HDMI-PIP-4P
4 x 1 HDMI Seamless Quad PIP Scaler
INSTRUCTION MANUAL
118 W. Streetsboro Street, Ste. 125 | Hudson, OH 44236 | Toll Free: (866) 865-7737
V.1.3
SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of fi re, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power off and disconnect unit from AC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
fl ow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualifi ed service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports fi rst, then remove the power cable; fi nally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualifi er service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL
TABLE OF CONTENTS
CONTENTS
Introduction & Contents ........................................................1
Features ................................................................................ 2
Specifi cations ........................................................................ 2
Operation Controls and Functions ........................................ 3
Front Panel Connection ..................................................3
Rear Panel Connection ...................................................3
Remote Control ...............................................................4
RS-232 Protocols ................................................................ 5
OSD Menu ...........................................................................6
Connection and Installation .................................................10
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update
or to keep current the information contained in this document.
We reserve the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part
translated into any language or computer fi le, in any form or by
any means—electronic, mechanical, magnetic, optical, chemical,
manual, or otherwise—without express written permission and
consent
© Copyright 2012. All Rights Reserved.
Version 1.3 MAY2013
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
INTRODUCTION
The 4 x 1 HDMI Seamless Quad PIP Scaler is a high performance, high speed zooming/shrinking system that can be easily confi gure and
control for quad or picture-in-picture video processing. Allowing 4 different input sources to be freely selected and arranged on one single
display with supporting resolution up to WUXGA@60RB, 1080p and audio up to 8Ch 192kHz for both input and output. Screen setting hot
keys with IR and RS-232 allows instant control and switching on the output display.
PACKAGE CONTENTS
1 x 4 by 1 HDMI Seamless Quad PIP Scaler
1 x Remote Control (ANI-124)
1 x 12V/3A DC Power Adaptor
Users Guide
1
FEATURES
FEATURES
• Seamless switching between channels and windows
• Zoom and Shrink 4CH input image and/or overlay
• Supports PIP, POP and multi-windows display
• Supports OSD, RS-232 Remote and on-panel controls
• Fade-In-Out, Chromakey, Mirror and Rotation (90˚ left & right and 180˚ up & down) functions
• 8 Screen setting hot keys and extra 4 customized favorite screen setting
• Support individual channel size and position adjustment
SYSTEM REQUIREMENTS
• Input source equipment such as DVD/Blu-ray players and PC/NB devices and output HD TV/monitor.
SPECIFICATIONS
• Video Bandwidth: 225MHz/6.75Gbps
• Input Port: 4x HDMI
• Output Port: 1 x HDMI
• ESD Protection: Human body model: ±8kV (air-gap discharge) / ±4kV (contact-gap discharge)
• Power Supply: 12V/3A DC (US/EU standards, CE/FCC/UL certifi ed)
• Dimensions (WxDxH): 17 x 6.8 x 1.73 in (432 x 172 x 44mm)
• Weight: 4.9 lbs / 2200g
• Chassis Material: Aluminum
• Silkscreen Color: Black
• Operating Temperature: 32˚F ~ 104˚F (0˚C ~ 40˚C)
• Storage Temperature: -4˚F ~ 140˚F (-20˚C ~ 60˚C)
• Relative Humidity: 20 ~ 90% RH (non-condensing)
2
OPERATION CONTROLS AND FUNCTIONS
FRONT PANEL
IR Window: Accept IR signal from the device’s remote control (included).
POWER: Press this button to power on the device or set it to standby mode.
MENU: Press this button to bring up the OSD menu on screen.
-/+ Buttons: Press these buttons to scroll down/up the OSD selections.
CHANNEL INPUT 1~4: Press these buttons to cycle thru HDMI 1~4 input source as assigned to each window.
WINDOW A~H: Press these hot keys to select the screen setting where A~D display a full screen of each channel and E~H are a
different combination of a full screen setting with all 4 channels (quad view).
REAR PANEL
HDMI IN: Connect with source equipments such as DVD, Blu-ray players, Computers, Apple TV, etc.
HDMI OUT: Connect with HD TV/monitor for output image display.
RJ45 JACK: Ethernet jack for switcher control using telnet control.
USB SERVICE ONLY: This slot is reserved for factory use only.
RS-232: Connect from PC/NB with D-Sub 15pin cable for RS-232 control.
DC 12V: Plug the 12V DC power supply into the unit and connect the adaptor to an AC outlet.
