Sienna 35PRO
ACOUSTIC GUITAR AMP
Congratulations on the purchase of your Sienna 35PRO.
Your Sienna Pro Model draws on decades of amp design and manufacturing experience at Kustom. This model was built from the
ground up to offer world-class tone, useful features and reliable performance. Inside this manual, you’ll nd valuable information about
the amp’s controls and specications. Being familiar with its features will help you effectively tailor your amp’s sound. We wish you
many years of enjoyment with your Kustom amplier.
IMPORTANT SAFETY INSTRUCTIONS
Danger
Exposure to extremely high noise levels may cause a
permanent hearing loss. Individuals vary considerably to noise
induced hearing loss but nearly everyone will lose some
hearing if exposed to sufficiently intense noise for a sufficient
time.
The U.S. Government's Occupational Safety and Health
Administration (OSHA) has specified the following
permissible noise level exposures:
DURATION PER DAY (HOURS) 8 6 4 3 2 1
SOUND LEVEL (dB) 90 93 95 97 100 103
According to OSHA, any exposure in the above permissible
limits could result in some hearing loss. Earplugs or protectors
in the ear canal or over the ears must be worn when operating
this amplification system in order to prevent a permanent
hearing loss. If exposure in excess of the limits as put forth
above, to insure against potentially harmful exposure to high
sound pressure levels, it is recommended that all persons
exposed to equipment capable of inducing high sound pressure
levels, such as this amplification system, be protected by
hearing protectors
while this unit is in operation.
THIS SYMBOL IS INTENDED TO ALERT THE
USER TO THE PRESENCE OF NON-INSULATED
"DANGEROUS VOLTAGE" WITHIN THE
PRODUCT'S ENCLOSURE THAT MAY BE OF
SUFFICIENT MAGNITUDE TO CONSTITUTE A
RISK OF ELECTRIC SHOCK TO PERSONS.
THIS SYMBOL IS INTENDED TO ALERT THE
USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE
(SERVICING) INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE UNIT.
APPARATUS SHALL NOT BE EXPOSED TO
DRIPPING OR SPLASHING AND
THAT NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS
VASES, SHALL BE PLACED ON THE
APPARATUS.
1. Read all safety and operating instructions before
using this product.
2. All safety and operating instructions should be kept
for future reference.
3. Read and understand all warnings listed on the
operating instructions.
4. Follow all operating instructions to operate this
product.
5. This product should not be used near water, i.e.
Bathtub, sink, swimming pool, wet basement, etc.
6. Only use dry cloth to clean this product.
7. Do not block any ventilation openings, It should not
be placed flat against a wall or placed in a built-in
enclosure that will impede the flow of cooling air.
8. Do not install this product near any heat sources;
such as, radiators, heat registers, stove or other
apparatus (including heat producing amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The
wide blade or the third prong are provided for your
safety if the provided plug does not fit into your
outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord being walked on or pinched,
particularly at Plugs, convenience receptacles and the
point where they exit from the
apparatus. Do not break the
ground pin of the power supply
cord.
11. Only use attachments specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer or sold with the
apparatus. When a cart is used, use caution when
moving cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Care should be taken so that objects do not fall and
liquids are not spilled into the unit through the
ventilation ports or any other openings.
15. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way; such as, power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally or has been dropped.
16. WARNING: To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or
moisture.
17. When the MAINS plug, or an appliance coupler is
used as the disconnect device, the disconnect device
shall remain readily operable.
18. Protective Ground Terminal: The apparatus shall be
connected to an AC main socket with a protective
earth ground connection.
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan
Apparatet må tilkoples jordet stikkontakt
Apparaten skall anslutas till jordat uttag
IMPORTANT SAFETY INSTRUCTIONS
FRENCH
Danger
L‘exposition a des niveaux eleves de bruit peut provoquer une
perte permanente de l’audition, Chaque organisme humain
reagit differemment quant a la perte de l’audition, mais
quasiment tout le monde subit une diminution de I’acuite
auditive lors d’une exposition suffisamment longue au bruit
intense. Les autorites competentes en reglementation de bruit
ont defini les expositions tolerees aux niveaux de bruits:
DURATION PER DAY (HOURS) 8 6 4 3 2 1
SOUND LEVEL (dB) 90 93 95 97 100 103
Selon les autorites, toute exposition dans les limites citees cidessus,peuvent provoquer certaines pertes d’audition. Des
bouchons ou protections dans l’appareil auditif ou sur l’oreille
doivent etre portes lors de l’utilisation de ce systeme
d’amplification afin de prevenir le risque de perte permanente
de l’audition, Dans le cas d’expositions superieures aux
limites precitees il est recommande, afin de se premunir contre
les expositions aux pressions acoustiques eIevees
potentielIement dangeureuses, aux personnes exposees aux
equipements capables de delivrer de telles puissances, tels ce
systeme d’amplification en fonctionnement, de proteger
l’appareil auditif.
