240V

• Parts with "•" are component parts or sub-assemblies of the
assembly appearing immediately above them.

• Parts with "'" indicates the Service parts.

– 3 –

FIG. 2 PAPER FEED COVER

1

)

*

^

(

HAD

‹

%

7

3A7

¤

‡

HAD

@

fi

‹

(

‡

%

&

°

2

3

⁄

›

8

fl

9

4

5

– 4 –

#

6

KAK

KAL

0

°

HAU

!

$

FIG. 2 PAPER FEED COVER

Ref.

SP Part. No. Description

No.

'

1 3A707010 COVER,PAPER FEED 1 1 1

'

2 3A707020 PULLEY,PAPER FEED 1 1 1

'

3 3A707030 PULLEY,LEADING FEED 1 1 1
4 3A707040 GUIDE,PAPER FEED PULLEY 1 1 1
5 3A707050 SHAFT,PAPER FEED 1 1 1
6 3A707060 SHAFT,LEADING FEED 1 1 1
7 3A707110 GEAR 30,PAPER FEED 1 1 1
8 3A707120 PULLEY,LEADING FEED 1 1 1
9 3A707130 BELT,LEADING FEED 1 1 1

'

10 3A707140 ACTUATOR,SIZE DETECTION 5 5 5
11 3A707150 MOUNT,ACTUATOR 1 1 1
12 3A707160 RETAINING PIN,PAPER FEED COVER 1 1 1
13 3A707220 HANDLE,RELEASE 1 1 1
14 3A707230 SHAFT,RELEASE 1 1 1
15 3A707240 HOOK,RELEASE 2 2 2
16 3A707250 STOPPER,PAPER FEED 1 1 1
17 3A707260 FRONT SUPPORT PLATE,PAPER FEED 1 1 1
18 3A707270 REAR SUPPORT PLATE,PAPER FEED 1 1 1
19 29806810 BUSHING,6 REGISTRATION 2 2 2
20 3AL05120 LABEL,DF ORIGINAL CAUTION 1 1 1
21 3BC07130 ONE-WAY CLUTCH 6 1 1 1
22 34806150 STOPPER 5 1 1 1
23 34907070 PIN,CLAW CASSETTE 2 2 2
24 36211500 GEAR,LEADING FEED JOINT 1 1 1
25 63511220 STOP RING,4 1 1 1
26 68721640 PULLEY 20,DUPLEX CONVEYING 1 1 1
27 72118141 SPRING,CLEANING BLADE 2 2 2
28 78620710 CLAW STOPPER 2 2 2

Quantity

230V120V 240V

Ref.

SP Part. No. Description

No.

3A7

Quantity

230V120V 240V

• Parts with "•" are component parts or sub-assemblies of the
assembly appearing immediately above them.

• Parts with "'" indicates the Service parts.

– 5 –

FIG. 3 PAPER TAKE-UP SECTION

$

HAD

™

^

Ú

*

%

¨

ı

fi

Œ

HAD

‰

ˆ

˜

HAD

„

Â

˛

˘



Å

HAD

¡

2



Í

˜

∏

◊

#

HAD



Ø

‚

HAD

&

HAD

¡

HAD

HAD

3A7

Î

Î

¡

‹

7

£

‹



HAD

5

¯

Ó

ˇ

HAD

ˆ

HAD



´

¤

¯

Á

KAL

Â



HAD

˜

(

3

HAD

1



°

Ó



ı

HAD

6

´

˜

KAL

¯

Ó

HAD



fl

– 6 –

¯



5

HAD

HAD

·

8

Ò

HAD

0

Ó

9

!



KAK

@

!

‡

)

⁄

BMF

Ç

¸

¿

Ô

˝

¿

›

4

Ï

HAD

⁄

FIG. 3 PAPER TAKE-UP SECTION

Ref.

SP Part. No. Description

No.

Quantity

230V120V 240V

Ref.

SP Part. No. Description

No.

