Page 1
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
N13275
INSTRUCTION MANUAL
Juice Extractor
Model Number JE-2
Page 2
2
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Welcome
Congratulations on choosing to buy a Kuchef® product.
All products brought to you by Kuchef® are manufactured to the highest
standards of performance and safety and, as part of our philosophy of
customer service and satisfaction, are backed by our comprehensive
2 Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Page 3
3
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Contents
02 Welcome
04 Warranty Details
05 General Safety Instructions
08 Product Overview
09 Getting Started
11 Instructions
14 Other Useful Information
16 Recipes
19 Repair and Refurbished Goods or Parts Notice
Page 4
4
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Juice Extractor
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 24 months from the date of purchase. Defects that occur
within this warranty period, under normal use and care, will be repaired,
replaced or refunded at our discretion, solely at our option with no charge for
parts and labour. The benefits conferred by this warranty are in addition
to all rights and remedies in respect of the product that the consumer
has under the Competition and Consumer Act 2010 and similar state and
territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
YEAR WARRANTY
2
Page 5
5
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
General Safety Instructions
Read this manual thoroughly before first use, even if you are familiar with this
type of product. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to.
Signal word definitions
DANGER! This term indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury. Usage of this
signal word is limited to the most extreme situations.
WARNING! This term indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION! This term indicates a potentially hazardous situation which, if not
avoided, may result in minor/moderate injury or product/property
damage. It also alerts against unsafe practices.
Keep the manual in a safe place for future reference, along with the completed
warranty card, purchase receipt and carton. If applicable, pass these instructions
on to the next owner of the appliance. Always follow basic safety precautions
and accident prevention measures when using an electrical appliance, including
those listed below.
WARNING! To reduce the risk of fire, electric shock or serious personal injury:
• Always ensure the product is unplugged from the electrical outlet before
relocating, assembling, disassembling, or cleaning it.
• Keep the product out of the reach of children and pets. This product is not
intended for use by children.
• Do not leave the product unattended while it is in use, especially when
children are present. Always unplug the product from the electrical outlet
when it is not in use.
• Do not place appliance base in water or expose it to water or other liquids.
• Keep the power cord and the appliance itself away from heated surfaces.
• Do not use attachments not recommended or sold by the product manufacturer.
• Handle the blades with care as they are extremely sharp. Use caution when
attaching or detaching the blades.
• Do not touch moving parts (e.g. the blades) while the product is in use. Keep
hands and utensils away from the moving blades while operating the product.
• Do not plug/unplug the product into/from the electrical outlet with a wet hand.
• To disconnect the product from an electrical outlet, pull directly on the plug;
do not pull on the power cord.
Page 6
6
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
General Safety Instructions (Cont.)
• Always operate the product with the cover in place.
• Never place the blade assembly on the base unless attached to the jar.
• Do not put any stress on the power cord where it connects to the product, as
the power cord could fray and break.
• Keep hands and utensils out of the container while juicing. A scraper may be
used, but only when the juicer is not running.
• Do not operate the product if it has a damaged or cut power cord or plug, if
wires are exposed, if it malfunctions, or if it is dropped or damaged.
• This product has no user-serviceable parts. Do not attempt to examine or
repair this product yourself. Only qualified service personnel should perform
any servicing. In case of damage, contact our after sales support line for
advice on inspection, repair or return of the damaged product.
CAUTION! To reduce the risk of personal injury or product/property damage:
• This appliance is intended for indoor, household use only. It is not suitable for
commercial or industrial use.
• Do not use the product outdoors or for anything other than its intended
purpose (processing foods for human consumption), and only use it as
described in this manual.
• The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Young children should be supervised to ensure they do not play with the
appliance. Close supervision is necessary when any appliance is used by or
near children.
• Always operate the product on a flat, stable surface.
• Do not attempt to open any part of the motor housing.
• Do not allow the power cord to hang over the edge of a table or benchtop,
where it may be tripped over or pulled.
Page 7
7
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
General Safety Instructions (Cont.)
Electrical safety
• Check if the voltage indicated on the base of the appliance corresponds to
the local mains voltage before you connect the appliance.
• Do not use the appliance when the mains cord, the plug or other components
are damaged.
• If the mains cord is damaged, it must be replaced by an authorised service
centre or by similarly qualified persons in order to avoid a hazard. Contact our
after sales support line for advice.
