Kyocera ST 2500 PF Diagram

ST-2500

PF-620

PARTS LIST

Published in Oct.’02

5GD70771

Revision1

Parts List

ST-2500

PF-620

NOTE

1.Indicate parts number and machine model when placing an order.
eg. Parts Number Parts Name Machine Model Cycle Quantity

5GD20020 RIGHT COVER ST-2500 60Hz 1

2.Service calls and freight will be charged separately.

3.Symbols in the "Parts Number" column.

• Parts with "'" indicates the spare parts and the parts without "'" can not be supplied.

4.See the last page of this parts list for the classification of the screws in the illustrations.

CONTENTS

FIG. 1 HOUSING · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
FIG. 2 PAPER TAKE-UP SECTION (A) · · · · · · · · · · · · · · · · · · · · · · · · · 4
FIG. 3 PAPER TAKE-UP SECTION (B) · · · · · · · · · · · · · · · · · · · · · · · · · 6
FIG. 4 DRIVE SECTION · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 8
FIG. 5 PAPER TRAY UNIT (A)· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10
FIG. 6 PAPER TRAY UNIT (B)· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 12

• INDEX· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 14

– 1 –

FIG. 1 HOUSING

5GD-1/5G5

08

04

09

07

06

21

4012

08

05

03

4021

04

3504

03

21

4012

01

02

04

20

10

19

19

08

11

20

17

16

18

13

4012

12

21

15

04

08

14

10

– 2 –

21

FIG. 1 HOUSING

Ref.

SP Part. No. Description

No.

1 5GD20500 STOPPER 1
2 5GD20050 SHEET 1
3 5GD10100 EARTH GROUND 2
4 5GD20470 SHOULDER SCREW 4

'

5 5GD10050 COVER 1

'

6 5GD10060 COVER 1
7 5GD10080 SHOULDER SCREW 1

'

8 5GD10070 SEAL 4

'

9 5GD20030 LEFT COVER 1
10 5GD20490 COVER 2
11 5GD10190 SCREW 4
12 5GC10420 STOP PLATE 4
13 5GD10090 EARTH GROUND 1

'

14 5GD20020 RIGHT COVER 1
15 5GD20320 SHEET 1
16 5GD20460 LABEL WARNING 1
17 5GD20310 SHEET 1

'

18 5GD20300 COVER 1
19 5GD20480 SHOULDER SCREW 2

20 5GD10250 CASTOR 4

'

21 5GD20720 BRACKET 4

Quantity

Ref.

SP Part. No. Description

No.

5GD-1/5G5

Quantity

• Parts with "'" indicates the spare parts.

– 3 –

FIG. 2 PAPER TAKE-UP SECTION (A)

5GD-1/5G5

01

P2CL

15

17

16

09

9111

19

11

07

0203

13

P1CL

06

9111

14

04

05

9111

16

9111

10

03

15

09

9111

11

LS2

9111

12

08

04

9111

07

13

06

9111

04

14

05

15

03

LS1

02

9111

04

RSEN

1309

EMP

4012

1309

18

PPS1

18

02

S1

PPS0

01

4012

18

– 4 –

FIG. 2 PAPER TAKE-UP SECTION (A)

Ref.

SP Part. No. Description

No.

1 5GD20270 HOLDER 2

'

2 5GD20350 PHOTO INTERRUPTER 2

'

3 5GD10020 PHOTO INTERRUPTER 2

'

4 5GD20130 BUSHING 4

5 5GD20220 TENSION SPRING 2

'

6 5GD20210 PULLEY 20T 2

7 5GD20230 TENSION SPRING 2

'

8 5GD20260 TIMING BELT 1

'

9 5GD20370 CLUTCH 1

'

10 5GD20240 PULLEY 18T 1
11 5GD20200 ARM 2

'

12 5GD01020 ROLLER 1

'

13 5GD10180 GEAR 2
14 5GD20190 ARM 2
15 5GD20180 STOPPER RING 3

'

16 5GD01030 ROLLER 2

'

17 5GD20330 GEAR 1

'

18 5GD20340 PWB ASSY 3

'

19 5GD10310 WIRE HARNESS ASS'Y 1

Quantity

Ref.