3A7

Quantity

230V120V 240V

1 3A702020 FRONT FRAME 1 1 1
2 3A702030 REAR FRAME 1 1 1
3 3A702040 MOUNT BASE,CONVEYING 1 1 1
4 3A702130 REINFORCEMENT,ADF 1 1 1
5 3A702180 CUSHION,ADF 2 2 2
6 3A702210 ADJUSTING PLATE,PAPER FEED 1 1 1

'

7 3A704030 LOWER COVER,PAPER FEED 1 1 1

'

8 3A707020 PULLEY,PAPER FEED 1 1 1

9 3A707070 SHAFT,SEPARATION 1 1 1
10 3A707080 MOUNT,SEPARATION PULLEY 1 1 1
11 3A707090 HOLDER,SEPARATION PULLEY 2 2 2
12 3A707100 SPRING,SEPARATION PULLEY 2 2 2
13 3A707170 GUIDE,PAPER FEED 1 1 1
14 3A707181 GUIDE,LIFT 1 1 1
15 3A707190 SHAFT,LIFT 1 1 1
16 3A707200 SPRING,LIFT 1 1 1
17 3A707210 LEVER,LIFT 1 1 1

'

18 3A708010 UPPER ROLLER,REGISTRATION 1 1 1
19 3A708020 LOWER ROLLER,REGISTRATION 1 1 1
20 3A708030 GUIDE,READING 1 1 1
21 3A708040 SPRING,READING 2 2 2
22 3A708050 GUIDE,CONVEYING 1 1 1
23 3A708070 FILM,CONVEYING 2 2 2

'

24 3A708080 SHEET,READING 1 1 1

'

25 3A710010 UPPER ROLLER,EJECT 1 1 1
26 3A710020 LOWER ROLLER,EJECT 1 1 1
27 3A710030 UPPER GUIDE,EJECT 1 1 1
28 3A710040 LOWER GUIDE,EJECT 1 1 1
29 3A710050 FILM,EJECT 1 1 1
30 3A722010 MOUNT,MOTOR 1 1 1
31 3A722020 GEAR Z45/B16,IDLE 1 1 1
32 3A722030 PULLEY 19,REGISTRATION 1 1 1
33 3A722040 PULLEY 24,CONVEYING 2 2 2
34 3A722050 BELT 92,CONVEYING 1 1 1
35 3A722060 BELT 190,CONVEYING 1 1 1
36 3A722070 TENSION PLATE,EJECT 1 1 1
37 3A722080 TENSION PLATE,CONVEYING 1 1 1
38 3A722090 PULLEY,DRIVE 2 2 2
39 3A722100 GEAR 42/29 1 1 1
40 3A722110 CAM,LIFT 1 1 1

41 3A722120 GEAR 38,LIFT 1 1 1
42 3A722130 SQUARE SPRING,CAM 1 1 1

'

43 3A727010 MOTOR,PAPER FEED 2 2 2
44 3A727020 WIRE,PAPER FEED 1 1 1

'

45 3A728020 ADF SIZE DETECTION PCB 1 1 1
46 49027300 BUSHING 6 4 4 4

'

47 3AL27060 SWITCH,FEED 1 1 1
48 34806150 STOPPER 5 12 12 12
49 36706900 TORQUE LIMITER,PAPER FEED 1 1 1
50 3A707290 PAD,LIFT 1 1 1
51 63212210 STATIC ELIMINATOR,EJECT 1 1 1
52 63511220 STOP RING,4 1 1 1

'

53 63527020 SAFETY,SWITCH 1 1 1
54 65011310 GEAR 20,IDLE 1 1 1
55 72107160 BUSHING 6,LOWER REGISTRATION ROLLER 2 2 2
56 73210450 BUSH, 6 4 4 4
57 74808080 BEARING,686ZZNR 2 2 2
58 77706461 PRESSING SPRING 4 4 4
59 M1203200 OPEN BUSHING,OCB-375 1 1 1
60 M2105720 MINIATURE CLAMP,UAMS-05-2 3 3 3
61 M2105730 MINIATURE CLAMP,UAMS-07-0 5 5 5
62 3A707280 FILM,LIFT 1 1 1
63 3A708090 FILM B,CONVEYING 2 2 2

• Parts with "•" are component parts or sub-assemblies of the
assembly appearing immediately above them.

• Parts with "'" indicates the Service parts.

– 7 –

INDEX

Part. No.SP Description

Quantity

120V 240V

230V

Fig. No.

Part. No.SP Description

Quantity

120V 240V

230V

3A7

Fig. No.

