KYE SYSTEMS GMZI4 User Manual

ENGLISH

Hardware Installation

1. Install two AA batteries each into the mouse and keyboard.

2. Plug in your USB receiver to a USB port of your PC.

Software Installation

1. Place your CD driver in your PC drive for software installation.

2. Follow the instructions on the screen to finish the software
installation.

Replace Batteries

If the mouse or keyboard does not work properly, then the batteries
have lost their charge, so you need to replace them.

Warning: do not mix or use different types of batteries at the same time.

ID Channel Setting

The channel ID is factory preset. The green LED (data transmission
indicator) will be lit constantly when the wireless device is in normal
operation. In case your wireless devices do not work, reset the ID
channel by:

1. Press the connect button on the receiver and the LED will be blinking
for connection.

2. Press the connect button on each wireless device within 20 seconds
and observe if the LED light on the receiver has gone off. If yes, it
means the wireless device is ready for use.

1

ENGLISH

“Warning (Trouble shooting)

1. The wireless desktop set provides 256 ID codes, and it selects the ID
# for your wireless devices. You can only set up one wireless desktop
at a time. If you have another 27Mhz wireless desktop set within 10
square meters, there may be interference between the wireless
devices.

2. Although the mouse has been granted eye safety certification, it is
strongly suggested that direct eye contact with the laser lens be
avoided.

3. To use MSN and Lock function, the software must be installed.

4. To re-program other media programs, software installation is
required.

Mouse Factory Setting

Button Assignments

1. Left Button: Provides traditional
mouse functions like click, double
click and drag.

2. Right Button: Provides traditional
mouse click function

3. Magic-Roller: Scroll the button to surf
the Internet and Windows documents.

2
