1 About this manual
This manual is intended for Kvaser Leaf Pro HS v2 users. This document contains
a description of the hardware’s properties and general instructions for connecting
the device to a computer.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 5 (23)
2 Introduction
This section will describe the functions and features of the Kvaser Leaf Pro HS v2.
2.1 Welcome to Kvaser Leaf Pro HS v2
Figure 1: Kvaser Leaf Pro HS v2
Kvaser Leaf Pro HS v2 is a small, yet advanced, portable single channel CAN to
USB real time interface that handles transmission and reception of standard and
extended CAN messages on the CAN bus with a high time stamp precision. The
Kvaser Leaf Pro HS v2 is compatible with applications that use Kvaser‘s CANlib.
This guide applies to Kvaser Leaf Pro HS v2 devices listed in Table 1 on Page 6.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 6 (23)
Device Product Number (EAN)
Kvaser Leaf Pro HS v2 73-30130-00843-4
Kvaser Leaf Pro HS v2 OBDII 73-30130-00849-6
Table 1: Kvaser Leaf Pro HS v2 devices and their product numbers.
Throughout this document, we use the name Kvaser Leaf Pro HS v2 to mean any
one of the different Kvaser Leaf Pro HS v2 products listed in Table 1, unless
otherwise noted.
2.2 Major features
• USB CAN interface with Kvaser t programmability.
• Supports CAN FD, up to 8 Mbit/s (with proper physical layer).
• Quick and easy plug-and-play installation.
• Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
• Power is taken from the USB bus.
• 100% compatible with applications written for other Kvaser CAN hardware
with Kvaser CANlib.
• High-speed CAN connection (compliant with ISO 11898-2), up to 1 Mbit/s.
• Fully compatible with J1939, CANopen, NMEA 2000
R
and DeviceNet.
• Kvaser MagiSync – automatic time synchronization (see Section 4.7, Kvaser
MagiSync, on Page 17 for more details).
• Auto response buffers, to send messages on a defined event.
• Auto transmit buffers, to send messages on a defined interval.
• Simultaneous operation of multiple devices.
2.3 Interface
Kvaser Leaf Pro HS v2 provides a CAN bus interface through a standard USB
interface.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 7 (23)
2.4 The t programming language
The Kvaser t programming language is event oriented and modeled after C. It can
be used to customize the behavior of the Kvaser Leaf Pro HS v2 and other Kvaser
t capable devices.
A t program is invoked via hooks, which are entry points that are executed at the
occurrence of certain events. These events can be, for example, the arrival of
specific CAN messages or a timer expiration.
Like any Kvaser CAN interface, the Kvaser Leaf Pro HS v2 can be used via CANlib
on a PC. The addition of t programs running directly on the Kvaser Leaf Pro HS v2
makes it possible to react much quicker to CAN bus events (for example to speed
up file transfer protocols or to simulate missing hardware).
For more information, see the Kvaser t Programming Language guide that can be
downloaded at www.kvaser.com/download.
2.5 Restrictions in t functionality
The Kvaser Leaf Pro HS v2 is an interface and as such does not contain real-time
clock (RTC), logger or SD card functionality. This means that the t functionality
listed in Table 2 is not available on Kvaser Leaf Pro HS v2 as of version 3.2 of the t
language compiler.
Group Function name
Predefined File I/O Functions
fileOpen
fileClose
fileGets
fileReadBlock
filePuts
fileWriteBlock
fileSeek
fileDelete
Predefined XML Functions
xmlOpen
xmlClose
xmlGet
Predefined t Program Related Functions
scriptLoad
Predefined Logger Related Functions
filterDropMessage
loggerStatus
loggerStart
loggerStop
Other Predefined Functions
timeGetDate
Table 2: Functionality in the t language (v3.2) that is not supported by Kvaser Leaf
Pro HS v2.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 8 (23)
2.6 Additional software and documentation
The Kvaser CANlib SDK includes everything you need in order to develop software
for Kvaser CAN hardware. The SDK contains full documentation and many sample
programs, written in C, C++, C#, Delphi, Python and Visual Basic. All Kvaser CAN
interface hardware share a common software API. Programs written for one device
type will run without modification on other device types.
The latest versions of documentation, software and drivers can be downloaded for
free at www.kvaser.com/download.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 9 (23)
3 Kvaser Leaf Pro HS v2 hardware
In this section you can read more about the CAN channels, power supply and LED
indicators.