29806810 BUSHING,6 REGISTRATION 2 2 2 2
3AL05120 LABEL,DF ORIGINAL CAUTION 1 1 1 2
3AL06090 CUSHION,ORIGINAL GUIDE 2 2 2 1

'

3AL27060 SWITCH,FEED 1 1 1 3

'

3A702010 BASE,ADF 1 1 1 1
3A702020 FRONT FRAME 1 1 1 3
3A702030 REAR FRAME 1 1 1 3
3A702040 MOUNT BASE,CONVEYING 1 1 1 3
3A702050 STAY,BASE 1 1 1 1
3A702060 FRONT RETAINER,BASE 1 1 1 1
3A702070 REAR RETAINER,BASE 1 1 1 1
3A702080 FRONT WORK PLATE,BASE 1 1 1 1
3A702090 REAR WORK PLATE,BASE 1 1 1 1
3A702100 FRONT SHAFT,RETAINER BASE 1 1 1 1
3A702110 REAR SHAFT,RETAINER BASE 2 2 2 1
3A702120 SPRING,PAPER FEED 2 2 2 1
3A702130 REINFORCEMENT,ADF 1 1 1 3
3A702140 MOUNT,PCB DRIVER 1 1 1 1

'

3A702150 ACTUATOR,ORIGINAL DETECTION 1 1 1 1
3A702180 CUSHION,ADF 2 2 2 3
3A702190 MOUNT,ORIGINAL DETECTION 1 1 1 1
3A702200 RETAINING PIN,PAPER FEED 1 1 1 1
3A702210 ADJUSTING PLATE,PAPER FEED 1 1 1 3
3A703010 LEFT HINGE 1 1 1 1
3A703020 RIGHT STAY,HINGE 1 1 1 1
3A703030 RETAINER,HINGE 1 1 1 1
3A703040 FULCRUM PIN,HINGE 1 1 1 1

'

3A704010 LOWER FRONT COVER 1 1 1 1

'

3A704020 LOWER REAR COVER 1 1 1 1

'

3A704030 LOWER COVER,PAPER FEED 1 1 1 3
3A704040 FRONT MOUNT,COVER 2 2 2 1
3A705020 LABEL,ORIGINAL SIZE(METRIC) 1 1 1
3A705030 LABEL,ORIGINAL SIZE(INCH) 1 1
3A705040 LABEL,ORIGINAL CURSOR(METRIC) 1 1 1
3A705050 LABEL,ORIGINAL CURSOR(INCH) 1 1

'

3A706010 TABLE,ORIGINAL 1 1 1 1

'

3A706020 FRONT CURSOR,ORIGINAL TABLE 1 1 1 1

'

3A706030 REAR CURSOR,ORIGINAL TABLE 1 1 1 1

'

3A706040 COVER,ORIGINAL TABLE 1 1 1 1
3A706050 RACK,ORIGINAL TABLE 2 2 2 1

3A706060 ACTUATOR,ORIGINAL TABLE 1 1 1 1

'

3A707010 COVER,PAPER FEED 1 1 1 2

'

3A707020 PULLEY,PAPER FEED 2 2 2 2,3

'

3A707030 PULLEY,LEADING FEED 1 1 1 2
3A707040 GUIDE,PAPER FEED PULLEY 1 1 1 2
3A707050 SHAFT,PAPER FEED 1 1 1 2
3A707060 SHAFT,LEADING FEED 1 1 1 2
3A707070 SHAFT,SEPARATION 1 1 1 3
3A707080 MOUNT,SEPARATION PULLEY 1 1 1 3
3A707090 HOLDER,SEPARATION PULLEY 2 2 2 3
3A707100 SPRING,SEPARATION PULLEY 2 2 2 3
3A707110 GEAR 30,PAPER FEED 1 1 1 2
3A707120 PULLEY,LEADING FEED 1 1 1 2
3A707130 BELT,LEADING FEED 1 1 1 2

'

3A707140 ACTUATOR,SIZE DETECTION 5 5 5 2
3A707150 MOUNT,ACTUATOR 1 1 1 2
3A707160 RETAINING PIN,PAPER FEED COVER 1 1 1 2
3A707170 GUIDE,PAPER FEED 1 1 1 3
3A707181 GUIDE,LIFT 1 1 1 3
3A707190 SHAFT,LIFT 1 1 1 3
3A707200 SPRING,LIFT 1 1 1 3
3A707210 LEVER,LIFT 1 1 1 3
3A707220 HANDLE,RELEASE 1 1 1 2
3A707230 SHAFT,RELEASE 1 1 1 2
3A707240 HOOK,RELEASE 2 2 2 2
3A707250 STOPPER,PAPER FEED 1 1 1 2
3A707260 FRONT SUPPORT PLATE,PAPER FEED 1 1 1 2
3A707270 REAR SUPPORT PLATE,PAPER FEED 1 1 1 2
3A707280 FILM,LIFT 1 1 1 3
3A707290 PAD,LIFT 1 1 1 3