• To avoid a circuit overload when using this product, do not operate another
high-wattage product on the same electrical circuit.
• Avoid the use of an extension cord because the extension cord may overheat
increasing the risk of fire. However, if an extension cord must be used, it must
be rated not less than 1875W.
CAUTION! Important product-specific instructions
• Make sure all parts are correctly assembled before you switch on the
appliance.
• Only use the appliance when safety clamps are locked.
• Do not operate the appliance for more than 40 seconds at a time when juicing
heavy loads and let it cool down sufficiently afterwards.
• Never reach into the feeding chute with your fingers or an object while the
appliance is running. Only use the pusher for this purpose.
• Only unlock the clamps after you have switched the appliance off and the filter
has stopped rotating.
• Do not remove the pulp container when the appliance is in operation.
• Do not touch the small cutting blades in the base of the filter.
• Always unplug the appliance after use.
• Never immerse the motor unit in water or any other liquid. Do not rinse it
either.
• Do not use the appliance if the rotating sieve is damaged.
Page 8
8
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Product Overview
4
6
7
8
1 Pusher
2 Feeding chute
3 Lid
4 Filter (sieve)
5 Juice collector
6 Juicer spout
7 Motor unit
8 Safety clamp
9 Control knob
10 Cleaning brush
11 Pulp spout
12 Pulp container
13 Juice jug
14 Spout
3
2
13
1
5
10
11
12
14
9
Page 9
9
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Getting Started
Before first use
• Unpack the appliance but keep all packaging materials until you have made
sure your new juice extractor is undamaged and in good working order.
Plastic wrapping can be a suffocation hazard for babies and young children,
so ensure all packaging materials are out of their reach.
• Fully unwind the cord and inspect it for damage. Do not use the appliance if
anything has been damaged. In such a case, contact our after sales support
line for advice on examination, repair or return of the damaged product.
• Read this manual to familiarise yourself with all the parts. Pay particular
attention to the safety instructions on the previous pages.
• Make sure the appliance is disconnected from the power supply.
• Holding the rim of the filter with you fingers, lift the stainless steel filter out of
the juice collector. Then lift the plastic juice collector off the motor unit.
• Wash all detachable parts with a soft cloth or sponge in warm water and a
little washing-up detergent to remove any dust or other remnants from the
manufacturing process. CAUTION! Take care to avoid injury from the sharp
blades at the bottom of the filter.
• Rinse the parts with clean water and dry.
• When all parts are thoroughly dry, assemble the unit as follows.
Assembly
• Place the juice collector onto the top of the motor base — see Fig. 1 below.
• Tilt the motor unit slightly to attach the pulp container to the appliance, fitting
the top end underneath the pulp spout first, then lining up the bottom end —
see Fig. 2 below.
1
2
Page 10
10
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Getting Started (Cont.)
• Place the juice jug under the spout — see Fig. 5 below.
• Place the lid on top of the juice jug to avoid splattering, or if you want to store
the juice in the refrigerator — see Fig. 6 below.
5 6
A
3 4
B
• Place the filter back into the juice collector, making sure it sits securely in
place over the drive shaft — see Fig. 3 below. (You should be able to move it
around but not lift it out easily.)
• Place the lid with feeding chute on top of the appliance — see Fig. 3 below.
• Snap the safety clamp onto the lid to lock it into place — see (A) in Fig. 4 below.
• Slide the pusher into the feeding chute by aligning the groove in the pusher
with the small protrusion on the inside of the feeding chute — see (B) in Fig. 4
below. Make sure the safety clamps are securely locked on either side of the lid.
Page 11
11
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Instructions
Using the juice extractor
• Wash the fruit and/or vegetables you want to juice and cut them into pieces
that fit into the feeding chute. (See page 12 for hints.)
• Place the fully assembled juice extractor on a flat, stable work surface, plug it
into an appropriate power point and switch on power to the outlet.
• Make sure the juice jug has been placed under the spout.
• Switch the appliance on by turning the control knob to speed setting LO (low
speed) or HI (normal speed) — see Fig. 7 below, and page 13 for a juicing guide.
* Speed LO is particularly suitable for soft fruit and vegetables: watermelons,
grapes, tomatoes, cucumbers, raspberries and those with high water content.
* Speed HI is suitable for hard and fibrous fruit and vegetables.
• Put the pre-cut pieces into the feeding chute — see Fig. 8 below.
• Use the pusher to gently press the fruit pieces down towards the rotating filter
— see Fig. 9 below.
