Kyocera ST 3500P Diagram

R

ST-3500

ST-3500

PARTS LIST

Published in Apr. ’98

5BA70760

NOTE

1.Indicate parts number and machine model when placing an order.
eg. Parts Number Parts Name Machine Model Cycle Quantity

5BA08990 PAPER FEED COVER ST-3500 60Hz 1

2.Service calls and freight will be charged separately.

Parts List

ST-3500

CONTENTS

FIG. 1 LARGE CAPACITY TRAY I · · · · · · · · · · · · · · · · · · · · · · 2
FIG. 2 LARGE CAPACITY TRAY II · · · · · · · · · · · · · · · · · · · · · 4
FIG. 3 LARGE CAPACITY TRAY III · · · · · · · · · · · · · · · · · · · · · 6
FIG. 4 LARGE CAPACITY TRAY IV· · · · · · · · · · · · · · · · · · · · · 8
FIG. 5 LCT WIRING · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10

•INDEX · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 12

– 1 –

5BA

FIG. 1 LARGE CAPACITY TRAY I

– 2 –

FIG. 1 LARGE CAPACITY TRAY I

Ref.

Part. No. Description

No.

1 5BA07010 SENSOR MT PLATE CAULKING
2 5BA07020 STAPLE PAPER EXIT ACTUATOR
3 5A807760 PHOTO SENSOR
4 5BA07040 PAPER SEPARATE SHEET
5 5BA07050 PAPER STOPPER PLATE
6 5BA07060 LCT INTER WIRING(2)
7 5BA07070 LCT MT PLATE CAULKING
8 5BA07080 LCT MT SHAFT

9 5A816850 PAPER REGULATION CLAW
10 5BA07100 PAPER REGULATION PLATE
11 5A817270 CASSETTE INDICATION LABEL
12 5BA07120 SENSOR MT PLATE
13 5BA07130 HEATER INTER WIRING
14 5A807290 INNER HEATER
15 5BA07150 PAPER REGULATION SHAFT
16 5BA07160 LCT STAY(LOWER)
17 5BA07390 LCT WIRING(2)
18 5BA07180 PAPER FEED PANEL(FRONT)
19 5BA07190 LCT SETTING ROLLER(RIGHT)
20 5BA07200 BLADE LOCK SHEET
21 5BA07210 LCT SLIDE RAIL
22 5BA07220 LCT BOTTOM PLATE
23 5BA07230 LCT SETTING ROLLER(LEFT)
24 5BA07240 LCT ADJ ROLLER
25 5BA07250 PAPER FEED PANEL CAULKING(REAR)
26 5BA07260 LCT STAY(UPPER)
27 5BA07270 PAPER REGULATION BLOCK
28 5BA07290 CORD MT PLATE ASS’Y
29 5BA07310 LCT CONTROL WIRING
30 5A823190 CORD HOLDER
31 5BA07330 CORD MT PLATE CAULKING
32 5BA07350 LCT HEATER CORD
33 5BA07370 LCT DRIVE PCB ASS’Y
34 5BA07380 LCT WIRING(1)

5BA

Ref.

Part. No. Description

No.

a 5A810180 CROSS RECESSED PAN HEAD SCREW SEMS II M3X6
b 5A811530 CROSS RECESSED PAN HEAD SCREW SEMS II M4X6
c 5A809700 BIND SCREW M3X10
d 5BA07430 BIND SCREW M3X12
e 5A807430 BIND SCREW M4X6

f 5A807440 CROSS RECESSED PAN HEAD SCREW M3X4
g 5A807450 CROSS RECESSED PAN HEAD SCREW M3X6
h 5A815180 CROSS RECESSED PAN HEAD SCREW M3X10

i 5A807460 CROSS RECESSED PAN HEAD SCREW M4X6

j 5A810200 CROSS RECESSED PAN HEAD SCREW M4X8
k 5BA07500 CROSS RECESSED PAN HEAD SCREW M4X18
m 5BA07510 HEXAGON NUT(1)6
n 5A808630 E-RING 3
p 5A807910 WIRE SADDLE 17.2X5.7X7.9
q 5A814230 WIDE WIRE SADDLE
r 5BA07550 LOCKING CIRCUIT SUPPORT

– 3 –

5BA

FIG. 2 LARGE CAPACITY TRAY II

– 4 –

FIG. 2 LARGE CAPACITY TRAY II

Ref.