3
REMOTE CONTROL
OUTPUT RESOLUTIONS
Power: Press this button to switch on the device or press it again to set it to
standby mode.
Info: Press this button to show the device’s fi rmware version.
Input CH 1~4: Press these buttons to rotate HDMI 1~4 input source on
each channel to be displayed on screen
WA~H: Press these hot keys to select the screen setting where A~D will
display a full screen of each channel and E~H are a different combination of a full
screen setting with all 4 channels.
Mute: Press this button to mute the audio from HDMI output port.
▲▼►◄ & OK Buttons: Press these buttons to scroll through the OSD
selection and press OK to enter and confi rm the setting.
Menu: Press this button to enter into the OSD menu.
Exit: Press this button to exit the OSD menu or the OSD settings.
FAV. 1~4: Press these buttons to bring up the customized screen settings.
Fade-In-Out*: Press this button to switch on or off the Fade-in-out function.
Chromakey*: Press this button to enter into Chroma function where CH 1 is
the background and CH 2 is the top image.
Mirror*: Press this button to display the screen in mirror image.
Rotation*: Press this button to rotate the image 90˚ left and right or 180˚
upside down.
Audio 1~4: Press these buttons to select audio from HDMI input source 1~4.
* Functions only work under Window A to D. The system will force the switch to
Window A when current operation is Window E~H.
4
RS-232 PROTOCOLS
Baud Rate: 115200bps
Data Bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1
RS-232 PROTOCOLS
HDMI-PIP-4P Remote Control
PIN Assignment PIN Assignment
1NC 1NC
2Tx 2Rx
3Rx 3Tx
4NC 4NC
5 GND 5 GND
6NC 6NC
7NC 7NC
8NC 8NC
9NC 9NC
RS-232 COMMANDS
Command Action
POW000
POW001
WND001
WND002
WND003
WND004
WND005
WND006
WND007
WND008
CH1001
CH1002
CH1003
CH1004
CH2001
CH2002
CH2003
CH2004
CH3001
CH3002
CH3003
CH3004
CH4001
CH4002
CH4003
CH4004
POW000
POW001
Change to Window A
Change to Window B
Change to Window C
Change to Window D
Change to Window E
Change to Window F
Change to Window G
Change to Window H
Change CH1 to Source 1
Change CH1 to Source 2
Change CH1 to Source 3
Change CH1 to Source 4
Change CH2 to Source 1
Change CH2 to Source 2
Change CH2 to Source 3
Change CH2 to Source 4
Change CH3 to Source 1
Change CH3 to Source 2
Change CH3 to Source 3
Change CH3 to Source 4
Change CH4 to Source 1
Change CH4 to Source 2
Change CH4 to Source 3
Change CH4 to Source 4
Command Action
MUT000
MUT001
AUD001
AUD002
AUD003
AUD004
FAD000
FAD001
CHR000
CHR001
MIR000
MIR001
ROT000
ROT001
ROT002
ROT003
SFA001
SFA002
SFA003
SFA004
RFA001
RFA002
RFA003
RFA004
Mute Off
Mute On
Change Output Audio to Source 1
Change Output Audio to Source 2
Change Output Audio to Source 3
Change Output Audio to Source 4
Fade In-Out Off
Fade In-Out On
Chromakey Function Off
Chromakey Function On
Mirror Function Off
Mirror Function On
Rotation Function Off
Rotation Function R
Rotation Function L
Rotation Function Up-Side Down
Store window format to FAV 1*
Store window format to FAV 2*
Store window format to FAV 3*
Store window format to FAV 4*
Recall window from FAV 1
Recall window from FAV 2
Recall window from FAV 3
Recall window from FAV 4
Note: RS-232 command will be not executed unless followed with a carriage return and commands are case-sensitive.
* Commands will not execute under window A~D.
