KTM HINDLE META-SEAL METAL SEATED TRUNNION MOUNTED BALL VALVES
OperatiOn, installatiOn and Maintenance instructiOns
Before installation these instructions must be fully read and understood
1 FOREWORD
KTM Hindle design considerations have centred on reliability and safety being of principle importance to all modern process industries. The ‘Meta-Seal’ range of metal seated ball valves are designed and manufactured to withstand extremes of temperature and pressure under a wide range of chemical/ petrochemical and offshore duties. The seats are available in either carbon/metal composite material, or hard nickel fused alloy. Seals are pure graphite and the seat springs are Belleville type. All components are produced to tight tolerances and some are specially treated to withstand demanding service conditions. The excellent design features are complemented by KTM Hindle established quality assurance system, which is approved by major end users. Although it is possible to carry out on­site maintenance of this type of valve, it is recommended that the valves are serviced at:-
Emerson
Victoria Road, Leeds LS11 5UG Tel. : 44 (0) 113 2443741 Fax : 44 (0) 113 2833743 Where this is not possible, it is important that the following procedures are adopted. When ordering service spares, it is essential to specify the individual valve identification number, stamped on the body. KTM Hindle ball valves are more reliable, more intrinsically safe and have a longer service life than is commonly found amongst top quality ball valves.
2 MAIN CHARACTERISTICS
2.1 Full bore or reduced bore
Full bore valve and trim offer the following:
• Highest possible C.v. per inch of valve size,
due to it’s full opening. This can result in easier installation and lower cost when used as a control valve.
• Identical flow characteristics give dynamic
stability and reliable closing and sealing in both directions.
• Minimum flow resistance which saves on
pumping energy.
• Lends itself well to ‘pigging’ of the pipeline.
2.2 Trunnion mounting and stem/ball drive
The trunnion is an integral part of the ball, and the stem drive to the ball is positively achieved via a keyed coupling, or a drive boss. This offers the following advantages:
• No dead band or hysteresis.
• No lost motion during control.
• The positive drive makes it possible to operate
the valve when filled with highly viscous material, solids or high consistency slurries.
• Eliminates ‘camming’ action, a risk of
jamming with any design which depends on the ball moving off center towards the down stream seat when in the closed position.
• Avoids uneven wear on the stem,
ball and seats.
• Absorbs the thrust from the pressure,
preventing excess friction between the ball and seats, so even at high pressures operating torque remains low.
• Nitrox ‘P’ treated bearings give positive
support to the stem and trunnion with seals ensuring no ingress of media to bearing faces, giving longer life.
2.3 Seat design
• Seat/ball contact is designed for tangential
line contact which also assists with low torque and gives complete interchangeability.
• Pre-energized belleville disc springs ensure
leak-tight operation at low torque.
• Upstream sealing allows downstream cavity
relief. An increase of pressure within the body cavity reverses the positive action seats and
forces the seat from the ball to equalize the
pressure.
• Sealing of the seat holder is via preformed
flexible graphite seals retained with anti­extrusion rings. The proven self-lubricating properties and efficient sealing capabilities ensures prolonged, trouble free service in the most adverse environments.
• The compression ring can also incorporate
a spring protector for powder and abrasive media, which ensures free operation of the seat springs at all times.
2.4 Stem design
• The separate stem optimizes material
selection.
• Unique pressure energized primary and
secondary gland seals coupled with spring loaded non-adjustable gland means no routine maintenance is required.
Emerson.com/FinalControl © 2017 Emerson. All Rights Reserved. VCIOM-02389-EN 18/09
KTM HINDLE META-SEAL METAL SEATED TRUNNION MOUNTED BALL VALVES
OperatiOn, installatiOn and Maintenance instructiOns
3 PRE-COMMISSIONING
3.1 Replacement of valve components
Restore the paint work of any components which have been damaged in transportation.
4 INSTALLATION
4.1 Pre-installation
Ensure flange protectors on valve are removed and inspect internally to ensure the valve is
free from foreign matter. Check the valve
will operate and the position of the ball/bore alignment is correct. Ensure no external damage has occurred in transit.
Orientation
The valves referred to in this manual are bi-directional flow and therefore may be installed in the line either way round.
4.2 Installation procedure
NOTE
Ensure that the valve assembly is properly supported using adequate lifting hooks and cables where necessary.
1. Lift the valve into the installation, ensuring that the adjacent pipe flanges are aligned so that no pipe work stress is imposed upon the valve body. The valve should be lifted by the body and connector flanges, not by the actuator.
2. When the pipe work flanges are properly located, fit suitable gaskets to the flange faces and assemble flange bolting.
3. Tighten flange bolts in a diagonal sequence to ensure even compression of the gasket and equal bolt loading.
4. Leave the valve in the open position for hydrostatic test of the pipe work system before plant start up.
5. KTM Hindle actuator bracketry is designed
for valves fitted in horizontal pipe-work
with the valve stem in the vertical position. When fitted otherwise it is the end users responsibility to ensure adequate support of the actuator is given to prevent any undue stress to the valve and ensure smooth operation.
5 MAINTENANCE
5.1 Valve
Before attempting any maintenance, ensure
that the system has been depressurized and if
necessary, drain off all dangerous chemicals.
General
Ensure that the valve is properly supported, if it is required to be taken out of the line use adequate lifting hooks and cables.
5.2 Cleaning methods
1. When corrective maintenance is being carried out on the valve, care must be taken to ensure no debris grease is present in
the body housing. Clean using a degreasing
agent, in particular wipe all friction sealing contact surfaces with a clean cloth.
5.3 Routine maintenance
1. The KTM Hindle ‘Meta-Seal’ metal seated ball valve range has been designed to give long service life with little or no maintenance. Every six months the valve should be checked for correct working of main and associated components functioning.
5.4 Dismantling valve - actuator/gearbox
operated
1. Operate valve into closed position.
2. Mark orientation of actuator/gearbox mounting pedestal and valve upper cover, and remove operator. Remove the stem keys.
3. Mark orientation of the body (1) and connector (2). Mark orientation of the upper cover (3) and body.
4. Remove the upper cover nuts (27) to allow removal of the complete stem (10) and upper cover assembly. The valve coupling(17) will remain fixed to the ball. Remove coupling keys (22).
5. Remove coupling spring (20). Remove coupling retaining screw (21) followed by the coupling (17) and coupling washer (19). Remove ball keys (23).
6. Remove lower cover nuts (30).
7. Remove the lower cover (4) followed by the trunnion spring (16), trunnion bearing (15) and gasket (38).
8. Remove the connector nuts (26) and remove the connector (2).
9. Carefully remove the ball (5) and place on a
soft, non-metallic surface.
10. Remove upper cover gasket (36) and lower cover gasket (37).
11. Place a lever at the back of the seat and
loosen the compression ring (7) in both the body and the connector. (See Figure 1: Loosening the compression ring).
12. Remove seat/spring assemblies from the body and connector recesses.
13. Place the special stem tool over the
stem (10) and insert threaded bar through the tool into the top of the stem. (See Figure 2: Special stem tool).
14. Tighten nut to compress the stem spring (11). Remove the split stem retaining rings (14). Remove the special stem tool.
15. Push the stem (10) through the upper
cover(3).