Part. No. Description

No.

1 5BA07570 LCT OPEN-CLOSE HINGE
2 5BA09010 PAPER SUPPLY DOOR
3 5A819620 SPRING MT PLATE
4 5BA07600 LIFT UP SPRING
5 5BA07610 OPERATION INTICATION LABEL
6 5BA07620 STOPPER MATERIAL
7 5BA09090 LCT OPEN-CLOSE KNOB
8 5BA08990 PAPER FEED COVER

9 5BA07650 LEVER SLIDE SCREW
10 5BA07660 LEVER SLIDE PLATE ASS’Y
11 5A816980 DOUBLE FEED PV PLATE
12 5BA07680 DRIVE COVER(LEFT)
13 5BA07690 PAPER FEED STOPPER
14 5BA07700 LEVER ROTARY SHAFT
15 5A818920 DOOR LOCK CLAW
16 5BA07720 LEVER PRESSURE SPRING
17 5BA09070 LCT COVER(REAR)
18 5BA07740 STOPPER RUBBER
19 5BA07750 PROTECT COVER(FRONT)
20 5BA09030 LCT COVER(FRONT)
21 5BA07770 PAPER INTICATION LABEL(1)
22 5BA09050 LCT COVER(RIGHT)
23 5BA07790 PROTECT COVER(RIGHT)

5BA

Ref.

Part. No. Description

No.

a 5A808350 CROSS RECESSED PAN HEAD TRUSS SCREW M4X6
b 5A808370 BIND SCREW M3X6
c 5A807460 CROSS RECESSED PAN HEAD SCREW M4X6
d 5A808380 CROSS RECESSED PAN HEAD TAPPING SCREW M3X8
e 5A810220

f 5A808640 E-RING 4

CROSS RECESSED PAN HEAD TAPPING SCREW M3X10

– 5 –

5BA

FIG. 3 LARGE CAPACITY TRAY III

– 6 –

FIG. 3 LARGE CAPACITY TRAY III

Ref.

Part. No. Description

No.

1 5A822000 SLIDE MATERIAL

2 5BA07870 PAPER ELEVATION PLATE

3 5A816980 DOUBLE FEED PV PLATE

4 5A912990 COLLAR

5 5BA07890 ROLLER

6 5BA07900 PAPER PS SHAFT

7 5BA07910 RF SHAFT

8 5BA07920 RF PLATE

9 5BA07930 SWITCH(1)
10 5BA07940 LEVER RELEASE SCREW
11 5A821000 WIRE REGULATION COVER
12 5BA07960 PULLEY ROTARY SHAFT
13 5A821010 WIRE ROLLER
14 5BA07980 LEVER RELEASE WIRE
15 5BA07990 LEVER RELEASE SHAFT CAULKING
16 5BA08000 ACTUATOR
17 5BA08010 LCT INTERLOCK SWITCH
18 5BA08020 LCT INTERLOCK WIRING
19 5BA08030 ELEVATION PULLEY
20 5BA08040 PULLEY SUPPORT PLATE CAULKING
21 5BA08050 BELT SUPPORT MATERIAL
22 5BA08060 BELT TENSION MATERIAL
23 5BA08070 ELEVATION BELT
24 5BA08080 PAPER EXIT ROLLER
25 5BA08090 PAPER INDICATION SHAFT CAULKING
26 5BA08100 PAPER INDICATION PLATE
27 5A817170 PAPER REMAIND DETECT SPRING
28 5BA08120 PAPER INDICATION MATERIAL
29 5BA08130 OILLESS METAL(A)
30 5BA08140 PARALLEL PIN(3X18)
31 5BA08150 ELEVATION SHAFT(A)
32 5A813790 PIN(A)(3X16)
33 5BA08170 DRUM DRIVE GEAR(A)(Z=64)
34 5BA08180 PAPER FEED MOTOR
35 5BA08190 ELEVATION WORM
36 5A811470 METAL
37 5A822570 PAPER EXIT GEAR (Z=21)
38 5A815900 PIN(B)(3X14)
39 5BA08230 ELEVATION SHAFT(D)
40 5BA08240 ELEVATION WORM WHEEL(Z=20)
41 5BA08250 GEAR(S)(Z=40,20)
42 5BA08260 ELEVATION SHAFT(E)
43 5BA08270 IDLER GEAR(2)(Z=16,54)
44 5BA08280 ELEVATING PCB CAULKING

5BA

Ref.

