KT&C KPC-WDR4200NH Specsheet

KT&C, Inc.

Part No.: KPC-WDR4200NH

Option Color: Ivory

Key Features

• Sony 1/3’ Vertical Double-Density Interline CCD

• 550 TVL Horizontal Resolution

• WDR – Wide Dynamic Range Performance

• Intensified DSS accumulation up to X500

• Digital Day & Night

• C/CS Mount Lens (Lens Sold Separately)

• Convenient OSD (On Screen Display) Control

(English, Chinese, German, Russian, Spanish)

• BLC Compensation (Zone & Level Setting)

• Motion Detection

• Privacy Image masking up to 8 areas

• DC and AC Dual Power supply

WDR Innovative Professional Box Camera

• 550TVL Horizontal Resolution

• WDR (Wide Dynamic Range Performance

• Intensified DSS accumulation field up to X500

• Digital Day & Night

• Min Illumination of 1.0 lux @ F2.0 / 0.001 lux(DSS)

• Privacy Image masking (8 Zones)

• Motion Detection

• Convenient ODS Menu Control

• Dual Power of DC12V / AC24V

WDR (Wide Dynamic Range)

To get detail information from dark and bright combination image
without any saturation, the WDR technology is required. It combines
bright areas with high shutter speed exposure and dark areas with low
shutter speed exposure into one composite image

Super High Resolution of O TV Lines

The new advanced Sony Super
HAD CCD and DSP chipset Built­in KPC-WDR4200 provides you
the world highest horizontal
resolution up to 550 TV Lines for
color. User can expect extremely
clear and excellent visual image
quality

Conventional Camera KPC-WDR4200NH

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
777 Terrace Ave. Suite 402, Hasbrouck Heights, NJ 07604
T: 201-393-0118 F: 201-393-0116 E: [e-mail]

55

Normal BLC WDR On

DSS Technology of 0.001 lux

Digital Slow Shutter (DSS) technology enhances the low light
performance of the camera, producing outstanding images in low
light conditions. DSS slows the picture frame rate and increases
the cameras sensitivity

Conventional Camera KPC-WDR4200NH

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501, Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-WDR4200NH

Digital Day & Night

High advanced program built-in, KPC-WDR4200NH Provides true
Color Image at day time and real B/W Image at night time. Digital day
& night will enhance light sensitivity for monochrome mode and clear
picture will be delivered at lower cost.

Back Light Compensation Zone & Level

According to the various user environments, user can
position the backlight compensation zone and set levels to
optimize desired picture

BLC Off BLC On

Convenient OSD Menu

All camera operation can be controlled by OSD (On-Screen Display)
menu on the monitor screen that users can adjust this camera for
optimum setup with great convenience. This diagram shows the rear
back panel for better understanding on OSD menu controller.

General Feature Diagram

CS-Mount Adapter Ring Fixing Screw

C-Mount
Adapter Ring

Tripod Mounting Hole (1/4”-20 UNC)

Privacy Image Masking

For the privacy protection in the open
area observation, some particular area
can be masked for privacy purposes.
User can easily setup the masking
sizes and positions of the desired
zones. 8 Privacy Zone available.

Motion Detection

When user is simultaneously monitoring at the same time, KPC-4300
detects a motion of any objects on the screen and transmits alert signal
into the external alarm to have user’s attention on the screen

(Unit: mm)

Mount Cover

Auto IRIS Jack

CS-Mount Adapter Ring

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
777 Terrace Ave. Suite 402, Hasbrouck Heights, NJ 07604
T: 201-393-0118 F: 201-393-0116 E: [e-mail]

Tripod Mounting Hole (1/4”-20 UNC)

115

110

109

1 Down Button
2 Left Button
3 Up Button
4 Right Button
5 Power Led
6 Power Terminal
7 Video Out Jack

65

59

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501, Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-WDR4200NH

Technical Specification

Model KPC-WDR4200NH KPC-WDR4200PH

Signal System NTSC PAL
Image Sensor 1/3" Sony Vertical Double-Density Interline CCD
Scanning System 2:1 Interlace
Scanning Frequency (H) 15.734 KHz 15.625 KHZ
Scanning Frequency (V) 59.94 Hz 50 Hz
Total Pixels 811(H) x 508(V) 795(H) x 596(V)
Effective Pixels 768(H) x 494(V) 752(H) x 582(V)
Synchronization Internal (DC12V), Internal / Line Lock (AC24V)
Horizontal Resolution 550 TV Lines
Lens Type C/CS Mount / Video / DC / Manual Iris
S/N Ratio More than 48dB (AGC Off)
Minimum Illustration 1.0 Lux / F2.0 / 0.001 Lux at DSS
Gamma λ = 0.45
Shutter Speed 1/60 sec 1/50 sec
Video Output Level 1Vp-p Composite (75Ω), Unbalanced
Day & Night Digital Day & Night
OSD Built-in

WDR OFF / ON / AUTO (Level Adjustment)
Digital Slow Shutter

(DSS)
Digital Zoom Ratio 1.0X / 1.5X / 2.0X / 2.5X (WDR Off Mode)

OSD
Function

Operating Temperature -10 °C ~ 50 °C (14 °F ~ 122 °F)
Storage Temperature -20 °C ~ 60 °C (-4 °F ~ 140 °F)
Humidity Less than 80%RH
Power Supply
Dimensions

BLC ON / OFF (Zone & Level Adjustment)
AGC LOW / MID / HIGH
White Balance ATW / PUSH / PUSH LOCK / USER (R Gain, B Gain)
Privacy Masking 8 Zones each (Mask On / Off)
Motion Detection 6 Zones each (On / Off)
Language English, Chinese, Russian, Spanish, German

DC12 (±10%) Max 330mA / AC24 (±10%) Max 3.6W

65mm (W) X 59mm (H) X 110mm (D)/ 2.56” (W) X 2.32” (H) X 4.33” (D)

1~500 Field