SP Part. No. Description

No.

5GD-1/5G5

Quantity

• Parts with "'" indicates the spare parts.

– 5 –

FIG. 3 PAPER TAKE-UP SECTION (B)

08

4012

10

RCL

19

4012

SIDE

5GD-1/5G5

05

04

9108

11

BCL

9106

0508

0512

23

9111

22

9111

09

08

04

20

04

0508

08

07

21

06

29

0509

04

25

26

9111

04

9108

9103

24

12

0512

0512

03

9103

28

0512

27

13

01

0512

14

15

1305

04

9111

16

18

16

02

4012

01

17

4012

4012

08

9151

4012

– 6 –

FIG. 3 PAPER TAKE-UP SECTION (B)

Ref.

SP Part. No. Description

No.

'

1 5GD20280 ROLLER 2

2 5GD20290 PLATE SPRING 1

'

3 5GD10170 ROLLER 1

'

4 5GD20130 BUSHING 6

'

5 5GD20400 PHOTO INTERRUPTER 1

'

6 5GD10130 GEAR 1

7 5GD10140 SLEEVE 1

'

8 5GD20150 BUSH 4

'

9 5GD10120 GEAR 1

'

10 5GD20380 CLUTCH 1

'

11 5GD20390 CLUTCH 1
12 5GD10150 GUIDE 1
13 5GD10160 LEVER 1

'

14 5GD01050 ARBOR ASSY 1

'

15 5GD01060 ROLLER 1
16 5GD20180 STOPPER RING 2

'

17 5GD20250 ARBOR 1

'

18 5GD01040 ROLLER 1

'

19 5GD20560 GEAR 26T 1

'

20 5GD20570 PULLEY 20T 1

'

21 5GD20580 GEAR 18T 1

'

22 5GD20590 GEAR 24T 1

'

23 5GD20600 GEAR 1

'

24 5GD20610 PLY GEAR 14/26 1

'

25 5GD20620 PLY GEAR 14/26 1

'

26 5GD20630 PULLEY 14T 1

'

27 5GD20550 TENSION SPRING 1

'

28 5GD10270 METAL FRAME 1

'

29 5GD10350 FRAME ASSY 1

Quantity

Ref.

SP Part. No. Description

No.

5GD-1/5G5

Quantity

• Parts with "'" indicates the spare parts.

– 7 –

FIG. 4 DRIVE SECTION

5GD-1/5G5

9111

04

9111

3501

07

05

9111

9111

22

9111

14

1379

9111

15

9111

06

05

0509

05

9111

0509

04

3501

9111

05

3501

16

9111

22

9106

14

RS2

3501

RS1

9106

03

9111

03

17

02

01

13

3504

3501

1309

PWB-A

12

HMOT

3501

3501

11

21

20 18

9111

9111

03

FRONT

10

9151

19

08

EMOT

21

9111

20

9111

– 8 –

3501

1210

09

1210

09

FIG. 4 DRIVE SECTION

Ref.

SP Part. No. Description

No.

'

1 5GD10220

'

1 5G510030 IC (PF-620) 1

2 5GD10240 WIRE HARNESS ASSY 1

'

3 5GD20400 PHOTO INTERRUPTER 3

'

4 5GD20140 GEAR 58T 2

'

5 5GD20130 BUSHING 4

'

6 5GD20120 GEAR 72T 1

'

7 5GD20110 GEAR 72T 1

'

8 5GD20360 MOTOR 1

9 5GD20060 MAGNET 2

'

10 5GD10200 PULLEY 1

'

11 5GD10210 MOTOR 1

'

12 5GD01070 PWB ASSY (PWB-A) 1
13 5GD10110 GUIDE 1

'

14 5GD20640 GEAR 16/32T 2

'

15 5GD20650 GEAR 16/32T 1

'

16 5GD20660 GEAR 16/32T 1

'

17 5GD20670 ARBOR 1

'

18 5GD20680 GEAR 1

'

19 5GD20690 PULLEY 18 1

'

20 5GD10340 JOINT 2

'

21 5GD10330 PRESSURE SPRING 2

'

22 5GD10320 SHAFT 2

IC (ST-2500)

Quantity

1

Ref.