Part. No. Description

No.

a 5A810180 CROSS RECESSED PAN HEAD SCREW SEMS II M3X6
b 5BA08290 BIND SCREW M2X8
c 5A809690 BIND SCREW M3X6
d 5A807430 BIND SCREW M4X6
e 5BA08310 BIND SCREW M4X14

f 5A807450 CROSS RECESSED PAN HEAD SCREW M3X6
g 5BA08320 CROSS RECESSED PAN HEAD SCREW M3X20
h 5A807460 CROSS RECESSED PAN HEAD SCREW M4X6

i 5A810200 CROSS RECESSED PAN HEAD SCREW M4X8

j 5A810210 CROSS RECESSED PAN HEAD SCREW M4X10
k 5A813720 HEXAGON SOCKET SCREW(W POINT) M3X4
m 5A810230 HEXAGON SOCKET SCREW(W POINT) M4X6
n 5BA08360 HEXAGON NUT(1)30
p 5BA08370 HEXAGON NUT(1)10
q 5A816700 PLANE WASHER 3
r 5A808640 E-RING 4
s 5A807490 E-RING 6

t 5A816190 E-RING 8

– 7 –

5BA

FIG. 4 LARGE CAPACITY TRAY IV

– 8 –

FIG. 4 LARGE CAPACITY TRAY IV

Ref.

Part. No. Description

No.

1 5BA08410 PAPER CONVEYANCE SHAFT
2 5A815560 CONVEYANCE PRESSURE SPRING(2)
3 5A815610 SLIDE SHAFT HOLDER
4 5A815620 CONVEYANCE DRIVEN ROLLER(REAR)
5 5BA08450 PAPER FEED PROTECT MATERIAL
6 5BA08460 PAPER GUIDE PLATE(UPPER)
7 5BA08470 LCT INTER WIRING(1)
8 5A807760 PHOTO SENSOR

9 5A822250 SENSOR PRESSURE SPRING
10 5A815940 RESIST ACTUATOR
11 5A822240 SENSOR FIXED PLATE
12 5BA08510 PAPER FEED DRIVE SHAFT ASS’Y
13 5A821600 PIN(C)(3X11)
14 5A810950 DRIVE SHAFT HOLDER
15 5A811470 METAL
16 5A821560 DEVELOPING DRIVE GEAR (B)(Z=16)
17 5BA08550 RECYCLE GEAR(B)(Z=15)
18 5A822270 DOUBLE FEED DRIVE GEAR (Z=41,24)
19 5A822300 DELIVERY GEAR (Z=26)
20 5BA08580 DRIVE PCB CAULKING
21 5A822290 LCT CLUTCH(2)
22 5BA08600 DOUBLE FEED DRIVE SHAFT ASS’Y
23 5A813790 PIN(A)(3X16)
24 5BA08610 CLUTCH MT SHAFT
25 5A814450 PIN(B)(2X9.5)
26 5A821160 DELIEVERY ROLLER SHAFT ASS’Y
27 5A814320 STOPPER RING
28 5A814270 OILLESS METAL(A)
29 5A814430 PULLEY(1)(Z=15)
30 5A814410 ROLLER COLLAR(16X6)
31 5BA08680 PAPER DETECT ACTUATOR
32 5A814380 DELIVERY ROLLER(B)
33 5A814370 DOUBLE FEED PV RUBBER
34 5A814390 SLIDE SHAFT HOLDER(C)
35 5A814500 DELIVERY RUBBER(A)
36 5BA08730 DELIVERY ROLLER(A)
37 5BA08740 PAPER FEED OSCILLATE PLATE
38 5A821260 PAPER ENTER SHEET (UPPER)
39 5A821240 PAPER FEED OSCILLATE BELT (L=114)
40 5BA08770 DELIVERY SHAFT
41 5BA08780 PAPER CONVEYANCE ROLLER
42 5A821530 LCT REGULATION GEAR (Z=18)
43 5BA08800 PAPER FEED IDLER GEAR(Z=63,34)
44 5A811460 DEVELOPING DRIVE MOTOR
45 5A814660 SPACER(18X13)
46 5A821360 TORQUE LIMITTER
47 5A814690 PAPER FEED REVERSE GEAR(B)(Z=13)
48 5A821340 DOUBLE FEED PV SHAFT (1)
49 5A822220 DOUBLE FEED PV PLATE CAULKING
50 5A814680 LDLER GEAR(A)(Z=20)
51 5A814710 REVERSE ROLLER
52 5A814700 PAPER FEED REVERSE GEAR(A)(Z=12)
53 5BA08900 DOUBLE FEED PV SPRING
54 5A814600 OILLESS METAL
55 5A821370 PAPER FEED SPROCKET SPACER
56 5A811870 PIN (2X8)
57 5A821330 TORQUE LIMITTER SHAFT ASS’Y
58 5A822210 DOUBLE FEED PV PLATE (B)
59 5BA08960 DOUBLE FEED SUPPORT PLATE

