KUNBUS REVPI COMPACT Datasheet

RevPi Compact

Article No.: 100272

Technical Data

Housing dimensions (H x W x D) 90 x 160.6 x 58 mm

Housing type DIN rail housing (for DIN rail version EN 50022)

Housing material Polycarbonate

Weight approx. 290 g (incl. connectors)

IP Code IP20

Power supply - device typ. 24 V DC (10.8 … 28.8 V DC)

Power supply - digital outputs typ. 24 V DC (11.4 … 28.8 V DC)

Max. power consumption 20 W (incl. max. 10 W USB)

Operating temperature -20 °C .... +55 °C

Storage temperature -40 °C .... +85 °C

Humidity (at 40 °C) 93 % (non-condensing)

2 x RJ45 10/100 Ethernet (using separate MAC addresses),
4 x USB A (total current draw from all sockets max. 2 A),

Interfaces

Connectors 2-, 4- and 8-pole screw-type terminal

Processor Broadcom BCM2837B0 quad-core ARM Cortex A53

Clock rate 1.2 GHz

Processor cooling Passive with heat sink

RAM 1 GB

Flash memory

EERAM persistent memory 2 kB

Number of digital input channels 8

Input type 24 V DC

Input thresholds At 24 V DC compatible according to EN 61131-2 to type I and III sensors

1 x RS485 max. 500 kbps, termination switchable by software (not
galvanically isolated),
1 x Micro-USB (solely for image transfer to eMMC),
1 x HDMI

8 GB

KUNBUS GmbH, Heerweg 15C, 73770 Denkendorf, Germany | Tel: [phone] | Fax: [phone] | Email: [e-mail] | Web: www.kunbus.com

page 1/2Errors excepted and possible alterations without prior notice.

Version: 1.0

RevPi Compact

Article No.: 100272

Technical Data

Number of digital output channels 8

Digital output type

Maximum current per output

Number of analog input channels 8

High-side with 10 k pull down resistor,

short-circuit proof (internal temperature switch-o),

Potential separation system/digital outputs

Per output: 500 mA @ 24 V DC (resistive load!),
Sum of all outputs: max. 2 A @ 24 V DC (resistive load!)

Analog input type

Number of analog output channels 2

Analog output type

Maximum current load of the analog outputs 10 mA (10 V DC @ 1 k)

Software interface of inputs and outputs Via GPIOs and process image

EMC interference emission according to EN 61000-6-4

EMC immunity according to EN 61000-6-2

Buer time RTC min. 24 h

Optical indicator 3 status LEDs (bi-color), two of them freely programmable

RoHS conformity Yes

CE conformity Yes

0-10 V DC, single ended, 16 Bit at piControl, 21 Bit raw value,

2.5 mA current source activatable by software

0-10 V, short-circuit proof, protection against backfeeding
8-bit resolution, 1 % accuracy