3.1 Hardware installation
The Kvaser Leaf Pro HS v2 may be inserted in any free USB socket on the host
computer. You do not need to switch the power off before inserting or removing the
device.
For the Kvaser Leaf Pro HS v2 to communicate with the host computer, the correct
version of the Kvaser driver and firmware must be installed. The firmware is
downloaded and installed directly on the Kvaser Leaf Pro HS v2 and the driver is
installed on the host computer. The latest version of the driver and firmware can be
downloaded from www.kvaser.com/download.
The driver is installed by running the file
kvaser_drivers_setup.exe
.
For information on how to upgrade the firmware, see Section 4.6, Updating the
firmware, on Page 17.
3.2 USB connector
The Kvaser Leaf Pro HS v2 has a standard USB type “A” connector.
Figure 2: A standard USB type “A” connector.
Connect the device to your computer using any high quality USB 2.0 certified
cable. The maximum USB cable length is 5 m (∼ 16 ft). If you need a longer cable,
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 10 (23)
you can use USB hubs or USB extension cables with a built-in hub. By chaining up
to 5 hubs, you can achieve an effective cable length of up to 25 m (∼ 82 ft).
As USB cables become longer they are more sensitive to EMI,
because they make a longer antenna that can pick up more
noise. These issues can be mitigated by using higher quality
cables with better shielding. Thicker cables tend to be better than
thin ones, and braided shielding tends to be more reliable than
only foil. Furthermore, longer cables may introduce signal
degradation and timing issues that, if necessary, can be mitigated
using shorter cable segments combined with hubs that amplify
the signal and handle delays on a per-cable basis.
3.3 CAN channels
The Kvaser Leaf Pro HS v2 has one CAN Hi-Speed channel in a CAN connector
depending on the model. Either a 9-pin D-SUB or a 16-pin OBDII connector is
used. See Section 4.4, CAN connectors, on Page 15 for details about the pinout.
Figure 3: 9-pin D-SUB CAN connector
Figure 4: OBDII CAN connector
3.4 Power supply
The Kvaser Leaf Pro HS v2 is powered from the USB port.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 11 (23)
3.5 LED Indicators
The Kvaser Leaf Pro HS v2 has one power LED and one traffic LED for the CAN
channel as shown in Figure 5 on Page 11. Their functions are described in
Section 4.1, Definitions of LED states and colors, on Page 12.
Figure 5: LEDs on the Kvaser Leaf Pro HS v2.
3.6 Troubleshooting
Use “Kvaser Hardware” in the Control Panel to verify that the computer can
communicate with the Kvaser Leaf Pro HS v2. If the firmware version shown is all
zeros, there are communication problems.
If the LEDs are not flashing or do not light up at all, check the power supply.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 12 (23)
4 Appendices
In this section you will find technical information about the Kvaser Leaf Pro HS v2
and its connectors.
4.1 Definitions of LED states and colors
A Kvaser device has two basic types of LEDs; Power and Traffic. These are dual
colored as shown in Table 3. A device with multiple CAN channels has one Traffic
LED for each CAN channel. When the device has more than one channel a space
and digit is added on the label, CAN 1, CAN 2 etc. The red Traffic LEDs are also
used to indicate errors by using all red Traffic LEDs simultaneously.
LED Label Color
Power PWR Green/Yellow
Traffic CAN Yellow/Red
Table 3: The different type of LEDs.
The following definitions is used to describe the state of an LED:
Off The LED is off and no light is emitted.
Flash The LED is lit up for a very short time. A single flash may be hard to see
and a continuous set of flashes will look the same as On.
Slow Blink The LED is repeatedly turned On and Off. The On and Off phase is
equal in time.
Fast Blink The LED is repeatedly turned On and Off but with a higher frequency
than Slow Blink. The On and Off time is still equal.
On The LED is constantly emitting light.
Slow Waver This is a variant of Slow Blink but instead of being Off, a second color
is On. This is only possible with a dual colored LED.
Fast Waver The LED is alternating between two colors as in Slow Waver but
using a higher frequency.
Running This means that all LEDs are lit, one at the time, in sequence with every
color available i.e. “Power green->Power yellow->Traffic 1 yellow->Traffic 1
red->. . . ”
As an example, "Slow Waver (Green/Yellow)" means that the LED is slowly blinking
by alternating between green and yellow.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 13 (23)
4.1.1 Interface mode
The device is in Interface mode when connected to the PC via USB. If the Power
LED is showing a steady green light, the device is in Interface mode and working
correctly. When connected to the computer for the first time, the Power LED will
blink slowly in yellow until the driver is installed and the device has received a USB
configuration.