5BA

Ref.

Part. No. Description

No.

a 5A807450 CROSS RECESSED PAN HEAD SCREW M3X6
b 5A815180 CROSS RECESSED PAN HEAD SCREW M3X10
c 5BA08970 CROSS RECESSED PAN HEAD SCREW M3X18
d 5BA08980 HEXAGON SOCKET SCREW(W POINT) M3X6
e 5A808640 E-RING 4

f 5A807490 E-RING 6
g 5A807910 WIRE SADDLE 17.2X5.7X7.9
h 5A811610 MINI CLAMP

i 5A810930 LOCKING CIRCUIT BOARD SUPPORT

j 5A819090 EDGE SADDLE

– 9 –

5BA

FIG. 5 LCT WIRING

– 10 –

FIG. 5 LCT WIRING

Ref.

Part. No. Description

No.

1 5BA07380 LCT WIRING(1)
2 5BA07390 LCT WIRING(2)
3 5BA08470 LCT INTER WIRING(1)
4 5BA07060 LCT INTER WIRING(2)
5 5BA08020 LCT INTERLOCK WIRING
6 5BA07130 HEATER INTER WIRING
7 5BA07310 LCT CONTROL WIRING
8 5BA07350 LCT HEATER CORD

Ref.

Part. No. Description

No.

5BA

– 11 –

5BA

INDEX

Part. No. Description Fig. No.