CE SYMBOLE A POUR BUT D'AVERTIR
L'UTILISATEUR DE LA PRESENCE DE VOLTAGE
DANGEREUX NON-ISOLE A L'INTERIEUR DE CE
PRODUIT QUI PEUT ETRE DE PUISSANCE
SUFFISAMMENT IMPORTANTE POUR
PROVOQUER UN CHOC ELECTRIQUE AUX
PERSONNES.
CE SYMBOLE A POUR BUT D'AVERTIR
L'UTILISATEUR DE LA PRESENCE
D'INSTRUCTIONS D'UTILISATION ET DE
MAINTENANCE DANS LES
DOCUMENTS FOURNIS AVEC CE PRODUIT.
AFIN DE REDUIRE LES RISQUÉ D'INCENDIE
ET DE DECHARGE ELECTRIQUE, NE PAS
EXPOSER CET APPAREIL A LA PLUIE OU A
L'HUMIDITE.
1. Lire avec attention toutes les recommandations et
précautions d'emploi avant d'utiliser ce produit.
2. Toutes les recommandations et précautions d'emploi
doivent être conservées afin de pouvoir s'y reporter si
nécessaire.
3. Lire et comprendre tous les avertissements énumérés dans
les précautions d'emploi.
4. Suivre toutes les précautions d'emploi pour utiliser ce
produit.
5. Ce produit ne doit pas être utilisé près d'eau, comme par
exemple baignoires, éviers, piscine, sous-sol humides ...
Etc.
6. Utiliser exclusivement un chiffon sec pour nettoyer ce
produit.
7. Ne bloquér aucune ouverture de ventilation. Ne pas placer
le produit tout contre un mur ou dans une enceinte fernée,
cela gênerait le flux d'air nécessaire au refroidissement.
8. Ne pas placer le produit près de toute source de chaeur telle
que radiateurs, arrivées d'air chaud, fourneaux ou autres
appareils générant de la chaleur (incluant les amplificateurs
producteurs de chaleur) .
9. Ne pas négliger la sécurité que procure un branchement
polarisé ou avec raccordement à la terre, Un branchement
polarisé comprend deux fiches dont l'une est plus large que
l'autre. Un branchement à la terre comprend deux fiches
plus une troisième reliée à la terre. Si la fiche secteur
fournie ne s'insert pas dans votre prise de courant. consulter
un 'électricien afin de remplacer votre prise obsolète.
10. Protéger le cordon d'alimentation de tout écrasement ou
pincement, particulièrement au niveau des fiches, des
réceptacles utilisés et à l'endroit de sortie de l'appareil. Ne
pas casser la fiche de terre du cordon d'alimentation.
11. Utiliser uniquement les accessoires spécifiés par le
constructeur.
12. Utiliser uniquement avec le chariot de
transport, le support, le trépied, la
console ou la table spécifiés par le
constructeur ou vendus avec l'appareil.
Lors de l'utilisation d'un chariot, bouger
avec précaution l'ensemble
chariotlappareil afin d'éviter les dommages d'un
renversement.
13. Débrancher cet appareil lors d'orages ou s'il n'est pas utilisé
pendant une longue période.
14. Des précautions doivent être prises afin qu'aucun objet ne
tombe et qu'aucun liquide ne se répande à l'intérieur de
l'appareil par les orifics de ventilation ou n'importe quelle
autre ouverture.
15. Pour toutes interventions techniques s'adresser à un
technicien qualifié.L'intervention technique est nécessaire
lorsque l'appareil a été endommagé de n'importe quelle
façon, comme par exemple si le cordon secteur ou sa fiche
sont détériorés,si du liquide a coulé ou si des objets sont
tombés à l'intérieur de l'apparei1,si l'appareil a été exposé à
la pluie ou à l'humidité, s'il ne fonctionne pas normalement
ou s'il est tombé.
16. ATTENTI0N:Pour réduire le risque d'incendie ou de choc
electrique ne pas exposer l'appareil à la pluie ou à
l'humidité.
17. Quand La prise MAINS, au coupler, est utilisé pour la
source d'alimentation êlectrique. Il est conseillê de garder
cette prise facilement accessible.
18. Borne de terre de protection: L'appareil doit être connecté à
un connecteur AC principale avec un raccordement à la
terre de protection.
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan
Apparatet må tilkoples jordet stikkontakt
Apparaten skall anslutas till jordat uttag
1.) Mic/Line Input - this is a 1/4” 2 conductor input jack for plugging in a Hi-Z microphone or instrument. It is intended for microphones
but will accept other instruments as well.
2.) Guitar Input - this is a 1/4” 2 conductor input jack for plugging in your instrument. It is intended for guitar or Hi-Z microphones but
will accept other instruments as well.
3.) Mic/Line Volume - this control is the output volume control for the mic/line input. Slowly increase the control to increase the
volume. If you are using a high impedance microphone, be careful when increasing the volume. Depending on mic position, it may
feedback if mic is in front of speaker.
4.) Mic/Line Input - this switch will select a mic or line level input. If you are using a high impedence microphone, be careful when
increasing volume. Depending on mic placement, feedback may occur.