When in Interface mode, if the Power LED is yellow for an extended period,
something is wrong. Please see Table 4.
The power should never be removed when firmware update is in
progress.
Power LED Traffic LED Description
Slow Blink (Yellow) All off (-) Waiting for USB configuration
Slow Waver (Green/Yellow) Slow Waver (Yellow/Red) Firmware configuration error
1
Slow Waver (Green/Yellow) All Slow Blink (Yellow) Power problem
2
Table 4: Yellow Power LED shows problems in Interface mode.
Traffic LED Description
Off (-) Idle, no CAN traffic
Flash (Yellow) CAN message received or sent
Flash (Red) Error frame received
All Fast Blink (Yellow) Firmware update is in progress
Fast Blink (Red) CAN channel is error passive
On (Red)
3
CAN overrun
Table 5: Traffic LED shows CAN bus status in Interface mode .
4.1.2 Status of scripts
There are by default no LED indications showing the state of a t program. Instead,
the developer of a script can override any of the existing LEDs and create
notifications as needed when the t program is running, including program
exceptions.
1
This should not normally happen. If it does, please contact Kvaser support.
2
This indicates low power supply, such as using an unpowered USB hub.
3
The red Traffic LED indicating overrun will stay on until the device goes bus off.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 14 (23)
4.2 Start and stop of t programs
All events that a t program will react to are specified using various event hooks. In
effect, these are functions which are called when the specific events occur. Among
other events, the program can react to starting and stopping itself which this
section describes. Read the Kvaser t Programming Language guide that can be
downloaded at www.kvaser.com/download for more information.
The “on start” event will be triggered in the Kvaser Leaf Pro HS v2 when any of the
following occurs:
• When a t program is started using the CANlib API (
kvScriptStart()
).
• When a t program is started from another t program.
The “on stop” event will be triggered for running t programs during the
corresponding cases:
• When a t program is stopped using the CANlib API (
kvScriptStop()
).
• When a t program is stopped from another t program.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 15 (23)
4.3 Technical data
In Table 6 on Page 15 you will find the Kvaser Leaf Pro HS v2’s technical
specifications.
CAN Channels 1
CAN Transceivers MCP2561FD (Compliant with ISO 11898-2)
CAN Controller Kvaser CAN IP in FPGA
Galvanic isolation Yes
CAN Bit Rate 40 kbit/s to 1 Mbit/s
CAN FD Bit Rate Up to 8 Mbit/s (with proper physical layer)
Time stamp resolution 1 µs
Max message rate 20000 msg/s per channel
Error Frame Detection Yes
Error Frame Generation Yes
Silent mode Yes
Kvaser MagiSync Yes
PC interface USB Hi-Speed
Power consumption max 195 mA
Hardware configuration Done by software (Plug & Play).
Software requirements Windows Vista or later. (For other operating systems, contact Kvaser
support.)
Dimensions 35 x 165 x 17 mm for body incl. strain relief
Weight 120 g (D-SUB), 130 g (OBDII)
Operating temperature −40◦C to +85◦C
Storage temperature −40◦C to +85◦C
Relative humidity 0% to 85 % (non-condensing.)
Table 6: Technical Specifications.
4.4 CAN connectors
Kvaser Leaf Pro HS v2 devices that use the 9-pin D-SUB connector (see Figure 6)
have the pinning described in Table 7 on Page 16.
Figure 6: The D-SUB 9 connector pin numbers
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 16 (23)
D-SUB pin number Function
1 Not connected
2 CAN_L
3 GND
4 Not connected
5 Shield
6 Not connected
7 CAN_H
8 Not connected
9 Not connected
Table 7: Configuration of the 9-pin D-SUB
Kvaser Leaf Pro HS v2 devices that use the 16-pin OBDII plug (see Figure 7) have
the pinning described in Table 8.
Figure 7: OBDII Connector
OBDII pin number Function
4 GND
6 CAN_H
14 CAN_L
16 Not connected
Table 8: OBDII pin configuration (showing only connected pins)
4.5 CAN bus termination
Every CAN bus must be terminated with a 120 Ohm resistor at each end of the
bus. The Kvaser Leaf Pro HS v2 does not contain any CAN bus termination,
because their inclusion could cause severe disturbance in a system which is
already correctly terminated.