5A807290 INNER HEATER 1
5A807430 BIND SCREW M4X6 1, 3
5A807440 CROSS RECESSED PAN HEAD SCREW M3X4 1
5A807450 CROSS RECESSED PAN HEAD SCREW M3X6 1, 3, 4
5A807460 CROSS RECESSED PAN HEAD SCREW M4X6 1, 2, 3
5A807490 E-RING 6 3, 4
5A807760 PHOTO SENSOR 1, 4
5A807910 WIRE SADDLE 17.2X5.7X7.9 1, 4
5A808350 CROSS RECESSED PAN HEAD TRUSS SCREW M4X6 2
5A808370 BIND SCREW M3X6 2
5A808380 CROSS RECESSED PAN HEAD TAPPING SCREW M3X8 2
5A808630 E-RING 3 1
5A808640 E-RING 4 2, 3, 4
5A809690 BIND SCREW M3X6 3
5A809700 BIND SCREW M3X10 1
5A810180 CROSS RECESSED PAN HEAD SCREW SEMS II M3X6 1, 3
5A810200 CROSS RECESSED PAN HEAD SCREW M4X8 1, 3
5A810210 CROSS RECESSED PAN HEAD SCREW M4X10 3
5A810220 CROSS RECESSED PAN HEAD TAPPING SCREW M3X10 2
5A810230 HEXAGON SOCKET SCREW(W POINT) M4X6 3
5A810930 LOCKING CIRCUIT BOARD SUPPORT 4
5A810950 DRIVE SHAFT HOLDER 4
5A811460 DEVELOPING DRIVE MOTOR 4
5A811470 METAL 3, 4
5A811530 CROSS RECESSED PAN HEAD SCREW SEMS II M4X6 1
5A811610 MINI CLAMP 4
5A811870 PIN (2X8) 4
5A812990 COLLAR 3
5A813720 HEXAGON SOCKET SCREW(W POINT) M3X4 3
5A813790 PIN(A)(3X16) 3, 4
5A814230 WIDE WIRE SADDLE 1
5A814270 OILLESS METAL(A) 4
5A814320 STOPPER RING 4
5A814370 DOUBLE FEED PV RUBBER 4
5A814380 DELIVERY ROLLER(B) 4
5A814390 SLIDE SHAFT HOLDER(C) 4
5A814410 ROLLER COLLAR(16X6) 4
5A814430 PULLEY(1)(Z=15) 4
5A814450 PIN(B)(2X9.5) 4
5A814500 DELIVERY RUBBER(A) 4
5A814600 OILLESS METAL 4
5A814660 SPACER(18X13) 4
5A814680 LDLER GEAR(A)(Z=20) 4
5A814690 PAPER FEED REVERSE GEAR(B)(Z=13) 4
5A814700 PAPER FEED REVERSE GEAR(A)(Z=12) 4
5A814710 REVERSE ROLLER 4
5A815180 CROSS RECESSED PAN HEAD SCREW M3X10 1, 4
5A815560 CONVEYANCE PRESSURE SPRING(2) 4
5A815610 SLIDE SHAFT HOLDER 4
5A815620 CONVEYANCE DRIVEN ROLLER(REAR) 4
5A815900 PIN(B)(3X14) 3
5A815940 RESIST ACTUATOR 4
5A816190 E-RING 8 3
5A816700 PLANE WASHER 3 3
5A816850 PAPER REGULATION CLAW 1
5A816980 DOUBLE FEED PV PLATE 2, 3
5A817170 PAPER REMAIND DETECT SPRING 3
5A817270 CASSETTE INDICATION LABEL 1
5A818920 DOOR LOCK CLAW 2
5A819090 EDGE SADDLE 4
5A819620 SPRING MT PLATE 2
5A821000 WIRE REGULATION COVER 3
5A821010 WIRE ROLLER 3
5A821160 DELIEVERY ROLLER SHAFT ASS’Y 4
5A821240 PAPER FEED OSCILLATE BELT (L=114) 4
5A821260 PAPER ENTER SHEET (UPPER) 4
5A821330 TORQUE LIMITTER SHAFT ASS’Y 4
5A821340 DOUBLE FEED PV SHAFT (1) 4

– 12 –

Part. No. Description Fig. No.