SP Part. No. Description

No.

5GD-1/5G5

Quantity

• Parts with "'" indicates the spare parts.

– 9 –

FIG. 5 PAPER TRAY UNIT (A)

08

07

02

02

01

1723

08

4021

01

5GD-1/5G5

4022

4022

1723

06

05

03

4022

04

– 10 –

FIG. 5 PAPER TRAY UNIT (A)

Ref.

SP Part. No. Description

No.

1 5GD20160 POLYESER FILM 2

2 5GD20170 GUIDE 2

3 5GD20040 STOPPER 1

'

4 5GD10030 COVER 1

5 5GD10040 HANDLE 1

6 5GD20450 LABEL LETTER 1

'

7 5GD10010 HEATER ASSY 1

'

8 5GD10290 RAIL 2

Quantity

Ref.

SP Part. No. Description

No.

5GD-1/5G5

Quantity

• Parts with "'" indicates the spare parts.

– 11 –

FIG. 6 PAPER TRAY UNIT (B)

5GD-1/5G5

9151

0245

0531

9151

0245

0531

9111

14

9111

9111

9151

9151

14

02

9151

9111

04

15

9151

9151

9151

05

9151

9151

9151

15

9151

9151

9151

9151

9151

9151

9151

9151

15

06 08

01

09

9151

9151

9151

11

9151

9151

15

13

03

04

05

– 12 –

07

10

12

FIG. 6 PAPER TRAY UNIT (B)

Ref.

SP Part. No. Description

No.

'

1 5GD01010 ROLLER ASSY 1

2 5GD20080 TORSION SPRING 1

3 5GD20070 TORSION SPRING 1

'

4 5GD20090 PULLEY 2

'

5 5GD20100 TIMING BELT 2

6 5GD20410 WIRING SADDLE 2

7 5GD20420 WIRING SADDLE 6

8 5GD20010 WIRING SADDLE 1

9 5GD20430 CORD CLAMP 4
10 5BM09840 WIRING SADDLE 2
11 5BM09880 CABLE TIE 3
12 5GD20440 CORD CLAMP 1
13 5GD10230 EDGE COVER 2

'

14 5GD20700 CAM 2

'

15 5GD20710 GEAR 24T 8

Quantity

Ref.

SP Part. No. Description

No.

5GD-1/5G5

Quantity

• Parts with "'" indicates the spare parts.

– 13 –

INDEX

5GD-1/5G5

Part. No.SP Description

5BM09840 WIRING SADDLE 2 6
5BM09880 CABLE TIE 3 6
5GC10420 STOP PLATE 4 1

'

5GD01010 ROLLER ASSY 1 6

'

5GD01020 ROLLER 1 2

'

5GD01030 ROLLER 2 2

'

5GD01040 ROLLER 1 3

'

5GD01050 ARBOR ASSY 1 3

'

5GD01060 ROLLER 1 3

'

5GD01070 PWB ASSY (PWB-A) 1 4

'

5GD10010 HEATER ASSY 1 5

'

5GD10020 PHOTO INTERRUPTER 2 2

'

5GD10030 COVER 1 5
5GD10040 HANDLE 1 5

'

5GD10050 COVER 1 1

'

5GD10060 COVER 1 1

'

