KT&C KPC-N701NUW10 Specsheet

KT&C, Inc.

Part No.: KPC-N701NU

Smart IR Outdoor Bullet Color Camera

• 700TVL Horizontal Resolution

• 45 Units of Smart IR LED with Max. 150ft

• Lens options: 2.8~12mm or 9.0~22mm

• Waterproof (IP67) with Dual Window Structure

• External Zoom & Focus Adjustable

• True Mechanical Day & Night (ICR)

• ATR / HLC / Privacy Masking / Motion Detection / Mirror

• Suitable for extreme weathe r (up to -40°F)

• Adaptive Tone-curve Reproduction (ATR)

• DC 12V / AC 24V Dual Po wer

Key Features

• 45 Units of Smart IR LED

• 1/3” 960H Interline CCD

• 700TVL Horizontal Resolution

• Outstanding Durability with IP67

• Megapixel Varifocal (2.8~12mm or 9~22 mm)

• True Mechanical Day & Night

• Fast Shutter Speed (1/60 ~ 1/10,000 sec)

• Adaptive Tone-curve Reproduction (ATR)

• Back Light Compensation (BLC)

• Highlight Compensation (HLC)

• 4 Zone (Privacy Masking / Motion Detection)

• Mirror / Brightness / Contrast / Sharpness

/ HUE / Gain

• Multilingual On Screen Display (OSD) Menu

• DC 12V / AC 24V

• Second Video Output Terminal for Easy Servicing

Superior Image Resolution of

27% more effective pixel than previous generation of high resolution camera
would bring up the quality of the image immensely. Experience the clarity of
700 TVL resolution. Ideal for discrete locations, transit industry, financial
Institutions and more. Practical choice for both indoor and outdoor
environments.

700

TV Lines

45 High Performance Smart IR LEDs

KPC-N701NU is equipped with 45 units of high performance smart
IR LEDs that adjust the IR LED’s strength so that the user can have
the best image possible regardless of the distance from the camera
to an object. This camera can cover the reliable video surveillance
up to 150 feet.

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
40 Lane Road 1
T: 973-276-0118 F: 973-276-0116 E: [e-mail]

st

Floor Fairfield, NJ 07004

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501 Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-N701NU

High Color Reproduction

KPC-N701NU is equipped with excellent color reproduction and wide
range of ATW mode.(1,800K to 10,500K)

Color Chart
Under Halogen
Lamp

Still Object under
Artificial Sunlight

Conventional 960H 700 TVL Camera

Convenient OSD Menu

All camera operation can be controlled by OSD (On-Screen Display)
menu on the monitor screen so that users can adjust this camera for
optimal setting with great convenience.

Privacy Image Masking

For the privacy protection in the open area observation, some
particular area can be masked for privacy purposes. Users can
easily setup the masking areas of the desired zones.
4 Privacy Zone available.

Motion Detection

KPC-N701NU detects a motion of any objects on the screen and
transmits alert signal into the external alarm to have user’s attention
on the screen.

2D Digital Noise Reduction (2D DNR)

The amount of low luminance noise if remarkably reduced and signal-to­noise ratio (S/N) as well as horizontal resolution dramatically improved, it
results in a clear and sharp image display even in the dark lighting
condition.

ATR(Adaptive Tone-curve Reproduction)

KPC-N701NU provides gradation compensation to improve the contrast of
subjects in both low-luminance areas and high luminance areas in the same
picture.

Outstanding Durability with IP6

With Dust and Rain Resistant Design,
this camera boasts IP67 rating that
resist dust and rain of outdoor
environment. It can be a perfect
solution for outdoor surveillance, such
as building eaves , loading docks,
factories, storage yards and so on.

7

General Feature Diagram

KT&C America, Inc.: (East)
40 Lane Road 1
T: 973-276-0118 F: 973-276-0116 E: [e-mail]

st

Floor Fairfield, NJ 07004

(Unit: mm)

* Specifications & Features are subject to change without prior notice.

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501 Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

KT&C, Inc.

Part No.: KPC-N701NU

Technical Specification

Model KPC-N701NU

Signal System NTSC PAL
Image Sensor 1/3“ 960H Interline CCD
Scanning System 2:1 Interlace
Horizontal Resolution 700TV Lines
Scanning Frequency (H) 15.734 KHz 15.625 KHZ
Scanning Frequency (V) 59.94 Hz 50 Hz
Total Pixels 1020(H) x 508(V) 1020H) x 596(V)
Effective Pixels 976(H) x 494(V) 976(H) x 582(V)
Synchronization Internal
Lens Size Megapixel Varifocal 2.8 ~12.0mm or 9 ~ 22mm
S/N More than 50dB (AGC Off)
Gamma r = 0.45
Min. Illumination 0 Lux (IR LED On)
Shutter Speed 1/60 ~ 1/10,000 sec 1/50 ~ 1/10,000 sec
IR LED Smart IR (850 nm), 45 ea, up to 50m
IR LED Operation On (1 Lux), Off (3 Lux)
Day & Night True Mechanical Day & Night (ICR)
Video Output Level 1Vp-p Composite (75Ω)
IP Rating IP67 (Waterproof)

On-Screen Display (OSD) Built-in (Inner Key / Joystick)
BLC Off / BLC / HLC
2DNR On / OFF (Level Adjustable)
ATR On / OFF (Level Adjustable)

Function

Operating Temperature

Storage Temperature -20
Dimension (mm) 78 Φ x 110.5mm
Power Supply

* Specifications & Features are subject to change without prior notice.

KT&C America, Inc.: (East)
40 Lane Road 1
T: 973-276-0118 F: 973-276-0116 E: [e-mail]

White Balance ATW / Push / User1 / User2 / Anti CR / Manual / Push-lock
Privacy Masking 4 Zones
Mirror On / Off
Motion Detection 4 Zones
Other Function Brightness / Contrast / Sharpness / HUE / Gain
Language Option English / Japanese / German / French / Russian / Portuguese / Spanish

14°F ~ 122°F (-10Ԩ ~ 50Ԩ)

Heater On : -40°F ~ 122°F (-40Ԩ ~ 50Ԩ)

C ~ 60 °C (-4 °F ~ 140 °F)

°

DC12V (±10%), Max 1.1A (IR & Heater On) / AC24V (

st

Floor Fairfield, NJ 07004

KT&C USA, Inc.: (West)
3240 Wilshire Blvd. #501 Los Angeles, CA 90010
T: 213-381-0061 / F: 213-381-0061 E: [e-mail]

±10%), Max 21W (IR & Heater On)