5A821360 TORQUE LIMITTER 4
5A821370 PAPER FEED SPROCKET SPACER 4
5A821530 LCT REGULATION GEAR (Z=18) 4
5A821560 DEVELOPING DRIVE GEAR (B)(Z=16) 4
5A821600 PIN(C)(3X11) 4
5A822000 SLIDE MATERIAL 3
5A822210 DOUBLE FEED PV PLATE (B) 4
5A822220 DOUBLE FEED PV PLATE CAULKING 4
5A822240 SENSOR FIXED PLATE 4
5A822250 SENSOR PRESSURE SPRING 4
5A822270 DOUBLE FEED DRIVE GEAR (Z=41,24) 4
5A822290 LCT CLUTCH(2) 4
5A822300 DELIVERY GEAR (Z=26) 4
5A822570 PAPER EXIT GEAR (Z=21) 3
5A823190 CORD HOLDER 1
5BA07010 SENSOR MT PLATE CAULKING 1
5BA07020 STAPLE PAPER EXIT ACTUATOR 1
5BA07040 PAPER SEPARATE SHEET 1
5BA07050 PAPER STOPPER PLATE 1
5BA07060 LCT INTER WIRING(2) 1, 5
5BA07070 LCT MT PLATE CAULKING 1
5BA07080 LCT MT SHAFT 1
5BA07100 PAPER REGULATION PLATE 1
5BA07120 SENSOR MT PLATE 1
5BA07130 HEATER INTER WIRING 1, 5
5BA07150 PAPER REGULATION SHAFT 1
5BA07160 LCT STAY(LOWER) 1
5BA07180 PAPER FEED PANEL(FRONT) 1
5BA07190 LCT SETTING ROLLER(RIGHT) 1
5BA07200 BLADE LOCK SHEET 1
5BA07210 LCT SLIDE RAIL 1
5BA07220 LCT BOTTOM PLATE 1
5BA07230 LCT SETTING ROLLER(LEFT) 1
5BA07240 LCT ADJ ROLLER 1
5BA07250 PAPER FEED PANEL CAULKING(REAR) 1
5BA07260 LCT STAY(UPPER) 1
5BA07270 PAPER REGULATION BLOCK 1
5BA07290 CORD MT PLATE ASS’Y 1
5BA07310 LCT CONTROL WIRING 1, 5
5BA07330 CORD MT PLATE CAULKING 1
5BA07350 LCT HEATER CORD 1, 5
5BA07370 LCT DRIVE PCB ASS’Y 1
5BA07380 LCT WIRING(1) 1, 5
5BA07390 LCT WIRING(2) 1, 5
5BA07430 BIND SCREW M3X12 1
5BA07500 CROSS RECESSED PAN HEAD SCREW M4X18 1
5BA07510 HEXAGON NUT(1)6 1
5BA07550 LOCKING CIRCUIT SUPPORT 1
5BA07570 LCT OPEN-CLOSE HINGE 2
5BA07600 LIFT UP SPRING 2
5BA07610 OPERATION INTICATION LABEL 2
5BA07620 STOPPER MATERIAL 2
5BA07650 LEVER SLIDE SCREW 2
5BA07660 LEVER SLIDE PLATE ASS’Y 2
5BA07680 DRIVE COVER(LEFT) 2
5BA07690 PAPER FEED STOPPER 2
5BA07700 LEVER ROTARY SHAFT 2
5BA07720 LEVER PRESSURE SPRING 2
5BA07740 STOPPER RUBBER 2
5BA07750 PROTECT COVER(FRONT) 2
5BA07770 PAPER INTICATION LABEL(1) 2
5BA07790 PROTECT COVER(RIGHT) 2
5BA07870 PAPER ELEVATION PLATE 3
5BA07890 ROLLER 3
5BA07900 PAPER PS SHAFT 3
5BA07910 RF SHAFT 3
5BA07920 RF PLATE 3
5BA07930 SWITCH(1) 3

5BA

– 13 –

5BA

Part. No. Description Fig. No.