NOTE: Do not exert too much pressure on the pusher, as this could affect the
juice quality and it could even cause the filter to come to a halt.
CAUTION! The appliance will only function if all parts are properly assembled
and the lid is securely locked in place with the clamp.
7
9
8
• After you have processed all ingredients and the juice flow has stopped,
switch the appliance off and wait until the filter has stopped rotating.
• If the pulp container needs emptying, switch off the appliance, carefully
remove the container, empty it and then reassemble it before continuing.
Page 12
12
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Instructions (Cont.)
Tips for best results
• Whenever possible, use fresh fruit and vegetables, as they contain more
juice than produce that has been kept in the fruit bowl or fridge for some
time.
• The following fruit and vegetables are particularly suitable for juicing in
the juice extractor: pineapple, beetroot, celery stalks, apples, cucumbers,
carrots, spinach, melons, tomatoes, oranges, grapes.
• You do not have to remove thin peels or skins. Only thick peels need to be
removed, such as orange peel, pineapple skin and the skin of uncooked
beetroot.
• Pit all fruits with hard seeds or stones such as peaches, nectarines, cherries.
• When preparing apple juice, remember that the thickness of the apple juice
depends on the type of apple you are using. The juicier the apple, the thinner
the juice. Choose a type of apple that produces the type of juice you prefer.
• Apple juice turns brown very quickly. You can slow down this process by
adding a few drops of lemon juice.
• Fruits that contain starch, such as papayas, avocados, figs and mangoes,
are not suitable for processing in the juice extractor. Use a food processor or
blender to process these fruits.
• Leaves and leaf stalks of lettuce and similar leaf vegetables can also be
processed in the juice extractor.
• Drink the juice immediately after extracting it. If it is exposed to air for some
time, the juice will lose its taste and nutritional value. It may also change its
colour and texture/consistency.
• To extract the maximum amount of juice, always press the pusher down
slowly.
• The juicer is not suitable for processing very hard and/or fibrous/starchy fruit
or vegetables such as sugar cane.
CAUTION! Never insert your fingers or an object into the feeding chute.
Page 13
13
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Instructions (Cont.)
Juicing guide
Fruit / Vegetable Juicing Speed
Apples HI
Apricots: stone removed LO
Bananas: peeled HI
Beetroot (uncooked skin removed) HI
Berries (blueberries, strawberries, raspberries) LO
Capsicum: seeds removed LO
Carrots HI
Celery HI
Cherries: stones removed LO
Cucumber LO
Ginger HI
Grapes: stems removed LO
Grapefruit: peeled LO
Herbs and leaf vegetables (e.g. parsley, mint, spinach) HI
Kiwi fruit: peeled LO
Lemon: peeled LO
Lime: peeled LO
Mandarins: peeled LO
Melon (watermelon, rockmelon, honey dew): peeled LO
Oranges: peeled LO
Pears HI
Peaches/Nectarines: stones removed LO
Pineapple: peeled HI
Plums: stone removed LO
Tomatoes LO
Page 14
14
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Other Useful Information
Care and cleaning
The appliance is easier to clean if you do so immediately after use.
All detachable parts are dishwasher safe, on the top tray of the dishwasher. Make
sure they are placed well away from the heating element.
Do not use abrasive cleaning agents, scourers, acetone or alcohol-based
cleaners as they will affect the plastic and steel surfaces.
To clean the juice extractor after use, proceed as follows:
• Switch the appliance off, remove the plug from the wall socket and wait until
the filter has stopped rotating.
• Remove the soiled parts from the motor unit. Disassemble the appliance in
the following order:
• Remove the pulp container.
• Remove the pusher.
• Open the clamp.
• Remove the lid.
• Remove the juice collector together with the filter — see Fig. 10 below.
• Clean these parts with a cleaning brush in warm water with some washing-up
liquid and rinse them under the tap — see Fig. 11 below.
• Clean the motor unit with a damp cloth.
CAUTION! Never immerse the motor unit in water nor rinse it under the tap.
10 11
Page 15
15
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Other Useful Information (Cont.)
Troubleshooting guide
This chapter summarises the most common problems you could encounter with
your juice extractor. Please read the different sections for more details. If you
are unable to solve the problem, please contact our after sales support line for
advice on examination or repair.
Problem Solution
The appliance does not work. The appliance is equipped with a safety
system. It will not work if the parts have not
been assembled properly. Check whether
the parts have been assembled correctly, but
switch off the appliance before you do so.