'

3A708010 UPPER ROLLER,REGISTRATION 1 1 1 3
3A708020 LOWER ROLLER,REGISTRATION 1 1 1 3
3A708030 GUIDE,READING 1 1 1 3
3A708040 SPRING,READING 2 2 2 3
3A708050 GUIDE,CONVEYING 1 1 1 3

'

3A708060 MAT,ORIGINAL HOLDER 1 1 1 1
3A708070 FILM,CONVEYING 2 2 2 3

'

3A708080 SHEET,READING 1 1 1 3
3A708090 FILM B,CONVEYING 2 2 2 3

'

3A710010 UPPER ROLLER,EJECT 1 1 1 3

• Parts with "'" indicates the Service parts.

– 8 –

Part. No.SP Description

Quantity

120V 240V

230V

Fig. No.

Part. No.SP Description

Quantity

120V 240V

230V

3A7

Fig. No.

3A710020 LOWER ROLLER,EJECT 1 1 1 3
3A710030 UPPER GUIDE,EJECT 1 1 1 3
3A710040 LOWER GUIDE,EJECT 1 1 1 3
3A710050 FILM,EJECT 1 1 1 3
3A722010 MOUNT,MOTOR 1 1 1 3
3A722020 GEAR Z45/B16,IDLE 1 1 1 3
3A722030 PULLEY 19,REGISTRATION 1 1 1 3
3A722040 PULLEY 24,CONVEYING 2 2 2 3
3A722050 BELT 92,CONVEYING 1 1 1 3
3A722060 BELT 190,CONVEYING 1 1 1 3
3A722070 TENSION PLATE,EJECT 1 1 1 3
3A722080 TENSION PLATE,CONVEYING 1 1 1 3
3A722090 PULLEY,DRIVE 2 2 2 3
3A722100 GEAR 42/29 1 1 1 3
3A722110 CAM,LIFT 1 1 1 3
3A722120 GEAR 38,LIFT 1 1 1 3
3A722130 SQUARE SPRING,CAM 1 1 1 3

'

3A727010 MOTOR,PAPER FEED 2 2 2 3
3A727020 WIRE,PAPER FEED 1 1 1 3
3A727030 WIRE,INTERFACE 1 1 1 1
3A727040 JUNCTION WIRING,SIZE DETECTION 1 1 1 1

'

3A728010 DRIVER PCB 1 1 1 1

'

3A728020 ADF SIZE DETECTION PCB 1 1 1 3

3BC07130 ONE-WAY CLUTCH 6 1 1 1 2

34806150 STOPPER 5 15 15 15 1,2,3

34907070 PIN,CLAW CASSETTE 2 2 2 2

34920190 GROUND PLATE,FIXING UNIT 1 1 1 1

'

35327400 SWITCH,FEED 2 2 2 1

36211500 GEAR,LEADING FEED JOINT 1 1 1 2

36706900 TORQUE LIMITER,PAPER FEED 1 1 1 3

49027300 BUSHING 6 4 4 4 3

63212210 STATIC ELIMINATOR,EJECT 1 1 1 3

63511220 STOP RING,4 6 6 6 1,2,3

'

63527020 SAFETY,SWITCH 1 1 1 3

65011310 GEAR 20,IDLE 1 1 1 3

65907210 GEAR 20,CASSETTE 1 1 1 1

68721640 PULLEY 20,DUPLEX CONVEYING 1 1 1 2

72107160 BUSHING 6,LOWER REGISTRATION ROLLE 2 2 2 3

72118141 SPRING,CLEANING BLADE 2 2 2 2

73210450 BUSH, 6 4 4 4 3

74808080 BEARING,686ZZNR 2 2 2 3
77706461 PRESSING SPRING 4 4 4 3

78620710 CLAW STOPPER 2 2 2 2
M1203200 OPEN BUSHING,OCB-375 2 2 2 1,3
M2105040 NYLON CLAMP 6N,NK-6N 1 1 1 1
M2105720 MINIATURE CLAMP,UAMS-05-2 4 4 4 1,3
M2105730 MINIATURE CLAMP,UAMS-07-0 5 5 5 3
M2108000 SPACER,KGLS-3S 3 3 3 1
M2108080 SPACER,KGPS-3S 1 1 1 1
M2109050 LOCKING WIRE SADDLE,LWS-2Y 3 3 3 1

• Parts with "'" indicates the Service parts.

– 9 –