For laboratory or testing use, the exact value of the termination resistors is not
always critical. Sometimes a single terminator is sufficient. For production, proper
termination is essential. If you see error frames on the bus, you should check the
termination.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 17 (23)
To save yourself a lot of trouble, always terminate the CAN
bus properly.
4.6 Updating the firmware
For the Kvaser Leaf Pro HS v2 to communicate with the host computer, compatible
versions of the Kvaser CANlib (including driver) and firmware must be installed.
The latest versions of firmware and drivers can be downloaded for free at
www.kvaser.com/download.
Connect the Kvaser Leaf Pro HS v2 to your PC with the USB cable and start the
update.exe application. A window opens showing the Firmware Update
Instructions, read and follow those carefully.
To check the current firmware version, open “Kvaser Hardware” which can be
found in the Control Panel. Select “Kvaser Leaf Pro HS v2” in the tree view to the
left, and click on the channel. The firmware revision information now appears in the
right half of the window.
4.7 Kvaser MagiSync
Time synchronization is needed to achieve accurate and precise time stamping
between several PC-to-bus interfaces connected to one PC. Since each PC-to-bus
interface uses its on-board clock to set the time stamps.
Kvaser MagiSync is an innovative way to synchronize several different Kvaser USB
interfaces. You do not need external cables - you get instant synchronisation when
you connect the MagiSync enabled Kvaser USB device.
For this to work the Kvaser USB interfaces must reside on the same USB root hub.
If they do not they will not be synchronized, see Figure 8 on Page 18 and Figure 9
on Page 18.
Usually, a computer has a USB controller with one root hub in a computer. If you
use that one, you do not need an external USB hub to get your Kvaser Leafs
synchronized. The easiest way to verify the setup is to look under the
Synchronization tab in "Kvaser Hardware" in your computer’s control panel. If all
your hardware is placed in one Kvaser MagiSync Group, then you are ready to go.
When connected correctly, all units are synchronized achieving a high precision
virtual clock accurate to the microsecond.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 18 (23)
Figure 8: An example setup where all devices are synchronized via MagiSync.
Figure 9: Not all devices are synchronized via MagiSync in this setup.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 19 (23)
5 Disposal and Recycling Information
When this product reaches its end of life, please dispose of it
according to your local environmental laws and guidelines.
For information about Kvaser’s recycling programs, visit:
http://www.kvaser.com/en/kvaser/recycling-policy.html
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 20 (23)
6 Legal acknowledgements
6.1 Usage warning
WARNING FOR ALL USERS
WARNING! - YOUR USE OF THIS DEVICE MUST BE DONE WITH CAUTION AND A FULL
UNDERSTANDING OF THE RISKS!
THIS WARNING IS PRESENTED TO INFORM YOU THAT THE OPERATION OF THIS DEVICE
MAY BE DANGEROUS. YOUR ACTIONS CAN INFLUENCE THE BEHAVIOR OF A CAN-BASED
DISTRIBUTED EMBEDDED SYSTEM, AND DEPENDING ON THE APPLICATION, THE
CONSEQUENCES OF YOUR IMPROPER ACTIONS COULD CAUSE SERIOUS OPERATIONAL
MALFUNCTION, LOSS OF INFORMATION, DAMAGE TO EQUIPMENT, AND PHYSICAL
INJURY TO YOURSELF AND OTHERS. A POTENTIALLY HAZARDOUS OPERATING
CONDITION IS PRESENT WHEN THE FOLLOWING TWO CONDITIONS ARE
CONCURRENTLY TRUE: THE PRODUCT IS PHYSICALLY INTERCONNECTED TO A REAL
DISTRIBUTED EMBEDDED SYSTEM; AND THE FUNCTIONS AND OPERATIONS OF THE
REAL DISTRIBUTED EMBEDDED SYSTEM ARE CONTROLLABLE OR INFLUENCED BY THE
USE OF THE CAN NETWORK. A POTENTIALLY HAZARDOUS OPERATING CONDITION MAY
RESULT FROM THE ACTIVITY OR NON-ACTIVITY OF SOME DISTRIBUTED EMBEDDED
SYSTEM FUNCTIONS AND OPERATIONS, WHICH MAY RESULT IN SERIOUS PHYSICAL
HARM OR DEATH OR CAUSE DAMAGE TO EQUIPMENT, DEVICES, OR THE SURROUNDING
ENVIRONMENT.
