KUNK 602201 User Manual

Product Manual

(Kunk)

Kunk Co., Ltd.

1. General Information

1.1 Product Instruction

Kunk is the smart diffuser which is
connected with application through
smart phone app, providing
personalized solutions for users.
Kunk is mainly composed of lighting
module and scent spray module. It is
controlled in real time through our wire­less communication application.
Our app can control the device without
any distortions within 50 meters. Kunk
can play and save the maximum 3
patterns, containing the stop and power
buttons.
Also, Kunk can provide the individual­centered scent services because

application controls the device’s

operation, effect and modes

1.3 Product Constitution

- Scent Diffusing Device

- Cartridge

- Filter

- Manual

1.2 Main Function

Individual-centered Service

KUNK provides users with a scent
whenever and wherever they need it

most. Whether you’re driving, sleeping

or focusing on work, choose your
preferred scent that fits the occasion
through our app.

Soft Light

We have built soft light s into our de
vice so user get visual and sentimental
effects as well

Various Scents

You no longer have to stick with one

scent in one place, because our product

can be assembled easily, Our diverse
array of cartridges gives users a variety
of scents to choose from.

Control Scent

KUNK is the life - type IoT product that
makes it possible to control time, mode
and illuminate your scent with our smart
phone app

2. Device Function Instruction

LED Lighting

Spraying Hole

USB Charging

Play button

Stop, Power button

3. Method of use

3.1 Power On/Off

- To turn on the power, switch power

button more than 1.5 seconds.

- Seeing 4 blue LED light slow flicker,
you can notice the power is on.

- If you want to turn off the power,
switch power button more than 1.5
seconds again. Then you can see
another red LED light.

3.2 Operation Effect Selection

- Switch the operation button shortly.

- You can see the first operation LED

effect.

- If you want to choose LED effect, you
can switch operation button shortly
again to select the effect.

- If the selection is over, you can switch
the power button more than 1.5
seconds to get a scent of present LED

effect while LED is playing.

- Press power button shortly to turn
off the LED effect.

3.3 Stop Operation

- You can stop the LED and Spray
effect while device is operating.

- Press Stop button to stop the
operation

3.4 Battery charge

- There is a 3.7V/400mA Lithium

Polymer rechargeable battery in this
device.

- You can charge this device

connecting the USB cable to device’s

USB socket.

- Cable for charging is a micro USB

which is generally used.

- Device’s LED turns to blue and flicker

during charge.

- If charge is complete, LED stops

flickering and keeps blue color
continuously.

- Charging the device when it was off,

LED will turn off after full charge.

4. Specification

Type : Scent Diffusing Unit for mobile communications

Connecting Method : low-power Bluetooth

Frequency band : 2.4GHz ISM

Data Rate : 250 kbps, 1 Mbps or 2 Mbps

Resonant Frequency : 165KHz

Antenna : on board chip type

Size : 7x6x3 cm (2.75x2.36x1.18 inch)

Weight : basic 70g, extra 20g for Scent containing Cartridge

Cartridge Capacity : 20ml(0.67oz)

Company name : Kunk Co., Ltd.
Product : Scent Diffusing Device for

mobile Communications
Model name : Kunk602201
Manufacturer : Kunk Co., Ltd. / KR

Types of Cartridge : Refill Cartridge or Fragrance containing Cartridge

Material : PC, polypropylene

Diffusing Power : 70 min without stop

Battery type : 400mAh, lithium polymer battery

Guarantee : 1 year

FCC Information to User

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
con-nected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution

Modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

FCC Compliance Information : This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation

IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
The antennas used for this transmitter must be installed to provide a separation distance of at
least 25 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this equipment near water.

6) Do not using near any heat sources such as radiators, heat resisters, stove, or other
equipment that produce heat.

European CE notice to users and product statements

This product is CE marked according to the provisions of the R&TTE
Directive(1999/5/EC). Hereby, KUNK declares that this product is in
compliance with the essential requirements and other relevant provisions
of Directive 1999/5/EC.
For further information, please contact http://

www.kunk.kr

KUNK
A-102HO, 29 Gonghang-daero 61-gil, GANGSEO-GU, Seoul, KOREA
Tel: [phone]
Fax: [phone]
URL: www.kunk.kr

CONTACT INFORMATION

Manufacturer Address : A-102HO, 29 Gonghang-daero 61-gil, GANGSEO-GU, Seoul, KOREA
To locate in-country KUNK, distributors of the SMART DIFFUSER please refer to the KUNK Website http://
www.kunk.kr
These distributor(s) represent local contacts for this product.

CORPORATE HEADQUARTERS:

KUNK

A-102HO, 29 Gonghang-daero 61-gil, GANGSEO-GU, Seoul, KOREA

Tel: [phone]

Fax: [phone]

Web: http://www.kunk.kr

This device complies with Industry Canada license-exempt RSS standard(s).
Operation is Subject to the following two condition: (1) this device may not cause interference
,and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.

EUROPEAN UNION “DECLARATION OF CONFORMITY”

DECLARATION OF CONFORMITY

KUNK

A-102HO, 29 Gonghang-daero 61-gil, GANGSEO-GU, Seoul, KOREA

declare under our sole responsibility that the product(s)

SMART DIFFUSER – KUNK1601

to which this declaration relate(s) is in conformance with the following standards:

EN 301 489-1 V1.9.2:2011

EN 301 489-17 V2.2.1:2012

EN 60950-1:2006/A2:2013

EN 300 328 V1.9.1:2015

following the provisions of the 1999/5/EC Directives.