5GD10070 SEAL 4 1
5GD10080 SHOULDER SCREW 1 1
5GD10090 EARTH GROUND 1 1
5GD10100 EARTH GROUND 2 1
5GD10110 GUIDE 1 4

'

5GD10120 GEAR 1 3

'

5GD10130 GEAR 1 3
5GD10140 SLEEVE 1 3
5GD10150 GUIDE 1 3
5GD10160 LEVER 1 3

'

5GD10170 ROLLER 1 3

'

5GD10180 GEAR 2 2
5GD10190 SCREW 4 1

'

5GD10200 PULLEY 1 4

'

5GD10210 MOTOR 1 4

'

5GD10220
5GD10230 EDGE COVER 2 6
5GD10240 WIRE HARNESS ASSY 1 4

5GD10250 CASTOR 4 1

'

5GD10270 METAL FRAME 1 3

'

5GD10290 RAIL 2 5

'

5GD10310 WIRE HARNESS ASS'Y 1 2

'

5GD10320 SHAFT 2 4

'

5GD10330 PRESSURE SPRING 2 4

IC (ST-2500)

Quantity

14

Fig. No.

Part. No.SP Description

'

5GD10340 JOINT 2 4

'

5GD10350 FRAME ASSY 1 3

5GD20010 WIRING SADDLE 1 6

'

5GD20020 RIGHT COVER 1 1

'

5GD20030 LEFT COVER 1 1
5GD20040 STOPPER 1 5
5GD20050 SHEET 1 1
5GD20060 MAGNET 2 4
5GD20070 TORSION SPRING 1 6
5GD20080 TORSION SPRING 1 6

'

5GD20090 PULLEY 2 6

'

5GD20100 TIMING BELT 2 6

'

5GD20110 GEAR 72T 1 4

'

5GD20120 GEAR 72T 1 4

'

5GD20130 BUSHING 14 2,3,4

'

5GD20140 GEAR 58T 2 4

'

5GD20150 BUSH 4 3
5GD20160 POLYESER FILM 2 5
5GD20170 GUIDE 2 5
5GD20180 STOPPER RING 5 2,3
5GD20190 ARM 2 2
5GD20200 ARM 2 2

'

5GD20210 PULLEY 20T 2 2
5GD20220 TENSION SPRING 2 2
5GD20230 TENSION SPRING 2 2

'

5GD20240 PULLEY 18T 1 2

'

5GD20250 ARBOR 1 3

'

5GD20260 TIMING BELT 1 2
5GD20270 HOLDER 2 2

'

5GD20280 ROLLER 2 3
5GD20290 PLATE SPRING 1 3

'

5GD20300 COVER 1 1
5GD20310 SHEET 1 1
5GD20320 SHEET 1 1

'

5GD20330 GEAR 1 2

'

5GD20340 PWB ASSY 3 2

'

5GD20350 PHOTO INTERRUPTER 2 2

'

5GD20360 MOTOR 1 4

'

5GD20370 CLUTCH 1 2

'

5GD20380 CLUTCH 1 3

Quantity

Fig. No.

• Parts with "'" indicates the spare parts.

– 14 –

5GD-1/5G5

Part. No.SP Description

'

5GD20390 CLUTCH 1 3

'

5GD20400 PHOTO INTERRUPTER 4 3,4
5GD20410 WIRING SADDLE 2 6
5GD20420 WIRING SADDLE 6 6
5GD20430 CORD CLAMP 4 6
5GD20440 CORD CLAMP 1 6
5GD20450 LABEL LETTER 1 5
5GD20460 LABEL WARNING 1 1
5GD20470 SHOULDER SCREW 4 1
5GD20480 SHOULDER SCREW 2 1
5GD20490 COVER 2 1
5GD20500 STOPPER 1 1

'

5GD20550 TENSION SPRING 1 3

'

5GD20560 GEAR 26T 1 3

'

5GD20570 PULLEY 20T 1 3

'

5GD20580 GEAR 18T 1 3

'