5.) Guitar Volume - this control is the output volume control for the guitar input. Slowly increase the control to increase the volume. If
you are using a guitar with an on-board preamp, set it’s level for a mid position before increasing this control otherwise distortion may
occur.
6.) Guitar Input- this switch will place a -20db pad in the circuit which will allow use of active on-board electronics from pre-amplied
guitars. This will help keep the signal extremely clean.
7.) Frequency - this control is a tight Hi-Q cut lter notch with an extremely narrow width. It sweeps between 50Hz & 500Hz and “ne
tunes” the midrange of the acoustic guitar. This helps eliminate unwanted “ringing” tones. It is preset to -10db.
8.) Low - this control is the bass control. It is active and set to boost or cut frequencies at 60 Hz. This will effect the low frequency
signals. Turning it counterclockwise, the low will be rolled off -18db. Clockwise, it will boost +18db. Especially good for “cleaning up”
preset patches or making thin toned guitars sound fuller.
9.) Mid - this control is the midrange control. It is active and set to boost or cut frequencies 1.5KHz. This will effect the mid-low
frequency signals. Turning it counterclockwise, the low-mids will be rolled off -12db. Clockwise, it will boost +12db. Especially good for
“cleaning up” guitar overtones.
10.) High - this is the high frequency tone control. It is active and set to boost or cut frequencies at 5KHz. This will effect the high
frequency signals. Turning it counterclockwise, the highs will be rolled off -18db. Clockwise, it will boost +18db. This will add or subtract
the high end shimmer and clarity.
11.) Effects On/Off - this switch engages the digital effects section.
13.) Effects Level - this control adds the digital effects section and mixes it into the main signal buss. Several different effects are
available.
13.) Program Select - this switch will select any of eight different effects. 3- Chorus, 4- Reverb, and 1- delay.
14.) Jewel Light - this jewel light lets you know that the amplier is on.
15.) Power - this switch turns on and off the AC power to the amp.
Back Panel - (not pictured)
Speaker Out - this is a 2 conductor 1/4” speaker output jack. This will disconnect the internal speaker and allow an external speaker
cabinet to be employed. Rating is 8 ohms.
Line Output - this is a 2 conductor 1/4” line output jack. This will allow an external amplier or mixing board to be supplied with the
signal from this amp. This signal is attenuated and comes from the power amp.
Headphone Jack - this is a three conductor 1/4”jack for plugging headphones. It will sum the signal and put the sound in both ears,
thereby creating a pseudo-stereo sound. Volume will be determined by the volume control on the channel you are on. It will disconnect
the internal speaker when plugged in. This will allow quiet practicing.
Footswitch- this is a three conductor 1/4” for connecting a footswitch to turn the Reverb and Chorus On and Off.
Model Sienna 35PRO Acoustic guitar amplifier
Output Power 30 Watts 8 Ohms @ 5 % THD
Eq ualizer 4 B and
Channels Two
Impe da nce 8 Ohms
ects 8 PresetsDigital E ffects
Ampli
Dimensions
er Type MOS-FET Transistor
mm/kg 380 (Height) x 460 (Width) x 245 (Depth), 14 kg
Inc hes/Pounds 15 (Height) x 18.2 (Width) x 9 .7 (Depth), 31 lbs
EC Declaration of Conformity
We: Kustom Musical Amplification INC.
3015 Kustom Drive
Hebron, Ky 41048
Tel: 1-859-817-7164 Fax: 1-859-817-7199
Declare that the product
Product name: Kustom
Product model number: Sienna 35PRO
to which this declaration relates is in conformity with the following standards;
EN55013: 2001/+A1:
2003+A2: 2006 Limits and methods of measurement of radio disturbance characteristics of broadcast
receivers and associated equipment.
EN55020: 2007 Electromagnetic immunity of broadcast receivers and associated equipment.
EN61000-3-2: 2006/+A1:
2009 + A2: 2009 Limits for harmonic current emissions (equipment input current < 16A per phase).
EN61000-3-3: 2008 Limitation of voltage fluctuations and flicker in low voltage supply systems for
equipment with rated currents < 16A.
EN60065: 2002 + A1:2006
+ A11: 2008 + A2:2010
+ A12:2011 Safety requirements for main operated electronic and related apparatus for household and
similar general use.
Following the provisions of EU Council Directive(s): 2004/108/EC and 2006/95/EC.
We the undersigned, hereby declare that the equipment specified above conforms to the aforementioned directive(s).
Name of authorized person: Fred Conrad, Manager Engineering services
Signature:____________________ Date: 03 July, 2013
Kustom Musical Amplification INC.
3015 Kustom Drive
Hebron, Ky 41048
Tel: 1-859-817-7164 Fax: 1-859-817-7199
Sienna 35PRO Owner’s Manual
www.kustom.com
3015 Kustom Drive
Hebron, Kentucky
USA 41048
888-4-KUSTOM (888-458-7866)
Loading...