WITH THIS DEVICE, YOU MAY POTENTIALLY:
• CAUSE A CHANGE IN THE OPERATION OF THE SYSTEM, MODULE, DEVICE,
CIRCUIT, OR OUTPUT.
• TURN ON OR ACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR FUNCTION.
• TURN OFF OR DEACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR
FUNCTION.
• INHIBIT, TURN OFF, OR DEACTIVATE NORMAL OPERATION.
• MODIFY THE BEHAVIOR OF A DISTRIBUTED PRODUCT.
• ACTIVATE AN UNINTENDED OPERATION.
• PLACE THE SYSTEM, MODULE, DEVICE, CIRCUIT, OR OUTPUT INTO AN
UNINTENDED MODE.
ONLY THOSE PERSONS WHO:
(A) ARE PROPERLY TRAINED AND QUALIFIED WITH RESPECT TO THE USE OF THE
DEVICE,
(B) UNDERSTAND THE WARNINGS ABOVE, AND
(C) UNDERSTAND HOW THIS DEVICE INTERACTS WITH AND IMPACTS THE FUNCTION
AND SAFETY OF OTHER PRODUCTS IN A DISTRIBUTED SYSTEM AND THE APPLICATION
FOR WHICH THIS DEVICE WILL BE APPLIED, MAY USE THE DEVICE.
PLEASE NOTE THAT YOU CAN INTEGRATE THIS PRODUCT AS A SUBSYSTEM INTO
HIGHER-LEVEL SYSTEMS. IN CASE YOU DO SO, KVASER AB HEREBY DECLARES THAT
KVASER AB’S WARRANTY SHALL BE LIMITED TO THE CORRECTION OF DEFECTS, AND
KVASER AB HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY OVER AND ABOVE THE
REFUNDING OF THE PRICE PAID FOR THIS DEVICE, SINCE KVASER AB DOES NOT HAVE
ANY INFLUENCE ON THE IMPLEMENTATIONS OF THE HIGHER-LEVEL SYSTEM, WHICH
MAY BE DEFECTIVE.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 21 (23)
6.2 EC Regulatory Compliance
The product(s); 73-30130-00843-4, 73-30130-00849-6, is in conformity with the
essential requirements of the following regulations and directives:
• WEEE Directive 2012/19/EU of the European Parliament and of the Council
of 4 July 2012
• REACH Regulation (EC) No 1907/2006 of the European Parliament and of
the Council of 18 December 2006
The products listed above also complies with RoHS recast Directive 2011/65/EU of
the European Parliament and of the Council of 8 June 2011 and is in conformity
with the following standards and/or other normative documents:
Standard Description
EN 50581 (2012) Assessment with respect to restriction of hazardous substances
Table 9: Standards and normative documents for RoHS 2011
The products listed above also complies with DIRECTIVE 2004/108/EC OF THE
EUROPEAN PARLIAMENT AND OF THE COUNCIL of 15 December 2004
(EMC-directive) and is in conformity with the following standards and/or other
normative documents:
Standard Description
EN 55 022 (2010) Class B, radiated. IT equipment, commercial emission
EN 55 024 (2010) IT equipment, commercial immunity
Table 10: Standards and normative documents for EMC 2004
NOTE: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the
interference at his/her own expense.
6.3 Patents, Copyrights and Trademarks
All trademarks are the property of their respective owner. Windows is a registered
trademark of Microsoft Corporation in the United States and other countries.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 22 (23)
Adobe, the Adobe logo, and Reader are either registered trademarks or trademarks
of Adobe Systems Incorporated in the United States and/or other countries.
MagiSync is a trademark of Kvaser AB.
DeviceNet is a trademark of Open DeviceNet Vendor Association, Inc.
NMEA 2000 is the registered trademark of the National Marine Electronics
Association, Inc.
For information about Kvaser related CAN patents, see www.kvaser.com/patent.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Kvaser Leaf Pro HS v2 User’s Guide 23 (23)
7 Document Revision History
Version history for document UG_98178_leaf_pro_hs_v2:
Revision Date Changes
1.0 2015-08-10 Initial version
1.1 2015-10-29 Minor textual changes
1.2 2016-02-04 Minor textual changes
1.3 2017-01-09 Updated compliance text, added link to patents
Kvaser AB, Mölndal, Sweden — www.kvaser.com
Loading...