5BA07940 LEVER RELEASE SCREW 3
5BA07960 PULLEY ROTARY SHAFT 3
5BA07980 LEVER RELEASE WIRE 3
5BA07990 LEVER RELEASE SHAFT CAULKING 3
5BA08000 ACTUATOR 3
5BA08010 LCT INTERLOCK SWITCH 3
5BA08020 LCT INTERLOCK WIRING 3, 5
5BA08030 ELEVATION PULLEY 3
5BA08040 PULLEY SUPPORT PLATE CAULKING 3
5BA08050 BELT SUPPORT MATERIAL 3
5BA08060 BELT TENSION MATERIAL 3
5BA08070 ELEVATION BELT 3
5BA08080 PAPER EXIT ROLLER 3
5BA08090 PAPER INDICATION SHAFT CAULKING 3
5BA08100 PAPER INDICATION PLATE 3
5BA08120 PAPER INDICATION MATERIAL 3
5BA08130 OILLESS METAL(A) 3
5BA08140 PARALLEL PIN(3X18) 3
5BA08150 ELEVATION SHAFT(A) 3
5BA08170 DRUM DRIVE GEAR(A)(Z=64) 3
5BA08180 PAPER FEED MOTOR 3
5BA08190 ELEVATION WORM 3
5BA08230 ELEVATION SHAFT(D) 3
5BA08240 ELEVATION WORM WHEEL(Z=20) 3
5BA08250 GEAR(S)(Z=40,20) 3
5BA08260 ELEVATION SHAFT(E) 3
5BA08270 IDLER GEAR(2)(Z=16,54) 3
5BA08280 ELEVATING PCB CAULKING 3
5BA08290 BIND SCREW M2X8 3
5BA08310 BIND SCREW M4X14 3
5BA08320 CROSS RECESSED PAN HEAD SCREW M3X20 3
5BA08360 HEXAGON NUT(1)30 3
5BA08370 HEXAGON NUT(1)10 3
5BA08410 PAPER CONVEYANCE SHAFT 4
5BA08450 PAPER FEED PROTECT MATERIAL 4
5BA08460 PAPER GUIDE PLATE(UPPER) 4
5BA08470 LCT INTER WIRING(1) 4, 5
5BA08510 PAPER FEED DRIVE SHAFT ASS’Y 4
5BA08550 RECYCLE GEAR(B)(Z=15) 4
5BA08580 DRIVE PCB CAULKING 4
5BA08600 DOUBLE FEED DRIVE SHAFT ASS’Y 4
5BA08610 CLUTCH MT SHAFT 4
5BA08680 PAPER DETECT ACTUATOR 4
5BA08730 DELIVERY ROLLER(A) 4
5BA08740 PAPER FEED OSCILLATE PLATE 4
5BA08770 DELIVERY SHAFT 4
5BA08780 PAPER CONVEYANCE ROLLER 4
5BA08800 PAPER FEED IDLER GEAR(Z=63,34) 4
5BA08900 DOUBLE FEED PV SPRING 4
5BA08960 DOUBLE FEED SUPPORT PLATE 4
5BA08970 CROSS RECESSED PAN HEAD SCREW M3X18 4
5BA08980 HEXAGON SOCKET SCREW(W POINT) M3X6 4
5BA08990 PAPER FEED COVER 2
5BA09010 PAPER SUPPLY DOOR 2
5BA09030 LCT COVER(FRONT) 2
5BA09050 LCT COVER(RIGHT) 2
5BA09070 LCT COVER(REAR) 2
5BA09090 LCT OPEN-CLOSE KNOB 2

– 14 –

©

MITA COPYSTAR AMERICA, INC.

Headquarters:

225 Sand Road, P.O. Box 40008
Fairfield, New Jersey 07004-0008
TEL : [phone]
FAX : [phone]

New York Show Room:

149 West 51st street,
New York, NY 10019
TEL : [phone]
FAX : [phone]

Northeastern Region:

225 Sand Road, P.O. Box 40008
Fairfield, New Jersey 07004-0008
TEL : [phone]
FAX : [phone]

Midwestern Region:

225 Spring Lake Drive,
Itasca, Illinois 60143
TEL : [phone]
FAX : [phone]

Western Region:

14101 Alton Parkway,
P.O.Box 57006, Irvine,
California 92618-7006
TEL : [phone]
FAX : [phone]

Southeastern Region:

1500 Oakbrook Drive,
Norcross, Georgia 30093
TEL : [phone]
FAX : [phone]

Southwestern Region:

2825 West Story Road,
Irving, Texas 75038-5299
TEL : [phone]
FAX : [phone]

Dallas Parts Distribution Center
& National Training Center:

2825 West Story Road,
Irving, Texas 75038-5299
TEL : [phone]
FAX : [phone]

MITA COPYSTAR CANADA, LTD.

6120 Kestrel Road,
Mississauga, Ontario L5T 1S8
TEL : [phone]
FAX : [phone]

MITA COPYSTAR MEXICO, S.A. DE C.V.

Av. 16 de Septiembre #407
Col. Santa Inés,
Delegación Azcapotzalco
México, D.F. C.P. 02130
TEL : [phone]
FAX : [phone]

MITA COPYSTAR SOUTH AMERICA S.A.

Av. Mitre 1345 Florida (1602)
Pcia, Buenos Aires, Argentina.
TEL : [phone]
FAX : [phone]

1998 MITA INDUSTRIAL CO., LTD.

MITA and are registered trademarks of MITA INDUSTRIAL CO., LTD.

Printed in U.S.A.