5GD20590 GEAR 24T 1 3

'

5GD20600 GEAR 1 3

'

5GD20610 PLY GEAR 14/26 1 3

'

5GD20620 PLY GEAR 14/26 1 3

'

5GD20630 PULLEY 14T 1 3

'

5GD20640 GEAR 16/32T 2 4

'

5GD20650 GEAR 16/32T 1 4

'

5GD20660 GEAR 16/32T 1 4

'

5GD20670 ARBOR 1 3

'

5GD20680 GEAR 1 4

'

5GD20690 PULLEY 18 1 4

'

5GD20700 CAM 2 6

'

5GD20710 GEAR 24T 8 6

'

5GD20720 BRACKET 4 1

'

5G510030 IC (PF-620) 1 4

Quantity

Fig. No.

Part. No.SP Description

Quantity

Fig. No.

• Parts with "'" indicates the spare parts.

– 15 –

CLASSIFICATION OF THE SCREWS IN ILLUSTRATION

REF. ITEM # DESCRIPTION

0203 5F931490 PIN
0245 5GD20540 SPRING ROLL PIN
0508 50355060 PIN M20X10(STAINLESS)
0509 50355070 PIN M20X12(STAINLESS)
0512 50356100 PIN M20X8(STAINLESS)
0531 5GD20530 PIN
1210 50355140 SCREW M3X8 (P-ZN(C))
1305 50355160 SCREW M3X6 (P-ZN(C)
1309 50355180 SCREW M3X10 (P-ZN(C))
1723 5GD20510 SCREW
3501 50355570 TAPPING SCREW M3X6(P-ZN(C))
3504 50355590 TAPPING SCREW M3X8(P-ZN(C))
4012 50356260 TAPPING SCREW M3X6(P-ZN(C))
4021 50355830 TAPPING SCREW M3X8(P-CD)
4022 5GD20520 TAPPING SCREW
9103 5BM10010 RETAINING RING E-2
9106 5BM10020 RETAINING RING E-3
9108 5BM10030 RETAINING RING E-4
9111 5BM10040 RETAINING RING E-5
9151 5BM10060 RETAINING RING E-7

330/331

KYOCERA MITA AMERICA, INC.

Headquarters:

225 Sand Road, P.O. Box 40008
Fairfield, New Jersey 07004-0008
TEL : [phone]
FAX : [phone]

New York Show Room:

1410 Broadway 23rd floor
New York, NY 10018
TEL : [phone]
FAX : [phone]

Northeastern Region:

225 Sand Road, P.O. Box 40008
Fairfield, New Jersey 07004-0008
TEL : [phone]
FAX : [phone]

Midwestern Region:

201 Hansen Court Suite 119
Wood Dale, Illinois 60191
TEL : [phone]
FAX : [phone]

KYOCERA MITA CANADA, LTD.

6120 Kestrel Road, Mississauga,
Ontario L5T 1S8, Canada
TEL : [phone]
FAX : [phone]

Western Region:

14101 Alton Parkway,
Irvine, California 92618-7006
TEL : [phone]
FAX : [phone]

Southeastern Region:

1500 Oakbrook Drive,
Norcross, Georgia 30093
TEL : [phone]
FAX : [phone]

Southwestern Region:

2825 West Story Road,
Irving, Texas 75038-5299
TEL : [phone]
FAX : [phone]

Dallas Parts Distribution Center
& National Training Center:

2825 West Story Road,
Irving, Texas 75038-5299
TEL : [phone]
FAX : [phone]

KYOCERA MITA MEXICO, S.A. DE C.V.

Av. 16 de Septiembre #407
Col. Santa Inés,
02130 Azcapotzalco
México, D.F. México
TEL : [phone]
FAX : [phone]

© 2002 KYOCERA MITA CORPORATION

is a trademark of Kyocera Corporation
is a registered trademark of KYOCERA MITA CORPORATION

Printed in U.S.A.