The motor unit gives off an
unpleasant smell the first few
times the appliance is used.
This is not unusual. If the appliance continues
to give off this smell after a few times, check
(and possibly reduce) the quantities you are
processing and the processing time.
The appliance makes a lot of
noise, gives off an unpleasant
smell, is too hot to touch,
gives of smoke etc.
Switch the appliance off and unplug it. Contact
our after sales support line for assistance.
The filter is blocked. Switch the juicer off, clean the feeding chute
and the filter and process a smaller quantity.
The filter touches the feeding
chute or vibrates strongly
during processing.
Switch the appliance off and unplug it. Check
if the filter has been properly placed in the
juice collector. The ribs in the bottom of the
filter should fit properly onto the driving shaft.
Check if the filter is damaged. Cracks, a loose
grating disc or any other irregularity may cause
malfunction. In such a case, contact our after
sales support line for assistance.
Responsible disposal
At the end of its working life, do not throw this appliance out with your household
rubbish. Electrical and electronic products contain substances that can have
a detrimental effect on the environment and human health if disposed of
inappropriately. Observe any local regulations regarding the disposal of electrical
consumer goods and dispose of it appropriately for recycling. Contact your local
authorities for advice on recycling facilities in your area.
Page 16
16
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Recipes
Prepare the ingredients as suggested in the juicing guide on page 13.
Process in the order listed below. Serve immediately.
So good
Beetroot ............................1 small
Apples .............................. 2
Carrot ...............................1
Mint .................................. a few leaves
Summer memory
Watermelon .......................¼
Lemon ...............................¼
Ginger ................................1 tbsp
Mint ...................................a few leaves
Spicy carrot
Carrots ...............................4
Fennel ................................¼ head
Ginger ................................1 tbsp
Sweet and tangy
Oranges .............................2
Pineapple ...........................¼
Strawberries ..................... ½ punnet
Tropical delight
Papaya ..............................½
Watermelon .......................1 wedge
Kiwi fruit .............................1
Peach ................................1
Tomato magic
Tomatoes .......................... 3
Carrot ................................1
Celery ................................1 stalk
Parsley ...............................a few sprigs
Any time
Pineapple ......................... ½
Apples, green ...................2
Celery ............................... 1 stalk
Mint leaves ....................... a few leaves
Fruity surprise
Oranges ............................ 2
Strawberries, large ...........2
Kiwi fruit ............................ 1
Mint .................................. a few leaves
Green starter
Apples, green ...................2
Kale .................................. 2 leaves
Spinach leaves ................. a handful
Orange delight
Orange .............................. 1
Carrots ..............................2
Apple ................................ 1
Beetroot ............................1 small
Refresh
Cucumber ..........................1 large
Apple, green ......................1
Lemon ...............................¼
Mint .................................. a few leaves
Smooth juice
Orange .............................. 1
Rockmelon ....................... ½
Strawberries ..................... ½ punnet
Page 17
17
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
This page has been left blank intentionally.
Page 18
18
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
This page has been left blank intentionally.
Page 19
19
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Repair and Refurbished
Goods or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to
be returned to the supplier for repair.
Please be aware that if your product is capable of retaining user-generated data
(such as files stored on a computer hard drive, telephone numbers stored on
a mobile telephone, songs stored on a portable media player, games saved on
a games console or files stored on a USB memory stick) during the process of
repair, some or all of your stored data may be lost. We recommend you save this
data elsewhere prior to sending the product for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used
where they meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may
escalate your complaint. Please telephone us on 1300 886 649 or write to us at:
Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086
Telephone: 1300 886 649 (Aust) - Fax: (02) 9975 2688
Tempo Help Desk: 1300 886 649 (Aust)
(Operating Hours: Mon-Fri 08:30am to 06:00pm EST)
Email: info@tempo.org
Juice Extractor
YEAR WARRANTY
2
Page 20
AFTER SALES SUPPORT
1300 886 649
info@tempo.org
AUS
MODEL: JE-2 PRODUCT CODE: 91820 12/2014
Warranty returns
Should you for any reason need to return this product for
a warranty claim, make sure to include all accessories with
the product.
Product does not work?
If you encounter problems with this product, or if it fails to
perform to your expectations, make sure to contact our
After Sales Support Centre on 1300 886 649 before
returning it to the store for a refund.
Loading...