5
OSD MENU
OSD MENU
Main Menu 1st Layer 2nd Layer 3rd Layer
CH 1 0~100 (50)
CH 2 0~100 (50)
Brightness
Adjust
Contrast
Adjust
Image Adjust
Hue Adjust
Picture Reset
Menu Exit
Channel 1
Select
CH 3 0~100 (50)
CH 4 0~100 (50)
Value Reset
Menu Exit
CH 1 0~100 (50)
CH 2 0~100 (50)
CH 3 0~100 (50)
CH 4 0~100 (50)
Value Reset
Menu Exit
CH 1 0~100 (50)
CH 2 0~100 (50)
CH 3 0~100 (50)
CH 4 0~100 (50)
Value Reset
Menu Exit
CH1 Wxxx Hxxx
Width Unit
Width Ten
Size
Position
Image Output OnOff
Window Reset
Menu Exit
Width Hundred
Height Unit
Height Ten
Height Hundred
CH1 Hxxx Vxxx
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
6
OSD MENU
OSD MENU
Main Menu 1st Layer 2nd Layer 3rd Layer
CH2 Wxxx Hxxx
Width Unit
Width Ten
Size
Channel 2
Select
Position
Image Output OnOff
Window Reset
Menu Exit
Size
Channel 3
Select
Position
Image Output OnOff
Window Reset
Menu Exit
Width Hundred
Height Unit
Height Ten
Height Hundred
CH2 Hxxx Vxxx
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
CH3 Wxxx Hxxx
Width Unit
Width Ten
Width Hundred
Height Unit
Height Ten
Height Hundred
CH3 Hxxx Vxxx
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
7
OSD MENU
OSD MENU
Main Menu 1st Layer 2nd Layer 3rd Layer
CH4 Wxxx Hxxx
Width Unit
Width Ten
Window
Convert
Channel 4
Select
Favorites
Store
Favorites
Recall
Menu Exit
Channel 1
Convert
Channel 2
Convert
Size
Position CH4 Hxxx Vxxx
Image Output OnOff
Window Reset
Menu Exit
FAV 1 Store ON/OFF/OK
FAV 2 Store ON/OFF/OK
FAV 3 Store ON/OFF/OK
FAV 4 Store ON/OFF/OK
Menu Exit
FAV 1 Recall ON/OFF/OK
FAV 2 Recall ON/OFF/OK
FAV 3 Recall ON/OFF/OK
FAV 4 Recall ON/OFF/OK
Menu Exit
Mirror On/Off
Fade In-Out On/Off
Rotation R90/L90/
Up-Side Down180/Off
Window Reset
Menu Exit
Mirror On/Off
Fade In-Out On/Off
Rotation R90/L90/
Up-Side Down180/Off
Window Reset
Menu Exit
Width Hundred
Height Unit
Height Ten
Height Hundred
Horizontal Unit
Horizontal Ten
Horizontal Hundred
Vertical Unit
Vertical Ten
Vertical Hundred
8
OSD MENU
OSD MENU
Main Menu 1st Layer 2nd Layer 3rd Layer
Mirror On/Off
Fade In-Out On/Off
Channel 3
Convert
Window
Convert
Channel 4
Convert
Minimum For
R 000~255
Maximum For
R 000~255
Minimum For
G 000~255
Chromakey
Setup*
Sys Reset
Information F/V version
Menu Exit
Maximum For
G 000~255
Minimum For
B 000~255
Maximum For
B 000~255
Switch ON/
OFF
Exit
Rotation R90/L90/
Up-Side Down180/Off
Window Reset
Menu Exit
Mirror On/Off
Fade In-Out On/Off
Rotation R90/L90/
Up-Side Down180/Off
Window Reset
Menu Exit
* Chromakey Setup works under CH1 & CH2 where CH1 is the background and CH2 is the top layer. RGB’s minimum setting cannot be
greater than the maximum and the maximum cannot be lower than the minimum setting.
9
CONNECTION AND INST ALLA TION
10
TERMS AND CONDITIONS OF USE
PLEASE READ THE FOLLOWING TERMS AND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTS AND SOFTW ARE PROVIDED
BY, THROUGH OR UNDER KVM SWITCH TECH, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify
your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to KVM SWITCH
TECH, Inc. at the return address set forth on the Product’s packing label at your expense. KVM SWITCH TECH, Inc. may modify these Terms and Conditions at
anytime, without notice to you.
RESTRICTIONS ON USE OF THE PRODUCT
It is your responsibility to read and understand the installation and operation instructions, both verbal and in writing, provided to you with respect to the Product.
You are authorized to use the Product solely in connection with such instructions. Any use of the Product not in accordance with such instructions shall void any
warranty pertaining to the Product. Any and all damages that may occur in the use of the Product that is not strictly in accordance with such instructions shall be
borne by you and you agree to indemnify and hold harmless KVM SWITCH TECH, Inc. from and against any such damage.
The Product is protected by certain intellectual property rights owned by or licensed to KVM SWITCH TECH. Any intellectual property rights pertaining to the
Product are licensed to you by KVM SWITCH TECH, Inc. and/or its affi liates, including any manufacturers or distributors of the Product (collectively, “KVM SWITCH
TECH”) for your personal use only, provided that you do not change or delete any proprietary notices that may be provided with respect to the Product.
The Product is sold to you and any use of any associated intellectual property is deemed to be licensed to you by KVM SWITCH TECH for your personal use only.
KVM SWITCH TECH does not transfer either the title or the intellectual property rights to the Product and KVM SWITCH TECH retains full and complete title to the
intellectual property rights therein. All trademarks and logos are owned by KVM SWITCH TECH or its licensors and providers of the Product, and you may not copy
or use them in any manner without the prior written consent of KVM SWITCH TECH, which consent may be withheld at the sole discretion of KVM SWITCH TECH.
The functionality and usability of the Product is controlled by KVM SWITCH TECH, Inc. from its offi ces within the State of Texas, United States of America. KVM
SWITCH TECH makes no representation that materials pertaining to the Product are appropriate or available for use in other locations other than the shipping
address you provided with respect thereto. You are advised that the Product may be subject to U.S. export controls.
Disclaimers and Limitation of Liability
KVM SWITCH TECH may change or modify the Product at any time, from time to time.
THE PRODUCT IS PROVIDED “AS IS” AND WITHOUT WARRANTIES OF ANY KIND EITHER EXPRESS OR IMPLIED. KVM SWITCH TECH DOES NOT
WARRANT OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESUL TS OF THE USE OF THE PRODUCT’S CORRECTNESS, ACCURACY,
RELIABILITY, OR OTHERWISE.
KVM SWITCH TECH has no duty or policy to update any information or statements pertaining to the Product and, therefore, such information or statements should
not be relied upon as being current as of the date you use the Product. Moreover, any portion of the materials pertaining to the Product may include technical
inaccuracies or typographical errors. Changes may be made from time to time without notice with respect to the Product.
TO THE FULLEST EXTENT PERMISSIBLE PURSUANT TO APPLICABLE LAW, KVM SWITCH TECH DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT.
KVM SWITCH TECH DOES NOT WARRANT THE ACCURACY, COMPLETENESS OR USEFULNESS OF ANY INFORMATION WITH RESPECT TO THE
PRODUCT. KVM SWITCH TECH DOES NOT WARRANT THAT THE FUNCTIONS PERTAINING TO THE PRODUCT WILL BE ERROR-FREE, THAT DEFECTS
WITH RESPECT TO THE PRODUCT WILL BE CORRECTED, OR THAT THE MATERIALS PERTAINING THERETO ARE FREE OF DEFECTS OR OTHER
HARMFUL COMPONENTS. KVM SWITCH TECH WILL USE ITS REASONABLE EFFORTS TO CORRECT ANY DEFECTS IN THE PRODUCT UPON TIMELY
WRITTEN NOTICE FROM YOU NOT TO EXCEED 10 BUSINESS DAYS AFTER RECEIPT BY YOU OF THE PRODUCT, BUT YOU (AND NOT KVM SWITCH
TECH) ASSUME THE ENTIRE COST OF ALL NECESSARY SERVICING, REPAIR AND CORRECTION THAT WAS CAUSED BY YOU UNLESS OTHERWISE
AGREED TO IN A SEPARATE WRITING BY KVM SWITCH TECH.
UNDER NO CIRCUMSTANCES, INCLUDING, BUT NOT LIMITED TO, NEGLIGENCE, SHALL KVM SWITCH TECH BE LIABLE FOR ANY SPECIAL OR
CONSEQUENTIAL DAMAGES THA T RESUL T FROM THE USE OF, OR THE INABILITY TO USE THE PRODUCT IN ACCORDANCE WITH ITS SPECIFICATIONS,
EVEN IF KVM SWITCH TECH OR ITS REPRESENTATIVES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL KVM
SWITCH TECH’S TOTAL LIABILITY TO YOU FROM ALL DAMAGES, LOSSES, AND CAUSES OF ACTION (WHETHER IN CONTRACT, OR OTHERWISE)
EXCEED THE AMOUNT YOU PAID TO KVM SWITCH TECH, IF ANY, FOR THE PRODUCT.
END OF DOCUMENT
11
Loading...
